AEG DGE3650HB User manual

INSTALLATION & USER MANUAL
EN User Manual
Rangehood
DGE3650HB
DGE3950HB

2
WELCOME TO AEG
LEGEND
The symbols you will see in this booklet have
these meanings:
WARNING!
This symbol indicates information concerning
your personal safety
CAUTION!
This symbol indicates information on how to avoid
damaging the rangehood
IMPORTANT!
This symbol indicates tips and information about
use of the rangehood
ENVIRONMENT!
This symbol indicates tips and information about
economical and ecological use of the rangehood
CONDITIONS OF USE
This appliance is intended to be used in household and
similar applications such as:
• Staff kitchen areas in shops, offices and other
working environments
• Farm houses
• By clients in hotels, motels and other residential
type environments
• Bed and breakfast type environments.
• Catering and similar non-retail applications
CONTENTS
3Important safety instructions
4Installation
6Operation and maintenance
7Warranty
RECORD MODEL AND SERIAL
NUMBER HERE:
Model:
Serial No:
IMPORTANT INFORMATION THAT MAY
IMPACT YOUR MANUFACTURER’S
WARRANTY
Adherence to the directions for use in this manual is
extremely important for health and safety. Failure to
strictly adhere to the requirements in this manual
may result in personal injury, property damage and
affect your ability to make a claim under the AEG
manufacturer’s warranty provided with your product.
Products must be used, installed and operated in
accordance with this manual. You may not be able
to claim on the AEG manufacturer’s warranty
in the event that your product fault is due to failure to
adhere this manual.
Thank you for purchasing a AEG appliance.
You’ve chosen a product that brings with it decades
of professional experience and innovation. Ingenious
and stylish, it has been designed with you in mind.
So whenever you use it, you can be safe in the
knowledge that you’ll get great results every time.
Welcome to AEG.

3
SAFETY INSTRUCTIONS
Please read this manual carefully prior to installing and
using the rangehood in order to avoid damage or injury.
The manufacturer will not accept liability for damage
caused from not following these instructions. If you
need assistance contact Customer Care. Please keep
the manual for future reference and pass it on to any
new owners of the appliance.
ENVIRONMENT!
Remove and discard any packaging material before
using this accessory. Most of the packaging materials are
recyclable. Please dispose of those materials through your
local recycling depot or by placing them in the appropriate
collection containers.
WARNING!
This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to ensure that they do
not play with the appliance.
Ensure the rangehood is switched off before carrying
out maintenance, to avoid any possibility of electric
shock.
Grease filters must be removed every four weeks
(maximum) for cleaning to reduce the risk of fire.
Do not flambe or have an exposed flame under the
rangehood.
This rangehood is not recommended for barbecues.
The exhaust air from the rangehood must not be
discharged into any heating flue, which may carry
combustion products from other sources.
Exhaust air must not be discharged into a wall cavity,
unless the cavity is designed for the purpose.
There must be adequate ventilation of the room
when the rangehood is used at the same time as
appliances burning gas or other fuels.
Always cover lit gas burners with pots or pans when
the rangehood is in use.
Always switch off gas burners before you remove pots
or pans.
CAUTION
Accessible parts may become hot when used with
cooking appliance.
Regulations concerning the discharge of air have to
be fulfilled.
Failure to install the screws or fixing device in
accordance with these instructions may result in
electrical hazards.
Cleaning
Wipe the rangehood body and flue with a sponge or
soft cloth soaked in warm soapy water, and dry with a
soft cloth, for stainless steel models apply a stainless
steel protector. Do not use oven cleaners or other
abrasive materials.
There is a fire risk if cleaning is not carried out in
accordance with the instructions.
Electrical Connection
Check that the mains voltage matches with the
voltage on the data plate inside the rangehood.
Check that the installation complies with standards of
local gas and electricity authorities.
If the supply cord is damaged, it must be replaced
by the manufacturer or its service agent or a similarly
qualified person in order to avoid a hazard.
Accessories
Use 150mm round exhaust ducting for best
performance.
When using flexible duct always install duct with the
wire helix pulled taut to minimise pressure loss.
Try to keep exhaust duct short and straight.
Keep bends in the exhaust duct to a minimum.
Do not restrict exhaust duct.
Reducing the size of the exhaust duct will reduce the
airflow of the rangehood. Please read instructions
carefully. Service calls resulting from incorrect
installation will be charged for.
Installation must comply in all respects with your gas and
electrical authorities. This rangehood is an indoor domestic
appliance, and has been manufactured and tested to
comply with Australian and New Zealand Standard
AS/NZS 60335.2.31
In order to avoid a hazard due to inadvertent resetting
of the thermal cut-out, this appliance must not be
supplied through an external switching device, such
as a timer, or connected to a circuit that is regularly
switched on and off by the utility.
This appliance has a 1.2m power cord and 10A plug,
ensure that the plug is accessible after installation.
Range hoods and other cooking fume extractors
may adversely affect the safe operation of appliances
burning gas or other fuels (including those in other
rooms) due to back flow of combustion gases.
These gases can potentially result in carbon monoxide
poisoning. After installation of a range hood or other
cooking fume extractor, the operation of open flued
gas appliances should be tested by a competent
person to ensure that back flow of combustion gases
does not occur.

4
INSTALLATION
Standard ducting installation
It is recommended that the unit be positioned at a
minimum of 600mm for an electric cooktop and 650mm
for a gas cooktop, and no further from the cooktop than
800mm. The unit becomes less effective as the distance
from the cooking surface to the rangehood increase.
650
GAS
ELECTRIC
600
Fixing point dimensions – DGE3650HB
Fixing point dimensions – DGE3950HB
WARNING!
Failure to install the screws or fixing device in
accordance with these instructions may result in
electrical hazards.
Parts supplied with hood
1 x Ø 150mm air outlet
2 x self tapping screws 3.5 x 12mm
Parts to be purchased
• Aluminium tape or cable ties to secure flue pipe
• Ducting accessories
Cutting the cabinet
Cut the slot in the cabinet according to the fixing
point dimension.
Fixing the air outlet
underside of
rangehood
top of cooking
surface
if the cooktop
manufacturer
specifies
a greater
clearance
then that
must be used
Use screws to fix the air outlet to the rangehood.
1 x Ø 150-120mm reducer*
454
492
254
277
150
282
457~475
260~265
Cabinet
12~23
792
744
277
250
312
150
Cabinet
762~766
257
~
263
12~23
Fixing the rangehood
Fix the rangehood to the cabinet from bottom side
untill you hear the ‘click’ sound.
ST 3.5x12
* Using Ø120mm reducer will decrease airflow of the hood

5
INSTALLATION
Fastening the fasteners
Fasten the fasteners by turning the screw clock-wise.
Fixing the flue pipe
IMPORTANT!
If using a flexible duct, always install duct with the
wire helix pulled taut to minimise pressure and noise
Ducting accessories
Fix a Ø 150mm, non-combustible, rigid flue pipe to the
exhaust transition duct using cable ties or duct tape.
Fixing a Ø 120mm flue pipe
Fix the Ø150mm to 120mm converter to the rangehood
first, then fix a Ø125mm noncombustible flue pipe to the
exhaust transition duct using cable ties or duct tape.
roof cowl
AR150RC
(AR125RC)
rigid flue pipe
AR150F
(AR125F)
flexible duct
AR150FD
(AR125FD)
flue joiner
AR125FJD
with damper
wall vent kit
AR150WV
(AR125WV)
bend
AR150FD
(AR125B)
AR610CF
For best performance Ø 150mm ducting is recommended
(Ø 125mm ducting can be used, but will reduce the
airflow of the rangehood).
Accessories can be bought from your local appliance
retailer, or in Australia at our online spare parts and
accessories store: shop.electrolux.com.au
AR150WV
(AR125WV)
Ducted recirculating installation
Optional carbon filters(AR610CF) diminish cooking odours in
the recirculated air. Depending on the frequency of use and
the type of cooking, the expected life of carbon filters is
3 months. Using carbon filters will reduce the airflow of
the rangehood.
Please install the carbon filters as following picture shows.
For DGE3650HB, turn the carbon filters clockwise,
For DGE3950HB, turn the carbon filters anti-clockwise.
Warning: Do not over
tighten screws or fascia
panel will deform.
* Using 120mm reducer will decrease airflow of the hood.

6
OPERATION & MAINTENANCE
Maintenance
WARNING!
Do not change the light bulb or carry out maintance
immediately after use as the bulb and the
rangehood maybe hot. Allow it to cool first.
Use both hands for removing and re-fitting the
filter to avoid accidentally dropping the filter
on to your cooktop or kitchen bench.
• Before maintenance or cleaning is carried out,
the rangehood should be disconnected from
the main power supply. Ensure that the rangehood
is switched off at the wall socket and the plug
removed.
• External surfaces are susceptible to scratches
and abrasions, so please follow the cleaning
instructions to ensure the best possible result is
achieved without damage.
• There is a fire risk if cleaning is not carried out
in accordance with the instructions.
•
•
i
Cleaning steel surface
Clean stainless steel surfaces using non-abrasive cleaning
products that are specifically for use on stainless steel.
To ensure best results also use an even pressure and
follow the grain of the stainless steel. Use of a soft cloth
reduces the risk of scratching. If the cloth is wet ensure
that a dry soft cloth is used to wipe down the surface
again reducing the risk of any surface rust appearing.
Cleaning
grease filters
The mesh filters can be cleaned by hand in warm soapy
water. Soak in warm water and some washing up liquid.
For stubborn grease stains use a soft nylon brush to help
remove these stains. After cleaning ensure that the filters
are completely dry before refitting.
Replacing the lamp
Take care of sharp edges during installation,
maintenance and cleaning. When the filters,
light cover or fascia panel are removed,
wear gloves for protection.
•
Suitable lamp for replacement
123 4 5
1 Lamp on/off 4 Speed 2
2Delay end 5 Speed 3
3Speed 1
Speeds
Speed 1: light frying/boiling
Speed 2: frying/wok cooking/heavy boiling
Speed 3: grilling, intensive frying and wok cooking
Turing on/off the lamp
Press button to turn on the lamp, press once again
to turn off the lamp.
Turing on/off the fan
Press any fan level button to turn on required fan level.
Press once again to turn off the fan. Or press other fan
level button to change the fan level.
Delay end
When the rangehood is working at any fan level, press
button to activate delay end function and button
will begin to flash. After 5 min, The cooker hood will be
switch off automatically. Press this button once again will
deactivate delay end function.
NOTE: Delay end function is only for the fan motor.
You need to turn off the lamp manually.
Filter check
When the motor on time reaches 50 hours, the lamp control
button will flash when the cooker hood is on. press and hold
lamp control button for 3 sec to stop the flashing and reset
the time counter.
Control operation
Ensure lamp is cool before removing.
To remove the lamp, apply pressure to the lamp and turn
anti-clockwise to unscrew and remove. Replace the lamp
with one of similar type and voltage.
Use only with self-shielded tungsten halogen lamps or
self-shielded metal halide lamps
Picture of lamp:
GU10 3.5W -> DBR-3.5-H-GU10-50/53

This document sets out the terms and conditions of the product warranties for
AEG Appliances. It is an important document. Please keep it with your proof
of purchase documents in a safe place for future reference should there be a
manufacturing defect in your Appliance. This warranty is in addition to other
rights you may have under the Australian Consumer Law.
1. In this warranty:
(a) ‘ACL’ or ‘Australian Consumer Law’ means Schedule 2 to the Competition and
Consumer Act 2010;
(b) ‘Appliance’ means any Electrolux product purchased by you and accompanied
by this document;
(c) ‘ASC’ means Electrolux’s authorised serviced centres;
(d) ‘AEG’ is the brand controlled by Electrolux Home Products Pty Ltd of 163
O’Riordan Street, Mascot NSW 2020, ABN 51 004 762 341 in respect of
Appliances purchased in Australia and Electrolux (NZ) Limited (collectively
“Electrolux”) of 3-5 Niall Burgess Road, Mount Wellington, in respect of
Appliances purchased in New Zealand;
(e) ‘Warranty Period’ means the period specified in clause 3 of this warranty;
(f) ‘you’ means the purchaser of the Appliance not having purchased the
Appliance for re-sale, and ‘your’ has a corresponding meaning.
2. Application: This warranty only applies to new Appliances, purchased and used
in Australia or New Zealand and is in addition to (and does not exclude, restrict, or
modify in any way) other rights and remedies under a law to which the Appliances
or services relate, including any non-excludable statutory guarantees in Australia
and New Zealand.
3. Warranty Period: Subject to these terms and conditions, this warranty continues
for in Australia for a period of 60 months and in New Zealand for a period of 60
months, following the date of original purchase of the Appliance.
4. Repair or replace warranty: During the Warranty Period, Electrolux or its ASC
will, at no extra charge if your Appliance is readily accessible for service, without
special equipment and subject to these terms and conditions, repair or replace
any parts which it considers to be defective. Electrolux may, in its absolute
or replacement. Electrolux or its ASC may use refurbished parts to repair your
Appliance. You agree that any replaced Appliances or parts become the property
of Electrolux.
5. Travel and transportation costs: Subject to clause 7, Electrolux will bear the
reasonable cost of transportation, travel and delivery of the Appliance to and from
Electrolux or its ASC. Travel and transportation will be arranged by Electrolux as
part of any valid warranty claim.
6. Proof of purchase is required before you can make a claim under this warranty.
7. Exclusions:You may not make aclaim under this warranty unless the defect claimed
is due to faulty or defective parts or workmanship. This warranty does not cover:
(a) light globes, batteries, filters or similar perishable parts;
(b) parts and Appliances not supplied by Electrolux;
(c)
(d) damage to the Appliance caused by:
(i) negligence or accident;
(ii) misuse or abuse, including failure to properly maintain or service;
(iii) improper, negligent or faulty servicing or repair works done by
anyone other than an Electrolux authorised repairer or ASC;
(iv) normal wear and tear;
(v) power surges, electrical storm damage or incorrect power supply;
(vi)incomplete or improper installation;
(vii) incorrect, improper or inappropriate operation;
(viii)insect or vermin infestation;
(ix) failure to comply with any additional instructions supplied with
the Appliance;
In addition, Electroluxis not liable underthis warranty if:
(a) the Appliance has been, or Electrolux reasonably believes that the Appliance
has been, used for purposes other than those for which the Appliance was
intended, including where the Appliance has
been used for any non-domesticpurpose;
(b) the Appliance is modified without authority from Electrolux in writing;
(c) the Appliance’s serial number or warranty seal has been removed
or defaced.
8. How to claim under this warranty: To enquire about claiming under this warranty,
please follow these steps:
(a) carefully check the operating instructions, user manual and the terms of
this warranty;
(b) have the model and serial number of the Appliance available;
(c) have the proof of purchase (e.g. an invoice) available;
(d) telephone the numbers shown below.
9. Australia: For Appliances and services provided by Electrolux in Australia: Electrolux
goods come with guarantees that cannot be excluded under the Australian
Consumer Law. You are entitled to a replacement or refund for a major failure and
for compensation for any other reasonably foreseeable loss or damage. You are also
entitled to have the Appliance repaired or replaced ifthe Appliance fails to be of
acceptable quality and the failure does not amount to a major failure. ‘Acceptable
quality’ and ‘major failure’ have the same meaning as referred to in the ACL.
10. New Zealand: For Appliances and services provided by Electrolux in New
Zealand, the Appliances come with a guarantee by Electrolux pursuant to the
provisions of the Consumer Guarantees Act, the Sale of Goods Act and the Fair
Trading Act. Where the Appliance was purchased in New Zealand for commercial
purposes the Consumer Guarantee Act does not apply.
11. Confidentiality: You accept that if you make a warranty claim, Electrolux and
its agents including ASC may exchange information in relation to you to enable
Electrolux to meet its obligations under this warranty.
Warranty
FOR SALES IN AUSTRALIA AND NEW ZEALAND
ALL AEG BRANDED APPLIANCES
Important Notice
Before calling for service, please ensure that the steps listed in clause 8 above have been followed.
FOR SERVICE
or to find the address of your nearest
authorised service centre in Australia
PLEASE CALL 1300 363 664
OR EMAIL
[e-mail]
For the cost of a local call (Australia only)
SERVICE AUSTRALIA
aeg.com/au
FOR SPARE PARTS
or to find the address of your nearest
spare parts centre in Australia
PLEASE CALL 13 13 50
OR EMAIL
[e-mail]
For the cost of a local call (Australia only)
FOR SERVICE
or to find the address of your nearest
authorised service centre in New Zealand
PLEASE CALL 0800 234 234
OR EMAIL [e-mail]
(New Zealand only)
SERVICE NEW ZEALAND
aegnewzealand.co.nz
FOR SPARE PARTS
or to find the address of your nearest
spare parts centre in New Zealand
PLEASE CALL 0800 10 66 20
OR EMAIL [e-mail]
(New Zealand only)
AEG_Warr_May17

www.aeg.com/au
AMAN_TAS_DGE3650HB_DGE3950HB_Jul 21
