Aerotech ABRT Series User manual

Revision: 1.05.00
ABRT Hardware Manual

Global Technical Support
Go to www.aerotech.com/global-technical-support for information and support about your Aerotech products. To get help
immediately, contact a service office or your sales representative ([e-mail]). Include your customer order
number in your email.
Software Support:Aerotech offers a range of software packages readily available for download. Free software is available
for instant download. Chargeable software requires a current software key. Link:Software Downloads
Software Activation:The following link provides information and resources to activate your Aerotech software.
Link:Software Activation
Manuals, Help Files, and Cable Drawings:Browse a directory of manuals, help files, and cable drawings for Aerotech
software and hardware products. Link:Browse Manuals, Help Files, and Cable Drawings
Frequently Asked Questions: The Frequently Asked Questions (FAQs) section provides answers to most common
questions about Aerotech products. Link: Product FAQs
Product Training: View training information and schedule a training class. Link: Training Sessions
Request Product Repair or Return: We offer complete service and repair services for all of our products. Learn more about
our pricing and warranties, plus access the forms required for many Global Technical Support port requests. Link:Repair &
Return
Remote and Field Service Technical Support:Schedule a remote session now or a field service
appointment.Link:Remote Technical Support
This manual contains proprietary information and may not be reproduced, disclosed, or used in whole or in part without the
express written permission of Aerotech, Inc. Product names mentioned herein are used for identification purposes only and
may be trademarks of their respective companies.
Copyright © 2006-2020, Aerotech, Inc., All rights reserved.

Table of Contents
ABRT Hardware Manual 1
Table of Contents 3
List of Figures 4
List of Tables 5
Safety Procedures and Warnings 6
EU Declaration of Incorporation 7
Chapter 1: Overview 9
1.1. Environmental Specifications 10
1.2. Accuracy and Temperature Effects 10
1.3. Basic Specifications 11
1.4. Air Requirements 12
1.5. Vacuum Operation 12
Chapter 2: Installation 13
2.1. Unpacking and Handling the Stage 13
2.2. Dimensions 15
2.3. Securing the Stage to the Mounting Surface 18
2.4. Attaching the Payload to the Stage 20
Chapter 3: Electrical Installation 21
3.1. Motor and Feedback Connectors 22
3.2. Motor and Feedback Wiring 25
3.3. Motor and Feedback Specifications 26
3.4. Limits, Marker, and Machine Direction 28
3.5. Motor and Feedback Phasing 29
Chapter 4: Maintenance 31
4.1. Service and Inspection Schedule 31
4.2. Cleaning and Lubrication 32
4.3. Troubleshooting 33
Appendix A: Warranty and Field Service 35
Appendix B: Revision History 37
Index 39
www.aerotech.com 3
ABRT Hardware Manual Table of Contents

List of Figures
Figure 1-1: ABRTSeries Rotary Air-Bearing Stage 9
Figure 2-1: ABRT with Shipping Clamps 14
Figure 2-2: ABRT150 Dimensions 15
Figure 2-3: ABRT200 Dimensions 16
Figure 2-4: ABRT260 Dimensions 17
Figure 2-5: Top View of an ABRT250MP Stage Showing Mounting Holes 19
Figure 2-6: Side View of an ABRT250MP Stage Showing Tapped Fixturing Holes 19
Figure 3-1: Motor and Feedback Wiring 25
Figure 3-2: Machine Direction 28
Figure 3-3: Hall Phasing 29
Figure 3-4: Analog Encoder Phasing Reference Diagram (-E1 Encoder Option) 30
Figure 3-5: Digital Encoder Phasing Reference Diagram (-E2 Encoder Option) 30
List of Figures ABRT Hardware Manual
4 www.aerotech.com

List of Tables
Table 1-1: Model Options 9
Table 1-2: Environmental Specifications 10
Table 1-3: ABRT Series Specifications 11
Table 2-1: Stage to Mounting Surface Hardware 18
Table 2-2: ABRT Series Load Capability 20
Table 3-1: 4-Pin Motor ConnectorPinout 23
Table 3-2: Mating Connector Part Numbers for the 4-Pin Motor Connector 23
Table 3-3: 25-Pin Feedback Connector Pinout 24
Table 3-4: Mating Connector Part Numbers for the 25-Pin Feedback Connector 24
Table 3-5: Feedback Specifications 26
Table 3-6: ABRT Series Resolution Information 26
Table 3-7: ABRT Series Maximum Encoder Frequency 26
Table 3-8: ABRT Series Motor Specifications 27
www.aerotech.com 5
ABRT Hardware Manual List of Tables

Safety Procedures and Warnings
This manual tells you how to carefully and correctly use and operate the ABRT.
lRead all parts of this manual before you install or operate the ABRT or before you do
maintenance to your system.
lTo prevent injury to you and damage to the equipment, obey the precautions in this
manual.
lAerotech continually improves its product offerings; listed options may be superseded at
any time. All drawings and illustrations are for reference only and were complete and
accurate as of this manual’s release. Refer to www.aerotech.com for the most up-to-date
information.
If you do not understand the information in this manual, contact Aerotech Global Technical
Support.
N O T E : This product is intended for light industrial manufacturing or laboratory use.
D A N G E R : This product contains potentially lethal voltages. To reduce the possibility of
electrical shock, bodily injury, or death the following precautions must be followed.
1. Access to the (missing or bad snippet) and component parts must be restricted while
connected to a power source.
2. Do not connect or disconnect any electrical components or connecting cables while
connected to a power source.
3. Disconnect electrical power before servicing equipment.
4. All components must be properly grounded in accordance with local electrical safety
requirements.
5. Operator safeguarding requirements must be addressed during final integration of the
product.
W A R N I N G : To minimize the possibility of electrical shock, bodily injury or death the
following precautions must be followed.
1. Moving parts can cause crushing or shearing injuries. Access to all stage and motor parts
must be restricted while connected to a power source.
2. Cables can pose a tripping hazard. Securely mount and position all system cables to avoid
potential hazards.
3. Do not expose this product to environments or conditions outside of the listed
specifications. Exceeding environmental or operating specifications can cause damage to
the equipment.
4. The ABRT stage must be mounted securely. Improper mounting can result in injury and
damage to the equipment.
5. Use care when moving the ABRT stage. Lifting or transporting the ABRT stage improperly
can result in injury or damage to the ABRT.
6. If the product is used in a manner not specified by the manufacturer, the protection
provided by the product can be impaired and result in damage, shock, injury, or death.
7. Operators must be trained before operating this equipment.
8. All service and maintenance must be performed by qualified personnel.
Safety Procedures and Warnings ABRT Hardware Manual
6 www.aerotech.com

EU Declaration of Incorporation
Manufacturer: Aerotech, Inc.
101 Zeta Drive
Pittsburgh, PA 15238-2811
USA
herewith declares that the product:
ABRT Air-Bearing Direct Drive Rotary Stage
is intended to be incorporated into machinery to constitute machinery covered by the Directive 2006/42/EC
as amended;
and that the following harmonized European standards have been applied:
EN ISO 12100:2010
Safety of machinery - Basic concepts, general principles for design
EN 60204-1:2010
Safety of machinery - Electrical equipment of machines - Part 1:General requirements
and further more declares that
it is not allowed to put the equipment into service until the machinery into which it is to be
incorporated or of which it is to be a component has been found and declared to be in
conformity with the provisions of the Directive 2006/42/EC and with national
implementing legislation, for example, as a whole, including the equipment referred to in
this Declaration.
This is to certify that the aforementioned product is in accordance with the applicable requirements of the
following Directive(s):
EU 2015/863 Directive, Restricted Substances (RoHS 3)
Authorized Representative: Simon Smith, European Director
Address: Aerotech Ltd
The Old Brick Kiln, Ramsdell, Tadley
Hampshire RG26 5PR
UK
Name
/ Alex Weibel
Position Engineer Verifying Compliance
Location Pittsburgh, PA
Date 12/14/2020
www.aerotech.com 7
ABRT Hardware Manual EU Declaration of Incorporation

This page intentionally left blank.
EU Declaration of Incorporation ABRT Hardware Manual
8 www.aerotech.com

Chapter 1: Overview
N O T E : Aerotech continually improves its product offerings; listed options may be superseded at any
time. All drawings and illustrations are for reference only and were complete and accurate as of this
manual’s release. Refer to www.aerotech.com for the most up-to-date information.
Table 1-1: Model Options
ABRTAir-Bearing Direct-Drive Rotary Stage
ABRT150 150 mm wide air-bearing direct-drive rotary stage
ABRT200 200 mm wide air-bearing direct-drive rotary stage
ABRT260 260 mm wide air-bearing direct-drive rotary stage
Feedback (Required)
-E1 Incremental encoder, 1 Vpp
-E2 Incremental encoder, Digital RS422 (x50 interpolation)
Accessories (To Be Ordered As Separate Line Item)
-ABF Air-bearing filtration kit
Figure 1-1: ABRTSeries Rotary Air-Bearing Stage
www.aerotech.com 9
ABRT Hardware Manual Chapter 1: Overview

1.1. Environmental Specifications
Table 1-2: Environmental Specifications
Ambient
Temperature
Operating: 10° to 35° C (50° to 95° F)
The optimal operating temperature is 20° C ±2° C (68° F ±4° F). If at any time the
operating temperature deviates from 20° C, degradation in performance could occur.
Storage: 0° to 40° C (32° to 104° F) in original shipping packaging
Humidity Operating: 20% to 60% RH
Storage: 10% to 70% RH, non-condensing in original packaging
Altitude
Operating: 0 m to 2,000 m (0 ft to 6,562 ft) above sea level
Contact Aerotech if your specific application involves use above 2,000 m or below sea
level.
Vibration
Use the system in a low vibration environment. Excessive floor or acoustical vibration
can affect system performance. Contact Aerotech for information regarding your spe-
cific application.
Protection
Rating
The ABRT stages are not suited for dusty or wet environments. This equates to an ingress
protection rating of IP00.
Use Indoor use only
W A R N I N G : Do not expose this product to environments or conditions outside of the listed
specifications. Exceeding environmental or operating specifications can cause damage to the
equipment.
1.2. Accuracy and Temperature Effects
Aerotech products are designed for and built in a 20°C (68°F) environment. Extreme temperature changes
could cause a decrease in performance or permanent damage to the ABRT. At a minimum, the
environmental temperature must be controlled to within 0.25ºC per 24 hours to ensure the ABRT
specifications are repeatable over an extended period of time. The severity of temperature effects on all
specifications depends on many different environmental conditions, including how the ABRT is mounted.
Contact the factory for more details.
1.1. Environmental Specifications ABRT Hardware Manual
10 www.aerotech.com

1.3. Basic Specifications
N O T E : Aerotech continually improves its product offerings; listed options may be superseded at any
time. All drawings and illustrations are for reference only and were complete and accurate as of this
manual’s release. Refer to www.aerotech.com for the most up-to-date information.
Resolution is dependent upon the encoder resolution and the controller interpolation.
Table 1-3: ABRT Series Specifications
ABRT Series ABRT150 ABRT200 ABRT260
Width 146 mm 196 mm 260 mm
Tabletop Diameter 100 mm 145 mm 200 mm
Height 135 mm 165 mm 185 mm
Aperture 20 mm 30 mm 50 mm
Total Travel 360° Continuous
Bus Voltage 340 VDC
Fundamental Encoder Resolution 11,840
lines/rev
18,000
lines/rev
23,600
lines/rev
Max Speed(1) 1200 rpm 800 rpm 600 rpm
Accuracy (2) ±2 arc sec
Repeatability <1 arc sec
Max Load (3)
Axial 20 kg 41 kg 69 kg
Radial 3 kg 6 kg 10 kg
Tilt 3.5 N·m 8 N·m 18 N·m
Axial Error Motion (Synchronous) <100 nm
Radial Error Motion (Synchronous) <150 nm
Tilt Error Motion (Synchronous) <2.4 µrad (<0.5 arc sec)
Axial Error Motion (Asynchronous) <20 nm
Radial Error Motion (Asynchronous) <20 nm
Tilt Error Motion (Asynchronous) <0.2 µrad (<0.04 arc sec)
Operating Pressure (5) 80 psig (5.5 bar) ±5 psig (0.3 bar)
Air Consumption (6) <56.6 SLPM (<2 SCFM)
Inertia (Unloaded) 2,300 kg·mm213,500
kg·mm246,400 kg·mm2
Total Mass 6.7 kg 14.7 kg 27.1 kg
Material Aluminum
Finish Hardcoat (62 Rockwell Hardness)
(1) Maximum speed based on stage capability. Maximum application velocity may be limited by system data rate and system
resolution.
(2) Certified with each stage. Requires the use of an Aerotech controller.
(3) Maximum loads are mutually exclusive.
(4) All error motion specifications are measured at 60 rpm.
(5) To protect air bearing against under-pressure, an in-line pressure switch tied to the motion controller/amplifier E-Stop is
recommended.
(6) Air supply must be clean, dry to 0° F dew point and filtered to 0.25 μm or better. Recommend nitrogen at 99.9% purity.
www.aerotech.com 11
ABRT Hardware Manual 1.3. Basic Specifications

1.4. Air Requirements
W A R N I N G : Wear eye protection when you are close to compressed air components.
W A R N I N G : Do not attempt to rotate the stage table until the air supply has been installed.
Moving the stage table without air supplied can cause permanent damage to the stage.
Connect the air supply hose to the air inlet fitting. The location of the air inlet is shown in the dimensional
drawings (Section 2.2.).
It is important to the operation of the ABRT that the air supply meets Aerotech specifications. For
compressed air, the air must be filtered to 0.25 microns, dry to 0°F dew point, and oil free. For nitrogen, the
nitrogen must be 99.99% pure and filtered to 0.25 microns. Filtration is required to prevent particles from
clogging the air bearing orifices and other parts.
Air pressure must be in the range of 551 kPa ± 34 kPa (80 psi ± 5 psi) with an airflow rate of 56 SLPM
(standard liters per minute) at 551 kPa for a single axis. Aerotech recommends that you connect the air
supply with a polyurethane air hose.
Aerotech also recommends that you install a pressure switch (Aerotech P/N: MCA03094) tied to the motion
controller's emergency stop (ESTOP)that will remove power to the air bearing if pressure drops below 40 psi
(a drop in pressure could result in contact between bearing surfaces which could cause damage to the
surfaces). Aerotech’s ABF accessory kit incorporates air filtration plus a pressure monitoring switch.
1.5. Vacuum Operation
The ABRT is an air-bearing stage and is not compatible with operation in a vacuum environment. Contact
Aerotech for alternate solutions.
1.4. Air Requirements ABRT Hardware Manual
12 www.aerotech.com

Chapter 2: Installation
W A R N I N G : ABRT installation must be in accordance to instructions provided by this
manual and any accompanying documentation. Failure to follow these instructions could result
in injury or damage to the equipment.
2.1. Unpacking and Handling the Stage
D A N G E R / H E A V Y : Do not attempt to manually lift a stage that is too heavy (in excess of
18 kg). Refer to Section 1.3. for stage mass specifications.
lDo not attempt to manually lift heavy loads single handed.
lUse a fork lift or cart to transport the stage.
W A R N I N G : It is the customer's responsibility to safely and carefully lift the stage.
lMake sure that all moving parts are secure before moving the ABRT. Unsecured moving
parts may shift and cause bodily injury.
lImproper handling could adversely affect the performance of the ABRT. Use care when
moving the ABRT.
lLift only by the base. Do not use the tabletop or cables as lifting points.
N O T E : If any damage has occurred during shipping, report it immediately.
Carefully remove the ABRT stagefrom its protective shipping container.
lLift only from the base.
lDo not use any of the cables as lifting points.
lDo not use the tabletop as a lifting point.
W A R N I N G : Do not attempt to rotate the stage table until the air supply, detailed in Section
1.4., has been installed. Moving the stage table without air supplied can cause permanent
damage to the stage.
Gently set the ABRT stage on a smooth, flat, and clean surface.
Allow the stage to stabilize at room temperature for at least 12 hours before you attempt to operate it. A
stabilized stage will ensure that all of the alignments, preloads, and tolerances are the same as they were
when tested at Aerotech. Use compressed nitrogen or clean, dry, oil-free air to remove any dust or debris
that has collected during shipping.
Each ABRT has a label listing the system part number and serial number. These numbers contain
information necessary for maintaining or updating system hardware and software. Locate this label and
record the information for later reference.
www.aerotech.com 13
ABRT Hardware Manual Chapter 2: Installation

Shipping Clamps
If the ABRT has shipped as part of a system, shipping clamps (typically red, anodized aluminum) could have
been installed to secure the system prior to shipment. The shipping clamps, if installed, will need to be
removed prior to machine start up.
Figure 2-1: ABRT with Shipping Clamps
2.1. Unpacking and Handling the Stage ABRT Hardware Manual
14 www.aerotech.com

2.2. Dimensions
N O T E : Aerotech continually improves its product offerings; listed options may be superseded at any
time. All drawings and illustrations are for reference only and were complete and accurate as of this
manual’s release. Refer to www.aerotech.com for the most up-to-date information.
Figure 2-2: ABRT150 Dimensions
www.aerotech.com 15
ABRT Hardware Manual 2.2. Dimensions

Figure 2-3: ABRT200 Dimensions
2.2. Dimensions ABRT Hardware Manual
16 www.aerotech.com

Figure 2-4: ABRT260 Dimensions
www.aerotech.com 17
ABRT Hardware Manual 2.2. Dimensions

2.3. Securing the Stage to the Mounting Surface
W A R N I N G : Make sure that all moving parts are secure before moving the ABRT. Unsecured
moving parts may shift and cause bodily injury.
W A R N I N G : Do not attempt to manually move the ABRT if it is connected to a power source.
W A R N I N G : The ABRT must be mounted securely. Improper mounting can result in injury
and damage to the equipment.
The mounting surface must be flat and have adequate stiffness to achieve the maximum performance from
the ABRT stage. When it is mounted to a non-flat surface, the stage can be distorted while the mounting
screws are tightened. This distortion will decrease overall accuracy. Adjustments to the mounting surface
must be done before the stage is secured.
Inspect the mounting surface for dirt or unwanted residue and clean if necessary. Use precision flatstones
on the mounting surface to remove any burrs or high spots. Clean the mounting surface with a lint-free cloth
and acetone or isopropyl alcohol and allow the cleaning solvent to completely dry. Gently place the stage on
the mounting surface.
N O T E : To maintain accuracy, the mounting surface must be flat to within 2 µm TIR.
N O T E : The stage base is precision machined and verified for flatness prior to stage assembly at the
factory. If machining is required to achieve the desired flatness, it should be performed on the mounting
surface rather than the stage base. Shimming should be avoided if possible. If shimming is required, it
should be minimized to improve the rigidity of the system.
ABRT series stages have a fixed mounting pattern (as shown in Figure 2-5).
The ABRT should be mounted with the axis of rotation in the vertical direction using the counterbored
mounting holes shown in Figure 2-5 or the tapped mounting holes shown in Figure 2-6. Mounting the stage
with the axis of rotation in a horizontal orientation is acceptable but could have a negative effect on
performance. Consult Aerotech for more information if your application requires a horizontal axis of rotation
configuration.
Tightening torque values for the mounting hardware are dependent on the properties of the surface to which
the stage is being mounted. Values provided in Table 2-1 are typical values and may not be accurate for your
mounting surface. Refer to Section 2.2. for specific model mounting locations and dimensions.
Table 2-1: Stage to Mounting Surface Hardware
Mounting Hardware Typical Screw Torque
[Top Mounting] 6 mm SHCS 7 N·m
[Side Mounting] M6x1.0 7 N·m
2.3. Securing the Stage to the Mounting Surface ABRT Hardware Manual
18 www.aerotech.com

Figure 2-5: Top View of an ABRT250MP Stage Showing Mounting Holes
Figure 2-6: Side View of an ABRT250MP Stage Showing Tapped Fixturing Holes
www.aerotech.com 19
ABRT Hardware Manual 2.3. Securing the Stage to the Mounting Surface

2.4. Attaching the Payload to the Stage
Inspect the mounting surface for dirt or unwanted residue and clean if necessary. Clean the mounting
surface with a lint-free cloth and acetone or isopropyl alcohol and allow the cleaning solvent to completely
dry.
Aerotech recommends that customers use a representative payload during start-up to prevent accidental
damage to the stage and the payload. Proceed with the electrical installation and test the motion control
system in accordance with the system documentation. Document all results for future reference. For
information on electrical installation refer to Chapter 3 and the documentation delivered with the stage.
N O T E : If your ABRT was purchased with Aerotech controls, it might have been tuned with a
representative payload based on the information provided at the time of order. If the ABRT is started up
without a payload, the servo gains provided by Aerotech with the shipment may not be appropriate and
servo instability can occur. Refer to the controller help file for tuning assistance.
The payload must be flat, rigid, and comparable to the stage in quality to maintain optimum performance.
Additionally, the payload must be reasonably balanced in order to maintain stage accuracy. Consult
Aerotech to determine if the payload may potentially result in any deterioration of stage performance.
Refer to Section 2.2. for the location of the mounting holes on the stage tabletop to mount payloads. The
payload mounting holes have reinforced threads to allow frequent removal and installation of mounting
screws.
N O T E : For valid system performance, the mounting interface should be flat within 2 µm TIR.
W A R N I N G : Refer to the dimensions in Section 2.2. for maximum allowable thread
engagement. A screw extending through the stage table can affect travel and damage the
stage.
The ABRT rotary stage loading specifications are shown in Table 2-2.
Table 2-2: ABRT Series Load Capability
ABRT150 ABRT200 ABRT260
Max Load – Axial* 20 kg 41 kg 69 kg
Max Load – Radial* 3 kg 6 kg 10 kg
Max Load – Tilt* 3.5 N·m 8 N·m 18 N·m
* Maximum loads are mutually exclusive.
2.4. Attaching the Payload to the Stage ABRT Hardware Manual
20 www.aerotech.com
