Agilent E5070BU/E5071BU Option 017
Removable Hard Disk Upgrade Kit
Upgrade Manual
Second Edition
Agilent Part No. E5070-90118
June 2005
Printed in Japan

2
Notices
The information contained in this document is subject to change without notice.
This document contains proprietary information that is protected by copyright.All rights
are reserved. No part of this document may be photocopied, reproduced, or translated to
another language without the prior written consent of the Agilent Technologies.
© Copyright 2005 Agilent Technologies
Manual Printing History
The manual’s printing date and part number indicate its current edition. The printing date
changes when a new edition is printed. (Minor corrections and updates that are
incorporated at reprint do not cause the date to change.) The manual part number changes
when extensive technical changes are incorporated.
May 2005 First Edition
June 2005 Second Edition
Typeface Conventions
Sample (bold) Boldface type is used when a term is defined or
emphasis.
Sample (Italic) Italic type is used for emphasis.
key Indicates a hardkey (key on the front panel or
external keyboard) labeled “Sample.” “key” may
be omitted.
Sample menu/button/box Indicates a menu/button/box on the screen labeled
“Sample” which can be selected/executed by
clicking. “menu,” “button,” or “box” may be
omitted.
Sample block/toolbar Indicates a block (group of hardkeys) or a toolbar
(setup toolbar) labeled “Sample.”
Sample 1 - Sample 2 - Sample 3 Indicates a sequential operation of Sample 1,
Sample 2, and Sample 3 (menu, button, or box).
“-” may be omitted.

3
1 General Information
This chapter describes the Upgrade Kit, contents of the kit, and required tools to install the
Option 017 into the Agilent E5070B/E5071B.

4Chapter1
General Information
Option 017 Upgrade Kit
Option 017 Upgrade Kit
The purpose of this kit is to install the option 017 removable hard disk upgrade into the
Agilent E5070B/E5071B.
This upgrade can be performed by Agilent qualified personnel. After incoming inspection,
this kit should be sent to the nearest Agilent Technologies service office with the
E5070B/E5071B for option upgrade.
Contents of the Agilent E5070BU/E5071BU Option 017
Upgrade Kit
The kit includes the parts listed in Table 1-1. If anything is missing, contact the nearest
Agilent Technologies office.
Table 1-1 Contents of the Agilent E5070BU/E5071BU Option 017 Upgrade Kit
Description Agilent PN Qty.
Upgrade Manual (This manual) E5070-90108 1
HDD BOX E5070-01254 1
INNER COVER E5070-01253 1
INTERFACE BD PCA E5070-66534 1
CONNECTOR BD PCA E5070-66535 1
HDD BRACKET E5070-01255 1
HEAT TRANSFER SHEET E5070-25051 1
FLAT CABLE ASSY E5070-61638 1
LID E5070-01252 1
COVER ASSY FOR E5070B/E5071B E5070-04023 1
ANGLE E5070-01256 1
GUIDE-PC BOARD NYL 19 MM-LG 0403-1143 1
CLAMP-CABLE .187-DIA .25-WD NYL 1400-0866 1
SADDLE-WIRE 1400-1051 1
CLAMP-FL-CA 1-WD PVC 1400-0611 1
CABLE-TIE .062-1 .25-DIA .14-WD NYL 1400-0493 1
BRACKET E5070-01258 1
WIRE ASSY E5070-61637 1

Chapter 1 5
General Information
Contents of the Agilent E5070BU/E5071BU Option 017 Upgrade Kit
SCREW-MACH M3.0 x 6 PN T10 0515-0430 9
SCREW-MACH M3.0 x 8 PN T10 0515-0372 1
SCREW-MACH M2.5 x 6 FL T8 0515-2028 2
SCREW-MACH M3.0 x 4 FL T10 0515-2146 8
SCREW-MACH M3.0 x 10 PN T10 0515-0374 4
Table 1-1 Contents of the Agilent E5070BU/E5071BU Option 017 Upgrade Kit
Description Agilent PN Qty.

6Chapter1
General Information
Contents of the Agilent E5070BU/E5071BU Option 017 Upgrade Kit

7
2 Option Installation
This chapter describes the procedure to install the option 017 into the Agilent
E5070B/E5071B.

8Chapter2
Option Installation
Introduction
Introduction
This chapter describes the procedure to install Option 017 into the E5070B/E5071B. The
procedure consists of the following items.
• Installation Requirements
• Hardware Installation
Update Procedure
Installation Requirement
• TORX Screwdriver, T8, T10, T15, and T20
Hardware Installation
Refer to Figure 2-2, Figure 2-3, and Figure 2-4 for this procedure.
Step 1. Remove the outer cover.
Step 2. Remove the two TORX T10 screws (item 1) fastening the A27 mass storage disk drive
assembly.
Step 3. Disconnect the three cables connected to the A27 assembly, and lift the A27 assembly.
Step 4. Remove the four TORX T10 screws (item 2), and remove the mass storage disk drive from
the A27 assembly.
Step 5. Remove two TORX T10 screws (item 3) fastening the handler I/O bracket on rear panel.
Step 6. Pull the bracket with handler I/O board only a little.
Step 7. Remove two TORX T10 screws (item 4) fastening the handler I/O bracket, and remove the
bracket from the handler I/O board.
Step 8. Fasten the new bracket using the two TORX T10 screws to the handler I/O board.
Step 9. Fasten the new bracket with the handler I/O board using the two TORX T10 screws to the
rear panel.
Step 10. Connect the power cable (item 5) to the removable hard disk assembly.
Twist the flat cable (item 5) and connect to the removable hard disk assembly.
Replace the wire connected to the Oven assembly with the new wire, and connect it (item
5) to the removable hard disk assembly.
Step 11. Fasten the removable hard disk assembly with angle to chassis using the five TORX T10
screws (item 6).

Chapter 2 9
Option Installation
Update Procedure
Step 12. Clamp the slack cable between the power unit and the FDD, the Oven assembly and the
removable hard disk assembly (item 7).
Step 13. Clamp wires between the power unit and the FDD (item 8).
Step 14. Stick the cable clamp included in this kit as shown Figure 2-2 (item 9), and then clamp the
slack flat cable between the mother board and the removable hard disk assembly.
Step 15. Clamp all unused cables of the power unit by cable tie (item 10).
Step 16. Stick the heat transfer sheet to the mass storage disk drive rear side (Refer to Figure 2-1).
Figure 2-1 Heat Transfer Sheet
Step 17. Remove the four TORX T10 screws (item 11), and remove the two TORX T8 screws (item
12).
Step 18. Remove the HDD bracket from the connector board.
Step 19. Connect the mass storage disk drive with heat transfer sheet to the connector board.
Step 20. Fasten the mass storage disk drive with the connector board to the HDD bracket using the
four TORX T10 screws (item 13) and the two TORX T8 screws (item 12).
Step 21. Fasten the HDD bracket to the HDD box using the four TORX T10 screws (item 11).
Step 22. Connect the flat cable between the connector board and the interface board.
Step 23. Fasten the cover assembly for the removable hard disk.

10 Chapter2
Option Installation
Update Procedure
Figure 2-2 Hardware Installation (1 of 3)

Chapter 2 11
Option Installation
Update Procedure
Figure 2-3 Hardware Installation (2 of 3)

12 Chapter2
Option Installation
Update Procedure
Figure 2-4 Hardware Installation (3 of 3)
