SERVICE MANUAL
DATA
STEREO
CASSETTE PLAYER BASIC TAPE MECHANISM : 7ZM-1 P1NF
HS-PXM2000
YH,AH,
AE
S/M Code No. 09-006-405-2R4
REVISION
• This Service Manual is the "Revision Publishing" and replaces "Simple Manual"
(S/M Code No. 09-004-405-2T4).
M2000

SPECIFICATIONS
- 2 -
• Design and specifications are subject to change without
notice.
Maximum output: 4 mW + 4 mW (EIAJ 16 ohms)<AE>
4 mW + 4 mW (EIAJ 32 ohms)<AH,YH>
Load impedance: 16 – 32 ohms
Power sources: DC 1.2 V using supplied rechargeable battery NB-5G,
DC 1.5 V using an R6 (AA) dry cell battery,
AC house current using the optional AC adaptor
Maximum dimensions: 80 (W) x 112.9 (H) x 18.9 (D) mm (31/4 x 41/2 x 3/4in.)
Weight Approx. 134 g, 4.7 oz. (excluding batteries)
• Dolby noise reduction manufactured under license from Dolby
Laboratories Licensing Corporation.
“DOLBY” and the double-D symbol are trademarks of Dolby
Laboratories Licensing Corporation.

DESCRIPTIONREF. NO. KANRI
NO.
PARTNO. KANRI
NO.
REF. NO. DESCRIPTIONPARTNO.
ELECTRICAL MAIN PARTS LIST
- 3 -
IC
87-A21-179-010 C-IC,TA2123AF
87-A21-061-010 C-IC,ML63512-120
87-A21-050-040 C-IC,S-80810ANNP-E70-T2
87-A20-603-140 C-IC,RN5RK241A
87-A20-961-040 C-IC,MM1279XV
87-A20-818-040 C-IC,NJM2185AV<AE>
TRANSISTOR
89-113-625-080 TR,2SA1362
87-026-535-080 C-TR,RN4907
87-026-418-080 TR,RN1311
89-342-132-080 TR,2SC4213B
87-026-417-080 TR,RN1310
89-341-165-080 C-TR,2SC4116
87-026-481-080 C-TR,RN4607<AE>
87-A30-085-040 C-TR,CSA1362
89-333-266-080 C-TR,2SC3326B
DIODE
87-001-553-080 C-DIODE 1SS322
MAIN C.B
C101 87-012-273-080 C-CAP,U 820P-50 B
C102 87-012-273-080 C-CAP,U 820P-50 B
C103 87-012-273-080 C-CAP,U 820P-50 B
C104 87-012-273-080 C-CAP,U 820P-50 B
C105 87-A10-952-080 C-CAP,TN 22-4 M A MCM
C106 87-A10-952-080 C-CAP,TN 22-4 M A MCM
C107 87-016-114-080 C-CAP,U 0.01-25 B<AE>
C107 87-012-286-080 C-CAP,U 0.01-25 K B<AH,YH>
C108 87-016-114-080 C-CAP,U 0.01-25 B<AE>
C108 87-012-286-080 C-CAP,U 0.01-25 K B<AH,YH>
C109 87-010-828-080 CHIP CAPACITOR,U 0.033
C110 87-010-828-080 CHIP CAPACITOR,U 0.033
C111 87-A10-025-080 C-CAP,U 0.22-16Z F
C112 87-A10-031-080 C-CAP,U 0.01-25 KB
C113 87-A10-263-080 C-CAP,U 0.1-16ZF
C114 87-A11-056-080 C-CAP,U 1-10 Z F
C115 87-A10-952-080 C-CAP,TN 22-4 M A MCM
C116 87-A11-244-080 C-CAP,TN 47-4 A MCM
C117 87-A10-707-080 C-CAP,U 0.47U-16 F Z
C118 87-A10-707-080 C-CAP,U 0.47U-16 F Z
C119 87-A10-707-080 C-CAP,U 0.47U-16 F Z
C120 87-A10-704-080 C-CAP,TN 100-2.5 M B2
C121 87-A10-704-080 C-CAP,TN 100-2.5 M B2
C122 87-010-424-080 CAPACTOR,TANTAL 4.7-4
C123 87-A11-063-080 C-CAP,S 4.7-10 Z F
C124 87-A10-707-080 C-CAP,U 0.47U-16 F Z
C125 87-A10-263-080 C-CAP,U 0.1-16ZF
C126 87-A10-263-080 C-CAP,U 0.1-16ZF
C127 87-A10-031-080 C-CAP,U 0.01-25 KB
C128 87-A10-031-080 C-CAP,U 0.01-25 KB
C129 87-016-462-080 C-CAP,S 1-16 F
C130 87-016-462-080 C-CAP,S 1-16 F
C131 87-012-274-080 CHIP CAP,U 1000P-50B
C132 87-012-274-080 CHIP CAP,U 1000P-50B
C133 87-A10-025-080 C-CAP,U 0.22-16Z F
C134 87-A10-707-080 C-CAP,U 0.47U-16 F Z
C135 87-A11-056-080 C-CAP,U 1-10 Z F
C136 87-A10-707-080 C-CAP,U 0.47U-16 F Z
C137 87-A10-707-080 C-CAP,U 0.47U-16 F Z
C138 87-A11-063-080 C-CAP,S 4.7-10 Z F
C139 87-A10-025-080 C-CAP,U 0.22-16Z F
C140 87-A11-062-080 C-CAP,S 2.2-16 Z F
C141 87-A11-063-080 C-CAP,S 4.7-10 Z F
C142 87-016-317-080 C-CAP,TN 2.2-6.3
C143 87-A10-952-080 C-CAP,TN 22-4 M A MCM
C151 87-016-462-080 C-CAP,S 1-16 ZF<AE>
C152 87-016-462-080 C-CAP,S 1-16 ZF<AE>
C153 87-012-274-080 C-CAP,U 1000P-50 KB<AE>
C154 87-010-746-080 C-CAP,TN 10-4 M 125<AE>
C155 87-016-526-080 C-CAP,S 0.47-16 BK<AE>
C156 87-016-526-080 C-CAP,S 0.47-16 BK<AE>
C157 87-016-460-080 C-CAP,S 0.22-16 KB<AE>
C158 87-016-460-080 C-CAP,S 0.22-16 KB<AE>
C159 87-010-746-080 C-CAP,TN 10-4 M 125<AE>
C160 87-016-462-080 C-CAP,S 1-16 F<AE>
C161 87-016-462-080 C-CAP,S 1-16 F<AE>
C201 87-016-462-080 C-CAP,S 1-16 Z F
C202 87-010-505-080 CAP,CHIP TANTALUM 1-16
C203 87-A10-263-080 C-CAP,U 0.1-16ZF
C204 87-A10-263-080 C-CAP,U 0.1-16ZF
C205 87-A11-056-080 C-CAP,U 1-10 Z F
C206 87-A11-056-080 C-CAP,U 1-10 Z F
C207 87-A10-263-080 C-CAP,U 0.1-16ZF
C208 87-A10-263-080 C-CAP,U 0.1-16ZF
C209 87-010-787-080 CAP, U 0.022-25
C210 87-A10-263-080 C-CAP,U 0.1-16 Z F
C211 87-012-270-080 CHIP CAP,U 470P-50B<AE>
C211 87-012-276-080 CHIP CAP,U 1500P-50KB<YH,AH>
C212 87-012-270-080 CHIP CAP,U 470P-50B<AE>
C212 87-012-276-080 CHIP CAP,U 1500P-50KB<YH,AH>
C213 87-012-282-080 CHIP CAP,U 4700P-50KB
C214 87-012-274-080 CHIP CAP,U 1000P-50B
C215 87-A10-263-080 C-CAP,U 0.1-16 Z F
C216 87-A10-263-080 C-CAP,U 0.1-16 Z F
C251 87-016-462-080 C-CAP,S 1-16 F
C252 87-A10-952-080 C-CAP,TN 22-4 M A MCM
C253 87-A10-263-080 C-CAP,U 0.1-16 Z F
C254 87-A11-244-080 C-CAP,TN 47-4 M B2 MCM
C255 87-A10-034-080 C-CAP,TN 33-10(B2)
C256 87-A10-263-080 C-CAP,U 0.1-16ZF
C257 87-A10-952-080 C-CAP,TN 22-4 M A MCM
C261 87-A11-062-080 C-CAP,S 2.2-16 ZF
C271 87-A11-062-080 C-CAP,S 2.2-16 ZF
C301 87-A10-031-080 C-CAP,U 0.01-25 KB
C302 87-A10-260-080 C-CAP,U 0.1-16 K B
C303 87-A11-063-080 C-CAP,S 4.7-10 Z F
C304 87-A10-263-080 C-CAP,U 0.1-16ZF
C305 87-A10-707-080 C-CAP,U 0.47-10 ZF
C306 87-A10-707-080 C-CAP,U 0.47U-16 F Z
C307 87-A10-031-080 C-CAP,U 0.01-25 KB
C308 87-A10-031-080 C-CAP,U 0.01-25 KB
C309 87-A10-031-080 C-CAP,U 0.01-25 KB
D201 87-A90-278-080 C-LED,SML-210VT RED
JR159 87-016-462-080 C-CAP,S 1-16 F<YH,AH>
JR160 87-016-462-080 C-CAP,S 1-16 F<YH,AH>
L200 87-003-375-080 C-COIL,1608 10UH K MLF1608
L251 87-A50-352-080 C-COIL, 100UH NP 05DB101M
PS261 87-A91-374-080 C-SNSR,PHOTO, NJL5194KN
PS271 87-A91-374-080 C-SNSR,PHOTO, NJL5194KN
R103 87-022-279-080 CHIP RES,U 470-1/16W F
R104 87-022-279-080 CHIP RES,U 470-1/16W F
R105 87-022-215-080 CHIP RES,U 1K-1/16W F<AE>
R106 87-022-215-080 CHIP RES,U 1K-1/16W F<AE>
R107 87-022-243-080 CHIP RES,U 15K-1/16W F
R108 87-022-243-080 CHIP RES,U 15K-1/16W F
R109 87-022-292-080 CHIP RES U 330K-1/16W F
R110 87-022-292-080 CHIP RES U 330K-1/16W F
R151 87-022-252-080 CHIP RES,U 36K-1/16W F<AE>
R214 87-022-243-080 CHIP RES,U 15K-1/16W F
R215 87-022-243-080 CHIP RES,U 15K-1/16W F
S101 8Z-HK4-606-010 SW,LEAF 7ZM-1
S201 87-036-379-180 C-SW,SL 1-1-2 SS-350-A12B-C-T
S202 87-036-379-180 C-SW,SL 1-1-2 SS-350-A12B-C-T
S207 87-A90-698-080 C-SWICH PUSH 1-1-1 PS-170-AT

DESCRIPTIONREF. NO. KANRI
NO.
PARTNO. KANRI
NO.
REF. NO. DESCRIPTIONPARTNO.
- 4 -
88
A
Resistor Code
Chip Resistor Part Coding
Figure
Value of resistor
Chip resistor
Wattage Type Tolerance
1/16W
1/10W
1/8W
1608
2125
3216
5%
5%
5%
CJ
CJ
CJ
Form
LW t
1.6 0.8 0.45
2 1.25 0.45
3.2 1.6
108
118
128
: A
: A
CHIP RESISTOR PART CODE
0.55
Resistor Code
Dimensions (mm)
Symbol
1/16W 1005 5% CJ
1.0 0.5 0.35 104
Lt
W
S207 87-A90-698-080 C-SWICH PUSH 1-1-1 PS-170-AT
S209 8Z-HK4-607-010 SW,LID 7ZM-1
SFR301 87-A91-011-080 C-SFR,6.8K RH03APA
VR101 87-024-686-080 C-VR,20KAX2 DIA14
X201 87-A70-151-110 VIB,XTAL 32.768KHZ VT
JACK C.B
J101 85-HK3-605-010 JACK,DIA3.5 ST 5P
SW C.B
S203 87-A90-665-180 C-SW,TACT LS7A2M
S204 87-A90-665-180 C-SW,TACT LS7A2M
S205 87-A90-665-180 C-SW,TACT LS7A2M
S206 87-A90-665-180 C-SW,TACT LS7A2M
HEAD FLEX C.B
PH1 87-ZM1-601-010 HEAD ASSY, 7ZM-1
B
E
C
RN1310
RN1311
2SA1362
CSA1362
2SC4116
TRANSISTOR ILLUSTRATION
2SC3326B
2SC4213B
C1
C2
E1
B2
E2
B1
RN4607
RN4907

WIRING
- 5 -
876543211345678
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
2
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
9 10 11 12 13 14 15 16910111213141516

SCHEMATIC DIAGRAM
- 6 -

IC BLOCK DIAGRAM
- 7 -

- 8 -
IC DESCRIPTION
1 AF IN I ‘H’: Exist music, ‘L’: Not exist music.
2 SCLK I Serialclockinputterminal.
3 MUTE O ‘H’: MUTE OFF, ‘L’: MUTE ON.
4 SDATA O Serial data output terminal.
5 F/R CONT O ‘H’: FWD direction, ‘L’: REV direction.
6 HI-SP-SW O ‘H’: Motor HI speed.
7 MOT DIR O ‘H’: Motor counterclockwise (FWD), ‘L’: Motor clockwise (REV).
8 MOTOR 1. 2 O Motor normal speed. (Not connected)
9 HI-SP DET I ‘H’: No exist DD drive output, ‘L’: Exist DD drive output.
10 MOT ON O ‘H’: Motor ON, ‘L’: Motor OFF.
11 MOT BR O ‘H’: Motor brake ON, ‘L’: Motor brake OFF.
12 HOLD IN I 'H' : Hold OFF, 'L' : Hold ON.
13 P-REV IN I Photo senser input terminal (REV side).
14 P-FWD IN I Photo senser input terminal (FWD side).
15 KEY MAIN I Key input terminal (Main unit).
16 KEY REMOTE I Key input terminal (Remote controller).
17 P-FWD K O Output for photo senser control (FWD side).
18 P-REV K O Output for photo senser control (REV side).
19 LED K O OPE battery LED control output.
20 P-CHECK (NC) O Photo senser puls checking output. (Not connected)
21 VDDI - Interface power supply terminal for external equipment.
22 VSS - Negative power supply terminal.
23 VDD - Positive power supply terminal.
24 VDDH - Boost power supply for backup.
25 ~ 26 CB1 ~ CB2 - Connected to power supply booster capacitor.
27 VDDL - Positive power supply for internal logic circuit.
28 ~ 29 XT0 ~ XT1 -
Clock oscilltor terminals (Low speed side).
Connected to 32.768 kHz crystal oscillator.
30 ~ 31 TEST1B ~ TEST2B - Test terminals. (Connected to GND).
32 OSCM - Connected to capacitor for high speed clock. (Connected to GND).
33 ~ 34 OSC0 ~ OSC1 - Clock oscilltor terminals (high speed side).
35 RESETB I Reset input.
36 BEEP O Alarm sound output.
37 CASS SW I ‘H’: Exist cassette, ‘L’: Not exist cassette.
38 SET STOP I ‘H’: Normal operation, ‘L’: Mechanism stop.
39 VOLTAGE DET I Input terminal for control motor speed.
40 TIMING SW I Input terminal for detect mechanism operation.
41 LID SW I ‘H’: Cassette case OPEN, ‘L’: Cassette case CLOSE.
42 DOLBY SW I ‘H’: Dolby ON, ‘L’: Dolby OFF.
43 DSL1 O Output: DSL1 OFF, Stop: DSL1 ON.
44 DSL2/EGS O ‘H’: DSL2/EGS OFF, ‘L’: DSL2/EGS ON.
Pin No. Pin Name I/O Description
IC, ML63512-120

- 9 -
Pin No. Pin Name I/O Description
45 POWER ON O "H" : Power ON, "L" : Power OFF.
46 DD DRIVE O Output terminal for control DC-DC converter.
47 EJECT SW I Input terminal for detect EJECT operation. "L" : Wait.
48 BS / MODE IN I
"H" : Continuous playback / BS enable,
"L" : Auto reverse playback / BS disable.

- 10 -
ADJUSTMENT
1. Tape Speed Adjustment
Settings : • Test tape : TTA–100
(Tape center)
• Test point : PHONES (J101)
• Adjustment location : SFR301
• TAPE SELECTOR : NORM
• VOLUME : MAX
Method : Play back (FWD) the test tape and adjust SFR301
so that the frequency becomes 3015 Hz ± 10 Hz.
Then confirm WOW is less than 0.50%.
2. Dolby level check
Settings : • Test tape : TTA – 200
• Test point : Dolby test point
TP1(R–CH), TP2(L–CH)
• DOLBY SW : OFF
• TAPE SELECTOR : NORM(auto)
• VOLUME : MIN
Method : Connected an electroytic capacitor (10uF/16V) to
measured equipment and TP1 or TP2, check that
the voltage is 32 mV ± 1.0 dB.
SFR301
MAIN C.B
A
PHONES
1
1
VR101
VOLUME
IC201
J101
IC301
TP2
(R-CH)
(L-CH)
TP1
2
*
* : At the other side of the pattern.

- 11 -
MECHANICAL EXPLODED VIEW 1 / 1
1
A
4
CONT C.B
32
3
31
30
F
I
A
2
6
5
7ZM-1 P1NF
7
8
9
B
10
MAIN C.B
14
33
F
K
15
JB
16
19
G
F
18
13
17
11
C
12
27
29
26
25
23
H
28
L
21
20
22
E
D24
SW C.B

DESCRIPTIONREF. NO. KANRI
NO.
PARTNO. KANRI
NO.
REF. NO. DESCRIPTIONPARTNO.
- 12 -
MECHANICAL PARTS LIST 1 / 1
COLOR NAME TABLE
Basic color symbol Color Basic color symbol Color Basic color symbol Color
B Black C Cream D Orange
G Green H Gray L Blue
LT Transparent Blue N Gold P Pink
R Red S Silver ST Titan Silver
T Brown V Violet W White
WT Transparent White Y Yellow YT Transparent Yellow
LM Metallic Blue LL Light Blue GT Transparent Green
LD Dark Blue DT Transparent Orange GM Metallic Green
YM Metallic Yellow DM Metallic Orange
1 8Z-HK4-045-010 LID,CASS 2000 ASSY<AH,YH>
1 8Z-HK4-052-010 LID,CASS 2000E ASSY<AE>
2 8Z-HK4-228-010 SPR-P,LID
3 8Z-HK4-057-010 HLDR,SPR LID
4 8Z-HK4-205-010 HLDR,LID
5 8Z-HK4-206-110 HLDR,ARM ASSY
6 8Z-HK4-210-010 NUT, B-BOX
7 8Z-HK4-204-110 HLDR,CONT
8 8Z-HK4-212-010 BAT-CONTACT,(+)
9 8Z-HK4-229-010 SHAFT,ASSY
10 8Z-HK4-007-110 LID,BAT
11 8Z-HK4-201-010 HLDR,BAT
12 8Z-HK4-215-010 LEVER,EJECT
13 8Z-HK4-211-010 BAT-CONTACT,(-)
14 8Z-HK4-049-010 FRAME,CTR 2000
15 8Z-HK4-225-010 PLATE,KNOB
16 8Z-HK4-011-010 KNOB,SL OPEN
17 8Z-HK4-051-010 KNOB,SL BLS 2000
18 8Z-HK4-047-010 CABI,REAR 2000<AH,YH>
18 8Z-HK4-054-010 CABI,REAR 2000E<AE>
19 8Z-HK4-012-010 LENS,LED
20 8Z-HK4-230-010 SPR-C,OPEN
21 8Z-HK4-217-010 PLATE,OPEN
22 8Z-HK4-218-010 PLATE,LOCK
23 8Z-HK4-219-010 SPR-T,LOCK
24 8Z-HK4-216-010 BASE,LOCK
25 8Z-HK4-221-010 SPR-P,CASS
26 8Z-HK4-050-010 KNOB,SL HOLD 2000
27 8Z-HK4-008-010 KEY,CONT
28 8Z-HK4-048-010 FRAME,CONT 2000
29 8Z-HK4-606-010 SW,LEAF 7ZM-1
30 8Z-HK4-607-010 SW,LID 7ZM-1
31 85-HK3-605-010 JACK,DIA3.5 ST 5P
32 8Z-HK4-203-010 HLDR,PWB
33 8Z-HK4-232-010 BAT-CONTACT,BOX(-) S
A 87-HK5-237-010 S-SCREW,1.4-2 CR NL
B 87-067-732-010 TAPPING SCREW, VT1.4-3
C 87-067-511-010 SCREW,V+1.4-2 BK
D 87-078-206-010 S-SCRW,1.4-0.6 B NL
E 87-078-183-010 SCRW-SR,1.4-1.4 BL
F 85-HK3-241-010 SCRW-SR,1.4-3CR L
G 8Z-HK4-231-010 S-SCREW,SERR+1.4-5.0 SWCH/CR
H 87-067-429-010 SCREW1.4-2.5
I 87-067-480-010 SPECIAL SCREW +1.4-3
J 8Z-HK4-227-010 S-SCREW,SERR+1.4-4.8 SWCH/CR E
K 87-078-153-010 SCRW,1.4-2.5 CR
L 87-078-108-010 S-SCRW 1.4-0.7 CRNL

- 13 -
TAPE MECHANISM EXPLODED VIEW 1 / 1
D
F
F
F
C
E
C
G
G
C
34
35
33
36
40
39
38
37
42
43
44
41
46
47
48
42
22
45
43
16
44
17
23
18
20
21
24
50
26
25
26
27
28
29
30
31
32
B
A
A
11
13
8
4
7
9
10
12
6
5
1
HEAD FLEX. C.B
3
2
14
19
H
BRG,
7ZSIA
15
49

DESCRIPTIONREF. NO. KANRI
NO.
PARTNO. KANRI
NO.
REF. NO. DESCRIPTIONPARTNO.
- 14 -
TAPE MECHANISM PARTS LIST 1 / 1
1 87-ZM1-230-010 HLDR,HEAD
2 87-ZM1-254-110 ARM ASSY,PINCH R
3 87-ZM1-287-010 SPR-T,PINCH BACK R
4 87-ZM1-285-010 SPR-T,PINCH R
5 87-ZM1-252-110 ARM ASSY,PINCH L
6 87-ZM1-286-010 SPR-T,PINCH BACK L
7 87-ZM1-284-010 SPR-T,PINCH L
8 87-ZM1-225-110 HLDR ASSY,CASSET
9 87-ZM1-275-010 SPR-T,HEAD BACK
10 87-ZM1-269-010 SHAFT,PINCH
11 87-ZM1-267-010 CAP,CAPSTAN
12 87-ZM1-263-010 HLDR,CASSET HLD L
13 87-ZM1-221-110 LEVER ASSY,DIR
14 87-ZM1-264-010 HLDR,CASSET HLD R
15 87-ZM1-601-010 HEAD ASSY, 7ZM-1
16 87-ZM1-271-010 BELT,MOT
17 87-ZM1-234-110 GEAR,PULLY
18 87-ZM1-244-010 GEAR,IDL D
19 M8-7ZS-191-000 ABL-71 YMB
20 87-ZS1-205-010 COIL,FP 7ZS1A
21 87-ZS1-209-010 PIN ASSY,7ZS1A
22 87-ZM1-243-010 GEAR,IDL C
23 87-ZS1-210-210 HLDR,7ZS1A
24 87-ZM1-248-410 FLY-WHL ASSY,L
25 80-ZM4-230-310 REAL CAP,L
26 85-ZM2-269-010 SPR-C GEAR REEL
27 80-ZM4-231-210 REAL CAP,R
28 87-ZM1-232-010 GEAR,CAM
29 87-ZM1-266-210 HLDR,DIR
30 87-ZM1-268-010 LEVER,CAM 2
31 87-ZM1-265-010 HLDR,CAM
32 87-ZM1-261-010 LEVER,SW
33 87-ZM1-250-210 FLY-WHL ASSY,R
34 87-ZM1-272-010 BELT,FLY-WHL
35 87-ZM1-260-010 LEVER,DIR OFF
36 87-ZM1-231-010 LEVER,CAM CONNECT
37 87-ZM1-207-010 SHAFT,CONTROL
38 87-ZM1-262-110 LEVER,FR CONTROL
39 87-ZM1-246-010 GEAR,CAM C
40 87-ZM1-282-110 SPR-E,CAM
41 87-ZM1-237-010 GEAR ASSY,SLIP
42 87-ZM1-241-010 GEAR,IDL A
43 87-ZM1-297-010 SH,AUTO 4
44 87-ZM1-236-110 GEAR,REEL
45 87-ZM1-217-010 LEVER ASSY,T-UP
46 87-ZM1-281-010 SPR-C,FR
47 87-ZM1-245-010 GEAR,FF/REW
48 87-ZM1-242-010 GEAR,IDL B
49 87-ZM1-330-210 CHAS ASSY,OUT-SERT P1NF
50 87-ZS1-211-010 MAGNET,PULL 7ZS1A
A 87-ZM1-273-010 S-SCREW,1.7-5
B 87-ZM1-274-010 S-SCREW,HEAD 7ZM-1
C 87-B10-136-010 W-P,1.09-3.1-0.4
D 87-B10-228-010 W-P,0.95-2-0.2
E 87-ZM1-292-010 W,1.55-2.62-0.2 SOMA LIGHT
F 87-ZM1-291-010 W-P,0.86-3-0.25
G 87-ZM1-296-010 W-L,1.15-2.6-0.188
H 87-ZS1-215-010 S-SCREW,VT+1.4-3.5 CR HL

DESCRIPTIONREF. NO. KANRI
NO.
PARTNO. KANRI
NO.
REF. NO. DESCRIPTIONPARTNO.
ACCESSORIES / PACKAGE LIST
1 8Z-HK4-922-010 IB,H(ECC) S 2000<AH>
1 8Z-HK4-923-010 IB,YHS(EC) S <YH>
1 8Z-HK4-925-010 IB,E(5L) S 2000<AE>
1 8Z-HK4-926-010 IB,E(5L) S 2000<AE>
2 87-B30-083-110 CHARGER,RB-107 E<AE>
2 87-B30-341-010 CHARGER,RB-107 H<AH>
3 87-B30-298-010 BAT,NB-5G(S)
4 87-B30-337-010 HEADPHONE,HP-M054
5 8A-HJ2-952-010 CASE,CARRYING BLK
6 8Z-HK4-090-010 BOX,BAT ASSY SIL
7 8Z-HK4-953-010 RC UNIT,RC2000P<AE>
7 8Z-HK4-954-010 RC UNIT,RC2000H<AH,YH>
- 15 -

2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:[phone]
Printed in Singapore9630469 0251431
