AIDA HD-X3L-IP67 User manual

Version 1.0 / April 2021
Reproduction of this manual, in whole or in part, by any means, is prohibited.
FHD Weatherproof POV Camera
HD-X3L-IP67
OPERATION GUIDE

2
WARNING
To prevent damage which may result in fire or electric shock hazard, do not modify or open the housing of the camera.
1. Be sure to use only the standard adapter that is specied in the specication sheet. Using any other adapter could cause re,
electrical shock, or damage to the product.
2. Incorrectly connecting the power supply or replacing battery may cause explosion,cause excessive heat or re
3. Securely plug the power cord into the power receptacle. Insecure connection may cause re.
4. Do not place conductive objects (e.g. screw drivers, coins, metal items, etc.) or containers lled with water on top of the camera.
Doing so may cause personal injury due to re, electric shock, or falling objects.
Continue on Next Page
CAUTION:
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK)
NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING
This symbol indicates that dangerous
voltage consisting a risk of electric shock
is present within this unit.
PRECAUTION
This exclamation point symbol is intended to alert
the user to the presence of important operating and
maintenance (servicing) instructions in the literature
accompanying the appliance.

3
5. If any unusual smells or smoke come from the unit, stop using the product. Immediately disconnect the power source
and contact the service center. Continued use in such a condition may cause fire or electric shock.
6. If this product fails to operate normally, contact the nearest service center. Never disassemble or modify this product in any way.
7. When cleaning, do not spray water directly onto parts of the product. Doing so may cause fire or electric shock.
Please read this Operation Guide before installing and using the camera & retain this copy for your reference.
1.Always follow the instructions in the operations guide when applying power. Fire and equipment damage can occur if power is
applied incorrectly. For the correct power supply,refer to the specifications page.
2. Do not use camera if fumes, smoke or a strange odor is emitted from the camera, or if it seems not functional correctly.
Disconnect the power source immediately and consult with your supplier.
3. Do not use the camera in extreme environments where high temperatures or high humidity exists. Use the camera under
conditions where temperatures are between 32°F ~ 104°F.
4. If installed close to a TV, radio transmitter, magnet, electric motor transformer or audio speakers the magnetic field generated
may interfere with or distort the image.
5. Try to avoid fluorescent light reflections, unstable light conditions, direct pointing toward the sun. Use caution when operating the camera in
the vicinity of spotlights or other bright lights and light reflecting objects.
6. To prevent damage, do not drop the camera or subject it to strong shock or vibration.
Warning continues
PRECAUTION

4
HD-X3L-IP67

5
L- Left |R- Right |U- Up |D- Down |- Select
•Full-HD 1/3" Progressive Scan CMOS sensor captures sharp and vivid Full-HD video even under low light conditions.
•X3 optical zoom features 78˜ ~ 25˜ wide angle of view.
•Built-in zoom lens offers zoom, focus and iris control.
•Advanced digital imaging processor provides vivid and detailed images by utilizing Dynamic Range, Auto White Balance, and
Noise Reduction.
•10 ft weatherproof OSD breakout cable with power input, 3G-SDI out, and RS485 communications for remote control.
•Perfectly suited for outdoor events, outdoor research, OB vehicles and security.
•Versatile, compact, and IP67 rated protection covering dust, moisture, and water submersion up to 1m for 30 minutes.
1. Move the Cursor Up/Down to Choose Menu
To move from item to item in the menu, move the joystick to the Up/Down.
2. Change the Value
To change the value of the selected item, move the joystick to the Left/Right.
3. Shift to the Sub Menu of the Chosen Menu
To go into sub menu, press SEL key. The menu items with > always have its sub menu.
FEATURES
OSD MENU
MAIN MENU
*FOCUS CONTROL
WB CONTROL
AE CONTROL
COLOR/ B/W
IMAGE CONTROL
SPECIAL
SETUP
RESET
EXIT

6
FOCUS CONTROL
ZOOM SPEED
AUTO
Auto mode will have the focus be done automatically.
MANUAL
Focus control is done manually and will remain the same.
• PUSH : Press SEL key to focus automatically from the current view.
FOCUS CONTROL
FOCUS MODE AUTO
PUSH
ZOOM SPEED 5
FOCUS LIMIT 50CM
*AF AREA/SIZE
RETURN 0 ~ 7 ( Adjust the speed at which the camera zooms.)
FOCUS LIMIT
10cm, 50cm, 1m, 2m, 3m, 5m, 10m ( Adjust the Autofocus algorithm by distance ).
AFAREA/SIZE
Allows for setting focus parameters. The camera will try to focus based off the users
box settings.
User Mode : ON, OFF
WIDTH - 0 ~ 20 ( Auto mode will adjust the exposure level automatically ).
HEIGHT - 0 ~ 20 ( Auto mode will adjust the exposure level automatically ).
MOVE HOR - 0 ~ 20 ( Auto mode will adjust the exposure level automatically ).
MOVE VER - 0 ~ 20 ( Auto mode will adjust the exposure level automatically ).

7
WB CONTROL
•AGC MAX : Set the maximum gain value to control video noise caused by AGC
•SENS UP : OFF, x2 ~ x15
“SENS UP” mode controls the digital slow shutter to allow extra light into the
camera and adjust the picture quality.
•AE BRIGHT : 0~20
Auto Exposure brightness level can be adjusted.
EXPOSURE
*AE MODE AUTO
SHUTTER
AGC
SENS UP OFF
AE BRIGHT 6
FLKCONTROL OFF
RETURN
AWB - Auto white balance mode will adjust white balance within
3,000˜K ~ 8,000˜K temperature.
ATW - Auto trace white mode will adjust white balance within
1,900˜K ~ 11,000˜K temperature.
ONE PUSH - One push mode is used if AWB or ATW cannot produce the proper white
balance. Place a white paper in front of the camera when using the one push mode to
self adapt.
INDOOR - Indoor mode will adjust white balance to indoor lighting conditions.
OUTDOOR - Outdoor mode will adjust white balance to outdoor lighting conditions.
MANUAL - Manual mode will adjust white balance manually.
BLUE - 0 ~ 100 ( Select Manual blue gain within the range of 0 to 100 )
RED - 0 ~ 100 ( Select Manual red gain within the range of 0 to 100 )
BLUE OFFSET - 0 ~ 100 ( Select AWB blue offset within the range of 0 to 100)
RED OFFSET - 0 ~ 100 ( Select AWB red offset within the range of 0 to 100)
AUTO
Auto mode will adjust the exposure level automatically.
Detailed fine tuning options are available under this menu
WHITE BALANCE
*MODE AT W
PUSH
BLUE
RED
RETURN
BLUE OFFSET
RED OFFSET
AGC MAX 13

8
SHUT FIX
SHUT FIX mode provides more detailed shutter speed option.
All other controls are tuned for the selected shutter speed.
•SHUTTER : AUTO, 1/30 ~ 1/10,000 ( Shutter speed can be set )
•AGC MAX : sets the maximum gain value to control the video noise caused by
Auto Gain Control.
•SENS UP : 0~15
“SENS UP” mode controls the digital slow shutter to allow extra light into the
camera and adjust the picture quality.
•AE BRIGHT : 0~24
Auto Exposure brightness level can be adjusted.
EXPOSURE
*AE MODE AUTO
SHUTTER
AGC
SENS UP OFF
AE BRIGHT 6
FLKCONTROL OFF
RETURN
AGC MAX 13
AE CONTROL

9
AE CONTROL
AGC FIX
AGC FIX mode provides more detailed gain options.
All other controls are tuned for the selected gain value.
•AGC : 0dB ~ 27dB,
Gain level can be set. ( lower values=less adjusted lighting in image)
•AE BRIGHT : 0~10
Auto Exposure brightness level can be adjusted.
•FLK CONTROL : AUTO, ON, OFF
“FLK CONTROL” mode provides a proper image sensor frequency to match the
power frequency in order to minimize video f icker.
AE CONTROL
EXPOSURE
*AE MODE AUTO
SHUTTER
AGC
SENS UP OFF
AE BRIGHT 6
FLKCONTROL OFF
RETURN
AGC MAX 13

10
Camera image control can be adjusted from EFFECT menu.
•AUTO EDGE : ON, OFF
Allows automatic sharpening of image depending on focus.
•BLACK LEVEL :-64 ~ 64 ( Gamma level can be adjusted )
•GAMMA CORRECT :DEFAULT, 0.4 ~ 1.0 ( Gamma level can be adjusted )
•DNR :Camera noise level can be adjusted from this menu.
•DNR MODE : OFF, 2D, 3D, 2D+3D
Digital noise reduction can be applied from this menu.
•DNR LEVEL :AUTO, LOW, MIDDLE, HIGH
Noise reduction level can be adjusted from this menu.
IMAGE CONTROL
*LENS SHADING
OFF
CON TR A ST 11
BRIGHTNESS 11
SATUR AT ION 10
HUE 0
EDGE ENHA NCE 5
AUT O SATU R ATE MIDDLE
AUTO EDGE ON
BLACK WHITE LV
GAMMA CORRECT DEFAULT
DNR
RETURN
IMAGE CONTROL
IMAGE CONTROL
LENS SHADING OFF
*CON TR A ST 11
BRIGHTNESS 11
SATUR AT ION 10
HUE 0
EDGE ENHA NCE 5
AUT O SATU R ATE MIDDLE
AUTO EDGE ON
BLACK WHITE LV
GAMMA CORRECT DEFAULT
DNR
RETURN
•LENS SHADING: ON, OFF
Optical vignetting issue can be correct from this menu.
•CONTRAST : 0 ~ 20 ( Contrast level can be adjusted )
•BRIGHTNESS : 0 ~ 20 ( Brightness level can be adjusted )
•SATURATION :0 ~ 20 ( Saturation level can be adjusted )
•HUE :0 ~ 20 ( Hue level can be adjusted )
•EDGE ENHANCE : 0 ~ 20 ( Image sharpness level can be adjusted )
•AUTO SATURATE :OFF, LOW, MIDDLE, HIGH
Decrease saturation automatically when noisy scene isdetected.

11
SPECIAL
D ZOOM : ON, OFF ( Digital Zoom can be enabled from this menu )
•DZOOM LIMIT: 1x ~ 12x ( Allows ability to digitally zoom this far)
To use this function, keep zooming in after standard 3x optical zoom, you will then slowly
enter the digitally zoomed imaging.
Camera special functions can be adjusted from SPECIAL menu.
SPECIAL
*DZOOM OFF
DEFOG OFF
BA CK LIG HT OFF
BINNING OFF
DEFECT PIXEL ON
DISP. FUNCTION
PRIVACY
RETURN
D-ZOOM
*ZOOM CONTROL X 1.0
RETURN
WDR
ZOOM MAG OFF
ZOOM MAG : ON, OFF ( Displays the zoom level at the top right of image) .

12
SPECIAL
DEFOG : ON, OFF, AUTO ( “DEFOG” menu improves foggy image)
• STRENGTH : 0 ~ 16
Change defog strength.
• THRESHOLD : 0 ~ 3
Threshold value sets minimum sensitivity value for automatic defog control.
Higher value makes defog-on control reluctant.
• AUTO LEVEL : LOW, MID, HIGH
Auto level value sets maximum strength value for automatic defog control.
Higher value makes defog effect to be stronger.
BACK-LIGHT : OFF, BLC, HLM
Camera back-light compensation can be adjusted.
BLC : OFF, ON
BLC enables back light compensation.
•SIZE/POSITION : SIZE, POSITION, RETURN
Adjust BLC area window size.
•LEVEL : Back-light level compensation level can be adjusted from this menu.
Higher level will compensate more from the selected area
•DISPL AY : OFF, ON ( BLC area display can be turned ON or OFF )
•DEFAULT : Set BLC menu to default value.
DEFOG SETUP
*STRENGTH 4
THRESHOLD
AUTO LEVEL
RETURN
BACKLIGHT - BLC
*BLC ON
SIZE/POSITION
LEVEL 128
DISPLAY ON
D EFA U LT
RETURN

13
SPECIAL
HLM : OFF, ON
HLM can be adjusted.
•AREA DISPLAY : ON, OFF
HLM AREA DISPLAY can be turned ON or OFF.
•SIZE/POSITION : SIZE, POSITION, RETURN
Adjust BLC area window size.
•LEVEL : 0 ~ 20
Amount of masking area can be adjusted.
• BLACK MASK : OFF, ON
Masking area highlight can be turned ON or OFF.
•DEFAULT : Set HLM menu to default value.
BINNING : OFF, ON
Binning can be turned ON or OFF. (Sacrifice pixel quality to raise image contrast)
DEFECT PIXEL : OFF, ON,
To fix dead or stuck pixels accumulated on the sensor, please enter this following
menu.
•STATIC PROCESS : PRESS OK.
To use this progress, please cover the lens of the camera until the image is
completely black. Press OK, and then it will adjust. Once complete, your
dead or stuck pixels will now be mirrored by a neighboring pixel.
BACKLIGHT - HLM
*AREA DISPLAY ON
SIZE/POSITIO N
LEVEL 3
BLACK MASK ON
DEFA ULT
RETURN
DEFECT PIXEL
*STATIC PROGRESS PRESS OK
RETURN

14
SPECIAL
DISPLAY FUNCTION : OFF, ON
Adjust image display features from this menu.
•FREEZE : OFF, ON
Image freeze can be turned ON or OFF.
•MIRROR : OFF, MIRROR, Image mirror can be operated.
•FLIP : OFF, V-FLIP, Image flip can be operated.
•IMAGE EFFECT : OFF, NEGATIVE, GREY MODE, REDDISH-1 ~ 4,
BLUISH-1 ~ 4, GREENISH-1 ~ 4.ROTATION : OFF, ROT_L 1:1
Several color effects can be applied.
•ROTATION : OFF, ROT_L FULL, ROT_L 1:1, ROT_R Full, ROT_R 1:1
Image can be rotated either left or right side. (*Will not work on 60 frames resolution)
•PICTURE STYLE : OFF, STANDARD, VIVID, CLEAR, VIVID CLEAR, NEUTRAL
Different types of picture style can be applied. Overrides Image control for fine
tuning
•PIC CONTRAST : 0 ~ 6 (Applies contrast to image)
•PIC SATURATION : 0 ~ 6 (Applies saturation to image)
•PIC EDGE : 0 ~ 6 (Applies sharpness to image)
FLICKER DETECT : OFF, ON
“FLICKER DETECT” mode provides a proper image sensor frequency
to match the power frequency in order to minimize video icker.
DISPLAY FUNCITON
*FREEZE OFF
MIRROR OFF
IMAGE EFFECT NEGATIVE
R OTATION ROT
PICTURE STYLE VIVID
RETURN
WDR : Wide Dynamic range can be turned on or off.
FLIP OFF
PIC CONTRAST 3
PIC SATURATION 3
PIC EDGE 3

15
Privacy zone can be setup from this menu.
MODE : ON, OFF
Enable “PRIVACY ZONE” ON or OFF.
MASK NO : MASK1 ~ MASK8
Select privacy zone mask number.
DISPLAY : ON, OFF
Turn ON or OFF the selected privacy mask zone.
COLOR : WHITE, GREEN, BLUE, RED, CYAN, MAGENTA, YELLOW, GRAY-1 ~ 6,
MOSAIC, BLACK. ( Select privacy zone mask color )
POSITION-X & POSITION-Y
Change the size of the selected corner from “POLY SELECT” menu.
SIZE-X & SIZE-Y
Change the size of the privacy square.
DEFAULT
Set privacy zone to default value.
PRIVACY
PRIVACY MASK
*MODE ON
MASK NO. MASK 1
DISPLAY ON
COLOR BLACK
POSITION-X 2
POSITION-Y 5
SIZE-X 20
SIZE-Y 11
D E FAULT
RETURN

16
Camera setup can be adjusted from this menu.
CAM TITLE : OFF, ON
Camera title can be turned ON or OFF.
COMMUNICATION : ON, OFF,
VISCA communication control can be adjusted.
• CAM ID : 0 ~ 7
Camera ID can be setup.
• ID DISPLAY : OFF, ON
Camera ID can be setup.
• BAUDRATE : 2400, 4800, 9600, 19200, 38400
Camera baudrate can be set.
SYSTEM INFO :
Camera S/W version can be found under this menu.
OUTPUT FORMAT : ON, OFF
Camera resolution and frame rate can be set. Select
to set.
SETUP
Supported formats are:
* 1080p by default
1080P - 60 / 59.94
50 / 30 / 29.97 / 25 / 24
1080I - 60 / 59.94 / 50
720P - 60 / 59.94 / 50
SETUP
*CAM TITLE OFF
COMMUNICATION
SYSTEM INFO
OUTPUT FORMAT 1080P60
RETURN

17
MODE : FACTORY, USER
Camera will reset to factory default or user saved value.
RESET : NO, YES
Reset the camera to the selected mode.
SAVE AS USER :
Save the user desired setting from the menu. Mode must be set to User.
All settings will be saved, from focus and zoom to image settings.
RESET
RESET
*MODE FACTORY
RESET
SAVE AS USER
RETURN

18
VIDEO
Image Sensor 1/3” inch Progressive CMOS
Sensor Size Diagonal 7.20mm
Effective Pixels Horizontal: 1920, Vertical: 1080
Pixel Size
Resolution
Resolution Rate
Output
Color Space
2.75 µm x 2.75 µm
1080p: 1920 x 1080
1080i : 1920 x 1080
720p : 1280 x 720
1080p : 60 / 59.94 / 50 / 30 / 29.97 / 25 / 24
1 1080i : 60 / 59.94 / 50
720p : 60 / 59.94 / 50
3G-SDI
4:2:2 (YCbCr) 10bit
FUNCTION
White Balance AWB / AE / AF
Exposure Full Auto, Bright, Shutter Priority, Iris Priority, Manual
Other WDR, DIS (Digital Image Stabilization), 2D/3D
Noise Reduction, Digital Slow Shutter,
Black Level Compensation, Flicker Detection.
LENS
Lens 3X Optical Zoom Lens,
3.85mm/78° (Wide) ~ 13.4mm/25° (Tele))
STANDARD
SMPTE SMPTE 292M, SMPTE 424M
PHYSICAL
Weatherproof Rating IP67
Camera Control RS-485, OSD Button
Operation Temp 32° F - 104° F
Dimension
Weight
Power
83.09mm x 48mm x 48mm (excl. 3M attached cable)
3.25" x 1.95" x 1.95" (excl.10ft attached cable) (LxWxH)
140g / 0.30lbs
12VDC (+9 - +15VDC)
*Specication are subject to change without notice.
SPECIFICATION
Cable Length 10FT

19
QUESTIONS
Visit us:
www.aidaimaging.com/support
E-mail us:
suppor[email protected]
Give us a Call:
Toll Free: 844.631.8367 |Tel: [phone]
Operating Hours: Mon-Fri | 8:00am – 5:00pm PST

20
Disposal of Old Appliances
1. When this crossed-out wheel bin symbol is attached to a product it means the product is covered by the European Directive 2002/96/EC.
2. All electrical and electronic products should be disposed of separately form the municipal waste stream in accordance to laws designated by the government or the local authorities.
3. The correct disposal of your old appliance will help prevent potential negative consequences for the environment and human health.
4. For more detailed information about disposal of your old appliance, please contact your city ofce, waste disposal service or the shop where you purchased the product.
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful inter ference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful inter ference to radio communications. Operation of this equipment in a residential area is likely to cause harmful inter reference in which case the user will be required
to correct the interference at his own expense.
