Aeronaut Triple Neo Series User manual

aero
naut
TripleNeospeed
r.e.s.
thermic

Most wood parts of this kit are laser-cut and numbered. The included stripwood can be identified
using the parts list at the end of this manual. Use a sharp modeller´s knife to remove parts from
laser-cut sheets. Use sandpaper to remove residue resulting from the laser-cutting process as well
as retaining tabs to achieve a good surface for gluing.
Always check that parts fit perfectly and correct, if necessary, before you glue. Give glue sufficient
time to dry or cure, before your proceed to the next step.
Construction should be according to the step-by-step instructions provided in this manual.
Remove only those parts from the laser sheets which are required for the current building step.
We recommend white glue (if not otherwise noted) for gluing, which offers good strength and
low weight. White glue retains a certain degree of elasticity after the glue has cured and will stand
up to any loads which occur during flying.
Technical Data TRIPLE speed TRIPLE R.E.S. TRIPLE thermic
Order-No.: 1128/03 1128/04 1128/05
Wingspan: 1.810 mm 1.930 mm 2.580 mm
Length: 1.200 mm 1.200 mm 1.200 mm
Wing area: ca. 29,5 dm² ca. 36,3 dm² ca. 47 dm²
Weight: ca. 840 g ca. 870 g ca. 980 g
RC-functions: ESC (opt.) ESC (opt.) ESC (opt.)
elevator/rudder elevator/rudder elevator/rudder
ailerons spoilers airlerons
spoilers
TripleNeospeed
r.e.s.
thermic
Tips & Notes
Building sections
For construction we recommend
our aero-pick modeller´s pins.
Order.-No. 7855/02
Please use recommended glue.
i
Attention! Please follow building
instructions precisely.
Note! Additional information for
current building step.
Carefully sand off retaining tabs
for good results.
To avoid damage to parts, use a
sharp modeller´s knife to cut
individual parts from laser sheets.
Recommended glues
Material Glue (Order-No.)
wood/wood Ponal Express (7638/10), UHU hart (7631/02)
wood/metal UHU Plus sofortfest (7633/07)
Electric power
Motor Ø 28-mm-outrunner, from ca. W 150
ESC from 20 A
Battery 3S-LiPo, up to ca. 2.500 mAh
Recommend components for electric power
CAMcarbon folding prop* 9×5“ to 12×7“
prop adapter* motor shaft 3,00 mm Order-No. 7124/23
3,17 mm 7124/37motor shaft Order-No.
4,00 mm 7124/04motor shaft Order-No.
Recommended RC components
servo for tail unit + ailerons, up to 11,5 mm wide
servo for spoiler, up to 10 mm wide
Fuselage + tail unit
Triple SPEED
Triple R.E.S.
Triple thermic
Wing centre section
Please identify and read thoroughly the
sections relevant for you model version.
* compare with data sheet of your motor
We recommend our balsa-ply building boards for wing
construction.
Our building boards are made up of several layers of balsa
which make it easy to position and fix model parts using aero-
pick modeller´s pins.
size ca. 400 x 1.500 mm
thickness: 25 mm
Order-No. 7506/77
We recommend aero-pick modeller´s pins for
construction. Design and material of aero-pick
pins have been chosen with the modeller in
mind.
VE = 20 pcs.
Order-No. 7506/77
CAMcarbon folding props
For decades aero-naut has been one of the leading companies regarding design and production of highly efficient folding props. Model
aeroplane pilots all over the world rely on CAMcarbon folding props!
CAMcarbon blade design is synonymous with precision and efficiency. Our prop blades are produced using a mixure of carbon fibres
and nylon which offers a high degree of strength and torsion-resistance.
For electric power:
For successful construction
Accesories for your model aeroplane:
Tipp
The top selling
folding props

Most wood parts of this kit are laser-cut and numbered. The included stripwood can be identified
using the parts list at the end of this manual. Use a sharp modeller´s knife to remove parts from
laser-cut sheets. Use sandpaper to remove residue resulting from the laser-cutting process as well
as retaining tabs to achieve a good surface for gluing.
Always check that parts fit perfectly and correct, if necessary, before you glue. Give glue sufficient
time to dry or cure, before your proceed to the next step.
Construction should be according to the step-by-step instructions provided in this manual.
Remove only those parts from the laser sheets which are required for the current building step.
We recommend white glue (if not otherwise noted) for gluing, which offers good strength and
low weight. White glue retains a certain degree of elasticity after the glue has cured and will stand
up to any loads which occur during flying.
Technical Data TRIPLE speed TRIPLE R.E.S. TRIPLE thermic
Order-No.: 1128/03 1128/04 1128/05
Wingspan: 1.810 mm 1.930 mm 2.580 mm
Length: 1.200 mm 1.200 mm 1.200 mm
Wing area: ca. 29,5 dm² ca. 36,3 dm² ca. 47 dm²
Weight: ca. 840 g ca. 870 g ca. 980 g
RC-functions: ESC (opt.) ESC (opt.) ESC (opt.)
elevator/rudder elevator/rudder elevator/rudder
ailerons spoilers airlerons
spoilers
TripleNeospeed
r.e.s.
thermic
Tips & Notes
Building sections
For construction we recommend
our aero-pick modeller´s pins.
Order.-No. 7855/02
Please use recommended glue.
i
Attention! Please follow building
instructions precisely.
Note! Additional information for
current building step.
Carefully sand off retaining tabs
for good results.
To avoid damage to parts, use a
sharp modeller´s knife to cut
individual parts from laser sheets.
Recommended glues
Material Glue (Order-No.)
wood/wood Ponal Express (7638/10), UHU hart (7631/02)
wood/metal UHU Plus sofortfest (7633/07)
Electric power
Motor Ø 28-mm-outrunner, from ca. W 150
ESC from 20 A
Battery 3S-LiPo, up to ca. 2.500 mAh
Recommend components for electric power
CAMcarbon folding prop* 9×5“ to 12×7“
prop adapter* motor shaft 3,00 mm Order-No. 7124/23
3,17 mm 7124/37motor shaft Order-No.
4,00 mm 7124/04motor shaft Order-No.
Recommended RC components
servo for tail unit + ailerons, up to 11,5 mm wide
servo for spoiler, up to 10 mm wide
Fuselage + tail unit
Triple SPEED
Triple R.E.S.
Triple thermic
Wing centre section
Please identify and read thoroughly the
sections relevant for you model version.
* compare with data sheet of your motor
We recommend our balsa-ply building boards for wing
construction.
Our building boards are made up of several layers of balsa
which make it easy to position and fix model parts using aero-
pick modeller´s pins.
size ca. 400 x 1.500 mm
thickness: 25 mm
Order-No. 7506/77
We recommend aero-pick modeller´s pins for
construction. Design and material of aero-pick
pins have been chosen with the modeller in
mind.
VE = 20 pcs.
Order-No. 7506/77
CAMcarbon folding props
For decades aero-naut has been one of the leading companies regarding design and production of highly efficient folding props. Model
aeroplane pilots all over the world rely on CAMcarbon folding props!
CAMcarbon blade design is synonymous with precision and efficiency. Our prop blades are produced using a mixure of carbon fibres
and nylon which offers a high degree of strength and torsion-resistance.
For electric power:
For successful construction
Accesories for your model aeroplane:
Tipp
The top selling
folding props

i
S1 S2
S3
S4
R2
S6
S5
R1
Bring fuselage in a vertical position and glue motor mount in place.
Make sure installation tool S7 is positioned correctly on the fuselage as
shown.
Please note that there is a small gap between motor mount R2 and the
fuselage. This is necessary for the motor mount to be positioned
correctly.
Tack-glue the motor mount in place with four drops of epoxy applied
through the openings in S7.
Do not apply glue to completely glue the motor mount
in place!
4
5
6
To complete the next building step you will need the collet prop adapter which is available as an accessory.
Make sure the prop adapter fits the prop shaft of your motor (for Order-No. see page 2).
Remove installing tool S7 when epoxy glue has cured. Assemble the collet adapter with prop hub yoke and
temporarily install the motor into the fuselage. Install collet adapter on motor shaft and tighten nut with
your fingers.
Install spinner R5 onto prop adapter using two washers R7 for correct spacing, insert and tighten screw R6. Check spinner for correct
position in relation to fuselage. Correct, if necessary.
When spinner position is correct, disassemble/remove installed parts and glue motor mount in place with epoxy resin mixed with cotton
flocks or chopped glass fibre strands. Leave to cure.
R3
R4
R5
R6
R7
Fuselage
Install motor mount R2 using screw S6, spacers S5, installation tool
S7 and nut S8.
Slide motor mount R2 and spacers S5 onto screw S6 and install in
fuselage through cockpit opening.
From the outside slide installation tool S7 and nut S8 onto screw.
Then tighten nut with your fingers.
To use electric power in your Triple Neo the nose of the fuselage
needs to be cut off with the help of a template. For the glider version
skip building steps 1-6.
Glue together fuselage template from parts S1-S4. Leave to dry.
Slide fuselage R0 into template as shown. Please note that there is a
small bump on the underside of the fuselage which fits into template
exactly.
Run a sharp knife around the fuselage as shown to mark the cut-off
line.
Remove the template and cut off the nose with a razor saw. For best
results rotate the fuselage while you saw.
2
1
S7
S8
S7
3
7
8
Glue in place brass tube R9 together with former R8 in
fuselage. Trial-fit R8 before you glue and - if necessary -
correct contour of former to fit fuselage.
Fit and glue in place four magnets R23.
Attention: Make sure you check polarity of magnets if you
have already built a set of wings for your Triple.
Use epoxy glue mixed with cotton flocks for gluing.
Glue in place servo tray R10. Please note that
front end of tray is flush with opening in
fuselage (see graphics). To get correct vertical
position of tray, temporarily install servos, mark
position of tray in fuselage and remove servos
before you glue.
R8
R9
R10
i
R 23

i
S1 S2
S3
S4
R2
S6
S5
R1
Bring fuselage in a vertical position and glue motor mount in place.
Make sure installation tool S7 is positioned correctly on the fuselage as
shown.
Please note that there is a small gap between motor mount R2 and the
fuselage. This is necessary for the motor mount to be positioned
correctly.
Tack-glue the motor mount in place with four drops of epoxy applied
through the openings in S7.
Do not apply glue to completely glue the motor mount
in place!
4
5
6
To complete the next building step you will need the collet prop adapter which is available as an accessory.
Make sure the prop adapter fits the prop shaft of your motor (for Order-No. see page 2).
Remove installing tool S7 when epoxy glue has cured. Assemble the collet adapter with prop hub yoke and
temporarily install the motor into the fuselage. Install collet adapter on motor shaft and tighten nut with
your fingers.
Install spinner R5 onto prop adapter using two washers R7 for correct spacing, insert and tighten screw R6. Check spinner for correct
position in relation to fuselage. Correct, if necessary.
When spinner position is correct, disassemble/remove installed parts and glue motor mount in place with epoxy resin mixed with cotton
flocks or chopped glass fibre strands. Leave to cure.
R3
R4
R5
R6
R7
Fuselage
Install motor mount R2 using screw S6, spacers S5, installation tool
S7 and nut S8.
Slide motor mount R2 and spacers S5 onto screw S6 and install in
fuselage through cockpit opening.
From the outside slide installation tool S7 and nut S8 onto screw.
Then tighten nut with your fingers.
To use electric power in your Triple Neo the nose of the fuselage
needs to be cut off with the help of a template. For the glider version
skip building steps 1-6.
Glue together fuselage template from parts S1-S4. Leave to dry.
Slide fuselage R0 into template as shown. Please note that there is a
small bump on the underside of the fuselage which fits into template
exactly.
Run a sharp knife around the fuselage as shown to mark the cut-off
line.
Remove the template and cut off the nose with a razor saw. For best
results rotate the fuselage while you saw.
2
1
S7
S8
S7
3
7
8
Glue in place brass tube R9 together with former R8 in
fuselage. Trial-fit R8 before you glue and - if necessary -
correct contour of former to fit fuselage.
Fit and glue in place four magnets R23.
Attention: Make sure you check polarity of magnets if you
have already built a set of wings for your Triple.
Use epoxy glue mixed with cotton flocks for gluing.
Glue in place servo tray R10. Please note that
front end of tray is flush with opening in
fuselage (see graphics). To get correct vertical
position of tray, temporarily install servos, mark
position of tray in fuselage and remove servos
before you glue.
R8
R9
R10
i
R 23

10 Use templates S9 and S10 to install the fuselage tube. Insert wing joiner R11 and torsion rod R12 in corresponding sleeves in fuselage and
slide templates S9 onto R11/R12.
Insert fuselage tube R13 into fuselage and rear former. Place end of tube in template S10 as shown to find correct position for tube.
Do not glue tube to fuselage at this stage!
S9
S10
R11 R12
R13
11 Slightly sand front end of carbon tube R13. Apply epoxy resin to oblong
opening in former R8. Then glue plywood ring R14 to tube and former.
The tube will automatically be aligned in a perfectly horizontal position by
using the templates. Leave to cure.
R13
R8
R14
12 Bring fuselage in a vertical position and apply epoxy resin to opening in fuselage around
tube.
Apply glue to tube and fuselage
13 Sand left and right edges of battery tray R15 to fit contour of fuselage sides and
glue in place with epoxy resin.
R15
Make sure you place templates on a horizontal and even surface!
R16
R17
R18 R19
R20
14
15
Slightly sand inner surface of canopy R16 and fuselage cover R19. Glue in place piano wires R17 and R20
with epoxy resin; reinforce with fabric R18. Leave to cure.
To place canopy and cover on fuselage, insert piano wire in
opening, slide forward, insert rear end of wire in opening and slide
canopy/cover in correct position on fuselage.
Paint canopy as desired.
Glue together balsa parts R21 and plywood parts R22 to form the tailplane support.
Wrap 180 grit sandpaper around the carbon
fuselage tube R13 and sand tailplane support to fit
carbon tube.
Note that edges of plywood parts must
not be sanded down. See enlarged
graphics for correct result. This will
guarantee a perfect fit on the fuselage
tube.
Work carefully and glue support to
fuselage tube with epoxy. Make sure it
is absolutely straight and horizontal.
9
7
R22
R22
R13
R13
R21
R22
R21

10 Use templates S9 and S10 to install the fuselage tube. Insert wing joiner R11 and torsion rod R12 in corresponding sleeves in fuselage and
slide templates S9 onto R11/R12.
Insert fuselage tube R13 into fuselage and rear former. Place end of tube in template S10 as shown to find correct position for tube.
Do not glue tube to fuselage at this stage!
S9
S10
R11 R12
R13
11 Slightly sand front end of carbon tube R13. Apply epoxy resin to oblong
opening in former R8. Then glue plywood ring R14 to tube and former.
The tube will automatically be aligned in a perfectly horizontal position by
using the templates. Leave to cure.
R13
R8
R14
12 Bring fuselage in a vertical position and apply epoxy resin to opening in fuselage around
tube.
Apply glue to tube and fuselage
13 Sand left and right edges of battery tray R15 to fit contour of fuselage sides and
glue in place with epoxy resin.
R15
Make sure you place templates on a horizontal and even surface!
R16
R17
R18 R19
R20
14
15
Slightly sand inner surface of canopy R16 and fuselage cover R19. Glue in place piano wires R17 and R20
with epoxy resin; reinforce with fabric R18. Leave to cure.
To place canopy and cover on fuselage, insert piano wire in
opening, slide forward, insert rear end of wire in opening and slide
canopy/cover in correct position on fuselage.
Paint canopy as desired.
Glue together balsa parts R21 and plywood parts R22 to form the tailplane support.
Wrap 180 grit sandpaper around the carbon
fuselage tube R13 and sand tailplane support to fit
carbon tube.
Note that edges of plywood parts must
not be sanded down. See enlarged
graphics for correct result. This will
guarantee a perfect fit on the fuselage
tube.
Work carefully and glue support to
fuselage tube with epoxy. Make sure it
is absolutely straight and horizontal.
9
7
R22
R22
R13
R13
R21
R22
R21

A flat surface or building board is required to build the tail unit. Protect building board with cling film so that tailplane
parts will not stick to the surface of the building board.
Remove required parts from laser sheets and glue in place as shown.
1
Tail Unit
Use 1-mm-balsa to sheet the tail unit. Glue laser-cut sheeting material to either side of structure and weigh down evenly to
avoid warping. When completey dry, round off edges with the exception of those where the elevator will be attached later
on.
Glue spruce connector L11 to elevator panels.
2
L1
L2
L3
L3
L4
L4
L5
L5
L6
L6
L7
L7
L8
L8
L9
L10
L11
When sheetig material has dried completely, bevel off rear edge of tailplane to allow for sufficient control throw of
elevator.
Glue reinforcements L12 to inner edges of
elevator panels.
Build up fin and rudder in the same way.
3
4
5
L1 L9
L12
L13
L14
L15
L16
L17
L18
L19
L20
L21
L22
L23

A flat surface or building board is required to build the tail unit. Protect building board with cling film so that tailplane
parts will not stick to the surface of the building board.
Remove required parts from laser sheets and glue in place as shown.
1
Tail Unit
Use 1-mm-balsa to sheet the tail unit. Glue laser-cut sheeting material to either side of structure and weigh down evenly to
avoid warping. When completey dry, round off edges with the exception of those where the elevator will be attached later
on.
Glue spruce connector L11 to elevator panels.
2
L1
L2
L3
L3
L4
L4
L5
L5
L6
L6
L7
L7
L8
L8
L9
L10
L11
When sheetig material has dried completely, bevel off rear edge of tailplane to allow for sufficient control throw of
elevator.
Glue reinforcements L12 to inner edges of
elevator panels.
Build up fin and rudder in the same way.
3
4
5
L1 L9
L12
L13
L14
L15
L16
L17
L18
L19
L20
L21
L22
L23

R24
Lightly sand rear end of carbon tube and glue tailplane support to carbon tube with
epoxy. Use template S10 for proper alignment. See graphics for correct position of
tailplane support.
Glue tail skid R24 into carbon tube with epoxy. A slot in template S10 will
accommodate the skid.
Make sure there is room for the bowden cables in the tube on
either side of the tail skid.
Glue the fin to the tailplane and let dry. Then use epoxy to glue complete
assembly to the tailplane support, placing the tailplane horizontally onto
template S10.
Make sure the fuselage is correctly seated in templates
S9 + S10 on an even and horizontal surface.
8
9
1 cm
S10
Glue control horns L24 into rudder and elevator.
10
10
11
12
L24
Rounf off front of triangular stock L25 and glue to either side of fin.
Apply covering material to the tail unit and attach rudder and elevator with
hinge tape or equivalent.
Slide bowden cables R25 into carbon tube on either side of tail skid R24.
Glue bowden cable outers to skid with a drop of epoxy.
Install and glue part R26 to fuselage end of carbon
tube between bowden cable outers R25. Glue cable
outers to R26 with a drop of epoxy.
L25
R26
R24
R25

R24
Lightly sand rear end of carbon tube and glue tailplane support to carbon tube with
epoxy. Use template S10 for proper alignment. See graphics for correct position of
tailplane support.
Glue tail skid R24 into carbon tube with epoxy. A slot in template S10 will
accommodate the skid.
Make sure there is room for the bowden cables in the tube on
either side of the tail skid.
Glue the fin to the tailplane and let dry. Then use epoxy to glue complete
assembly to the tailplane support, placing the tailplane horizontally onto
template S10.
Make sure the fuselage is correctly seated in templates
S9 + S10 on an even and horizontal surface.
8
9
1 cm
S10
Glue control horns L24 into rudder and elevator.
10
10
11
12
L24
Rounf off front of triangular stock L25 and glue to either side of fin.
Apply covering material to the tail unit and attach rudder and elevator with
hinge tape or equivalent.
Slide bowden cables R25 into carbon tube on either side of tail skid R24.
Glue bowden cable outers to skid with a drop of epoxy.
Install and glue part R26 to fuselage end of carbon
tube between bowden cable outers R25. Glue cable
outers to R26 with a drop of epoxy.
L25
R26
R24
R25

Protect building board with cling film. Place two parts TS-01 on
building board as shown and secure with pins.
Glue spruce strip TS-02 (2 x 8 mm) to TS-01 and cut off flush with
sheeting material on either side. Make sure to build a left and a
right wing panel!
1
Attention: Make sure you build a left and a right wing panel. In this section construction of one wing panel is described. Build the opposite wing
panel accordingly.
TS-01
TS-01
TS-02
TS-02
TS-03
Position main spar TS-03 exactly in the middle
of TS-02 and glue in place. Use pins to secure.
Wing joiner part TS-04 will be glued in place
after ribs have been placed.
For the next building steps place the wing panel in the Depron building jig as shown to guarantee correct alignment of parts.
Place Depron jig on building board and secure with tape or pins. Then place the components you have just built in the jig as
shown.
2
3
Enlarged view of main
wing spar, glued on
place on TS-02.
Section IV - Triple speed Wing
Place two-piece trailing edge sheeting TS-05 and TS-07 as well as
aileron sheeting TS-06 in the jig as shown.
Fit ribs TS-09 to TS-25 in place in numerical order. Root rib TS-08 will be fitted at a later
stage. Make sure you position ribs exactly at right angles in relation to spar, then glue in
place. Note, that ribs are glued to spruce spar, main spar, trailing edge sheeting and aileron
sheeting. Do not apply glue to front part of ribs between wing spar and leading edge
position.
4
5
6
TS-05
TS-07
TS-06
Glue in place aileron riblets TS-26 and TS-
27 on either end of aileron.
7Glue in place TS-04 together with rib TS-08. Make
sure TS-08 is slightly angled in accordance with
dihedral of wing.
When parts are positioned correctly correct dihedral
is achieved automatically.
TS-26
TS-27
TS-04
TS-08
TS-03
Note: Root rib TS-08 will be gleud in place together with
TS-04. TS-04 determines the correct dihedral angle for the
root rib.
TS-08
TS-04
TS-03
ca. 1°

Protect building board with cling film. Place two parts TS-01 on
building board as shown and secure with pins.
Glue spruce strip TS-02 (2 x 8 mm) to TS-01 and cut off flush with
sheeting material on either side. Make sure to build a left and a
right wing panel!
1
Attention: Make sure you build a left and a right wing panel. In this section construction of one wing panel is described. Build the opposite wing
panel accordingly.
TS-01
TS-01
TS-02
TS-02
TS-03
Position main spar TS-03 exactly in the middle
of TS-02 and glue in place. Use pins to secure.
Wing joiner part TS-04 will be glued in place
after ribs have been placed.
For the next building steps place the wing panel in the Depron building jig as shown to guarantee correct alignment of parts.
Place Depron jig on building board and secure with tape or pins. Then place the components you have just built in the jig as
shown.
2
3
Enlarged view of main
wing spar, glued on
place on TS-02.
Section IV - Triple speed Wing
Place two-piece trailing edge sheeting TS-05 and TS-07 as well as
aileron sheeting TS-06 in the jig as shown.
Fit ribs TS-09 to TS-25 in place in numerical order. Root rib TS-08 will be fitted at a later
stage. Make sure you position ribs exactly at right angles in relation to spar, then glue in
place. Note, that ribs are glued to spruce spar, main spar, trailing edge sheeting and aileron
sheeting. Do not apply glue to front part of ribs between wing spar and leading edge
position.
4
5
6
TS-05
TS-07
TS-06
Glue in place aileron riblets TS-26 and TS-
27 on either end of aileron.
7Glue in place TS-04 together with rib TS-08. Make
sure TS-08 is slightly angled in accordance with
dihedral of wing.
When parts are positioned correctly correct dihedral
is achieved automatically.
TS-26
TS-27
TS-04
TS-08
TS-03
Note: Root rib TS-08 will be gleud in place together with
TS-04. TS-04 determines the correct dihedral angle for the
root rib.
TS-08
TS-04
TS-03
ca. 1°

8
9
10
Cut to length upper spruce spar TS-02 (2 x 8 mm) and glue to ribs and main spar. Use suitable weigths to hold spar in place and leave to dry.
Glue in place aileron spar TS-28, aileron leading edge TS-29 as well as gussets TS-30 and TS-31. Insert servo tray TS-32
between ribs TS-16 and TS-17, flush with underside of ribs and against wing spar. Do not glue!
Glue end stop TS-32.1 to both ribs and glue reinforcement TS-32.2 in place on aileron.
TS-02
Slightly bevel the last 3 mm of trailing edge and aileron
sheeting to establish a good contact surface for gluing.
Then glue in place top sheeting.
Tip: Glue rear edge of sheeting with epoxy to get a
strong trailing edge which can be sanded down to fine
profile.
TS-29
TS-28
TS-30
TS-31
TS-32
TS-32.1
TS-32.2
Glue together servo frames TS-32.3 and TS-32.4 as shown, and glue to spar
and ribs. Make sure that hole for servo lead is not obstructed.
Attention: Do not glue frame to servo tray TS-32! TS-32 is
merely used to position frame correctly.
TS-32.3
TS-32.4
TS-32
Carefully sand surface of wing joiner sleeve TS-35 and insert in wing root. Insert wing joiner R-40 into sleeve and make sure it
moves freely and without binding. Then remove R-40 and glue sleeve in place with epoxy mixed with glass fibres. Repeat for
TS-35.1.
Align magnet supports TS-46 and TS-47 with corresponding holes in rib TS-08, then glue to the inside of rib TS-08.
11
Glue together wing root sheeting material TS-33
and TS-34, then glue to first two rib bays.
12
TS-33
TS-34
TS-35
TS-35.1
TS-46
TS-47

8
9
10
Cut to length upper spruce spar TS-02 (2 x 8 mm) and glue to ribs and main spar. Use suitable weigths to hold spar in place and leave to dry.
Glue in place aileron spar TS-28, aileron leading edge TS-29 as well as gussets TS-30 and TS-31. Insert servo tray TS-32
between ribs TS-16 and TS-17, flush with underside of ribs and against wing spar. Do not glue!
Glue end stop TS-32.1 to both ribs and glue reinforcement TS-32.2 in place on aileron.
TS-02
Slightly bevel the last 3 mm of trailing edge and aileron
sheeting to establish a good contact surface for gluing.
Then glue in place top sheeting.
Tip: Glue rear edge of sheeting with epoxy to get a
strong trailing edge which can be sanded down to fine
profile.
TS-29
TS-28
TS-30
TS-31
TS-32
TS-32.1
TS-32.2
Glue together servo frames TS-32.3 and TS-32.4 as shown, and glue to spar
and ribs. Make sure that hole for servo lead is not obstructed.
Attention: Do not glue frame to servo tray TS-32! TS-32 is
merely used to position frame correctly.
TS-32.3
TS-32.4
TS-32
Carefully sand surface of wing joiner sleeve TS-35 and insert in wing root. Insert wing joiner R-40 into sleeve and make sure it
moves freely and without binding. Then remove R-40 and glue sleeve in place with epoxy mixed with glass fibres. Repeat for
TS-35.1.
Align magnet supports TS-46 and TS-47 with corresponding holes in rib TS-08, then glue to the inside of rib TS-08.
11
Glue together wing root sheeting material TS-33
and TS-34, then glue to first two rib bays.
12
TS-33
TS-34
TS-35
TS-35.1
TS-46
TS-47

Glue false leading edge TS-36 (balsa, 2 x 8 mm) to ribs and
bottom sheeting. Sand flush with top of ribs after glue has
dried.
Glue in place top sheeting TS-01 on ribs, spar and flase leading edge. Use suitable weights and tape to secure
sheeting material until glue has dried completely.
14
15
TS-36
TS-01
Remove wing from building board. Please handle with care and
always place on an even surface, as the wing has no tortional stability
at this time.
Glue bottom sheeting material to ribs. For best results use thin CA.
Also glue in place sheeting material to the underside of wing
root.
13
Cut off sheeting material flush with false leading edge then carefully sand sheeting
material flush with false leading edge. Use a long sanding bar for best results. Then
glue leading edge TS-37 (balsa, 3 x 8 mm) to false leading eding edge and sand to
shape after glue has dried.
16
TS-37
Make up wing tips from 3 parts TS-38 and
secure with clamps until dry.
Sand sheeting material and spars flush
with tip rib TS-25 and glue in place wing
tip TS-38.
Then sand wing tip to fit planform of wing
and shape of wing section.
17
18
TS-38
TS-38

Glue false leading edge TS-36 (balsa, 2 x 8 mm) to ribs and
bottom sheeting. Sand flush with top of ribs after glue has
dried.
Glue in place top sheeting TS-01 on ribs, spar and flase leading edge. Use suitable weights and tape to secure
sheeting material until glue has dried completely.
14
15
TS-36
TS-01
Remove wing from building board. Please handle with care and
always place on an even surface, as the wing has no tortional stability
at this time.
Glue bottom sheeting material to ribs. For best results use thin CA.
Also glue in place sheeting material to the underside of wing
root.
13
Cut off sheeting material flush with false leading edge then carefully sand sheeting
material flush with false leading edge. Use a long sanding bar for best results. Then
glue leading edge TS-37 (balsa, 3 x 8 mm) to false leading eding edge and sand to
shape after glue has dried.
16
TS-37
Make up wing tips from 3 parts TS-38 and
secure with clamps until dry.
Sand sheeting material and spars flush
with tip rib TS-25 and glue in place wing
tip TS-38.
Then sand wing tip to fit planform of wing
and shape of wing section.
17
18
TS-38
TS-38

Use a razor saw to cut out the aileron and carefully sand sheeting material flush with riblets on either side. Glue TS-39 to front of
aileron and bevel off to allow for sufficient control throw. After covering attach aileron to wing with tape.
Tip: If you do not want to use tape, you can bevel off top and bottom of TS-39 and use small hinges to attach the aileron to the wing.
TS-39
19
Triplespeed
1
2
For the next building steps place the wing panel in the Depron building jig as shown to
guarantee correct alignment of parts.
Place Depron jig on building board and secure with tape or pins. Then place the components
you have just built as well as trailong edge sheeting TR-05 in the jig as shown.
3
TR-02
TR-03
TR-05
TR-01
Attention: Make sure you build a left and a right wing panel. In this section construction of one wing panel is described. Build the opposite
wing panel accordingly.
Section V - Triple R.E.S. Wing
Protect building board with cling film. Place two parts
TR-01 on building board as shown and secure with
pins.
Glue spruce strip TR-02 (2 x 8 mm) to TR-01 and cut off
flush with sheeting material on either side. Make sure
to build a left and a right wing panel!
Position main spar TR-03 exactly in the
middle of TR-02 and glue in place.
Secure with pins until dry.
Wing joiner part TR-04 will be glued in
place after ribs have been placed.

Use a razor saw to cut out the aileron and carefully sand sheeting material flush with riblets on either side. Glue TS-39 to front of
aileron and bevel off to allow for sufficient control throw. After covering attach aileron to wing with tape.
Tip: If you do not want to use tape, you can bevel off top and bottom of TS-39 and use small hinges to attach the aileron to the wing.
TS-39
19
Triplespeed
1
2
For the next building steps place the wing panel in the Depron building jig as shown to
guarantee correct alignment of parts.
Place Depron jig on building board and secure with tape or pins. Then place the components
you have just built as well as trailong edge sheeting TR-05 in the jig as shown.
3
TR-02
TR-03
TR-05
TR-01
Attention: Make sure you build a left and a right wing panel. In this section construction of one wing panel is described. Build the opposite
wing panel accordingly.
Section V - Triple R.E.S. Wing
Protect building board with cling film. Place two parts
TR-01 on building board as shown and secure with
pins.
Glue spruce strip TR-02 (2 x 8 mm) to TR-01 and cut off
flush with sheeting material on either side. Make sure
to build a left and a right wing panel!
Position main spar TR-03 exactly in the
middle of TR-02 and glue in place.
Secure with pins until dry.
Wing joiner part TR-04 will be glued in
place after ribs have been placed.

TR-15
TR-07
TR-04
TR-02
TR-06
TR-16
TR-05
TR-17
Fit ribs TR-07 to TR-15 in place in numerical order. Notches in Spar and trailing edge help to position the ribs correctly. Note, that ribs are
glued to spruce spar, main spar and trailing edge sheeting TR-05. Do not apply glue to front part of ribs between wing spar and leading edge
position.
4
Note: Root rib TR-06 will be fitted at a later stage
together with TR-04. TR-04 determines the correct dihedral
angle for the root rib.
5
6Remove wing from jig. Slightly bevel the last 3 mm of trailing edge
sheeting to establish a good contact surface for gluing. Then glue in
place top sheeting TR-05. Glue together wing root sheeting material
TR-16 and TR-17, then glue to first rib bay.
Tip: Glue rear edge of sheeting with epoxy to get a strong trailing
edge which can be sanded down to fine profile.
TR-04
TR-06
Glue in place TR-04 together with top spar TR-02 (spruce,
2 x 8 mm). Glue in place rib TR-06 and make sure it is
slightly angled in accordance with dihedral of wing.
When parts are positioned correctly correct dihedral is
achieved automatically.
Glue bottom sheeting material to ribs. For best results
use thin CA. Also glue in place sheeting material to
the underside of wing root.
Place wing on building board and glue false leading
edge TR-18 (balsa, 2 x 8 mm) to ribs and bottom
sheeting. Sand flush with top of ribs after glue has
dried.
TR-17
TR-18
TR-16
7
8
9
Glue together wing root sheeting material TR-16
and TR-17, then glue to first rib bay on underside
of wing.
