Airgle AG800 User manual
OWNER'S MANUAL
PurePal® Air Cleaner (Model: AG800)
PurePal® Plus Air Cleaner (Model: AG850)
®
2
®Save these instructions
3
®
The gold standard for air cleaner
CONTENTS
Warning: IMPORTANT SAFETY INSTRUCTIONS 2
The Airgle®PurePal®Air Cleaning System 4
Unpacking 6
Choosing a Suitable Location 7
Connecting to Power 9
Airgle® PurePal®Components 10
How the Airgle®PurePal®System Works 11
Using the Control Panel 12
Using the Remote Control 17
Care and Maintenance of Your PurePal®Air Cleaning System 18
Congratulations on your purchase of this Airgle®PurePal®air cleaner.
Please study this manual carefully to familiarize yourself with the
features and functions of your Airgle®PurePal®air cleaner. Inside you
will find many helpful hints on how to use and maintain your Airgle®
PurePal®properly.
WARNING
Important safety instructions
Read all instructions before using this air cleaner
When using an electrical appliance, basic precautions should always be
followed, including the following:
sMake sure the cleaner is plugged into a live 110-120V AC outlet (if you
purchased this unit outside the United States and Canada, your dealer
outlet).
sAlways
sDisconnect the power supply from your air cleaner by unplugging the
sDo not use ®.
sDo not use the air cleaner outdoors.
sDo not attempt
sDo not attempt to repair the air cleaner.
sDo not attempt to plug in the machine when your hands are wet.
sDo not soak the cleaner in water or splash water on it.
sDo not operate
sDo not obstruct the air inlet and air outlet of the air cleaner.
sSave these instructions for future reference.
s4OREDUCETHERISKOFELECTRICSHOCKDONOTEXPOSETOWATERORRAIN
This product employs overload protection (fuse). A blown fuse indicates an
overload or short-circuit situation. If the fuse blows, unplug the product from
the outlet. Replace the fuse as per the user servicing instructions (follow
product marking for proper fuse rating) and check the product. If the
replacement fuse blows, a short-circuit may be present and the product
should be discarded or returned to an authorized service facility for
EXAMINATIONANDORREPAIR
Do not run cord under carpeting. Do not cover cord with throw rugs, runners,
or similar coverings. Do not route cord under furniture or appliances. Arrange
cord away from traffic area and where it will not be tripped over.
s
s
READ AND SAVE THESE INSTRUCTIONS
2
®Save these instructions
3
®
The gold standard for air cleaner
CONTENTS
Warning: IMPORTANT SAFETY INSTRUCTIONS 2
The Airgle®PurePal®Air Cleaning System 4
Unpacking 6
Choosing a Suitable Location 7
Connecting to Power 9
Airgle® PurePal®Components 10
How the Airgle®PurePal®System Works 11
Using the Control Panel 12
Using the Remote Control 17
Care and Maintenance of Your PurePal®Air Cleaning System 18
Congratulations on your purchase of this Airgle®PurePal®air cleaner.
Please study this manual carefully to familiarize yourself with the
features and functions of your Airgle®PurePal®air cleaner. Inside you
will find many helpful hints on how to use and maintain your Airgle®
PurePal®properly.
WARNING
Important safety instructions
Read all instructions before using this air cleaner
When using an electrical appliance, basic precautions should always be
followed, including the following:
sMake sure the cleaner is plugged into a live 110-120V AC outlet (if you
purchased this unit outside the United States and Canada, your dealer
outlet).
sAlways
sDisconnect the power supply from your air cleaner by unplugging the
sDo not use ®.
sDo not use the air cleaner outdoors.
sDo not attempt
sDo not attempt to repair the air cleaner.
sDo not attempt to plug in the machine when your hands are wet.
sDo not soak the cleaner in water or splash water on it.
sDo not operate
sDo not obstruct the air inlet and air outlet of the air cleaner.
sSave these instructions for future reference.
s4OREDUCETHERISKOFELECTRICSHOCKDONOTEXPOSETOWATERORRAIN
This product employs overload protection (fuse). A blown fuse indicates an
overload or short-circuit situation. If the fuse blows, unplug the product from
the outlet. Replace the fuse as per the user servicing instructions (follow
product marking for proper fuse rating) and check the product. If the
replacement fuse blows, a short-circuit may be present and the product
should be discarded or returned to an authorized service facility for
EXAMINATIONANDORREPAIR
Do not run cord under carpeting. Do not cover cord with throw rugs, runners,
or similar coverings. Do not route cord under furniture or appliances. Arrange
cord away from traffic area and where it will not be tripped over.
s
s
READ AND SAVE THESE INSTRUCTIONS
4
Introduction to Airgle®PurePal®and PurePal® Plus
®
THE AIRGLE
The Airgle®PurePal®Air Cleaning System
An efficient air cleaning system plays an important role when it comes to improving indoor air
quality. However, an air cleaning system cannot do the complete job – it needs assistance.
Controlling the sources of air pollution and making sure proper ventilation is utilized are critical
components in improving air quality in your home or office.
To tackle any indoor air quality problem, you will want to:
sEliminate or reduce the source of air pollution as much as you can. Locating and controlling the
source of pollution in your home right at the source is very effective.
sProper ventilation is EXtremely important. Cleaning your air cannot reverse the fact that the air in
your home or office is converted to carbon dioXIDE (CO2) every time someone EXHALES. Proper
ventilation will ensure that clean fresh air is continually introduced into the room from outside.
Ideally, when you purchased your new Airgle®PurePal®cleaning system, you had assistance in
making sure that you were purchasing enough air cleaning power for your room size. However, if
you are in an area with heavy air pollution or there other factors restricting sufficient ventilation and
pollution control, you may need to evaluate your level of air turnover.
It is important to understand how to calculate the level of air turnover you DESIRENEEDObviously,
the larger the room, the more air, and therefore the more power needed to purify the air. The
calculation we use is as follows:
2OOMAIRVOLUMEXHOURLYDELIVERy level to purify the air
Your new Airgle®PurePal®system can purify and circulate clean air 5 times per hour in a 698 sq.
ft. room size.
Titanium Pro®Module
5
Introduction to Airgle®PurePal®and PurePal® Plus ®
PurePal®and PurePal®Plus Air Cleaning Systems
Our patented pending Titanium Pro®includes the following features:
sA catalytic metal plate, an electronic component, a UV germicidal lamp and UV lamp ballast into
a single disposable module - A single, handheld, unitized package, designed for easy insertion
and removal into an air cleaner.
sUnique structure design allows MAXIMUMairflow, rapidly diluting the concentration of unwanted
airborne contaminants.
sTIMESGREATEREFFective catalytic area, comparing other conversional Tio2 module
sWATT56#LAMP
s0LUGANDPLAYTECHNOLOGY
s(IGHDESTRUCtive efficiency at room temperature
s.OCHEMICALADDITIVes
s.ORESIDUALOZONE
s(IGHOXIDATIONYIELDSFor gas phase reactants and odors
sLow energy requirements
sWorks in humid conditions
s,ong service life
sZero maintenance requirement
Airgle®PurePal®(AG800) is designed:
s&or general purpose usage
sTo assist asthma & allergy sufferers
sWith a wide spectrum particle, molecular and odor filtration system that includes
s!'AS/DORfilter (3 lbs enhanced carbon blend)
s!SQft. HEPAfast surface area
Airgle®PurePal®Plus (AG850) is designed:
sWith enhanced technology for particle, chemical,
odor & microbe filtration
sThe filtration configuration includes
s!'AS/DORfilter (3 lbs enhanced carbon blend)
s!SQft. HEPAfast surface area
s)NCLUDESTitanium Pro®
4HE!'COMESWITHTHE4ITANIUM0RO§MODULE4HISMODULEISCONSIDEREDTHENEXTGENERATIONOF
0HOTOCATALYTICOXIDATIONTECHNOLOGY4HECATALYTICAREAINTHEMODULESAFELYBREAKSDOWNHARMFUL
chemicals and odors and effectively kills bacteria and virus pollutants.
0OLLUTANTSAREABSORBEDBYTHESURFACEOFTHECATALYST4HEPOLLUTANTANDCATALYSTARETHENEXPOSED
to the photons of UV light. The light energy activates the catalyst, which breaks down the pollutant
INTONONTOXICPRODUCTS/DORSAND6/#SAREVAPORIZEDBYTHE56LIGHTINMUCHTHESAMEWAYTHATA
drop of cold water is vaporized when it drops into a hot skillet.
4
Introduction to Airgle®PurePal®and PurePal® Plus
®
THE AIRGLE
The Airgle®PurePal®Air Cleaning System
An efficient air cleaning system plays an important role when it comes to improving indoor air
quality. However, an air cleaning system cannot do the complete job – it needs assistance.
Controlling the sources of air pollution and making sure proper ventilation is utilized are critical
components in improving air quality in your home or office.
To tackle any indoor air quality problem, you will want to:
sEliminate or reduce the source of air pollution as much as you can. Locating and controlling the
source of pollution in your home right at the source is very effective.
sProper ventilation is EXtremely important. Cleaning your air cannot reverse the fact that the air in
your home or office is converted to carbon dioXIDE (CO2) every time someone EXHALES. Proper
ventilation will ensure that clean fresh air is continually introduced into the room from outside.
Ideally, when you purchased your new Airgle®PurePal®cleaning system, you had assistance in
making sure that you were purchasing enough air cleaning power for your room size. However, if
you are in an area with heavy air pollution or there other factors restricting sufficient ventilation and
pollution control, you may need to evaluate your level of air turnover.
It is important to understand how to calculate the level of air turnover you DESIRENEEDObviously,
the larger the room, the more air, and therefore the more power needed to purify the air. The
calculation we use is as follows:
2OOMAIRVOLUMEXHOURLYDELIVERy level to purify the air
Your new Airgle®PurePal®system can purify and circulate clean air 5 times per hour in a 698 sq.
ft. room size.
Titanium Pro®Module
5
Introduction to Airgle®PurePal®and PurePal® Plus ®
PurePal®and PurePal®Plus Air Cleaning Systems
Our patented pending Titanium Pro®includes the following features:
sA catalytic metal plate, an electronic component, a UV germicidal lamp and UV lamp ballast into
a single disposable module - A single, handheld, unitized package, designed for easy insertion
and removal into an air cleaner.
sUnique structure design allows MAXIMUMairflow, rapidly diluting the concentration of unwanted
airborne contaminants.
sTIMESGREATEREFFective catalytic area, comparing other conversional Tio2 module
sWATT56#LAMP
s0LUGANDPLAYTECHNOLOGY
s(IGHDESTRUCtive efficiency at room temperature
s.OCHEMICALADDITIVes
s.ORESIDUALOZONE
s(IGHOXIDATIONYIELDSFor gas phase reactants and odors
sLow energy requirements
sWorks in humid conditions
s,ong service life
sZero maintenance requirement
Airgle®PurePal®(AG800) is designed:
s&or general purpose usage
sTo assist asthma & allergy sufferers
sWith a wide spectrum particle, molecular and odor filtration system that includes
s!'AS/DORfilter (3 lbs enhanced carbon blend)
s!SQft. HEPAfast surface area
Airgle®PurePal®Plus (AG850) is designed:
sWith enhanced technology for particle, chemical,
odor & microbe filtration
sThe filtration configuration includes
s!'AS/DORfilter (3 lbs enhanced carbon blend)
s!SQft. HEPAfast surface area
s)NCLUDESTitanium Pro®
4HE!'COMESWITHTHE4ITANIUM0RO§MODULE4HISMODULEISCONSIDEREDTHENEXTGENERATIONOF
0HOTOCATALYTICOXIDATIONTECHNOLOGY4HECATALYTICAREAINTHEMODULESAFELYBREAKSDOWNHARMFUL
chemicals and odors and effectively kills bacteria and virus pollutants.
0OLLUTANTSAREABSORBEDBYTHESURFACEOFTHECATALYST4HEPOLLUTANTANDCATALYSTARETHENEXPOSED
to the photons of UV light. The light energy activates the catalyst, which breaks down the pollutant
INTONONTOXICPRODUCTS/DORSAND6/#SAREVAPORIZEDBYTHE56LIGHTINMUCHTHESAMEWAYTHATA
drop of cold water is vaporized when it drops into a hot skillet.
6
Introduction to Airgle®PurePal®and PurePal® Plus
®
UNPACKING
1. Remove the PurePal®System from the packaging.
2. Do not throw the original boX and packaging away. Keep it in case you have to transport the
unit again sometime in the future.
3. Check the components received against your packing slip to make sure you have all the parts.
4. Check the unit and all the components for damage. If the unit or any of the components show
damage from shipping, contact your local dealer.
5. For your future convenience, record the model information here. Model information can be
found on the name plate located on the bottom of your unit.
Model Number:
Purchase Date:
Model Name:
Serial Number:
Unpack your Airgle®PurePal®System
as follows:
Pre-installed Filters:
Gas & Odor filter, HEPAfast filter, and Titanium
Pro®( AG850)
7
Introduction to Airgle®PurePal®and PurePal® Plus ®
CHOOSING A SUITABLE LOCATION
Now that you have unpacked your air cleaning
system, where are you going to use it?
Does someone in your family have allergies
and asthma? People with allergies and
asthma sometimes have a hard sleeping
as many of their symptoms worsen during
the night. Moving your air cleaning system
into your bedroom at night will help them.
Be sure to have one foot of space between
the system and any walls, cabinets or large
furniture to allow for better air circulation.
Placing your air cleaning system in a
central location of your largest room will
help purify the air in the entire room and
may be beneficial to other rooms that
have doorways to the main room. Be sure
to have one foot of space between the
system and any walls, cabinets or large
furniture to allow for better air circulation.
Bedrooms:
,IVINGFAMILYROOMS
123
Installing the supplied casters.They make it easy to
move the air purifier between rooms.
1) Carefully insert caster stem into receptor tube.
2）Press on caster, until it snaps into place. Repeat
steps 1) and 2) with the remaining casters.
3）Ensure that each caster is securely fitted before
placing the machine in its upright position onto the casters.
6
Introduction to Airgle®PurePal®and PurePal® Plus
®
UNPACKING
1. Remove the PurePal®System from the packaging.
2. Do not throw the original boX and packaging away. Keep it in case you have to transport the
unit again sometime in the future.
3. Check the components received against your packing slip to make sure you have all the parts.
4. Check the unit and all the components for damage. If the unit or any of the components show
damage from shipping, contact your local dealer.
5. For your future convenience, record the model information here. Model information can be
found on the name plate located on the bottom of your unit.
Model Number:
Purchase Date:
Model Name:
Serial Number:
Unpack your Airgle®PurePal®System
as follows:
Pre-installed Filters:
Gas & Odor filter, HEPAfast filter, and Titanium
Pro®( AG850)
7
Introduction to Airgle®PurePal®and PurePal® Plus ®
CHOOSING A SUITABLE LOCATION
Now that you have unpacked your air cleaning
system, where are you going to use it?
Does someone in your family have allergies
and asthma? People with allergies and
asthma sometimes have a hard sleeping
as many of their symptoms worsen during
the night. Moving your air cleaning system
into your bedroom at night will help them.
Be sure to have one foot of space between
the system and any walls, cabinets or large
furniture to allow for better air circulation.
Placing your air cleaning system in a
central location of your largest room will
help purify the air in the entire room and
may be beneficial to other rooms that
have doorways to the main room. Be sure
to have one foot of space between the
system and any walls, cabinets or large
furniture to allow for better air circulation.
Bedrooms:
,IVINGFAMILYROOMS
123
Installing the supplied casters.They make it easy to
move the air purifier between rooms.
1) Carefully insert caster stem into receptor tube.
2）Press on caster, until it snaps into place. Repeat
steps 1) and 2) with the remaining casters.
3）Ensure that each caster is securely fitted before
placing the machine in its upright position onto the casters.
8
Introduction to Airgle®PurePal®and PurePal® Plus
®
Many people will turn on their air cleaner periodically throughout the day – we recommend that
you leave it on for constant air cleaning while you are using the room– after all, air pollution never
takes a break- why should your air cleaner?
We have found that many people start with one air cleaning system and move it from room to
room throughout the day. You should focus your air cleaning efforts in the area where you and
your family spend the most time. Some of them continue the practice of moving the air cleaner
from room to room – others purchase additional units. How you end up using your system or
systems, you need to remember this one thing…
For optimal performance, keep these 3 things in mind:
1. Position the air cleaning system at least 1 foot away from the wall. The more centrally the air
cleaner is positioned, the better and faster air cleaner can purify the air.
2. Keep the power cord away from walk ways.
3. Make sure you can easily access the control panel.
Home office or den:
Keeping your system in your home
office or den will certainly clean the
air in that room – but probably only
that room.
9
Introduction to Airgle®PurePal®and PurePal® Plus ®
CONNECTING TO POWER
Make sure the cleaner is
plugged into a live 110-
120V AC outlet (or 220-
240V AC outlet if you are
located outside the United
States and Canada).
After selecting the location for your air cleaning system, and clearing the space around where it
will stay, connect the power cord to the unit and the other end into the socket.
ecti
on
tay,
After se
l
ll
le
r s
Plug type may vary
8
Introduction to Airgle®PurePal®and PurePal® Plus
®
Many people will turn on their air cleaner periodically throughout the day – we recommend that
you leave it on for constant air cleaning while you are using the room– after all, air pollution never
takes a break- why should your air cleaner?
We have found that many people start with one air cleaning system and move it from room to
room throughout the day. You should focus your air cleaning efforts in the area where you and
your family spend the most time. Some of them continue the practice of moving the air cleaner
from room to room – others purchase additional units. How you end up using your system or
systems, you need to remember this one thing…
For optimal performance, keep these 3 things in mind:
1. Position the air cleaning system at least 1 foot away from the wall. The more centrally the air
cleaner is positioned, the better and faster air cleaner can purify the air.
2. Keep the power cord away from walk ways.
3. Make sure you can easily access the control panel.
Home office or den:
Keeping your system in your home
office or den will certainly clean the
air in that room – but probably only
that room.
9
Introduction to Airgle®PurePal®and PurePal® Plus ®
CONNECTING TO POWER
Make sure the cleaner is
plugged into a live 110-
120V AC outlet (or 220-
240V AC outlet if you are
located outside the United
States and Canada).
After selecting the location for your air cleaning system, and clearing the space around where it
will stay, connect the power cord to the unit and the other end into the socket.
ecti
on
tay,
After se
l
ll
le
r s
Plug type may vary
10
The art of purification
®
1. Sensor: Monitors the amount of particles in the room to determine airflow activity (if unit is on
auto)
2. Housing: The outside “bOX” for the unit. You will want to make sure that this is kept clean and
THATNOAREASSUCHASTHESENSORORAIRINTAKEOUTFLow become covered or blocked.
3. Casters: Install the casters provided with your cleaning system to make it easier to move as
needed when cleaning as well as to keep the unit off the floor for better airflow.
4. Titanium Pro®: This module is easily removed when replacement is required as indicated on the
control panel. The light bulb indicator on the control panel will start blinking when the module
has reached its life of 6000 hours and requires replacement. ( AG850)
5. HEPAfast Filter: This filter is easily removed for replacement when indicated on control panel.
6. Gas & Odor Filter: This filter is removed for cleaning (by vacuum) or replacement. We recommend
checking for possible cleaning every cleaning every two months. The filter may need replacement
every two years depending on use.
7. Rear Door: Make sure that the rear door is latched on correctly so as not to overload the air
cleaning system with additional air intake that is not entering the unit in the proper manner.
8. Auto Shut Off: This safety feature will automatically turn off the unit if the rear door is removed
while the unit is running.
8
1
2
3
4
5
6
7
AIRGLE®
PUREPAL®
COMPONENTS
PurePal®Components withoutTitanium Pro®
Showing 5 and 6 here
PurePal®Plus Components withTitanium Pro®
Showing 4, 5 and 6 here
11
The art of purification ®
HOW THE AIRGLE®PUREPAL®
SYSTEM WORKS
1. Room air is drawn into the system via the rear grill
2. The cleaning process starts when the air moves through the Gas & Odor filter. This filter captures
large particles, and VOC that are adding to air pollution.
3. NeXT the air moves through the HEPAfast filter which captures tobacco smoke, dust mites,
pollen, dander, smog, mold, and other airborne pollutants.
4. If your unit includes the Titanium Pro®Module, the air moves through this final filter where
additional items such as mold, odors, and VOCS are filtered out and bacTERIAVIRUS organisms
are killed.
5. Purified air is then returned to the room via the front grill.
1
Room air
is
The clea
eaning p
article
43
5 2
1
Purified air Air Intake
Fan
10
The art of purification
®
1. Sensor: Monitors the amount of particles in the room to determine airflow activity (if unit is on
auto)
2. Housing: The outside “bOX” for the unit. You will want to make sure that this is kept clean and
THATNOAREASSUCHASTHESENSORORAIRINTAKEOUTFLow become covered or blocked.
3. Casters: Install the casters provided with your cleaning system to make it easier to move as
needed when cleaning as well as to keep the unit off the floor for better airflow.
4. Titanium Pro®: This module is easily removed when replacement is required as indicated on the
control panel. The light bulb indicator on the control panel will start blinking when the module
has reached its life of 6000 hours and requires replacement. ( AG850)
5. HEPAfast Filter: This filter is easily removed for replacement when indicated on control panel.
6. Gas & Odor Filter: This filter is removed for cleaning (by vacuum) or replacement. We recommend
checking for possible cleaning every cleaning every two months. The filter may need replacement
every two years depending on use.
7. Rear Door: Make sure that the rear door is latched on correctly so as not to overload the air
cleaning system with additional air intake that is not entering the unit in the proper manner.
8. Auto Shut Off: This safety feature will automatically turn off the unit if the rear door is removed
while the unit is running.
8
1
2
3
4
5
6
7
AIRGLE®
PUREPAL®
COMPONENTS
PurePal®Components withoutTitanium Pro®
Showing 5 and 6 here
PurePal®Plus Components withTitanium Pro®
Showing 4, 5 and 6 here
11
The art of purification ®
HOW THE AIRGLE®PUREPAL®
SYSTEM WORKS
1. Room air is drawn into the system via the rear grill
2. The cleaning process starts when the air moves through the Gas & Odor filter. This filter captures
large particles, and VOC that are adding to air pollution.
3. NeXT the air moves through the HEPAfast filter which captures tobacco smoke, dust mites,
pollen, dander, smog, mold, and other airborne pollutants.
4. If your unit includes the Titanium Pro®Module, the air moves through this final filter where
additional items such as mold, odors, and VOCS are filtered out and bacTERIAVIRUS organisms
are killed.
5. Purified air is then returned to the room via the front grill.
1
Room air
is
The clea
eaning p
article
43
5 2
1
Purified air Air Intake
Fan
12
The art of purification
®
USING THE CONTROL PANEL
The Airgle®System is equipped with a state-of-the-art control panel. This advanced control panel
allows you to see unit status with one quick glance.
1
4
7
5
6
2
3
IR
13
The art of purification ®
2. Filter Life: This monitor calculates the remaining life of the system’s filters. The calculation takes
into account both the already elapsed operation time and fan speed. This allows for a more ac-
curate report on filter life. The 6 status bars indicate if the filter should be changed (1 bar) to when
it is at its full life (6 bars). When the filter needs attention,“the first bar”will be blinking.
3. Control Setting: This advanced setting is for users who encounter challenging air pollution en-
VIRONMENTSANDORNEEDs. The default setting is Moderate which should work for most users.
For more information, see the Control Setting section in this manual.
4. Light Bulb: This indicator displays if you have installedTitanium Pro®. If blinking, indicates that
the filter needs to be replaced. For more information, see the Titanium Pro®section in this
manual.
5. Speed: This indicates the speed selected by using the knob on the right hand side of the
panel.
6. Auto: This indicates if you have elected to use the Auto-Mode (selected using the button on the
right side of the panel).
7. Timer: This indicates how much time is left until the system shuts down (activated by the
Timer button on the right hand side of the panel).
1. Air Quality: The Airgle®system is equipped with an advanced air quality monitoring sensor. The
Air Quality Gauge displays the quality of the air in the room – the air you breathe. The 6 status
bars indicate the quality from Unhealthy (1 bar) to Good (6 bars).
Unhealthy
Change
66% Remaining
33% Remaining
Full Life
Moderate Good
12
The art of purification
®
USING THE CONTROL PANEL
The Airgle®System is equipped with a state-of-the-art control panel. This advanced control panel
allows you to see unit status with one quick glance.
1
4
7
5
6
2
3
IR
13
The art of purification ®
2. Filter Life: This monitor calculates the remaining life of the system’s filters. The calculation takes
into account both the already elapsed operation time and fan speed. This allows for a more ac-
curate report on filter life. The 6 status bars indicate if the filter should be changed (1 bar) to when
it is at its full life (6 bars). When the filter needs attention,“the first bar”will be blinking.
3. Control Setting: This advanced setting is for users who encounter challenging air pollution en-
VIRONMENTSANDORNEEDs. The default setting is Moderate which should work for most users.
For more information, see the Control Setting section in this manual.
4. Light Bulb: This indicator displays if you have installedTitanium Pro®. If blinking, indicates that
the filter needs to be replaced. For more information, see the Titanium Pro®section in this
manual.
5. Speed: This indicates the speed selected by using the knob on the right hand side of the
panel.
6. Auto: This indicates if you have elected to use the Auto-Mode (selected using the button on the
right side of the panel).
7. Timer: This indicates how much time is left until the system shuts down (activated by the
Timer button on the right hand side of the panel).
1. Air Quality: The Airgle®system is equipped with an advanced air quality monitoring sensor. The
Air Quality Gauge displays the quality of the air in the room – the air you breathe. The 6 status
bars indicate the quality from Unhealthy (1 bar) to Good (6 bars).
Unhealthy
Change
66% Remaining
33% Remaining
Full Life
Moderate Good
14
The art of purification
®
IR
Control Panel details: right hand side
1. Timer: Press this button to set the timer for up to 12 hours of continuous operation. The time
left displays on the left hand side of the panel.
2. Auto: When you select auto mode, your unit will automatically change to the optimum speed
needed for air purification in the room. The sensor (located on the side of the unit) will tell the
unit when to raise or lower fan speed depending on the amount of particles in the room.
Night Mode: If you wish the LCD on the left hand side of the panel to turn off, press the Auto
button and hold down for 3 or more seconds to set the panel on Sleep mode. Press Auto
button again and hold down for 3 or more seconds to turn the LCD back on.
3. Reset: Press this button after you have replaced any of the filters. This will reset any blinking
lights and set filter life to full.
Note: This function is only activated when any of the filters require changing. If the filter life is full,
the button is disabled to prevent the accidental press of the button.
4. PoWER3PEED To turn the system on, rotate knob to select a speed from 1 to 5. The light
indicator for the selected speed will display as blue and the speed you selected will display
on the left hand side of the panel. To turn the system off, rotate the knob to the “power off”
position. When the air purifier is turned off, the fan stops rotating.
1
2
3
4
5
15
The art of purification ®
5. IR: This infrared receiver is used by your remote control to change unit settings
The default setting for the unit is moderate and will be displayed as 4 bars on the control panel.
This setting should meet most needs.
For advanced users only:
1. Make sure that the unit is on Standby mode (plug in the unit, and confirm knob is at the
“power off” position)
2. Press and hold“Auto” button for more than 5 seconds. You will hear a “ding” sound, the Con-
trol Setting bars will go from High, Moderate, Low, Moderate....... and then start blinking.
3. If you release “Auto “ button when “High” is blinking, the system is set to High Mode.
Answer the following questions to see if you need to change your setting.
Auto Mode: Your system will start on high to purify the air until it senses an eXTremely low con-
centration of particles and then auto change itself to the low setting.
If you answered“Yes” to any of the questions above, you may want to consider changing your
setting to “High”. If you answered “No”, answer the following question.
If you answered“Yes” to this question, you may want to consider changing your setting to“Low”.
Control Setting
Are you noticing severe indoor air pollution problems?
!REYOUORAMEMBEROFYOURFAMILYHAVINGSEVEREASTHMAANDORALLERGYISSUES
Do you want to able to always set your system to Auto* mode?
Yes No
Do you have a clean environment and purchased the unit for general air
purification reasons?
Yes No
14
The art of purification
®
IR
Control Panel details: right hand side
1. Timer: Press this button to set the timer for up to 12 hours of continuous operation. The time
left displays on the left hand side of the panel.
2. Auto: When you select auto mode, your unit will automatically change to the optimum speed
needed for air purification in the room. The sensor (located on the side of the unit) will tell the
unit when to raise or lower fan speed depending on the amount of particles in the room.
Night Mode: If you wish the LCD on the left hand side of the panel to turn off, press the Auto
button and hold down for 3 or more seconds to set the panel on Sleep mode. Press Auto
button again and hold down for 3 or more seconds to turn the LCD back on.
3. Reset: Press this button after you have replaced any of the filters. This will reset any blinking
lights and set filter life to full.
Note: This function is only activated when any of the filters require changing. If the filter life is full,
the button is disabled to prevent the accidental press of the button.
4. PoWER3PEED To turn the system on, rotate knob to select a speed from 1 to 5. The light
indicator for the selected speed will display as blue and the speed you selected will display
on the left hand side of the panel. To turn the system off, rotate the knob to the “power off”
position. When the air purifier is turned off, the fan stops rotating.
1
2
3
4
5
15
The art of purification ®
5. IR: This infrared receiver is used by your remote control to change unit settings
The default setting for the unit is moderate and will be displayed as 4 bars on the control panel.
This setting should meet most needs.
For advanced users only:
1. Make sure that the unit is on Standby mode (plug in the unit, and confirm knob is at the
“power off” position)
2. Press and hold“Auto” button for more than 5 seconds. You will hear a “ding” sound, the Con-
trol Setting bars will go from High, Moderate, Low, Moderate....... and then start blinking.
3. If you release “Auto “ button when “High” is blinking, the system is set to High Mode.
Answer the following questions to see if you need to change your setting.
Auto Mode: Your system will start on high to purify the air until it senses an eXTremely low con-
centration of particles and then auto change itself to the low setting.
If you answered“Yes” to any of the questions above, you may want to consider changing your
setting to “High”. If you answered “No”, answer the following question.
If you answered“Yes” to this question, you may want to consider changing your setting to“Low”.
Control Setting
Are you noticing severe indoor air pollution problems?
!REYOUORAMEMBEROFYOURFAMILYHAVINGSEVEREASTHMAANDORALLERGYISSUES
Do you want to able to always set your system to Auto* mode?
Yes No
Do you have a clean environment and purchased the unit for general air
purification reasons?
Yes No
16
The art of purification
®
When your unit is set on High, the sensor (on the side of the unit) is more sensitive to the
environment. The system will auto-activate when it detects small amounts of particles in the air.
And since it is more responsive to these small amounts of particles, it will activate frequently and
this will shorten the life of the filter however air will be more pure in your room.
When you unit is set on Low, The sensor (on the side of the unit) is less sensitive to the environment.
The system does not auto-activate until it senses a medium to high amount of particles in the air.
This setting eXTends the filter life.
If you own an AG850, that unit includes the Titanium Pro®module.
If your unit has been installed with the Titanium Pro®module, the light bulb icon will display on
your control panel. The light bulb serves to indicate if your unit has the module installed, but also
indicates when it is time to replace the module by blinking.
The Titanium Pro®module is designed to last 6000 hours. When that time is up, the light bulb icon
will start blinking. After you replace the filter, and you press the Reset button (right hand side of
the panel), it will stop blinking.
If desired, the Titanium Pro®module can be turned off.
1. With the power turned off, press the Timer button and hold down for more than 5 seconds.
2. The light bulb indicator will start blinking
3. When the light bulb is on, press the Timer button again to turn on the Titanium Pro®module
4. When the light bulb is off, press the Timer button to turn off the Titanium Pro®module
What happens in High Mode?
What happens in Low Mode?
Titanium Pro®
17
The art of purification ®
USING THE REMOTE CONTROL
Use the remote control to:
3WITCHTHESYSTEMONOFF
2. Change mode from manual to auto
3. Regulate fan speed
4. Set timer
The infrared receiver of the Airgle®system is located in the right hand bottom corner of the control
panel. In order to get the best signal transmission, the remote control should be pointed at the
control panel when pressing any button on the remote.
1. Open the battery compartment by pressing the small lever to the side and slide the battery
compartment out.
2. Remove the used battery.
3. Insert the new battery (Lithium coin battery 3V). Be sure that the (+) and (-) are correct.
Note: Rechargeable batteries are not compatible with the remote control.
Replacing the remote control battery
1
2
3
4
Used battery
16
The art of purification
®
When your unit is set on High, the sensor (on the side of the unit) is more sensitive to the
environment. The system will auto-activate when it detects small amounts of particles in the air.
And since it is more responsive to these small amounts of particles, it will activate frequently and
this will shorten the life of the filter however air will be more pure in your room.
When you unit is set on Low, The sensor (on the side of the unit) is less sensitive to the environment.
The system does not auto-activate until it senses a medium to high amount of particles in the air.
This setting eXTends the filter life.
If you own an AG850, that unit includes the Titanium Pro®module.
If your unit has been installed with the Titanium Pro®module, the light bulb icon will display on
your control panel. The light bulb serves to indicate if your unit has the module installed, but also
indicates when it is time to replace the module by blinking.
The Titanium Pro®module is designed to last 6000 hours. When that time is up, the light bulb icon
will start blinking. After you replace the filter, and you press the Reset button (right hand side of
the panel), it will stop blinking.
If desired, the Titanium Pro®module can be turned off.
1. With the power turned off, press the Timer button and hold down for more than 5 seconds.
2. The light bulb indicator will start blinking
3. When the light bulb is on, press the Timer button again to turn on the Titanium Pro®module
4. When the light bulb is off, press the Timer button to turn off the Titanium Pro®module
What happens in High Mode?
What happens in Low Mode?
Titanium Pro®
17
The art of purification ®
USING THE REMOTE CONTROL
Use the remote control to:
3WITCHTHESYSTEMONOFF
2. Change mode from manual to auto
3. Regulate fan speed
4. Set timer
The infrared receiver of the Airgle®system is located in the right hand bottom corner of the control
panel. In order to get the best signal transmission, the remote control should be pointed at the
control panel when pressing any button on the remote.
1. Open the battery compartment by pressing the small lever to the side and slide the battery
compartment out.
2. Remove the used battery.
3. Insert the new battery (Lithium coin battery 3V). Be sure that the (+) and (-) are correct.
Note: Rechargeable batteries are not compatible with the remote control.
Replacing the remote control battery
1
2
3
4
Used battery
19
18
The art of purification
®
USER SERVICING INSTRUCTIONS
OF YOUR PUREPAL®
AIR CLEANING SYSTEM
Your PurePal®system is equipped with a filter life monitor which will assist you in determining
when a filter needs to be replaced. If indicated, replace your filters.
Always turn off the air cleaner and unplug the power cord when doing any cleaning or maintenance
tasks.
Your PurePal®system provides access to all installed filters from the rear grill. Pull up the handle
to remove the grill and access the filters.
Filter Removal
Remove Filters (AG800 Model)
Remove Filters (AG850 Model)
Replace all filters in reverse order of removal
when done and make sure that the rear door
is completed closed.
®
The Gas & Odor filter is not
monitored by the Filter Check
system. The Gas & Odor Filter
should be checked at least every
two months to see if cleaning is
necessary.Trapped particles in the
filter build up and will block the
airflow which then shortens the
life of the HEPAfast filter. This will
reduce the system effectiveness
in cleaning the air in your room
Cleaning the Gas & Odor Filter
19
The art of purification
Open Rear Door
1 pull upǃ
2 pull outǃ
19
18
The art of purification
®
USER SERVICING INSTRUCTIONS
OF YOUR PUREPAL®
AIR CLEANING SYSTEM
Your PurePal®system is equipped with a filter life monitor which will assist you in determining
when a filter needs to be replaced. If indicated, replace your filters.
Always turn off the air cleaner and unplug the power cord when doing any cleaning or maintenance
tasks.
Your PurePal®system provides access to all installed filters from the rear grill. Pull up the handle
to remove the grill and access the filters.
Filter Removal
Remove Filters (AG800 Model)
Remove Filters (AG850 Model)
Replace all filters in reverse order of removal
when done and make sure that the rear door
is completed closed.
®
The Gas & Odor filter is not
monitored by the Filter Check
system. The Gas & Odor Filter
should be checked at least every
two months to see if cleaning is
necessary.Trapped particles in the
filter build up and will block the
airflow which then shortens the
life of the HEPAfast filter. This will
reduce the system effectiveness
in cleaning the air in your room
Cleaning the Gas & Odor Filter
19
The art of purification
Open Rear Door
1 pull upǃ
2 pull outǃ
®
IR
IR
When the first bar on the
Filter Life LCD is blinking, it
means the HEPAfast filter
needs replacement. Follow the
instructions above to remove the
dirty and install new ones.
Press the “Reset” button on the
Control Panel to reset the filter.
The filter life gauge should reset
to 6 full bars.
Replacing the HEPAfast filter
Replacing the Titanium Pro® module
When “Light bulb” sign on
the control panel is blinking, it
means the Titanium Pro®module
needs replacement. Follow the
instructions above to remove the
used Titanium Pro®and install
a new one. Press the “Reset”
button on the Control Panel to
reset. The “light bulb” will stop
blinking.
20
®
All other elecTRONICCOMPONENTSOFTHEUNITSUCHASMOTORFANAREMAINTENANCE-free
Cleaning the Housing and Sensor
Our unique Airgle®system design includes
a rear door with a grill that acts as a filter
for human hair and large particles. This
helps the life of the Gas & Odor filter,
the HEPAfast filter and the Titanium Pro®
module (if installed). Use your vacuum to
clean the grill on the rear door.
The sensor and housing can be cleaned,
using lukewarm water and a small amount
of detergent.
.
The art of purification
The art of purification
21
filter
This manual suits for next models
1
Table of contents
Other Airgle Air Cleaner manuals
Airgle
Airgle Purepal AG950 User manual
Airgle
Airgle AG550 User manual
Airgle
Airgle PurePal AG900 User manual
Airgle
Airgle PurePal AG900 User manual
Airgle
Airgle AG600 User manual
Airgle
Airgle AG600S User manual
Airgle
Airgle AG500 User manual
Airgle
Airgle 750 User manual
Airgle
Airgle AG500 User manual
Airgle
Airgle Purepal AG950 Maintenance manual
Popular Air Cleaner manuals by other brands
Purafil
Purafil PuraShield Smart 500 user manual
Ultravation
Ultravation UVPhotomax Signature SS-PTX-1224 Installation and owner's manual
RedyPure
RedyPure JR6 owner's manual
Field Controls
Field Controls Healthy Home System DUO-11/24 manual
Hunter
Hunter EcoSilver HP850UV quick start guide
Philips
Philips AC4054 user manual
