AIDA HD-NDI-200 User manual

HD-NDI-200
Full-HD NDI®|HX2 POV Camera
Version 2.0
AIDA

Table of Contents:
1 Safety Guides
2 Packing List and Quick Start
3 Product Highlights and Camera Specs
6 OSD Menu
9 Web Settings
16 VISCA Control
17 VISCA Commands
18 NDI®|HX2 Protocol*
20 Warranty and Support
NDI®is a registered trademark of Newtek Inc.*
The information within this manual is subject to change at any time without prior notice**

1
Safety Guide:
1. Before operation, please read all the instructions in the manual carefully. For
your convenience, please keep this manual.
2. Ensure the power supply input is within the recommended rate before
powering on.
3. Camera power voltage = 12VDC, with a rated currency to 2A.
4. Please keep the power cable, video cable, and control cable safe and out of
obstructions.
5. Operational temperature of the camera is between 0-50C / 32F-122F. To avoid
damage, do not pour anything inside the camera. Avoid direct sunlight or outdoor
environments.
6. Do not remove the camera housing or cover. For service, please contact our
support line.
7. Use a dry, soft cloth to clean the camera housing with a neutral cleaning agent
when needed.

2
Packing List:
Check for the items below when opening the package:
1EA
Quick Start:
1. Ensure that all cable connections are secure before powering on the camera.
2. Test the video either through HDMI or NDI. The camera will be default
resolution of 1080 30p.

3
Product Highlights:
•Contains a Sony CMOS ISP (1/2.8” progressive CMOS sensor) providing up to
1920x1080 full HD resolution.
•Utilizes the newest NDI®|HX2 for the lowest latency, quality and compression
video over a single network.
•Autodiscover enabled for fast installation over any network.
•Standard 4mm lens for a standard 80 degree HFOV shot.
•Full HD video over HDMI, RTSP, RTMP, and NDI.
•Fully adjustable camera settings, from White balance, exposure settings, and
image parameters.
•Supports PoE: get power and video over one ethernet cord.
•Controllable over RS485 or online web UI.
•Menu based image parameters controllable over breakout cable or web UI.
•Free firmware updates when needed.
•Mountable tripod holes on the top and bottom.
•Audio input in rear portion of the camera for multi-channel TRS stereo audio via
NDI®|HX2 or RJ45 streaming.
•Functional tally light for program, preview, and standby modes. (NDI
transmission)

4
Camera Specs:
Video Interface
HDMI (V1.4) | RJ-45 | NDI®|HX2
Sensor
1/2.8” Sony Progressive CMOS Sensor
Lens
4mm Default lens (80 degree HFOV)
Lens Mount
CS Mount (C mount adapter included)
Control Port
RS485, RJ-45 (VISCA over IP), NDI
Network Speed
1000M
Video Encode
H.264/H.265
Bit-Rate Control
Variable Bit Rate, Constant Bit Rate
Video Bit Rate
1024 kbps (min) ~ 20480 kbps (max)
IP Protocol
IP, RTSP, RTMP, VISCA over IP, NDI®|HX2
POE
Supported (IEEE802.3af)
Minimum Lux
0.01 Lux
White Balance
Auto/Indoor/Outdoor/One Push/ATW/Manual
Exposure
Auto/Manual
Gamma
Supported
WDR
Supported
BLC
Supported
2D/3D NDR
Supported
Audio
TRS Stereo Line In (3.5mm Jack)
Dimensions
LWH 2.13” x 5” x 2.13” (54mm x 127mm x 54mm)

5
Camera Specs: (CONTD.)
Video
Format
HDMI
1920 x 1080
60p/59.94p/50/30p/29.97p/25p/24p/23.98p
1920x1080
60i/59.94i/50i
1280x720
60p/59.94p/50p/30p/29.97p/25p
IP / NDI|HX
(frames)
1920x1080
3~60
1280x720
3~60
1024x576
3~60
620x360
3~60

6
OSD Menu:(CONTD.)
1. To access the OSD menu, please use the OSD controller on the breakout cable.
2. Enter the menu by pressing the OSD control button once.
3. Navigate through the menu by tilting the joystick up, down, left or right to
manipulate the menu.
4. To exit, go back to the main menu and press the OSD control button once.
SYSTEM
Language
Select Language (English only)
Default: English
Protocol
VISCA: Serial and IP default
Default: VISCA
Address
Select VISCA address ID
Default: 1
Baudrate
Select the VISCA baudrate
Default: 9600
Return
Return to previous menu
EXPOSURE
EXP. Mode
Choose between auto and
manual exposure settings
Default: AUTO
Shutter
Change shutter speed under
manual settings only
Default: AUTO
Manual: 1/100
Gain
Change gain under manual
settings only
Default: AUTO
Manual: 0
DC IRIS
Allow for DC IRIS Lens
compatibility
Default: On
Flick
Allows for adjustment of
flickerless option
Default: 50hz
Backlight
Allows for enabling of backlight
to compensate for low light
Default: OFF
Gamma
Allows for changing gamma
settings
Default: 0
Return
Return to the previous menu

7
OSD Menu:(CONTD.)
WB Mode
Auto/Indoor/Outdoor/Onepush/
ATW/Manual/Sodium/Flourescent
Default:
AUTO
R_Gain
Adjust red gain under manual
settings
Default:52
B_Gain
Adjust blue gain under manual
settings
Default:58
Defog
Allows adjustment against hazy
objects
Default: OFF
Return
Return to previous menu
QUALITY
2D NR
When enabled, image noises and
sharpness are reduced
Default: OFF
3D NR
When enabled, less image
reduction happens
Default:
AUTO
Sharpness
Set the level for sharpness
Default: 3
Contrast
Set the level for contrast
Default: 8
Saturation
Set the level for Saturation
Default: 8
Bright
Set level for brightness
Default: 8
D_WDR
Enables control of WDR
Default: OFF
Return
Return to previous menu
CTRL
Mirror
Mirrors the image across the Y
plane
Default: OFF
Flip
Mirrors the image across the X
plane
Default: OFF
D/N Mode
Enables the night shutter mode
for low light situations
Default: DAY
Gain Limit
Allows to set limit on amount of
light that enters the camera
Default: 128
FORMAT
Resolutions
Allows for the changing of
resolutions. Scroll down for more
options.
Default:
1080 30p
Return
Return to previous menu

8
OSD Menu:(CONTD.)
NETWORK
DHCP
Enable or disable DHCP
Default: OFF
Address
Set the IP address of the camera
Default:
192.168.1.188
Netmask
Set the netmask of the camera
255.255.255.0
Gateway
Set the gateway of the camera
192.168.1.001
Return
Return to the previous message
RESET
Cam Reset
Reset all Image parameters
Default:
RESET
All Reset
Factory reset the camera (please
give the camera a moment to
reboot)
Default:
RESET
Return
Return to the previous menu
INFO
FW Ver
Use this when referring to
support
Info
Use this to quickly glance over
the cameras IP settings, as well
as resolution and visca settings.
Return
Return to previous menu
