INSTALLATION, OPERATION,
AND MAINTENANCE MANUAL

GENERAL DESCRIPTION
The Air+ DM-6000 is an auto-cleaning, zero-ozone, needlepoint ionizer producing billions of positive
and negative ions that deactivate bacteria and viruses, agglomerate particulate, and neutralize other
harmful pollutants. No maintenance is required as the needles are cleaned of dirt and dust automati-
cally and programmed from the factory at once per 24 hours of operation and upon start-up. The
DM-6000 can be installed in the supply duct of any air handling system. The goal of the technology is
to introduce ions to the airflow and have them delivered to the occupied space, so mount the
DM-6000 as close to the supply diffusers as possible. .
The unit can be powered with 12V or 24V, AC or DC, or a power supply can be provided for utilizing
120V or 240V AC power. The unit has communication capabilities including a dry contact and data
export to the BMS. The DM-6000 provides an electronic signal only when the ionizer is creating ions.
This signal is used to initiate a relay that closes the dry contact and powers the Ionization LED. The
DM-6000 is UL2998 validated for zero ozone emissions. ..
MECHANICAL INSTALLATION
The preferred location of the DM-6000 is in the supply air duct leaving the air handler. Be sure
to pick a location before any branch duct take-offs and ensure access to all switches and pow-
er/communication input and data output terminals. To improve the effectiveness of the filter,
the DM-6000 can be installed in the return duct upstream of the filter. .
1.
To mount the unit in a duct (See Figure 1): .2.
Install the DM-6000 such that the ionizing needles are pointed downstream of the airflow. A
directional arrow is located on the label to aid in unit orientation (See Figure 2). .
.
3.
Trace a 5 ½“ by 5 ½“ square on the surface of the duct onto which you are mounting
the ionizer. The units have a gasket that forms a seal between the duct and the
mounting flange. .
a.
Cut out the traced portion of the duct using snips or sheet metal shears. .
b.
Screw the DM-6000 onto the duct using sheet metal screws (See Figure 1). .
c.
CAUTION: The DM-6000 should not be installed immediately downstream of a humidifier
or exposed to any moisture. .
CAUTION: This product is intended for mounting into metallic construction only. .
CAUTION: The DM-6000 shall not be installed behind an inaccessible suspended floor/-
ceiling or a structural wall, ceiling, or floor. .
FIGURE 1
ON
OFF
Airow
FIGURE 2

ON
OFF
Ionization
LED
On/Off
Switch
FIGURE 4
ELECTRICAL INSTALLATION
Ideally, a dedicated 24V AC transformer be used to power the DM-6000. If this is not possi-
ble, power from a transformer serving other equipment may be used if sized adequately
to handle the additional VA rating of the DM-6000. The power source should be protect-
ed by a circuit breaker not exceeding 20 Amps. . .
1.
Power can be connected by either bringing 24V AC or DC directly to the terminal block on
the unit or using a factory provided 120V/240V to 12V DC power supply (Air+ Part No.
PS-Low). Connect 2.1mm pin to pin jack on the unit. (See Figure 3). ..
2.
To communicate with the BMS, connect BMS wires to the terminal block on the outside
of the unit. (See Figure 3). .
3.
Once power is connected to the unit, press the power switch to the "ON" position. The LED
should illuminate. (See Figure 4). .
.
4.
CAUTION: Do not connect power to the DM-6000 before the installation is complete.
Always disconnect power before handling any of the unit components. .
CAUTION: Surge protection should be utilized for this product at the equipment or
circuit feeding the ionizer. A transformer used to power the product must be grounded.
CAUTION: Do not power the ionizer from the same circuit or transformer to a UV Lamp.
FIGURE 3
24V AC or DC
OPTION 1
POWER
SUPPLY
120V/240V AC12V DC
OPTION 2
BMS WIRING TO ALARM CONTACTS (OPTIONAL)
Air+ Part No. PS-Low
Wiring and equipment provided by Air+
Wiring provided by contractor
*
*
AIR DUCT MOUNTED ACCESSORY WITH RESPECT TO ELECTRIC SHOCK, FIRE AND CASUALTY HAZARDS ONLY. E534812 VALIDATED
ZERO OZONE EMISSIONS - MEASURED OZONE EMSSIONS FROM Air+ DM-6000 DURING USE PHASE DOES NOTEXCEED 0.005 PPM ASTESTED BY UL 867 UL.COM/ECV
DM-6000
Auto-Cleaning Bipolar Ionizer
[phone]
[email protected] 222 Purchase St. Suite 210 Rye, NY 10580
IONIZATION
INDICATOR
POWER
ON OFF
POWER INPUT
24V AC OR DC 12V DC DRY CONTACTS
COMMUNICATION
DATA OUTPUT
COMMUNICATION
DATA OUTPUT
BMS COMMUNICATION

Air+, Inc | 222 Purchase St, Suite 210, Rye, NY 10580
Ph: 203-883-6700 | Fax: [phone] | [e-mail] | air-plus.com
OPERATION
The DM-6000 has an Alarm Circuit that communicates with the BMS. The Alarm Circuit utilizes a
relay with normally closed contacts. The contacts are open whenever the unit is not powered or
there is a fault in the system. When the DM-6000 is operating normally and producing ions, the
contacts close and the Ionization LED on the outside of the unit will illuminate. Connect the BMS
control wires to the BMS terminal block on the outside of the unit. (See Figure 3). .
TROUBLESHOOTING
BMS ALARM CONTACTS
When the power switch is turned “On”, the DM-6000 will activate, the LED will illuminate, and
the unit will produce ions. After about a minute, the self-cleaning mechanism will run
through a complete cleaning cycle and the unit will produce ions again (See Figure 4). .
1.
If the DM-6000 is not operating, check that the power switch is set to the “On” position and
the Ionization LED is illuminated. .
1.
The DM-6000 has an internal automatically resetting fuse. If the fuse trips, remove power by
turning the power switch off, wait 2-5 minutes for the fuse to reset and turn power back on. If
the fuse trips again, contact customer support. .
3.
Confirm that all power wiring is connected properly to the terminal block on the outside of
the unit. Test the BMS Dry Contacts using a multimeter set to continuity mode. If the multime-
ter alarms, the circuit is continuous, and operation is confirmed. If it does not alarm, the circuit
is not continuous and there is a problem. Contact Air+ customer support as needed. ..
2.
Because the DM-6000 is self-cleaning, no maintenance of any kind is required. The cleaning
cycle is factory programmed to initiate every 24 hours and upon start-up. .
2.
