Aerus Mobile User manual

Portable Electronic Purier
READ MANUAL CAREFULLY FOR PROPER PROCEDURES AND OPERATION.
2017 Space Technology
Hall of Fame Inductee

CONTENTS
Specifications ................................2
Important Safety Instructions .................3
Parts and Accessories.........................4
Control Pad Layout ...........................5
Operation ....................................5
Mounting the Base ...........................5
Adjusting the Wire Stand .....................6
Wire Stand Positions..........................6
12VDC Adapter Fuse..........................6
Power Adapters ..............................7
Portability....................................7
Disassembly..................................8
Assembly ....................................9
Yearly Maintenance...........................9
Cleaning ....................................10
Troubleshooting.............................10
PRODUCT OVERVIEW
Congratulations, you have purchased one of the most effective, technologically advanced mobile air purifiers
available. Your new Aerus Mobile is designed to provide clean, healthy air for your car, truck, RV, or camper
by reducing airborne contaminants, odors and pollutants. Be sure to read and follow all service procedures
outlined in this owner’s manual, and use only genuine Aerus replacement parts available from your
Independent Distributor/Contractor.
DID YOU FORGET TO REGISTER YOUR AERUS MOBILE?
By registering, you’ll activate your warranty. Your privacy is guaranteed. Just fill out your warranty card and
drop it in the mail.
If you have any questions concerning this, or any Aerus product, contact your
Independent Distributor/Contractor or Aerus Customer Service at 800.243.9078
(U.S.) or 800.668.0763 (CANADA).
GENERAL INFORMATION
SPECIFICATIONS
Electrical:
• 12VDC or 110 - 240 VAC 50/60Hz
• Fuse (12V DC adapter only): 2 Amp Buss type
• Maximum 10.7 Watts
Operating Temperature:
• 45˚F - 100˚F (7˚C - 38˚C)
Technology
• ActivePure® Technology
• Fixed 8.5 KV DC needle ion generator
Mechanical:
• 3 Speed Fan
Dimensions:
• 3.625”x 6”x 1.0”
(9.21cm x 15.25cm x 2.54cm w/o base)
Weight:
• 8 ounces (.23kg)
Warranty:
• Limited (1) year
Please record the name and phone number of your Independent Distributor/Contractor. here, and
retain it for future reference.
Name ____________________________________________________________________________
Phone ____________________________________________________________________________
Serial # ___________________________________________________________________________
2

3
IMPORTANT SAFETY INSTRUCTIONS
CAUTION: Not for use on 12 volt positive ground or 24 volt vehicles. Doing so may damage
the product.
WARNING: UV Lamp operation. Do not operate this unit unless the case is completely and
correctly assembled. Failure to comply may result in serious eye damage.
CAUTION: Do not operate unit near heat sources, open flame, or combustible vapors or gases.
SAVE THESE INSTRUCTIONS
Read this manual in its entirety before using your Aerus Mobile.
• Disconnect power cord before servicing
• DO NOT immerse in water or other liquids
• DO NOT touch the control panel or plug with a wet hand
• DO NOT insert or allow foreign objects to enter any ventilation or exhaust opening as this may cause
an electric shock or fire, or damage the air cleaner
• To prevent a possible fire, DO NOT block the air intakes or exhaust in any manner; DO NOT use on soft
surfaces, where openings may become blocked
• To disconnect air cleaner, turn controls to OFF, then remove plug from outlet; pull firmly on the plug,
DO NOT unplug by pulling on the cord
• Always unplug the unit before moving or cleaning, or whenever the air cleaner is not in use
• DO NOT use outdoors or on wet surfaces
• DO NOT attempt to repair or adjust any electrical or mechanical functions on this unit, doing so will
void your warranty
• Connect to properly grounded outlets only
• To reduce the risk of electrical shock, do not change the plug in any way
CAUTION: The unit must be disconnected from its power source before servicing, and
should not have the power reconnected unless the case is correctly and
completely reassembled.

4
PARTS AND ACCESSORIES
A. WIRE STAND ........................................................................9950153
B. BASE ...............................................................................9950154
C. KNOB/CLAMP PACK (2) ..............................................................9950155
D. 12VDC ADAPTER ...................................................................9950157
E. 2.0 AMP FUSE .......................................................................9950162
F. AC ADAPTER .......................................................................9950158
C
C
C
C
A
B
D
E
A. WIRE STAND 9950153
B. BASE 9950154
C. KNOB/CLAMP PACK (2) 9950155
D. 12VDC ADAPTER 9950157
E. 2.0 AMP FUSE 9950162
F. AC ADAPTER 9950158
Fuse for 12VDC Adapter only
L
O
C
K
O
P
E
N
L
O
C
K
O
P
E
N
PUSH
F
ORDER PART# 9950159
FRESH AIR MOBILE SERVICE KIT
ACTIVEPURE
®
TARGET
TARGET FRAME
Red Wires
UV BULB
ACTIVEPURE
®
PLATE
C
C
C
C
A
B
D
E
A. WIRE STAND 9950153
B. BASE 9950154
C. KNOB/CLAMP PACK (2) 9950155
D. 12VDC ADAPTER 9950157
E. 2.0 AMP FUSE 9950162
F. AC ADAPTER 9950158
Fuse for 12VDC Adapter only
L
O
C
K
O
P
E
N
L
O
C
K
O
P
E
N
PUSH
F
TARGET FRAME
ACTIVEPURE
®
TARGET
UV BULB
ORDER PART# 9950209
FRESH AIR MOBILE SERVICE KIT
AERUS MOBILE SERVICE KIT

5
2. Peel and stick one part
of the Velcro to the
base, then attach the
other to a clean, dry
surface, or...
1. Attach suction cups by
pressing and twisting
into the base, or...
3. Screws may be used
for extra security
and where the other
methods are not
appropriate.
1. If desired, mount the base in an appropriate location (see below).
2. Adjust the wire stand (see page 5).
3. Plug in either the 12VDC car adapter or the AC adapter.
4. The Aerus Mobile unit will turn on when power is supplied to the unit.
ON/OFF: When pressed, the unit turns on or off. LED above button will be lit when unit is on.
TIMER: When pressed, it turns the Timer on for 4 hours, then turns off. LED above button will be lit when
the Timer is on.
NOTE: If Timer is not pressed, the unit will operate continuously, until turned off or unplugged.
PURIFIER: Adjusts the Purifier Fan by pressing the Purifier UP and Purifier DOWN buttons.
5. When the unit is off, all the LED lights will also be off.
The base for the Aerus Mobile can be mounted using the included suction cups, Velcro, or screws,
depending on preference. When using suction cups or Velcro, be sure the surface is smooth and clean. Dirt,
grease, protectants, and other substances will affect performance and holding ability.
OPERATION
MOUNTING THE BASE
LOW HIGH
MED
CONTROL PAD LAYOUT

6
1. Sitting on a at
surface with or
without the base
2. Hanging over an
edge pointing
down (laundry
hamper, garbage
can, etc.)
3. Sitting on a at surface
without the base
4. On a vertical surface with
the base (wall mount,
window, etc.)
5. Hanging over an edge
pointing up (seat pocket
in car)
The wire stand on the Aerus Mobile allows for quick release from the base, provides a stand or
hanger for the unit independent of the base, and allows the unit to either stand or hang from the
base depending on how the base is mounted.
To adjust the wire stand, loosen the two knobs on the sides of the unit approximately 1/2
turn. The unit may then be tilted up or down to adjust the angle or moved on the wire stand
to change the height. You can also remove and change the position of the wire stand to
accommodate several different mounting methods. To reinstall, simply align the two clamp
collars and insert the wire stand. Once the unit is adjusted, tighten both knobs to hold it in place.
WIRE STAND POSITIONS
ORTHEN
NOTE: Unit can be used without attaching the base or wire stand.
EFFECTS OF HIGH OR LOW VOLTAGES ON AERUS MOBILE™
WHEN USING THE 12VDC CAR ADAPTER
The Aerus Mobile™ has an operating voltage range of 11 VDC to 14.6 VDC. If the voltage coming into the unit
is too high, the unit may blow the 12VDC adapter fuse. This type of problem usually indicates something is
wrong with a vehicle’s electrical system. If the unit shuts down while using the 12VDC automotive adapter
and you are unsure of the cause, check the adapter fuse. If the fuse is not blown, test the unit using the
supplied AC adapter. Once the voltage problem (drained car battery, electrical system problem, etc.) is
corrected by a qualified service person, you will be able to resume using your Aerus Mobile™ with the
12VDC adapter.
ADJUSTING THE WIRE STAND

7
Insert the car adapter
into an appropriate
12 volt automotive
type power outlet.
Insert the small adapter plug into the opening located underneath at the
rear of the unit.
Select and install the proper international plug into the AC adapter. Insert correctly assembled adapter
into a standard electrical outlet.
THEN
NOTE: when installing one of the interchangeable plugs, be sure to twist and lock it into place. When
removing a plug, press the raised tab to release, then turn the plug out the top.
PUSH
L
O
C
K
O
P
E
N
L
O
C
K
O
P
E
N
PRESS HERE
2. To remove the unit from an
attached base, press down
on the front latch and slide
the unit back, then up.
NOTE : If you prefer to remove the base and unit together, mount the base with Velcro or suction cups
to a clean, dry surface.
1. Once the unit is assembled and
the base mounted, simply snap
the wire stand into the base.
The latch at the front of the
base should snap into place,
locking in the stand and unit.
PRESSSLIDE THEN LIFT
3. For added convenience,
mount extra bases where
you use your Aerus
Mobile most. See your
Independent Distributor/
Contractor for more
information.
The Aerus Mobile comes with both a 12 volt DC car adapter and a 100 - 240 volt 50/60 Hz AC adapter
with interchangeable plugs.
PORTABILITY
Depending on how it is mounted, your Aerus Mobile can be ready to take with you in just a few seconds.
To change the car adapter fuse, unscrew and remove the
front of the adapter. Replace with the same type and rating
only: 2 amp Buss type fuse (service part #9950162).
OR
12VDC Adapter Fuse
POWER ADAPTERS
CAUTION: Not for use on 12 volt positive ground or 24 volt vehicles. Doing so may damage
the product.

8
1. Turn unit over, tilt up
slightly, and remove screws
at the front of the unit.
2. With the front remaining
tilted up, slide the lower half
of the case back and up until
it is free.
3. Lift the small circuit board
holding the target screen and
bulb (Bulb Assembly) from the
two tabs.
4. Disconnect the leads of the
Bulb Assembly from the
main circuit board.
All user maintainable parts of the Aerus Mobile are accessed by removing the lower half of the case.
DISASSEMBLY FOR MAINTENANCE AND REPLACEMENT OF SERVICE KIT 9950209
CAUTION: The unit must be disconnected from its power source before servicing, and
should not have the power reconnected unless the case is correctly and
completely reassembled.

9
Reinstallation is the reverse of the above steps:
1. UV Lamp – Do not touch with bare hands. If
touched, clean the bulb with a cotton swab and a
small amount of alcohol.
2. Attach ActivePure® Target Screen (a) to the Target
Frames (b).
3. Install the legs of the Target Frames (b) into the four
holes of the Bulb Assembly PC board (c).
4. Attach the 3-pin connector (d) of the Bulb Assembly
to the main unit PC board.
5. Carefully align the two holes in the Bulb Assembly to
the two tabs on the main unit.
6. Press gently to install the Bulb Assembly.
7. Carefully replace the bottom case, being sure the
pins inside the back of the bottom case fit into the
two standoffs at back of the top case.
8. Slide the bottom case forward then down, making
sure the wires are completely inside the case.
9. Check for proper alignment before installing and
tightening the screws.
NOTE: Failure to correctly assemble may cause
damage to the case.
10. Replace cover and two screws.
5. Remove the Bulb Assembly from the unit.
YEARLY MAINTENANCE
A Service Kit is available for your Aerus Mobile. The kit contains a new ActivePure® Target and UV bulb. For
optimum performance, Aerus recommends replacing these components annually.
For more information, contact your Independent Distributor/Contractor or Aerus Customer Service at
800.243.9078 (U.S.) or 800.668.0763 (CANADA).
DISASSEMBLY CONTINUED
ASSEMBLY
a
b
c
d
Tabs
CAUTION: The unit must be disconnected from its power source before servicing, and
should not have the power reconnected unless the case is correctly and
completely reassembled.

10
Depending on conditions, your Aerus Mobile will require periodic cleaning of certain
internal components every one to three months.
ActivePure® Target - Clean the target by gently removing dust with a small, soft brush.
UV Bulb - The UV bulb should be gently wiped with a soft, dry cloth. Avoid handling the UV bulb more
than necessary.
Case - Clean the exterior case of your Aerus Mobile with a soft cloth dampened (not wet)
with water. Do not use harsh chemicals or solvents.
Fan/Interior of unit - The interior and fan may be cleared of dust using canned air suitable for electronics.
TROUBLESHOOTING
If your unit fails to operate properly after performing troubleshooting, contact your
Independent Distributor/Contractor or Aerus Customer Service at 800.243.9078 (U.S.) or
800.668.0763 (CANADA) for additional support.
Unit does not operate/ all LEDs off:
• Unplug and reinsert the adapter plug and adapter to check where the power supply is plugged in to be
sure it has power.
• If using the 12VDC car adapter, remove the fuse by unscrewing the end of the adapter and check to see if it
is blown. Replace it with the same type and rating fuse only (see Specifications).
NOTE: If the fuse is not blown, check the outlet for proper voltage.
UV bulb may not be working:
• Press the PURIFIER UP or PURIFIER DOWN buttons to turn the Purifier function ON.
• If cleaning and reinstalling does not correct the problem, replace the Bulb Assembly (service kit #9950209).
• When looking through the rear inlet vents in low light you should see a slight bluish glow. If there is no
glow, replace the Bulb Assembly (Service Kit #9950209).
Lack of air flow:
• Make sure the intake vents are not blocked and the front of the unit is clear.
• Check to see if the fan is operating (if not, see above).
NOTE: See page 8 for detail views of components.
WARNING: Under no circumstances should your Aerus Mobile unit be operated while any part
of the case is damaged, missing, or disassembled. If the case is damaged, return
your unit to your Independent Distributor/Contractor for repair or replacement.
Direct exposure to the internal UV light may cause eye damage.
CLEANING
CAUTION: The unit must be disconnected from its power source before servicing, and
should not have the power reconnected unless the case is correctly and
completely reassembled.
