Agilent Technologies 8922 User manual

HP/Agilent 8922 GSM HSCSD Test System
Option #K09
Supplementary
User’s Guide
Systems Covered
HP/Agilent 8922 P Multi-Band Test System
Manufacturing Part Number: 08922-90218
© Copyright February 1999 Agilent Technologies

ii
Warranty
This Agilent Technologies instrument product is warranted against
defects in material and workmanship for a period of one year from date
of shipment. During the warranty period, Agilent Technologies will at its
option, either repair or replace products which prove to be defective
For warranty service or repair, this product must be returned to a service
facility designated by Agilent Technologies. Buyer shall prepay shipping
charges to Agilent Technologies and Agilent Technologies shall pay
shipping charges, duties, and taxes for products returned to Agilent
Technologies from another country
Agilent Technologies warrants that its software and firmware designated
by Agilent Technologies for use with an instrument will execute its
programming instructions when properly installed on that instrument.
Agilent Technologies does not warrant that the operation of the
instrument, or software, or firmware will be uninterrupted or error free.
Limitation of Warranty
The foregoing warranty shall not apply to defects resulting from
improper or inadequate maintenance by Buyer, Buyer-supplied software
or interfacing, unauthorized modification or misuse, operation outside of
the environmental specifications for the product, or improper site
preparation or maintenance.
NO OTHER WARRANTY IS EXPRESSED OR IMPLIED. AGILENT
TECHNOLOGIES SPECIFICALLY DISCLAIMS THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE.

iii
Limitation of Remedies and Liability
THE REMEDIES PROVIDED HEREIN ARE BUYER’S SOLE AND
EXCLUSIVE REMEDIES. AGILENT TECHNOLOGIES SHALL NOT
BE LIABLE FOR ANY DIRECT, INDIRECT, SPECIAL, INCIDENTAL,
OR CONSEQUENTIAL DAMAGES, WHETHER BASED ON
CONTRACT, TORT, OR ANY OTHER LEGAL THEORY.
Responsibilities of the Customer
The customer shall provide;
• Access to the products during the specified periods of coverage to
perform maintenance.
• Adequate working space around the products for servicing by Agilent
Technologies personnel.
• Access to and use of all information and facilities determined
necessary by Agilent Technologies to service and/or maintain the
products. (In so far as these items may contain proprietary or
classified information, the customer shall assume full responsibility
for safeguarding and protection from wrongful use.)
• Routine operator maintenance and cleaning as specified in the
Agilent Technologies Operating and Service Manuals.
• Consumables such as paper, disks, magnetic tapes, ribbons, inks,
pens, gases, solvents, lamps, filters, fuses, seals, etc.
Certification
Agilent Technologies certifies that this product met its published
specifications at the time of shipment from the factory. Agilent
Technologies further certifies that its calibration measurements are

iv
traceable to the United States National Bureau of Standards and
Technology, to the extent allowed by the Bureau’s calibration facility, and
to the calibration facilities of other International Standards
Organization members.
Assistance
Product maintenance agreements and other customer assistance
agreements are available forAgilent Technologies products.
For any assistance, contact your local Agilent Technologies Sales and
Service Office. For a list of contact information, “Sales and Service
Offices” on page 72.
Notices
The information contained in this document is subject to change without
notice. AGILENT TECHNOLOGIES MAKES NO WARRANTY OF ANY
KIND WITH REGARD TO THIS MATERIAL, INCLUDING, BUT NOT
LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE. Agilent Technologies
shall not be liable for errors contained herein or for incidental or
consequential damages in connection with the furnishing, performance
or use of this material.
Agilent Technologies assumes no responsibility for the use or reliability
of its software on equipment that is not furnished by Agilent
Technologies.
Restricted Rights Legend
If Software is for use in the performance of a U.S. Government prime
contract or subcontract, Software is delivered and licensed as
"Commercial computer software" as defined in DFAR 252.227-7014 (June
1995), or as a "commercial item" as defined in FAR 2.101(a) or as

v
"restricted computer software" as defined in FAR 52.227-19 (June 1987)
or any equivalent agency regulation or contract clause. Use, duplication
or disclosure of Software is subject to Agilent Technologies’ standard
commercial license terms and non-DOD Departments and Agencies of
the U.S. Government will receive no greater than Restricted Rights as
defined in FAR 52.227-19(c)(1-2) (June 1987). U.S. Government users will
receive no greater than Limited Rights as defined in FAR 52.227-14
(June 1987) or DFAR 252.227-7015 (b)(2) (November 1995), as applicable
in any technical data. Copyright 2000 Agilent Technologies Inc. All
Rights Reserved.
Statement of Compliance
This product conforms to EN61010-1(1993) / IEC 1010-1(1990)
+A1(1992) +A2(1994) /CSA C22.2 No. 1010.1(1993) Safety requirements
for Electrical Equipment for Measurement, Control and Laboratory Use,
and has been supplied in a safe condition. The instruction documentation
contains information and warnings which must be followed by the user
to ensure safe operation and to maintain the instrument in a safe
condition.
Electromagnetic Compatibility (EMC)
Information
This product has been designed to meet the protection requirements of
the European Communities Electromagnetic Compatibility (EMC)
directive:
EN55011:1991 (Group 1, Class A)
EN50082-1:1992
- IEC 1000-4-2 (1995) ESD
- IEC 1000-4-3 (1995) Radiated Susceptibility
- IEC 1000-4-4 (1995) EFT
In order to preserve the EMC performance of this product, any cable
which becomes worn or damaged, must be replaced with the same type
and specification.

vi
Sound Emission
Manufacturer’s Declaration
This statement is provided to comply with the requirements of the
German Sound Emission Directive, from 18 January 1991.
This product has a sound pressure emission (at the operator position) <
70 dB(A).
• Sound Pressure Lp < 70 dB(A).
• At Operator Position.
• Normal Operation.
• According to ISO 7779:1988/EN 27779:1991 (Type Test).
Herstellerbescheinigung
Diese Information steht im Zusammenhang mit den Anforderungen der
Maschinenlärminformationsverordnung vom 18 Januar 1991.
• Schalldruckpegel Lp < 70 dB(A).
• Am Arbeitsplatz.
• Normaler Betrieb.
• Nach ISO 7779:1988/EN 27779:1991 (Typprfung).
Safety Information
The following general safety precautions must be observed during all
phases of operation, service, and repair of this instrument. Failure to
comply with these precautions or with specific warnings elsewhere in
this manual violates safety standards of design, manufacture, and

vii
intended use of the instrument. Agilent Technologies assumes no
liability for the customer’s failure to comply with these requirements.
WARNING This is a Safety Class I instrument (provided with a protective
earthing ground, incorporated in the power cord). The mains
plug shall only be inserted in a socket outlet provided with a
protective earth contact. Any interruption of the protective
conductor inside or outside of the instrument is likely to make
the instrument dangerous. Intentional interruption is
prohibited.
DO NOT operate the product in an explosive atmosphere or in the
presence of flammable gasses or fumes.
DO NOT use repaired fuses or short-circuited fuseholders: For continued
protection against fire, replace the line fuse(s) only with fuse(s) of the
same voltage and current rating and type.
DO NOT perform procedures involving cover or shield removal unless
you are qualified to do so: Operating personnel must not remove
equipment covers or shields. Procedures involving the removal of covers
and shields are for use by service-trained personnel only.
DO NOT service or adjust alone: Under certain conditions, dangerous
voltages may exist even with the equipment switched off. To avoid
dangerous electrical shock, service personnel must not attempt internal
service or adjustment unless another person, capable of rendering first
aid and resuscitation, is present.
DO NOT operate damaged equipment: Whenever it is possible that the
safety protection features built into this product have been impaired,
either through physical damage, excessive moisture, or any other reason,
REMOVE POWER and do not use the product until safe operation can be
verified by service-trained personnel. If necessary, return the product to
an Agilent Technologies Sales and Service Office for service and repair
to ensure the safety features are maintained.
DO NOT substitute parts or modify equipment: Because of the danger of
introducing additional hazards,do not install substitute parts or perform
any unauthorized modification to the product. Return the product to an
Agilent Technologies Sales and Service Office for service and repair to
ensure the safety features are maintained.

viii
Safety Symbols
The following symbols on the instrument and in the manual indicate
precautions which must be taken to maintain safe operation of the
instrument
Safety Symbols
The Instruction Documentation Symbol. The product is
marked with this symbol when it is necessary for the user
to refer to the instructions in the supplied documentation.
Indicates the field wiring terminal that must be connected
to earth ground before operating the equipment - protects
against electrical shock in case of fault.
Frame or chassis ground terminal - typically connects to
the equipment's metal frame.
Alternating current (AC)
Direct current (DC)
Indicates hazardous voltages.
WARNING Warning denotes a hazard. It calls attention to a
procedure, which if not correctly performed or adhered to
could result in injury or loss of life. Do not proceed
beyond a warning note until the indicated conditions are
fully understood and met.
CAUTION Caution denotes a hazard. It calls attention to a
procedure, which if not correctly performed or adhered to
could result in damage to or destruction of the
instrument. Do not proceed beyond a warning note until
the indicated conditions are fully understood and met.

ix
The CE mark shows that the product complies with all
relevant European Legal Directives.
ISM 1-A This is a symbol of an Industrial, Scientific, and Medical
Group 1 Class A product.
The CSA mark is a registered trademark of the Canadian
Standards Association, and indicates compliance to the
standards defined by them.
Indicates that a laser is fitted. The user must refer to the
manual for specific Warning or Caution information to
avoid personal injury or damage to the product.
Safety Symbols

x
About this Guide
Overview
This User’s Guide is a supplement to the manuals currently supplied
with the HP/Agilent 8922 GSM Test Sets. The information contained in
this User’s Guide is only relevant to the additional features of the HP/
Agilent 8922 GSM HSCSD Test System. For more information on the
HP/Agilent 8922 and HP/Agilent83220, refer the following Guides;
•Agilent 8922M⁄S User’s Guide
•Agilent 8922M⁄S Programming Reference Guide
•Agilent 83220A⁄E User’s Guide
• Agilent Multi-Band Test System Supplementary User’s Guide
User’s Guide - Abbreviations
For clarity, and unless otherwise stated, the following abbreviations will
be used:
HP/Agilent 8922P/X Option 010: this will be abbreviated to HP/
Agilent 8922
HP/Agilent 83220A/E Option 010: this will be abbreviated to HP/
Agilent 83220

Contents
xi
1. Understanding the HP/Agilent 8922 GSM HSCSD Test System
Getting an overview of the HP/Agilent 8922 GSM HSCSD Test System.2
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
2. Setting up the HP/Agilent 8922 GSM HSCSD Test System
Before you start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Checking the HP/Agilent 8922 Requirements for HSCSD . . . . . . . . . . . .7
Making the front panel connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Making the rear panel connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Enabling the HSCSD functionality . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Calibrating the overall system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
3. Manual operation
Configuring the system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Establishing a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Making measurements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Choosing which timeslot to measure. . . . . . . . . . . . . . . . . . . . . . . . . . .19
Measuring BER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Changing band and making measurements in the
E-GSM900 and DCS 1800 bands19
Changing power levels, timeslot and channels . . . . . . . . . . . . . . . . . . . .20
Ending a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
4. Screens
Config screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
1. Instrument type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
2. Slave address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

xii
Contents
HSCSD screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
1. Master downlink amplitude . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
2. Slave offset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
3. Master channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
4. Master timeslot. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
5. Slave timeslot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
6. Call Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
7. Data rate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
8. Measure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
9. Master Tx level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
10. Master input level. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
11. Master mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
12. Slave Tx level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
13. Slave input level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
14. Slave control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
15. Mobile reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
16. Peak power display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
17. To Screen menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Fast BER Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Loopback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
5. Remote operation
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Configure Subsystem GPIB Commands . . . . . . . . . . . . . . . . . . . . . . . . . 43
CONFigure:INSTrument[:TYPE]. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Display Subsystem GPIB Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . 44
DISPlay:SCReen HSCSD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
HSCSD Subsystem GPIB Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . 45
HSCSd:MASTer:TCH:ARFCn . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
HSCSd:MASTer:STATus:TCH:TSLot . . . . . . . . . . . . . . . . . . . . . . . . . 49

Contents
xiii
HSCSd:MASTer:DOWNlink:AMPLitude . . . . . . . . . . . . . . . . . . . . . . .50
HSCSd:MASTer:TCH:TLEVel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
HSCSd:MASTer:UPLink:AMPLitude . . . . . . . . . . . . . . . . . . . . . . . . . .52
HSCSd:MASTer:UPLink:AMPLitude:CONTrol. . . . . . . . . . . . . . . . . .53
HSCSD:MASTer:CALL:TYPE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
HSCSD:MASTer:CALL:RATE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
HSCSd:SLAVe:STATus:SYNC. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
HSCSd:SLAVe:STATus:TCH:TSLot? . . . . . . . . . . . . . . . . . . . . . . . . . .57
HSCSd:SLAVe:DOWNlink:AMPLitude:OFFSet. . . . . . . . . . . . . . . . . .58
HSCSd:SLAVe:TCH:TLEVel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
HSCSd:SLAVe:UPLink:AMPLitude . . . . . . . . . . . . . . . . . . . . . . . . . . .60
HSCSd:SLAVe:UPLink:AMPLitude:CONTrol . . . . . . . . . . . . . . . . . . .61
Remote operating procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
Configuring the system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
Establishing a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
Making measurements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
Changing channels, timeslot and power levels. . . . . . . . . . . . . . . . . . .64
Ending a call. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65
Example code showing a dual-band handover from E-GSM to DCS . . .66
6. Returning equipment for repair
Return Procedure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .70
Sales and Service Offices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72
Asia Pacific:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72
Japan: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72
Australia/New Zealand: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72
Canada:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73
Europe: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73
Latin America: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73
United States:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73

xiv
Contents
A. Upgrading the HOP Controller ROM and Firmware
Upgrading the Hop Controller ROM. . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Upgrading the firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

1
1 Understanding the HP/Agilent
8922 GSM HSCSD Test System
This chapter provides an overview of the HP/Agilent 8922 GSM HSCSD
Test System.

2Chapter1
Understanding the HP/Agilent 8922 GSM HSCSD Test System
Getting an overview of the HP/Agilent 8922 GSM HSCSD Test System
Getting an overview of the HP/Agilent 8922
GSM HSCSD Test System
The HP/Agilent 8922 GSM HSCSD Test System option #K09, is ideal for
mobile testing in research and development, and can also be used in
manufacturing test applications. The HP/Agilent 8922 GSM HSCSD Test
System option #K09 consists of two HP/Agilent 8922 P systems
connected together in a master/slave setup as shown below. A single unit
version of the HP/Agilent 8922 GSM HSCSD Test System (option #K17),
ideal for manufacturing and service test, is also available.
Figure 1-1 The HP/Agilent 8922 GSM HSCSD Test System, option #K09
Remote operation using
Manual operation using
GPIB commands
front panel user interface
Master unit
GPIB control bus
Frame reset
10 MHz
Slave unit

Chapter 1 3
Understanding the HP/Agilent 8922 GSM HSCSD Test System
Getting an overview of the HP/Agilent 8922 GSM HSCSD Test System
The HP/Agilent 8922 GSM HSCSD Test System is used either as a
stand-alone instrument controlled manually via the front panel user
interface, or as part of an automated test system controlled remotely
over the GPIB bus using a PC or workstation. Note that manual and
remote operation are not possible simultaneously.
The HP/Agilent 8922 GSM HSCSD Test System provides one
configuration consisting of two uplink and two downlink timeslots (2x2)
or two downlink and one uplink timeslot (2x1). Data rates of 9.6 and 14.4
kbit/s on each timeslot are supported. The timeslots used are always
adjacent, with the master channel in the first of these slots. You are able
to independently change the uplink and downlink power levels on the
two downlink timeslots and make measurements on either timeslot as
required.
Note that the system does not perform any data channel decoding on the
uplinks and only provides pre-coded data on the downlinks. The current
system only allows transparent data links, which means that the RLP
data layer is not supported.
Operating modes The master unit operates in Active Cell Mode and is responsible for all
protocol messages. The mobile must therefore camp to the master unit,
establish the call to it and receive channel assignment commands from it
etc.
The slave unit operates in Test Mode. It generates a second downlink
TCH and can analyze a second uplink TCH (if it exists). The slave unit
remains in synchronization with the master unit at all times.
The BCH of the slave unit includes information to prevent the mobile
from camping to the slave, thus ensuring that the mobile camps to the
master unit. To discourage unsynchronised operation, the slave unit does
not generate a downlink TCH unless it has received a reset signal from
the master unit.

4Chapter1
Understanding the HP/Agilent 8922 GSM HSCSD Test System
Features
Features
The HP/Agilent 8922 GSM HSCSD Test System supports the following
features. The full range of features available in speech mode is
maintained.
• Support of fully variable power level of each active timeslot on the
downlink. This provides complete freedom to control the amplitude of
the downlinks.
• Support of fully independent power control by protocol of each active
timeslot on the uplink. This allows you to independently set the Tx
level of each timeslot.
• Transmit SACCH in each active slot on the downlink (call
maintenance + power control) according to ETSI multi-frame
structure. This provides a SACCH frame in the correct position on
both the downlink TCHs.
• All existing measurement functionality and performance maintained
and performed on any slot independently. You can select either uplink
slot to measure, either by selecting one instrument or via a field on
the user interface.
• Support of protocol to set up a 2x2 or 2x1, 9.6 or 14.4 kbps timeslot
uplink/downlink data channel (both Mobile Originated and Mobile
Terminated). The existing HP/Agilent 8922P functionality to
originate or receive a call is still available.
• Support of burst-by-burst (fast) BER test on both 14.4 kbps timeslot
data channels simultaneously. The existing bit error test functionality
of the HP/Agilent 8922P is available in speech mode only.
• You can select any timeslot for the master channel in the range 2
through 5. The slave timeslot is always the following slot. Any
ARFCN can be used in any of the currently supported bands
(GSM900, E-GSM, DCS1800 and PCS1900).
• Dual-band assignment supported. The existing HP/Agilent 8922P
functionality to perform a dual-band assignment is maintained.
• All 2x2 HSCSD calls are in transparent mode and all 2x1 calls are in
non-transparent mode.

5
2 Setting up the HP/Agilent 8922
GSM HSCSD Test System
This chapter describes how to connect and set up the HP/Agilent 8922
GSM HSCSD Test System.

6Chapter2
Setting up the HP/Agilent 8922 GSM HSCSD Test System
Before you start
Before you start
WARNING The HP/Agilent 8922 is a Safety Class 1 product (provided with a
protective earth terminal). A safety earth ground must be
provided from the mains power source to the product input
wiring terminals, power cord, or supplied power cord set.
Whenever it is likely that the protection has been impaired, the
HP/Agilent 8922 GSM HSCSD Test System must be made
inoperative and be secured against any unintended operation.
WARNING If the HP/Agilent 8922 is to be energized via an external
autotransformer for voltage reduction, make sure that the
common terminal is connected to the neu tral pole of the power
source.
