AEG AWUS040B8B User manual

USER
MANUAL
EN User Manual
Wine Cabinet
AWUS040B8B

CONTENTS
1. SAFETY INFORMATION......................................................................................2
2. SAFETY INSTRUCTIONS.................................................................................... 4
3. INSTALLATION.....................................................................................................6
4. PRODUCT DESCRIPTION...................................................................................9
5. OPERATION.........................................................................................................9
6. DAILY USE......................................................................................................... 12
7. HINTS AND TIPS................................................................................................14
8. CARE AND CLEANING...................................................................................... 14
9. TROUBLESHOOTING........................................................................................15
10. NOISES.............................................................................................................18
11. TECHNICAL DATA........................................................................................... 18
12. INFORMATION FOR TEST INSTITUTES........................................................ 18
13. ENVIRONMENTAL CONCERNS......................................................................18
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you
impeccable performance for many years, with innovative technologies that help
make life simpler – features you might not find on ordinary appliances. Please
spend a few minutes reading to get the very best from it.
Visit our website to:
Get usage advice, brochures, trouble shooter, service and repair information:
www.aeg.com/support
Register your product for better service:
www.registeraeg.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
responsible for any injuries or damage that are the result
www.aeg.com2

of incorrect installation or usage. Always keep the
instructions in a safe and accessible location for future
reference.
1.1 Children and vulnerable people safety
•This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning the use of the appliance in a
safe way and understand the hazards involved.
•Children aged from 3 to 8 years are allowed to load
and unload the appliance provided that they have
been properly instructed.
•This appliance may be used by persons with very
extensive and complex disabilities provided that they
have been properly instructed.
•Children of less than 3 years of age should be kept
away from the appliance unless continuously
supervised.
•Children should be supervised to ensure that they do
not play with the appliance.
•Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
•Keep all packaging away from children and dispose of
it appropriately.
1.2 General Safety
•This appliance is for storing wine only.
•This appliance is designed for single household
domestic use in an indoor environment.
•This appliance may be used in, offices, hotel guest
rooms, bed & breakfast guest rooms, farm guest
houses and other similar accommodation where such
use does not exceed (average) domestic usage levels.
•WARNING: Keep ventilation openings, in the
appliance enclosure or in the built-in structure, clear of
obstruction.
ENGLISH 3

•WARNING: Do not use mechanical devices or other
means to accelerate the defrosting process, other than
those recommended by the manufacturer.
•WARNING: Do not damage the refrigerant circuit.
•WARNING: Do not use electrical appliances inside the
food storage compartments of the appliance, unless
they are of the type recommended by the
manufacturer.
•Do not use water spray and steam to clean the
appliance.
•Clean the appliance with a moist soft cloth. Only use
neutral detergents. Do not use abrasive products,
abrasive cleaning pads, solvents or metal objects.
•When the appliance is empty for long period, switch it
off, defrost, clean, dry and leave the door open to
prevent mould from developing within the appliance.
•Do not store explosive substances such as aerosol
cans with a flammable propellant in this appliance.
•If the supply cord is damaged, it must be replaced by
the manufacturer, its Authorised Service Centre or
similarly qualified persons in order to avoid a hazard.
2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must
install this appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Do not use the appliance before
installing it in the built-in structure due
to safety manner.
• Follow the installation instructions
supplied with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Make sure the air can circulate
around the appliance.
• At first installation or after reversing
the door wait at least 4 hours before
connecting the appliance to the power
supply. This is to allow the oil to flow
back in the compressor.
• Before carrying out any operations on
the appliance (e.g. reversing the
door), remove the plug from the
power socket.
• Do not install the appliance close to
radiators or cookers, ovens or hobs.
• Do not expose the appliance to the
rain.
• Do not install the appliance where
there is direct sunlight.
• Do not install this appliance in areas
that are too humid or too cold.
• When you move the appliance, lift it
by the front edge to avoid scratching
the floor.
www.aeg.com4

2.2 Electrical connection
WARNING!
Risk of fire and electric
shock.
WARNING!
When positioning the
appliance, ensure the supply
cord is not trapped or
damaged.
WARNING!
Do not use multi-plug
adapters and extension
cables.
• The appliance must be earthed.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Always use a correctly installed
shockproof socket.
• Make sure not to cause damage to
the electrical components (e.g. mains
plug, mains cable, compressor).
Contact the Authorised Service
Centre or an electrician to change the
electrical components.
• The mains cable must stay below the
level of the mains plug.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
2.3 Use
WARNING!
Risk of injury, burns, electric
shock or fire.
The appliance contains flammable
gas, isobutane (R600a), a natural gas
with a high level of environmental
compatibility. Be careful not to cause
damage to the refrigerant circuit
containing isobutane.
• Do not change the specification of this
appliance.
• Any use of the built-in product as free-
standing is strictly prohibited.
• Do not put electrical appliances (e.g.
ice cream makers) in the appliance
unless they are stated applicable by
the manufacturer.
• If damage occurs to the refrigerant
circuit, make sure that there are no
flames and sources of ignition in the
room. Ventilate the room.
• Do not let hot items to touch the
plastic parts of the appliance.
• Do not store flammable gas and liquid
in the appliance.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
• Do not touch the compressor or the
condenser. They are hot.
2.4 Internal lighting
WARNING!
Risk of electric shock.
• This product contains one or more
light sources of energy efficiency
class E.
• Concerning the lamp(s) inside this
product and spare part lamps sold
separately: These lamps are intended
to withstand extreme physical
conditions in household appliances,
such as temperature, vibration,
humidity, or are intended to signal
information about the operational
status of the appliance. They are not
intended to be used in other
applications and are not suitable for
household room illumination.
2.5 Care and cleaning
WARNING!
Risk of injury or damage to
the appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains
plug from the mains socket.
• This appliance contains hydrocarbons
in the cooling unit. Only a qualified
person must do the maintenance and
the recharging of the unit.
ENGLISH 5

• Regularly examine the drain of the
appliance and if necessary, clean it. If
the drain is blocked, defrosted water
collects in the bottom of the
appliance.
2.6 Service
• To repair the appliance contact the
Authorised Service Centre. Use
original spare parts only.
• Please note that self-repair or non-
professional repair can have safety
consequences and might void the
guarantee.
• The following spare parts will be
available for 7 years after the model
has been discontinued: thermostats,
temperature sensors, printed circuit
boards, light sources, door handles,
door hinges, trays and baskets.
Please note that some of these spare
parts are only available to
professional repairers, and that not all
spare parts are relevant for all
models.
• Door gaskets will be available for 10
years after the model has been
discontinued.
2.7 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains cable and discard it.
• Remove the door to prevent children
and pets to be closed inside of the
appliance.
• The refrigerant circuit and the
insulation materials of this appliance
are ozone-friendly.
• The insulation foam contains
flammable gas. Contact your
municipal authority for information on
how to discard the appliance
correctly.
• Do not cause damage to the part of
the cooling unit that is near the heat
exchanger.
3. INSTALLATION
WARNING!
Refer to Safety chapters.
3.1 Dimensions
H1
H2
D3
W3
90°
D2
W2
D1
W1
www.aeg.com6

Overall dimensions ¹
H1 mm 818
W1 mm 595
D1 mm 577
¹ the height, width and depth of the
appliance without the handle
Space required in use ²
H2 mm 820
W2 mm 600
D2 mm 580
² the height, width and depth of the
appliance including the handle, plus the
space necessary for free circulation of
the cooling air
Overall space required in use ³
H2 mm 820
W3 mm 600
D3 mm 1162
³ the height, width and depth of the
appliance including the handle, plus the
space necessary for free circulation of
the cooling air, plus the space necessary
to allow door opening to the minimum
angle permitting removal of all internal
equipment
3.2 Location
To ensure appliance's best functionality,
you should not install the appliance in the
nearby of the heat source (oven, stoves,
radiators, cookers or hobs) or in a place
with direct sunlight. Make sure that air
can circulate freely around the back of
the cabinet.
This appliance should be installed in a
dry, well ventilated indoor position.
This appliance is intended to be used at
ambient temperature ranging from 10°C
to 38°C.
The correct operation of the
appliance can only be
guaranteed within the
specified temperature range.
If you have any doubts
regarding where to install the
appliance, please turn to the
vendor, to our customer
service or to the nearest
Authorised Service Centre.
It must be possible to
disconnect the appliance
from the mains power
supply. The plug must
therefore be easily
accessible after installation.
3.3 Electrical Connection
CAUTION!
Any electrical work required
to install this appliance
should be carried out by a
qualified electrician or
competent person.
WARNING!
This appliance must be
earthed.
The manufacturer declines
any liability should these
safety measures not be
observed.
The wires in the mains lead are coloured
in accordance with the following code:
A B
C
D
E
•A - green and yellow: Earth
ENGLISH 7

•C - brown: Live
•D - blue: Neutral
As the colours of the wires in the mains
lead of this appliance may not
correspond with the coloured markings
identifying the terminals in your plug,
proceed as follows:
1. Connect the wire coloured green and
yellow to the terminal marked either
with the letter “E“ or by the earth
symbol or coloured green and
yellow.
2. Connect the wire coloured blue to the
terminal either marked with the letter
“N“ or coloured black.
3. Connect the wire coloured brown to
the terminal either marked with the
“L“ or coloured red.
4. Check that no cut, or stray strands of
wire is present and the cord clamp
(E) is secure over the outer sheath.
Make sure the electricity supply
voltage is the same as that indicated
on the appliance rating plate.
5. Switch on the appliance.
The appliance is supplied with a 13 amp
fuse (B). In the event of having to
change the fuse in the plug supplied, a
13 amp ASTA approved (BS 1362) fuse
must be used.
WARNING!
A cut off plug inserted into a
13 amp socket is a serious
safety (shock) hazard.
Ensure that it is disposed of
safely.
3.4 Levelling
When placing the appliance make sure
that it stands level. This can be achieved
by four adjustable feet at the bottom of
the appliance.
3.5 Door reversibility
Please refer to the separate document
with instructions on installation and door
reversal.
CAUTION!
At every stage of reversing
the door protect the floor
from scratching with a
durable material.
www.aeg.com8

4. PRODUCT DESCRIPTION
4.1 Product overview
1
2
3
4
65
7
8
1Control panel
2Shelf
3Foot
4Decorative frame
5Tempered glass door
6Handle
7Gasket
8Air filter
5. OPERATION
WARNING!
Do not spill any liquids on
the control panel. This may
damage the equipment and
increase the risk of electric
shock.
5.1 Control panel
1 2 3 4 5
1Cellar Mode key
2Display
3Temperature decrease key
4Temperature increase key
5Light key
ENGLISH 9

5.2 Display
A B
C
D
A. Alarm indicator
B. Filter reset indicator
C. Temperature indicator
D. Child lock indicator
5.3 Switching on and off
To switch on the appliance:
1. Insert the plug into the wall socket.
2. Go to the right side of the control
panel.
3. Tap and hold the Temperature
decrease key and Light key for 3
seconds if the display is off.
4. The display shows the default set
temperature (12°C).
To switch off the appliance, repeat the
above procedure in reverse order.
To select a different temperature, refer to
the "Temperature regulation" section.
5.4 Temperature regulation
The default set temperature
for the wine cabinet is 12°C.
The temperature can be
adjusted between +5 and
+20°C.
To set the temperature, tap the
temperature increase or decrease key for
the compartment:
• Single tap shows the current set
temperature.
• Second tap increases or decreases
the temperature by one degree.
• To speed up the selection, tap and
hold the temperature increase or
decrease key until you reach the
desired temperature.
By default, the temperature
digits show the current
temperature at half
brightness. When you tap
once or start selecting a new
setting, the displayed digits
blink. After 3 seconds
without tapping the keys, the
digits stop blinking and the
current temperature is
displayed.
To set the right temperature for each
type of wine, refer to the "Daily use"
chapter.
5.5 Light setup
Tap the Light key once to turn the light
on or off. The default light setting is 1A
for the light behaviour and 9L for the light
brightness.
The light has no negative
effect on the quality of wine.
You may adjust behaviour and
brightness of the light.
Light behaviour (A):
•1A door open - lights on at the highest
dimming level, door closed - lights
turn off
•2A door open - lights on at the highest
dimming level, door closed - lights on
at the selected dimming level
•3A door open and closed - lights on at
the selected dimming level
•4A door open - lights on at the
selected dimming level, door closed -
lights on at the highest dimming level
www.aeg.com10

Light brightness (L):
•9L is the brightest setting while 1L is
the dimmest one.
To set the light behaviour or brightness:
1. Tap and hold the Light key for 3
seconds to enter the light setting
menu.
2. Light behaviour A appears. Tap the
Light key again to go to the light
brightness L.
3. Tap the temperature regulators
repeatedly to set the desired light
behaviour or brightness.
5.6 Cellaring
In this mode, the appliance switches to
the preset default temperature of 12°C.
To activate the Cellaring mode, tap the
Cellar Mode key. CE on the display starts
blinking. Wait 5 seconds. The mode is
active when CE stops blinking and is lit
at half brightness.
To deactivate the Cellaring mode, tap
Cellar Mode once again.
5.7 Child Lock mode
Activate the Child Lock mode to lock the
keys from an unintentional operation.
To activate the Child Lock, tap and hold
the Cellar Mode key for 3 seconds.
When the mode is on, the lock indicator
lights up at full brightness. After 3
seconds, the lock indicator dims to half
brightness.
If you press any key other
than Cellar Mode, the lock
indicator blinks three times.
To deactivate the Child Lock mode, tap
the corresponding key again.
The Child Lock mode
deactivates after electricity
interruption or unplugging
the appliance.
5.8 Reset air filter
To reset the air filter alarm:
1. Change the carbon air filter. Refer to
the "Replacing air filter" section.
2. Tap and hold the Temperature
increase and Light keys
simultaneously for 5 seconds.
3. The filter indicator turns off for the
next 6 months.
After 6 months, the display
shows the filter indicator to
remind you to replace filter.
5.9 Mute or unmute sounds
The sounds are enabled by default.
To mute or unmute the sounds:
1. Tap and hold the Cellar Mode and
Temperature increase keys
simultaneously for 5 seconds.
2. The display shows Of for 2 seconds
when the sounds are muted, or On
for 2 seconds when the sounds are
unmuted.
5.10 Changing temperature
units
To switch the temperature units between
°C and °F:
1. Tap simultaneously the Cellar Mode
and Temperature decrease keys.
2. Once you set your preferable unit, °C
or °F blinks on the display for 5
seconds.
5.11 Demo mode
Activate the Demo mode to demonstrate
the appliance's features.
To activate the Demo mode, tap and
hold the Light and Cellar Mode keys
simultaneously for 10 seconds.
Once the mode is on, the display shows
dE and On blinking alternately for 5
seconds.
The above message is displayed every 5
minutes to remind you that the appliance
is in the Demo mode.
To deactivate the Demo mode, repeat
the above procedure.
Once you deactivate the mode, the
display shows dE and Of blinking
alternately for 5 seconds.
ENGLISH 11

5.12 High and low
temperature alarm
High temperature alarm
The alarm goes off when the
compartment's temperature is 5°C higher
than the set temperature for more than
60 minutes.
During the alarm:
• the display shows Hº
• the alarm indicator flashes
Low temperature alarm
The alarm goes off when the
compartment's temperature is 2°C lower
than the set temperature for more than
60 minutes.
During the alarm:
• the display shows Lº
• the alarm indicator flashes
Press any key on the control panel to
turn off the alarm.
• If the appliance adjusted the
temperature automatically, the normal
display restores. Check if the wine
inside is not spoiled.
• If the temperature is still too high or
too low, the alarm goes off again after
60 minutes.
The alarm does not go off
within the first 90 minutes
after switching on the
appliance.
5.13 Door open alarm
If the door is left open for approximately
5 minutes, the lights start to flash and
display shows alternately dr and OP.
After 2 more minutes the sound is on.
The alarm stops after closing the door or
after pressing any key on the control
panel.
The alarm goes off again
after 5 minutes if the door is
still open.
6. DAILY USE
6.1 Wine storage
This appliance is intended to
be used exclusively for the
storage of wine.
Wine storage compartment
is the one marked (on the
rating plate) with .
The storage time for wine depends on
age, alcoholic content, type of grapes
and level of fructose and tannin in it. At
the time of purchase, check if the wine is
already aged or if it will improve over
time.
Recommended storage temperatures:
• For champagne and sparkling wines,
between +6°C and +8°C.
• For white wines, between +10°C and
+12°C.
• For rose and light red wines, between
+12°C and +16°C.
• Aged red wines, between +14°C and
+18°C.
The appliance is designed to store up to
40 bordeaux bottles (0.75 l) by placing:
• 5 bottles on level 1,
• 7 bottles on level 2,3,4,5,6,
• Shelf levels
1
2
3
5
4
6
www.aeg.com12

Full shelf levels 2,3,4,5,6
6.2 Removing and installing
shelves
Removing shelves
To remove the shelf:
1. Open the wine cabinet door
completely.
2. Pull the shelf out.
3. Grab the shelf in the middle, lift it up
slightly and take it out of the wine
cabinet.
Installing shelves
To put the shelf back into its initial
position:
1. Pull out the shelf's rails completely.
2. Position the shelf's rear mounts on
the rails, so they are engaged on
both sides.
3. Align the guides in the front.
4. Press the back of the shelf down
firmly to check if it is placed and
engaged correctly on the rails and
push it back into the appliance.
CAUTION!
Before placing any wine
bottles on the shelves, make
sure they are properly
engaged on the rails.
Check for the possible wrong shelf
positioning:
ENGLISH 13

Use the wooden shelves
only to store bottles.
6.3 Replacing air filter
Your appliance is equipped with the air
carbon filter located next to the control
panel. Refer to the "Product description"
chapter.
The filter purifies air from unwanted
odours in the wine cabinet, improving the
storage quality.
To replace the air filter:
1. Locate the filter and detach it from
the appliance. Remove its cover.
2. Remove the old filter.
3. Take out the new filter from the
plastic bag.
4. Insert the new filter ensuring the side
with the text is facing upward.
5. Put the filter cover back and install it
back into the appliance.
6. Go to the control panel and reset the
filter to deactivate the alarm. Refer to
the "Reset air filter" section.
To get the best performance, the filter
should be changed every 6 months. New
active filter can be purchased from your
local dealer or through the website. The
part number is printed on the plastic bag.
7. HINTS AND TIPS
7.1 Hints for energy saving
• The internal configuration of the
appliance is the one that ensures the
most efficient use of energy.
• Do not open the door frequently or
leave it open longer than necessary.
• Ensure a good ventilation. Do not
cover the ventilation grilles or holes.
8. CARE AND CLEANING
WARNING!
Refer to Safety chapters.
www.aeg.com14

8.1 General warnings
CAUTION!
Unplug the appliance before
carrying out any
maintenance operation.
This appliance contains
hydrocarbons in its cooling
unit; maintenance and
recharging must therefore
only be carried out by
authorized technicians.
The accessories and parts of
the appliance are not
suitable for washing in a
dishwasher.
8.2 Cleaning the interior
Before using the appliance for the first
time, the interior and all internal
accessories should be washed with
lukewarm water and some neutral soap
to remove the typical smell of a brand-
new product, then dried thoroughly.
CAUTION!
Do not use detergents,
abrasive powders, chlorine
or oil-based cleaners as they
will damage the finish.
8.3 Periodic cleaning
The equipment has to be cleaned
regularly:
1. Clean the inside with lukewarm water
and baking soda solution. The
solution should be about 2
tablespoons of baking soda to a litre
of water.
2. Wring excess water out of sponge or
cloth when cleaning the area of the
controls, or any electrical parts.
3. Clean the outside of the appliance
with warm water and some neutral
soap.
4. Regularly check the door seals and
wipe them clean to ensure they are
clean and free from debris.
5. Rinse and dry thoroughly.
8.4 Cleaning the drain
Periodically clean the drain hole to
prevent water from overflowing and
dripping onto the stored bottles. The
drain hole is located on the rear wall in
the lower left part of the appliance. To
reach it more easily, slightly press the
covering grid.
For this purpose, use a thin, plastic, non-
sharp stick.
1
2
3
8.5 Periods of non-operation
When the appliance is not in use for long
periods, take the following precautions:
1. Disconnect the appliance from
electricity supply.
2. Remove all items.
3. Clean the appliance and all
accessories.
4. Leave the door open to prevent
unpleasant smells.
When the appliance is not in use due to
power failure:
• Most power failures are corrected
within a few hours and don't affect the
temperature of your appliance if you
minimize the door opening.
• If the power is going to be off for a
longer time, you need to take the
proper steps described above.
9. TROUBLESHOOTING
WARNING!
Refer to Safety chapters.
ENGLISH 15

9.1 What to do if...
Problem Possible cause Solution
The appliance does not op‐
erate.
The appliance is switched
off.
Switch on the appliance.
The mains plug is not con‐
nected to the mains socket
correctly.
Connect the mains plug to the
mains socket correctly.
There is no voltage in the
mains socket.
Connect a different electrical
appliance to the mains socket,
to check if electricity is flowing.
If not, contact a qualified elec‐
trician.
The circuit breaker tripped
or a blown fuse.
Turn on the circuit breaker or
change the fuse.
The compressor operates
continually.
Temperature is set incor‐
rectly.
Refer to the "Operation" chap‐
ter.
The room temperature is
too high.
Refer to the "Installation"
chapter.
The door is opened too of‐
ten.
Do not keep the door open
longer than necessary.
The door is not closed cor‐
rectly.
Refer to the "Closing the door"
section.
The light does not work. The light is turned off. Turn on the light. Refer to the
"Light setup" section.
The appliance is not plug‐
ged in.
Connect the appliance.
The circuit breaker tripped
or a blown fuse.
Turn on the circuit breaker or
change the fuse.
The lamp is defective. Contact the service.
The light button is not op‐
erating.
Contact the service.
Too much vibration. The appliance is not sup‐
ported properly.
Check if the appliance stands
stable.
The appliance is noisy. The appliance is not sup‐
ported properly.
Check if the appliance stands
stable.
Water flows on the rear plate
of the appliance.
During the automatic de‐
frosting process, frost
melts on the rear plate.
This is correct.
www.aeg.com16

Problem Possible cause Solution
Water flows inside the wine
cabinet.
The appliance drain is
clogged.
Clean the appliance drain
hole. Refer to the "Cleaning
the drain" section.
Water flows inside the wine
cabinet.
Products prevent that wa‐
ter flows into the water col‐
lector.
Make sure that products do
not touch the rear plate.
The temperature in the wine
cabinet is too low or too
high.
The temperature regulator
is not set correctly.
Set a higher or lower tempera‐
ture.
The door is not closed cor‐
rectly.
Refer to the "Closing the door"
section.
If the advice does not lead to
the desired result, call the
nearest brand-mark service.
9.2 Replacing the lamp
The appliance is equipped with a longlife
LED interior light.
Only service is allowed to replace the
lighting device. Contact your Authorised
Service Centre.
9.3 Closing the door
1. Clean the door gaskets.
2. If necessary, adjust the door. Refer
to the "Installation" chapter.
3. If necessary, replace the defective
door gaskets. Contact the Authorised
Service Centre.
ENGLISH 17

10. NOISES
SSSRRR!
CLICK!
HISSS!
BRRR!
BLUBB!
11. TECHNICAL DATA
The technical information is situated in
the rating plate on the internal side of the
appliance and on the energy label.
The QR code on the energy label
supplied with the appliance provides a
web link to the information related to the
performance of the appliance. Keep the
energy label for reference together with
the user manual and all other documents
provided with this appliance.
12. INFORMATION FOR TEST INSTITUTES
Installation and preparation of the
appliance for any EcoDesign verification
shall be compliant with BS EN 62552.
Ventilation requirements, recess
dimensions and minimum rear
clearances shall be as stated in this User
Manual at Chapter 3. Please contact the
manufacturer for any other further
information, including loading plans.
13. ENVIRONMENTAL CONCERNS
Recycle materials with the symbol .
Put the packaging in relevant containers
to recycle it. Help protect the
environment and human health by
recycling waste of electrical and
electronic appliances. Do not dispose of
appliances marked with the symbol
with the household waste. Return the
product to your local recycling facility or
contact your municipal office.
*
www.aeg.com18

www.aeg.com/shop
212002793-8121006-01
