S E R V I C E M A N U A L

SIMPLE MANUAL

•Replace this Service Manual with ”Revision Publishing” when it is issued.

HS-JS479

•TYPE:YU,YH1,YJ1

S/M Code No. 09–992–410–4T1

STEREO RADIO CASSETTE RECORDER

HSJS479co.p65 25-Feb-99, 11:42 AM1

ELECTRICAL MAIN PARTS LIST-1/3

NOTE: The characters in the suffix column indicate the part usage.

YJ1 ....................XX..................................A...................

YU .....................XX...................................B..................

YH1 ....................XX....................................C.................

KANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

C 2 87-010-178-080 CHIP CAP 1000P ABC.................

C 1 87-010-178-080 CHIP CAP 1000P ABC.................

C 8 87-010-186-080 CAP,CHIP 4700P ABC.................

C 7 87-010-186-080 CAP,CHIP 4700P ABC.................

C 9 87-010-197-080 CAP, CHIP 0.01 DM ABC.................

C 5 87-010-322-080 C-CAP,S 100P-50 CH ABC.................

C 6 87-010-322-080 C-CAP,S 100P-50 CH ABC.................

C 4 87-016-462-080 C-CAP,S 1-16 F ABC.................

C 3 87-016-462-080 C-CAP,S 1-16 F ABC.................

C 10 87-010-197-080 CAP, CHIP 0.01 DM ABC.................

C 16 87-010-198-080 CAP, CHIP 0.022 ABC.................

C 15 87-010-198-080 CAP, CHIP 0.022 ABC.................

C 13 87-010-220-080 C-CAP,S 0.018-25 B ABC.................

C 14 87-010-220-080 C-CAP,S 0.018-25 B ABC.................

C 18 87-016-462-080 C-CAP,S 1-16 F ABC.................

C 17 87-016-462-080 C-CAP,S 1-16 F ABC.................

C 19 87-016-462-080 C-CAP,S 1-16 F ABC.................

C 12 87-A10-418-080 C-CAP,TN 22-4 A TCF ABC.................

C 11 87-A10-418-080 C-CAP,TN 22-4 A TCF ABC.................

C 28 87-010-503-040 CAP,E 220-4 GAS ABC.................

C 25 87-010-589-040 CAP,E 330-2 ABC.................

C 21 87-016-462-080 C-CAP,S 1-16 F ABC.................

C 22 87-016-462-080 C-CAP,S 1-16 F ABC.................

C 20 87-016-462-080 C-CAP,S 1-16 F ABC.................

C 24 87-016-462-080 C-CAP,S 1-16 F ABC.................

C 23 87-016-462-080 C-CAP,S 1-16 F ABC.................

C 26 87-016-526-080 C-CAP,S 0.47-16 BK ABC.................

C 29 87-A10-419-080 C-CAP,TN 1-16 A TCF ABC.................

C 36 87-010-178-080 CHIP CAP 1000P ABC.................

C 35 87-010-181-080 CAP,CHIP S 1800P ABC.................

C 34 87-010-181-080 CAP,CHIP S 1800P ABC.................

C 32 87-010-501-040 E/CAP GAS 47-4 ABC.................

C 31 87-010-587-040 E,CAP 100-2 ABC.................

C 37 87-012-140-080 CAP 470P ABC.................

C 30 87-A10-419-080 C-CAP,TN 1-16 A TCF ABC.................

C 33 87-A10-422-080 C-CAP,TN 10-4 A TCF ABC.................

D 4 87-020-027-080 CHIP-DIODE 1SS184 ABC.................

D 2 87-020-027-080 CHIP-DIODE 1SS184 ABC.................

D 3 87-020-339-080 CHIP DIODE,1SS226 ABC.................

D 1 87-A40-360-080 C-DIODE,MA786 ABC.................

IC 1 87-001-943-080 IC,TA8155F ABC.................

J 2 85-HRL-623-010 JACK,3.5 ST BLK ABC.................

J 1 85-HRL-623-010 JACK,3.5 ST BLK ABC.................

J 3 87-A60-122-010 JACK,DC 3.8 ABC.................

L 2 87-003-089-010 CHOKE COIL ABC.................

L 1 87-A50-167-010 COIL,RF CHOKE3.0UH ABC.................

Q 9 87-026-261-080 CHIP-TR,RN1404 ABC.................

Q 4 87-026-262-080 C-TR,RN1407 ABC.................

Q 2 87-026-263-080 C-TR,RN1410 ABC.................

Q 3 87-026-263-080 C-TR,RN1410 ABC.................

Q 1 89-113-625-080 TR,2SA1362GR(120MHZ,0. ABC.................

Q 6 89-502-094-040 C-FET,2SK209Y ABC.................

Q 5 89-502-094-040 C-FET,2SK209Y ABC.................

Q 8 89-502-094-040 C-FET,2SK209Y ABC.................

Q 7 89-502-094-040 C-FET,2SK209Y ABC.................

Q 10 87-026-261-080 CHIP-TR,RN1404 ABC.................

SFR 2 87-A90-789-080 C-SFR,470 RH03AXA12X ABC.................

SFR 1 87-A90-789-080 C-SFR,470 RH03AXA12X ABC.................

SW 4 87-036-123-010 C-SWITCH SLIDE 1-1-2 ABC.................

SW 6 87-A90-422-010 SW,SL 2-2-2 ABC.................

SW 1 87-A90-423-010 SW,LEAF ABC.................

VR 1 87-A90-479-010 VR,RTRY 20KAX2 ABC.................

C 352 87-010-186-080 CAP,CHIP 4700P ABC.................

C 351 87-010-186-080 CAP,CHIP 4700P ABC.................

C 353 87-010-193-080 CHIP CAPACITOR,0.033 ABC.................

C 358 87-010-193-080 CHIP CAPACITOR,0.033 ABC.................

C 354 87-010-193-080 CHIP CAPACITOR,0.033 ABC.................

C 357 87-010-193-080 CHIP CAPACITOR,0.033 ABC.................

C 359 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 355 87-010-197-080 CAP, CHIP 0.01 DM ABC.................

C 356 87-010-197-080 CAP, CHIP 0.01 DM ABC.................

C 360 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 361 87-010-820-040 CAP,E 47-4 (MJ) ABC.................

IC 351 87-001-934-080 IC,BA1106F- ABC.................

Q 352 87-026-263-080 C-TR,RN1410 ABC.................

Q 351 87-026-263-080 C-TR,RN1410 ABC.................

SW 351 87-A90-050-010 SW, SL 2-2-2 NS (BLK) ABC.................

C 315 87-010-820-040 CAP,E 47-4 (MJ) A...................

C 501 87-010-196-080 CHIP CAPACITOR,0.1-25 ....................

C 502 87-010-820-040 CAP,E 47-4 (MJ) ABC.................

C 503 87-016-462-080 C-CAP,S 1-16 F ABC.................

D 501 87-020-339-080 CHIP DIODE,1SS226 ABC.................

Q 503 89-327-125-080 CHIP TR,2SC2712GR ABC.................

Q 501 89-327-125-080 CHIP TR,2SC2712GR ABC.................

HSJS479co.p65 25-Feb-99, 11:42 AM2

ELECTRICAL MAIN PARTS LIST-2/3

Q 502 89-327-125-080 CHIP TR,2SC2712GR ABC.................

SW 501 87-036-145-080 CHIP SWITCH SLIDE 1-1-3 ....................

C 655 87-010-178-080 CHIP CAP 1000P ABC.................

C 652 87-010-180-080 C-CER 1500P ABC.................

C 651 87-010-180-080 C-CER 1500P ABC.................

C 657 87-010-322-080 C-CAP,S 100P-50 CH ABC.................

C 659 87-010-503-040 CAP,E 220-4 GAS ABC.................

C 658 87-010-503-040 CAP,E 220-4 GAS ABC.................

C 656 87-010-819-040 CAP,E 33-4 M MJ ABC.................

C 654 87-016-669-080 C-CAP,S 0.1-25 K B ABC.................

C 653 87-016-669-080 C-CAP,S 0.1-25 K B ABC.................

C 660 87-010-820-040 CAP,E 47-4 (MJ) ABC.................

IC 651 87-001-371-080 IC,LA4533M ABC.................

C 58 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 54 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 57 87-010-502-040 CAP ELECT GAS 100/4 ABC.................

C 56 87-010-992-080 C-CAP,S 0.047-25 B ABC.................

C 55 87-016-526-080 C-CAP,S 0.47-16 BK ABC.................

C 59 87-016-669-080 C-CAP,S 0.1-25 K B ABC.................

C 53 87-016-669-080 C-CAP,S 0.1-25 K B ABC.................

C 51 87-A10-201-080 C-CAP,S0.33-16 KB ABC.................

C 60 87-016-669-080 C-CAP,S 0.1-25 K B ABC.................

C 61 87-016-669-080 C-CAP,S 0.1-25 K B ABC.................

IC 51 87-A20-532-040 IC,LB1977M ABC.................

SFR 51 87-A90-734-080 C-SFR,33K B RH03AXAN4X ABC.................

SW 51 87-036-123-010 C-SWITCH SLIDE 1-1-2 ABC.................

TH 51 87-A90-542-080 C-THMS,NTH5G2M35A472K04TE ABC.................

C 704 87-010-178-080 CHIP CAP 1000P ABC.................

C 707 87-010-184-080 CHIP CAPACITOR 3300P(K) ABC.................

C 706 87-010-197-080 CAP, CHIP 0.01 DM ABC.................

C 703 87-010-197-080 CAP, CHIP 0.01 DM ABC.................

C 705 87-010-197-080 CAP, CHIP 0.01 DM ABC.................

C 701 87-012-145-080 CAP, CHIP S 270P CH ABC.................

C 702 87-016-462-080 C-CAP,S 1-16 F ABC.................

C 708 87-A10-418-080 C-CAP,TN 22-4 A TCF ABC.................

C 710 87-016-462-080 C-CAP,S 1-16 F ABC.................

L 701 87-007-189-010 COIL OSC ABC.................

Q 701 87-026-263-080 C-TR,RN1410 ABC.................

Q 702 89-333-266-080 CHIP TR,2SC3326B ABC.................

SW 701 87-036-082-010 SLIDE SWITCH, 2-2-2 ABC.................

87-008-543-010 FLTR KIT,10.7M ....................

87-A91-236-010 FLTR,KIT KSKM2CD-AO-004 ABC.................

BPF 101 87-A90-601-010 FLTR,BPF GFWB7 ABC.................

C 109 87-010-145-080 C-CAP,S 1P-50 CH ....................

C 104 87-010-146-080 CHIP CAP 2PF ABC.................

C 109 87-010-150-080 C-CAP,S 6P-50 CH ABC.................

C 102 87-010-175-080 CAP 560P ABC.................

C 103 87-010-194-080 CAP, CHIP 0.047 ABC.................

C 101 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 106 87-010-197-080 CAP, CHIP 0.01 DM ABC.................

C 107 87-010-197-080 CAP, CHIP 0.01 DM ....................

C 105 87-010-319-080 C-CAP,S 56P-50 CH ....................

C 105 87-010-320-080 CHIP CAP 68P ABC.................

C 108 87-010-320-080 CHIP CAP 68P ....................

C 102 87-012-140-080 CAP 470P ....................

C 107 87-016-462-080 C-CAP,S 1-16 F ABC.................

C 111 87-010-145-080 C-CAP,S 1P-50 CH ABC.................

C 115 87-010-154-080 CAP CHIP 10P ABC.................

C 113 87-010-197-080 CAP, CHIP 0.01 DM ABC.................

C 114 87-010-311-080 CAP 12P ABC.................

C 110 87-010-318-080 C-CAP,S 47P-50 CH ABC.................

C 116 87-010-503-040 CAP,E 220-4 GAS ABC.................

C 119 87-012-141-080 CHIP-CAPACITOR,0.22-16F ABC.................

C 117 87-012-141-080 CHIP-CAPACITOR,0.22-16F ABC.................

C 118 87-012-157-080 C-CAP,S 330P-50 CH ABC.................

C 112 87-016-462-080 C-CAP,S 1-16 F ABC.................

C 128 87-010-178-080 CHIP CAP 1000P .B..................

C 127 87-010-178-080 CHIP CAP 1000P ABC.................

C 120 87-010-195-080 C-CAP,S 0.068-25 F ....................

C 122 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 120 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 121 87-010-196-080 CHIP CAPACITOR,0.1-25 ....................

C 126 87-010-197-080 CAP, CHIP 0.01 DM ABC.................

C 125 87-010-197-080 CAP, CHIP 0.01 DM ABC.................

C 123 87-010-198-080 CAP, CHIP 0.022 ABC.................

C 124 87-010-198-080 CAP, CHIP 0.022 ABC.................

C 129 87-010-819-040 CAP,E 33-4 M MJ ABC.................

C 121 87-016-462-080 C-CAP,S 1-16 F ABC.................

C 134 87-010-145-080 C-CAP,S 1P-50 CH ABC.................

C 135 87-010-154-080 CAP CHIP 10P ABC.................

C 132 87-010-197-080 CAP, CHIP 0.01 DM ABC.................

C 133 87-010-197-080 CAP, CHIP 0.01 DM ABC.................

C 131 87-010-197-080 CAP, CHIP 0.01 DM ABC.................

C 138 87-010-197-080 CAP, CHIP 0.01 DM ABC.................

C 139 87-010-318-080 C-CAP,S 47P-50 CH ....................

C 137 87-010-322-080 C-CAP,S 100P-50 CH ABC.................

C 130 87-010-452-080 CAPACITOR,1-16 ABC.................

C 136 87-010-502-040 CAP ELECT GAS 100/4 ABC.................

C 142 87-010-178-080 CHIP CAP 1000P ....................

C 144 87-010-178-080 CHIP CAP 1000P ABC.................

C 145 87-010-178-080 CHIP CAP 1000P A.C.................

C 146 87-010-178-080 CHIP CAP 1000P A.C.................

HSJS479co.p65 25-Feb-99, 11:42 AM3

ELECTRICAL MAIN PARTS LIST-3/3

C 141 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 142 87-010-309-080 C-CAP,1000P-50 CH ABC.................

C 143 87-010-318-080 C-CAP,S 47P-50 CH ....................

C 143 87-010-322-080 C-CAP,S 100P-50 CH ....................

C 155 87-010-318-080 C-CAP,S 47P-50 CH A.C.................

C 155 87-010-322-080 C-CAP,S 100P-50 CH .B..................

C 150 87-016-461-080 C-CAP,S 0.47-16F ABC.................

CF 101 87-A90-456-080 C-FLTR,PFWCC 450J3 ABC.................

D 101 87-A40-290-070 C-VARI-CAP,KV1590 ABC.................

D 103 87-A40-479-040 C-VARI-CAP,KV1430TL ABC.................

D 102 87-A40-479-040 C-VARI-CAP,KV1430TL ABC.................

IC 101 87-001-379-080 IC,TA8122AF ....................

IC 101 87-A20-851-040 C-IC,TA2111F ABC.................

L 105 85-HRE-619-010 IFT,AM ....................

L 104 87-003-226-080 MICRO INDUCTOR 100UJ ABC.................

L 105 87-A90-663-010 IFT,MW 5L H6.4 ABC.................

L 102 87-HJ6-607-010 COIL,RF FM ....................

L 103 87-HJ6-608-010 COIL,OSC FM ....................

L 101 87-HJ6-610-010 BAR-ANT,MW ABC.................

L 102 87-HJ6-614-010 COIL,RF FM ABC.................

L 103 87-HJ6-615-010 COIL,OSC FM ABC.................

Q 103 87-026-268-080 C-TR,RN2411 ABC.................

Q 106 87-026-268-080 C-TR,RN2411 ABC.................

Q 108 87-026-581-080 C-TR,RN2405 ABC.................

Q 105 89-327-143-080 TR,2SC2714 (0.1W) ABC.................

Q 107 89-327-143-080 TR,2SC2714 (0.1W) ABC.................

Q 102 89-327-143-080 TR,2SC2714 (0.1W) ABC.................

Q 104 89-327-143-080 TR,2SC2714 (0.1W) ABC.................

Q 110 87-A30-085-070 C-TR,CSA1362GR ABC.................

VC 101 87-011-217-010 TRIMER,10P VCT35 ABC.................

C 256 87-010-149-080 C-CAP,S 5P-50 CH ABC.................

C 254 87-010-152-080 C-CAP,S 8P-50 CH ABC.................

C 259 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 253 87-010-197-080 CAP, CHIP 0.01 DM ABC.................

C 251 87-010-197-080 CAP, CHIP 0.01 DM ABC.................

C 255 87-010-319-080 C-CAP,S 56P-50 CH ABC.................

C 252 87-010-452-080 CAPACITOR,1-16 ABC.................

C 257 87-016-462-080 C-CAP,S 1-16 F ABC.................

C 258 87-016-462-080 C-CAP,S 1-16 F ABC.................

IC 251 87-A20-124-080 IC, TK11823 ABC.................

L 251 87-A50-230-080 C-COIL,D-D(CP4LBM) ABC.................

Q 251 89-327-125-080 CHIP TR,2SC2712GR ABC.................

Q 252 89-327-125-080 CHIP TR,2SC2712GR ABC.................

87-HJ6-604-010 FF-CABLE, 22P ABC.................

C 303 87-010-181-080 CAP,CHIP S 1800P ABC.................

C 304 87-010-181-080 CAP,CHIP S 1800P ABC.................

C 309 87-010-189-080 C-CAP,S 8200P-50 B ABC.................

C 305 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 306 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 307 87-016-462-080 C-CAP,S 1-16 F ABC.................

C 308 87-016-462-080 C-CAP,S 1-16 F ABC.................

C 301 87-016-462-080 C-CAP,S 1-16 F ABC.................

C 302 87-016-462-080 C-CAP,S 1-16 F ABC.................

C 314 87-010-188-080 CAP,CHIP 6800P ABC.................

C 313 87-010-188-080 CAP,CHIP 6800P ABC.................

C 310 87-010-189-080 C-CAP,S 8200P-50 B ABC.................

C 311 87-010-195-080 C-CAP,S 0.068-25 F ABC.................

C 312 87-010-195-080 C-CAP,S 0.068-25 F ABC.................

Q 303 87-026-264-080 C-TR,RN1411 ABC.................

Q 301 87-026-264-080 C-TR,RN1411 ABC.................

Q 304 87-026-264-080 C-TR,RN1411 ABC.................

Q 302 87-026-264-080 C-TR,RN1411 ABC.................

Q 309 87-026-268-080 C-TR,RN2411 ABC.................

Q 307 89-327-125-080 CHIP TR,2SC2712GR ABC.................

Q 308 89-327-125-080 CHIP TR,2SC2712GR ABC.................

Q 305 89-327-125-080 CHIP TR,2SC2712GR ABC.................

Q 306 89-327-125-080 CHIP TR,2SC2712GR ABC.................

C 206 87-010-197-080 CAP, CHIP 0.01 DM ABC.................

C 208 87-016-462-080 C-CAP,S 1-16 F ABC.................

C 207 87-016-462-080 C-CAP,S 1-16 F ABC.................

C 205 87-016-462-080 C-CAP,S 1-16 F ABC.................

C 209 87-016-462-080 C-CAP,S 1-16 F ABC.................

C 213 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 215 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 214 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 211 87-010-312-080 C-CAP,S 15P-50 CH ABC.................

C 210 87-010-314-080 C-CAP,S 22P-50V ABC.................

C 212 87-012-142-080 CAP, S 0.33-16 ABC.................

IC 201 87-A20-505-210 C-IC,TC9318FB-019 ABC.................

LCD 201 87-HJ6-609-010 LCD,HS ASSY(BAND/TU) ABC.................

Q 201 87-A30-085-070 C-TR,CSA1362GR ABC.................

R 205 87-022-353-080 C-RES,S 6.8K-1/10W F ABC.................

R 206 87-022-353-080 C-RES,S 6.8K-1/10W F ABC.................

R 207 87-022-361-080 C-RES,S 47K-1/10W F ABC.................

SW 213 87-036-123-080 CHIP SLIDE SWITCH,1-1-2 ABC.................

TH 201 87-A90-547-080 C-THMS,47K (5%)NTH 5G ABC.................

X 201 87-A70-082-010 VIB,XTAL 75KHZ ABC.................

HSJS479co.p65 25-Feb-99, 11:42 AM4

SCHEMATIC DIAGRAM - 1 (MAIN)

SCHEMATIC DIAGRAM-2(FRONT)

MECHANICAL PARTS LIST - 1/1

NOTE: The characters in the suffix column indicate the part usage.

YJ1 ....................XX..................................A...................

YU .....................XX...................................B..................

YH1 ....................XX....................................C.................

KANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

87-HJ6-005-210 WINDOW,LCD ....................

87-HJ6-020-010 LID,CASS ASSBL Y ....................

87-HJ6-021-010 LID,CASS ASSBL Y (EGS) ....................

87-HJ6-030-010 LID,CASS ASSY 479 ABC.................

87-HJ6-035-010 WINDOW,LCD 479 ABC.................

87-HJ6-006-010 BTN,FUNCTION ....................

87-HJ6-007-010 CAP, FUNCTION ABC.................

87-HJ6-008-110 CAP, MSP ABC.................

87-HJ6-038-010 BTN,FUNCTION 479 ABC.................

87-067-732-010 TAPPING SCREW, VT1.4-3 ABC.................

87-HJ6-211-010 SH,WASHER 23.6-9.4-0.02 W/ADH ABC.................

87-HRA-204-010 SPR-T,CLICK ABC.................

87-HJ6-002-110 FRAME,CENTER ABC.................

87-HJ6-003-210 CABI,REAR ....................

87-HJ6-004-010 LID,BAT ....................

87-HJ6-017-210 CABI,REAR (EGS) ....................

87-HJ6-018-210 CABI,REAR (YJ) ....................

87-HJ6-033-010 CABI,REAR 479 ABC.................

87-HJ6-034-010 LID,BATT 479 ABC.................

87-HJ6-010-010 BTN,REC ABC.................

87-HJ6-011-110 BTN,PLAY ABC.................

87-HJ6-012-110 BTN,STOP ABC.................

87-HJ6-013-210 BTN,REW ABC.................

87-HJ6-014-110 BTN,FF ABC.................

87-HJ6-015-010 KNOB,SL PAUSE ....................

87-HJ6-019-010 KNOB,SL EGS ....................

87-HJ6-039-010 KNOB,SL PAUSE 479 ABC.................

87-HJ6-040-010 KNOB,SL EGS 479 ABC.................

87-067-384-010 SCREWVT1.4-3.5HL ABC.................

87-067-732-010 TAPPING SCREW, VT1.4-3 ABC.................

87-067-770-010 VT2+1.7-9(3) BLK ABC.................

87-HG6-204-010 SPR-P,CASS ABC.................

87-HJ6-201-010 HLDR,BAR ANT ABC.................

87-HJ6-203-110 BAT-CONTACT,- ABC.................

87-HJ6-207-010 BAT-CONTACT,(+) 479 ABC.................

87-HJ6-208-010 HLDR,BAT ABC.................

87-HJ6-209-010 LEVER,PAUSE ABC.................

87-HJ6-210-010 PLATE,IND DIR ABC.................

HSJS479co.p65 25-Feb-99, 11:42 AM5

ACCESSORIES / PACKAGE LIST - 1/1

NOTE: The characters in the suffix column indicate the part usage.

YJ1 ....................XX..................................A...................

YU .....................XX...................................B..................

YH1 ....................XX....................................C.................

KANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

87-HJ6-901-010 IB,YU (ESF) ....................

87-HJ6-902-010 IB,Y (ESF) ....................

87-HJ6-903-010 IB,Y (EGI) ....................

87-HJ6-904-010 IB,YJ (ESC) ....................

87-HJ6-905-010 IB,YL (ESP) ....................

87-HJ6-906-010 IB,YU (ESF) JS479 .B..................

87-HJ6-907-010 IB,YJ (ECC) JS479 A.C.................

84-447-019-310 CLIP,BELT ABC..................

87-041-083-110 CM-S40A ABC.................

87-B30-042-010 HEADPHONE,HP-24NSH .B..................

87-B30-081-110 HEADPHONE,HP-M009(S) ....................

87-B30-255-010 HEADPHONE,HP-M007B(S) A.C.................

HSJS479co.p65 25-Feb-99, 11:42 AM6

PrintedinSingapore

TokyoJapan

9630466

HSJS479co.p65 25-Feb-99, 11:42 AM7

Other manuals for HS-JS479

Table of contents

Popular Recording Equipment manuals by other brands

Volfoni

Volfoni ActivHub RF50 user guide

Musical Surroundings

Musical Surroundings Fozgometer Testing and Calibration Procedure

CZone

CZone Motor Output Interface User & installation manual

AMX

AMX AXC-232 Plus plus Dimensional drawing

PRESONUS

PRESONUS FIRESTUDIO - V 3.0 user manual

Mastervolt

Mastervolt MasterBus LIN Interface User and installation manual

ALA Coach

ALA Coach MB100 user manual

National Instruments

National Instruments NI-845 Series installation guide

aci

aci TIF-401 Installation and reference guide

AMX

AMX AXB-IRS4 instruction manual

PRACQ

PRACQ MELODIC STEP SEQUENCER Reference manual

ABB

ABB FEN-31 user manual

Camplex

Camplex BLACKJACK-1 User manual & installation guide

JGC

JGC JGC-RRMP-670 USB user manual

SEW-Eurodrive

SEW-Eurodrive DFE33B manual

Abekas

Abekas DVEOUS Technical guide

Lowrance

Lowrance RIM 200 installation instructions

Roland

Roland Micro Composer MC-80 Service notes

Aiwa HS-JS479 User manual

Popular Recording Equipment manuals by other brands
