AEG FUSION ADT18 User manual

ALT58LI401
ALT58B
ADT18
A18FPHD142

2
2
Important!
It is essential that you read the instructions in this manual before
assembling, operating, and maintaining the product.
Subject to technical modifications.
ADT18
x 1 x 1 x 1
x 1
x 16 x 8
x 8 x 1 x 1
x 1
WARNING: To prevent personal injury or damage to underground utility equipment, consult local organisations for advice,
such as DIAL BEFORE YOU DIG (call 1100 or visit www.1100.com.au).

33
ADT18
x 1 x 1 x 1
x 1
x 16 x 8
x 8 x 1 x 1
x 1

4
4
LED INDCATOR DESCRIPTIONS
LED State Description
Status LED Solid red The kickback protection has been activated. Release the trigger, and turn on the product again
to continue digging. If the kickback protection is continuously activated, lower the auger speed.
Status LED Flashing red The overload protection has been activated. Release the trigger, and turn on the product again
to continue digging. If the kickback protection is continuously activated, lower the auger speed or
clear the auger from the hole more often.
Speed mode LED Solid green Indicates what speed the auger is spinning at.
●Speed 1 = 100 rpm
●Speed 2 = 150 rpm
●Speed 3 = 200 rpm
FWD/REV LED Solid green Indicates which direction the auger is spinning in.
A18FPHD142
x 2 x 2
x 1 x 1
x 1 x 1 x 1
x 1 x 1
x 16 x 8
x 8

55
LED INDCATOR DESCRIPTIONS
LED State Description
Status LED Solid red The kickback protection has been activated. Release the trigger, and turn on the product again
to continue digging. If the kickback protection is continuously activated, lower the auger speed.
Status LED Flashing red The overload protection has been activated. Release the trigger, and turn on the product again
to continue digging. If the kickback protection is continuously activated, lower the auger speed or
clear the auger from the hole more often.
Speed mode LED Solid green Indicates what speed the auger is spinning at.
●Speed 1 = 100 rpm
●Speed 2 = 150 rpm
●Speed 3 = 200 rpm
FWD/REV LED Solid green Indicates which direction the auger is spinning in.
A18FPHD142
x 2 x 2
x 1 x 1
x 1 x 1 x 1
x 1 x 1
x 16 x 8
x 8
TRIGGER RELEASE LED INDICATOR
SPEED SELECTOR
KICKBACK BAR
HANDLE
TRIGGER SWITCH
FORWARD/REVERSE
BUTTON
GEAR BOX
QUICK LOCK PIN
AUGER

6
6
START
STOP
13
14
STARTING THE PRODUCT
OPERATING THE PRODUCT
12
INSTALLING THE HANDLE ASSEMBLIES
INSTALLING THE BATTERIES
8

77
START
STOP
19
17
11
16 10
STORING THE PRODUCT
CLEANING THE PRODUCT
INSTALLING THE AUGER
INSTALLING THE KICKBACK BARUSING THE KICKBACK BAR

8
8
1
1
22
1
2
3
4
x 1x 16
x 8x 8
5
6
7
INSTALLING THE HANDLE ASSEMBLIES
1. Locate the frame bolts, nuts and washers, as
well as the spanner and Torx wrench.
2. Facing the LED side of the powerhead, slide
in the left-hand handle assembly and align
the bolts holes (handle without the trigger
switch).
3. Facing the LED side of the powerhead, slide
in the right-hand handle assembly and align
the bolt holes.
4. Insert the bolts through the frame holes, with
a washer on either side of the frame. Install
and hand-tighten nuts on each bolt to keep
the handles in place.
5. Securely tighten the bolts using the Torx
wrench and spanner.
6. Connect the signal cable in the right handle
assembly to the signal cable from the
powerhead. Ensure that the pins are aligned
before connecting and securing.
7. Connect the signal cable in the right
handle assembly to the signal cable from
the powerhead. Ensure that the pins are
aligned before connecting and securing.

99
1
1
22
1
2
3
4
x 1x 16
x 8x 8
5
6
7
5. Securely tighten the bolts using the Torx
wrench and spanner.
6. Connect the signal cable in the right handle
assembly to the signal cable from the
powerhead. Ensure that the pins are aligned
before connecting and securing.
7. Connect the signal cable in the right
handle assembly to the signal cable from
the powerhead. Ensure that the pins are
aligned before connecting and securing.

10
10
1
2
3
4
click
INSTALLING THE AUGER
1
2
3
INSTALLING THE KICKBACK BAR
NOTE: When attaching the auger, align the holes
on the drive shaft and auger. This is most easily
completed by laying the product on the ground.

11 11
1
2
3
4
click
INSTALLING THE AUGER
1
2
3
NOTE: When attaching the auger, align the holes
on the drive shaft and auger. This is most easily
completed by laying the product on the ground.

12
12
1
2
click
1
2
INSTALLING THE BATTERIES
NOTE: The product requires two battery packs
to operate. For best performance use two FORCE
battery packs of the same capacity.

13 13
1
2
click
1
2
START
STOP
STARTING THE PRODUCT

14
14
click
1
2
OPERATING THE PRODUCT
NOTE: Always use the product with 2 hands.
Keep the product as close to the body as
possible to prevent injury and ensure kickback
protection can be activated if required.

15 15
click
1
2
3
4
5
1
2
NOTE: The product has 3 dierent auger
speeds — 100/150/200 RPM. The multiple
speeds can be beneficial in dierent scenarios.
In rocky soil a slower speed may help in
preventing kickback issues.
NOTE: Frequently remove dirt and debris
from the hole and auger during use to improve
digging eiciency.

16
16
3
4
2
1
STOP
USING THE KICKBACK BAR
NOTE: If the kickback protection is activated,
release trigger, allow the kickback bar to go
back to its natural position, and then restart the
product to continue digging.

17 17
3
4
2
1
CLEANING THE PRODUCT
STOP

18
18
6
5
NOTE: The auger can be cleaned with water
once it has been removed from the powerhead
and moved away to a safe distance from the
powerhead.
NOTE: Do not clean the powerhead with water.
Only clean it with a dry cloth or soft brush.
3
4
2
1
STORING THE PRODUCT

19 19
6
5
3
4
2
1
STORING THE PRODUCT

20
20
6
5
NOTE: Always store the product in a cool,
dry, well ventilated area.
BATTERY AND CHARGER
Model ADT18 A18FPHD142
Battery pack — A18FB4 x 2
Charger — BL1218 x 2
Compatible battery
packs
L1815R, L1820R, L1825R, L1830R, L1840R,
L1850R, L1860R, L1850R-X5, L1860B,
L1890R, L1860R-X5
Compatible
chargers
BL1218, BLK1218, AL1218, BL18DP,
BL18DP2-X5
INTENDED USE
The cordless digging tool is intended to be used only by adults who
have read and understood the instructions and warnings in this
manual and can be considered responsible for their actions.
The product is intended only for outdoor use in a well-ventilated
area. For safety reasons, the product must be adequately controlled
by a two-handed operation.
TECHNICAL DATA CORDLESS DIGGING TOOL ADT18/A18FPHD142
Voltage 36V d.c. (2 x 18 V)
RPM
Speed 3 200+-10% / min
Speed 2 150+-10% / min
Speed 1 100+-10% / min
Weight with battery pack (no auger) 10.5 kg
Weight with auger and two battery packs 15.05 kg
Auger size 250 mm
Maximum reach 600 mm
Vibration level (in accordance with AS/NZS 62841.1:2015+A1:2015)
Vibration
Left handle 0.858 m/s2/ K= 1.5 m/s2
Right handle 1.022 m/s2/ K= 1.5 m/s2
Noise emission level (in accordance with AS/NZS 62841.1:2015+A1:2015)
A-weighted sound power level at the operator’s position 74.8 dB (A)
Uncertainty of measurement 3 dB
A-weighted sound power level 85.8 dB (A)
Uncertainty of measurement 3 dB
WARNING!
The declared vibration total values and the declared noise emission values given in this instruction manual have been measured in
accordance with a standardised test and may be used to compare one tool with another. They may be used for a preliminary assessment
of exposure
The declared vibration and noise emission values represent the main applications of the tool. However, if the tool is used for dierent
applications, used with dierent accessories, or poorly maintained, the vibration and noise emission may dier. These conditions may
significantly increase the exposure levels over the total working period.
An estimation of the level of exposure to vibration and noise should take into account the times when the tool is turned o or when it is
running idle. These conditions may significantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the eects of vibration and noise, such as maintaining the tool and the
accessories, keeping the hands warm (in case of vibration), and organising work patterns.
