AFi HB-MDN User manual

Adult assembly
ASSEMBLY INSTRUCTIONS
Before assembling your headboard, please read through these
Page 1 of 2
1
2
3
A
B
B
B
A
A
A
Instructions apply for bed sizes
TWIN > FULL
PARTS LIST HARDWARE
JCB M6 X 110mm (4 3/8”) - 4 pcs
Spare - 1 pc
A
B
ATTENTION! If you receive a damaged or defective item,
please contact afifurnishings at [email protected] or 1-800-955-3726
Barrel nut - 4 pcs
Spare - 1 pc
READY
ASSEMBLE
TO
instructions carefully and familiarize yourself with the different parts.
PO :
Split washer - 4 pcs
Flat washer - 4 pcs
JCB M6 X 25mm (1”) - 4 pcs
HARDWARE FOR METAL BED FRAME
Spare - 1 pc
Spare - 1 pc
Spare - 1 pc
E
D
C
FAllen wrench - 1pc
Spare - 1pc
If you purchased a wood headboard to attach to metal bed frame, please refer to page 2.
NOTE: WE INCLUDE SPARE HARDWARE IN CASE DAMAGE OCCURS DURING ASSEMBLY.
BACK VIEW
A
B
HEADBOARD PANEL 1 PC
1
2
3
1 PC
1 PC
LEFT LEG
RIGHT LEG
Step 1 Attach the legs (2) and (3) to headboard panel (1),
using JCB (A) and barrel nut (B).
Tighten with the Allen wrench (F).
FRONT VIEW
TAPER INSIDE AND
HOLES TO THE FRONT.
HEADBOARD
CODE ITEM ITEM
HB-MDN R-28682X R-28683X

ASSEMBLY INSTRUCTIONS
Before assembling your bed frame, please read through these
instructions carefully and familiarize yourself with the different parts.
Wood button - 2 pcs
Spare - 1 pc
Barrel nut - 2 pcs
JCB M6 X 100mm (4”) - 2 pcs
Wooden dowels - 4 pcs
Spare - 1 pc
Spare - 1 pc
Spare - 1 pc
Page 1 of 1
Instructions apply for all bed sizes
Twin > Twin XL > Full > Queen > King
PARTS LIST HARDWARE
END RAIL 1 PC
b
ad
c
2 PCS
2 PCS
2 PCS
TALL LEG
SHORT LEG
SIDE RAIL
1
2
3
4
Allen wrench - 1pc
Spare - 1pc
e
1
4
4
2
1
3
b
b
c
c
d
d
a
Attach the legs (2) or (3) to end rail (1),
using JCB M6 X 100mm (b) and barrel nut (c).
Tighten with the Allen wrench (e).
Cover holes with wood button (d).
Insert wooden dowels (a) into the
locator holes on (1) both ends
of end rail.
NOTE: WE INCLUDE SPARE HARDWARE IN CASE DAMAGE OCCURS DURING ASSEMBLY.
Attach side rails (4) to the end rail using bed hook
as shown. For headboard assembly, follow assembly
instructions included with headboard.
Short leg
Tall leg
Choose the when using
storage drawers, Trundle bed or
mattress only, choose the
tall legs
short
legs if using both foundation and
mattress.
OR
Step 1
Step 2
Step 3
READY
ASSEMBLE
TO
PO:
Adult assembly
BED FRAME
ATTENTION! If you receive a damaged or defective item,
please contact afifurnishigs at [email protected] or 1-800-955-3726
ITEMCODE
FR-UBN
FR-UBN
FR-UBN
FR-UBN
FR-UBN
R-26311X
R-26321X
R-26331X
R-26341X
R-26351X

ASSEMBLY INSTRUCTION
( TWIN )
Before assembling your bed slat kit, please read through these
instructions carefully and familiarize yourself with the different parts.
PARTS LIST
Step 1
Please note that you will require a Phillips screwdriver.
Assemble bed frame or bunk bed according to assembly instructions.
SLAT KIT 1 SET
01
A
Page 1 of 1
HARDWARE
1 1/4” Wood screw - 28 pcs Spare - 2 pcs
Lay the slat kit onto the bed.
PLATFORM BED
BUNK BED
Screw slat kit (01) to side rail, using wood screw (A).
Tighten with Phillips screwdriver. (Customer supplied)
Be sure the space between slats is even.
WEBBING MUST FACE UP
WEBBING MUST FACE UP
NOTE: WEBBING MUST FACE UP
SLAT KIT
A
Wood screw
Be sure to align slat kit evenly with both
ends of side rail.
01
ATTENTION! If you receive a damaged or defective item,
please contact afifurnishings at [email protected] or 1-800-955-3726
READY
ASSEMBLE
TO
Step 2 A
A
A
01
01
PO :
Adult assembly
NOTE: WE INCLUDE SPARE HARDWARE IN CASE DAMAGE OCCURS DURING ASSEMBLY.
CODE ITEM
SL-PF E-65000
