SERVICE MANUAL
DATA
TP-VS715
S/M Code No. 09-032-366-0T1
YU(S)
CASSETTE RECORDER BASIC TAPE MECHANISM: 7ZM-5 YM2NC
SIMPLE
Replace this Service Manual with “Revision Publishing” when it is issued.
All manuals and user guides at all-guides.com
all-guides.com

-2-
ACCESSORIES PARTS LIST -1/1
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
SPECIFICATIONS -1/1
Track system 2 tracks 1 channel, monaural
Usabel tapes Type I(normal) tapes
Recording speed Approx. 4.8 cm/sec. with the REC SPEED switch set to
NORMAL
Approx. 2.4 cm/sec. with the REC SPEED switch set to
EXT
Frequency response 250 - 8,000 Hz JEITA
Built-in Microphone Electret condenser microphone (monaural)
Maximum output 300 mW (JEITA 8 ohms/DC)
Input jack EXT.MIC jack (monaural mini-jack) (1)
Output jack EARPHONE jack (monaural mini-jack) (1)
Other jack DC 3 V jack
Speaker Diameter 50 mm, 8 ohms
Recording system DC bias
Erasing system DC bias
Power sources DC 3 V using two size AA (R6) dry cell batteries
AC house current using the optional AC power adaptor
Sony AC-E30HG
Battery life
Maximum outside dimensions
84(W) x 113.4(H) x 35.1(D) mm (3 3/8⋅4 1/2⋅1 7/16 in.)
(excluding projecting parts and controls)
Weight Approx. 200 g (7 oz.) (excluding batteries)
Specifications and external appearance are subject to change without notice.
Battery JEITA Recording JEITA 10 mW
Manganese (R6P) batteries Approx. 6 hrs. Approx. 4.5 hrs.
Alkaline (LR6) batteries Approx. 16.5 hrs. Approx. 13.5 hrs.
TP-VS715
YUSC
O AS1001 8C-HT4-901-11 IB,YU(ESF)GH TP-VS715 a
O AS1002 87-PD3-050-01 STRAP,HAND a
All manuals and user guides at all-guides.com

! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-3-
ELECTRICAL PARTS LIST -1/3
TP-VS715
YUSC
LED O IC 0401 87-017-643-08 IC,MM1206XF a
LED X JR 0401 S2-261-250-005 C-RES,0-1/10W a
LED X JR 0402 S2-261-250-005 C-RES,0-1/10W a
LED O LED0401 87-A91-357-04 C-LED,PY1112H-TR-GRN a
LED O LED0402 87-A91-356-04 C-LED,AY1112H-TR-YEL a
LED O LED0403 87-A91-355-04 C-LED,BR1112H-TR-RED a
LED O LED0404 S5-571-100-116 C-LED,SML-110VT(L,K)RED a
LED X R 0401 S2-261-251-815 C-RES,180-1/10W a
LED X R 0402 S2-261-251-015 C-RES,100-1/10W a
LED X R 0403 S2-261-252-705 C-RES,27-1/10W a
LED X R 0404 S2-261-252-215 C-RES,220-1/10W a
LED O SW 0103 87-036-379-38 C-SW,SL 1-1-2 SS-350-A12B-C a
LED O SW 0302 87-A90-968-08 C-SW,SL 1-2-2 SSSS82 a
LED X W 0401 87-HT6-607-01 WIRE,5P LED(65MM) a
MAIN O C 0101 S3-660-171-078 C-CAP,E 100-4 M MV a
MAIN O C 0102 S3-680-364-735 C-CAP,0.047-16V K a
MAIN O C 0103 87-010-505-08 C-CAP,TN 1-16 a
MAIN O C 0104 87-010-198-08 C-CAP,S 0.022-25 B a
MAIN O C 0105 S3-680-564-725 CAP,0.0047-50V a
MAIN O C 0106 87-010-522-08 CAP,TN 2.2-10V a
TP-VS715
YUSC
MAIN O C 0107 S3-680-564-725 CAP,0.0047-50V a
MAIN O C 0108 87-010-522-08 CAP,TN 2.2-10V a
MAIN O C 0109 87-A10-952-08 C-CAP,TN 22-4 M A MCM a
MAIN O C 0110 87-010-424-08 C-CAP,TN 4.7-4 a
MAIN O C 0111 S3-680-364-735 C-CAP,0.047-16V K a
MAIN O C 0112 87-010-746-08 C-CAP,TN 10-4 M 125 a
MAIN O C 0113 87-010-198-08 C-CAP,S 0.022-25 B a
MAIN O C 0114 S3-680-201-055 C-CAP,1-10V a
MAIN O C 0121 S3-680-564-725 CAP,0.0047-50V a
MAIN O C 0122 87-012-141-08 C-CAP,0.22-16F a
MAIN O C 0123 87-010-424-08 C-CAP,TN 4.7-4 a
MAIN O C 0124 87-010-746-08 C-CAP,TN 10-4 M 125 a
MAIN O C 0127 87-010-588-01 CAP,E 220-2 a
MAIN O C 0128 87-010-503-01 CAP,E 220-4 GAS a
MAIN O C 0129 S3-660-174-768 CAP,E 47-4 a
MAIN O C 0141 87-010-502-01 CAP,E 100-4 a
MAIN O C 0142 87-010-196-08 C-CAP,S 0.1-25 F a
MAIN O C 0151 87-015-922-08 C-CAP,TN 0.1-35 a
MAIN O C 0152 87-010-746-08 C-CAP,TN 10-4 M 125 a
MAIN O C 0153 S3-680-201-055 C-CAP,1-10V a
TP-VS715
YUSC
MAIN O C 0201 S3-680-201-055 C-CAP,1-10V a
MAIN O C 0202 87-010-322-08 C-CAP,S 100P-50 CH a
MAIN O C 0203 87-010-502-01 CAP,E 100-4 a
MAIN O C 0204 87-A10-952-08 C-CAP,TN 22-4 M A MCM a
MAIN O C 0205 87-010-504-08 C-CAP,TN 0.47-25 a
MAIN O C 0206 87-010-504-08 C-CAP,TN 0.47-25 a
MAIN O C 0207 87-010-424-08 C-CAP,TN 4.7-4 a
MAIN O C 0208 87-010-424-08 C-CAP,TN 4.7-4 a
MAIN O C 0209 87-012-141-08 C-CAP,0.22-16F a
MAIN O C 0210 87-010-503-01 CAP,E 220-4 GAS a
MAIN O C 0211 87-010-746-08 C-CAP,TN 10-4 M 125 a
MAIN O C 0212 87-010-196-08 C-CAP,S 0.1-25 F a
MAIN O C 0213 87-012-365-08 C-CAP,S 0.027-25VBK a
MAIN O C 0301 87-010-503-01 CAP,E 220-4 a
MAIN O C 0302 S3-680-361-045 C-CAP,0.1-16V a
MAIN O C 0303 S3-680-163-345 C-CAP,0.33-6.3V a
MAIN O C 0304 S3-680-361-045 C-CAP,0.1-16V a
MAIN O C 0305 S3-680-361-045 C-CAP,0.1-16V a
MAIN O C 0306 S3-680-361-045 C-CAP,0.1-16V a
MAIN O C 0307 S3-680-164-745 C-CAP,0.47-6.3V a
TP-VS715
YUSC
MAIN O C 0308 87-010-196-08 C-CAP,S 0.1-25 F a
MAIN O C 0310 S3-680-364-735 C-CAP,0.047-16V K a
MAIN O C 0312 87-A10-219-04 CAP,E 470-4 a
MAIN O C 0313 87-010-196-08 C-CAP,S 0.1-25 F a
MAIN O C 0401 S3-680-201-055 C-CAP,1-10V a
MAIN O C 0451 87-010-196-08 C-CAP,S 0.1-25 F a
MAIN O C 0452 87-010-196-08 C-CAP,S 0.1-25 F a
MAIN O C 0453 87-012-141-08 C-CAP,0.22-16F a
MAIN O D 0301 87-A40-822-04 C-DIODE,CRS01 a
MAIN O D 0451 87-001-167-08 C-DIODE,1SS302 a
MAIN O D 0452 87-001-166-08 C-DIODE,1SS301 a
MAIN S IC 0101 87-A20-792-04 C-IC,AN7085NS a
MAIN S IC 0201 87-A21-902-04 C-IC,BA5208AF TL a
MAIN S IC 0301 87-A21-224-04 C-IC,LB1877M a
MAIN O J 0101 S1-912-100-195 JACK,3.5 GRN EJS-5-3335G a
MAIN O J 0102 S1-912-100-194 JACK,3.5 RED EJM-3-3335R a
MAIN O J 0103 87-A61-124-11 JACK,DC DIA2.75 BLK TC a
MAIN O MIC0101 87-A91-891-01 MIC,ECM OBO-54LN-OB a
MAIN S Q 0101 87-026-411-08 C-TR,RN1304 a
MAIN S Q 0103 89-333-266-08 C-TR,2SC3326B a
All manuals and user guides at all-guides.com

! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-4-
ELECTRICAL PARTS LIST -2/3
TP-VS715
YUSC
MAIN S Q 0131 87-026-411-08 C-TR,RN1304 a
MAIN S Q 0132 87-026-414-08 C-TR,RN1307 a
MAIN S Q 0141 89-341-165-08 C-TR,2SC4116GR a
MAIN S Q 0142 87-026-414-08 C-TR,RN1307 a
MAIN S Q 0151 87-026-417-08 C-TR,RN1310 a
MAIN S Q 0152 87-026-417-08 C-TR,RN1310 a
MAIN S Q 0153 89-342-132-08 TR,2SC4213 a
MAIN S Q 0154 89-341-165-08 C-TR,2SC4116GR a
MAIN S Q 0301 87-A30-179-01 FET,2SJ107GR a
MAIN S Q 0302 87-A30-184-07 C-FET,2SJ106Y a
MAIN S Q 0303 87-A30-184-07 C-FET,2SJ106Y a
MAIN S Q 0304 89-342-132-08 TR,2SC4213 a
MAIN S Q 0305 87-026-414-08 C-TR,RN1307 a
MAIN S Q 0306 89-342-132-08 TR,2SC4213 a
MAIN S Q 0307 89-341-165-08 C-TR,2SC4116GR a
MAIN S Q 0451 89-341-165-08 C-TR,2SC4116GR a
MAIN S Q 0452 89-333-266-08 C-TR,2SC3326B a
MAIN S Q 0453 87-026-414-08 C-TR,RN1307 a
MAIN S Q 0454 87-026-417-08 C-TR,RN1310 a
MAIN X R 0101 88-118-222-08 C-RES,S 2.2K-1/10W J a
TP-VS715
YUSC
MAIN X R 0102 88-118-102-08 C-RES,S 1K-1/10W J a
MAIN X R 0103 88-118-102-08 C-RES,S 1K-1/10W J a
MAIN X R 0104 88-118-153-08 C-RES,15K-1/10W a
MAIN X R 0105 88-118-103-08 C-RES,S 10K-1/10W J a
MAIN X R 0106 88-118-562-08 C-RES,S 5.6K-1/10W J a
MAIN X R 0107 88-118-560-08 C-RES,S 56-1/10W J a
MAIN X R 0108 88-118-474-08 C-RES,S 470K-1/10W J a
MAIN X R 0109 88-118-152-08 C-RES,S 1.5K-1/10W J a
MAIN X R 0110 88-118-271-08 C-RES,270-1/10W a
MAIN X R 0111 88-118-560-08 C-RES,S 56-1/10W J a
MAIN X R 0112 88-118-822-08 C-RES,S 8.2K-1/10W J a
MAIN X R 0113 88-118-102-08 C-RES,S 1K-1/10W J a
MAIN X R 0115 88-118-152-08 C-RES,S 1.5K-1/10W J a
MAIN X R 0116 88-118-222-08 C-RES,S 2.2K-1/10W J a
MAIN X R 0117 88-118-181-08 C-RES,S 180-1/10W J a
MAIN X R 0119 88-118-393-08 C-RES,S 39K-1/10W J a
MAIN X R 0121 88-118-102-08 C-RES,S 1K-1/10W J a
MAIN X R 0122 88-118-822-08 C-RES,S 8.2K-1/10W J a
MAIN X R 0123 88-118-479-08 C-RES,4.7-1/10W a
MAIN X R 0131 88-118-332-08 C-RES,S 3.3K-1/10W J a
TP-VS715
YUSC
MAIN X R 0132 88-118-153-08 C-RES,15K-1/10W a
MAIN X R 0141 88-118-104-08 C-RES,S 100K-1/10W J a
MAIN X R 0142 88-118-104-08 C-RES,S 100K-1/10W J a
MAIN X R 0143 88-118-335-08 C-RES,S 3.3M-1/10W J a
MAIN X R 0144 88-118-102-08 C-RES,S 1K-1/10W J a
MAIN X R 0151 88-118-333-08 C-RES,S 33K-1/10W J a
MAIN X R 0152 88-118-334-08 C-RES,S 330K-1/10W J a
MAIN X R 0154 88-118-472-08 C-RES,S 4.7K-1/10W J a
MAIN X R 0155 88-118-473-08 C-RES,S 47K-1/10W J a
MAIN X R 0161 88-118-221-08 C-RES,S 220-1/10W J a
MAIN X R 0201 88-118-103-08 C-RES,S 10K-1/10W J a
MAIN X R 0202 88-118-102-08 C-RES,S 1K-1/10W J a
MAIN X R 0203 88-118-102-08 C-RES,S 1K-1/10W J a
MAIN X R 0204 88-118-102-08 C-RES,S 1K-1/10W J a
MAIN X R 0205 88-118-681-08 C-RES,S 680-1/10W J a
MAIN X R 0301 88-118-333-08 C-RES,S 33K-1/10W J a
MAIN X R 0302 88-118-103-08 C-RES,S 10K-1/10W J a
MAIN X R 0303 88-118-105-08 C-RES,S 1M-1/10W J a
MAIN X R 0304 88-118-104-08 C-RES,S 100K-1-10W J a
MAIN X R 0305 S2-261-252-735 C-RES,27K-1/10W a
TP-VS715
YUSC
MAIN X R 0306 88-118-562-08 C-RES,S 5.6K-1/10W J a
MAIN X R 0308 S2-261-251-835 C-RES,18K-1/10W a
MAIN X R 0309 88-118-105-08 C-RES,S 1M-1/10W J a
MAIN X R 0310 S2-261-256-825 C-RES,6.8K-1/10W a
MAIN X R 0311 88-118-105-08 C-RES,S 1M-1/10W J a
MAIN X R 0314 88-118-105-08 C-RES,S 1M-1/10W J a
MAIN X R 0315 88-118-105-08 C-RES,S 1M-1/10W J a
MAIN X R 0316 88-118-104-08 C-RES,S 100K-1-10W J a
MAIN X R 0317 88-118-105-08 C-RES,S 1M-1/10W J a
MAIN X R 0318 88-118-105-08 C-RES,S 1M-1/10W J a
MAIN X R 0319 88-118-105-08 C-RES,S 1M-1/10W J a
MAIN X R 0320 S2-261-250-005 C-RES,0-1/10W a
MAIN X R 0321 88-118-104-08 C-RES,S 100K-1-10W J a
MAIN X R 0322 88-118-222-08 C-RES,S 2.2K-1/10W J a
MAIN X R 0323 S2-261-253-925 C-RES,3.9K-1/10W a
MAIN X R 0451 88-118-102-08 C-RES,S 1K-1/10W J a
MAIN X R 0452 S2-261-255-645 C-RES,560K-1/10W a
MAIN X R 0453 S2-261-251-015 C-RES,100-1/10W a
MAIN X R 0454 S2-261-251-835 C-RES,18K-1/10W a
MAIN X R 0455 S2-261-251-225 C-RES,1.2K-1/10W a
All manuals and user guides at all-guides.com

ELECTRICAL PARTS LIST -3/3
TP-VS715
YUSC
MAIN X R 0456 S2-261-255-615 C-RES,560-1/10W a
MAIN X R 0457 S2-261-254-705 C-RES,47-1/10W a
MAIN O SFR0301 87-A91-653-04 C-SFR,K 33K H RH03CAEC a
MAIN O SFR0302 S1-740-153-200 C-VR TMC3K-B15K-TR a
MAIN O SW 0101 87-A90-422-01 SW,SL 2-2-2 a
MAIN O SW 0102 87-A90-725-01 SW,SL 2-2-2 a
MAIN O SW 0131 87-036-379-38 C-SW,SL 1-1-2 SS-350-A12B-C a
MAIN O SW 0141 87-036-379-38 C-SW,SL 1-1-2 SS-350-A12B-C a
MAIN O SW 0151 87-036-379-38 C-SW,SL 1-1-2 SS-350-A12B-C a
MAIN O SW 0161 87-A90-564-01 SW,LEAF MUTE a
MAIN O SW 0301 87-A90-423-01 SW,LEAF a
MAIN O TH 0301 87-A90-477-08 C-THMS,157-502-53002-TP a
MAIN O TH 0302 87-A90-477-08 C-THMS,157-502-53002-TP a
MAIN O VR 0101 87-A91-893-01 VR,RTRY 20KA H XV010702GPH3N1 a
MAIN O VR 0301 87-A91-822-01 VR,RTRY 10KB H XV081PH1NCC-30 a
MAIN X W 0101 87-HT6-606-01 WIRE,2P ECM(150MM) a
MAIN X W 0201 87-HT6-605-01 WIRE,2P SP(80MM) a
MAIN X W 0301 87-HT6-604-01 WIRE,5P MOTOR(35MM) a
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-5-
88
A
Resistor Code
Chip Resistor Part Coding
Figure
Value of resistor
Chip resistor
Wattage Type Tolerance
1/16W
1/10W
1/8W
1608
2125
3216
5%
5%
5%
CJ
CJ
CJ
Form
LW t
1.6 0.8 0.45
2 1.25 0.45
3.2 1.6
108
118
128
: A
: A
CHIP RESISTOR PART CODE
0.55
Resistor Code
Dimensions (mm)
Symbol
1/16W 1005 5% CJ
1.0 0.5 0.35 104
Lt
W
• Regarding connectors, they are not stocked as they are not the initial order items.
The connectors are available after they are supplied from connector manufacturers upon the order is received.
TRANSISTOR ILLUSTRATION -1/1
D G S
2SJ107
S
D
G
2SJ106
B
E
C
2SC3326
2SC4116
2SC4213
RN1304
RN1307
RN1310
All manuals and user guides at all-guides.com

-6-
SCHEMATIC DIAGRAM - 1/1
W401
220
PY1112H-TR-GRN
AY1112H-TR-YEL
BR1112H-TR-RED
SML-110VT(K,L) RED
W201
W301
SP101
(EARPHONE)
J101
SW301
R6AA X 2
100P
RN1304
4700P
4700P
470K
22/4
J102
EXT. MIC
4700P
1/16
MIC101 W101
MAIN C.B LED C.B
SIGNAL
NOTE
:AUDIO(PB)
:AUDIO(REC)
=
J103
DC 3V
8 7 6 5
1
2
1
6
3
4
2 3 4
5
VOLUME/
V-SENSOR
LEVEL
PLAYBACK
SPEED
LED403
LED402
LED402
LED401
LED404
RED
ORANGE
GREEN
Hi Lo
NFR
V-SENSOR
OUT IN
47
All manuals and user guides at all-guides.com
all-guides.com

-7-
18
19
20
23
5
1
2
3
4
8
9
15
10
11
12
13
36
35
33
14
17
16
31
37
37
32
32
7
28
29
30
6
A
24
21
22
27
26
34
25
B
B
C
D
D
G
H
H
F
E
MECHANICAL EXPLODED VIEW -1/1
All manuals and user guides at all-guides.com

! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-8-
MECHANICAL MAIN PARTS LIST -1/1
COLOR NAME TABLE -1/1
Basic color symbol Color Basic color symbol Color Basic color symbol Color
B Black C Cream D Orange
G Green H Gray L Blue
LT Transparent Blue N Gold P Pink
R Red S Silver ST Titan Silver
T Brown V Violet W White
WT Transparent White Y Yellow YT Transparent Yellow
LM Metallic Blue LL Light Blue GT Transparent Green
LD Dark Blue DT Transparent Orange GM Metallic Green
YM Metallic Yellow DM Metallic Orange PT Transparent Pink
LA Aqua Blue GL Light Green HT Transparent Gray
HM Metallic Gray NH Champagne Gold M Wood Pattern
TP-VS715
YUSC
O MC1001 8C-HT4-022-01 FRAME,CENTER YU a
O MC1002 87-HT6-221-11 COUNTER,MU331-001 a
O MC1003 87-HT6-222-01 BELT,COUNTER a
O MC1004 87-HT6-207-01 HLDR,COUNTER a
O MC1005 87-HT6-212-11 SPR-P,CASS a
X MC1006 S1-013-020-800 RUBBER FELT 2X5X8 a
O MC1007 87-HT6-206-01 HLDR,JACK DC a
X MC1008 M8-7ZM-59C-07 7ZM-5 YM2NC a
O MC1009 8C-HT4-008-01 BTN,REC a
O MC1010 8C-HT4-010-01 BTN,PLAY a
O MC1011 8C-HT4-009-01 BTN,STOP a
O MC1012 8C-HT4-011-01 BTN,FF a
O MC1013 8C-HT4-012-01 BTN,REW a
X MC1014 87-HT6-203-01 HLDR,PWB a
O MC1015 8C-HT4-205-01 BAT-CONTACT,(-) a
X MC1016 8C-HT4-602-01 PWB,MAIN 2M a
O MC1017 8C-HT4-204-01 BAT-CONTACT,(+) a
O MC1018 8C-HT4-003-01 FRAME,MIC a
O MC1019 8C-HT4-201-01 HLDR,MIC a
O MC1020 8C-HT4-004-01 PLATE,MIC a
TP-VS715
YUSC
O MC1021 8C-HT4-013-01 KNOB,RTRY MIC/REC a
O MC1022 8C-HT4-002-01 WINDOW,CASS a
O MC1023 8C-HT4-021-01 LID,CASS YU a
O MC1024 8C-HT4-016-01 LENS,LED a
X MC1025 8C-HT4-603-01 PWB,LED a
O MC1026 87-A92-201-01 SPKR,DIA50 8OHM 0.7W ML20D0.5 a
O MC1027 8C-HT4-203-01 SPR-T,CASS a
O MC1028 87-HT6-208-01 HLDR,BAT a
O MC1029 8C-HT4-006-01 LID,BAT ABS a
O MC1030 8C-HT4-023-01 CABI,REAR YU a
O MC1031 8C-HT4-014-01 KNOB,SL PAUSE a
O MC1032 8C-HT4-015-01 KNOB,SL SLSS/MIC a
O MC1033 87-HT6-205-01 LEVER,PAUSE a
X MC1034 8A-HT6-212-01 SH SPEAKER W/ADH HIEM. T= a
O MC1035 87-HT6-118-01 SEAL,DIR a
X MC1036 8B-HC4-211-01 SH PWB A a
O MC1037 8C-HT4-202-01 FOOT,RUBBER a
O MC1A 87-HT6-218-01 S-SCREW,STP+1.4-2.5 a
O MC1B 87-B10-113-01 QT2+1.7-3 BLACK a
O MC1C 87-067-534-01 SCREW,VT-1.4-6 a
TP-VS715
YUSC
O MC1D 87-B10-112-01 VT2+2-14 BLACK a
O MC1E 8C-HT4-209-01 VT2+1.4-6 a
O MC1F 87-067-746-01 SCREW,M 1.4-2(H0.5) a
O MC1G 8C-HT4-207-01 S-SCREW 1.4X8 a
O MC1H 8C-HT4-208-01 S-SCREW 1.4X3 a
All manuals and user guides at all-guides.com

-9-
1
2
34
8
4
5
6
C
50
7
7
67
44
52
51
10
46
48
49
47
55
56
57
58
54
60
59
9
53
68
A
A
TAPE MECHANISM EXPLODED VIEW -1/2 <7ZM-5 YM2NC>
All manuals and user guides at all-guides.com

-10-
a
b
c
23
24
25
26
27 28
28
29
30
43
41
42
42
32
d
45
31
13
14
16
17
12
20
18
19
38
21
22
d
45
e
62
63 64
ab
c
40
39
37
36
35
34
15
11
fe
f
65
66
61
33
D
A
A
A
H
G
A
F
B
E
E
TAPE MECHANISM EXPLODED VIEW -2/2 <7ZM-5 YM2NC>
All manuals and user guides at all-guides.com

! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-11-
TAPE MECHANISM PARTS LIST -1/2 <7ZM-5 YM2NC>
7ZM-5
M2NC
O ST1001 87-ZM5-314-210 LEVER,MODE SEL REC a
O ST1002 87-ZM5-361-010 SPR-T,PINCH L REC a
O ST1003 87-ZM5-351-010 ARM,PINCH L REC a
O ST1004 87-ZM5-279-110 ROLLER ASSY,PINCH L a
X ST1004a 87-ZM5-280-110 CLR,PINCH ROLLER L a
X ST1004b 87-ZM5-281-010 ROLLER,RUBBER L a
O ST1005 87-ZM5-324-110 LEVER,PLAY MS a
O ST1006 87-ZM5-251-010 SPR-C,GEAR REEL a
O ST1007 87-ZM5-354-110 GEAR,REEL REC a
O ST1008 87-ZM5-352-010 ARM,PINCH R REC a
O ST1009 87-ZM5-362-010 SPR-T,PINCH R REC a
O ST1010 87-ZM5-355-010 BTN,DIR KNOB TP a
O ST1011 87-ZM5-221-110 GEAR,IDL A a
O ST1012 87-ZM5-222-310 GEAR,IDL B a
O ST1013 87-ZM5-339-110 LEVER ASSY,DIR TP a
X ST1013a 87-ZM5-337-110 LEVER,DIR TP a
O ST1014 85-ZM1-212-110 PULLY PM 2 a
O ST1015 87-ZM5-335-110 LEVER,LOCK REC a
O ST1016 M8-6ZS-39B-070 ABL-63 AC a
O ST1017 87-ZM5-208-310 LEVER ASSY,T-UP a
7ZM-5
M2NC
X ST1017a 87-ZM5-209-210 LEVER,T-UP a
O ST1018 87-ZM5-223-010 GEAR,PLAY a
O ST1019 87-ZM5-259-210 CAP,PLAY a
O ST1020 87-ZM5-216-010 LEVER,PLAY SW a
O ST1021 87-ZM5-228-310 GEAR,SLIP B a
O ST1022 87-ZM5-229-110 FELT,CLUTCH a
O ST1023 87-ZM5-390-010 GEAR,SLIP A3 a
O ST1024 87-ZM5-277-310 SPR-C,SLIP 2 a
O ST1025 87-ZM5-246-310 SPR-T,AUTO a
O ST1026 87-ZM5-214-410 LEVER,AUTO a
O ST1027 87-ZM5-204-510 LEVER ASSY,FF a
X ST1027a 87-ZM5-205-410 LEVER,FF a
O ST1028 87-ZM5-225-410 GEAR,FF/REW a
O ST1029 87-ZM5-349-410 LEVER ASSY,REW REC a
X ST1029a 87-ZM5-348-010 SHAFT,REV BACK a
O ST1029b 87-ZM5-350-310 LEVER,REW REC a
O ST1030 87-ZM5-332-110 LEVER,STOP REC a
O ST1031 87-ZM5-261-A10 LEVER,AUTO 2 S a
O ST1032 87-ZM5-380-010 BELT,MAIN 2 a
O ST1033 87-ZM5-258-010 CAP,CAPSTAN a
7ZM-5
M2NC
O ST1034 87-ZM5-245-110 SPR-T,DIR a
O ST1035 87-ZM5-243-010 SPR-T,FF a
O ST1036 87-ZM5-247-010 SPR-T,AUTO 2 a
O ST1037 87-ZM5-379-010 SPR-T,REW REC a
O ST1038 87-ZM5-250-310 SPR-T,LEVER T-UP a
O ST1039 87-ZM5-374-010 SPR-T,LVR LOCK REC a
O ST1040 87-ZM5-368-010 SPR-T,PLAY L REC a
O ST1041 87-ZM5-236-110 FLY-WHL,R a
O ST1042 87-ZM5-345-010 CAPSTAN,REC 1.8-21.59 a
O ST1043 87-ZM5-235-110 FLY-WHL,L a
O ST1044 87-ZM5-301-910 CHAS ASSY,OUT-SERT REC a
O ST1045 87-ZM5-260-110 CLR,BEARING a
O ST1046 87-ZM5-329-010 LEVER,HEAD a
O ST1047 87-ZM5-313-110 HLDR,HEAD a
O ST1048 87-ZM5-367-010 SPR-T,HEAD POSITION L a
O ST1049 87-ZM5-377-010 SPR-T,HEAD POSITION R a
O ST1050 87-ZM5-378-010 SPR-C,BT REC a
O ST1051 87-ZM5-364-010 SPR-T,RVS REC SEL a
O ST1052 87-ZM5-366-110 SPR-T,REC OFF a
O ST1053 87-ZM5-363-010 SPR-T,REC SEARCH L a
7ZM-5
M2NC
O ST1054 87-ZM5-311-010 LEVER,REC OFF a
O ST1055 87-ZM5-336-110 LEVER,BTN TP REC a
O ST1056 87-ZM5-323-010 LEVER,REC GUARD a
O ST1057 87-ZM5-328-010 LEVER,TRANSMIT a
O ST1058 87-ZM5-327-010 LEVER,RVS REC SEL a
O ST1059 87-ZM5-322-010 LEVER,REC SEARCH R a
O ST1060 87-ZM5-321-010 LEVER,REC SEARCH L a
O ST1061 87-ZM5-365-010 SPR-T,BTN REC a
O ST1062 87-ZM5-342-010 SHAFT,COUNTER PULLEY a
X ST1062a 87-ZM5-341-010 SHAFT,DIR a
O ST1063 87-ZM5-316-010 GEAR,COUNTER PULLEY a
O ST1064 87-ZM5-315-010 GEAR,COUNTER REEL a
O ST1065 87-ZM5-330-110 LEVER,CUE REV a
O ST1066 87-ZM5-240-210 SHAFT,PULLEY a
O ST1067 87-A90-658-110 HEAD ASSY,7HT-6 a
X ST1067a 87-A90-657-010 PWB,FLEX RP/E 7HT6 a
X ST1067b 86-ZM2-294-010 HEAD,RPH a
O ST1067c 86-ZM2-297-110 ARM,EH a
O ST1068 87-HT6-118-010 SEAL,DIR a
O ST1A 87-B10-136-010 W-P,1.09-3.1-0.4 a
All manuals and user guides at all-guides.com
all-guides.com

! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-12-
7ZM-5
M2NC
O ST1B 87-ZM5-271-110 S-SCREW,1.4-2.6 -STP a
O ST1C 87-ZM5-385-010 S-SCREW,EH+1.4-10.1 a
X ST1D 87-B10-070-010 W-P,1.55-2.9-0.25 SLIT a
O ST1E 87-B10-135-010 W-L,1.17-3-0.35 a
O ST1F 87-B10-151-010 W-PVC,1.09-3.1-0.3 a
X ST1G 87-B10-262-010 W-L,1.97-3.8-0.05 RED a
X ST1H 87-B10-107-010 W-L,1.96-4.2-0.1 a
TAPE MECHANISM PARTS LIST -2/2 <7ZM-5 YM2NC>
All manuals and user guides at all-guides.com

! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-13-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
OTHER PARTS LIST -1/2
OTHER PARTS LIST -2/2 <7ZM-5 YM2NC>
7ZM-5
M2NC
X 87-ZM5-389-010 SH, MYLAR 0.8-3-0.1 W/ADH a
TP-VS715
YUSC
X 8C-HT4-863-01 CTN,OUTER 715 YUSC a
X 87-B40-057-01 BAG,PP 0.03-150-200 a
X 8C-HT4-862-01 CTN,INNER 715 YUSC a
X 8C-HT4-861-11 CTN,PRINTED 715 YUSC a
X 87-B50-054-01 WARR-CARD,USA NOR-CUST/PORTAB a
X 87-B40-282-01 LBL,BAR-CODE AU 35X8 a
X 87-B40-154-01 LBL,BAR-CODE CU a
X 8C-HT4-105-21 LBL,SPEC YU a
All manuals and user guides at all-guides.com
