Agriframes 39100-tbk User manual

8 X VINE ARCH CROSS POLES

WITH 3 RING CLAMPS

6 X LARGE END

PLUGS

12 X MOISTURE

SEALS

1 X ALLEN KEY

6 X UPRIGHTS

WITH ONE

REDUCED END

24 X GRUB

SCREWS (IN THE

RING CLAMPS) AND

SPARES IN A BAG

1 X HOLE

MAKER

AGRIFRAMES, Journal House, Hartcliffe Way, Bristol, BS3 5RJ

ORDERS (0)117 934 1790 FAX (0)117 934 1791 ORDER ONLINE www.agriframes.co.uk

Please read the assembly instructions

carefully prior to construction.

Tips:

Positioning of the Cross Poles

In many cases the position of the Cross Poles

is down to personal preference. However, if

you have the lattice option you will need to

leave the correct distance between bars.

On the bottom section the Cross Poles need

to be at least 3 inches above the base of the

tube.

Tips:

Cross Poles

Before positioning the Cross Poles on the

uprights, half screw in the grub screws to

the ring clamps on the spacer bars, to

reduce the risk of losing the screws.

Once correctly positioned tighten the

grub screw to secure the spacer bar to

the uprights.

Lattice Panel

For illustrative purposes we have only

shown one side fixed with the lattice

panels. Attach panels to both sides as you

proceed.

Issues:

If you are experiencing any issues with your Agriframes product please contact our customer services team

on 0117 934 1790 and quote your order reference.

WARNING: Contains small parts, tools and plastic bags. Keep children away until the unit is assembled and

everything is cleared away.

NOTE: The card, paper sack, and polythene bags are recyclable - please dispose of carefully

MISSING PARTS PROCEDURE: Please call our customer service team on 0117 934 1790 and quote your

order reference and quote the missing part. E.g. ASO-----, 2 uprights missing.

PARTS LIST

In the unlikely event you are missing any components please call 0117 934 1790 and state the name of the

product, size and description of the item. i.e. Classic Extra Vine Arch Matt Black, 1 x End Plug.

Assembly Instructions for Classic Extra Vine Arch - Matt Black

Product Code: 39100-TBK

6 X VINE ARCH

CURVES WITH ONE

REDUCED END

16 X SMALL END

PLUGS

*Lattice & Ties

Arch Cells Quantity

1.8m 5 x 4 4

4 x 4 4

100 X CABLE TIES

3 X ROOF CONNECTOR

CLASSIC EXTRA VINE ARCH - MATT BLACK

STEP 1:

END CAP

* ONLY FOR ORDERS WITH LATTICE PANELS. PANELS CAN BE ORDERED FROM www.agriframes.co.uk

STEP 3:

STEP 4:

STEP 5:

STEP 2:

Assembly Instructions for Classic Extra Vine Arch Matt Black

Please read these instructions carefully.

Step 1:

Before assembly check the cross poles to ensure the grub screws are inserted into the holes on the ring clamps.

oLoosen these grub screws ½ way out of the hole, to ensure when the ring clamps are moved into position the grub screw does not scratch the outer

coating of the metal.

Slide a moisture seal onto the reduced ends of all the vine arch curves.

Connect the reduced ends of 2 Vine Arch curves into the roof connectors, cover the joins between the poles with moisture seals. Repeat this process with

all of the Vine Arch Curves.

Slide a Cross pole onto the Vine Arch curves, on the outside of the arch.

oStarting with the top cross poles, these poles should be positioned towards the join of the curves. Once you are satisfied with the cross poles

position tighten the grub screw.

oThe second cross pole needs to be placed 40” below the top Cross Pole, to allow for the lattice infill. This may require the second cross pole to be

positioned on the join between the curve and the upright.

Slide a moisture seal over the end of the curve.

Attach the small end plug to the ends of the Cross poles.

Attach the lattice using the cable ties, once the ties are secured trim the excess.

Step 2:

Once the top of the arch has been completed move the structure to where it is to be installed and, firmly push the structure into the ground to make an

impression, indentation or mark to indicate where the uprights should be placed. Then remove the top structure and check that the marks can clearly be

seen.

Step 3:

Using the hole-maker create a hole 15” into the ground, where you have marked or indented the ground previously, ensure that the holes are vertical and

to the same depth.

Insert the end plugs into the non-reduced ends of the 6 uprights, then insert these uprights into the hole in ground, with the end plugs going into the soil.

Assembly Requires: a Rubber Mallet, an Allen Key (provided), a Ladder, Spirit Level, Pliers and a Tape Measure.

Step 4:

Once the uprights have been inserted, slide on 2 sets of Cross Poles to each set of uprights and once you are satisfied with the Cross Poles Position tighten

the grub screws. Repeat this action with the remaining 2 Cross Poles on the remaining uprights. Slide moisture seals over the reduced end of the uprights.

oIf you are have chosen the lattice option you will need to position the Cross Poles, on the uprights, approximately 50” away from one another, to

accommodate the lattice infill.
