AFL Hyperscale H-Series 7RU Housing User manual

Installation Guide
H-Series 7RU
Housing
Series

2© AFL Hyperscale. All rights reserved Series
Safety Precautions
Laser Precautions
Warning: The laser light used to transmit information over optical ber cables can cause severe eye
damage. Because this light is invisible, it will not cause the iris of the eye to contract involuntarily as when
viewing a bright visible light, and no pain is felt as the retina is burned.
Never look into the end of a ber or connector which may have a laser coupled to it. Should accidental
eye exposure to laser light be suspected, arrange for an eye examination immediately.
General Precautions
Personnel must be thoroughly familiarized with all applicable Occupational Health and Safety (OH&S)
regulations, local regulations, and your company safety practices and policies.
Warning: To reduce the chance of accidental injury:
Before work begins, all personnel must be thoroughly familiar with the operation of all equipment
and procedures to be used during the installation.
Before use, all equipment, especially safety gear, must be inspected and tested for proper operation.
Replace and repair as necessary.
H-Series 7RU Housing
Before installing or adjusting this product, please read these instructions carefully.
Please keep this guide for future reference.

3
H-Series 7RU Housing
© AFL Hyperscale. All rights reserved
Series
Component Overview

4© AFL Hyperscale. All rights reserved Series
In the Box
Item
Number Item Qty
01 H-Series 7RU Housing 1
02 Door Label 1
03 Housing Number Label 1
(01) H-Series 7RU Housing
(02) Door Label
Cross-Head
Screwdriver
250 μm Wrapping Tube
Cable (WTC) with SpiderWeb
Ribbon® (SWR®)
Up to 24 H-Series
Cassettes
MPO MicroCable Patch
Assembly (Single Jacket 3mm
OD)
LC Premium Uniboot Patch
Cords Reversible Polarity
M6 x 16mm Screw and
Nuts (4pcs)
MicroCable Assemblies
(2mm Tails)
What You Will Need Related Products
Data Center Patch Cords
(03) Housing Number Label

5
H-Series 7RU Housing
© AFL Hyperscale. All rights reserved
Series
H-Series Cassette Types
H-Series Cassette Types
MPO – LC Cassette BASE-12 24f
24f Pass-Through Cassette
MPO Cassette BASE-12 144f
Blank Plate
24f LC Ribbon / Single Splice Cassette
24f Splice Only Cassette
Splice Only Cassette

6© AFL Hyperscale. All rights reserved Series
Mounting the Housing
Install the housing in the rack using the M6 x 16mm screws.
1
Open the front door (up to a 135º angle) and place the label on the inside of the door.
2

7
H-Series 7RU Housing
© AFL Hyperscale. All rights reserved
Series
Loading a H-Series Cassette
Insert the cassette into the housing, aligning the snap rivets of the cassette with the holes to the top and bottom
of the housing ensuring the cassette is straight. Make sure the adapter or cable gland for cable entry is at the
top of the cassette, and outbound adapters for patch cords are at the bottom before being installed into the
housing.
3
Install the remainder of the cassettes.
4

8© AFL Hyperscale. All rights reserved Series
Loading the Cables
Incoming cable can enter from the left or right of the top ber management bar.
5
Left hand entry
for incoming/
inbound cable Right hand entry
for incoming/
inbound cable

9
H-Series 7RU Housing
© AFL Hyperscale. All rights reserved
Series
Loading the Cables
Install patch cords using the bottom ber management bar from both the left and right hand side. This method
of patching is suitable for 2mm uniboot round duplex, 3mm MPO cable jackets or LC short boot (18mm) simplex
patch cords with 2mm cable.
6a
Patch cords can be dressed to exit to the left or right side of the bottom ber management bar. This conguration
is suitable for use with LCR Uniboot round duplex 2mm cable or LC short boot (18mm) simplex patch cords with
2mm cable.
6b
One side connection:
Connecting both sides:

10 © AFL Hyperscale. All rights reserved Series
MPO – LC Cassette BASE-12 24f
Connect the MPO at the top of the cassette. When patching, start from the bottom of the cassette and work your way
to the top.
7a
24f LC Ribbon / Single Splice Cassette
Once all cassettes are in position, proceed to address the cable to the correct slot positions in order. Once complete, ensure there
is enough cable to proceed with the splicing. Start to patch from the bottom of the cassette to the top.
7b
Loading the Cables
NOTE: It is recommended to use LCR Uniboot round duplex 2mm cable or 3mm MPO cables when patching the front of
the unit.
One slot per two
cassettes
One slot per two
cassettes
One slot per two
cassettes
One slot per two
cassettes

11
H-Series 7RU Housing
© AFL Hyperscale. All rights reserved
Series
Remove dust caps and load the cables as illustrated below.
Loading the Cables
24f LC Pass-Through Cassette
Open the cassette and install connectors into the back of the adapters as required. Once installed screw the cassette closed,
install into the housing and patch from the bottom of the cassette to the top. Note: Assemblies not included with cassette.
7c
MPO Cassette BASE-12 144f
H-Series Housing can accommodate up to 12 MPO BASE-12 144f Cassettes. Start to patch from the bottom of the cassette
to the top following indications at the front of the cassette. Cassette can be used with MPO pre-terminated assemblies
or FUSEConnect.
7d

12 © AFL Hyperscale. All rights reserved Series
Loading the Cables
Remove dust caps and load the cables as illustrated below.
MPO – LC Cassette BASE-12 24f and Blank Plate
Installation procedure for a blank plate is the same as the cassette. If the number of cassettes required does not ll all the
positions in the housing, we recommend adding blank plates for the remaining spaces. Start to patch from the bottom of the
cassette to the top.
7e

13
H-Series 7RU Housing
© AFL Hyperscale. All rights reserved
Series
1) Separate the pigtails into two bundles of 12 as per mapping requirements.
Position of Port 1 of the cassette is located at the bottom.
2) Proceed to feed the incoming cable at the top of the cassette and secure using the gland.
We recommend feeding up to 1.2 meters of cable.
3) Proceed to strip the cable.
Leave up to 30mm of aramid yarn to secure in the holders as shown above.
4) Separate the bers in the incoming cable to match the pigtail bundle and proceed to splice.
5) Once complete, coil the rst bundle in the cassette clockwise and secure the splice protector in the bottom
splice holder (position 2).
6) Repeat the process anti-clockwise for the second bundle and secure the splice protector in the top splice
holder (position 1).
7) Close the cassette and position it back in the housing.
8a
Single Splice Cassette
Wrap the aramid yarn
around the stud and
tighten by using the
spacer and nut.
Splice holder
position 1
Splice holder
position 2

14 © AFL Hyperscale. All rights reserved Series
Ribbon Splice Cassette
8b
Wrap the aramid yarn
around the stud and
tighten by using the spacer
and nut.
1) Uncoil the ribbon pigtail and separate the rst and second ribbon as per label indication.
2) Proceed to feed the incoming cable at the top of the cassette and secure using the gland.
We recommend feeding up to 1.5 meters of cable.
3) Strip the cable. Leave up to 30mm of aramid yarn to secure in the holders as shown above.
4) Separate the bers in the incoming cable to match the pigtail bundle and proceed to splice as per
manufacturer’s guidelines. For ribbon bers, identify the rst and second ribbons before splicing.
5) Once complete, coil the rst bundle in the cassette clockwise and secure the splice protector in the splice
holder.
6) Close the cassette and position it back in the housing.

15
H-Series 7RU Housing
© AFL Hyperscale. All rights reserved
Series
For single splice cassette, load and splice the pigtails as illustrated above. Close housing door once installation is
complete.
8c
Ribbon / Single Splice Cassettes
Magnet
Magnet
Slot Bracket
Complete installation
8d

Thank you for choosing AFL Hyperscale
AFLHSHS7RUH270820
www.aflhyperscale.com
AFL Hyperscale reserves the right to make changes
in this Installation Guide without notice
