AFL Hyperscale 96HP User manual

Level 4 96f Backboard
Installation Guide
96f POC
Backboard
Conguration SKU Code
96HP 10014768

2© AFL Hyperscale. All rights reserved
Safety Precautions
Laser Precautions
Warning: The laser light used to transmit information over optical ber cables can cause severe eye
damage. Because this light is invisible, it will not cause the iris of the eye to contract involuntarily as when
viewing a bright visible light, and no pain is felt as the retina is burned.
Never look into the end of a ber or connector which may have a laser coupled to it. Should accidental
eye exposure to laser light be suspected, arrange for an eye examination immediately.
General Precautions
Personnel must be thoroughly familiarized with all applicable Occupational Health and Safety (OH&S)
regulations, local regulations, and your company safety practices and policies.
Warning: To reduce the chance of accidental injury:
Before work begins, all personnel must be thoroughly familiar with the operation of all equipment
and procedures to be used during the installation.
Before use, all equipment, especially safety gear, must be inspected and tested for proper operation.
Replace and repair as necessary.
96f PoC Backboard
Before installing or adjusting this product, please read these instructions carefully.
Please keep this guide for future reference.

3
Level 4 96f PoC Backboard
© AFL Hyperscale. All rights reserved
Component Overview
1. Backboard
2. Cassette Chassis
3. Cable Manager
4. Pedestal Cable Manager
5. 3 Finger Cable Manager
6. Splice Tray
7. 1x4 Splitter Tray
8. Modular Raceway
9. Cable/Tube Manifold
10. Single Duct Tie Point
11. Universal Duct Tie Point
12. Installation Guide / QR Code
01
09
10
11
11
12
08
07
06
06
02
03
05
04

4© AFL Hyperscale. All rights reserved
In the Box
Item
Number Item Qty
01 Backboard 1
02 Cassette Chassis 2
03 Cable Manager 2
04 Pedestal Cable Manager 4
05 3 Finger Cable Manager 2
06 Splice Tray 6
07 1x4 Splitter Tray 6
08 Modular Raceway 4
09 Cable/Tube Manifold 1
10 Single Duct Tie Point 2
11 Universal Duct Tie Point 12
12 Installation Guide / QR Code 1
(01) Backboard
(06) 8mm Splice Tray
(03) Cable Manager
(02) Cassette
Chassis
(07) 1x4 Splitter Tray (08) Modular Raceway
(11) Universal 8-way
Duct Tie point
(12) nstallation Guide
/ QR Code
(05) 3 Finger Cable
Manager
(09) ) Cable/Tube
Manifold
(10) Single Duct Tie Point
(04) Pedestal Cable
Manager
Cable Ties Splice ProtectorsTube Cutter
Marker PenScissors Cross-Head
Screwdriver
What You Will Need Related Products
FCP2 Fiber Cleaning Kit for SC/ST/FC/LC

5
Level 4 96f PoC Backboard
© AFL Hyperscale. All rights reserved
Backboard Installation
Slot studs into back panel - no tools required.
1
Backboard must be central, top, location as shown.
Rear Section View

6© AFL Hyperscale. All rights reserved
24f cable looped inside the raceway.
Use tie-off positions for network duct/cable.
Secure using hose clip.
5
3
Install 24f cable – minimum overlength 3m from
gas block (Ø3mm blowing cable only).
Cut the ducts to length and push duct into teeth
and secure with cable tie. Push on blowing
indicator (not supplied).
4
2
Installation Process

7
Level 4 96f PoC Backboard
© AFL Hyperscale. All rights reserved
Splitter input bre map
7
Tray / Module map – Colours for document visualization only
Cable/Tray – Fibre Map
8
6
Installation Process
Tray Type Tray Position Linked to Module
8mm Splice Tray
12
11
10
9
4 x 1x4
Splitter Tray
812
11
710
9
68
7
56
5
44
3
32
1
8mm Splice Tray
2
1
* Virgin Media
recommended
ber routing.
Please check
splicing schedule
* Virgin Media
recommended
ber routing.
Please check
splicing schedule

8© AFL Hyperscale. All rights reserved
Overall Routing
9
1:4 Splitter Outputs
(routed to modules)
1:4 Splitter Outputs
(routed to splice tray)
Network ber
from L3 – all 24
into one tray
Cable Routing

9
Level 4 96f PoC Backboard
© AFL Hyperscale. All rights reserved
Routing 1:4 Splitter Outputs trays 3-5 down to network splice tray. Excess splitter input tail length should be
stored in the splitter trays, not the splice trays.
10
1:4 Splitter Outputs
(routed to modules)
1:4 Splitter Inputs
(routed to splice tray)
1x4 G.657A2
splitter
1:4 Routing: Trays 3-5

10 © AFL Hyperscale. All rights reserved
1:4 Routing: Trays 6-8
Routing 1:4 Splitter Outputs trays 6-8 down to network splice tray. Excess splitter input tail length should be
stored in the splitter trays, not the splice trays.
11
1:4 Splitter
Outputs
(routed to
modules)
1:4 Splitter Inputs
(routed to splice
tray)
1x4 G.657A2
splitter

11
Level 4 96f PoC Backboard
© AFL Hyperscale. All rights reserved
Splice 1:4 Inputs to network bre
12
Network ber
from L3 spliced
into bottom tray
1:4 Splitter Inputs
(routed to splice tray)
Splice
protectors
1:2 Input Splicing

12 © AFL Hyperscale. All rights reserved
Splitter “Prohibited” Port Label
(Labels must be installed at commisioning stage)
Remove dust caps.
1
Installation of the label is now complete.
3
Replace dust caps through label.
2
Only use on non-live ports.
Check MDR patching schedule to identify
which port needs to be covered over.
Ordering Information
Splitter Prohibited
Port Label
SKU: 10011758

13
Level 4 96f PoC Backboard
© AFL Hyperscale. All rights reserved
Splitter Specication
Type 1xN 1x4
Operating Wavelength Range (nm) 1260~1650nm
Insertion Loss (dB) Max 7.6 (with connectors)
PDL (dB) Max 0.2
Uniformity (dB) Max 0.6
PLC Return Loss (dB) Min 55
Directivity (dB) Min 55
Operating Temperature (°C)
-40~+85
Storage Temperature (°C)
Housing Dimension (mm) LxWxH 60x7x4
Fiber Type G.657A2

14 © AFL Hyperscale. All rights reserved
Notes

15
Level 4 96f PoC Backboard
© AFL Hyperscale. All rights reserved
Notes

Thank you for choosing AFL Hyperscale
AFLHSL496fPOC140322
