Aiwa CDC-MP33R User manual
2
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
O ACCESSORY 87-B10-141-010 0E NUT,5 TYPE-2 YZSTF CDC-MP33R
O ACCESSORY 87-B10-143-010 0E UT1+5-15 W/O SLOT YZSTF CDC-MP33R
O ACCESSORY 87-B10-144-010 0E W,5 2-10-0 5 YZSTF CDC-MP33R
O ACCESSORY 87-B10-145-010 0E W-SPR,5 3-8 5-1 5 YZSTF CDC-MP33R
X ACCESSORY 87-B40-178-010 0E BAG,PV 0 04-100-250 YZSTF CDC-MP33R
X ACCESSORY 87-B40-179-010 0E BAG,PV 0 04-50-100 YZSTF CDC-MP33R
O ACCESSORY 8Z-KC1-231-110 1C HLDR,HALF -C YZSTF CDC-MP33R
O ACCESSORY 8Z-KC1-232-010 0E KEY,REMOVE -C YZSTF CDC-MP33R
O ACCESSORY 8Z-KC1-235-010 0E HLDR,REAR MTG YZSTF CDC-MP33R
O ACCESSORY 8Z-KC1-244-010 0E S-SCREW,5*6 TH+ TAPPING ST YZSTF CDC-MP33R
O ACCESSORY 8Z-KC1-250-010 0E S-SCREW,HEXAGON YZSTF CDC-MP33R
O APPEARANCE 8B-KC5-001-010 -- WINDOW,LCD MP33R YZ YZSTF CDC-MP33R
O APPEARANCE 8B-KC7-025-010 -- PANEL,BOARD YZSTF CDC-MP33R
O APPEARANCE * 8B-KC6-002-010 -- CABI,FRONT AL MP3 YZSTF CDC-MP33R
O APPEARANCE * 8B-KC7-001-010 -- CABI,FRONT HIGH YZSTF CDC-MP33R
O APPEARANCE * 8B-KC7-002-010 -- CABI,REAR YZSTF CDC-MP33R
O APPEARANCE * 8B-KC7-008-010 -- CABI,BTN PANEL B YZSTF CDC-MP33R
O APPEARANCE * 8B-KC7-015-010 -- LENS,BER YZSTF CDC-MP33R
O APPEARANCE * 8B-KC7-021-010 -- CABI,BASE MAIN YZSTF CDC-MP33R
O APPEARANCE * 8B-KC7-022-010 -- LENS,CD YZSTF CDC-MP33R
O APPEARANCE * 8B-KC7-023-010 -- CABI,BASE AROUND YZSTF CDC-MP33R
O APPEARANCE * 8B-KC7-024-010 -- CABI,TRIM YZSTF CDC-MP33R
O CD 88-KC4-641-010 1A FF-CABLE, 20P 1 0 90MM YZSTF CDC-MP33R
O CD 88-ZG5-317-010 0E S-SCREW,8ZG5S+2-4 W/O YZSTF CDC-MP33R
O CD 8A-KC7-255-010 0E SPR-C,WIRE YZSTF CDC-MP33R
X CD A8-BZA-890-040 -- BZA-8 MP3NF YZSTF CDC-MP33R
X CD M8-AZK-E90-070 3M CDC02AW1 YZSTF CDC-MP33R
O CD C 0402 87-A10-369-080 0E C-CAP,S 0 47-16 K B YZSTF CDC-MP33R
O CD C 0403 87-A10-369-080 0E C-CAP,S 0 47-16 K B YZSTF CDC-MP33R
O CD C 0409 87-010-494-040 0E CAP,E 1-50 M 5L SRE YZSTF CDC-MP33R
O CD C 0410 87-010-494-040 0E CAP,E 1-50 M 5L SRE YZSTF CDC-MP33R
X CD R 0435 88-108-183-080 0E C-RES,U 18K-1/16W J YZSTF CDC-MP33R
X CD R 0436 88-108-183-080 0E C-RES,U 18K-1/16W J YZSTF CDC-MP33R
X CONNECTION 8A-KCG-615-010 -- WIRE,400 P-MUTE YZSTF CDC-MP33R
O CONNECTION 8B-KC1-603-010 0E F-CABLE,2P (PWB LED) YZSTF CDC-MP33R
O CONNECTION * 8B-KC7-617-010 0E CONN ASSY,6P EMP YZSTF CDC-MP33R
O CONNECTION * 8B-KC7-618-010 0E F-CABLE,2P MOT YZSTF CDC-MP33R
O CONNECTION ANT0101 8Z-KT1-614-010 1A ANT,AW-002 YZSTF CDC-MP33R
O CONNECTION CON0401 87-A61-219-010 1A CONN,20P H 52089-2020 YZSTF CDC-MP33R
O CONNECTION CON0402 87-A61-584-010 1B CONN,24P H 52089-2420 YZSTF CDC-MP33R
O CONNECTION CON0403 87-A61-583-010 1A CONN,16P H 52089-1620 YZSTF CDC-MP33R
O CONNECTION CON0701 8A-KT1-646-010 1C CONN ASSY,8P ISO-WHITE-B YZSTF CDC-MP33R
O CONNECTION CON0702 8A-KT1-645-010 1C CONN ASSY,8P ISO-BLACK-B YZSTF CDC-MP33R
O CONNECTION CON0751 87-A60-670-010 0E CONN,6P H 2MM JMT YZSTF CDC-MP33R
O CONNECTION J 0401 87-A61-224-110 1A JACK,PIN 4P XR-401 YZSTF CDC-MP33R
O CONNECTION J 0402 8A-KC7-620-010 1B JACK,DIN 13 P SKDS1302 YZSTF CDC-MP33R
O E-VOL C 0301 87-010-497-040 0E CAP,E 4 7-35 M 5L SRE YZSTF CDC-MP33R
O E-VOL C 0302 87-010-497-040 0E CAP,E 4 7-35 M 5L SRE YZSTF CDC-MP33R
O E-VOL C 0303 87-010-494-040 0E CAP,E 1-50 M 5L SRE YZSTF CDC-MP33R
O E-VOL C 0304 87-010-494-040 0E CAP,E 1-50 M 5L SRE YZSTF CDC-MP33R
O E-VOL C 0305 87-012-280-080 0E C-CAP,U 3300P-50 K B YZSTF CDC-MP33R
O E-VOL C 0306 87-012-280-080 0E C-CAP,U 3300P-50 K B YZSTF CDC-MP33R
O E-VOL C 0307 87-010-787-080 0E C-CAP,U 0 022-25 K B YZSTF CDC-MP33R
O E-VOL C 0308 87-010-787-080 0E C-CAP,U 0 022-25 K B YZSTF CDC-MP33R
O E-VOL C 0309 87-010-494-040 0E CAP,E 1-50 M 5L SRE YZSTF CDC-MP33R
O E-VOL C 0310 87-010-494-040 0E CAP,E 1-50 M 5L SRE YZSTF CDC-MP33R
O E-VOL C 0311 87-A12-308-080 0E C-CAP,S 0 15-25 K B YZSTF CDC-MP33R
O E-VOL C 0312 87-A12-308-080 0E C-CAP,S 0 15-25 K B YZSTF CDC-MP33R
O E-VOL C 0313 87-A12-308-080 0E C-CAP,S 0 15-25 K B YZSTF CDC-MP33R
O E-VOL C 0314 87-A12-308-080 0E C-CAP,S 0 15-25 K B YZSTF CDC-MP33R
O E-VOL C 0315 87-010-494-040 0E CAP,E 1-50 M 5L SRE YZSTF CDC-MP33R
O E-VOL C 0316 87-010-494-040 0E CAP,E 1-50 M 5L SRE YZSTF CDC-MP33R
O E-VOL C 0317 87-010-831-080 0E C-CAP,U 0 1-16 Z F YZSTF CDC-MP33R
O E-VOL C 0318 87-010-498-040 0E CAP,E 10-16 M 5L SRE YZSTF CDC-MP33R
O E-VOL C 0321 87-010-555-040 0E CAP,E 100-10 M 5L SRE YZSTF CDC-MP33R
O E-VOL C 0322 87-010-787-080 0E C-CAP,U 0 022-25 K B YZSTF CDC-MP33R
O E-VOL C 0323 87-010-498-040 0E CAP,E 10-16 M 5L SRE YZSTF CDC-MP33R
O E-VOL C 0324 87-010-498-040 0E CAP,E 10-16 M 5L SRE YZSTF CDC-MP33R
O E-VOL C 0325 87-010-498-040 0E CAP,E 10-16 M 5L SRE YZSTF CDC-MP33R
O E-VOL C 0326 87-010-498-040 0E CAP,E 10-16 M 5L SRE YZSTF CDC-MP33R
3
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
O E-VOL C 0341 87-010-491-040 0E CAP,E 0 22-50 M 5L SRE YZSTF CDC-MP33R
O E-VOL C 0342 87-010-491-040 0E CAP,E 0 22-50 M 5L SRE YZSTF CDC-MP33R
O E-VOL C 0401 87-010-494-040 0E CAP,E 1-50 M 5L SRE YZSTF CDC-MP33R
O E-VOL C 0423 87-010-497-040 0E CAP,E 4 7-35 M 5L SRE YZSTF CDC-MP33R
O E-VOL C 0424 87-010-497-040 0E CAP,E 4 7-35 M 5L SRE YZSTF CDC-MP33R
O E-VOL C 0425 87-010-497-040 0E CAP,E 4 7-35 M 5L SRE YZSTF CDC-MP33R
O E-VOL C 0426 87-010-497-040 0E CAP,E 4 7-35 M 5L SRE YZSTF CDC-MP33R
O E-VOL C 0427 87-012-270-080 0E C-CAP,U 470P-50 K B YZSTF CDC-MP33R
O E-VOL C 0428 87-012-270-080 0E C-CAP,U 470P-50 K B YZSTF CDC-MP33R
O E-VOL C 0429 87-012-270-080 0E C-CAP,U 470P-50 K B YZSTF CDC-MP33R
O E-VOL C 0430 87-012-270-080 0E C-CAP,U 470P-50 K B YZSTF CDC-MP33R
O E-VOL C 0451 87-012-358-080 0E C-CAP,S 0 47-10 Z F CM/CB YZSTF CDC-MP33R
O E-VOL C 0452 87-012-358-080 0E C-CAP,S 0 47-10 Z F CM/CB YZSTF CDC-MP33R
O E-VOL C 0453 87-010-831-080 0E C-CAP,U 0 1-16 Z F YZSTF CDC-MP33R
O E-VOL C 0454 87-012-286-080 0E C-CAP,U 0 01-25 K B YZSTF CDC-MP33R
S E-VOL D 0301 87-020-331-040 0E C-DIODE,DAN202K YZSTF CDC-MP33R
S E-VOL D 0401 87-020-331-040 0E C-DIODE,DAN202K YZSTF CDC-MP33R
S E-VOL D 0451 87-A40-250-040 0E C-DIODE,DAN217 YZSTF CDC-MP33R
S E-VOL IC 0301 8Z-KT1-622-010 2A C-IC,LC75374E YZSTF CDC-MP33R
X E-VOL JR 0005 88-108-000-080 0E C-JUMPER,U YZSTF CDC-MP33R
X E-VOL JR 0006 88-108-000-080 0E C-JUMPER,U YZSTF CDC-MP33R
X E-VOL JR 0007 88-108-000-080 0E C-JUMPER,U YZSTF CDC-MP33R
X E-VOL JR 0008 88-108-000-080 0E C-JUMPER,U YZSTF CDC-MP33R
X E-VOL JR 0009 88-108-000-080 0E C-JUMPER,U YZSTF CDC-MP33R
X E-VOL JR 0010 88-108-000-080 0E C-JUMPER,U YZSTF CDC-MP33R
O E-VOL L 0401 87-003-102-080 0E COIL,10UH J LAL02 YZSTF CDC-MP33R
S E-VOL Q 0341 87-A30-287-040 0E C-TR,DTC114TKA YZSTF CDC-MP33R
S E-VOL Q 0342 87-A30-287-040 0E C-TR,DTC114TKA YZSTF CDC-MP33R
S E-VOL Q 0401 87-A30-283-040 0E C-TR,DTA114YKA YZSTF CDC-MP33R
S E-VOL Q 0402 87-A30-287-040 0E C-TR,DTC114TKA YZSTF CDC-MP33R
S E-VOL Q 0403 87-A30-287-040 0E C-TR,DTC114TKA YZSTF CDC-MP33R
S E-VOL Q 0404 87-A30-287-040 0E C-TR,DTC114TKA YZSTF CDC-MP33R
S E-VOL Q 0405 87-A30-287-040 0E C-TR,DTC114TKA YZSTF CDC-MP33R
S E-VOL Q 0406 87-A30-287-040 0E C-TR,DTC114TKA YZSTF CDC-MP33R
S E-VOL Q 0451 89-324-122-040 0E C-TR,2SC2412KR YZSTF CDC-MP33R
X E-VOL R 0301 88-108-332-080 0E C-RES,U 3 3K-1/16W J YZSTF CDC-MP33R
X E-VOL R 0302 88-108-332-080 0E C-RES,U 3 3K-1/16W J YZSTF CDC-MP33R
X E-VOL R 0303 88-108-332-080 0E C-RES,U 3 3K-1/16W J YZSTF CDC-MP33R
X E-VOL R 0304 88-108-332-080 0E C-RES,U 3 3K-1/16W J YZSTF CDC-MP33R
X E-VOL R 0305 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X E-VOL R 0306 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X E-VOL R 0307 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X E-VOL R 0308 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X E-VOL R 0311 88-108-223-080 0E C-RES,U 22K-1/16W J YZSTF CDC-MP33R
X E-VOL R 0312 88-108-223-080 0E C-RES,U 22K-1/16W J YZSTF CDC-MP33R
X E-VOL R 0313 88-108-223-080 0E C-RES,U 22K-1/16W J YZSTF CDC-MP33R
X E-VOL R 0314 88-108-223-080 0E C-RES,U 22K-1/16W J YZSTF CDC-MP33R
X E-VOL R 0315 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X E-VOL R 0316 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X E-VOL R 0317 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X E-VOL R 0318 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X E-VOL R 0321 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X E-VOL R 0322 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X E-VOL R 0323 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X E-VOL R 0341 88-108-335-080 0E C-RES,U 3 3M-1/16W J YZSTF CDC-MP33R
X E-VOL R 0342 88-108-335-080 0E C-RES,U 3 3M-1/16W J YZSTF CDC-MP33R
X E-VOL R 0343 88-108-104-080 0E C-RES,U 100K-1/16W J YZSTF CDC-MP33R
X E-VOL R 0344 88-108-104-080 0E C-RES,U 100K-1/16W J YZSTF CDC-MP33R
X E-VOL R 0345 88-108-104-080 0E C-RES,U 100K-1/16W J YZSTF CDC-MP33R
X E-VOL R 0346 88-108-104-080 0E C-RES,U 100K-1/16W J YZSTF CDC-MP33R
X E-VOL R 0401 88-108-562-080 0E C-RES,U 5 6K-1/16W J YZSTF CDC-MP33R
X E-VOL R 0402 88-108-222-080 0E C-RES,U 2 2K-1/16W J YZSTF CDC-MP33R
X E-VOL R 0411 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X E-VOL R 0412 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X E-VOL R 0413 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X E-VOL R 0414 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X E-VOL R 0437 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X E-VOL R 0438 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X E-VOL R 0439 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X E-VOL R 0440 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
4
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
X E-VOL R 0451 88-108-104-080 0E C-RES,U 100K-1/16W J YZSTF CDC-MP33R
X E-VOL R 0452 88-108-104-080 0E C-RES,U 100K-1/16W J YZSTF CDC-MP33R
X E-VOL R 0453 88-108-105-080 0E C-RES,U 1M-1/16W J YZSTF CDC-MP33R
X E-VOL R 0454 88-108-472-080 0E C-RES,U 4 7K-1/16W J YZSTF CDC-MP33R
X E-VOL R 0455 88-108-103-080 0E C-RES,U 10K-1/16W J YZSTF CDC-MP33R
X E-VOL R 0456 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X E-VOL R 0457 88-108-105-080 0E C-RES,U 1M-1/16W J YZSTF CDC-MP33R
O ELECTRICAL C 0602 87-010-831-080 0E C-CAP,U 0 1-16 Z F YZSTF CDC-MP33R
O ELECTRICAL C 0603 87-010-831-080 0E C-CAP,U 0 1-16 Z F YZSTF CDC-MP33R
O ELECTRICAL C 0604 87-A10-504-080 0E C-CAP,U 0 047-16 K B YZSTF CDC-MP33R
O ELECTRICAL C 0605 87-012-199-080 0E C-CAP,U 220P-50 J CH YZSTF CDC-MP33R
O ELECTRICAL C 0606 87-A10-504-080 0E C-CAP,U 0 047-16 K B YZSTF CDC-MP33R
O ELECTRICAL C 0607 87-A10-504-080 0E C-CAP,U 0 047-16 K B YZSTF CDC-MP33R
O ELECTRICAL C 0608 87-A10-504-080 0E C-CAP,U 0 047-16 K B YZSTF CDC-MP33R
O ELECTRICAL C 0609 87-A10-504-080 0E C-CAP,U 0 047-16 K B YZSTF CDC-MP33R
O ELECTRICAL C 0610 87-010-805-080 0E C-CAP,S 1-16 Z F YZSTF CDC-MP33R
O ELECTRICAL C 0611 87-010-831-080 0E C-CAP,U 0 1-16 Z F YZSTF CDC-MP33R
O ELECTRICAL C 0612 87-010-831-080 0E C-CAP,U 0 1-16 Z F YZSTF CDC-MP33R
O ELECTRICAL C 0613 87-012-286-080 0E C-CAP,U 0 01-25 K B YZSTF CDC-MP33R
O ELECTRICAL C 0621 87-010-831-080 0E C-CAP,U 0 1-16 Z F YZSTF CDC-MP33R
O ELECTRICAL CON0601 87-A61-585-080 1B C-CONN,24P H 54548-2490 YZSTF CDC-MP33R
O ELECTRICAL CON0603 87-A61-586-080 1A C-CONN,16P V FLZT-SM1 YZSTF CDC-MP33R
S ELECTRICAL D 0601 87-A40-250-040 0E C-DIODE,DAN217 YZSTF CDC-MP33R
S ELECTRICAL IC 0601 87-A21-532-030 2M C-IC,LC75817W-8720 YZSTF CDC-MP33R
X ELECTRICAL JR 0601 88-108-000-080 0E C-JUMPER,U YZSTF CDC-MP33R
X ELECTRICAL JR 0602 88-108-000-080 0E C-JUMPER,U YZSTF CDC-MP33R
O ELECTRICAL L 0601 87-005-906-080 0E C-COIL,S 10UH K LK2125 YZSTF CDC-MP33R
O ELECTRICAL L 0602 87-005-906-080 0E C-COIL,S 10UH K LK2125 YZSTF CDC-MP33R
O ELECTRICAL L 0603 87-005-906-080 0E C-COIL,S 10UH K LK2125 YZSTF CDC-MP33R
O ELECTRICAL LED0601 87-A91-355-040 0E C-LED,BR1112H-TR-RED YZSTF CDC-MP33R
O ELECTRICAL LED0602 87-A91-355-040 0E C-LED,BR1112H-TR-RED YZSTF CDC-MP33R
O ELECTRICAL LED0603 87-A91-355-040 0E C-LED,BR1112H-TR-RED YZSTF CDC-MP33R
O ELECTRICAL LED0604 87-A91-355-040 0E C-LED,BR1112H-TR-RED YZSTF CDC-MP33R
O ELECTRICAL LED0611 87-A91-355-040 0E C-LED,BR1112H-TR-RED YZSTF CDC-MP33R
O ELECTRICAL LED0612 87-A91-355-040 0E C-LED,BR1112H-TR-RED YZSTF CDC-MP33R
O ELECTRICAL LED0613 87-A91-355-040 0E C-LED,BR1112H-TR-RED YZSTF CDC-MP33R
O ELECTRICAL LED0614 87-A91-355-040 0E C-LED,BR1112H-TR-RED YZSTF CDC-MP33R
O ELECTRICAL LED0615 87-A91-355-040 0E C-LED,BR1112H-TR-RED YZSTF CDC-MP33R
O ELECTRICAL LED0616 87-A91-355-040 0E C-LED,BR1112H-TR-RED YZSTF CDC-MP33R
O ELECTRICAL LED0617 87-A91-355-040 0E C-LED,BR1112H-TR-RED YZSTF CDC-MP33R
O ELECTRICAL LED0619 87-A40-813-240 1E C-LED,SEC1E01C BLU YZSTF CDC-MP33R
O ELECTRICAL LED0620 87-A40-813-240 1E C-LED,SEC1E01C BLU YZSTF CDC-MP33R
O ELECTRICAL LED0621 87-A40-813-240 1E C-LED,SEC1E01C BLU YZSTF CDC-MP33R
O ELECTRICAL LED0622 87-A40-813-240 1E C-LED,SEC1E01C BLU YZSTF CDC-MP33R
O ELECTRICAL LED0625 87-A91-355-040 0E C-LED,BR1112H-TR-RED YZSTF CDC-MP33R
O ELECTRICAL LED0626 87-A91-355-040 0E C-LED,BR1112H-TR-RED YZSTF CDC-MP33R
S ELECTRICAL Q 0611 89-324-122-040 0E C-TR,2SC2412KR YZSTF CDC-MP33R
S ELECTRICAL Q 0613 87-A30-287-040 0E C-TR,DTC114TKA YZSTF CDC-MP33R
S ELECTRICAL Q 0614 89-324-122-040 0E C-TR,2SC2412KR YZSTF CDC-MP33R
S ELECTRICAL Q 0615 89-324-122-040 0E C-TR,2SC2412KR YZSTF CDC-MP33R
X ELECTRICAL R 0601 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X ELECTRICAL R 0602 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X ELECTRICAL R 0603 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X ELECTRICAL R 0604 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X ELECTRICAL R 0605 88-108-333-080 0E C-RES,U 33K-1/16W J YZSTF CDC-MP33R
X ELECTRICAL R 0606 88-108-103-080 0E C-RES,U 10K-1/16W J YZSTF CDC-MP33R
X ELECTRICAL R 0607 88-108-103-080 0E C-RES,U 10K-1/16W J YZSTF CDC-MP33R
X ELECTRICAL R 0608 88-108-103-080 0E C-RES,U 10K-1/16W J YZSTF CDC-MP33R
X ELECTRICAL R 0609 88-108-103-080 0E C-RES,U 10K-1/16W J YZSTF CDC-MP33R
X ELECTRICAL R 0612 88-118-471-080 0E C-RES,S 470-1/10W J YZSTF CDC-MP33R
X ELECTRICAL R 0613 88-118-471-080 0E C-RES,S 470-1/10W J YZSTF CDC-MP33R
X ELECTRICAL R 0615 88-108-331-080 0E C-RES,U 330-1/16W J YZSTF CDC-MP33R
X ELECTRICAL R 0616 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X ELECTRICAL R 0617 88-108-180-080 0E C-RES,U 18-1/16W J YZSTF CDC-MP33R
X ELECTRICAL R 0618 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X ELECTRICAL R 0619 88-108-332-080 0E C-RES,U 3 3K-1/16W J YZSTF CDC-MP33R
X ELECTRICAL R 0620 88-118-331-080 0E C-RES,S 330-1/10W J YZSTF CDC-MP33R
X ELECTRICAL R 0621 88-118-331-080 0E C-RES,S 330-1/10W J YZSTF CDC-MP33R
X ELECTRICAL R 0651 88-118-331-080 0E C-RES,S 330-1/10W J YZSTF CDC-MP33R
X ELECTRICAL R 0652 88-118-471-080 0E C-RES,S 470-1/10W J YZSTF CDC-MP33R
5
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
X ELECTRICAL R 0653 88-118-471-080 0E C-RES,S 470-1/10W J YZSTF CDC-MP33R
X ELECTRICAL R 0654 88-118-331-080 0E C-RES,S 330-1/10W J YZSTF CDC-MP33R
X ELECTRICAL R 0655 88-108-152-080 0E C-RES,U 1 5K-1/16W J YZSTF CDC-MP33R
X ELECTRICAL R 0656 88-108-152-080 0E C-RES,U 1 5K-1/16W J YZSTF CDC-MP33R
X ELECTRICAL R 0657 88-118-331-080 0E C-RES,S 330-1/10W J YZSTF CDC-MP33R
X ELECTRICAL R 0658 88-118-331-080 0E C-RES,S 330-1/10W J YZSTF CDC-MP33R
X ELECTRICAL R 0659 88-118-331-080 0E C-RES,S 330-1/10W J YZSTF CDC-MP33R
X ELECTRICAL R 0660 88-118-331-080 0E C-RES,S 330-1/10W J YZSTF CDC-MP33R
X ELECTRICAL R 0661 88-118-331-080 0E C-RES,S 330-1/10W J YZSTF CDC-MP33R
O ELECTRICAL SW 0601 87-A90-001-080 1A C-SW,TACT SKQMAL YZSTF CDC-MP33R
O ELECTRICAL SW 0602 87-A90-001-080 1A C-SW,TACT SKQMAL YZSTF CDC-MP33R
O ELECTRICAL SW 0603 87-A90-001-080 1A C-SW,TACT SKQMAL YZSTF CDC-MP33R
O ELECTRICAL SW 0604 87-A90-001-080 1A C-SW,TACT SKQMAL YZSTF CDC-MP33R
O ELECTRICAL SW 0605 87-A90-001-080 1A C-SW,TACT SKQMAL YZSTF CDC-MP33R
O ELECTRICAL SW 0606 87-036-220-080 1A C-SW,TACT SKQDAA YZSTF CDC-MP33R
O ELECTRICAL SW 0607 87-036-220-080 1A C-SW,TACT SKQDAA YZSTF CDC-MP33R
O ELECTRICAL SW 0608 87-036-220-080 1A C-SW,TACT SKQDAA YZSTF CDC-MP33R
O ELECTRICAL SW 0609 87-036-220-080 1A C-SW,TACT SKQDAA YZSTF CDC-MP33R
O ELECTRICAL SW 0610 87-036-220-080 1A C-SW,TACT SKQDAA YZSTF CDC-MP33R
O ELECTRICAL SW 0611 87-036-220-080 1A C-SW,TACT SKQDAA YZSTF CDC-MP33R
O ELECTRICAL SW 0612 87-036-220-080 1A C-SW,TACT SKQDAA YZSTF CDC-MP33R
O ELECTRICAL SW 0613 87-036-220-080 1A C-SW,TACT SKQDAA YZSTF CDC-MP33R
O ELECTRICAL SW 0614 87-036-220-080 1A C-SW,TACT SKQDAA YZSTF CDC-MP33R
O ELECTRICAL SW 0615 87-036-220-080 1A C-SW,TACT SKQDAA YZSTF CDC-MP33R
O ELECTRICAL SW 0616 87-036-220-080 1A C-SW,TACT SKQDAA YZSTF CDC-MP33R
O ELECTRICAL SW 0617 87-036-220-080 1A C-SW,TACT SKQDAA YZSTF CDC-MP33R
O ELECTRICAL SW 0618 87-036-220-080 1A C-SW,TACT SKQDAA YZSTF CDC-MP33R
O ELECTRICAL SW 0620 87-A90-001-080 1A C-SW,TACT SKQMAL YZSTF CDC-MP33R
O KNOB 8B-KC1-002-010 -- BTN,P-SET YZ YZSTF CDC-MP33R
O KNOB 8B-KC7-004-010 -- BTN,+/- YZSTF CDC-MP33R
O KNOB 8B-KC7-005-010 -- BTN,MUTE YZSTF CDC-MP33R
O KNOB 8B-KC7-006-010 -- BTN,TWIN YZSTF CDC-MP33R
X LBL,POP 8B-KC6-970-010 0E LBL,POP MF 4C MP3 YZSTF CDC-MP33R
X MECHANISM M8-AZL-290-040 -- AZL-2 ANF YZSTF CDC-MP33R
O MICON C 0461 87-010-787-080 0E C-CAP,U 0 022-25 K B YZSTF CDC-MP33R
O MICON C 0901 87-016-039-090 1B CAP,DL 0 022F-5 5 Z 70 FM YZSTF CDC-MP33R
O MICON C 0902 87-012-358-080 0E C-CAP,S 0 47-10 Z F CM/CB YZSTF CDC-MP33R
O MICON C 0903 87-010-831-080 0E C-CAP,U 0 1-16 Z F YZSTF CDC-MP33R
O MICON C 0904 87-010-787-080 0E C-CAP,U 0 022-25 K B YZSTF CDC-MP33R
O MICON C 0905 87-012-180-080 0E C-CAP,U 22P-50 J CH YZSTF CDC-MP33R
O MICON C 0906 87-012-182-080 0E C-CAP,U 27P-50 J CH YZSTF CDC-MP33R
O MICON C 0907 87-010-831-080 0E C-CAP,U 0 1-16 Z F YZSTF CDC-MP33R
O MICON C 0908 87-012-282-080 0E C-CAP,U 4700P-50 K B YZSTF CDC-MP33R
O MICON C 0909 87-012-274-080 0E C-CAP,U 1000P-50 K B YZSTF CDC-MP33R
O MICON C 0910 87-012-195-080 0E C-CAP,U 100P-50 J CH YZSTF CDC-MP33R
O MICON C 0911 87-012-195-080 0E C-CAP,U 100P-50 J CH YZSTF CDC-MP33R
O MICON C 0912 87-010-787-080 0E C-CAP,U 0 022-25 K B YZSTF CDC-MP33R
O MICON C 0913 87-010-787-080 0E C-CAP,U 0 022-25 K B YZSTF CDC-MP33R
O MICON C 0915 87-012-274-080 0E C-CAP,U 1000P-50 K B YZSTF CDC-MP33R
O MICON C 0916 87-010-787-080 0E C-CAP,U 0 022-25 K B YZSTF CDC-MP33R
S MICON D 0461 87-A40-817-040 0E C-ZENER,STZ6 8N YZSTF CDC-MP33R
S MICON D 0462 87-A40-817-040 0E C-ZENER,STZ6 8N YZSTF CDC-MP33R
S MICON D 0463 87-A40-817-040 0E C-ZENER,STZ6 8N YZSTF CDC-MP33R
S MICON D 0708 87-020-330-040 0E C-DIODE,DAP202K YZSTF CDC-MP33R
S MICON D 0713 87-070-136-080 0E ZENER,MTZJ5 1B YZSTF CDC-MP33R
S MICON D 0901 87-020-331-040 0E C-DIODE,DAN202K YZSTF CDC-MP33R
S MICON D 0904 87-020-331-040 0E C-DIODE,DAN202K YZSTF CDC-MP33R
S MICON D 0905 87-020-331-040 0E C-DIODE,DAN202K YZSTF CDC-MP33R
S MICON D 0907 87-020-331-040 0E C-DIODE,DAN202K YZSTF CDC-MP33R
S MICON D 0908 87-020-331-040 0E C-DIODE,DAN202K YZSTF CDC-MP33R
S MICON D 0909 87-020-331-040 0E C-DIODE,DAN202K YZSTF CDC-MP33R
S MICON D 0910 87-020-331-040 0E C-DIODE,DAN202K YZSTF CDC-MP33R
S MICON D 0911 87-020-331-040 0E C-DIODE,DAN202K YZSTF CDC-MP33R
S MICON IC 0901 8B-KC6-621-030 -- C-IC,UPD178018AGC-XXX YZSTF CDC-MP33R
S MICON IC 0903 87-020-784-040 1B C-IC,TC4053BF YZSTF CDC-MP33R
O MICON L 0702 87-003-149-080 0E COIL,47UH J LAL02 YZSTF CDC-MP33R
S MICON Q 0461 87-A30-283-040 0E C-TR,DTA114YKA YZSTF CDC-MP33R
S MICON Q 0462 87-A30-288-040 0E C-TR,DTC114YKA YZSTF CDC-MP33R
X MICON R 0403 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X MICON R 0461 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
6
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
X MICON R 0462 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X MICON R 0463 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X MICON R 0464 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X MICON R 0465 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X MICON R 0466 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X MICON R 0467 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X MICON R 0468 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X MICON R 0469 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X MICON R 0470 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X MICON R 0471 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X MICON R 0718 88-108-222-080 0E C-RES,U 2 2K-1/16W J YZSTF CDC-MP33R
X MICON R 0901 88-108-473-080 0E C-RES,U 47K-1/16W J YZSTF CDC-MP33R
X MICON R 0902 88-108-104-080 0E C-RES,U 100K-1/16W J YZSTF CDC-MP33R
X MICON R 0903 88-108-104-080 0E C-RES,U 100K-1/16W J YZSTF CDC-MP33R
X MICON R 0904 88-108-104-080 0E C-RES,U 100K-1/16W J YZSTF CDC-MP33R
X MICON R 0905 88-108-104-080 0E C-RES,U 100K-1/16W J YZSTF CDC-MP33R
X MICON R 0906 88-108-224-080 0E C-RES,U 220K-1/16W J YZSTF CDC-MP33R
X MICON R 0907 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X MICON R 0908 88-108-152-080 0E C-RES,U 1 5K-1/16W J YZSTF CDC-MP33R
X MICON R 0909 88-108-473-080 0E C-RES,U 47K-1/16W J YZSTF CDC-MP33R
X MICON R 0910 88-108-104-080 0E C-RES,U 100K-1/16W J YZSTF CDC-MP33R
X MICON R 0911 88-108-222-080 0E C-RES,U 2 2K-1/16W J YZSTF CDC-MP33R
X MICON R 0912 88-108-222-080 0E C-RES,U 2 2K-1/16W J YZSTF CDC-MP33R
X MICON R 0913 88-108-104-080 0E C-RES,U 100K-1/16W J YZSTF CDC-MP33R
X MICON R 0914 88-108-223-080 0E C-RES,U 22K-1/16W J YZSTF CDC-MP33R
X MICON R 0915 88-108-223-080 0E C-RES,U 22K-1/16W J YZSTF CDC-MP33R
X MICON R 0916 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X MICON R 0917 88-108-222-080 0E C-RES,U 2 2K-1/16W J YZSTF CDC-MP33R
X MICON R 0918 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X MICON R 0919 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X MICON R 0920 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X MICON R 0921 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X MICON R 0922 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X MICON R 0923 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X MICON R 0924 88-108-224-080 0E C-RES,U 220K-1/16W J YZSTF CDC-MP33R
X MICON R 0929 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X MICON R 0931 88-108-104-080 0E C-RES,U 100K-1/16W J YZSTF CDC-MP33R
X MICON R 0932 88-108-104-080 0E C-RES,U 100K-1/16W J YZSTF CDC-MP33R
X MICON R 0933 88-108-104-080 0E C-RES,U 100K-1/16W J YZSTF CDC-MP33R
X MICON R 0934 88-108-223-080 0E C-RES,U 22K-1/16W J YZSTF CDC-MP33R
X MICON R 0935 88-108-104-080 0E C-RES,U 100K-1/16W J YZSTF CDC-MP33R
O MICON X 0901 87-A70-175-010 1B VIB,XTAL 4 5MHZ AT-49 YZSTF CDC-MP33R
O OTHERS 85-ZL3-203-010 0E MAGNET,ACU YZSTF CDC-MP33R
O OTHERS 8B-KC1-201-010 -- COVER, BT RDS YZSTF CDC-MP33R
O OTHERS 8B-KC1-213-010 0E CHAS,SIDE L-BC YZSTF CDC-MP33R
O OTHERS 8B-KC1-214-010 0E CHAS,SIDE R-BC YZSTF CDC-MP33R
O OTHERS 8B-KC7-201-010 -- PLATE,LENS BOTTOM YZSTF CDC-MP33R
O OTHERS 8B-KC7-204-010 -- CASE,LCD YZSTF CDC-MP33R
X OTHERS 8B-KC7-205-010 -- PLATE,PANEL-SW YZSTF CDC-MP33R
X OTHERS 8B-KC7-206-010 -- SHAFT,PANEL-SW YZSTF CDC-MP33R
O OTHERS 8B-KC7-207-010 1A PLATE,PANEL A'SSY YZSTF CDC-MP33R
O OTHERS 8B-KC7-208-010 -- COVER, DUST YZSTF CDC-MP33R
O OTHERS 8B-KC7-215-010 0E SHAFT,FLAP L/R YZSTF CDC-MP33R
X OTHERS 8B-KC7-230-010 -- SH,FLEX YZSTF CDC-MP33R
X OTHERS 8B-KC7-231-010 -- SH,JACK PWB YZSTF CDC-MP33R
X OTHERS 8B-KC7-232-010 -- SH,REMOTE YZSTF CDC-MP33R
X OTHERS 8B-KC7-240-110 -- PANEL,HT-SINK-Z YZSTF CDC-MP33R
X OTHERS 8B-KC7-253-010 -- SH,BER YZSTF CDC-MP33R
O OTHERS 8B-KC7-611-010 1B PWB,FLEX DISP YZSTF CDC-MP33R
O OTHERS 8B-KC7-612-010 1A PWB,FLEX KEY YZSTF CDC-MP33R
X OTHERS 8B-KCG-223-010 0E TUBE,ISO-WIRE -BC YZSTF CDC-MP33R
O OTHERS 8Z-KC1-256-010 1B COVER, BOTTOM RDS YZSTF CDC-MP33R
O OTHERS * 8A-KC7-224-010 0E HLDR,P-IC -AC YZSTF CDC-MP33R
O OTHERS * 8A-KC7-225-010 0E HLDR,CD-AC YZSTF CDC-MP33R
O OTHERS * 8B-KC1-602-010 0E F-CABLE,4P (AUX-W/S) YZSTF CDC-MP33R
O OTHERS * 8B-KC6-201-010 0E HLDR,STATIC MP3 YZSTF CDC-MP33R
X OTHERS * 8B-KC6-202-010 -- SH,HLDR STATIC YZSTF CDC-MP33R
O OTHERS * 8B-KC7-202-010 -- LENS,LCD YZSTF CDC-MP33R
X OTHERS * 8B-KC7-203-010 -- SH,LCD YZSTF CDC-MP33R
O OTHERS * 8B-KC7-209-010 0E HLDR,SP-L YZSTF CDC-MP33R
7
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
O OTHERS * 8B-KC7-210-010 0E HLDR,SP-R YZSTF CDC-MP33R
O OTHERS * 8B-KC7-211-010 0E HLDR,MECHA YZSTF CDC-MP33R
O OTHERS * 8B-KC7-212-010 -- HLDR,TR2-B YZSTF CDC-MP33R
X OTHERS * 8B-KC7-213-010 -- SH,ADH WINDOW YZSTF CDC-MP33R
X OTHERS * 8B-KC7-214-010 -- SH,CABI REAR YZSTF CDC-MP33R
O OTHERS * 8B-KC7-217-010 0E HLDR,MECHA FR YZSTF CDC-MP33R
O OTHERS * 8B-KC7-218-010 0E TERMINAL,PWB YZSTF CDC-MP33R
O OTHERS * 8B-KC7-218-010 0E TERMINAL,PWB YZSTF CDC-MP33R
O OTHERS * 8B-KC7-218-010 0E TERMINAL,PWB YZSTF CDC-MP33R
O OTHERS * 8B-KC7-218-010 0E TERMINAL,PWB YZSTF CDC-MP33R
X OTHERS * 8B-KC7-220-010 -- SH,PANEL YZSTF CDC-MP33R
X OTHERS * 8B-KC7-221-010 -- SH,L-BT 18 YZSTF CDC-MP33R
O OTHERS * 8B-KC7-222-010 0E PLATE,MAGNET YZSTF CDC-MP33R
O OTHERS * 8B-KC7-222-010 0E PLATE,MAGNET YZSTF CDC-MP33R
X OTHERS * 8B-KC7-223-010 -- SH, 6-6-0 1 W/ADH BLK YZSTF CDC-MP33R
X OTHERS * 8B-KC7-224-010 -- SH, 5 5-10-0 7 W/ADH BLK YZSTF CDC-MP33R
O OTHERS * 8B-KC7-246-010 0E HLDR,ISO WIRE B YZSTF CDC-MP33R
X OTHERS * 8Z-KC1-234-110 1B SH,PWB YZSTF CDC-MP33R
O OTHERS C 0407 87-010-494-040 0E CAP,E 1-50 M 5L SRE YZSTF CDC-MP33R
O OTHERS C 0408 87-010-494-040 0E CAP,E 1-50 M 5L SRE YZSTF CDC-MP33R
O OTHERS C 0751 87-012-368-080 0E C-CAP,S 0 1-50 Z F YZSTF CDC-MP33R
O OTHERS C 0752 87-012-368-080 0E C-CAP,S 0 1-50 Z F YZSTF CDC-MP33R
O OTHERS C 0753 87-012-368-080 0E C-CAP,S 0 1-50 Z F YZSTF CDC-MP33R
O OTHERS C 0754 87-010-553-040 0E CAP,E 47-16 M 5L SRE YZSTF CDC-MP33R
O OTHERS C 0914 87-010-831-080 0E C-CAP,U 0 1-16 Z F YZSTF CDC-MP33R
O OTHERS IC 0602 87-A90-951-010 1C RCR UNIT,SBX1971-52 YZSTF CDC-MP33R
S OTHERS IC 0751 87-A20-712-040 1B C-IC,BA6417F YZSTF CDC-MP33R
O OTHERS J 0601 87-A60-925-010 1A JACK,3 6 BLK ST W/SW YZSTF CDC-MP33R
O OTHERS L 0402 87-003-102-080 0E COIL,10UH J LAL02 YZSTF CDC-MP33R
O OTHERS LCD0701 8B-KC7-626-010 2M LCD,BKC-1/7 YZSTF CDC-MP33R
O OTHERS LED0605 87-A41-085-010 1E LED,NSPW315BS WHT YZSTF CDC-MP33R
O OTHERS LED0606 87-A41-085-010 1E LED,NSPW315BS WHT YZSTF CDC-MP33R
O OTHERS LED0618 87-A41-096-010 1D LED,E1L31-3B0A2 BLU YZSTF CDC-MP33R
O OTHERS LED0651 87-A40-228-010 0E LED,SLR-342MG T31 GREEN YZSTF CDC-MP33R
O OTHERS PS 0671 87-A92-061-080 1A C-SNSR,GP1S092 HCPI YZSTF CDC-MP33R
X OTHERS R 0405 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X OTHERS R 0406 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X OTHERS R 0407 88-108-153-080 0E C-RES,U 15K-1/16W J YZSTF CDC-MP33R
X OTHERS R 0408 88-108-153-080 0E C-RES,U 15K-1/16W J YZSTF CDC-MP33R
X OTHERS R 0475 88-108-224-080 0E C-RES,U 220K-1/16W J YZSTF CDC-MP33R
X OTHERS R 0476 88-108-224-080 0E C-RES,U 220K-1/16W J YZSTF CDC-MP33R
X OTHERS R 0671 88-118-331-080 0E C-RES,S 330-1/10W J YZSTF CDC-MP33R
X OTHERS R 0671 88-118-391-080 0E C-RES,S 390-1/10W J YZSTF CDC-MP33R
X OTHERS R 0672 88-108-563-080 0E C-RES,U 56K-1/16W J YZSTF CDC-MP33R
X OTHERS R 0673 88-108-223-080 0E C-RES,U 22K-1/16W J YZSTF CDC-MP33R
X OTHERS R 0674 88-108-473-080 0E C-RES,U 47K-1/16W J YZSTF CDC-MP33R
X OTHERS R 0675 88-108-123-080 0E C-RES,U 12K-1/16W J YZSTF CDC-MP33R
X OTHERS R 0751 88-108-123-080 0E C-RES,U 12K-1/16W J YZSTF CDC-MP33R
X OTHERS R 0752 88-108-153-080 0E C-RES,U 15K-1/16W J YZSTF CDC-MP33R
X OTHERS R 0753 88-108-103-080 0E C-RES,U 10K-1/16W J YZSTF CDC-MP33R
X OTHERS R 0754 88-108-103-080 0E C-RES,U 10K-1/16W J YZSTF CDC-MP33R
X OTHERS R 0755 88-108-104-080 0E C-RES,U 100K-1/16W J YZSTF CDC-MP33R
X OTHERS R 0756 88-108-104-080 0E C-RES,U 100K-1/16W J YZSTF CDC-MP33R
O OTHERS SW 0671 87-A92-039-080 0E C-SW,PUSH ESE22MH24XQ YZSTF CDC-MP33R
O OTHERS(RC UNIT) R8-BZR-191-040 -- BZR-1 RC3YZNF YZSTF CDC-MP33R
X PACKING DU 87-B40-087-010 0E BAG,PV 0 04-250-350 PL YZSTF CDC-MP33R
X PACKING DU 8B-KC5-851-010 -- CTN,PRINTED 3R YZSTF YZSTF CDC-MP33R
X PACKING DU 8B-KC5-852-010 -- CTN,OUTER 3R YZSTF YZSTF CDC-MP33R
X PACKING DU 8B-KC7-851-010 0E CUSHION,LEFT 7 AIS YZSTF CDC-MP33R
X PACKING DU 8B-KC7-852-010 0E CUSHION,RIGHT 7 AIS YZSTF CDC-MP33R
X PLATE 87-B40-154-010 0E LBL,BAR-CODE CU YZSTF CDC-MP33R
X PLATE 87-B40-281-010 0E LBL,BAR-CODE A 35X8 YZSTF CDC-MP33R
X PLATE 8B-KC5-021-010 -- LBL,SPEC MP33R YZ YZSTF CDC-MP33R
X PLATE 8Z-HC4-028-010 0E LBL,CLASS 1 & TRIANGLE-G YZSTF CDC-MP33R
O POWER AMP C 0501 87-012-358-080 0E C-CAP,S 0 47-10 Z F CM/CB YZSTF CDC-MP33R
O POWER AMP C 0502 87-012-358-080 0E C-CAP,S 0 47-10 Z F CM/CB YZSTF CDC-MP33R
O POWER AMP C 0503 87-012-358-080 0E C-CAP,S 0 47-10 Z F CM/CB YZSTF CDC-MP33R
O POWER AMP C 0504 87-012-358-080 0E C-CAP,S 0 47-10 Z F CM/CB YZSTF CDC-MP33R
O POWER AMP C 0505 87-012-270-080 0E C-CAP,U 470P-50 K B YZSTF CDC-MP33R
O POWER AMP C 0506 87-012-270-080 0E C-CAP,U 470P-50 K B YZSTF CDC-MP33R
8
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
O POWER AMP C 0507 87-012-270-080 0E C-CAP,U 470P-50 K B YZSTF CDC-MP33R
O POWER AMP C 0508 87-012-270-080 0E C-CAP,U 470P-50 K B YZSTF CDC-MP33R
O POWER AMP C 0510 87-010-498-040 0E CAP,E 10-16 M 5L SRE YZSTF CDC-MP33R
O POWER AMP C 0515 8A-KC7-623-000 1B CAP,E 2200-16 125 BT YZSTF CDC-MP33R
O POWER AMP C 0516 87-012-368-080 0E C-CAP,S 0 1-50 Z F YZSTF CDC-MP33R
O POWER AMP C 0517 87-012-368-080 0E C-CAP,S 0 1-50 Z F YZSTF CDC-MP33R
O POWER AMP C 0519 87-010-494-040 0E CAP,E 1-50 M 5L SRE YZSTF CDC-MP33R
O POWER AMP C 0522 87-012-368-080 0E C-CAP,S 0 1-50 Z F YZSTF CDC-MP33R
S POWER AMP D 0501 87-001-783-080 0E DIODE,1N4002 YZSTF CDC-MP33R
S POWER AMP D 0502 87-001-783-080 0E DIODE,1N4002 YZSTF CDC-MP33R
S POWER AMP D 0503 87-001-783-080 0E DIODE,1N4002 YZSTF CDC-MP33R
S POWER AMP D 0504 87-001-783-080 0E DIODE,1N4002 YZSTF CDC-MP33R
S POWER AMP D 0505 87-001-783-080 0E DIODE,1N4002 YZSTF CDC-MP33R
S POWER AMP D 0506 87-001-783-080 0E DIODE,1N4002 YZSTF CDC-MP33R
S POWER AMP D 0507 87-001-783-080 0E DIODE,1N4002 YZSTF CDC-MP33R
S POWER AMP D 0508 87-001-783-080 0E DIODE,1N4002 YZSTF CDC-MP33R
S POWER AMP D 0513 87-020-331-040 0E C-DIODE,DAN202K YZSTF CDC-MP33R
S POWER AMP IC 0501 8B-KCF-616-010 2P IC,TA8273H YZSTF CDC-MP33R
X POWER AMP R 0501 88-108-103-080 0E C-RES,U 10K-1/16W J YZSTF CDC-MP33R
X POWER AMP R 0502 88-108-103-080 0E C-RES,U 10K-1/16W J YZSTF CDC-MP33R
X POWER AMP R 0503 88-108-103-080 0E C-RES,U 10K-1/16W J YZSTF CDC-MP33R
X POWER AMP R 0504 88-108-103-080 0E C-RES,U 10K-1/16W J YZSTF CDC-MP33R
X POWER AMP R 0505 88-108-223-080 0E C-RES,U 22K-1/16W J YZSTF CDC-MP33R
X POWER AMP R 0506 88-108-223-080 0E C-RES,U 22K-1/16W J YZSTF CDC-MP33R
X POWER AMP R 0507 88-108-223-080 0E C-RES,U 22K-1/16W J YZSTF CDC-MP33R
X POWER AMP R 0508 88-108-223-080 0E C-RES,U 22K-1/16W J YZSTF CDC-MP33R
X POWER AMP R 0509 88-108-103-080 0E C-RES,U 10K-1/16W J YZSTF CDC-MP33R
O POWER SUPPLY C 0405 87-010-759-080 0E C-CAP,U 0 1-25 Z F YZSTF CDC-MP33R
O POWER SUPPLY C 0406 87-010-759-080 0E C-CAP,U 0 1-25 Z F YZSTF CDC-MP33R
O POWER SUPPLY C 0701 87-012-278-080 0E C-CAP,U 2200P-50 K B YZSTF CDC-MP33R
O POWER SUPPLY C 0704 87-012-368-080 0E C-CAP,S 0 1-50 Z F YZSTF CDC-MP33R
O POWER SUPPLY C 0705 87-012-278-080 0E C-CAP,U 2200P-50 K B YZSTF CDC-MP33R
O POWER SUPPLY C 0706 87-010-553-040 0E CAP,E 47-16 M 5L SRE YZSTF CDC-MP33R
O POWER SUPPLY C 0707 87-010-787-080 0E C-CAP,U 0 022-25 K B YZSTF CDC-MP33R
O POWER SUPPLY C 0708 87-010-553-040 0E CAP,E 47-16 M 5L SRE YZSTF CDC-MP33R
O POWER SUPPLY C 0709 87-010-759-080 0E C-CAP,U 0 1-25 Z F YZSTF CDC-MP33R
O POWER SUPPLY C 0713 87-010-759-080 0E C-CAP,U 0 1-25 Z F YZSTF CDC-MP33R
O POWER SUPPLY C 0714 87-010-787-080 0E C-CAP,U 0 022-25 K B YZSTF CDC-MP33R
O POWER SUPPLY C 0715 87-010-759-080 0E C-CAP,U 0 1-25 Z F YZSTF CDC-MP33R
O POWER SUPPLY C 0716 87-010-759-080 0E C-CAP,U 0 1-25 Z F YZSTF CDC-MP33R
O POWER SUPPLY C 0717 87-010-759-080 0E C-CAP,U 0 1-25 Z F YZSTF CDC-MP33R
O POWER SUPPLY C 0718 87-010-759-080 0E C-CAP,U 0 1-25 Z F YZSTF CDC-MP33R
O POWER SUPPLY C 0719 87-010-759-080 0E C-CAP,U 0 1-25 Z F YZSTF CDC-MP33R
O POWER SUPPLY C 0720 87-010-787-080 0E C-CAP,U 0 022-25 K B YZSTF CDC-MP33R
O POWER SUPPLY C 0723 87-010-759-080 0E C-CAP,U 0 1-25 Z F YZSTF CDC-MP33R
O POWER SUPPLY C 0725 87-010-553-040 0E CAP,E 47-16 M 5L SRE YZSTF CDC-MP33R
S POWER SUPPLY D 0701 87-A40-798-010 0E DIODE,1N5402 (3A/200V) YZSTF CDC-MP33R
S POWER SUPPLY D 0706 87-A40-624-080 0E ZENER,MTZJ10A YZSTF CDC-MP33R
S POWER SUPPLY D 0707 87-A40-509-080 0E ZENER,MTZJ6 8C YZSTF CDC-MP33R
S POWER SUPPLY D 0710 87-A40-624-080 0E ZENER,MTZJ10A YZSTF CDC-MP33R
S POWER SUPPLY D 0711 87-A40-620-080 0E ZENER,MTZJ6 2A YZSTF CDC-MP33R
S POWER SUPPLY D 0712 87-070-136-080 0E ZENER,MTZJ5 1B YZSTF CDC-MP33R
S POWER SUPPLY D 0716 87-A40-620-080 0E ZENER,MTZJ6 2A YZSTF CDC-MP33R
S POWER SUPPLY D 0717 87-020-331-040 0E C-DIODE,DAN202K YZSTF CDC-MP33R
S POWER SUPPLY D 0718 87-001-783-080 0E DIODE,1N4002 YZSTF CDC-MP33R
S POWER SUPPLY F 0701 8Z-KC1-621-010 1B FUSE,15A 32V YZSTF CDC-MP33R
S POWER SUPPLY IC 0701 88-KT1-606-080 1A IC,PST994D YZSTF CDC-MP33R
X POWER SUPPLY JR 0012 88-108-000-080 0E C-JUMPER,U YZSTF CDC-MP33R
O POWER SUPPLY L 0403 87-003-102-080 0E COIL,10UH J LAL02 YZSTF CDC-MP33R
O POWER SUPPLY L 0701 8B-KCF-615-010 1C FLTR,AMORPHOUS -CHOKE YZSTF CDC-MP33R
O POWER SUPPLY L 0703 87-003-050-080 0E COIL,47UH K LAL04 YZSTF CDC-MP33R
S POWER SUPPLY Q 0701 87-A30-290-010 1B TR,KTA1658(Y) YZSTF CDC-MP33R
S POWER SUPPLY Q 0702 86-NFZ-664-040 0E C-TR,DTC143TKA YZSTF CDC-MP33R
S POWER SUPPLY Q 0704 87-A30-291-010 1B TR,KTC4369(Y) YZSTF CDC-MP33R
S POWER SUPPLY Q 0706 87-A30-283-040 0E C-TR,DTA114YKA YZSTF CDC-MP33R
O POWER SUPPLY Q 0708 89-418-580-080 0E TR,2SD1858TV2 YZSTF CDC-MP33R
S POWER SUPPLY Q 0709 87-A30-291-010 1B TR,KTC4369(Y) YZSTF CDC-MP33R
S POWER SUPPLY Q 0710 89-324-122-040 0E C-TR,2SC2412KR YZSTF CDC-MP33R
S POWER SUPPLY Q 0711 87-A30-289-040 0E C-TR,2SA1037AK(R) YZSTF CDC-MP33R
S POWER SUPPLY Q 0712 86-NFZ-664-040 0E C-TR,DTC143TKA YZSTF CDC-MP33R
9
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
S POWER SUPPLY Q 0713 89-423-952-010 1A TR,2SD2395E YZSTF CDC-MP33R
S POWER SUPPLY Q 0715 87-A30-287-040 0E C-TR,DTC114TKA YZSTF CDC-MP33R
X POWER SUPPLY R 0701 88-108-103-080 0E C-RES,U 10K-1/16W J YZSTF CDC-MP33R
X POWER SUPPLY R 0702 88-148-681-080 0E C-RES, 680-1/2W J YZSTF CDC-MP33R
X POWER SUPPLY R 0703 88-118-391-080 0E C-RES,S 390-1/10W J YZSTF CDC-MP33R
X POWER SUPPLY R 0706 88-118-391-080 0E C-RES,S 390-1/10W J YZSTF CDC-MP33R
X POWER SUPPLY R 0707 88-108-680-080 0E C-RES,U 68-1/16W J YZSTF CDC-MP33R
X POWER SUPPLY R 0708 88-108-682-080 0E C-RES,U 6 8K-1/16W J YZSTF CDC-MP33R
X POWER SUPPLY R 0709 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X POWER SUPPLY R 0710 88-118-471-080 0E C-RES,S 470-1/10W J YZSTF CDC-MP33R
X POWER SUPPLY R 0711 88-108-273-080 0E C-RES,U 27K-1/16W J YZSTF CDC-MP33R
X POWER SUPPLY R 0712 88-108-103-080 0E C-RES,U 10K-1/16W J YZSTF CDC-MP33R
X POWER SUPPLY R 0713 88-108-123-080 0E C-RES,U 12K-1/16W J YZSTF CDC-MP33R
X POWER SUPPLY R 0714 88-108-273-080 0E C-RES,U 27K-1/16W J YZSTF CDC-MP33R
X POWER SUPPLY R 0715 88-108-473-080 0E C-RES,U 47K-1/16W J YZSTF CDC-MP33R
X POWER SUPPLY R 0716 88-108-473-080 0E C-RES,U 47K-1/16W J YZSTF CDC-MP33R
X POWER SUPPLY R 0717 88-108-473-080 0E C-RES,U 47K-1/16W J YZSTF CDC-MP33R
X POWER SUPPLY R 0720 88-148-229-080 0E C-RES, 2 2-1/2W J YZSTF CDC-MP33R
X POWER SUPPLY R 0725 88-108-103-080 0E C-RES,U 10K-1/16W J YZSTF CDC-MP33R
X PRINTED DU 87-056-168-010 0E SH,CAUTION INF-WARR(EC) YZSTF CDC-MP33R
X PRINTED DU 87-B40-085-010 0E BAG,PV 0 04-200-350 PL YZSTF CDC-MP33R
X PRINTED DU 87-B50-079-010 0E LIST,FACILITY(B)-0007 YZSTF CDC-MP33R
O PRINTED DU 8B-KC5-901-010 -- IB,YZ(9L) MP33R YZSTF CDC-MP33R
O PRINTED DU 8B-KCF-906-110 -- IB,INST,YZ,YV (9L,R)-I YZSTF CDC-MP33R
X PRINTED DU 8B-KCF-907-010 0E SH,CD-R/RW YZ,YV (9L,R)-I YZSTF CDC-MP33R
X PRINTED DU 8B-KCF-908-010 0E SH,RC YZ,YV (9L,R)-I YZSTF CDC-MP33R
X PRINTED DU 8B-KCF-909-010 0E SH,DEMO (14L)-I YZSTF CDC-MP33R
X PRINTED DU 8B-KCF-914-010 0E SH,MFP (14L)-I YZSTF CDC-MP33R
X PWB 8B-KC7-601-010 2M PWB,COMB MAIN (BKC-1/7) YZSTF CDC-MP33R
X PWB 8B-KC7-602-010 -- PWB,MAIN YZSTF CDC-MP33R
X PWB 8B-KC7-603-010 -- PWB,LED YZSTF CDC-MP33R
X PWB 8B-KC7-614-010 -- PWB,LED R YZSTF CDC-MP33R
X PWB * 8B-KC7-606-010 1E PWB,COMB 3M FRONT (BKC-1/7) YZSTF CDC-MP33R
X PWB * 8B-KC7-607-010 -- PWB,DISP YZSTF CDC-MP33R
X PWB * 8B-KC7-608-010 -- PWB,KEY YZSTF CDC-MP33R
X PWB * 8B-KC7-609-010 -- PWB,AUX YZSTF CDC-MP33R
X PWB * 8B-KC7-610-010 -- PWB,SENS YZSTF CDC-MP33R
X PWB * 8B-KC7-613-010 -- PWB,LED L YZSTF CDC-MP33R
O RDS C 0151 87-012-336-080 0E C-CAP,U 330P-50 J SL YZSTF CDC-MP33R
O RDS C 0152 87-010-495-040 0E CAP,E 2 2-50 M 5L SRE YZSTF CDC-MP33R
O RDS C 0153 87-012-271-080 0E C-CAP,U 560P-50 K B YZSTF CDC-MP33R
O RDS C 0154 87-010-787-010 0E C-CAP,U 0 022-25 K B YZSTF CDC-MP33R
O RDS C 0155 87-012-182-080 0E C-CAP,U 27P-50 J CH YZSTF CDC-MP33R
O RDS C 0156 87-012-183-080 0E C-CAP,U 30P-50 J CH YZSTF CDC-MP33R
O RDS C 0157 87-010-831-080 0E C-CAP,U 0 1-16 Z F YZSTF CDC-MP33R
O RDS C 0158 87-010-553-040 0E CAP,E 47-16 M 5L SRE YZSTF CDC-MP33R
S RDS D 0151 87-070-136-080 0E ZENER,MTZJ5 1B YZSTF CDC-MP33R
S RDS IC 0151 88-KT1-607-080 1H C-IC,SAA6579T YZSTF CDC-MP33R
X RDS R 0151 88-108-331-080 0E C-RES,U 330-1/16W J YZSTF CDC-MP33R
X RDS R 0152 88-108-222-080 0E C-RES,U 2 2K-1/16W J YZSTF CDC-MP33R
O RDS X 0151 87-A70-091-010 1B VIB,XTAL 4 332MHZ CSA-309 YZSTF CDC-MP33R
O SCREW 87-251-070-410 0E U+2 6-3 YZSTF CDC-MP33R
O SCREW 87-251-073-410 0E U+2 6-6 YZSTF CDC-MP33R
O SCREW 87-432-903-010 0E WTE,2 6 YZSTF CDC-MP33R
O SCREW 8Z-KC1-251-010 0E S-SCREW,TH2 6-4 0-0 8 YZSTF CDC-MP33R
O SCREW * 87-251-096-410 0E U+3-10 YZSTF CDC-MP33R
O SCREW * 87-251-096-410 0E U+3-10 YZSTF CDC-MP33R
O SCREW * 87-B10-216-010 0E U+2 6-4 0 ZINC BLK (BH M2 6) YZSTF CDC-MP33R
O SCREW * 87-B10-216-010 0E U+2 6-4 0 ZINC BLK (BH M2 6) YZSTF CDC-MP33R
O SCREW * 87-B10-216-010 0E U+2 6-4 0 ZINC BLK (BH M2 6) YZSTF CDC-MP33R
O SCREW * 87-B10-216-010 0E U+2 6-4 0 ZINC BLK (BH M2 6) YZSTF CDC-MP33R
O SCREW * 87-B10-216-010 0E U+2 6-4 0 ZINC BLK (BH M2 6) YZSTF CDC-MP33R
O SCREW * 87-B10-216-010 0E U+2 6-4 0 ZINC BLK (BH M2 6) YZSTF CDC-MP33R
O SCREW * 87-B10-259-010 0E UT2+3 0-10 0 W/O SLOT (BH TAP) YZSTF CDC-MP33R
O SCREW * 87-B10-335-010 0E VTT+1 7-4 W/O YZSTF CDC-MP33R
O SCREW * 87-B10-335-010 0E VTT+1 7-4 W/O YZSTF CDC-MP33R
O SCREW * 87-B10-336-010 0E VTT+2 6-6 W/O YZSTF CDC-MP33R
O SCREW * 87-B10-336-010 0E VTT+2 6-6 W/O YZSTF CDC-MP33R
O SCREW * 87-B10-336-010 0E VTT+2 6-6 W/O YZSTF CDC-MP33R
O SCREW * 87-B10-336-010 0E VTT+2 6-6 W/O YZSTF CDC-MP33R
10
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
O SCREW * 8Z-KC1-253-010 0E S-SCREW,PT 2*8 BH+ BLK YZSTF CDC-MP33R
O SCREW * 8Z-KC1-253-010 0E S-SCREW,PT 2*8 BH+ BLK YZSTF CDC-MP33R
O SCREW * 8Z-KC1-253-010 0E S-SCREW,PT 2*8 BH+ BLK YZSTF CDC-MP33R
O SCREW * 8Z-KC1-253-010 0E S-SCREW,PT 2*8 BH+ BLK YZSTF CDC-MP33R
O SCREW * 8Z-KC1-254-010 0E S-SCREW,PT 2*5 BH+ BLK YZSTF CDC-MP33R
O SCREW * 8Z-KC1-254-010 0E S-SCREW,PT 2*5 BH+ BLK YZSTF CDC-MP33R
X TUNER 8Z-KC1-614-010 0E WIRE,ANT YZSTF CDC-MP33R
O TUNER C 0101 87-012-274-080 0E C-CAP,U 1000P-50 K B YZSTF CDC-MP33R
O TUNER C 0102 87-012-286-080 0E C-CAP,U 0 01-25 K B YZSTF CDC-MP33R
O TUNER C 0103 87-012-282-080 0E C-CAP,U 4700P-50 K B YZSTF CDC-MP33R
O TUNER C 0104 87-010-498-040 0E CAP,E 10-16 M 5L SRE YZSTF CDC-MP33R
O TUNER C 0105 87-010-787-080 0E C-CAP,U 0 022-25 K B YZSTF CDC-MP33R
O TUNER C 0106 87-010-787-080 0E C-CAP,U 0 022-25 K B YZSTF CDC-MP33R
O TUNER C 0107 87-012-274-080 0E C-CAP,U 1000P-50 K B YZSTF CDC-MP33R
O TUNER C 0108 87-010-787-080 0E C-CAP,U 0 022-25 K B YZSTF CDC-MP33R
O TUNER C 0109 87-010-831-080 0E C-CAP,U 0 1-16 Z F YZSTF CDC-MP33R
O TUNER C 0110 87-012-281-080 0E C-CAP,U 3900P-50 K B GRM YZSTF CDC-MP33R
O TUNER C 0111 87-012-286-080 0E C-CAP,U 0 01-25 K B YZSTF CDC-MP33R
O TUNER C 0112 87-010-831-080 0E C-CAP,U 0 1-16 Z F YZSTF CDC-MP33R
O TUNER C 0114 87-010-831-080 0E C-CAP,U 0 1-16 Z F YZSTF CDC-MP33R
O TUNER C 0115 87-010-831-080 0E C-CAP,U 0 1-16 Z F YZSTF CDC-MP33R
O TUNER C 0116 87-010-495-040 0E CAP,E 2 2-50 M 5L SRE YZSTF CDC-MP33R
O TUNER C 0117 87-012-286-080 0E C-CAP,U 0 01-25 K B YZSTF CDC-MP33R
O TUNER C 0118 87-012-278-080 0E C-CAP,U 2200P-50 K B YZSTF CDC-MP33R
O TUNER C 0119 87-010-490-040 0E CAP,E 0 1-50 M 5L MA YZSTF CDC-MP33R
O TUNER C 0120 87-012-282-080 0E C-CAP,U 4700P-50 K B YZSTF CDC-MP33R
O TUNER C 0121 87-012-278-080 0E C-CAP,U 2200P-50 K B YZSTF CDC-MP33R
O TUNER C 0122 87-012-274-080 0E C-CAP,U 1000P-50 K B YZSTF CDC-MP33R
O TUNER C 0123 87-012-286-080 0E C-CAP,U 0 01-25 K B YZSTF CDC-MP33R
O TUNER C 0125 87-010-786-080 0E C-CAP,U 0 018-25 K B GRM YZSTF CDC-MP33R
O TUNER C 0126 87-010-786-080 0E C-CAP,U 0 018-25 K B GRM YZSTF CDC-MP33R
O TUNER C 0127 87-012-358-080 0E C-CAP,S 0 47-10 Z F CM/CB YZSTF CDC-MP33R
O TUNER C 0128 87-012-358-080 0E C-CAP,S 0 47-10 Z F CM/CB YZSTF CDC-MP33R
S TUNER D 0101 87-A40-250-040 0E C-DIODE,DAN217 YZSTF CDC-MP33R
X TUNER JR 0001 88-108-000-080 0E C-JUMPER,U YZSTF CDC-MP33R
O TUNER L 0101 87-003-143-080 0E COIL,4 7UH K LAL02 YZSTF CDC-MP33R
O TUNER L 0102 8Z-KT1-619-010 1A COIL,68MH K7-D YZSTF CDC-MP33R
S TUNER Q 0101 87-A30-287-040 0E C-TR,DTC114TKA YZSTF CDC-MP33R
S TUNER Q 0102 87-A30-289-040 0E C-TR,2SA1037AK(R) YZSTF CDC-MP33R
S TUNER Q 0103 89-324-122-040 0E C-TR,2SC2412KR YZSTF CDC-MP33R
S TUNER Q 0104 87-A30-287-040 0E C-TR,DTC114TKA YZSTF CDC-MP33R
S TUNER Q 0105 89-324-122-040 0E C-TR,2SC2412KR YZSTF CDC-MP33R
S TUNER Q 0106 89-324-122-040 0E C-TR,2SC2412KR YZSTF CDC-MP33R
S TUNER Q 0107 89-324-122-040 0E C-TR,2SC2412KR YZSTF CDC-MP33R
S TUNER Q 0108 89-324-122-040 0E C-TR,2SC2412KR YZSTF CDC-MP33R
S TUNER Q 0109 87-A30-287-040 0E C-TR,DTC114TKA YZSTF CDC-MP33R
X TUNER R 0101 88-108-105-080 0E C-RES,U 1M-1/16W J YZSTF CDC-MP33R
X TUNER R 0102 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X TUNER R 0103 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X TUNER R 0104 88-108-103-080 0E C-RES,U 10K-1/16W J YZSTF CDC-MP33R
X TUNER R 0105 88-108-222-080 0E C-RES,U 2 2K-1/16W J YZSTF CDC-MP33R
X TUNER R 0106 88-108-151-080 0E C-RES,U 150-1/16W J YZSTF CDC-MP33R
X TUNER R 0107 88-108-223-080 0E C-RES,U 22K-1/16W J YZSTF CDC-MP33R
X TUNER R 0108 88-108-821-080 0E C-RES,U 820-1/16W J YZSTF CDC-MP33R
X TUNER R 0109 88-108-103-080 0E C-RES,U 10K-1/16W J YZSTF CDC-MP33R
X TUNER R 0110 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X TUNER R 0111 88-108-333-080 0E C-RES,U 33K-1/16W J YZSTF CDC-MP33R
X TUNER R 0112 88-108-473-080 0E C-RES,U 47K-1/16W J YZSTF CDC-MP33R
X TUNER R 0113 88-108-104-080 0E C-RES,U 100K-1/16W J YZSTF CDC-MP33R
X TUNER R 0114 88-118-100-080 0E C-RES,S 10-1/10W J YZSTF CDC-MP33R
X TUNER R 0117 88-108-472-080 0E C-RES,U 4 7K-1/16W J YZSTF CDC-MP33R
X TUNER R 0118 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X TUNER R 0119 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X TUNER R 0120 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X TUNER R 0121 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R
X TUNER R 0122 88-108-473-080 0E C-RES,U 47K-1/16W J YZSTF CDC-MP33R
X TUNER R 0123 88-108-682-080 0E C-RES,U 6 8K-1/16W J YZSTF CDC-MP33R
X TUNER R 0124 88-108-682-080 0E C-RES,U 6 8K-1/16W J YZSTF CDC-MP33R
X TUNER R 0125 88-108-473-080 0E C-RES,U 47K-1/16W J YZSTF CDC-MP33R
O TUNER SFR0101 87-024-437-080 0E SFR,100K H RH063MC YZSTF CDC-MP33R
11
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
O TUNER TU 0101 8B-KC3-620-010 2Y TU UNIT, FAE347-E21 YZSTF CDC-MP33R
– 12 –
SCHEMATIC DIAGRAM – 1 (MAIN)
– 13 –
SCHEMATIC DIAGRAM – 2 (FRONT)
Other Aiwa Car Receiver manuals
