AFi BD-PDA-ST User manual

ASSEMBLY INSTRUCTIONS
Before assembling your bed frame, please read through these
ATTENTION! If you receive a damaged or defective item,
please contact afifurnishings at [email protected] or 1-800-955-3726
instructions carefully and familiarize yourself with the different parts.
Barrel nut - 4 pcs
Wood dowel 10 X 30mm( 1 1/4") - 8 pcs
JCB M6 X 70mm (2 3/4”) - 4 pcs
Wood screw(1 1/4”) - 16 pcs
Spare - 1 pc
Spare - 1 pc
Spare - 1 pc
BED FRAME
Page 1 of 2
PARTS LIST HARDWARE
A
H
F
I
J
B
C
D
FOOT RAIL
LEFT LEG
RIGHT LEG
SIDE RAILS
SLAT KIT
SUPPORT RAIL
SUPPORT LEG
2 PCS
2 PCS
2 PCS
2 PCS
2 SET
2 PCS
2 PCS
1
2
3
4
5
6
7
Allen wrench M4 - 1pc
Allen wrench M5 - 1pc
Spare - 1pc
EJCB M6 X 30mm ( 1 1/8") - 6 pcs
GJCB M8 X 40mm ( 1 5/8") - 2 pcs
4
4
1
1
1
D
2
3
B
C
B
C
A
A
B
C
D
A
Attach the legs (2) and (3)
to foot rail (1), using wood dowel
(C) JCB M6 X 70mm (A) and
barrel nut (B).
Tighten with the Allen wrench (I).
Cover holes with wood button (D) as shown.
NOTE: WE INCLUDE SPARE HARDWARE IN CASE DAMAGE OCCURS DURING ASSEMBLY.
Step 1
Step 2
READY
ASSEMBLE
TO
Adult assembly
JCB M6 X 70mm
Barrel nut
Wood dowel
Wood button
KING
PO: CODE ITEM
BD-PDA-ST R-21135X
Spare - 1 pc
Spare - 1 pc
Spare - 1 pc
Wood button - 4 pcs
wood button
Attach the side rails (04) to the foot rail (1) using
the bed hook as shown below.
Cap Nut - 6 pcs

Page 2 of 2
Congratulations!
Your bed is now ready for use.
H
Wood screw 1 1/4"
Step 3
Step 4
G
6
7
Attach support leg (7) to support rail (6) as shown below. Using JCB M8 (G)
tighten with Allen wrench M5 (J). Repeat the other.
We recommend that you periodically recheck that all screws are tight to ensure lasting safety.
KING
JCB M6 X 30mm
Cap nut
E
F
JCB M8 X 40mm
G
Attach support rail (6) to the slat kit (5) as shown below. Using JCB
M6 X 30mm (E) and cap nut (F). Tighten with Allen wrench M4 (I).
Using wood screw (H) tighten with Phillips head screwdriver.
(Customer supplied)
H
H
H
HH
H
H
H
H
H
H
H
H
H
E
E
E
E
E
E
5
56
6
F
F
F
F
F
F
