S E R V I C E M A N U A L

SIMPLE MANUAL

• Replace this Service Manual with ”Revision Publishing” when it is issued.

CSD-ES977

• TYPE: HR(S), HA(S)

S/M Code No. 09–995-331-6T1

COMPACT DISK STEREO RADIO

CASSETTE RECORDER

• BASIC TAPE MECHANISM :TN-51RV-240

• BASIC CD MECHANISM :KSM-213 CDM

ELECTRICAL MAIN PARTS LIST - 1

NOTE: The characters in the suffix column indicate the part usage.

HA(S) ..................XX...................................B..................

HR(S) ..................XX....................................C.................

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

C 218 87-010-400-080 0E CAP, ELECT 0.47-50V ABC.................

C 217 87-010-400-080 0E CAP, ELECT 0.47-50V ABC.................

C 229 87-010-401-080 0E CAP, ELECT 1-50V ABC.................

C 228 87-010-401-080 0E CAP, ELECT 1-50V ABC.................

C 232 87-010-213-080 0E C-CAP,S 0.015-50 B ABC.................

C 231 87-010-213-080 0E C-CAP,S 0.015-50 B ABC.................

C 238 87-010-263-080 0E CAP, ELECT 100-10V ABC.................

C 237 87-010-374-080 0E CAP, ELECT 47-10V ABC.................

C 236 87-010-544-080 0E CAP, ELECT 0.1-50V ABC.................

C 235 87-010-544-080 0E CAP, ELECT 0.1-50V ABC.................

C 234 87-010-546-080 0E CAP, ELECT 0.33-50V ABC.................

C 233 87-010-546-080 0E CAP, ELECT 0.33-50V ABC.................

C 248 87-010-404-080 0E CAP, ELECT 4.7-50V ABC.................

C 247 87-010-404-080 0E CAP, ELECT 4.7-50V ABC.................

C 246 87-010-405-080 0E CAP, ELECT 10-50V ABC.................

C 245 87-010-405-080 0E CAP, ELECT 10-50V ABC.................

C 241 87-010-405-080 0E CAP, ELECT 10-50V ABC.................

C 244 87-010-405-080 0E CAP, ELECT 10-50V ABC.................

C 242 87-010-405-080 0E CAP, ELECT 10-50V ABC.................

C 243 87-010-405-080 0E CAP, ELECT 10-50V ABC.................

C 262 87-010-402-080 0E CAP, ELECT 2.2-50V ABC.................

C 261 87-010-402-080 0E CAP, ELECT 2.2-50V ABC.................

D 281 87-A40-466-080 0E ZENER,MTZJ2.7A ABC.................

IC 203 87-A21-111-040 1C C-IC,M62495FP ABC.................

C 209 87-010-190-080 0E S CHIP F 0.01 ABC.................

C 208 87-010-402-080 0E CAP, ELECT 2.2-50V ABC.................

C 207 87-010-408-080 0E CAP, ELECT 47-50V ABC.................

C 210 87-010-190-080 0E S CHIP F 0.01 ABC.................

C 216 87-010-425-080 0E C-CAP,0.22-25 F ABC.................

C 215 87-010-425-080 0E C-CAP,0.22-25 F ABC.................

C 212 87-010-544-080 0E CAP, ELECT 0.1-50V ABC.................

C 211 87-010-544-080 0E CAP, ELECT 0.1-50V ABC.................

C 226 87-010-190-080 0E S CHIP F 0.01 ABC.................

C 223 87-010-190-080 0E S CHIP F 0.01 ABC.................

C 222 87-010-190-080 0E S CHIP F 0.01 ABC.................

C 220 87-010-405-080 0E CAP, ELECT 10-50V ABC.................

IC 201 87-A20-946-040 1D C-IC,MM1434XF ABC.................

C 251 87-010-401-080 0E CAP, ELECT 1-50V ABC.................

C 263 87-010-178-080 0E CHIP CAP 1000P ABC.................

C 264 87-010-178-080 0E CHIP CAP 1000P ABC.................

C 267 87-010-380-080 0E CAP, ELECT 47-16V ABC.................

C 268 87-010-380-080 0E CAP, ELECT 47-16V ABC.................

C 266 87-010-383-080 0E CAP, ELECT 33-25V ABC.................

C 265 87-010-383-080 0E CAP, ELECT 33-25V ABC.................

C 279 87-010-112-080 0E CAP, ELECT 100-16V ABC.................

C 272 87-010-236-010 0E ELECTROLYTIC, 1000-10 ABC.................

C 271 87-010-236-010 0E ELECTROLYTIC, 1000-10 ABC.................

C 277 87-010-260-080 0E CAP, ELECT 47-25V ABC.................

C 278 87-010-384-080 0E CAP, ELECT 100-25V ABC.................

C 274 87-010-628-080 0E CAP,E 3.3-16 M 5L BP SRE ABC.................

C 273 87-010-628-080 0E CAP,E 3.3-16 M 5L BP SRE ABC.................

C 281 87-010-401-080 0E CAP, ELECT 1-50V ABC.................

C 280 87-010-401-080 0E CAP, ELECT 1-50V ABC.................

IC 201 87-A20-591-010 1C IC,BA5417 ABC.................

J 251 87-A60-569-010 JACK,HTJ-035-18 ABC.................

Q 244 89-320-011-010 0E TR,2SC2001 (0.6W) ABC.................

Q 243 89-320-011-010 0E TR,2SC2001 (0.6W) ABC.................

C 308 87-010-221-080 0E CAP, ELECT 470-10V ABC.................

C 309 87-010-263-080 0E CAP, ELECT 100-10V ABC.................

C 307 87-010-401-080 0E CAP, ELECT 1-50V ABC.................

C 306 87-010-404-080 0E CAP, ELECT 4.7-50V ABC.................

C 301 87-010-453-010 1C CAP, ELECT 4700-25V ABC.................

C 315 87-010-197-080 0E CAP, CHIP 0.01 DM ABC.................

C 310 87-010-248-080 0E CAP, ELECT 220-10V ABC.................

C 314 87-010-248-080 0E CAP, ELECT 220-10V ABC.................

C 312 87-010-248-080 0E CAP, ELECT 220-10V ABC.................

C 311 87-010-263-080 0E CAP, ELECT 100-10V ABC.................

C 903 87-A10-577-080 CAP,CER 0.022-50 Z YF ABC.................

C 902 87-A10-577-080 CAP,CER 0.022-50 Z YF ABC.................

C 901 87-A10-577-080 CAP,CER 0.022-50 Z YF ABC.................

C 904 87-A10-577-080 CAP,CER 0.022-50 Z YF ABC.................

CN 301 87-049-919-010 0E CONN,3P EH V WHT ABC.................

D 307 87-017-148-080 0E ZENER,HZS6A1L ABC.................

D 304 87-017-162-080 ZENER,HZS7C3L ABC.................

D 309 87-020-465-080 0E DIODE,1SS133 (110MA) ABC.................

D 308 87-020-465-080 0E DIODE,1SS133 (110MA) ABC.................

D 305 87-020-465-080 0E DIODE,1SS133 (110MA) ABC.................

D 303 87-020-465-080 0E DIODE,1SS133 (110MA) ABC.................

D 306 87-020-465-080 0E DIODE,1SS133 (110MA) ABC.................

D 311 87-017-139-010 0E ZENER,HZS15-2 ABC.................

D 904 87-A40-465-010 0E DIODE,FR202 ABC.................

D 901 87-A40-465-010 0E DIODE,FR202 ABC.................

D 902 87-A40-465-010 0E DIODE,FR202 ABC.................

D 903 87-A40-465-010 0E DIODE,FR202 ABC.................

FC 902 87-033-213-010 0E CLAMP,FUSE SMK ABC.................

FC 901 87-033-213-010 0E CLAMP,FUSE SMK ABC.................

IC 310 87-070-416-010 1B IC,NJU7201 L55 ABC.................

Q 303 87-026-291-010 1A TR,DTC124XS ABC.................

Q 307 87-026-462-010 0E TR,2SC1740S ABC.................

Q 305 87-026-462-010 0E TR,2SC1740S ABC.................

Q 302 87-026-463-010 0E TR,2SA933S,RS ABC.................

Q 306 88-NF9-637-010 TR,2SA1318T/U ABC.................

Q 301 89-112-965-010 0E TR,2SA1296GR ABC.................

Q 304 89-213-702-010 1A TR,2SB1370 (1.8W) ABC.................

Q 310 87-026-462-010 0E TR,2SC1740S ABC.................

SP 901 87-CD6-213-010 SPR-C,BATT (-) ABC.................

SP 902 87-CD6-222-010 SPR-C,BATT (-) L ABC.................

C 803 87-010-177-080 0E C-CAP,S 820P-50 SL ABC.................

C 804 87-010-177-080 0E C-CAP,S 820P-50 SL ABC.................

C 802 87-010-402-080 0E CAP, ELECT 2.2-50V ABC.................

C 801 87-010-402-080 0E CAP, ELECT 2.2-50V ABC.................

C 809 87-010-406-010 0E CAP,E 22-50 SM ABC.................

C 805 87-012-158-080 0E C-CAP,S 390P-50 CH ABC.................

C 806 87-012-158-080 0E C-CAP,S 390P-50 CH ABC.................

C 815 87-010-374-010 0E CAP, ELECT 47-10V ABC.................

C 818 87-010-401-010 0E CAP, ELECT 1-50V ABC.................

C 817 87-010-401-010 0E CAP, ELECT 1-50V ABC.................

C 819 87-010-401-010 0E CAP, ELECT 1-50V ABC.................

C 813 87-010-402-080 0E CAP, ELECT 2.2-50V ABC.................

C 814 87-010-402-080 0E CAP, ELECT 2.2-50V ABC.................

C 811 87-010-404-010 0E CONDENSER 4.7-50 ABC.................

C 812 87-010-404-010 0E CONDENSER 4.7-50 ABC.................

C 810 87-010-406-010 0E CAP,E 22-50 SM ABC.................

C 823 87-010-213-080 0E C-CAP,S 0.015-50 B ABC.................

C 824 87-010-213-080 0E C-CAP,S 0.015-50 B ABC.................

C 820 87-010-401-010 0E CAP, ELECT 1-50V ABC.................

C 827 87-010-404-010 0E CONDENSER 4.7-50 ABC.................

C 828 87-010-404-010 0E CONDENSER 4.7-50 ABC.................

C 826 87-010-405-080 0E CAP, ELECT 10-50V ABC.................

C 825 87-010-405-080 0E CAP, ELECT 10-50V ABC.................

C 822 87-012-153-080 0E C-CAP,S 120P-50 CH ABC.................

C 821 87-012-153-080 0E C-CAP,S 120P-50 CH ABC.................

C 833 87-010-179-080 0E CAP,CHIP S B1200P ABC.................

C 839 87-010-186-080 0E CAP,CHIP 4700P ABC.................

C 831 87-010-198-080 0E CAP, CHIP 0.022 ABC.................

C 832 87-010-198-080 0E CAP, CHIP 0.022 ABC.................

C 834 87-010-248-080 0E CAP, ELECT 220-10V ABC.................

C 830 87-010-260-080 0E CAP, ELECT 47-25V ABC.................

C 835 87-010-374-010 0E CAP, ELECT 47-10V ABC.................

C 838 87-010-405-080 0E CAP, ELECT 10-50V ABC.................

C 845 87-010-178-080 0E CHIP CAP 1000P ABC.................

C 844 87-010-178-080 0E CHIP CAP 1000P ABC.................

C 849 87-010-184-080 0E CHIP CAPACITOR 3300P(K) ABC.................

C 840 87-010-186-080 0E CAP,CHIP 4700P ABC.................

C 843 87-010-190-080 0E S CHIP F 0.01 ABC.................

C 842 87-010-194-080 0E CAP, CHIP 0.047 ABC.................

C 841 87-010-194-080 0E CAP, CHIP 0.047 ABC.................

C 846 87-010-194-080 0E CAP, CHIP 0.047 ABC.................

C 850 87-010-184-080 0E CHIP CAPACITOR 3300P(K) ABC.................

C 851 87-010-186-080 0E CAP,CHIP 4700P ABC.................

CN 801 87-049-469-010 0E CONN,4P V ABC.................

CN 803 87-049-919-010 0E CONN,3P EH V WHT ABC.................

CN 802 87-099-186-010 0E CONN,6P EH V WHT ABC.................

D 807 87-020-465-080 0E DIODE,1SS133 (110MA) ABC.................

D 802 87-020-465-080 0E DIODE,1SS133 (110MA) ABC.................

D 805 87-020-465-080 0E DIODE,1SS133 (110MA) ABC.................

D 801 87-020-465-080 0E DIODE,1SS133 (110MA) ABC.................

D 804 87-020-465-080 0E DIODE,1SS133 (110MA) ABC.................

D 803 87-020-465-080 0E DIODE,1SS133 (110MA) ABC.................

D 808 87-020-465-080 0E DIODE,1SS133 (110MA) ABC.................

D 809 87-020-465-080 0E DIODE,1SS133 (110MA) ABC.................

D 806 87-020-465-080 0E DIODE,1SS133 (110MA) ABC.................

D 810 87-020-465-080 0E DIODE,1SS133 (110MA) ABC.................

D 841 87-070-136-080 0E ZENER,MTZJ5.1B ABC.................

IC 801 87-A21-145-040 C-IC,BA4560F-E2 ABC.................

IC 802 87-A21-145-040 C-IC,BA4560F-E2 ABC.................

L 801 87-007-342-010 0E COIL,OSC 85K BIAS ABC.................

Q 802 87-026-462-010 0E TR,2SC1740S ABC.................

Q 804 87-026-463-010 0E TR,2SA933S,RS ABC.................

Q 803 87-026-463-010 0E TR,2SA933S,RS ABC.................

Q 808 87-026-496-080 0E FET,2SJ103GR ABC.................

Q 809 87-026-496-080 0E FET,2SJ103GR ABC.................

Q 805 89-110-150-010 TR,2SA1015 ABC.................

Q 807 89-110-150-010 TR,2SA1015 ABC.................

Q 801 89-318-155-010 0E TR,2SC1815(GR) ABC.................

Q 806 89-318-155-010 0E TR,2SC1815(GR) ABC.................

Q 810 87-026-464-010 0E TR,DTC114TS ABC.................

R 840 87-029-124-010 0E RES,FUSE 2.2-1/4 ABC.................

C 299 87-010-190-080 0E S CHIP F 0.01 ABC.................

C 321 87-010-190-080 0E S CHIP F 0.01 ABC.................

C 322 87-010-263-080 0E CAP, ELECT 100-10V ABC.................

C 325 87-010-405-080 0E CAP, ELECT 10-50V ABC.................

CN 203 87-049-469-010 0E CONN,4P V ABC.................

CN 204 87-049-469-010 0E CONN,4P V ABC.................

CN 201 87-099-017-010 0E CONN, 15P 6216 V ABC.................

CN 205 87-A60-109-010 0E CONN,2P V S2M-2W ABC.................

D 32 87-027-399-080 0E ZENER,HZ7A3L (200MA) ABC.................

D 321 87-020-465-080 0E DIODE,1SS133 (110MA) ABC.................

D 323 87-020-465-080 0E DIODE,1SS133 (110MA) ABC.................

ELECTRICAL MAIN PARTS LIST - 2

D 322 87-020-465-080 0E DIODE,1SS133 (110MA) ABC.................

Q 323 87-026-291-080 1A TR,DTC124XS ABC.................

Q 322 87-026-463-080 0E TR,2SA933S (0.3W) ABC.................

Q 321 89-318-154-080 0E TR,2SC1815 (0.4W) ABC.................

C 608 87-010-196-080 0E CHIP CAPACITOR,0.1-25 ABC.................

C 609 87-010-196-080 0E CHIP CAPACITOR,0.1-25 ABC.................

C 607 87-010-197-080 0E CAP, CHIP 0.01 DM ABC.................

C 606 87-010-197-080 0E CAP, CHIP 0.01 DM ABC.................

C 601 87-010-313-080 0E CAP, CHIP 18P ABC.................

C 604 87-010-314-080 0E C-CAP,S 22P-50V ABC.................

C 602 87-010-315-080 0E C-CAP,S 27P-50 CH ABC.................

C 605 87-010-317-080 0E C-CAP,S 39P-50 CH ABC.................

C 603 87-010-317-080 0E C-CAP,S 39P-50 CH ABC.................

C 617 87-010-178-080 0E CHIP CAP 1000P ABC.................

C 614 87-010-196-080 0E CHIP CAPACITOR,0.1-25 ABC.................

C 611 87-010-196-080 0E CHIP CAPACITOR,0.1-25 ABC.................

C 615 87-010-400-080 0E CAP, ELECT 0.47-50V ABC.................

C 616 87-010-401-080 0E CAP, ELECT 1-50V ABC.................

C 613 87-010-402-080 0E CAP, ELECT 2.2-50V ABC.................

C 618 87-010-405-080 0E CAP, ELECT 10-50V ABC.................

C 612 87-010-754-010 0E CAP,E 220-10 SRA 7L ABC.................

C 610 87-015-677-040 0E CAP,E 100-6.3 7L ABC.................

CN 601 87-099-032-010 0E CONN,15P 6216 H ABC.................

CN 602 87-099-200-010 0E CONN,7P 6216H ABC.................

CN 605 87-099-202-010 0E CONN,9P 6216 H ABC.................

CN 604 87-099-202-010 0E CONN,9P 6216 H ABC.................

CN 603 87-099-209-010 0E CONN,4P 6216H ABC.................

D 602 87-020-465-080 0E DIODE,1SS133 (110MA) ABC.................

D 601 87-020-465-080 0E DIODE,1SS133 (110MA) ABC.................

D 603 87-020-465-080 0E DIODE,1SS133 (110MA) ABC.................

D 604 87-020-465-080 0E DIODE,1SS133 (110MA) ABC.................

D 614 87-020-465-080 0E DIODE,1SS133 (110MA) ABC.................

D 612 87-020-465-080 0E DIODE,1SS133 (110MA) ABC.................

D 611 87-020-465-080 0E DIODE,1SS133 (110MA) ABC.................

IC 602 87-A21-245-010 IC,RPM6938-V4 ABC.................

IC 601 8Z-CH4-636-010 2A IC,LC867132V-**** ABC.................

L 601 87-003-171-010 0E COIL,15UH TROIDAL ABC.................

LCD 601 8Z-CH4-635-010 LCD,HLC7365 ZCH-4 ABC.................

LED 601 88-CD6-630-010 LED,934ID RED ABC.................

LED 608 88-CD6-630-010 LED,934ID RED ABC.................

LED 605 88-CD6-630-010 LED,934ID RED ABC.................

LED 607 88-CD6-630-010 LED,934ID RED ABC.................

LED 609 88-CD6-630-010 LED,934ID RED ABC.................

LED 606 88-CD6-630-010 LED,934ID RED ABC.................

LED 613 88-CD6-630-010 LED,934ID RED ABC.................

LED 611 88-CD6-630-010 LED,934ID RED ABC.................

LED 612 88-CD6-630-010 LED,934ID RED ABC.................

LED 610 88-CD6-631-010 LED,934GD GRN ABC.................

Q 602 87-026-463-010 0E TR,2SA933S,RS ABC.................

Q 605 87-026-464-010 0E TR,DTC114TS ABC.................

Q 604 87-026-464-010 0E TR,DTC114TS ABC.................

Q 609 87-026-464-010 0E TR,DTC114TS ABC.................

Q 607 87-026-464-010 0E TR,DTC114TS ABC.................

Q 606 87-026-464-010 0E TR,DTC114TS ABC.................

Q 608 87-026-464-010 0E TR,DTC114TS ABC.................

Q 610 87-026-464-010 0E TR,DTC114TS ABC.................

Q 611 87-026-464-010 0E TR,DTC114TS ABC.................

Q 646 87-026-291-010 1A TR,DTC124XS ABC.................

S 601 87-A90-696-080 0E SW,TACT TS2103-03-430 ABC.................

S 604 87-A90-696-080 0E SW,TACT TS2103-03-430 ABC.................

S 608 87-A90-696-080 0E SW,TACT TS2103-03-430 ABC.................

S 607 87-A90-696-080 0E SW,TACT TS2103-03-430 ABC.................

S 605 87-A90-696-080 0E SW,TACT TS2103-03-430 ABC.................

S 606 87-A90-696-080 0E SW,TACT TS2103-03-430 ABC.................

S 609 87-A90-696-080 0E SW,TACT TS2103-03-430 ABC.................

S 613 87-A90-696-080 0E SW,TACT TS2103-03-430 ABC.................

S 612 87-A90-696-080 0E SW,TACT TS2103-03-430 ABC.................

S 614 87-A90-696-080 0E SW,TACT TS2103-03-430 ABC.................

S 611 87-A90-696-080 0E SW,TACT TS2103-03-430 ABC.................

S 610 87-A90-696-080 0E SW,TACT TS2103-03-430 ABC.................

S 615 87-A90-696-080 0E SW,TACT TS2103-03-430 ABC.................

X 602 87-030-273-010 1A VIB,XTAL 32.768K5PPM ABC.................

X 601 87-A70-070-080 1A VIB,CER 5.76MHZ CRHF ABC.................

C 400 87-010-178-080 0E CHIP CAP 1000P ABC.................

C 407 87-010-178-080 0E CHIP CAP 1000P ABC.................

C 405 87-010-197-080 0E CAP, CHIP 0.01 DM ABC.................

C 402 87-010-197-080 0E CAP, CHIP 0.01 DM ABC.................

C 409 87-010-248-080 0E CAP, ELECT 220-10V ABC.................

C 404 87-010-248-080 0E CAP, ELECT 220-10V ABC.................

C 403 87-010-263-080 0E CAP, ELECT 100-10V ABC.................

C 406 87-010-374-080 0E CAP, ELECT 47-10V ABC.................

C 401 87-010-403-080 0E CAP, ELECT 3.3-50V ABC.................

C 413 87-010-197-080 0E CAP, CHIP 0.01 DM ABC.................

C 410 87-010-263-080 0E CAP, ELECT 100-10V ABC.................

C 412 87-010-401-080 0E CAP, ELECT 1-50V ABC.................

C 414 87-010-405-080 0E CAP, ELECT 10-50V ABC.................

C 416 87-010-545-080 0E CAP, ELECT 0.22-50V ABC.................

C 417 87-012-157-080 0E C-CAP,S 330P-50 CH ABC.................

C 425 87-010-176-080 0E C-CAP,S 680P-50 SL ABC.................

C 429 87-010-186-080 0E CAP,CHIP 4700P ABC.................

C 439 87-010-178-080 0E CHIP CAP 1000P ABC.................

C 438 87-010-196-080 0E CHIP CAPACITOR,0.1-25 ABC.................

C 435 87-010-197-080 0E CAP, CHIP 0.01 DM ABC.................

ELECTRICAL MAIN PARTS LIST - 3

C 432 87-010-374-080 0E CAP, ELECT 47-10V ABC.................

C 436 87-010-374-080 0E CAP, ELECT 47-10V ABC.................

C 433 87-010-401-080 0E CAP, ELECT 1-50V ABC.................

C 437 87-010-404-080 0E CAP, ELECT 4.7-50V ABC.................

C 431 87-010-545-080 0E CAP, ELECT 0.22-50V ABC.................

C 430 87-012-156-080 0E C-CAP,S 220P-50 CH ABC.................

C 440 87-010-147-080 0E C-CAP,S 3P-50 CH ABC.................

C 445 87-010-196-080 0E CHIP CAPACITOR,0.1-25 ABC.................

C 447 87-010-196-080 0E CHIP CAPACITOR,0.1-25 ABC.................

C 446 87-010-196-080 0E CHIP CAPACITOR,0.1-25 ABC.................

C 442 87-010-313-080 0E CAP, CHIP 18P ABC.................

C 448 87-010-315-080 0E C-CAP,S 27P-50 CH ABC.................

C 459 87-010-263-080 0E CAP, ELECT 100-10V ABC.................

C 458 87-010-312-080 0E C-CAP,S 15P-50 CH ABC.................

C 457 87-010-312-080 0E C-CAP,S 15P-50 CH ABC.................

C 457 87-010-316-080 0E C-CAP,S 33P-50 CH ....................

C 458 87-010-316-080 0E C-CAP,S 33P-50 CH ....................

C 450 87-012-140-080 0E CAP 470P ABC.................

C 463 87-010-184-080 0E CHIP CAPACITOR 3300P(K) ABC.................

C 460 87-010-196-080 0E CHIP CAPACITOR,0.1-25 ABC.................

C 468 87-010-196-080 0E CHIP CAPACITOR,0.1-25 ABC.................

C 466 87-010-196-080 0E CHIP CAPACITOR,0.1-25 ABC.................

C 461 87-010-196-080 0E CHIP CAPACITOR,0.1-25 ABC.................

C 463 87-010-197-080 0E CAP, CHIP 0.01 DM ABC.................

C 467 87-010-263-080 0E CAP, ELECT 100-10V ABC.................

C 462 87-010-370-080 0E CAP,E 330-6.3 SME ABC.................

C 465 87-010-404-080 0E CAP, ELECT 4.7-50V ABC.................

C 469 87-012-154-080 0E C-CAP,S 150P-50 CH ABC.................

C 472 87-010-196-080 0E CHIP CAPACITOR,0.1-25 ABC.................

C 474 87-010-196-080 0E CHIP CAPACITOR,0.1-25 ABC.................

C 473 87-010-196-080 0E CHIP CAPACITOR,0.1-25 ABC.................

C 471 87-010-196-080 0E CHIP CAPACITOR,0.1-25 ABC.................

C 475 87-010-197-080 0E CAP, CHIP 0.01 DM ABC.................

C 477 87-010-197-080 0E CAP, CHIP 0.01 DM ABC.................

C 479 87-010-197-080 0E CAP, CHIP 0.01 DM ABC.................

C 476 87-010-236-080 0E CAP,E 1000-10 SME ABC.................

C 478 87-010-263-080 0E CAP, ELECT 100-10V ABC.................

C 489 87-010-196-080 0E CHIP CAPACITOR,0.1-25 ABC.................

C 480 87-010-221-080 0E CAP, ELECT 470-10V ABC.................

C 481 87-010-405-080 0E CAP, ELECT 10-50V ABC.................

C 482 87-010-405-080 0E CAP, ELECT 10-50V ABC.................

C 483 87-012-156-080 0E C-CAP,S 220P-50 CH ABC.................

C 484 87-012-156-080 0E C-CAP,S 220P-50 CH ABC.................

C 490 87-010-196-080 0E CHIP CAPACITOR,0.1-25 ABC.................

C 493 87-010-322-080 0E C-CAP,S 100P-50 CH ABC.................

C 495 87-010-322-080 0E C-CAP,S 100P-50 CH ABC.................

C 496 87-010-322-080 0E C-CAP,S 100P-50 CH ABC.................

C 497 87-010-322-080 0E C-CAP,S 100P-50 CH ABC.................

C 498 87-010-322-080 0E C-CAP,S 100P-50 CH ABC.................

C 499 87-010-322-080 0E C-CAP,S 100P-50 CH ABC.................

CN 403 87-099-195-010 0E CONN,7P 6216 V ABC.................

CN 401 87-A60-424-010 0E CONN,16P V TOC-B ABC.................

D 402 87-020-465-080 0E DIODE,1SS133 (110MA) ABC.................

D 401 87-020-465-080 0E DIODE,1SS133 (110MA) ABC.................

D 403 87-020-465-080 0E DIODE,1SS133 (110MA) ABC.................

D 494 87-020-465-080 0E DIODE,1SS133 (110MA) ABC.................

D 491 87-020-465-080 0E DIODE,1SS133 (110MA) ABC.................

IC 401 87-A20-446-010 1E C-IC,LA9241ML ABC.................

IC 402 87-A20-459-010 2A C-IC,LC78622ED ABC.................

IC 404 87-A21-093-010 1C IC,LA6541D ABC.................

L 401 87-003-102-080 0E COIL, 10UH ABC.................

L 402 87-005-847-080 0E COIL,2.2UH(CECS) ABC.................

L 406 87-005-847-080 0E COIL,2.2UH(CECS) ABC.................

L 403 87-008-372-010 0E FILTER, EMI BL OIRNI ABC.................

L 405 87-008-372-010 0E FILTER, EMI BL OIRNI ABC.................

L 404 87-008-372-010 0E FILTER, EMI BL OIRNI ABC.................

Q 403 87-026-502-080 0E DTC144TS ABC.................

Q 402 89-113-184-080 0E TR,2SA1318T ABC.................

SFR 401 87-024-437-080 0E SFR100K,RH063EC ABC.................

X 401 87-A70-046-010 1B VIB,XTAL 16.934MHZ ....................

X 401 8Z-CD5-633-010 VIB, CER16.93MHZ FCR16.93M2 ABC.................

C 491 87-010-197-080 0E CAP, CHIP 0.01 DM ABC.................

C 492 87-010-221-080 0E CAP, ELECT 470-10V ABC.................

D 494 87-020-465-080 0E DIODE,1SS133 (110MA) ABC.................

D 491 87-020-465-080 0E DIODE,1SS133 (110MA) ABC.................

D 492 87-020-465-080 0E DIODE,1SS133 (110MA) ABC.................

Q 401 87-026-463-080 0E TR,2SA933S (0.3W) ABC.................

Q 492 87-026-291-080 1A TR,DTC124XS ABC.................

Q 491 89-112-965-080 0E TR,2SA1296 (0.75W) ABC.................

84-ZG1-244-310 1A CABI,OPTICAL ....................

84-ZG1-245-210 0E CAP,OPTICAL ....................

C 485 87-010-263-080 0E CAP, ELECT 100-10V ....................

C 486 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 ....................

D 460 87-A40-558-010 0E LED,SLZ-8128A-01-A ....................

Q 462 87-026-462-080 0E TR,2SC1740 S(RS 0.3W) ....................

Q 461 87-026-462-080 0E TR,2SC1740 S(RS 0.3W) ....................

C 6 87-010-378-080 0E CAP, ELECT 10-16V ABC.................

C 8 87-018-132-080 0E CAP, CER 2200P-16V ABC.................

C 9 87-018-147-080 0E CAP,TC-U 10P-50 CH ABC.................

C 9 87-018-161-080 0E TC CAP 12P ....................

C 7 87-018-208-080 0E CAP 0.047-50F ABC.................

C 3 87-A11-073-080 0E CAP,TC U 22P-50 J CH ABC.................

C 1 87-A11-073-080 0E CAP,TC U 22P-50 J CH ABC.................

ELECTRICAL MAIN PARTS LIST - 4

C 2 87-A11-076-080 0E CAP,TC U 33P-50 J CH ABC.................

C 3 87-A11-078-080 0E CAP,TC U 39P-50 J CH ....................

C 2 87-A11-080-080 0E CAP,TC U 47P-50 J CH ....................

C 14 87-010-400-080 0E CAP, ELECT 0.47-50V ABC.................

C 17 87-010-544-080 0E CAP, ELECT 0.1-50V ABC.................

C 19 87-010-544-080 0E CAP, ELECT 0.1-50V ABC.................

C 16 87-018-131-080 0E CAP, CER 1000P-50V ABC.................

C 15 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 ABC.................

C 10 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 ABC.................

C 13 87-018-142-080 0E CAP,TC-U 3.9P-50 CH ABC.................

C 11 87-018-147-080 0E CAP,TC-U 10P-50 CH ....................

C 18 87-018-205-080 0E CAP, CERA-SOL 0.022 ABC.................

C 12 87-A11-073-080 0E CAP,TC U 22P-50 J CH ABC.................

C 20 87-010-400-080 0E CAP, ELECT 0.47-50V ABC.................

C 21 87-010-403-080 0E CAP, ELECT 3.3-50V ABC.................

C 27 87-010-545-080 0E CAP, ELECT 0.22-50V ABC.................

C 26 87-010-545-080 0E CAP, ELECT 0.22-50V ABC.................

C 22 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 ABC.................

C 25 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 ABC.................

C 24 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 ABC.................

C 28 87-018-208-080 0E CAP 0.047-50F ABC.................

C 29 87-018-208-080 0E CAP 0.047-50F ABC.................

C 30 87-010-248-080 0E CAP, ELECT 220-10V ABC.................

C 31 87-010-379-080 0E CAP, ELECT 22-16V ABC.................

C 37 87-018-122-080 0E CAP 180P-50 B ABC.................

C 33 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 ABC.................

C 34 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 ABC.................

C 32 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 ABC.................

C 38 87-A11-080-080 0E CAP,TC U 47P-50 J CH ABC.................

C 38 87-A11-086-080 0E CAP,TC U 82P-50 J CH ....................

C 46 87-012-275-080 0E C-CAP,U 1200P-50 B ....................

C 45 87-012-277-080 0E C-CAP, U 1800P-50 B ....................

C 44 87-018-124-080 0E CAP, CER 270P-50V ....................

C 41 87-018-147-080 0E CAP,TC-U 10P-50 CH ....................

CF 3 82-785-747-080 1A CF,MS2 GHY,R ABC.................

CF 2 82-785-747-080 1A CF,MS2 GHY,R ABC.................

CF 1 87-A90-128-010 0E FLTR,AM IF CFAL-455 ABC.................

D 2 87-020-465-080 0E DIODE,1SS133 (110MA) ABC.................

D 1 87-020-465-080 0E DIODE,1SS133 (110MA) ABC.................

D 4 87-020-465-080 0E DIODE,1SS133 (110MA) ABC.................

D 3 87-A40-226-080 0E VARI-CAP,SVC251SPA ABC.................

IC 1 87-A20-955-010 1C IC,LA1828 ABC.................

L 9 87-A50-334-010 1A COIL,FM DET (TOKO) ABC.................

L 8 87-A50-335-010 1A COIL,FM IFT (TOKO) ABC.................

L 7 87-A50-336-010 1A COIL,AM IFT (TOKO) ABC.................

L 6 87-A50-337-010 1A COIL,AM OSC (TOKO) ABC.................

L 5 87-A50-342-010 0E COIL,FM OSC D ....................

L 5 87-A50-343-010 0E COIL,FM OSC EX ABC.................

L 4 87-A50-345-010 0E COIL,FM RF EX ABC.................

L 2 87-A50-346-010 0E COIL,FM BPF D ....................

L 2 87-A50-347-010 0E COIL,FM BPF EX ABC.................

L 3 87-A50-349-010 COIL,BAR ANT AMW (COI) .B..................

L 3 87-A50-350-010 COIL,BAR ANT AMN (COI) A.C.................

L 6 87-A50-463-010 COIL,AM OSC HE(TOKO) ....................

L 3 87-A50-464-010 COIL,BAR ANT MW HE 71T:17T ....................

L 10 87-003-102-080 0E COIL, 10UH ABC.................

L 17 87-A50-340-010 COIL,SW OSC (TOKO) ....................

L 11 87-A50-341-010 COIL,SW ANT (TOKO) ....................

L 41 87-003-143-080 0E COIL 4.7 UH ....................

Q 3 87-026-215-080 0E TR,DTC114YS ABC.................

Q 2 87-026-572-080 0E TR,DTA114TS ABC.................

Q 4 89-109-521-080 0E TR,2SA952 (0.6W) ....................

Q 1 89-319-233-080 0E TR,2SC1923 (0.1W) ABC.................

SW 1 8Z-CD9-607-010 SW,SL 2-4-3 SK43D01G4 ....................

SW 1 8Z-CD9-640-010 SW,SL 2-4-2 SK42H01G4 ABC.................

TC 5 87-011-218-080 1A CAP,TRIMER 6P VCT ....................

TC 6 87-011-219-080 1A CAP, TRIMMER 10P ....................

VC 1 87-A91-167-010 TUN-CAP,20P-160P FA-22125 N000 .B..................

VC 1 87-A91-168-010 1C TUN-CAP,20P-140P FA-22124 N000 A.C.................

VC 1 87-A91-169-010 1D TUN-CAP,40P-140P FA-22124 AN00 ....................

VC 1 87-A91-170-010 TUN-CAP,20P-335P FA-2217 N000- ....................

ELECTRICAL MAIN PARTS LIST - 5

NOTE: The characters in the suffix column indicate the part usage.

HA(S) ..................XX...................................B..................

HR(S) ..................XX....................................C.................

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

84-CD5-024-010 0E BADGE,AIWA 30N ABC.................

88-CH6-019-010 PANEL,CD ABC.................

8Z-CD5-002-010 CABI,REAR D ....................

8Z-CD5-003-010 BOX,CASS ABC.................

8Z-CD5-005-010 CHAS,CD ABC.................

8Z-CD5-007-010 WINDOW,LCD D ....................

8Z-CD5-009-010 CABI,REAR EX ABC.................

8Z-CD5-013-010 WINDOW,CD ABC.................

8Z-CD5-014-010 WINDOW,TU D ....................

8Z-CD5-016-010 PANEL,LCD 51 D ....................

8Z-CD5-020-010 CABI,TOP L2 ABC.................

8Z-CD5-021-010 CABI,TOP R2 ABC.................

8Z-CD5-026-010 LID,BATT ABC.................

8Z-CD5-027-010 HANDL,ARM ABC.................

8Z-CD5-028-010 HANDL,GRIP ABC.................

8Z-CD5-037-010 POINTER,TU ABC.................

8Z-CD5-045-010 WINDOW,TU U .B..................

8Z-CD5-047-010 PANEL,LCD 51 ABC.................

8Z-CD5-054-010 CABI,FR D 51 ....................

8Z-CD5-057-010 CABI,FR HEJ 51 ....................

8Z-CD5-060-010 BOX,CD LCD 25 ABC.................

8Z-CD5-062-010 WINDOW,CASS 51 ABC.................

8Z-CD5-063-010 WINDOW,LCD A.C.................

8Z-CD5-064-010 WINDOW,LCD LH .B..................

8Z-CD5-065-010 WINDOW,TU HRJ A.C.................

8Z-CD5-066-010 WINDOW,TU HEJ ....................

8Z-CD5-069-010 WINDOW,FR 51 D ....................

8Z-CD5-070-010 WINDOW,FR 51 ABC.................

8Z-CD5-075-010 CABI,FR LH 51 ABC.................

8Z-CD5-090-010 GRILLE,FR L 25 ABC.................

8Z-CD5-091-010 GRILLE,FR R 25 ABC.................

8Z-CD5-094-010 GRILLE,TOP L 25 ABC.................

8Z-CD5-095-010 GRILLE,TOP R 25 ABC.................

8Z-CD5-030-010 KEY,CASS 51 ABC.................

8Z-CD5-031-010 BTN,FUNC D ....................

8Z-CD5-032-010 BTN,VOL ABC.................

8Z-CD5-033-010 BTN,CONTROL ABC.................

8Z-CD5-034-010 BTN,EQ D ....................

8Z-CD5-035-010 KNOB,SL BAND ABC.................

8Z-CD5-036-010 KNOB,RTRY TU ABC.................

8Z-CD5-049-010 BTN,FUNC EX ABC.................

8Z-CD5-050-010 BTN,EQ EX ABC.................

87-CD6-041-010 PLATE,AC ....................

87-CD6-042-010 PLATE,SL ABC.................

84-CD5-215-010 0E GEAR ABC.................

84-CD5-216-010 0E BRACKET ABC.................

84-CD5-217-010 PLATE,MAGNET ABC.................

85-CD7-217-010 HLDR,CHUCK A ABC.................

86-CT4-218-010 0E CUSHION,FOOT/PORON ABC.................

87-036-368-010 0E MAGNET ABC.................

87-A91-151-010 SW,LEAF 1P2T/TC48-021 ABC.................

87-CD6-214-010 SPR-C,BATT LINK ABC.................

87-CD6-223-010 SPR-C,BATT LINK L ABC.................

88-CH6-207-010 HLDR,ANT ABC.................

8Z-CD5-201-010 HLDR,LCD ABC.................

8Z-CD5-203-010 HLDR,BAND ABC.................

8Z-CD5-204-010 SPR-T,CASS ABC.................

8Z-CD5-205-010 SPR-T,CD ABC.................

8Z-CD5-207-010 GEAR,A ABC.................

8Z-CD5-208-010 GEAR,B ABC.................

8Z-CD5-209-010 DRUM,TU ABC.................

8Z-CD5-210-010 COVER, TU ABC.................

8Z-CD5-213-010 HLDR,OIL-DMPR ABC.................

8Z-CH4-204-010 HLDR,SPEAKER ABC.................

8Z-CH4-208-010 HLDR,PWB ABC.................

8Z-CH4-209-010 HLDR,PT ABC.................

8Z-CH4-211-010 BASE,CHUCK ABC.................

8Z-CH4-212-010 RING,CHUCK ABC.................

8Z-CH4-215-010 HLDR,REC-SW 51 ABC.................

* 8Z-CD5-202-010 GUIDE,LED 1 ABC.................

* 8Z-CD5-212-010 GUIDE,LED 2 ABC.................

87-067-566-010 0E TAPPING SCREW, VFTT+3-6 ABC.................

87-254-097-410 0E U+3-12 CR ABC.................

87-261-037-410 0E V+2-10 GLD ABC.................

87-342-074-010 0E UT2+2.6-8 ABC.................

87-353-076-210 0E VT2+2.6-12 ABC.................

87-501-073-410 0E VF+2.6-6 ABC.................

87-571-032-410 0E VIT+2-3 ABC.................

87-641-096-410 0E UT1+3-10 GLD ABC.................

87-644-096-410 UT1+3-10 CR ABC.................

87-661-097-410 0E TAPPING SCREW, VFT1+3-12 ABC.................

87-721-095-410 0E QT2+3-8GLD W/O SLOT ABC.................

87-741-095-410 0E UT2+3-8 GLD ABC.................

87-741-097-410 0E UT2+3-12 ABC.................

87-751-094-410 0E VT2+3-6 W10SL0T ABC.................

MECHANICAL PARTS LIST - 1

* 87-B10-242-010 UT2+3-30 W/O CR ABC.................

87-035-347-010 FUSE,2.5A 250V T ABC.................

87-036-389-010 1B SW,PUSH LOCK ABC.................

87-A60-178-010 JACK,AC E W/SW ABC.................

87-A60-179-010 1A JACK,AC D W/SW ....................

87-A91-302-010 1C SW,AC SL 2 2 2 SDKGA40100 ABC.................

88-CH6-625-010 PT,D ....................

88-CH6-628-010 PT,H ABC.................

8Z-CH4-618-010 FF-CABLE, 16P CD-RF ABC.................

8Z-CH4-621-010 FF-CABLE, 7P CD-FR ABC.................

8Z-CH4-640-010 ANT,ROD ABC.................

8Z-CH4-645-010 SPKR,MAYLOR 8OHM SILVER ABC.................

CN 402 8Z-CH4-614-010 CONN ASSY,6P CD-ME ABC.................

CNA 0 8Z-CH4-612-010 CONN ASSY,6P TA-MEREV ABC.................

SP 0 88-CD5-602-010 SPKR 4’3.2 ABC.................

W 0 8Z-CD5-601-010 FF-CABLE, 15P AF-FR ABC.................

W 0 8Z-CD5-602-010 FF-CABLE, 9P LED-FR ABC.................

W 0 8Z-CD5-603-010 FF-CABLE, 4P TU-FR ABC.................

84-ZG1-244-310 1A CABI,OPTICAL ....................

84-ZG1-245-210 0E CAP,OPTICAL ....................

MECHANICAL PARTS LIST - 2

ACCESSORIES LIST

NOTE: The characters in the suffix column indicate the part usage.

HA(S) ..................XX...................................B..................

HR(S) ..................XX....................................C.................

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

8Z-CD5-907-010 IB,H(ECA)B A.C.................

8Z-CDS-901-010 IB,D(J)B ....................

8Z-CDS-906-010 IB,LH(ESP)B .B..................

87-A80-033-010 1C AC CORD SET,D BLK ....................

87-A80-036-010 AC CORD SET ASSY,E W/FLTR VOL A.C.................

87-A80-119-010 1C AC CORD SET ASSY,AZ .B..................

87-A90-312-010 PLUG,CONVERSION WTN-1157R1 A.C.................

8Z-CDK-961-010 1H RC UNIT,RC-ZAT01(VS) ....................

8Z-CDK-962-010 1H RC UNIT,RC-ZAT02(VS) ABC.................

Printed in Singapore

Tokyo Japan

931196

Other manuals for CSD-ES977

Table of contents

Popular Cassette Player manuals by other brands

Ahuja

Ahuja CPA-360 Operation manual

Sony

Sony Pressman TCS-60DV Specifications

Philips

Philips AQ6485/14 Product information

Sony

Sony TCM-200DV - Cassette Recorder operating instructions

Nakamichi

Nakamichi BX-300 Service manual

Panasonic

Panasonic RQ-E25V operating instructions

Yamaha

Yamaha MT8X Operation manual

Sherwood

Sherwood Newcastle D-480 operating instructions

Manta

Manta MA408 user manual

GPO

GPO W0162B user guide

Marantz

Marantz CP230 Service manual

Sony

Sony HST-471 Service manual

Sharp

Sharp JC-AV1 Operation manual

Pioneer

Pioneer CT-W103 Service manual

Sony

Sony CFS-B15 - Am/fm Stereo Cassette Recorder operating instructions

Sony

Sony WMFS220 - Portable Sports AM/FM Cassette... operating instructions

Sanyo

Sanyo MCD-ZX700F Service manual

Sony

Sony Pressman TCM-465V operating instructions

Aiwa CSD-ES977 User manual

Popular Cassette Player manuals by other brands
