Aluminium Fold Flat Rollator
VP185/VP185G/VP185P
Usage and Maintenance Instrucons

N.B. This equipment must be installed by a competent person.
BEFORE USE
• Carefully remove all packaging. Avoid using any knives or other sharp instruments
as this may damage the surface of the product.
• Check the product for any visible damage. If you see any damage or suspect a
fault, do not use your product, but contact your supplier for support.
INTENDED USE
Your Aidapt Rollator has been designed to assist you when walking and carrying
small items of shopping using the bag provided. The bag was designed specifically
to fit your rollator, please only use the bag supplied for your Aidapt Rollator. Do not
use or combine bags and/ or baskets from other manufacturers.
When not in use, you can simply fold the Aidapt Rollator and store away until you
require it next. The Aidapt range of tri-walkers and rollators are designed to be used
both inside and outside the home.
FEATURES
• User friendly loop brakes with lock
• Simple brake cable adjustment
• Soft plastic solid wheels
• Swivelling front wheels
• Folding locking mechanism
• Height adjustable
• Ergonomic handgrips to reduce pressure
• Walking Stick holder
Do not exceed the weight limit stated - doing so could put the user at risk.
* For avoidance of doubt if user is 130kg then no more than 6kg can be
carried
VP185 White Fold Flat Rollator
VP185G Grey Fold Flat Rollator
VP185P Purple Fold Flat Rollator
Maximum Load 136kg*
Maximum User Weight 136kg*
This le is available to view and download as a PDF at www.aidapt.
co.uk. Sight impaired customers can use a free PDF Reader (such as
adobe.com/reader) to zoom in and increase the text size for improved
readability.

ASSEMBLY INSTRUCTIONS
Carefully remove all packaging, including the cardboard tubes covering the knurled
tube part of the brake assembly. Check the product thoroughly for damage or
obvious faults.
If you suspect the unit to faulty, please do not use, but contact your
supplier immediately for service.
Handgrip
Height
Adjustable Handles
Height
Adjustment Knob
Backrest
Seat
Rear Wheels
Front Wheels
Cane
Holder

Step 1:
Open the rollator by pulling the handles away from each other (see fig. 1)
Step 2:
Push down on the seat (see fig. 2) making sure that the seat arms click into the seat
brackets (see fig. 3). DO NOT USE THE ROLLATOR UNLESS THE SEAT ARMS
ARE FULLY LOCKED INTO THE SEAT BRACKETS.
Step 3:
Lower the rear legs by pulling up both sides of the red catch (see fig. 4) and lowering
the leg into position. Repeat step 3 for the other rear leg. A click will be heard when
the leg has locked into place. DO NOT USE THE ROLLATOR UNLESS THE LEG
HAS SECURELY LOCKED INTO PLACE.
Step 4:
Lower the front wheels by pushing the red catch down (see fig. 5) and lowering the
wheel into position. Repeat step 4 for the other front wheel. A click will be heard
when the wheel has locked into place. DO NOT USE THE ROLLATOR UNLESS
THE WHEEL HAS SECURELY LOCKED INTO PLACE.
The rollator is supplied fully assembled in its folded position. To unfold the rollator
follow these instructions.
ASSEMBLY INSTRUCTIONS (continued)
Backrest
Front Wheels
fig. 1
fig. 4 fig. 5
fig. 2 fig. 3

The height of the handgrips can be
raised or lowered to suit the user.
To adjust the height of the handgrips
loosen the height adjustment knob
(see fig. 6). Raise or lower the
handgrips to the desired user height.
You will hear a click as the handgrip
locks into one of the height adjustment
positions (see fig. 6)
When the desired height has been
achieved retighten the height
adjustment knob to lock the position.
ENSURE THAT BOTH HANDGRIPS ARE
AT THE SAME HEIGHT BEFORE USE
DO NOT USE THE ROLLATOR UNLESS THE HANDGRIPS HAVE LOCKED
INTO ONE OF THE HEIGHT ADJUSTMENT POSITIONS AND THE HEIGHT
ADJUSTMENT KNOB HAS BEEN TIGHTENED.
2. The brakes on your Rollator have a park option
(see fig. 8). To operate the park option, push
downwards on both brakes simultaneously. You will feel
the brake make a very slight click. Your brakes are now
in the ‘lock’ position.
3. To unlock, simply pull up the brake again, you will
hear a slight click as the ‘park’ disengages.
OPERATING THE BRAKES
HEIGHT ADJUSTMENT
fig. 7
fig. 8
HEIGHT
ADJUSTMENT
POSITIONS
fig. 6
1. To stop, gently apply a gripping pressure to both
brakes simultaneously (see fig. 7), this will slow down
and stop your Rollator.

BRAKE ADJUSTMENT
Your Aidapt Rollator brake system will
require periodic adjustment.
To adjust the brakes loosen Nut B and
then screw/unscrew Nut A. When
adjusted re-tighten Nut B. If further
adjustment is required then loosen the
Locking Screw and then using a pair of
pliers pull the cable down by
approximately a millimetre. Re-tighten
Locking Screw. The brakes can then be
adjusted further by loosening Nut B and
screwing/unscrewing Nut A as before
(see fig. 9)
fig. 9
REISSUE
If you reissue or are about to reissue this product, please thoroughly check all
components for their safety.
This includes:
• Bent or damaged tubes or cracks at the tube joints.
• Loose or worn horseshoe clips
• Elongated adjustment holes.
• Loose handles.
• Loose or worn Wheels and wheel fasteners (where fitted)
• Smooth, worn or split ferrules (rubber tips).
Replace all worn, missing or damaged parts where necessary. If in any doubt,
please do not issue or use, but immediately contact your supplier for service
support.

CARE AND MAINTENANCE & YOUR OBLIGATION
1. Only use your Aidapt Rollator for the purpose for which it intended, which is as an
aid to walking. It is intended your rollator is only used on standard pavements or at
home. It should not be used on rough terrain or pot-holed surfaces. The use of your
rollator on these surfaces can seriously compromise your safety and may damage
your rollator beyond repair.
2. Keep your Aidapt Rollator clean by wiping down with a damp cloth with a mild
detergent. Do not under any circumstances use an abrasive or solvent based
cleaner, as this will seriously damage the rollator and void your warranty.
3. Wipe off all surfaces with a dry cloth and use a water dispersing agent such as
WD40 on all metal joints.
4. Check that all wheels and the folding mechanism function correctly and that all
wheels move freely. Pay particular attention to the front wheels, ensuring that they
rotate freely and without obstruction and that they are attached securely to the
frame.
5. Monthly Checks - Check that no components are loose. Check the adjustment to
your brakes (fig 9). Check castors.
6. Do not fit any parts or accessories to your Aidapt Rollator manufactured by
another company. To do so will annul your warranty and may seriously compromise
your safety.
7. We suggest that you check your Aidapt Rollator visually every day. However we
recommend that you should have your rollator serviced every three months or less if
used by, or issued to, various users.
MAINTENANCE
Please make a safety check of the product at regular intervals or if you have any
concerns.
WARRANTY
This product carries a 12 month warranty from the date of purchase against
manufacturing defects. Misuse or Damage is not covered. This warranty does not
affect your statutory rights.
Withdraw your Aidapt Rollator immediately if any of the wheels
become difficult to turn or do not feel securely attached to the frame
or if you suspect damage or any other fault.

Aidapt Bathrooms Ltd, Lancots Lane, Sutton Oak, St Helens, WA9 3EX
Telephone: [phone] • Fax: [phone] • Web:
www.aidapt.com Email: [email protected]
IMPORTANT INFORMATION
The information given in this instruction booklet must not be taken as forming part of
or establishing any contractual or other commitment by Aidapt Bathrooms Limited,
Aidapt (Wales) Ltd or its agents or its subsidiaries and no warranty or representation
concerning the information is given. Please exercise common sense and do not take
any unnecessary risks when using this product; as the user you must accept liability
for safety when using the product. Please do not hesitate to contact the person who
issued this product to you or the manufacturer (detailed below) if you have any
queries concerning the assembly/use of your product.
SPECIFICATION
Dimensions (mm).............................................................690(L) x 645(W) x 800-900(H)
Height to handgrip (mm)................................................................................... 800-900
Seat size (mm).......................................................................................435(W) x 220(L)
Seat height (mm) ......................................................................................................570
Front/rear wheel size (“)................................................................................................8
Maximum user weight (kg/stone) ..................................................................... 136 / 21
Net weight (kg) ........................................................................................................8.85
Gross weight (kg).....................................................................................................10.2
Packaged dimensions (mm) ................................................... 415(L) x 310(W) x 645(H)
