AEG ASJ-01 User manual

ASJ-01
Original instructions

2
2
Important !
It is essential that you read the instructions in this manual before
assembling, operating and maintaining the product.
Subject to technical modifications.

33
1. Leg lock lever
2. Rear leg 1 - Rear leg
Fig. 1 Fig. 2
1 - Fixed clamp
2 - Sliding clamp
3 - Thumbscrew
4 - Leg lock lever
5 - Rear leg
6 - Foot lock lever
7 - Adjustable foot
8 - Feet
9 - Front legs
10 - Foot pedal
11 - Foot pedal release
12 - Front leg locks
13 - Lock/unlock latch
14 - Hand grip
123
13
14
5
4
10
11
8
9
7
6
12
1
1
2

4
4
1 - Foot pedal
1 - Rear leg
2 - Leg lock lever
1 - Adjustable foot
2 - Foot lock lever
3 - Lower lock button
4 - Upper lock button
Fig. 5
Fig. 3
Fig. 4
1
2
1
2
4
3
1
2
1
3
Fig. 6
Fig. 7
1
2
2
1 - Front legs
2 - Front leg locks
1 - Front legs
2 - Front leg lock
3 - Leg secured in place
1

55
1 - Front legs
2 - Front leg locks
1 - Thumbscrew
2 - Sliding clamp
3 - Lock/unlock latch
Fig. 8
1
2
3
3
2
4
Fig. 10
Fig. 11
Fig. 9
1
1 - Foot pedal release
2 - Foot pedal
1
5
2
2
1
2
1 - Rear leg
2 - Adjustable foot
3 - Leg storage hole
4 - Foot lock lever
5 - Leg lock lever

6
6
1 - Fixed clamp
2 - Sliding clamp
3 - Thumbscrew
Fig. 12 Fig. 15
Fig. 16
Fig. 13
Fig. 14
1 - Foot pedal
2 - Lock/unlock latch
3 - Workpiece
1
1
2
3
1 - Lock/unlock latch
1 - Rear leg
2 - Leg lock lever
1
12
3
2

77
1 - Sliding clamp in “reverse position”
2 - Tracks
Fig. 17 Fig. 19
Fig. 20
Fig. 18
1 - Workpiece
1
1
1 - Spacer
2 - Workpiece
2
1
2

8
8
1 - Clamp mechanism
Fig. 21 Fig. 23
Fig. 24
Fig. 22
1 - Leg lock lever
1 - Foot lock lever
2 - Nut
1
1 - Front clamp pad
2 - Back clamp pad
3 - Fixed clamp pad
2
1
1
3
1
2

99
WARNING! Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result in electric
shock, fire and/or serious injury. Save all warnings and instructions
for future reference.
SUPERCLAMP SAFETY WARNINGS
Know your product. Read the operator’s manual for the product and
for any tool being used with this workstation.
Do not allow familiarity with tools to make you careless. Remember
that a careless fraction of a second is suicient to inflict severe injury.
Always wear eye protection with side shields marked to comply with
AS/NZS 1337. Failure to do so could result in objects being thrown into
your eyes, resulting in possible serious injury.
Do not use any attachments or accessories not recommended by the
manufacturer of the product. The use of attachments or accessories
not recommended can result in serious personal injury.
Keep fingers, hands, and all body parts away from moving clamps.
Failure to do so could result in possible serious injury.
Stop immediately if the workpiece or product moves when operating.
Failure to do so could result in possible serious injury.
Make sure all moving parts are free from interference.
Keep hands free of all moving parts to avoid pinching and other
injuries.
Place the product on a firm, level surface where there is plenty of
room to handle and properly support the workpiece.
Make sure workpieces are properly supported.
Never perform work on the product outside the width of the front
legs. Doing so may cause the product to become unbalanced and tip.
Check that all screws and knobs are tight and legs are securely locked
before operating the product.
Do not use as a stepladder, standing platform, or scaolding support.
Stop immediately if the workpiece or the product moves when
operating.
Check to make sure the product does not rock, slide or move prior
to use.
Save these instructions. Refer to them frequently and use them to
instruct other users. If you loan someone the product, also loan these
instructions.
RESIDUAL RISKS
Even when the product is used as prescribed, it is still impossible
to completely eliminate certain residual risk factors. The following
hazards may arise and the operator should pay special attention to
avoid the following:
ŶKeep other persons away.
–Do not let persons, especially children, not involved in the
work touch the tool and keep them away from the work area.
ŶEnsure the product is set up on a firm, level ground in a stable
manner.
ŶCheck to make sure that all fixing screws and knobs are tight and
all legs are locked in place before using the tool.
ŶEnsure the workpiece is clamped firmly and the lock release
switch is in proper state before use. Unclamped workpieces can
cause severe injury and damage.
SPECIFIED CONDITIONS OF USE
The superclamp is intended to clamp wood, metal, plastics or any
other physical object, to support with other hand tools. The product is
also intended to be used on a level surface and in a dry environment.
The product is intended to be maintained by a skilled/qualified
operator following the operator’s instruction manual, and is not
intended to be used by anyone under 18 years old.
ASSEMBLY
WARNING
Do not use this product if it is not completely assembled or if any
parts appear to be missing or damaged. Use of a product that
is not properly and completely assembled or with damaged or
missing parts could result in serious personal injury.
WARNING
Do not attempt to modify this product or create accessories or
attachments not recommended for use with this product. Any such
alteration or modification is misuse and could result in a hazardous
condition leading to possible serious personal injury.
UNPACKING
Packing list
ŶSuperclamp x 1
ŶOperation manual x 1
OPERATION
SETTING UP THE PRODUCT
See Figures 1 - 8.
ŶPlace the product upside down on a flat level surface.
ŶUnlock the leg lock lever.
ŶSlide the rear leg towards the back of the product releasing it
from the storage hole.
ŶLift the leg slightly then slide the leg toward the front of the
product.
ŶRaise the leg and slide it down into place before locking the leg
lock lever.
ŶUnlock the rear foot lock lever.
ŶDepress the upper lock button to release the adjustable foot.
ŶTilt the adjustable foot until it is perpendicular to the rear leg and
push down to engage the lower lock button.
ŶLock the foot lock lever.
ŶLift the foot pedal and pull toward the front of the product until
it clicks into place.
ŶLift the right front leg and pull to the front of the product until leg
locks in place. Repeat for left leg.
NOTE: When the legs are secure, the lock levers will prevent
TECHNICAL DATA SUPERCLAMP ASJ-01
Clamping range 0 - 940 mm.
Clamping force 1 ton.
Maximum load 250 kg.
Weight 19 kg

10
10
them from folding. DO NOT use the product if the legs cannot
be secured.
ŶTurn the product over placing it upright on the ground. Recheck
that all levers are locked and all legs are secured firmly into place.
CAUTION
To reduce the risk of injury, never attempt to lift the product until
each leg has been properly secured in place.
FOLDING AND/OR CARRYING THE PRODUCT
See Figures 8 - 13.
ŶTighten the thumbscrew on the side of the sliding clamp to
secure it in place.
ŶPull the lock / unlock latch up to unlock.
ŶStep down on the foot pedal then let the pedal rise completely.
ŶTurn the product over and place it upside down on the ground.
ŶSlide the right front leg lock toward the centre of the product and
hold in place.
ŶLower the right front leg until it rests on the housing. Repeat this
process to lower the left leg.
ŶPlace a finger in the foot pedal release and pull up to unlock the
foot pedal.
ŶLower the foot pedal until it rests on the front legs.
ŶUnlock the rear foot lock lever.
ŶDepress the lower lock button to release the adjustable foot.
ŶTilt the adjustable foot until it is parallel to the rear leg and push
it toward the leg to engage the upper lock button.
ŶLock the foot lock lever.
ŶUnlock the leg lock lever.
ŶPull up on the rear leg and fold the leg toward the front of the
product.
ŶOnce the rear leg is resting on the housing, slide the rear leg
backwards and lower it onto the foot pedal.
ŶWith the rear leg resting on the foot pedal, slide the rear leg
forward into the leg storage hole.
ŶLock the leg lock lever.
NOTE: When transporting the product, the rear leg becomes the
carrying handle.
CLAMPING THE WORKPIECE
See Figure 14 - 15.
Always support the workpiece before releasing the foot pedal to
prevent the workpiece from falling o the product.
ŶLoosen the thumbscrew on the side of the sliding clamp.
ŶPlace the lock / unlock latch in the unlock position then push the
sliding clamp to open.
NOTE: When clamping long or heavy materials, always provide
proper support for the workpiece.
ŶPlace the workpiece between the fixed clamp and sliding clamp
with it balanced on the product.
ŶMove the sliding clamp until the clamp rests against the workpiece
or step repeatedly on the foot pedal to move the sliding clamp
against the workpiece. Each full stroke of the foot pedal moves
the sliding clamp approximately 13 mm.
ŶSlide the lock / unlock latch down to lock the sliding clamp against
the workpiece.
ŶStep on the foot pedal until the workpiece has been secured in
place.
NOTE: Stand on the foot pedal when extra force is needed. DO
NOT jump on the foot pedal as you could damage the product.
UNCLAMPING THE WORKPIECE
See Figure 16.
Always support the workpiece BEFORE unclamping it to prevent the
workpiece from falling o the product.
ŶPull the lock / unlock latch up to unlock.
ŶStep down on the foot pedal then let the pedal rise releasing the
force on the workpiece.
NOTE: If you have clamped the workpiece tightly, added pressure
on the foot pedal may be needed to release the workpiece from
the clamps.
ŶPush the sliding clamp toward the rear of the product then
remove the workpiece.
USING ONE SIDE OF THE CLAMP
See Figure 17.
If a large or awkward workpiece can only be clamped on one side of
the clamp, it will be necessary to use a spacer. Place a spacer the same
thickness as the workpiece on the other side of the clamp from the
workpiece to keep clamps from skewing.
CLAMPING WIDE WORKPIECES
See Figure 18 - 19.
The product can support wide workpieces. To clamp a wide workpiece
between 450 mm to 940 mm, it will be necessary to remove the clamp
pads as described in the Maintenance section and place the sliding
clamp in the “reverse position”.
ŶLoosen the thumbscrew on the side of the sliding clamp.
ŶPull the lock / unlock latch up to unlock.
ŶPush the sliding clamp toward the rear of the product and off
its tracks.
ŶTurn the clamp around (180 degrees).
ŶSlide the clamp back on the tracks.
NOTE: When clamping long or heavy materials, always provide
proper support for the workpiece.
USING AS A PRESS
See Figure 20.
With the lock / unlock latch in the unlock position and the rubber
clamp pads removed (see Maintenance section), the product can be
used as a press by stepping repeatedly on the foot pedal.
OPERATING TIPS
ŶUse the grooves in the clamp pads to securely hold material such
as tubing.
ŶThe easiest way to hacksaw square tubing is from corner to
corner rather than across the flats.
ŶSharpening a chain saw blade is made easier using two wooden
blocks on either side of the bar thus ensuring the chain can be
rotated as each tooth is filed.

11 11
MAINTENANCE
WARNING
For greater safety and reliability, all repairs should be performed by
an authorised AEG service centre.
Avoid using solvents when cleaning plastic parts. Most plastics are
susceptible to damage from various types of commercial solvents and
can be damaged by their use. Use clean cloths to remove dirt, dust,
oil, grease, etc.
Do not modify the product in any way or use accessories not
approved by the manufacturer. Your safety and that of others may
be compromised.
Before and after each use, check the product for damage or broken
parts. Keep the product in top working condition by immediately
replacing parts with spares approved by the manufacturer.
When servicing, use only identical replacement parts. Use of any other
parts may create a hazard or cause product damage.
Use only AEG accessories and AEG spare parts. Should components
need to be replaced which have not been described, please contact
one of our AEG service agents (see our list of guarantee/service
addresses).
REPLACING THE CLAMP PADS
See Figure 21.
To replace clamp pads or to remove them for greater clamping range:
To replace the clamp pad on the fixed clamp:
ŶPry off the fixed clamp pad using a flathead screwdriver.
ŶPlace a new clamp pad over the holes in the fixed clamp and press
the pad into place.
To replace the clamp pads on the sliding clamp:
ŶRemove the front and back clamp pads.
ŶPlace a new front clamp pad into the holes on the sliding clamp.
NOTE: Front clamp pad must be installed before the back clamp
pad.
ŶAlign the new back clamp pad holes over the tabs from the front
clamp pad and press the pads together.
LUBRICATING THE CLAMP MECHANISM
See Figure 22.
If the sliding clamp does not move smoothly, remove it and spray the
clamp mechanism with a small amount of general purpose grease.
ADJUSTING THE LOCK LEVERS
See Figure 23 - 24.
In the “locked” position, the action of pushing the leg lock lever or foot
lock lever down should feel tight and secure. If the levers are loose or
too tight, an adjustment may be required.
To adjust the leg lock lever:
ŶFold the product.
ŶUnlock the leg lock lever.
ŶRotate the leg lock lever clockwise to tighten and counterclockwise
to loosen.
To adjust the foot lock lever:
ŶFold the product.
ŶUnlock the leg lock lever.
ŶSlide the rear leg to the back of the product releasing it from the
storage position.
ŶLift the leg slightly then slide the leg toward the front of the
product.
ŶRaise the leg and slide it down into place before locking the leg
lock lever.
ŶUnlock the foot lock lever.
ŶUse a wrench to hold the nut in place.
ŶRotate the foot lock lever clockwise to tighten and
counterclockwise to loosen.
If needed, an exploded view of the tool can be ordered. Please state
the Article No. as well as the machine type printed on the label and
order the drawing at your local service agents or directly at:
Techtronic Industries Australia Pty Ltd
PO Box 1065
Mount Waverley VIC 3149
Tel. no. 1300 234 797
Australia
Techtronic Industries N.Z. Limited
PO Box 12-806
Penrose AUCKLAND 1642
Tel no. 0800 234 797
New Zealand
SYMBOLS
Safety alert
Please read the instructions carefully before
starting the product.
Do not reach into the gap. Beware of pinching.
Wear eye protection.
250
Do not exceed 250 kg.
Do not stand on top or use as ladder.
Do not sit on top.

Techtronic Industries Australia Pty Ltd
31 Gilby Road, Mount Waverley, VIC 3149
Melbourne, Australia
Techtronic Industries N.Z. Limited
2 Landing Drive, Mangere
Auckland, 2022, New Zealand
www.aegpowertools.com.au
www.aegpowertools.co.nz
