Basic Information
Thank you for purchasing the KVM-102UA Switch with Audio & Mic
Switching! With our highly reliable and quality product, user can enjoy
countless benefits from using it.
The KVM-102UA is a 2-port USB “KVM-in-the-Cable” Switch with audio
and microphone switching function. It provides 2 sets of built-in USB KVM
combo cables to save you cabling troubles. And its Audio and Microphone
switching function offers you uninterrupted multimedia experience. It
allows you to access, control, boot and reboot multiple USB-enabled
multimedia computers using only one USB keyboard, mouse, monitor and
a speaker set and microphone.
For PCs running Windows operating systems, it also provides an
innovative and easy-to-use KVM Switcher Software -- a small windows
client application to facilitate your KVM switching operations such as PC
selection and hotkey sequence programming, autoscanning, autoscan
delay time programming, independent/simultaneous audio & PC
Switching, etc.
The KVM-102UA USB “KVM-in-the-Cable” Switch offers USB 1.1
interface technology for Plug-and-Play and hot-pluggability. Users can
enjoy maximum flexibility and convenience with its compact and one-piece
design.
English
English

2
2
OvisLinkCor
p
. KV
M
-
102UA English
English
After the installation is completed, you will see a KVM Switcher icon on the
system tray of your window desktop. Just right click to evoke the operation
menu and double-click to evoke configuration box. For operation details of
the KVM Switcher software, please refer to the Operation Quick Reference.
Out-of-Box Installation
Take the Companion Diskette/CDROM and the KVM Switch out of the box
and follow the steps below for installation….
Step 1: Insert the companion CD ROM into your CD drive, and the installer
program, USBKVMIn.exe, will be run (or you can find it with the
Explorer and double-click its software icon to start installation).
Complete the software installation on each of the computers to be
connected to the KVM Switch.
: No live connection detected
: Current active PC channel is on port 1
: Current active PC channel is on port 2

3
3
OvisLinkCor
p
. KV
M
-
102UA
The KVM Switcher Software supports only the Windows platforms. For
other platforms such as Linux or MacOS, you can still use the keyboard
hotkey - ScrLk + ScrLK - to switch PC.
Step 2: Connect the shared USB keyboard, mouse, monitor,
speaker/headphone and microphone each to its port on your KVM
Switch.
Step 3: Connect a set of the built-in KVM/Audio&Mic cables to a
computer’s connectors. Connect another set of cables to another
computer. Now you can operate the KVM Switch immediately.
Some older computers with USB interface might need to manually enable
the USB option in the BIOS settings before you can use any USB devices.
If your USB interface does not work, please check the USB option status in
the BIOS.
If you use Windows 95/98/SE and has not yet installed a USB mouse on
your computer, there might be an error message telling you that mouse is
not detected and prompting you to decide whether to ignore the same
message in the future, and yet you found there is no mouse movement to
disable this message….So it is suggested that you should installed your
USB mouse on your computer first, before connected it to this KVM Switch.
English
English

4
4
OvisLinkCor
p
. KV
M
-
102UA
USB “KVM-in-the-Cable” Operation Quick Reference
There are three methods to control your KVM Switch for PC and Audio/Mic
channel selection: using (1) the front-panel push button, (2) a hotkey
sequence or (3) the KVM Switcher Software.
Face-panel button
The face-panel button allows you a direct control over KVM switching
operation. Simply press the button to switch to the next connected PC and
audio/mic channel (if binding is enabled). By default, PC port switching and
audio/mic port switching are bound together.
You can use the front panel button to switch to an empty port that is
not connected with any computer. Normally, if you use keyboard hotkeys
or the KVM Switcher software, you will not be able to switch to an empty
port.
Keyboard hotkeys
User-definable hotkeys for PC selection:
Hotkey sequence = Ctrl + Alt + [command key]*
* Please refer to next section for keys that are qualified to be used as a command key
Universal hotkey for PC toggle-switching:
Both the universal hotkey, ScrLk + ScrLk and the user-definable
hotkey, Ctrl + Alt + [command key] WILL NOT allow you to switch to an
empty port that is not connected with any computer. To force your KVM to
switch to an empty port, just press the front-panel button to switch.
Universal Hotkey sequence = ScrLk + ScrLk
* For operating systems other than Windows, you can still use this special hotkey to
facilitate PC switching.
Each keystroke within a hotkey sequence should be pressed within 2
seconds. Otherwise, the hotkey sequence will not be validated.
English
English

5
5
OvisLinkCor
p
. KV
M
-
102UA
KVM Switcher Operation Reference
After perform port switching, you have to wait till the KVM Switch
icon shows forth the target port before you can perform next switching
again. The KVM Switcher icon could be found on the system tray of your
Windows desktop after its installation.
KVM Switcher Software (only for Windows platform)
In addition to PC switching, the KVM Switcher Software also allows you
more advanced functions such as described in the next section….
English
English
Switch to PC x by Operation Menu
Right-click the KVM Switcher icon to evoke the operation menu, then select
whichever PC that is available for switching. Once you select a PC channel,
it will immediately switch to that PC. Note that the unconnected port(s) or
the active port will be grayed-out and non-selectable.
KVM SWITCHER
Operation Menu
KVM SWITCHER Configuration
Dialog Box

6
6
OvisLinkCor
p
. KV
M
-
102UA English
English
Switch to PC x by Keyboard Hotkeys
Hit the hotkey according to your current hotkey definition:
Hotkey sequence = Ctrl + Alt + [command key]*
* The factory default hotkey setting is Ctrl + Alt + 1/2/3/4 for PC 1/2/3/4. You can also
use ScrLk + ScrLk to switch PC.
Start Auto-scan
Right-click the KVM Switcher icon to evoke the operation menu, then select
Start Auto-Scan to activate autoscanning.
Stop Auto-scan
(While autoscanning) right-click the KVM Switcher icon to evoke the
operation menu, then select Stop Auto-Scan to de-activate autoscanning.
KVM Switcher configuration
Right-click the KVM Switcher icon and select Settings or double-click the
icon to bring up the configuration dialog box.
Define Hotkey commands
You can specify the command key as you like by typing it in. For example,
you can specify the hotkey for switching to PC 1 as CTRL + ALT + A by
typing an A (not case-sensitive) in the editable field.
Hotkey Sequence = CTRL + ALT + [command key]*
* The command key is user-definable via the configuration dialog box
Except those control keys such as Alt, Ctrl, Shift, CAPS, Tab, Esc and
those functions keys and edit keys, all other keys on the keyboard,
including those number keys on the number pad are all qualified to be used
a hotkey command key. In addition to the software KVM Switching by the
operation menu and the user-defined hotkeys, you can always use the
universal hotkey for PC switching – ScrLk + ScrLk

7
7
OvisLinkCor
p
. KV
M
-
102UA
MENO
Fix Audio Port at PC x
Check this option and then select the PC to fix the audio/mic channel to the
selected PC. Once this option is checked, the audio/mic channel will be
fixed and become non-switchable.
Auto Scan Period
Select the Autoscan period from 10 ~ 60 seconds with an increment of 5
seconds. The Autoscan period is the time your KVM Switch will wait to
switch to next PC.
English
English

8
8
OvisLinkCor
p
. KV
M
-
102UA
