COMPACT DISC STEREO
CASSETTE RECORDER
CSD-ED79
S/M Code No. 09-994-329-8R1
EZ(S)
SERVICE MANUAL
REVISION
This Service Manual is the “Revision Publishing” and replaces “Simple Manual”
CSD-ED79(EZ<S>)(S/M Code No.09-994-329-8T1) .
BASIC TAPE MECHANISM : TN21ZVC-1816
BASIC CD MECHANISM : KSM-213CDM
DATA
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

2
SPECIFICATIONS
<Tuner section>
(FM)
Tuning range 87.5 MHz to 108.0 MHz
Antenna Rod antenna
(MW)
Tuning range 522 kHz to 1611 kHz (9 kHz step)
530 kHz to 1710 kHz (10 kHz step)
Antenna Ferrite bar antenna
(LW)
Tuning range 153 kHz to 288 kHz
Antenna Ferrite bar antenna
<Cassette deck section>
Track format 4 track, 2 channels stereo
Frequency response Normal tape: 50 Hz - 12500 Hz
Recording system AC bias
Erasing system Magnet erase
Heads Recording/Playback head x 1
Erasure head x 1
<Compact disc player section>
Disk Compact disc
Scanning method Non-contact optical scanner
(Semicondactor laser)
<General>
Speakers 100 mm cone type (2)
36 mm cone type (2)
Power output 5.0 W + 5.0 W
(DIN MUSIC POWER)
4.5 W + 4.5 W
(EIAJ 3.2 ohms, T.H.D. 10 %)
3.3 W + 3.3 W
(DIN 1 % Rated Power)
Output Headphones (stereo minijack)
Power requirements DC 12 V using eight size C (R14)
batteries
AC 230 V
50 Hz
Power consumption 27 W
Dimensions of main unit (W x H x D)
507 x 206 x 299.5 mm
Weight of main unit 4.7 kg
• Design and specifications are subject to change without notice.
REF. NO PART NO. KANRI DESCRIPTION
NO.
ACCESSORIES LIST
1 8Z-CH4-908-010 IB,EZ(9L)B
!2 87-A80-036-010 AC CORD SET ASSY,E W/FLTR VOL
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

3
PROTECTION OF EYES FROM LASER BEAM DURING SERVICING
VAROITUS!
Laiteen Käyttäminen muulla kuin tässä käyttöohjeessa mainit-
ulla tavalla saattaa altistaa käyt-täjän turvallisuusluokan 1 ylit-
tävälle näkymättömälle lasersäteilylle.
VARNING!
Om apparaten används på annat sätt än vad som specificeras i
denna bruksanvising, kan användaren utsättas för osynling
laserstrålning, som överskrider gränsen för laserklass 1.
Caution: Invisible laser radiation when
open and interlocks defeated avoid expo-
sure to beam.
Advarsel:Usynling laserståling ved åbning,
når sikkerhedsafbrydere er ude af funktion.
Undgå udsættelse for stråling.
CAUTION
Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous
radiation exposure.
ATTENTION
L'utilisation de commandes, réglages ou procédures autres que
ceux spécifiés peut entraîner une dangereuse exposition aux
radiations.
ADVARSEL!
Usynlig laserståling ved åbning, når sikkerhedsafbrydereer ude
af funktion. Undgå udsættelse for stråling.
This Compact Disc player is classified as a CLASS 1 LASER
product.
The CLASS 1 LASER PRODUCT label is located on the rear
exterior.
This set employs laser. Therefore, be sure to follow carefully the
instructions below when servicing.
WARNING!
WHEN SERVICING, DO NOT APPROACH THE LASER EXIT
WITH THE EYE TOO CLOSELY. IN CASE IT IS NECESSARY TO
CONFIRM LASER BEAM EMISSION. BE SURE TO OBSERVE
FROM A DISTANCE OF MORE THAN 30cm FROM THE
SURFACE OF THE OBJECTIVE LENS ON THE OPTICAL
PICK-UP BLOCK.
CLASS 1
KLASSE 1
LUOKAN 1
KLASS 1
LASER PRODUCT
LASER PRODUKT
LASER LAITE
LASER APPARAT
CD PICK-UP ASSY P.C.B.
Precaution to replace Optical block
1) After the connection, remove solder shown in
the right figure.
Body or clothes electrostatic potential could ruin
laser diode in the optical block. Be sure ground
body and workbench, and use care the clothes
do not touch the diode.
Solder
(KSS – 213B)
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

4
REF. NO PART NO. KANRI DESCRIPTION
NO.
REF. NO PART NO. KANRI DESCRIPTION
NO.
ELECTRICAL MAIN PARTS LIST
IC
87-A20-459-010 C-IC,LC78622ED
8Z-CH4-636-010 IC,LC867132V-5K36
87-A21-184-010 IC,TA2104AN
87-A21-185-040 C-IC,LC72121M
87-A20-946-040 C-IC,MM1434XF
87-A20-591-010 IC,BA5417
87-A21-111-040 C-IC,M62495FP
87-070-416-010 IC,NJU7201 L55
87-A20-446-010 C-IC,LA9241ML
87-A21-093-010 IC,LA6541D
87-A21-145-040 C-IC,BA4560F-E2
TRANSISTOR
87-026-291-010 TR,DTC124XS
89-213-702-010 TR,2SB1370E(1.8W)
89-319-233-080 TR,2SC1923 (0.1W)
87-A30-092-080 FET,2SK439E/F
87-026-447-080 TR,2SC1740S R
89-320-011-080 TR,2SC2001K(15W)
87-026-214-080 TR,DTA114YS (0.3W)
87-026-215-010 TR,DTC114YS
89-112-965-010 TR,2SA1296GR
87-026-463-010 TR,2SA933S,RS
87-026-462-010 TR,2SC1740SRS
89-113-184-080 TR,2SA1318TU
89-112-965-080 TR,2SA1296GR(0.75W)
87-026-464-010 TR,DTC114TS
87-026-239-010 TR,DTC114TK
89-318-154-010 TR,2SC1815Y
89-318-155-010 TR,2SC1815(GR)
87-026-496-080 FET,2SJ103GR
88-NF9-637-010 TR,2SA1318T/U
89-110-150-010 TR,2SA1015
DIODE
87-070-345-080 DIODE,IN4148
87-017-072-080 ZENER,HZS3B1
87-027-607-080 ZENER,HZ7B3L
87-A40-466-080 ZENER,MTZJ2.7A
87-020-465-080 DIODE,1SS133 (110MA)
87-017-162-080 ZENER,HZS7C3L
87-017-148-080 ZENER,HZS6A1L
87-017-139-010 ZENER,HZS15-2
87-070-136-080 ZENER,MTZJ5.1B
87-A40-465-010 DIODE,FR202
MAIN C.B
C1 87-010-314-080 C-CAP,S 22P-50V
C2 87-010-316-080 C-CAP,S 33P-50 CH
C3 87-010-314-080 C-CAP,S 22P-50V
C5 87-A11-067-080 C-CAP,S 1-10 K B
C6 87-010-312-080 C-CAP,S 15P CH
C7 87-014-409-080 CAP,PP 470P-100J
C8 87-012-349-080 C-CAP,S 1000P-50 CH
C10 87-010-197-080 CAP, CHIP 0.01 DM
C11 87-010-197-080 CAP, CHIP 0.01 DM
C12 87-010-197-080 CAP, CHIP 0.01 DM
C13 87-010-150-080 C-CAP,S 6P-50 CH
C14 87-012-157-080 C-CAP 330P-50CH
C15 87-012-349-080 C-CAP,S 1000P-50 CH
C16 87-010-380-080 CAP, ELECT 47-16V
C17 87-010-198-080 CAP, CHIP 0.022
C18 87-015-819-080 CAPACITOR,0.01
C19 87-010-112-080 CAP, ELECT 100-16V
C20 87-010-404-080 CAP, ELECT 4.7-50V
C21 87-010-197-080 CAP, CHIP 0.01 DM
C22 87-010-197-080 CAP, CHIP 0.01 DM
C24 87-012-157-080 C-CAP 330P-50CH
C25 87-016-460-080 C-CAP,S 0.22-16 B
C26 87-010-322-080 C-CAP,S 100P-50
C27 87-A11-067-080 C-CAP,S 1-10 K B
C28 87-016-669-080 C-CAP,S 0.1-25 K B
C29 87-016-669-080 C-CAP,S 0.1-25 K B
C30 87-010-220-080 C-CAP,S 0.018-25 KB
C31 87-010-220-080 C-CAP,S 0.018-25 KB
C33 87-010-401-080 CAP, ELECT 1-50V
C34 87-010-401-080 CAP, ELECT 1-50V
C35 87-015-819-080 CAPACITOR,0.01
C36 87-010-112-080 CAP, ELECT 100-16V
C37 87-010-197-080 CAP, CHIP 0.01 DM
C38 87-010-380-080 CAP, ELECT 47-16V
C39 87-010-404-080 CAP, ELECT 4.7-50V
C40 87-010-197-080 CAP, CHIP 0.01 DM
C41 87-012-349-080 C-CAP,S 1000P-50 CH
C42 87-012-349-080 C-CAP,S 1000P-50 CH
C43 87-012-349-080 C-CAP,S 1000P-50 CH
C44 87-010-311-080 C-CAP,S 12P-50 J CH GRM
C45 87-010-312-080 C-CAP,S 15P-50 CH
C46 87-010-197-080 CAP, CHIP 0.01 DM
C47 87-010-197-080 CAP, CHIP 0.01 DM
C48 87-010-197-080 CAP, CHIP 0.01 DM
C49 87-012-156-080 C-CAP,S 220P-50 CH
C50 87-010-197-080 CAP, CHIP 0.01 DM
C51 87-010-316-080 C-CAP,S 33P-50 CH
C52 87-010-197-080 CAP, CHIP 0.01 DM
C53 87-010-197-080 CAP, CHIP 0.01 DM
C54 87-014-055-080 CAP,PP 820P-100 J
C55 87-010-197-080 CAP, CHIP 0.01 DM
C71 87-010-197-080 CAP, CHIP 0.01 DM
C72 87-016-669-080 C-CAP,S 0.1-25 K B
C73 87-016-669-080 C-CAP,S 0.1-25 K B
C78 87-016-669-080 C-CAP,S 0.1-25 K B
C207 87-010-408-080 CAP, ELECT 47-50V
C208 87-010-402-080 CAP, ELECT 2.2-50V
C209 87-010-190-080 S CHIP F 0.01
C210 87-010-190-080 S CHIP F 0.01
C211 87-010-401-080 CAP, ELECT 1-50V
C212 87-010-401-080 CAP, ELECT 1-50V
C215 87-010-425-080 C-CAP,0.22-25 F
C216 87-010-425-080 C-CAP,0.22-25 F
C217 87-010-400-080 CAP, ELECT 0.47-50V
C218 87-010-400-080 CAP, ELECT 0.47-50V
C220 87-010-405-080 CAP, ELECT 10-50V
C222 87-010-190-080 S CHIP F 0.01
C223 87-010-190-080 S CHIP F 0.01
C226 87-010-190-080 S CHIP F 0.01
C228 87-010-401-080 CAP, ELECT 1-50V
C229 87-010-401-080 CAP, ELECT 1-50V
C231 87-010-213-080 C-CAP,S 0.015-50 B
C232 87-010-213-080 C-CAP,S 0.015-50 B
C233 87-010-546-080 CAP, ELECT 0.33-50V
C234 87-010-546-080 CAP, ELECT 0.33-50V
C235 87-010-544-080 CAP, ELECT 0.1-50V
C236 87-010-544-080 CAP, ELECT 0.1-50V
C237 87-010-260-080 CAP, ELECT 47-25V
C238 87-010-263-080 CAP, ELECT 100-10V
C241 87-010-405-080 CAP, ELECT 10-50V
C242 87-010-405-080 CAP, ELECT 10-50V
C243 87-010-405-080 CAP, ELECT 10-50V
C244 87-010-405-080 CAP, ELECT 10-50V
C245 87-010-405-080 CAP, ELECT 10-50V
C246 87-010-405-080 CAP, ELECT 10-50V
C247 87-010-404-080 CAP, ELECT 4.7-50V
C248 87-010-404-080 CAP, ELECT 4.7-50V
C261 87-010-402-080 CAP, ELECT 2.2-50V
C262 87-010-402-080 CAP, ELECT 2.2-50V
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

5
REF. NO PART NO. KANRI DESCRIPTION
NO.
REF. NO PART NO. KANRI DESCRIPTION
NO.
C263 87-010-178-080 CHIP CAP 1000P
C264 87-010-178-080 CHIP CAP 1000P
C265 87-010-383-080 CAP, ELECT 33-25V
C266 87-010-383-080 CAP, ELECT 33-25V
C267 87-010-380-080 CAP, ELECT 47-16V
C268 87-010-380-080 CAP, ELECT 47-16V
C271 87-010-236-080 CAP, ELECT 1000-10V
C272 87-010-236-080 CAP, ELECT 1000-10V
C275 87-010-628-080 CAP,E 3.3-16 M 5L BP SRE
C276 87-010-628-080 CAP,E 3.3-16 M 5L BP SRE
C277 87-010-260-080 CAP, ELECT 47-25V
C278 87-010-263-080 CAP, ELECT 100-10V
C279 87-010-112-080 CAP, ELECT 100-16V
C299 87-010-190-080 S CHIP F 0.01
C301 87-010-453-010 CAP, ELECT 4700-25V
C306 87-010-404-080 CAP, ELECT 4.7-50V
C307 87-010-401-080 CAP, ELECT 1-50V
C308 87-010-221-080 CAP, ELECT 470-10V
C309 87-010-263-080 CAP, ELECT 100-10V
C310 87-010-248-080 CAP, ELECT 220-10V
C311 87-010-384-080 CAP, ELECT 100-25V
C312 87-010-385-080 CAP, ELECT 220-25V
C314 87-010-248-080 CAP, ELECT 220-10V
C315 87-010-197-080 CAP, CHIP 0.01 DM
C321 87-010-190-080 S CHIP F 0.01
C322 87-010-263-080 CAP, ELECT 100-10V
C325 87-010-405-080 CAP, ELECT 10-50V
C341 87-010-197-080 CAP, CHIP 0.01 DM
C342 87-010-221-080 CAP, ELECT 470-10V
C343 87-010-401-080 CAP, ELECT 1-50V
C801 87-010-402-080 CAP, ELECT 2.2-50V
C802 87-010-402-080 CAP, ELECT 2.2-50V
C803 87-010-181-080 C-CAP,S 1800P-50 KB
C804 87-010-181-080 C-CAP,S 1800P-50 KB
C805 87-012-158-080 C-CAP,S 390P-50 CH
C806 87-012-158-080 C-CAP,S 390P-50 CH
C809 87-010-379-010 CAP,E 22-10 SM
C810 87-010-379-010 CAP,E 22-10 SM
C811 87-010-404-010 CONDENSER 4.7-50
C812 87-010-404-010 CONDENSER 4.7-50
C815 87-010-374-010 CAP, ELECT 47-10V
C816 87-010-384-080 CAP, ELECT 100-25V
C819 87-010-401-010 CAP, ELECT 1-50V
C820 87-010-401-010 CAP, ELECT 1-50V
C821 87-010-183-080 C-CAP,S 2700P-50 KB
C822 87-010-183-080 C-CAP,S 2700P-50 KB
C823 87-010-213-080 C-CAP,S 0.015-50 B
C824 87-010-213-080 C-CAP,S 0.015-50 B
C825 87-010-405-080 CAP, ELECT 10-50V
C826 87-010-405-080 CAP, ELECT 10-50V
C827 87-010-404-010 CONDENSER 4.7-50
C828 87-010-404-010 CONDENSER 4.7-50
C830 87-010-260-080 CAP, ELECT 47-25V
C831 87-010-198-080 CAP, CHIP 0.022
C832 87-010-198-080 CAP, CHIP 0.022
C833 87-010-179-080 CAP,CHIP S B1200P
C834 87-010-248-080 CAP, ELECT 220-10V
C835 87-012-358-010 C-CAP,S 0.47-16V
C837 87-010-374-010 CAP, ELECT 47-10V
C838 87-010-405-080 CAP, ELECT 10-50V
C841 87-010-182-080 C-CAP,S 2200P-50 KB
C842 87-010-182-080 C-CAP,S 2200P-50 KB
C843 87-010-190-080 S CHIP F 0.01
C844 87-018-128-080 CAP,TC U 560P-50 KB
C845 87-018-128-080 CAP,TC U 560P-50 KB
C846 87-010-194-080 CAP, CHIP 0.047
C849 87-010-177-080 CHIP CAPACITOR 820P
C850 87-010-177-080 CHIP CAPACITOR 820P
C851 87-010-186-080 CAP,CHIP 4700P
C852 87-010-178-080 CHIP CAP 1000P
C853 87-010-190-080 S CHIP F 0.01
CF2 82-785-747-080 CF,MS2 GHY,R
CF3 82-785-747-080 CF,MS2 GHY,R
CF4 87-A91-094-010 FLTR,CDA10.7 MG
CN201 87-099-016-010 CONN,14P 6216V
CN203 87-049-469-010 CONN,4P V
CN204 87-049-469-010 CONN,4P V
CN205 87-A60-109-010 CONN,2P V S2M-2W
CN301 S1-2S3-002-500 CONN,3P
CN801 87-049-469-010 CONN,4P V
CN802 87-049-469-010 CONN,4P V
D3 87-A40-616-070 VARI-CAP,SVC384(S/T)
D4 87-A40-615-070 VARI-CAP,KV1311NT
D5 87-A40-615-070 VARI-CAP,KV1311NT
L2 87-A50-347-010 COIL,FM BPF EX
L3 87-A91-096-010 BAR-ANT,MW/LW FOR 3B(SYN)
L4 87-A50-420-010 COIL,MW OSC(SYN)
L5 87-A50-424-010 COIL,FM RF EX(SYN)
L6 87-A50-427-010 COIL,FM OSC EX(SYN)
L7 87-A91-308-010 FLTR,PCFAZH- 450T (TOK)
L8 87-005-849-080 COIL,10UH(CECS)
L9 87-005-849-080 COIL,10UH(CECS)
L51 87-A50-421-010 COIL,LW OSC(SYN)
L801 87-007-342-010 COIL,OSC 85K BIAS
R840 87-029-124-010 RES,FUSE 2.2-1/4
TC1 87-011-220-080 TRIMMER CAP 20P VTC
TC51 87-011-233-080 TRIMER,50P VCT54
X1 87-A70-061-010 VIB,XTAL 4.500MHZ CSA-309
FRONT C.B
C601 87-010-313-080 CAP, CHIP 18P
C602 87-010-315-080 C-CAP,S 27P-50 CH
C603 87-010-319-080 C-CAP,S 56P-50 J CH
C604 87-010-312-080 C-CAP,S 15P-50V CH
C605 87-010-317-080 C-CAP,S 39P-50 CH
C607 87-A11-067-080 C-CAP,S 1-10 K B
C608 87-A11-067-080 C-CAP,S 1-10 K B
C610 87-010-263-080 CAP, ELECT 100-10
C611 87-010-196-080 CHIP CAPACITOR,0.1-25
C612 87-010-248-080 CAP, ELECT 220-10V
C613 87-010-402-080 CAP, ELECT 2.2-50V
C614 87-010-196-080 CHIP CAPACITOR,0.1-25
C615 87-010-400-080 CAP, ELECT 0.47-50V
C616 87-010-401-080 CAP, ELECT 1-50V
C620 87-A11-067-080 C-CAP,S 1-10 K B
C627 87-010-401-080 CAP,E 1-50
C628 87-010-401-080 CAP,E 1-50
C691 87-010-405-080 CAP, ELECT 10-50V
CN601 87-099-031-010 CONN,14P 6216 H
CN602 87-099-200-010 CONN,7P 6216H
CN603 87-099-199-010 CONN,6P 6216 H
CN604 87-099-200-010 CONN,7P 6216H
CN605 87-099-200-010 CONN,7P 6216H
FC601 8Z-CH4-619-010 FF-CABLE, 14P AF-FR
FC602 8Z-CH4-621-010 FF-CABLE, 7P CD-FR
FC603 8Z-CH4-622-010 FF-CABLE, 6P TU-FR
FC604 8Z-CH4-620-010 FF-CABLE, 7P FR-LED
FC605 8Z-CH4-620-010 FF-CABLE, 7P FR-LED
L601 87-003-102-010 COIL,10UH TROIDAL
LCD601 8Z-CH4-635-010 LCD,HLC7365 ZCH-4
S601 87-A90-696-080 SW,TACT TS2103-03-430
S604 87-A90-696-080 SW,TACT TS2103-03-430
S605 87-A90-696-080 SW,TACT TS2103-03-430
S606 87-A90-696-080 SW,TACT TS2103-03-430
S607 87-A90-696-080 SW,TACT TS2103-03-430
S614 87-A90-696-080 SW,TACT TS2103-03-430
S615 87-A90-696-080 SW,TACT TS2103-03-430
X601 87-030-273-010 VIB,XTAL 32.768K5PPM
X602 87-A70-070-080 VIB,CER 5.76MHZ CRHF
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

6
CD MAIN C.B
C401 87-010-403-080 CAP, ELECT 3.3-50V
C402 87-010-197-080 CAP, CHIP 0.01 DM
C403 87-010-263-080 CAP, ELECT 100-10V
C404 87-010-248-080 CAP, ELECT 220-10V
C405 87-010-197-080 CAP, CHIP 0.01 DM
C406 87-010-374-080 CAP, ELECT 47-10V
C407 87-010-178-080 CHIP CAP 1000P
C409 87-010-248-080 CAP, ELECT 220-10V
C410 87-010-263-080 CAP, ELECT 100-10V
C412 87-010-401-080 CAP, ELECT 1-50V
C413 87-A11-138-080 CAP, CHIP 0.033-50
C414 87-010-405-080 CAP, ELECT 10-50V
C416 87-010-545-080 CAP, ELECT 0.22-50V
C417 87-012-157-080 C-CAP,S 330P-50 CH
C425 87-010-176-080 C-CAP,S 680P-50 SL
C429 87-010-186-080 CAP,CHIP 4700P
C430 87-012-156-080 C-CAP,S 220P-50 CH
C431 87-010-545-080 CAP, ELECT 0.22-50V
C432 87-010-374-080 CAP, ELECT 47-10V
C433 87-010-401-080 CAP, ELECT 1-50V
C434 87-010-184-080 CHIP CAPACITOR 3300P(K)
C435 87-010-197-080 CAP, CHIP 0.01 DM
C436 87-010-374-080 CAP, ELECT 47-10V
C437 87-010-404-080 CAP, ELECT 4.7-50V
C438 87-010-196-080 CHIP CAPACITOR,0.1-25
C440 87-010-145-080 C-CAP,S 1P-50 CH
C442 87-010-312-080 C-CAP,S 15P-50 CH
C445 87-010-196-080 CHIP CAPACITOR,0.1-25
C446 87-010-196-080 CHIP CAPACITOR,0.1-25
C447 87-010-196-080 CHIP CAPACITOR,0.1-25
C448 87-010-315-080 C-CAP,S 27P-50 CH
C450 87-012-140-080 CAP 470P
C451 87-012-156-080 C-CAP,S 220P-50 CH
C455 87-010-263-080 CAP, ELECT 100-10V
C457 87-010-312-080 C-CAP,S 15P-50 CH
C458 87-010-312-080 C-CAP,S 15P-50 CH
C459 87-010-263-080 CAP, ELECT 100-10V
C460 87-010-197-080 CAP, CHIP 0.01 DM
C461 87-010-196-080 CHIP CAPACITOR,0.1-25
C462 87-010-248-080 CAP,E 220-10 SME
C465 87-010-404-080 CAP, ELECT 4.7-50V
C466 87-010-196-080 CHIP CAPACITOR,0.1-25
C467 87-010-263-080 CAP, ELECT 100-10V
C469 87-012-154-080 C-CAP,S 150P-50 CH
C470 87-010-544-080 CAP, ELECT 0.1-50V
C475 87-010-197-080 CAP, CHIP 0.01 DM
C476 87-010-236-080 CAP,E 1000-10 SME
C477 87-010-197-080 CAP, CHIP 0.01 DM
C478 87-010-263-080 CAP, ELECT 100-10V
C479 87-010-197-080 CAP, CHIP 0.01 DM
C480 87-010-221-080 CAP, ELECT 470-10V
C481 87-010-405-080 CAP, ELECT 10-50V
C482 87-010-405-080 CAP, ELECT 10-50V
C483 87-012-156-080 C-CAP,S 220P-50 CH
C484 87-012-156-080 C-CAP,S 220P-50 CH
C489 87-010-196-080 CHIP CAPACITOR,0.1-25
C490 87-010-196-080 CHIP CAPACITOR,0.1-25
C491 87-010-197-080 CAP, CHIP 0.01 DM
C492 87-010-221-080 CAP, ELECT 470-10V
C493 87-010-197-080 CAP, CHIP 0.01 DM
C500 87-010-197-080 CAP, CHIP 0.01 DM
C501 87-010-196-080 CHIP CAPACITOR,0.1-25
C502 87-010-322-080 C-CAP,S 100P-50 CH
C503 87-010-322-080 C-CAP,S 100P-50 CH
C504 87-010-322-080 C-CAP,S 100P-50 CH
C505 87-010-322-080 C-CAP,S 100P-50 CH
C506 87-010-322-080 C-CAP,S 100P-50 CH
C510 87-010-196-080 CHIP CAPACITOR,0.1-25
CN401 87-A60-424-010 CONN,16P V TOC-B
CN402 8Z-CH4-614-010 CONN ASSY,6P CD-ME
CN403 87-099-195-010 CONN,7P 6216 V
FC401 8Z-CH4-618-010 FF-CABLE, 16P CD-RF
L401 87-003-102-080 COIL, 10UH
L404 87-008-372-010 FILTER, EMI BL OIRNI
SFR430 87-024-176-080 SFR,100K H NVZ6TLTA
X401 81-592-641-010 CERAMIC FILTER, 16.93MHZ
LED C.B
CN608 87-099-200-010 CONN,7P 6216H
CN609 87-099-200-010 CONN,7P 6216H
LED601 88-CD6-630-010 LED,934ID RED
LED602 88-CD6-630-010 LED,934ID RED
LED603 88-CD6-630-010 LED,934ID RED
LED604 88-CD6-630-010 LED,934ID RED
LED606 88-CD6-630-010 LED,934ID RED
LED607 88-CD6-630-010 LED,934ID RED
LED608 88-CD6-630-010 LED,934ID RED
LED609 88-CD6-630-010 LED,934ID RED
LED610 88-CD6-631-010 LED,934GD GRN
KEY C.B
S608 87-A90-696-080 SW,TACT TS2103-03-430
S609 87-A90-696-080 SW,TACT TS2103-03-430
S610 87-A90-696-080 SW,TACT TS2103-03-430
S611 87-A90-696-080 SW,TACT TS2103-03-430
S612 87-A90-696-080 SW,TACT TS2103-03-430
S613 87-A90-696-080 SW,TACT TS2103-03-430
HP C.B
J251 87-A60-569-010 JACK,HTJ-035-18
PWR C.B
C901 87-A10-577-080 CAP,CER 0.022-50 Z YF
C902 87-A10-577-080 CAP,CER 0.022-50 Z YF
C903 87-A10-577-080 CAP,CER 0.022-50 Z YF
C904 87-A10-577-080 CAP,CER 0.022-50 Z YF
!F901 87-035-347-010 FUSE,2.5AL 250V T
!FC901 87-033-213-010 CLAMP,FUSE SMK
!FC902 87-033-213-010 CLAMP,FUSE SMK
MOTOR-1 C.B
M2 9X-262-576-910 MOTOR
PIN3 91-564-722-110 CONNECTOR 6P
SW1 91-572-085-120 LEAF SWITCH
REF. NO PART NO. KANRI DESCRIPTION
NO.
REF. NO PART NO. KANRI DESCRIPTION
NO.
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

87
88
A
Resistor Code
Chip Resistor Part Coding
Figure
Value of resistor
Chip resistor
Wattage Type Tolerance
1/16W
1/10W
1/8W
1608
2125
3216
5%
5%
5%
CJ
CJ
CJ
Form
LW t
1.6 0.8 0.45
2 1.25 0.45
3.2 1.6
108
118
128
: A
: A
CHIP RESISTOR PART CODE
0.55
Resistor Code
Dimensions (mm)
Symbol
1/16W 1005 5% CJ
1.0 0.5 0.35 104
Lt
W
2SA1015
2SA1296
2SA1318
2SC1815
2SC1923
2SC2001
2SC2878
2SA933S
2SC1740S
DTA114YS
DTC114TK
DTC114TS
DTC114YS
DTC124XS
2SB1370
2SJ103 2SK439
E C B E C B B C E
S G D G S D
TRANSISTOR ILLUSTRATION
LCD DISPLAY
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

12345678910 11 12 13 14
A
B
C
D
E
F
G
H
I
J
109
WIRING-1
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

1211
SCHEMATIC DIAGRAM-1 (MAIN-1/2 SECTION)
1/4W
1/4W
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

1413
SCHEMATIC DIAGRAM-2 (MAIN 2/2 SECTION)
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
