AFi FR-PDA-STO User manual

ASSEMBLY INSTRUCTIONS
Before assembling your bed frame, please read through these
ATTENTION! If you receive a damaged or defective item,
please contact afifurnishings at [email protected] or 1-800-955-3726
instructions carefully and familiarize yourself with the different parts.
Barrel nut - 2 pcs
Wood dowel 10 X 30mm( 1 1/4") - 4 pcs
JCB M6 X 70mm (2 3/4”) - 2 pcs
Wood screw(1 1/4”) - 14 pcs
Spare - 1 pc
Spare - 1 pc
Spare - 1 pc
BED FRAME
Page 1 of 2
PARTS LIST HARDWARE
A
H
F
I
J
B
C
D
FOOT RAIL
LEFT LEG
RIGHT LEG
SIDE RAILS
SLAT KIT
HB SUPPORT RAIL
FB SUPPORT RAIL
SUPPORT LEGS
1 PC
1 PC
1 PC
2 PCS
2 SET
1 PC
1 PC
3 PCS
1
2
3
4
5
6
7
8
Allen wrench M4 - 1pc
Allen wrench M5- 1pc
Spare - 1pc
EJCB M6 X 30mm ( 1 1/8") - 6 pcs
GJCB M8 X 40mm ( 1 5/8") - 3 pcs
4
4
1
1
D
2
3
B
C
B
C
A
A
B
C
D
A
Attach the legs (2) and (3)
to foot rail (1), using wood dowel
(C) JCB M6 X 70mm (A) and
barrel nut (B).
Tighten with the Allen wrench (I).
Cover holes with wood button (D) as shown.
NOTE: WE INCLUDE SPARE HARDWARE IN CASE DAMAGE OCCURS DURING ASSEMBLY.
Step 1
Step 2
READY
ASSEMBLE
TO
Adult assembly
JCB M6 X 70mm
Barrel nut
Wood dowel
Wood button
QUEEN
PO: CODE ITEM
FR-PDA-STO R-21034X
Spare - 1 pc
Spare - 1 pc
Spare - 1 pc
Wood button - 2 pcs
wood button
Center set of pins.
Attach the side rails (04) to the headboard and footboard (1) using
the bed hook as shown below.
Cap Nut - 6 pcs

Page 2 of 2
Congratulations!
Your bed is now ready for use.
H
Wood screw 1 1/4"
Step 3
Step 4
G
G
G
8
8
7
6
8
Attach support leg (8) to support rail (6)(7) as shown below. Using JCB M8 (G)
tighten with Allen wrench M5(J).
We recommend that you periodically recheck that all screws are tight to ensure lasting safety.
QUEEN
JCB M8 X 40mm
JCB M6 X 30mm
Cap nut
G
E
F
Attach HB support rail (6) and FB support rail (7) to the slat kit (5) as shown below
using JCB M6 X 30mm (E) and cap nut (F). Tighten with Allen wrench M4 (I).
Using wood screw (H) tighten with Phillips head svcrewdriver. (Customer supplied)
If using a Trundle Bed attach slat supports off
center as shown.
2 legs at headboard section.
1 leg at footboard section.
H
H
HH
H
H
H
H
H
H
H
H
H
H
E
E
E
E
E
E
E
E
F
F
F
F
F
F
F

ASSEMBLY INSTRUCTIONS
Before assembling your headboard, please read through these
instructions carefully and familiarize yourself with the different parts.
HEADBOARD
Page 1 of 2
BACK VIEW
Step 1
Step 2
1
1
6
6
2
5
3
B
B
B
B
B
C
C
C
C
Instructions apply for bed sizes
QUEEN > KING
PARTS LIST HARDWARE
JCB M6 X 70mm (2 3/4”) - 4 pcs
Spare - 1 pc
B
A
C
D
H
HEADBOARD PANEL 1 PC
1
2
3
5
6
4
1 PC
1 PC
1 PC
2 PCS
2 PCS
LEFT LEG
RIGHT LEG
PILLOW STOP
PACKING STICK
SPACER BLOCK
Allen wrench - 1pc
Spare - 1pc
ATTENTION! If you receive a damaged or defective item,
please contact afifurnishings at [email protected] or 1-800-955-3726
Barrel nut - 4 pcs
Wooden dowel - 8 pcs
Wood screw - 4 pcs
Spare - 1 pc
Spare - 2 pcs
Spare - 1 pc
NOTE: WE INCLUDE SPARE HARDWARE IN CASE DAMAGE OCCURS DURING ASSEMBLY.
READY
ASSEMBLE
TO
Attach the legs (2) and (3) to the headboard panel (1) and pillow stop (5),
using JCB (B) and barrel nut (C). Tighten with the Allen wrench (H).
5
4
4
4
2
3
D
D
A
A
PO :
Remove packing stick (6) from headboard panel (1) and . Insert wooden dowels (A) to the
locator holes on spacer block (4) and pillow stop (5). Attach the spacer blocks (4) to the legs (2) and
(3), using wood screws (D), as shown below. Tighten with Phillips screwdriver. (customer supplied)
DISCARD
Adult assembly
If you purchased a wood headboard to attach to metal bed frame, please refer to page 2.
Split washer - 4 pcs
Flat washer - 4 pcs
JCB M6 X 25mm (1”) - 4 pcs
HARDWARE FOR METAL BED FRAME
Spare - 1 pc
Spare - 1 pc
Spare - 1 pc
G
F
E
CODE ITEM ITEM
HB-POR
R-28984X R-28985X

ASSEMBLY INSTRUCTIONS
Before assembling your bed, please read through these
instructions carefully and familiarize yourself with the different parts.
Attach the headboard assembly to the metal frame using JCB (E), flat washer (F),
and split washer (G) then tighten with Allen wrench (H), as shown below.
Congratulations!
JCB M6 X 1”
E
Allen wrench M4
H
Flat washer
Split washer
F
G
Instructions apply for bed sizes
Queen > King
Page 2of 2
Your Bed is now ready for use.
To ensure lasting safety, we recommend that you periodically check
that all screws are tight and all parts are secure.
E
E
G
G
F
F
ATTACHING HEADBOARD TO METAL BED FRAME
Metal bed frames are sold separately from wood headboards. The hardware shown on this page
is supplied with your wood headboard for attaching the bed frame to the headboard. The metal bed frame is supplied
with its own assembly instructions and hardware.
Adult assembly
HEADBOARD
Step 1
