Agilent Technologies E4400-60622 Installation and operation manual

Installation Note
Part Number E4400-90542
Printed in USA December 2002
Agilent Technologies ESG Vector Signal Generator E4438C
Semi-Rigid Cable Replacement Kits
Kit Part Numbers:
E4400-60622,
E4400-60623,
E4400-60624,
E4400-60625,
E4400-60626,
E4400-60627,
E4400-60628,
E4400-60629,
E4400-60630,
and E4400-60631

Notice
The information contained in this document is subject to change without notice.
Agilent Technologies makes no warranty of any kind with regard to this material, including but not
limited to, the implied warranties of merchantability and fitness for a particular purpose. Agilent
Technologies shall not be liable for errors contained herein or for incidental or consequential
damages in connection with the furnishing, performance, or use of this material.
© Copyright 2002 Agilent Technologies Inc.

3
Agilent Technologies ESG Vector Signal Generator E4438C
Semi-Rigid Cable Replacement Kits
Kit Part Numbers E4400-60622, E4400-60623, E4400-60624,
E4400-60625, E4400-60626, E4400-60627, E4400-60628,
E4400-60629, E4400-60630, and E4400-60631
Introduction
This kit contains the parts and instructions to replace the semi-rigid cables on the E4438C Vector Signal
Generator.
Installation includes the following steps:
1. Functionality Check.
2. Remove the outer and inner covers.
3. Remove daughterboard card cage boards.
4. Remove the old semi-rigid cables.
5. Install the new semi-rigid cables.
6. Replace daughterboard card cage boards.
7. Replace inner covers.
8. Verify the functionality of the signal generator.
9. Re-calibrate the signal generator.
10.Re-assemble the signal generator
11.Perform the functionality check of the signal generator.
Product Affected: . . . . . . . . . . . . . . . . . . . . . . . . . E4438C
Serial Numbers: . . . . . . . . . . . . . . . . . . . . . . . . . . All
Options: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
To Be Performed By: . . . . . . . . . . . . . . . . . . . . . . (X) Agilent Technologies Service Center
( ) Personnel Qualified by Agilent Technologies
( ) Customer
Estimated Installation Time: . . . . . . . . . . . . . . . 1.0 hours
Estimated Verification Time: . . . . . . . . . . . . . . .

4
Installation Kit Parts List
Table 1 Replacement Cable Kit for W11 E4400-60622
Item Quantity Description Part Number
12
Retainer Ring 0510-1643
2 2 Retainer Cable E4400-40002
3 1 Cable AY Jumper E4423-20025
4 1 Installation Note E4400-90542
Table 2 Replacement Cable Kit for W41 E4400-60623
Item Quantity Description Part Number
12
Retainer Ring 0510-1643
2 2 Retainer Cable E4400-40002
3 1 Cable out to Synth E4423-20024
4 1 Installation Note E4400-90542
Table 3 Replacement Cable Kit for W42 E4400-60624
Item Quantity Description Part Number
11
Retainer Ring 0510-1643
2 1 Retainer Cable E4400-40002
3 1 Cable Coherent Carrier E4400-20553
4 1 Installation Note E4400-90542
Table 4 Replacement Cable Kit for W43 E4400-60625
Item Quantity Description Part Number
11
Retainer Ring 0510-1643
2 1 Retainer Cable E4400-40002
3 1 Cable Out-Atten M51 E4400-20558
4 1 Installation Note E4400-90542

5
Table 5 Replacement Cable Kit for W44 E4400-60626
Item Quantity Description Part Number
12
Retainer Ring 0510-1643
2 2 Retainer Cable E4400-40002
3 1 Cable 1 GHz Jumper E4423-20026
4 1 Installation Note E4400-90542
Table 6 Replacement Cable Kit for W47 E4400-60627
Item Quantity Description Part Number
11
Retainer Ring 0510-1643
2 1 Retainer Cable E4400-40002
3 1 Cable Output to Mechanical attenuator E4400-20565
4 1 Installation Note E4400-90542
Table 7 Replacement Cable Kit for W50 E4400-60628
Item Quantity Description Part Number
11
Retainer Ring 0510-1643
2 1 Retainer Cable E4400-40002
3 1 Cable-Atten CB AY E4400-20557
4 1 Installation Note E4400-90542
Table 8 Replacement Cable Kit for W56 E4400-60629
Item Quantity Description Part Number
11
Retainer Ring 0510-1643
2 1 Retainer Cable E4400-40002
3 1 Cable Coupler to OTPT E4400-20562
4 1 Installation Note E4400-90542
Table 9 Replacement Cable Kit for W58 E4400-60630
Item Quantity Description Part Number
12
Retainer Ring 0510-1643
2 2 Retainer Cable E4400-40002
3 1 Cable OTPT to OTPT E4400-20563
4 1 Installation Note E4400-90542

6
Tools Required
• TORX T-10 driver
• TORX T-15 driver
• TORX T-20 driver
• Long Nose pliers
• 5/16 open-ended wrench
Safety Considerations
WARNING Before you disassemble the instrument, turn the power switch off and
unplug the signal generator. Failure to unplug the signal generator can
result in personal injury.
CAUTION Electrostatic discharge (ESD) can damage or destroy electronic components. All
work on electronic assemblies should be performed at a static-safe workstation.
Table 10 Replacement Cable Kit for W84 E4400-60631
Item Quantity Description Part Number
11
Retainer Ring 0510-1643
2 1 Retainer Cable E4400-40002
3 1 Cable COCAR 1EM E4400-20556
4 1 Installation Note E4400-90542

7
Checking Signal Generator Functionality
Use the following procedure to confirm that the signal generator powers on and that the internal check
does not identify errors. The internal check evaluates the operation of the signal generator and returns an
error message if it detects a problem.
NOTE When signal generators with Option 1E5 are first connected to ac line power, the error
message ERROR 514, Reference Oven Cold occurs, which causes both the OVEN COLD
annunciator and the ERR annunciator to turn on.
After approximately five minutes, the OVEN COLD annunciator automatically clears, but the
ERR annunciator remains on until all errors are cleared from the error queue.
1. Turn on the signal generator and let it warm up for at least five minutes.
2. Run the instrument self-test by pressing Utility > Instrument Info/Help Mode > Self Test > Run Complete Self
Test. Upon completion, a summary of the self-test will be displayed. Use the service guide to
troubleshoot any failures detected by the test.
NOTE Some circuits may require up to 50 minutes to warm up before passing the self-test. If
self-tests continue to fail after 50 minutes of warm up, troubleshoot the instrument.
3. Check to see if the ERR annunciator is on.
•IftheERR annunciator is on, review the error messages in the error queue by pressing
Utility > Error Info >View Next Error Message. The first error message in the error queue appears in the
display text area. (Refer to the signal generator error messages document for information about each
error message.)
After resolving all problems causing errors, press Utility > ClearErrorQueue(s).
•IftheERR annunciator is off, the signal generator functionality check has passed.

8
Removing Outer and Inner Covers
Tools Required
• TORX T-10 driver
• TORX T-15 driver
• TORX T-20 driver
Removing the Outer Cover
Refer to Figure 1.
1. Disconnect the power cord.
2. Using a T-20 driver, remove the two strap handles (1) by loosening the screws.
3. Using a T-15 driver, remove the center screws (3) on the four rear-panel feet (2).
4. Remove the four bottom feet (5) and (6) from the cover by pushing and pulling the tab.
5. Slide the outer cover (4) off the frame.
Removing the Inner Top Cover
Refer to Figure 1.
1. Using a T-10 driver, remove the ten screws (10) from the inner-top cover (7).
2. Remove the inner-top cover.
Removing the Instrument Side Cover
Refer to Figure 1.
1. Using a T-10 driver, remove the four screws (8) from the inner-side cover (9).
2. Slide the inner-side cover forward to unlock the sheet metal from the chassis.
3. Remove the inner-side cover.

9
Figure 1 Outer and Inner Cover Removal

10
Removing A13 thru A18 Daughter Card Cage Boards
Refer to Figure 2.
Use this procedure to remove any one of the following assemblies:
•A13 Output Board
•A14 Extended Frequency Output Board (Option 506)
•A15 Sampler Board (Option UNJ or Option 506)
•A16 Frac-N Board (Option UNJ or Option 506)
•A17 Synthesizer (Option 501, 502, 503 or 504)
•A18 Reference Board (Option 501, 502, 503, 504, UNJ or 506)
1. Lift the retention levers on the board you want to remove.
2. Disconnect the board from the A19 Daughterboard.

11
Figure 2 Card Cage Board Removal

12
Replacing W11, W41, W42, W43, W44, W47, W50, W56, W58, or W84
Remove Old Semi-Rigid Cables
For the location of W11, W41, W42, W43, W44, and W47, refer to Figure 3.
For the location of W50, W56, W58, and W84, refer to Figure 4.
1. Refer to Figure 5. Remove the snap ring (1) from the cable retainer (2) of the cable you want to remove.
The cable is now disconnected from the instrument chassis (3).
2. Disconnect the other end of the cable (4) and remove the cable.
Figure 3 W11, W41, W42, W43, W44, and W47 Semi Rigid Cable Locations

13
Figure 4 W50, W56, W58, and W84 Semi Rigid Cable Locations

14
Figure 5 Cable Retainer
Connect New Semi-Rigid Cables
Refer to Figure 5.
1. When installing a new cable, a new cable retainer (2) must be attached to one end of the cable (4). Verify
the cable retainer is correctly attached by listening for a click, as you slide the cable retainer over the
end of the cable.
2. Insert the end of the cable that has the cable retainer connected to it, into the opening of the instrument
chassis. Secure it with a snap ring (1).
3. Connect the other end of the cable to the appropriate location. Torque to 9 in-lbs.

15
Replace Daughterboard Card Cage Boards
1. Replace the board(s) into the card cage slot. Refer to Figure 2.
2. Press down on the retention levers until the board connects with the A19 Daughterboard.
Replace the Inside Top and Side Covers
Refer to Figure 1.
1. Reinstall the inside top (7) and side (9) covers by reversing the order of the steps in the “Removing the
Inner Top Cover” and “Removing the Inner Top Cover” procedures.
2. Torque all T-10 screws to 9 in-lbs.
Verification of Signal Generator Operation Signal Generator
1. Turn the signal generator on. Let the signal generator warm up for five minutes.
2. Press the front panel PRESET button to reset the signal generator.
3. Check for error messages.
•If error messages occur, refer to “Checking Signal Generator Functionality” on page 7, to clear the
error messages.
•If no error messages are present, the signal generator should function properly.
Instrument Calibration and Performance Tests
1. Allow it to warm up for 30 minutes.
2. Perform the calibration adjustments as called out in the “Post repair Procedures” chapter of the service
guide.
3. Perform the instrument performance tests as called out in the “Post Repair Procedures” chapter of the
service guide.
Re-Assembling the Instrument
Refer to Figure 1.
1. Turn the instrument off and unplug it.
2. Reinstall the outer instrument cover by reversing the order of the steps in the “Removing the Outer
Cover” procedure.
3. Torque all T-10 screws to 9 in-lbs.
4. Torque all T-15 and T-20 screws to 21 in-lbs.

16
Perform the Functionality Check of the Signal Generator
1. Reboot the signal generator, allowing it to warm up for five minutes.
2. Press the front panel PRESET button to reset the signal generator.
3. Check for error messages.
•If error messages occur, refer to “Checking Signal Generator Functionality” on page 7 to clear the
error messages.
•If no error messages are present, the signal generator should function properly.
