Aiwa NSX-DS8 User manual

SERVICE MANUAL
DATA
NSX-DS8 U
COMPACT DISC / STEREO
CASSETTE RECEIVER
SIMPLE
S/M Code No. 09-007-436-3T1
•Replace this Service manual with “Revision Publishing” when it is issued.
BASICTAPEMECHANISM:2ZM-3MK2PR7NM
BASICCDMECHANISM:AZG-1ZD3RNDM

PARTS LIST
-1-
! =! SAFTY PARTS
C=Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
K NO. =Only use japanese.
C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX
X AC-3 89-990-143-410 0E WIRE,U24X0-14-5 F USM CX-NDS8
O AC-3 C 0401 87-010-401-080 0E CAP,E 1-50 M 11L SME USM CX-NDS8
O AC-3 C 0402 87-010-401-080 0E CAP,E 1-50 M 11L SME USM CX-NDS8
O AC-3 C 0403 87-010-154-080 0E C-CAP,S 10P-50 D CH GRM USM CX-NDS8
O AC-3 C 0404 87-010-154-080 0E C-CAP,S 10P-50 D CH GRM USM CX-NDS8
O AC-3 C 0405 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O AC-3 C 0406 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O AC-3 C 0407 87-010-408-080 0E CAP,E 47-50 M 11L SME USM CX-NDS8
O AC-3 C 0408 87-010-408-080 0E CAP,E 47-50 M 11L SME USM CX-NDS8
O AC-3 C 0409 87-010-154-080 0E C-CAP,S 10P-50 D CH GRM USM CX-NDS8
X AC-3 C 0413 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X AC-3 C 0414 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
O AC-3 C 0421 87-010-401-080 0E CAP,E 1-50 M 11L SME USM CX-NDS8
O AC-3 C 0422 87-010-405-080 0E CAP,E 10-50 M 11L SME USM CX-NDS8
X AC-3 C 0423 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
O AC-3 C 0424 87-010-154-080 0E C-CAP,S 10P-50 D CH GRM USM CX-NDS8
O AC-3 C 0425 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O AC-3 C 0426 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O AC-3 C 0427 87-010-154-080 0E C-CAP,S 10P-50 D CH GRM USM CX-NDS8
O AC-3 C 0428 87-010-401-080 0E CAP,E 1-50 M 11L SME USM CX-NDS8
O AC-3 C 0431 87-010-154-080 0E C-CAP,S 10P-50 D CH GRM USM CX-NDS8
X AC-3 C 0432 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
O AC-3 C 0451 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O AC-3 C 0452 87-010-378-080 0E CAP,E 10-16 M 11L SME USM CX-NDS8
O AC-3 C 0453 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O AC-3 C 0454 87-010-378-080 0E CAP,E 10-16 M 11L SME USM CX-NDS8
O AC-3 C 0489 87-010-402-080 0E CAP,E 2.2-50 M 11L SME USM CX-NDS8
O AC-3 C 0491 87-010-402-080 0E CAP,E 2.2-50 M 11L SME USM CX-NDS8
O AC-3 C 0492 87-010-402-080 0E CAP,E 2.2-50 M 11L SME USM CX-NDS8
X AC-3 CLP0401 87-A60-884-010 0E PIN,DIA1 COATING-SHS USM CX-NDS8
O AC-3 CNA0401 8A-NFG-651-010 — CONN ASSY,10P ANF-G(BLUE) USM CX-NDS8
O AC-3 CNA0402 8A-NFG-652-010 — CONN ASSY,10P ANF-G(RED) USM CX-NDS8
S AC-3 D 0401 87-A40-737-080 0E ZENER,UZ2.2BSB USM CX-NDS8
S AC-3 D 0402 87-A40-737-080 0E ZENER,UZ2.2BSB USM CX-NDS8
X AC-3 FB 0401 88-100-000-010 0E PLATING-JW, 0.58 SN95 USM CX-NDS8
S AC-3 IC 0401 87-A21-111-040 1C C-IC,M62495FP USM CX-NDS8
S AC-3 IC 0402 87-A21-111-040 1C C-IC,M62495FP USM CX-NDS8
S AC-3 IC 0403 87-070-391-040 1A C-IC,BA4558F USM CX-NDS8
X AC-3 JR 0402 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X AC-3 JR 0403 88-129-000-080 0E C-JUMPER,3216 USM CX-NDS8
X AC-3 JR 0404 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X AC-3 JR 0407 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X AC-3 JR 0473 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
S AC-3 Q 0401 87-A30-086-040 0E C-TR,CSD1306E USM CX-NDS8
S AC-3 Q 0402 87-A30-086-040 0E C-TR,CSD1306E USM CX-NDS8
S AC-3 Q 0403 87-A30-075-080 0E C-TR,2SA1235F USM CX-NDS8
S AC-3 Q 0404 87-A30-086-040 0E C-TR,CSD1306E USM CX-NDS8
S AC-3 Q 0410 87-A30-076-080 0E C-TR,2SC3052F USM CX-NDS8
S AC-3 Q 0451 87-A30-086-040 0E C-TR,CSD1306E USM CX-NDS8
X AC-3 R 0401 88-118-393-080 0E C-RES,S 39K-1/10W J USM CX-NDS8
X AC-3 R 0402 88-118-393-080 0E C-RES,S 39K-1/10W J USM CX-NDS8
X AC-3 R 0403 88-118-332-080 0E C-RES,S 3.3K-1/10W J USM CX-NDS8
X AC-3 R 0404 88-118-332-080 0E C-RES,S 3.3K-1/10W J USM CX-NDS8
X AC-3 R 0405 88-118-682-080 0E C-RES,S 6.8K-1/10W J USM CX-NDS8
X AC-3 R 0406 88-118-682-080 0E C-RES,S 6.8K-1/10W J USM CX-NDS8
X AC-3 R 0407 88-118-562-080 0E C-RES,S 5.6K-1/10W J USM CX-NDS8
X AC-3 R 0408 88-118-562-080 0E C-RES,S 5.6K-1/10W J USM CX-NDS8
X AC-3 R 0409 88-118-222-080 0E C-RES,S 2.2K-1/10W J USM CX-NDS8
X AC-3 R 0410 88-121-822-080 0E RES,8.2K-1/8W J USM CX-NDS8
X AC-3 R 0411 88-118-123-080 0E C-RES,S 12K-1/10W J USM CX-NDS8
X AC-3 R 0415 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X AC-3 R 0416 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X AC-3 R 0421 88-118-223-080 0E C-RES,S 22K-1/10W J USM CX-NDS8
X AC-3 R 0422 88-118-473-080 0E C-RES,S 47K-1/10W J USM CX-NDS8
X AC-3 R 0423 88-118-472-080 0E C-RES,S 4.7K-1/10W J USM CX-NDS8
X AC-3 R 0424 88-118-332-080 0E C-RES,S 3.3K-1/10W J USM CX-NDS8
X AC-3 R 0425 88-118-682-080 0E C-RES,S 6.8K-1/10W J USM CX-NDS8
X AC-3 R 0426 88-118-472-080 0E C-RES,S 4.7K-1/10W J USM CX-NDS8
X AC-3 R 0427 88-118-682-080 0E C-RES,S 6.8K-1/10W J USM CX-NDS8
X AC-3 R 0429 88-118-472-080 0E C-RES,S 4.7K-1/10W J USM CX-NDS8

PARTS LIST
-2-
! =! SAFTY PARTS
C=Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
K NO. =Only use japanese.
C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX
X AC-3 R 0430 88-121-103-080 0E RES,10K-1/8W J USM CX-NDS8
X AC-3 R 0432 88-118-123-080 0E C-RES,S 12K-1/10W J USM CX-NDS8
O AC-3 R 0435 87-A00-373-050 0E RES,M/F 270-1W J VTP USM CX-NDS8
O AC-3 R 0436 87-A00-373-050 0E RES,M/F 270-1W J VTP USM CX-NDS8
X AC-3 R 0437 88-128-221-080 0E C-RES, 220-1/8W J USM CX-NDS8
X AC-3 R 0438 88-128-221-080 0E C-RES, 220-1/8W J USM CX-NDS8
X AC-3 R 0439 88-128-221-080 0E C-RES, 220-1/8W J USM CX-NDS8
X AC-3 R 0440 88-128-221-080 0E C-RES, 220-1/8W J USM CX-NDS8
X AC-3 R 0441 88-100-000-010 0E PLATING-JW, 0.58 SN95 USM CX-NDS8
X AC-3 R 0442 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X AC-3 R 0451 88-118-222-080 0E C-RES,S 2.2K-1/10W J USM CX-NDS8
X AC-3 R 0452 88-118-473-080 0E C-RES,S 47K-1/10W J USM CX-NDS8
X AC-3 R 0453 88-118-152-080 0E C-RES,S 1.5K-1/10W J USM CX-NDS8
X AC-3 R 0454 88-118-104-080 0E C-RES,S 100K-1/10W J USM CX-NDS8
X AC-3 R 0455 88-118-104-080 0E C-RES,S 100K-1/10W J USM CX-NDS8
X AC-3 R 0456 88-118-102-080 0E C-RES,S 1K-1/10W J USM CX-NDS8
X AC-3 R 0457 88-118-222-080 0E C-RES,S 2.2K-1/10W J USM CX-NDS8
X AC-3 R 0458 88-118-223-080 0E C-RES,S 22K-1/10W J USM CX-NDS8
X AC-3 R 0459 88-118-104-080 0E C-RES,S 100K-1/10W J USM CX-NDS8
X AC-3 R 0460 88-118-102-080 0E C-RES,S 1K-1/10W J USM CX-NDS8
X AC-3 R 0473 88-121-222-080 0E RES,2.2K-1/8W J USM CX-NDS8
X AC-3 R 0474 88-121-222-080 0E RES,2.2K-1/8W J USM CX-NDS8
X AC-3 R 0475 88-118-152-080 0E C-RES,S 1.5K-1/10W J USM CX-NDS8
X AC-3 R 0476 88-118-152-080 0E C-RES,S 1.5K-1/10W J USM CX-NDS8
X AC-3 R 0480 88-118-563-080 0E C-RES,S 56K-1/10W J USM CX-NDS8
X AC-3 R 0481 88-118-152-080 0E C-RES,S 1.5K-1/10W J USM CX-NDS8
X AC-3 R 0482 88-118-392-080 0E C-RES,S 3.9K-1/10W J USM CX-NDS8
X AC-3 W 0401 8Z-NFD-646-010 0E WIRE,FASTON-1P-400 MM USM CX-NDS8
O ACCESSORY 87-006-225-010 1D ANT,LOOP ANT NC2 USM CX-NDS8
O ACCESSORY 87-043-115-010 1A FEEDER-ANT,FM USM CX-NDS8
O ACCESSORY 8Z-NFD-702-010 2A RC UNIT,RC- ZAS22 USM CX-NDS8
X AMP 1F * 8A-NF6-650-210 1C PWB,AMP 1F 2M USM CX-NDS8
O AMP 1F C 0101 87-010-181-080 0E C-CAP,S 1800P-50 K B GRM USM CX-NDS8
O AMP 1F C 0102 87-010-181-080 0E C-CAP,S 1800P-50 K B GRM USM CX-NDS8
O AMP 1F C 0103 87-010-545-080 0E CAP,E 0.22-50 M 11L SME USM CX-NDS8
O AMP 1F C 0104 87-010-545-080 0E CAP,E 0.22-50 M 11L SME USM CX-NDS8
O AMP 1F C 0107 87-010-405-080 0E CAP,E 10-50 M 11L SME USM CX-NDS8
O AMP 1F C 0108 87-010-405-080 0E CAP,E 10-50 M 11L SME USM CX-NDS8
O AMP 1F C 0111 87-010-179-080 0E C-CAP,S 1200P-50 K B GRM USM CX-NDS8
O AMP 1F C 0112 87-010-179-080 0E C-CAP,S 1200P-50 K B GRM USM CX-NDS8
O AMP 1F C 0113 87-010-405-080 0E CAP,E 10-50 M 11L SME USM CX-NDS8
O AMP 1F C 0114 87-010-405-080 0E CAP,E 10-50 M 11L SME USM CX-NDS8
O AMP 1F C 0115 87-010-866-080 0E CAP,E 10-63 M VX USM CX-NDS8
O AMP 1F C 0116 87-010-866-080 0E CAP,E 10-63 M VX USM CX-NDS8
O AMP 1F C 0119 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USM CX-NDS8
O AMP 1F C 0120 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USM CX-NDS8
O AMP 1F C 0133 87-010-190-080 0E C-CAP,S 0.01-50 Z F C2012 USM CX-NDS8
O AMP 1F C 0153 87-010-188-080 0E C-CAP,S 6800P-50 K B C2012 USM CX-NDS8
O AMP 1F C 0201 87-A12-369-080 0E CAP,M 0.027-100 J CP USM CX-NDS8
O AMP 1F C 0202 87-A12-369-080 0E CAP,M 0.027-100 J CP USM CX-NDS8
O AMP 1F C 0203 87-A12-369-080 0E CAP,M 0.027-100 J CP USM CX-NDS8
O AMP 1F C 0204 87-A12-369-080 0E CAP,M 0.027-100 J CP USM CX-NDS8
O AMP 1F C 0205 87-010-180-080 0E C-CAP,S 1500P-50 K B C2012 USM CX-NDS8
O AMP 1F C 0206 87-010-180-080 0E C-CAP,S 1500P-50 K B C2012 USM CX-NDS8
O AMP 1F C 0207 87-010-401-080 0E CAP,E 1-50 M 11L SME USM CX-NDS8
O AMP 1F C 0208 87-010-401-080 0E CAP,E 1-50 M 11L SME USM CX-NDS8
O AMP 1F C 0209 87-010-187-080 0E C-CAP,S 5600P-50 K B USM CX-NDS8
O AMP 1F C 0210 87-010-187-080 0E C-CAP,S 5600P-50 K B USM CX-NDS8
O AMP 1F C 0211 87-010-403-080 0E CAP,E 3.3-50 M 11L SME USM CX-NDS8
O AMP 1F C 0212 87-010-403-080 0E CAP,E 3.3-50 M 11L SME USM CX-NDS8
O AMP 1F C 0215 87-010-179-080 0E C-CAP,S 1200P-50 K B GRM USM CX-NDS8
O AMP 1F C 0216 87-010-179-080 0E C-CAP,S 1200P-50 K B GRM USM CX-NDS8
O AMP 1F C 0217 87-010-405-080 0E CAP,E 10-50 M 11L SME USM CX-NDS8
O AMP 1F C 0218 87-010-405-080 0E CAP,E 10-50 M 11L SME USM CX-NDS8
O AMP 1F C 0221 87-010-405-080 0E CAP,E 10-50 M 11L SME USM CX-NDS8
O AMP 1F C 0222 87-010-405-080 0E CAP,E 10-50 M 11L SME USM CX-NDS8
O AMP 1F C 0223 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USM CX-NDS8
O AMP 1F C 0224 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USM CX-NDS8
O AMP 1F C 0251 87-012-368-080 0E C-CAP,S 0.1-50 Z F USM CX-NDS8
O AMP 1F C 0252 87-012-368-080 0E C-CAP,S 0.1-50 Z F USM CX-NDS8

PARTS LIST
-3-
! =! SAFTY PARTS
C=Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
K NO. =Only use japanese.
C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX
O AMP 1F C 0253 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O AMP 1F C 0254 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O AMP 1F C 0401 87-010-260-080 0E CAP,E 47-25 M 11L SME USM CX-NDS8
! O AMP 1F CN 0101 87-A61-011-010 0E CONN,13P H BLK TAC-L13P-A3 USM CX-NDS8
! O AMP 1F CN 0102 87-A61-011-010 0E CONN,13P H BLK TAC-L13P-A3 USM CX-NDS8
! O AMP 1F CN 0105 87-099-198-010 0E CONN,10P V BLK 6216 USM CX-NDS8
O AMP 1F CNA0101 8A-NF6-645-010 1B CONN ASSY,5P TID-A(530) USM CX-NDS8
! O AMP 1F CNA0103 8A-NF8-655-010 1A CONN ASSY,7P TID-A(250) USM CX-NDS8
S AMP 1F D 0101 87-A40-269-080 0E C-DIODE,MC2836 USM CX-NDS8
S AMP 1F D 0102 87-A40-270-080 0E C-DIODE,MC2838 USM CX-NDS8
S AMP 1F D 0103 87-A40-313-080 0E C-DIODE,MC2840 USM CX-NDS8
S AMP 1F D 0150 87-A40-270-080 0E C-DIODE,MC2838 USM CX-NDS8
S AMP 1F D 0201 87-A40-269-080 0E C-DIODE,MC2836 USM CX-NDS8
S AMP 1F D 0203 87-A40-313-080 0E C-DIODE,MC2840 USM CX-NDS8
S AMP 1F D 0204 87-020-465-080 0E DIODE,1SS133 USM CX-NDS8
S AMP 1F D 0401 87-A40-270-080 0E C-DIODE,MC2838 USM CX-NDS8
S AMP 1F D 0402 87-A40-553-080 0E DIODE,1N4003 LES USM CX-NDS8
S AMP 1F D 0403 87-A40-553-080 0E DIODE,1N4003 LES USM CX-NDS8
S AMP 1F IC 0101 87-A21-418-010 2M IC,STK490-340 USM CX-NDS8
! S AMP 1F IC 0201 87-A21-397-010 2A IC,STK490-070 USM CX-NDS8
O AMP 1F J 0202 87-A61-158-010 1A JACK,PIN 2P R/W/BL H(SEPA) KM USM CX-NDS8
X AMP 1F JR 0101 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X AMP 1F JR 0103 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X AMP 1F JR 0104 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X AMP 1F JR 0106 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X AMP 1F JR 0113 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X AMP 1F JR 0115 88-129-000-080 0E C-JUMPER,3216 USM CX-NDS8
X AMP 1F JR 0201 88-129-000-080 0E C-JUMPER,3216 USM CX-NDS8
X AMP 1F JR 0203 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X AMP 1F JR 0204 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X AMP 1F JR 0205 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X AMP 1F JR 0206 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X AMP 1F JR 0207 88-129-000-080 0E C-JUMPER,3216 USM CX-NDS8
X AMP 1F JR 0208 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X AMP 1F JR 0401 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
O AMP 1F L 0251 87-A50-610-010 0E COIL,1UH K(MDEC) USM CX-NDS8
O AMP 1F L 0252 87-A50-610-010 0E COIL,1UH K(MDEC) USM CX-NDS8
S AMP 1F Q 0101 87-A30-107-070 0E C-TR,CMBT5401 USM CX-NDS8
S AMP 1F Q 0102 87-A30-107-070 0E C-TR,CMBT5401 USM CX-NDS8
S AMP 1F Q 0150 87-A30-107-070 0E C-TR,CMBT5401 USM CX-NDS8
S AMP 1F Q 0151 87-A30-106-040 0E C-TR,CMBT5551 USM CX-NDS8
S AMP 1F Q 0201 87-A30-107-070 0E C-TR,CMBT5401 USM CX-NDS8
S AMP 1F Q 0202 87-A30-107-070 0E C-TR,CMBT5401 USM CX-NDS8
S AMP 1F Q 0203 87-A30-075-080 0E C-TR,2SA1235F USM CX-NDS8
S AMP 1F Q 0204 87-A30-075-080 0E C-TR,2SA1235F USM CX-NDS8
S AMP 1F Q 0401 87-A30-075-080 0E C-TR,2SA1235F USM CX-NDS8
S AMP 1F Q 0402 87-A30-075-080 0E C-TR,2SA1235F USM CX-NDS8
X AMP 1F R 0101 88-118-104-080 0E C-RES,S 100K-1/10W J USM CX-NDS8
X AMP 1F R 0102 88-118-104-080 0E C-RES,S 100K-1/10W J USM CX-NDS8
X AMP 1F R 0103 88-118-273-080 0E C-RES,S 27K-1/10W J USM CX-NDS8
X AMP 1F R 0104 88-118-273-080 0E C-RES,S 27K-1/10W J USM CX-NDS8
X AMP 1F R 0105 88-118-101-080 0E C-RES,S 100-1/10W J USM CX-NDS8
X AMP 1F R 0106 88-118-101-080 0E C-RES,S 100-1/10W J USM CX-NDS8
X AMP 1F R 0109 88-118-681-080 0E C-RES,S 680-1/10W J USM CX-NDS8
X AMP 1F R 0110 88-118-681-080 0E C-RES,S 680-1/10W J USM CX-NDS8
X AMP 1F R 0111 88-118-273-080 0E C-RES,S 27K-1/10W J USM CX-NDS8
X AMP 1F R 0112 88-118-273-080 0E C-RES,S 27K-1/10W J USM CX-NDS8
X AMP 1F R 0121 88-128-332-080 0E C-RES, 3.3K-1/8W J USM CX-NDS8
X AMP 1F R 0123 88-128-332-080 0E C-RES, 3.3K-1/8W J USM CX-NDS8
X AMP 1F R 0125 88-128-332-080 0E C-RES, 3.3K-1/8W J USM CX-NDS8
X AMP 1F R 0126 88-128-332-080 0E C-RES, 3.3K-1/8W J USM CX-NDS8
O AMP 1F R 0129 87-A00-262-080 0E RES,M/F 0.15-2W J USM CX-NDS8
O AMP 1F R 0130 87-A00-262-080 0E RES,M/F 0.15-2W J USM CX-NDS8
X AMP 1F R 0133 88-118-272-080 0E C-RES,S 2.7K-1/10W J USM CX-NDS8
X AMP 1F R 0134 88-118-272-080 0E C-RES,S 2.7K-1/10W J USM CX-NDS8
X AMP 1F R 0135 88-118-152-080 0E C-RES,S 1.5K-1/10W J USM CX-NDS8
X AMP 1F R 0136 88-118-152-080 0E C-RES,S 1.5K-1/10W J USM CX-NDS8
X AMP 1F R 0137 88-118-101-080 0E C-RES,S 100-1/10W J USM CX-NDS8
X AMP 1F R 0138 88-118-101-080 0E C-RES,S 100-1/10W J USM CX-NDS8
X AMP 1F R 0141 88-118-102-080 0E C-RES,S 1K-1/10W J USM CX-NDS8

PARTS LIST
-4-
! =! SAFTY PARTS
C=Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
K NO. =Only use japanese.
C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX
X AMP 1F R 0142 88-118-102-080 0E C-RES,S 1K-1/10W J USM CX-NDS8
X AMP 1F R 0143 88-118-123-080 0E C-RES,S 12K-1/10W J USM CX-NDS8
X AMP 1F R 0144 88-118-123-080 0E C-RES,S 12K-1/10W J USM CX-NDS8
X AMP 1F R 0145 88-118-104-080 0E C-RES,S 100K-1/10W J USM CX-NDS8
X AMP 1F R 0146 88-118-104-080 0E C-RES,S 100K-1/10W J USM CX-NDS8
X AMP 1F R 0150 88-118-103-080 0E C-RES,S 10K-1/10W J USM CX-NDS8
X AMP 1F R 0151 88-118-473-080 0E C-RES,S 47K-1/10W J USM CX-NDS8
X AMP 1F R 0152 88-118-103-080 0E C-RES,S 10K-1/10W J USM CX-NDS8
X AMP 1F R 0153 88-118-103-080 0E C-RES,S 10K-1/10W J USM CX-NDS8
X AMP 1F R 0154 88-118-103-080 0E C-RES,S 10K-1/10W J USM CX-NDS8
X AMP 1F R 0171 88-118-102-080 0E C-RES,S 1K-1/10W J USM CX-NDS8
X AMP 1F R 0172 88-118-102-080 0E C-RES,S 1K-1/10W J USM CX-NDS8
X AMP 1F R 0201 88-118-473-080 0E C-RES,S 47K-1/10W J USM CX-NDS8
X AMP 1F R 0202 88-118-473-080 0E C-RES,S 47K-1/10W J USM CX-NDS8
X AMP 1F R 0205 88-118-103-080 0E C-RES,S 10K-1/10W J USM CX-NDS8
X AMP 1F R 0206 88-118-103-080 0E C-RES,S 10K-1/10W J USM CX-NDS8
X AMP 1F R 0207 88-118-223-080 0E C-RES,S 22K-1/10W J USM CX-NDS8
X AMP 1F R 0208 88-118-223-080 0E C-RES,S 22K-1/10W J USM CX-NDS8
X AMP 1F R 0209 88-118-224-080 0E C-RES,S 220K-1/10W J USM CX-NDS8
X AMP 1F R 0210 88-118-224-080 0E C-RES,S 220K-1/10W J USM CX-NDS8
X AMP 1F R 0211 88-118-393-080 0E C-RES,S 39K-1/10W J USM CX-NDS8
X AMP 1F R 0212 88-118-393-080 0E C-RES,S 39K-1/10W J USM CX-NDS8
X AMP 1F R 0213 88-118-333-080 0E C-RES,S 33K-1/10W J USM CX-NDS8
X AMP 1F R 0214 88-118-333-080 0E C-RES,S 33K-1/10W J USM CX-NDS8
X AMP 1F R 0215 88-128-101-080 0E C-RES, 100-1/8W J USM CX-NDS8
X AMP 1F R 0216 88-118-101-080 0E C-RES,S 100-1/10W J USM CX-NDS8
X AMP 1F R 0217 88-118-222-080 0E C-RES,S 2.2K-1/10W J USM CX-NDS8
X AMP 1F R 0218 88-118-222-080 0E C-RES,S 2.2K-1/10W J USM CX-NDS8
X AMP 1F R 0219 88-118-333-080 0E C-RES,S 33K-1/10W J USM CX-NDS8
X AMP 1F R 0220 88-118-333-080 0E C-RES,S 33K-1/10W J USM CX-NDS8
X AMP 1F R 0221 88-118-152-080 0E C-RES,S 1.5K-1/10W J USM CX-NDS8
X AMP 1F R 0222 88-118-152-080 0E C-RES,S 1.5K-1/10W J USM CX-NDS8
X AMP 1F R 0223 88-128-332-080 0E C-RES, 3.3K-1/8W J USM CX-NDS8
X AMP 1F R 0224 88-128-332-080 0E C-RES, 3.3K-1/8W J USM CX-NDS8
X AMP 1F R 0227 88-128-332-080 0E C-RES, 3.3K-1/8W J USM CX-NDS8
X AMP 1F R 0228 88-128-332-080 0E C-RES, 3.3K-1/8W J USM CX-NDS8
O AMP 1F R 0231 87-A00-258-080 0E RES,M/F 0.22-1W J USM CX-NDS8
O AMP 1F R 0232 87-A00-258-080 0E RES,M/F 0.22-1W J USM CX-NDS8
X AMP 1F R 0233 88-118-222-080 0E C-RES,S 2.2K-1/10W J USM CX-NDS8
X AMP 1F R 0234 88-118-222-080 0E C-RES,S 2.2K-1/10W J USM CX-NDS8
X AMP 1F R 0235 88-118-222-080 0E C-RES,S 2.2K-1/10W J USM CX-NDS8
X AMP 1F R 0236 88-118-222-080 0E C-RES,S 2.2K-1/10W J USM CX-NDS8
X AMP 1F R 0237 88-118-101-080 0E C-RES,S 100-1/10W J USM CX-NDS8
X AMP 1F R 0238 88-118-101-080 0E C-RES,S 100-1/10W J USM CX-NDS8
X AMP 1F R 0239 88-118-153-080 0E C-RES,S 15K-1/10W J USM CX-NDS8
X AMP 1F R 0240 88-118-153-080 0E C-RES,S 15K-1/10W J USM CX-NDS8
X AMP 1F R 0241 88-118-102-080 0E C-RES,S 1K-1/10W J USM CX-NDS8
X AMP 1F R 0242 88-118-102-080 0E C-RES,S 1K-1/10W J USM CX-NDS8
X AMP 1F R 0245 88-118-563-080 0E C-RES,S 56K-1/10W J USM CX-NDS8
X AMP 1F R 0246 88-118-563-080 0E C-RES,S 56K-1/10W J USM CX-NDS8
X AMP 1F R 0251 88-130-100-080 0E RES,10-1/4W J USM CX-NDS8
X AMP 1F R 0252 88-130-100-080 0E RES,10-1/4W J USM CX-NDS8
X AMP 1F R 0253 88-118-562-080 0E C-RES,S 5.6K-1/10W J USM CX-NDS8
X AMP 1F R 0254 88-118-562-080 0E C-RES,S 5.6K-1/10W J USM CX-NDS8
X AMP 1F R 0255 88-128-100-080 0E C-RES, 10-1/8W J USM CX-NDS8
X AMP 1F R 0256 88-128-100-080 0E C-RES, 10-1/8W J USM CX-NDS8
X AMP 1F R 0260 88-118-562-080 0E C-RES,S 5.6K-1/10W J USM CX-NDS8
X AMP 1F R 0261 88-118-562-080 0E C-RES,S 5.6K-1/10W J USM CX-NDS8
X AMP 1F R 0262 88-118-562-080 0E C-RES,S 5.6K-1/10W J USM CX-NDS8
X AMP 1F R 0264 88-118-271-080 0E C-RES,S 270-1/10W J USM CX-NDS8
X AMP 1F R 0271 88-118-102-080 0E C-RES,S 1K-1/10W J USM CX-NDS8
X AMP 1F R 0272 88-118-102-080 0E C-RES,S 1K-1/10W J USM CX-NDS8
X AMP 1F R 0304 88-128-153-080 0E C-RES, 15K-1/8W J USM CX-NDS8
X AMP 1F R 0305 88-128-153-080 0E C-RES, 15K-1/8W J USM CX-NDS8
X AMP 1F R 0306 88-128-153-080 0E C-RES, 15K-1/8W J USM CX-NDS8
X AMP 1F R 0309 88-128-103-080 0E C-RES, 10K-1/8W J USM CX-NDS8
X AMP 1F R 0310 88-128-103-080 0E C-RES, 10K-1/8W J USM CX-NDS8
X AMP 1F R 0401 88-118-472-080 0E C-RES,S 4.7K-1/10W J USM CX-NDS8
X AMP 1F R 0402 88-118-472-080 0E C-RES,S 4.7K-1/10W J USM CX-NDS8
X AMP 1F R 0403 88-118-472-080 0E C-RES,S 4.7K-1/10W J USM CX-NDS8

PARTS LIST
-5-
! =! SAFTY PARTS
C=Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
K NO. =Only use japanese.
C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX
X AMP 1F R 0404 88-118-104-080 0E C-RES,S 100K-1/10W J USM CX-NDS8
X AMP 1F R 0405 88-121-103-080 0E RES,10K-1/8W J USM CX-NDS8
! O AMP 1F WH 0101 87-A90-459-010 0E HLDR,WIRE 2.5-5P USM CX-NDS8
! O AMP 1F WH 0102 87-A90-460-010 0E HLDR,WIRE 2.5-7P USM CX-NDS8
X AMP 2F * 8A-NF6-655-210 1B PWB,AMP 2M P-LOGIC USM CX-NDS8
O AMP 2F C 0101 87-010-181-080 0E C-CAP,S 1800P-50 K B GRM USM CX-NDS8
O AMP 2F C 0102 87-010-181-080 0E C-CAP,S 1800P-50 K B GRM USM CX-NDS8
O AMP 2F C 0103 87-010-400-080 0E CAP,E 0.47-50 M 11L SME USM CX-NDS8
O AMP 2F C 0104 87-010-400-080 0E CAP,E 0.47-50 M 11L SME USM CX-NDS8
O AMP 2F C 0107 87-010-404-080 0E CAP,E 4.7-50 M 11L SME USM CX-NDS8
O AMP 2F C 0108 87-010-404-080 0E CAP,E 4.7-50 M 11L SME USM CX-NDS8
O AMP 2F C 0111 87-010-179-080 0E C-CAP,S 1200P-50 K B GRM USM CX-NDS8
O AMP 2F C 0112 87-010-179-080 0E C-CAP,S 1200P-50 K B GRM USM CX-NDS8
O AMP 2F C 0113 87-010-405-080 0E CAP,E 10-50 M 11L SME USM CX-NDS8
O AMP 2F C 0114 87-010-405-080 0E CAP,E 10-50 M 11L SME USM CX-NDS8
O AMP 2F C 0115 87-010-405-080 0E CAP,E 10-50 M 11L SME USM CX-NDS8
O AMP 2F C 0116 87-010-405-080 0E CAP,E 10-50 M 11L SME USM CX-NDS8
O AMP 2F C 0121 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USM CX-NDS8
O AMP 2F C 0122 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USM CX-NDS8
O AMP 2F C 0151 87-012-368-080 0E C-CAP,S 0.1-50 Z F USM CX-NDS8
O AMP 2F C 0152 87-012-368-080 0E C-CAP,S 0.1-50 Z F USM CX-NDS8
O AMP 2F C 0153 87-012-368-080 0E C-CAP,S 0.1-50 Z F USM CX-NDS8
O AMP 2F C 0154 87-012-368-080 0E C-CAP,S 0.1-50 Z F USM CX-NDS8
O AMP 2F C 0155 87-010-190-080 0E C-CAP,S 0.01-50 Z F C2012 USM CX-NDS8
O AMP 2F C 0156 87-010-190-080 0E C-CAP,S 0.01-50 Z F C2012 USM CX-NDS8
O AMP 2F C 0160 87-010-190-080 0E C-CAP,S 0.01-50 Z F C2012 USM CX-NDS8
O AMP 2F C 0161 87-010-188-080 0E C-CAP,S 6800P-50 K B C2012 USM CX-NDS8
O AMP 2F C 0201 87-010-181-080 0E C-CAP,S 1800P-50 K B GRM USM CX-NDS8
O AMP 2F C 0202 87-010-400-080 0E CAP,E 0.47-50 M 11L SME USM CX-NDS8
O AMP 2F C 0203 87-010-322-080 0E C-CAP,S 100P-50 J CH GRM USM CX-NDS8
O AMP 2F C 0204 87-010-405-080 0E CAP,E 10-50 M 11L SME USM CX-NDS8
O AMP 2F C 0205 87-010-260-080 0E CAP,E 47-25 M 11L SME USM CX-NDS8
O AMP 2F C 0206 87-A10-946-080 0E C-CAP,S 220P-100 J CH USM CX-NDS8
O AMP 2F C 0208 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USM CX-NDS8
O AMP 2F C 0209 87-010-260-080 0E CAP,E 47-25 M 11L SME USM CX-NDS8
O AMP 2F C 0210 87-010-260-080 0E CAP,E 47-25 M 11L SME USM CX-NDS8
O AMP 2F C 0211 87-010-178-080 0E C-CAP,S 1000P-50 K B C2012 USM CX-NDS8
O AMP 2F C 0212 87-010-178-080 0E C-CAP,S 1000P-50 K B C2012 USM CX-NDS8
O AMP 2F C 0251 87-012-368-080 0E C-CAP,S 0.1-50 Z F USM CX-NDS8
O AMP 2F C 0252 87-012-368-080 0E C-CAP,S 0.1-50 Z F USM CX-NDS8
O AMP 2F C 0253 87-010-190-080 0E C-CAP,S 0.01-50 Z F C2012 USM CX-NDS8
! O AMP 2F CN 0101 87-A61-109-010 0E CONN,7P V TID-A USM CX-NDS8
! O AMP 2F CN 0102 87-099-198-010 0E CONN,10P V BLK 6216 USM CX-NDS8
S AMP 2F D 0101 87-A40-269-080 0E C-DIODE,MC2836 USM CX-NDS8
S AMP 2F D 0103 87-A40-313-080 0E C-DIODE,MC2840 USM CX-NDS8
S AMP 2F D 0160 87-A40-270-080 0E C-DIODE,MC2838 USM CX-NDS8
S AMP 2F D 0201 87-020-465-080 0E DIODE,1SS133 USM CX-NDS8
S AMP 2F D 0202 87-020-465-080 0E DIODE,1SS133 USM CX-NDS8
S AMP 2F D 0203 87-020-465-080 0E DIODE,1SS133 USM CX-NDS8
S AMP 2F D 0204 87-020-465-080 0E DIODE,1SS133 USM CX-NDS8
S AMP 2F D 0205 87-020-465-080 0E DIODE,1SS133 USM CX-NDS8
S AMP 2F D 0207 87-020-465-080 0E DIODE,1SS133 USM CX-NDS8
S AMP 2F D 0208 87-020-465-080 0E DIODE,1SS133 USM CX-NDS8
S AMP 2F D 0209 87-A40-535-080 0E DIODE,1N5393-GOODARK USM CX-NDS8
S AMP 2F D 0210 87-A40-535-080 0E DIODE,1N5393-GOODARK USM CX-NDS8
S AMP 2F D 0211 87-A40-754-080 0E ZENER,UZ6.8BSC USM CX-NDS8
S AMP 2F D 0212 87-A40-754-080 0E ZENER,UZ6.8BSC USM CX-NDS8
S AMP 2F D 0214 87-A40-313-080 0E C-DIODE,MC2840 USM CX-NDS8
S AMP 2F D 0216 87-020-465-080 0E DIODE,1SS133 USM CX-NDS8
S AMP 2F D 0218 87-A40-535-080 0E DIODE,1N5393-GOODARK USM CX-NDS8
S AMP 2F D 0219 87-A40-535-080 0E DIODE,1N5393-GOODARK USM CX-NDS8
! S AMP 2F IC 0101 87-A21-397-010 2A IC,STK490-070 USM CX-NDS8
O AMP 2F J 0101 87-A61-485-010 — JACK,PIN 4P RWBO TC58 118-14 USM CX-NDS8
X AMP 2F JR 0102 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X AMP 2F JR 0103 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X AMP 2F JR 0104 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X AMP 2F JR 0105 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X AMP 2F JR 0107 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X AMP 2F JR 0108 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
O AMP 2F L 0151 87-A50-610-010 0E COIL,1UH K(MDEC) USM CX-NDS8

PARTS LIST
-6-
! =! SAFTY PARTS
C=Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
K NO. =Only use japanese.
C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX
O AMP 2F L 0152 87-A50-610-010 0E COIL,1UH K(MDEC) USM CX-NDS8
O AMP 2F L 0251 87-A50-610-010 0E COIL,1UH K(MDEC) USM CX-NDS8
S AMP 2F Q 0101 87-A30-107-070 0E C-TR,CMBT5401 USM CX-NDS8
S AMP 2F Q 0102 87-A30-107-070 0E C-TR,CMBT5401 USM CX-NDS8
S AMP 2F Q 0160 87-A30-107-070 0E C-TR,CMBT5401 USM CX-NDS8
S AMP 2F Q 0161 87-A30-106-040 0E C-TR,CMBT5551 USM CX-NDS8
S AMP 2F Q 0201 87-A30-075-080 0E C-TR,2SA1235F USM CX-NDS8
S AMP 2F Q 0202 87-A30-076-080 0E C-TR,2SC3052F USM CX-NDS8
S AMP 2F Q 0203 87-A30-075-080 0E C-TR,2SA1235F USM CX-NDS8
S AMP 2F Q 0204 87-A30-076-080 0E C-TR,2SC3052F USM CX-NDS8
S AMP 2F Q 0206 87-A30-190-080 0E TR,CC5551 USM CX-NDS8
S AMP 2F Q 0207 87-A30-076-080 0E C-TR,2SC3052F USM CX-NDS8
S AMP 2F Q 0208 87-A30-076-080 0E C-TR,2SC3052F USM CX-NDS8
S AMP 2F Q 0209 87-A30-256-010 1A TR,2SD1933 USM CX-NDS8
S AMP 2F Q 0210 87-A30-255-010 1A TR,2SB1342 USM CX-NDS8
S AMP 2F Q 0211 87-A30-256-010 1A TR,2SD1933 USM CX-NDS8
S AMP 2F Q 0212 87-A30-255-010 1A TR,2SB1342 USM CX-NDS8
S AMP 2F Q 0213 87-A30-107-070 0E C-TR,CMBT5401 USM CX-NDS8
S AMP 2F Q 0214 87-A30-074-080 0E C-TR,RT1P 141C USM CX-NDS8
S AMP 2F Q 0215 87-A30-075-080 0E C-TR,2SA1235F USM CX-NDS8
S AMP 2F Q 0217 87-A30-075-080 0E C-TR,2SA1235F USM CX-NDS8
X AMP 2F R 0101 88-118-223-080 0E C-RES,S 22K-1/10W J USM CX-NDS8
X AMP 2F R 0102 88-118-223-080 0E C-RES,S 22K-1/10W J USM CX-NDS8
X AMP 2F R 0103 88-118-333-080 0E C-RES,S 33K-1/10W J USM CX-NDS8
X AMP 2F R 0104 88-118-333-080 0E C-RES,S 33K-1/10W J USM CX-NDS8
X AMP 2F R 0105 88-118-101-080 0E C-RES,S 100-1/10W J USM CX-NDS8
X AMP 2F R 0106 88-118-101-080 0E C-RES,S 100-1/10W J USM CX-NDS8
X AMP 2F R 0109 88-118-681-080 0E C-RES,S 680-1/10W J USM CX-NDS8
X AMP 2F R 0110 88-118-681-080 0E C-RES,S 680-1/10W J USM CX-NDS8
X AMP 2F R 0111 88-118-333-080 0E C-RES,S 33K-1/10W J USM CX-NDS8
X AMP 2F R 0112 88-118-333-080 0E C-RES,S 33K-1/10W J USM CX-NDS8
X AMP 2F R 0121 88-128-332-080 0E C-RES, 3.3K-1/8W J USM CX-NDS8
X AMP 2F R 0123 88-128-332-080 0E C-RES, 3.3K-1/8W J USM CX-NDS8
X AMP 2F R 0125 88-128-332-080 0E C-RES, 3.3K-1/8W J USM CX-NDS8
X AMP 2F R 0126 88-128-332-080 0E C-RES, 3.3K-1/8W J USM CX-NDS8
X AMP 2F R 0127 88-118-102-080 0E C-RES,S 1K-1/10W J USM CX-NDS8
X AMP 2F R 0128 88-118-102-080 0E C-RES,S 1K-1/10W J USM CX-NDS8
O AMP 2F R 0131 87-A00-258-080 0E RES,M/F 0.22-1W J USM CX-NDS8
O AMP 2F R 0132 87-A00-258-080 0E RES,M/F 0.22-1W J USM CX-NDS8
X AMP 2F R 0133 88-118-222-080 0E C-RES,S 2.2K-1/10W J USM CX-NDS8
X AMP 2F R 0134 88-118-222-080 0E C-RES,S 2.2K-1/10W J USM CX-NDS8
X AMP 2F R 0135 88-118-222-080 0E C-RES,S 2.2K-1/10W J USM CX-NDS8
X AMP 2F R 0136 88-118-222-080 0E C-RES,S 2.2K-1/10W J USM CX-NDS8
X AMP 2F R 0137 88-118-101-080 0E C-RES,S 100-1/10W J USM CX-NDS8
X AMP 2F R 0138 88-118-101-080 0E C-RES,S 100-1/10W J USM CX-NDS8
X AMP 2F R 0139 88-118-153-080 0E C-RES,S 15K-1/10W J USM CX-NDS8
X AMP 2F R 0140 88-118-153-080 0E C-RES,S 15K-1/10W J USM CX-NDS8
X AMP 2F R 0141 88-118-102-080 0E C-RES,S 1K-1/10W J USM CX-NDS8
X AMP 2F R 0142 88-118-102-080 0E C-RES,S 1K-1/10W J USM CX-NDS8
X AMP 2F R 0145 88-118-563-080 0E C-RES,S 56K-1/10W J USM CX-NDS8
X AMP 2F R 0146 88-118-563-080 0E C-RES,S 56K-1/10W J USM CX-NDS8
X AMP 2F R 0151 88-130-100-080 0E RES,10-1/4W J USM CX-NDS8
X AMP 2F R 0152 88-130-100-080 0E RES,10-1/4W J USM CX-NDS8
X AMP 2F R 0153 88-118-562-080 0E C-RES,S 5.6K-1/10W J USM CX-NDS8
X AMP 2F R 0154 88-118-562-080 0E C-RES,S 5.6K-1/10W J USM CX-NDS8
X AMP 2F R 0155 88-128-100-080 0E C-RES, 10-1/8W J USM CX-NDS8
X AMP 2F R 0156 88-128-100-080 0E C-RES, 10-1/8W J USM CX-NDS8
X AMP 2F R 0160 88-118-103-080 0E C-RES,S 10K-1/10W J USM CX-NDS8
X AMP 2F R 0161 88-118-473-080 0E C-RES,S 47K-1/10W J USM CX-NDS8
X AMP 2F R 0162 88-118-103-080 0E C-RES,S 10K-1/10W J USM CX-NDS8
X AMP 2F R 0163 88-118-103-080 0E C-RES,S 10K-1/10W J USM CX-NDS8
X AMP 2F R 0164 88-118-103-080 0E C-RES,S 10K-1/10W J USM CX-NDS8
X AMP 2F R 0201 88-118-472-080 0E C-RES,S 4.7K-1/10W J USM CX-NDS8
X AMP 2F R 0202 88-118-333-080 0E C-RES,S 33K-1/10W J USM CX-NDS8
X AMP 2F R 0203 88-118-101-080 0E C-RES,S 100-1/10W J USM CX-NDS8
X AMP 2F R 0204 88-118-102-080 0E C-RES,S 1K-1/10W J USM CX-NDS8
X AMP 2F R 0205 88-118-103-080 0E C-RES,S 10K-1/10W J USM CX-NDS8
X AMP 2F R 0206 88-118-101-080 0E C-RES,S 100-1/10W J USM CX-NDS8
X AMP 2F R 0207 88-118-101-080 0E C-RES,S 100-1/10W J USM CX-NDS8
X AMP 2F R 0208 88-118-472-080 0E C-RES,S 4.7K-1/10W J USM CX-NDS8

PARTS LIST
-7-
! =! SAFTY PARTS
C=Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
K NO. =Only use japanese.
C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX
X AMP 2F R 0209 88-128-222-080 0E C-RES, 2.2K-1/8W J USM CX-NDS8
X AMP 2F R 0210 88-118-333-080 0E C-RES,S 33K-1/10W J USM CX-NDS8
X AMP 2F R 0211 88-128-222-080 0E C-RES, 2.2K-1/8W J USM CX-NDS8
X AMP 2F R 0212 88-118-471-080 0E C-RES,S 470-1/10W J USM CX-NDS8
X AMP 2F R 0213 88-118-152-080 0E C-RES,S 1.5K-1/10W J USM CX-NDS8
X AMP 2F R 0214 88-118-222-080 0E C-RES,S 2.2K-1/10W J USM CX-NDS8
X AMP 2F R 0215 88-118-473-080 0E C-RES,S 47K-1/10W J USM CX-NDS8
X AMP 2F R 0216 88-118-390-080 0E C-RES,S 39-1/10W J USM CX-NDS8
X AMP 2F R 0217 88-118-331-080 0E C-RES,S 330-1/10W J USM CX-NDS8
O AMP 2F R 0218 87-A00-258-080 0E RES,M/F 0.22-1W J USM CX-NDS8
X AMP 2F R 0219 88-118-471-080 0E C-RES,S 470-1/10W J USM CX-NDS8
X AMP 2F R 0220 88-118-471-080 0E C-RES,S 470-1/10W J USM CX-NDS8
X AMP 2F R 0221 88-118-101-080 0E C-RES,S 100-1/10W J USM CX-NDS8
X AMP 2F R 0222 88-118-222-080 0E C-RES,S 2.2K-1/10W J USM CX-NDS8
X AMP 2F R 0223 88-118-222-080 0E C-RES,S 2.2K-1/10W J USM CX-NDS8
X AMP 2F R 0224 88-118-102-080 0E C-RES,S 1K-1/10W J USM CX-NDS8
X AMP 2F R 0226 88-118-153-080 0E C-RES,S 15K-1/10W J USM CX-NDS8
X AMP 2F R 0227 88-118-223-080 0E C-RES,S 22K-1/10W J USM CX-NDS8
X AMP 2F R 0228 88-118-223-080 0E C-RES,S 22K-1/10W J USM CX-NDS8
X AMP 2F R 0229 88-118-563-080 0E C-RES,S 56K-1/10W J USM CX-NDS8
X AMP 2F R 0231 88-118-473-080 0E C-RES,S 47K-1/10W J USM CX-NDS8
X AMP 2F R 0232 88-118-272-080 0E C-RES,S 2.7K-1/10W J USM CX-NDS8
X AMP 2F R 0233 88-118-103-080 0E C-RES,S 10K-1/10W J USM CX-NDS8
X AMP 2F R 0235 88-118-562-080 0E C-RES,S 5.6K-1/10W J USM CX-NDS8
X AMP 2F R 0236 88-118-562-080 0E C-RES,S 5.6K-1/10W J USM CX-NDS8
X AMP 2F R 0237 88-118-104-080 0E C-RES,S 100K-1/10W J USM CX-NDS8
X AMP 2F R 0238 88-118-271-080 0E C-RES,S 270-1/10W J USM CX-NDS8
X AMP 2F R 0239 88-118-102-080 0E C-RES,S 1K-1/10W J USM CX-NDS8
X AMP 2F R 0251 88-130-100-080 0E RES,10-1/4W J USM CX-NDS8
X AMP 2F R 0252 88-118-562-080 0E C-RES,S 5.6K-1/10W J USM CX-NDS8
X AMP 2F R 0253 88-128-100-080 0E C-RES, 10-1/8W J USM CX-NDS8
O AMP 2F TH 0201 87-A91-042-080 0E C-THMS,100K 55001 USM CX-NDS8
O APPEARANCE 8A-NF6-003-010 1C CABI,BOTTOM USM CX-NDS8
O APPEARANCE 8A-NF6-005-010 1D PANEL,TOP USM CX-NDS8
O APPEARANCE 8A-NF6-006-110 1D BOX,CASS 1 USM CX-NDS8
O APPEARANCE 8A-NF6-007-110 1D BOX,CASS 2 USM CX-NDS8
O APPEARANCE 8A-NF6-008-010 1C PANEL,TRAY USM CX-NDS8
O APPEARANCE 8A-NF6-009-110 1B PANEL,CD USM CX-NDS8
O APPEARANCE 8A-NF6-010-010 1D PANEL,DIRECT USM CX-NDS8
O APPEARANCE 8A-NF6-018-010 0E WINDOW,CASS 1 USM CX-NDS8
O APPEARANCE 8A-NF6-019-010 0E WINDOW,CASS 2 USM CX-NDS8
O APPEARANCE 8A-NF6-041-010 1A RING,VOL USM CX-NDS8
O APPEARANCE 8A-NF6-058-010 2M CABI,STEEL HR USM CX-NDS8
O APPEARANCE 8A-NFG-002-010 1B WINDOW,DISP U USM CX-NDS8
O APPEARANCE 8A-NFG-008-010 — PANEL,FR U USM CX-NDS8
O APPEARANCE 8A-NFG-010-010 — COVER, REAR USM USM CX-NDS8
O APPEARANCE 8A-NFG-011-010 1C PANEL,REAR USM USM CX-NDS8
O APPEARANCE * 8A-NFG-001-010 1H CABI,FR U USM CX-NDS8
O CD 84-ZG1-245-210 0E CAP,OPTICAL USM CX-NDS8
X CD M8-AZG-19P-230 — AZG-1 ZD3RNDM USM CX-NDS8
O DOLBY DIGITAL 87-067-579-010 0E BVT2+3-8 W/0 SL0T USM CX-NDS8
X DOLBY DIGITAL 88-AR1-219-010 0E HT-SINK,TR USM CX-NDS8
X DOLBY DIGITAL 89-990-243-410 0E WIRE,U24X0-24-5 USM CX-NDS8
X DOLBY DIGITAL 8Z-NFD-630-210 1C PWB,AC-3 USM CX-NDS8
O DOLBY DIGITAL C 0101 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0102 87-010-374-080 0E CAP,E 47-10 M 11L SME USM CX-NDS8
O DOLBY DIGITAL C 0103 87-010-314-080 0E C-CAP,S 22P-50 J CH GRM USM CX-NDS8
O DOLBY DIGITAL C 0104 87-010-313-080 0E C-CAP,S 18P-50 J CH GRM USM CX-NDS8
O DOLBY DIGITAL C 0105 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0106 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USM CX-NDS8
O DOLBY DIGITAL C 0107 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0108 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0109 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0110 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0111 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0112 87-010-404-080 0E CAP,E 4.7-50 M 11L SME USM CX-NDS8
O DOLBY DIGITAL C 0113 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0114 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0115 87-010-374-080 0E CAP,E 47-10 M 11L SME USM CX-NDS8
O DOLBY DIGITAL C 0116 87-012-140-080 0E C-CAP,S 470P-50 J CH USM CX-NDS8

PARTS LIST
-8-
! =! SAFTY PARTS
C=Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
K NO. =Only use japanese.
C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX
O DOLBY DIGITAL C 0117 87-010-198-080 0E C-CAP,S 0.022-25 K B C2012 USM CX-NDS8
O DOLBY DIGITAL C 0118 87-010-401-080 0E CAP,E 1-50 M 11L SME USM CX-NDS8
O DOLBY DIGITAL C 0119 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0120 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0121 87-010-401-080 0E CAP,E 1-50 M 11L SME USM CX-NDS8
O DOLBY DIGITAL C 0122 87-010-311-080 0E C-CAP,S 12P-50 J CH GRM USM CX-NDS8
O DOLBY DIGITAL C 0123 87-010-311-080 0E C-CAP,S 12P-50 J CH GRM USM CX-NDS8
O DOLBY DIGITAL C 0124 87-010-263-080 0E CAP,E 100-10 M 11L SME USM CX-NDS8
O DOLBY DIGITAL C 0125 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0126 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0127 87-010-555-040 0E CAP,E 100-10 M 5L SRE USM CX-NDS8
O DOLBY DIGITAL C 0128 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0129 87-010-384-080 0E CAP,E 100-25 M 11L SME USM CX-NDS8
X DOLBY DIGITAL C 0130 88-118-102-080 0E C-RES,S 1K-1/10W J USM CX-NDS8
O DOLBY DIGITAL C 0131 87-010-263-080 0E CAP,E 100-10 M 11L SME USM CX-NDS8
O DOLBY DIGITAL C 0132 87-010-401-080 0E CAP,E 1-50 M 11L SME USM CX-NDS8
O DOLBY DIGITAL C 0135 87-010-405-080 0E CAP,E 10-50 M 11L SME USM CX-NDS8
O DOLBY DIGITAL C 0136 87-010-405-080 0E CAP,E 10-50 M 11L SME USM CX-NDS8
O DOLBY DIGITAL C 0140 87-010-552-040 0E CAP,E 22-16 M 5L SRE USM CX-NDS8
O DOLBY DIGITAL C 0141 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0143 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0144 87-010-312-080 0E C-CAP,S 15P-50 J CH GRM USM CX-NDS8
O DOLBY DIGITAL C 0145 87-012-154-080 0E C-CAP,S 150P-50 J CH GRM USM CX-NDS8
O DOLBY DIGITAL C 0146 87-012-154-080 0E C-CAP,S 150P-50 J CH GRM USM CX-NDS8
O DOLBY DIGITAL C 0147 87-010-405-080 0E CAP,E 10-50 M 11L SME USM CX-NDS8
O DOLBY DIGITAL C 0148 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0149 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0150 87-010-405-080 0E CAP,E 10-50 M 11L SME USM CX-NDS8
O DOLBY DIGITAL C 0151 87-010-405-080 0E CAP,E 10-50 M 11L SME USM CX-NDS8
O DOLBY DIGITAL C 0152 87-010-405-080 0E CAP,E 10-50 M 11L SME USM CX-NDS8
O DOLBY DIGITAL C 0153 87-010-178-080 0E C-CAP,S 1000P-50 K B C2012 USM CX-NDS8
O DOLBY DIGITAL C 0154 87-010-178-080 0E C-CAP,S 1000P-50 K B C2012 USM CX-NDS8
O DOLBY DIGITAL C 0155 87-A10-369-080 0E C-CAP,S 0.47-16 K B USM CX-NDS8
O DOLBY DIGITAL C 0157 87-012-154-080 0E C-CAP,S 150P-50 J CH GRM USM CX-NDS8
O DOLBY DIGITAL C 0158 87-012-154-080 0E C-CAP,S 150P-50 J CH GRM USM CX-NDS8
O DOLBY DIGITAL C 0159 87-010-178-080 0E C-CAP,S 1000P-50 K B C2012 USM CX-NDS8
O DOLBY DIGITAL C 0160 87-010-178-080 0E C-CAP,S 1000P-50 K B C2012 USM CX-NDS8
O DOLBY DIGITAL C 0161 87-010-405-080 0E CAP,E 10-50 M 11L SME USM CX-NDS8
O DOLBY DIGITAL C 0162 87-010-405-080 0E CAP,E 10-50 M 11L SME USM CX-NDS8
O DOLBY DIGITAL C 0163 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0164 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0165 87-A10-369-080 0E C-CAP,S 0.47-16 K B USM CX-NDS8
O DOLBY DIGITAL C 0166 87-010-405-080 0E CAP,E 10-50 M 11L SME USM CX-NDS8
O DOLBY DIGITAL C 0167 87-010-405-080 0E CAP,E 10-50 M 11L SME USM CX-NDS8
O DOLBY DIGITAL C 0169 87-012-154-080 0E C-CAP,S 150P-50 J CH GRM USM CX-NDS8
O DOLBY DIGITAL C 0170 87-012-154-080 0E C-CAP,S 150P-50 J CH GRM USM CX-NDS8
O DOLBY DIGITAL C 0171 87-010-178-080 0E C-CAP,S 1000P-50 K B C2012 USM CX-NDS8
O DOLBY DIGITAL C 0172 87-010-178-080 0E C-CAP,S 1000P-50 K B C2012 USM CX-NDS8
O DOLBY DIGITAL C 0173 87-018-209-080 0E CAP,TC U 0.1-50 Z F UP050 USM CX-NDS8
O DOLBY DIGITAL C 0174 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0175 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0177 87-A10-369-080 0E C-CAP,S 0.47-16 K B USM CX-NDS8
O DOLBY DIGITAL C 0178 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0179 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0180 87-010-405-080 0E CAP,E 10-50 M 11L SME USM CX-NDS8
O DOLBY DIGITAL C 0181 87-010-405-080 0E CAP,E 10-50 M 11L SME USM CX-NDS8
O DOLBY DIGITAL C 0182 87-010-405-080 0E CAP,E 10-50 M 11L SME USM CX-NDS8
O DOLBY DIGITAL C 0183 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0184 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0185 87-010-405-080 0E CAP,E 10-50 M 11L SME USM CX-NDS8
O DOLBY DIGITAL C 0186 87-010-405-080 0E CAP,E 10-50 M 11L SME USM CX-NDS8
O DOLBY DIGITAL C 0187 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0188 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0189 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0190 87-010-405-080 0E CAP,E 10-50 M 11L SME USM CX-NDS8
O DOLBY DIGITAL C 0191 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0192 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0193 87-010-154-080 0E C-CAP,S 10P-50 D CH GRM USM CX-NDS8
O DOLBY DIGITAL C 0194 87-010-154-080 0E C-CAP,S 10P-50 D CH GRM USM CX-NDS8
O DOLBY DIGITAL C 0195 87-010-405-080 0E CAP,E 10-50 M 11L SME USM CX-NDS8

PARTS LIST
-9-
! =! SAFTY PARTS
C=Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
K NO. =Only use japanese.
C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX
O DOLBY DIGITAL C 0196 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0197 87-010-405-080 0E CAP,E 10-50 M 11L SME USM CX-NDS8
O DOLBY DIGITAL C 0198 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0199 87-A10-369-080 0E C-CAP,S 0.47-16 K B USM CX-NDS8
O DOLBY DIGITAL C 0201 87-010-154-080 0E C-CAP,S 10P-50 D CH GRM USM CX-NDS8
O DOLBY DIGITAL C 0202 87-010-154-080 0E C-CAP,S 10P-50 D CH GRM USM CX-NDS8
O DOLBY DIGITAL C 0203 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0204 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0205 87-A10-369-080 0E C-CAP,S 0.47-16 K B USM CX-NDS8
O DOLBY DIGITAL C 0206 87-010-401-080 0E CAP,E 1-50 M 11L SME USM CX-NDS8
O DOLBY DIGITAL C 0207 87-010-405-080 0E CAP,E 10-50 M 11L SME USM CX-NDS8
O DOLBY DIGITAL C 0208 87-010-405-080 0E CAP,E 10-50 M 11L SME USM CX-NDS8
O DOLBY DIGITAL C 0209 87-010-154-080 0E C-CAP,S 10P-50 D CH GRM USM CX-NDS8
O DOLBY DIGITAL C 0210 87-010-154-080 0E C-CAP,S 10P-50 D CH GRM USM CX-NDS8
O DOLBY DIGITAL C 0211 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0212 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0213 87-A10-369-080 0E C-CAP,S 0.47-16 K B USM CX-NDS8
O DOLBY DIGITAL C 0214 87-010-405-080 0E CAP,E 10-50 M 11L SME USM CX-NDS8
O DOLBY DIGITAL C 0215 87-010-405-080 0E CAP,E 10-50 M 11L SME USM CX-NDS8
O DOLBY DIGITAL C 0216 87-010-405-080 0E CAP,E 10-50 M 11L SME USM CX-NDS8
O DOLBY DIGITAL C 0217 87-A10-793-080 0E C-CAP,S 0.12-16 K B USM CX-NDS8
O DOLBY DIGITAL C 0218 87-A10-793-080 0E C-CAP,S 0.12-16 K B USM CX-NDS8
O DOLBY DIGITAL C 0219 87-010-993-080 0E C-CAP,S 0.056-25 K B MK212 USM CX-NDS8
O DOLBY DIGITAL C 0220 87-A10-369-080 0E C-CAP,S 0.47-16 K B USM CX-NDS8
O DOLBY DIGITAL C 0222 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0224 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0225 87-012-155-080 0E C-CAP,S 180P-50 J CH GRM USM CX-NDS8
O DOLBY DIGITAL C 0226 87-012-155-080 0E C-CAP,S 180P-50 J CH GRM USM CX-NDS8
O DOLBY DIGITAL C 0227 87-010-405-080 0E CAP,E 10-50 M 11L SME USM CX-NDS8
O DOLBY DIGITAL C 0228 87-010-405-080 0E CAP,E 10-50 M 11L SME USM CX-NDS8
O DOLBY DIGITAL C 0230 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0232 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0236 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0237 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0238 87-010-314-080 0E C-CAP,S 22P-50 J CH GRM USM CX-NDS8
O DOLBY DIGITAL C 0239 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0240 87-010-314-080 0E C-CAP,S 22P-50 J CH GRM USM CX-NDS8
O DOLBY DIGITAL C 0241 87-010-405-080 0E CAP,E 10-50 M 11L SME USM CX-NDS8
O DOLBY DIGITAL C 0242 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0243 87-010-322-080 0E C-CAP,S 100P-50 J CH GRM USM CX-NDS8
O DOLBY DIGITAL C 0260 87-010-378-080 0E CAP,E 10-16 M 11L SME USM CX-NDS8
O DOLBY DIGITAL C 0261 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0270 87-012-155-080 0E C-CAP,S 180P-50 J CH GRM USM CX-NDS8
O DOLBY DIGITAL C 0301 87-012-393-080 0E C-CAP,S 0.22-16 K W5R CM/CB USM CX-NDS8
O DOLBY DIGITAL C 0302 87-012-393-080 0E C-CAP,S 0.22-16 K W5R CM/CB USM CX-NDS8
O DOLBY DIGITAL C 0303 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0304 87-012-393-080 0E C-CAP,S 0.22-16 K W5R CM/CB USM CX-NDS8
O DOLBY DIGITAL C 0305 87-010-184-080 0E C-CAP,S 3300P-50 K B C2012 USM CX-NDS8
O DOLBY DIGITAL C 0306 87-010-179-080 0E C-CAP,S 1200P-50 K B GRM USM CX-NDS8
O DOLBY DIGITAL C 0307 87-016-669-080 0E C-CAP,S 0.1-25 K B USM CX-NDS8
O DOLBY DIGITAL C 0308 87-016-669-080 0E C-CAP,S 0.1-25 K B USM CX-NDS8
O DOLBY DIGITAL C 0309 87-010-184-080 0E C-CAP,S 3300P-50 K B C2012 USM CX-NDS8
O DOLBY DIGITAL C 0310 87-010-179-080 0E C-CAP,S 1200P-50 K B GRM USM CX-NDS8
O DOLBY DIGITAL C 0311 87-012-393-080 0E C-CAP,S 0.22-16 K W5R CM/CB USM CX-NDS8
O DOLBY DIGITAL C 0312 87-010-374-080 0E CAP,E 47-10 M 11L SME USM CX-NDS8
O DOLBY DIGITAL C 0313 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0315 87-010-374-080 0E CAP,E 47-10 M 11L SME USM CX-NDS8
O DOLBY DIGITAL C 0316 87-010-374-080 0E CAP,E 47-10 M 11L SME USM CX-NDS8
O DOLBY DIGITAL C 0317 87-010-183-080 0E C-CAP,S 2700P-50 K B GRM USM CX-NDS8
O DOLBY DIGITAL C 0318 87-010-183-080 0E C-CAP,S 2700P-50 K B GRM USM CX-NDS8
O DOLBY DIGITAL C 0319 87-010-545-080 0E CAP,E 0.22-50 M 11L SME USM CX-NDS8
O DOLBY DIGITAL C 0320 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0321 87-010-263-080 0E CAP,E 100-10 M 11L SME USM CX-NDS8
O DOLBY DIGITAL C 0401 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DOLBY DIGITAL C 0402 87-010-404-080 0E CAP,E 4.7-50 M 11L SME USM CX-NDS8
O DOLBY DIGITAL C 0403 87-010-401-080 0E CAP,E 1-50 M 11L SME USM CX-NDS8
O DOLBY DIGITAL C 0405 87-018-147-080 0E CAP,TC U 10P-50 J CH UP050 USM CX-NDS8
O DOLBY DIGITAL C 0502 87-010-322-080 0E C-CAP,S 100P-50 J CH GRM USM CX-NDS8
O DOLBY DIGITAL C 0506 87-010-322-080 0E C-CAP,S 100P-50 J CH GRM USM CX-NDS8
O DOLBY DIGITAL C 0508 87-018-119-080 0E CAP,TC U 100P-50 K B UP050 USM CX-NDS8

PARTS LIST
-10-
! =! SAFTY PARTS
C=Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
K NO. =Only use japanese.
C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX
O DOLBY DIGITAL C 0511 87-018-113-080 0E CAP,TC U 33P-50 J SL UP050 USM CX-NDS8
O DOLBY DIGITAL C 0512 87-A11-132-080 0E CAP,TC U 0.01-50 K B USM CX-NDS8
! O DOLBY DIGITAL CN 0101 87-A60-057-010 0E CONN,11P V 9604S-11C USM CX-NDS8
O DOLBY DIGITAL CN 0102 87-A60-627-010 0E CONN,10P V 2MM JMT USM CX-NDS8
O DOLBY DIGITAL CN 0105 87-A60-627-010 0E CONN,10P V 2MM JMT USM CX-NDS8
O DOLBY DIGITAL CNA0101 8A-NFG-650-010 1A CONN ASSY,6P ANF-G USM CX-NDS8
S DOLBY DIGITAL D 0101 87-020-465-080 0E DIODE,1SS133 USM CX-NDS8
S DOLBY DIGITAL D 0301 87-017-931-080 0E ZENER,MTZJ5.6B USM CX-NDS8
S DOLBY DIGITAL D 0401 87-020-465-080 0E DIODE,1SS133 USM CX-NDS8
S DOLBY DIGITAL D 0402 87-020-465-080 0E DIODE,1SS133 USM CX-NDS8
S DOLBY DIGITAL D 0403 87-020-465-080 0E DIODE,1SS133 USM CX-NDS8
S DOLBY DIGITAL D 0404 87-A40-348-080 0E ZENER,MTZJ3.3A USM CX-NDS8
S DOLBY DIGITAL D 0410 87-A40-737-080 0E ZENER,UZ2.2BSB USM CX-NDS8
O DOLBY DIGITAL FB 0102 87-008-372-080 0E FLTR,EMI BL01 RN1 USM CX-NDS8
O DOLBY DIGITAL FB 0103 87-008-372-080 0E FLTR,EMI BL01 RN1 USM CX-NDS8
O DOLBY DIGITAL FB 0104 87-008-372-080 0E FLTR,EMI BL01 RN1 USM CX-NDS8
O DOLBY DIGITAL FB 0105 87-008-372-080 0E FLTR,EMI BL01 RN1 USM CX-NDS8
O DOLBY DIGITAL FB 0106 87-008-372-080 0E FLTR,EMI BL01 RN1 USM CX-NDS8
O DOLBY DIGITAL FB 0107 87-008-474-080 0E F-BEAD, BL02RN1-R62T2 EMI USM CX-NDS8
O DOLBY DIGITAL FB 0108 87-008-474-080 0E F-BEAD, BL02RN1-R62T2 EMI USM CX-NDS8
O DOLBY DIGITAL FB 0109 87-008-474-080 0E F-BEAD, BL02RN1-R62T2 EMI USM CX-NDS8
O DOLBY DIGITAL FB 0110 87-003-223-080 0E F-BEAD, BL02RN2 USM CX-NDS8
O DOLBY DIGITAL FB 0112 87-003-223-080 0E F-BEAD, BL02RN2 USM CX-NDS8
S DOLBY DIGITAL IC 0101 87-A20-823-010 2D C-IC,YSS248 USM CX-NDS8
S DOLBY DIGITAL IC 0102 87-A20-824-010 2C C-IC,CS4226 USM CX-NDS8
S DOLBY DIGITAL IC 0103 87-020-903-010 1B IC,NJM7805FA USM CX-NDS8
S DOLBY DIGITAL IC 0105 87-017-022-080 1A C-IC,NJM2068M-D(T1) USM CX-NDS8
S DOLBY DIGITAL IC 0106 87-017-022-080 1A C-IC,NJM2068M-D(T1) USM CX-NDS8
S DOLBY DIGITAL IC 0107 87-017-022-080 1A C-IC,NJM2068M-D(T1) USM CX-NDS8
S DOLBY DIGITAL IC 0108 87-020-784-080 1B C-IC,TC4053BF USM CX-NDS8
S DOLBY DIGITAL IC 0109 87-020-784-080 1B C-IC,TC4053BF USM CX-NDS8
S DOLBY DIGITAL IC 0110 87-017-022-080 1A C-IC,NJM2068M-D(T1) USM CX-NDS8
S DOLBY DIGITAL IC 0111 87-017-022-080 1A C-IC,NJM2068M-D(T1) USM CX-NDS8
S DOLBY DIGITAL IC 0112 87-017-022-080 1A C-IC,NJM2068M-D(T1) USM CX-NDS8
S DOLBY DIGITAL IC 0113 87-017-022-080 1A C-IC,NJM2068M-D(T1) USM CX-NDS8
S DOLBY DIGITAL IC 0114 87-017-022-080 1A C-IC,NJM2068M-D(T1) USM CX-NDS8
S DOLBY DIGITAL IC 0117 87-A21-018-040 1H C-IC,M65849BFP631D USM CX-NDS8
S DOLBY DIGITAL IC 0118 87-001-604-080 1A C-IC,TC74HCU04M USM CX-NDS8
S DOLBY DIGITAL IC 0119 87-020-784-080 1B C-IC,TC4053BF USM CX-NDS8
S DOLBY DIGITAL IC 0120 87-017-022-080 1A C-IC,NJM2068M-D(T1) USM CX-NDS8
S DOLBY DIGITAL IC 0121 87-002-298-080 1A C-IC,TC74HC00AF USM CX-NDS8
X DOLBY DIGITAL JR 0103 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0104 88-129-000-080 0E C-JUMPER,3216 USM CX-NDS8
X DOLBY DIGITAL JR 0106 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0107 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0108 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0109 88-129-000-080 0E C-JUMPER,3216 USM CX-NDS8
X DOLBY DIGITAL JR 0110 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0111 88-129-000-080 0E C-JUMPER,3216 USM CX-NDS8
X DOLBY DIGITAL JR 0112 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0113 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0114 88-129-000-080 0E C-JUMPER,3216 USM CX-NDS8
X DOLBY DIGITAL JR 0115 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0116 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0117 88-129-000-080 0E C-JUMPER,3216 USM CX-NDS8
X DOLBY DIGITAL JR 0119 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0120 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0121 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0123 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0124 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0125 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0126 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0127 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0128 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0129 88-129-000-080 0E C-JUMPER,3216 USM CX-NDS8
X DOLBY DIGITAL JR 0131 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0132 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0133 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0134 88-129-000-080 0E C-JUMPER,3216 USM CX-NDS8
X DOLBY DIGITAL JR 0135 88-118-000-080 0E C-JUMPER,S USM CX-NDS8

PARTS LIST
-11-
! =! SAFTY PARTS
C=Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
K NO. =Only use japanese.
C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX
X DOLBY DIGITAL JR 0136 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0137 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0138 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0139 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0140 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0141 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0142 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0143 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0144 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0145 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0146 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0147 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0148 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0149 88-129-000-080 0E C-JUMPER,3216 USM CX-NDS8
X DOLBY DIGITAL JR 0150 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0151 88-129-000-080 0E C-JUMPER,3216 USM CX-NDS8
X DOLBY DIGITAL JR 0152 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0153 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0154 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0155 88-129-000-080 0E C-JUMPER,3216 USM CX-NDS8
X DOLBY DIGITAL JR 0156 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0160 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0161 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0165 88-129-000-080 0E C-JUMPER,3216 USM CX-NDS8
X DOLBY DIGITAL JR 0166 88-129-000-080 0E C-JUMPER,3216 USM CX-NDS8
X DOLBY DIGITAL JR 0167 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0168 88-129-000-080 0E C-JUMPER,3216 USM CX-NDS8
X DOLBY DIGITAL JR 0170 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0175 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL JR 0181 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
O DOLBY DIGITAL L 0102 87-A50-095-010 1A COIL,68UH RCR875D USM CX-NDS8
O DOLBY DIGITAL L 0104 87-008-501-080 0E FLTR, DSS306-55 USM CX-NDS8
O DOLBY DIGITAL L 0106 87-003-097-080 0E COIL,1.0UH K LAL02 USM CX-NDS8
X DOLBY DIGITAL P 0001 86-NFZ-222-010 0E PIN,DIA1-5.6 USM CX-NDS8
S DOLBY DIGITAL Q 0101 87-A30-071-080 0E C-TR,RT1N 144C USM CX-NDS8
S DOLBY DIGITAL Q 0102 87-A30-071-080 0E C-TR,RT1N 144C USM CX-NDS8
S DOLBY DIGITAL Q 0103 87-A30-071-080 0E C-TR,RT1N 144C USM CX-NDS8
S DOLBY DIGITAL Q 0105 87-A30-071-080 0E C-TR,RT1N 144C USM CX-NDS8
S DOLBY DIGITAL Q 0106 87-A30-075-080 0E C-TR,2SA1235F USM CX-NDS8
S DOLBY DIGITAL Q 0107 87-A30-257-080 0E C-TR,2SD1306E USM CX-NDS8
S DOLBY DIGITAL Q 0401 87-A30-076-080 0E C-TR,2SC3052F USM CX-NDS8
S DOLBY DIGITAL Q 0402 87-A30-076-080 0E C-TR,2SC3052F USM CX-NDS8
S DOLBY DIGITAL Q 0403 87-A30-076-080 0E C-TR,2SC3052F USM CX-NDS8
S DOLBY DIGITAL Q 0404 87-026-608-080 0E C-TR,DTC123JK USM CX-NDS8
S DOLBY DIGITAL Q 0405 87-A30-076-080 0E C-TR,2SC3052F USM CX-NDS8
X DOLBY DIGITAL R 0101 88-118-105-080 0E C-RES,S 1M-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0102 88-118-102-080 0E C-RES,S 1K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0103 88-118-821-080 0E C-RES,S 820-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0104 88-118-101-080 0E C-RES,S 100-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0105 88-118-183-080 0E C-RES,S 18K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0106 88-118-104-080 0E C-RES,S 100K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0107 88-118-101-080 0E C-RES,S 100-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0108 88-121-103-080 0E RES,10K-1/8W J USM CX-NDS8
X DOLBY DIGITAL R 0109 88-121-102-080 0E RES,1K-1/8W J USM CX-NDS8
X DOLBY DIGITAL R 0110 88-121-102-080 0E RES,1K-1/8W J USM CX-NDS8
X DOLBY DIGITAL R 0111 88-121-102-080 0E RES,1K-1/8W J USM CX-NDS8
X DOLBY DIGITAL R 0112 88-128-101-080 0E C-RES, 100-1/8W J USM CX-NDS8
X DOLBY DIGITAL R 0113 88-128-101-080 0E C-RES, 100-1/8W J USM CX-NDS8
X DOLBY DIGITAL R 0114 88-128-101-080 0E C-RES, 100-1/8W J USM CX-NDS8
X DOLBY DIGITAL R 0115 88-121-101-080 0E RES,100-1/8W J USM CX-NDS8
X DOLBY DIGITAL R 0116 88-121-101-080 0E RES,100-1/8W J USM CX-NDS8
X DOLBY DIGITAL R 0117 88-121-101-080 0E RES,100-1/8W J USM CX-NDS8
X DOLBY DIGITAL R 0118 88-121-101-080 0E RES,100-1/8W J USM CX-NDS8
X DOLBY DIGITAL R 0119 88-121-101-080 0E RES,100-1/8W J USM CX-NDS8
X DOLBY DIGITAL R 0120 88-118-101-080 0E C-RES,S 100-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0121 88-121-102-080 0E RES,1K-1/8W J USM CX-NDS8
X DOLBY DIGITAL R 0122 88-121-102-080 0E RES,1K-1/8W J USM CX-NDS8
X DOLBY DIGITAL R 0123 88-121-102-080 0E RES,1K-1/8W J USM CX-NDS8
X DOLBY DIGITAL R 0124 88-121-103-080 0E RES,10K-1/8W J USM CX-NDS8
X DOLBY DIGITAL R 0125 88-118-223-080 0E C-RES,S 22K-1/10W J USM CX-NDS8

PARTS LIST
-12-
! =! SAFTY PARTS
C=Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
K NO. =Only use japanese.
C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX
X DOLBY DIGITAL R 0126 88-118-182-080 0E C-RES,S 1.8K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0127 88-118-101-080 0E C-RES,S 100-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0128 88-118-101-080 0E C-RES,S 100-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0129 88-118-101-080 0E C-RES,S 100-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0130 88-121-472-080 0E RES,4.7K-1/8W J USM CX-NDS8
X DOLBY DIGITAL R 0133 88-121-102-080 0E RES,1K-1/8W J USM CX-NDS8
X DOLBY DIGITAL R 0138 88-118-681-080 0E C-RES,S 680-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0139 88-118-472-080 0E C-RES,S 4.7K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0140 88-118-183-080 0E C-RES,S 18K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0143 88-118-221-080 0E C-RES,S 220-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0144 88-118-221-080 0E C-RES,S 220-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0145 88-118-471-080 0E C-RES,S 470-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0146 88-118-471-080 0E C-RES,S 470-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0147 88-118-223-080 0E C-RES,S 22K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0148 88-118-223-080 0E C-RES,S 22K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0149 88-118-472-080 0E C-RES,S 4.7K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0150 88-118-392-080 0E C-RES,S 3.9K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0151 88-118-392-080 0E C-RES,S 3.9K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0153 88-118-223-080 0E C-RES,S 22K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0154 88-118-223-080 0E C-RES,S 22K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0155 88-118-223-080 0E C-RES,S 22K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0156 88-118-223-080 0E C-RES,S 22K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0157 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL R 0158 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL R 0159 88-118-104-080 0E C-RES,S 100K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0160 88-118-104-080 0E C-RES,S 100K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0161 88-118-223-080 0E C-RES,S 22K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0162 88-118-223-080 0E C-RES,S 22K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0163 88-118-392-080 0E C-RES,S 3.9K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0164 88-118-392-080 0E C-RES,S 3.9K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0165 88-118-223-080 0E C-RES,S 22K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0166 88-118-223-080 0E C-RES,S 22K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0167 88-118-223-080 0E C-RES,S 22K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0168 88-118-223-080 0E C-RES,S 22K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0169 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL R 0170 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL R 0171 88-118-104-080 0E C-RES,S 100K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0172 88-118-104-080 0E C-RES,S 100K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0173 88-118-472-080 0E C-RES,S 4.7K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0175 88-118-223-080 0E C-RES,S 22K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0176 88-118-223-080 0E C-RES,S 22K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0177 88-118-392-080 0E C-RES,S 3.9K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0178 88-118-392-080 0E C-RES,S 3.9K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0179 88-118-223-080 0E C-RES,S 22K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0180 88-118-223-080 0E C-RES,S 22K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0181 88-118-223-080 0E C-RES,S 22K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0182 88-118-223-080 0E C-RES,S 22K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0183 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL R 0184 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL R 0185 88-118-104-080 0E C-RES,S 100K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0186 88-118-104-080 0E C-RES,S 100K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0187 88-118-472-080 0E C-RES,S 4.7K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0188 88-121-124-080 0E RES,120K-1/8W J USM CX-NDS8
X DOLBY DIGITAL R 0189 88-121-124-080 0E RES,120K-1/8W J USM CX-NDS8
X DOLBY DIGITAL R 0190 88-118-124-080 0E C-RES,S 120K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0191 88-118-124-080 0E C-RES,S 120K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0192 88-118-124-080 0E C-RES,S 120K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0193 88-118-393-080 0E C-RES,S 39K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0194 88-118-102-080 0E C-RES,S 1K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0195 88-118-124-080 0E C-RES,S 120K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0196 88-118-152-080 0E C-RES,S 1.5K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0197 88-118-472-080 0E C-RES,S 4.7K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0199 88-118-103-080 0E C-RES,S 10K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0200 88-118-103-080 0E C-RES,S 10K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0201 88-118-472-080 0E C-RES,S 4.7K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0202 88-121-152-080 0E RES,1.5K-1/8W J USM CX-NDS8
X DOLBY DIGITAL R 0203 88-118-124-080 0E C-RES,S 120K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0204 88-118-124-080 0E C-RES,S 120K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0205 88-118-124-080 0E C-RES,S 120K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0206 88-121-124-080 0E RES,120K-1/8W J USM CX-NDS8

PARTS LIST
-13-
! =! SAFTY PARTS
C=Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
K NO. =Only use japanese.
C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX
X DOLBY DIGITAL R 0207 88-118-153-080 0E C-RES,S 15K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0208 88-118-153-080 0E C-RES,S 15K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0209 88-118-153-080 0E C-RES,S 15K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0210 88-118-153-080 0E C-RES,S 15K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0211 88-118-153-080 0E C-RES,S 15K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0212 88-118-153-080 0E C-RES,S 15K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0213 88-118-153-080 0E C-RES,S 15K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0214 88-118-153-080 0E C-RES,S 15K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0215 88-128-153-080 0E C-RES, 15K-1/8W J USM CX-NDS8
X DOLBY DIGITAL R 0216 88-128-153-080 0E C-RES, 15K-1/8W J USM CX-NDS8
X DOLBY DIGITAL R 0217 88-118-152-080 0E C-RES,S 1.5K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0218 88-118-472-080 0E C-RES,S 4.7K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0219 88-128-152-080 0E C-RES, 1.5K-1/8W J USM CX-NDS8
X DOLBY DIGITAL R 0220 88-118-472-080 0E C-RES,S 4.7K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0221 88-118-183-080 0E C-RES,S 18K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0222 88-118-183-080 0E C-RES,S 18K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0223 88-118-153-080 0E C-RES,S 15K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0224 88-118-153-080 0E C-RES,S 15K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0225 88-118-472-080 0E C-RES,S 4.7K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0226 88-118-822-080 0E C-RES,S 8.2K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0227 88-118-183-080 0E C-RES,S 18K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0228 88-118-183-080 0E C-RES,S 18K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0229 88-118-153-080 0E C-RES,S 15K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0230 88-118-153-080 0E C-RES,S 15K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0231 88-118-472-080 0E C-RES,S 4.7K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0233 88-118-183-080 0E C-RES,S 18K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0234 88-118-562-080 0E C-RES,S 5.6K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0235 88-118-153-080 0E C-RES,S 15K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0236 88-118-822-080 0E C-RES,S 8.2K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0237 88-118-472-080 0E C-RES,S 4.7K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0238 88-118-681-080 0E C-RES,S 680-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0239 88-118-822-080 0E C-RES,S 8.2K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0240 88-118-472-080 0E C-RES,S 4.7K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0243 88-118-223-080 0E C-RES,S 22K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0244 88-118-103-080 0E C-RES,S 10K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0245 88-118-471-080 0E C-RES,S 470-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0246 88-118-333-080 0E C-RES,S 33K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0249 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL R 0250 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL R 0251 88-118-153-080 0E C-RES,S 15K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0252 88-118-153-080 0E C-RES,S 15K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0253 88-118-472-080 0E C-RES,S 4.7K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0256 88-118-273-080 0E C-RES,S 27K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0257 88-118-273-080 0E C-RES,S 27K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0258 88-128-153-080 0E C-RES, 15K-1/8W J USM CX-NDS8
X DOLBY DIGITAL R 0259 88-121-153-080 0E RES,15K-1/8W J USM CX-NDS8
X DOLBY DIGITAL R 0267 88-118-152-080 0E C-RES,S 1.5K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0268 88-118-472-080 0E C-RES,S 4.7K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0269 88-118-103-080 0E C-RES,S 10K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0270 88-118-152-080 0E C-RES,S 1.5K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0271 88-118-472-080 0E C-RES,S 4.7K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0272 88-118-224-080 0E C-RES,S 220K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0273 88-118-224-080 0E C-RES,S 220K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0275 88-118-224-080 0E C-RES,S 220K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0276 88-118-224-080 0E C-RES,S 220K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0277 88-100-000-010 0E PLATING-JW, 0.58 SN95 USM CX-NDS8
X DOLBY DIGITAL R 0278 88-100-000-010 0E PLATING-JW, 0.58 SN95 USM CX-NDS8
X DOLBY DIGITAL R 0279 88-118-103-080 0E C-RES,S 10K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0287 88-118-470-080 0E C-RES,S 47-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0288 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL R 0289 88-118-471-080 0E C-RES,S 470-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0291 88-118-183-080 0E C-RES,S 18K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0292 88-118-103-080 0E C-RES,S 10K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0293 88-118-683-080 0E C-RES,S 68K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0294 88-118-102-080 0E C-RES,S 1K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0295 88-118-105-080 0E C-RES,S 1M-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0296 88-118-183-080 0E C-RES,S 18K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0301 88-118-223-080 0E C-RES,S 22K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0302 88-118-222-080 0E C-RES,S 2.2K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0303 88-118-473-080 0E C-RES,S 47K-1/10W J USM CX-NDS8

PARTS LIST
-14-
! =! SAFTY PARTS
C=Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
K NO. =Only use japanese.
C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX
X DOLBY DIGITAL R 0304 88-118-473-080 0E C-RES,S 47K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0305 88-118-473-080 0E C-RES,S 47K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0306 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X DOLBY DIGITAL R 0307 88-118-102-080 0E C-RES,S 1K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0308 88-118-102-080 0E C-RES,S 1K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0309 88-118-392-080 0E C-RES,S 3.9K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0310 88-140-121-080 0E RES,120-1/2W J USM CX-NDS8
X DOLBY DIGITAL R 0401 88-118-104-080 0E C-RES,S 100K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0402 88-118-104-080 0E C-RES,S 100K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0403 88-118-473-080 0E C-RES,S 47K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0404 88-118-472-080 0E C-RES,S 4.7K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0405 88-118-473-080 0E C-RES,S 47K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0406 88-118-472-080 0E C-RES,S 4.7K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0407 88-118-102-080 0E C-RES,S 1K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0408 88-118-472-080 0E C-RES,S 4.7K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0409 88-118-102-080 0E C-RES,S 1K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0410 88-118-472-080 0E C-RES,S 4.7K-1/10W J USM CX-NDS8
X DOLBY DIGITAL R 0411 88-118-100-080 0E C-RES,S 10-1/10W J USM CX-NDS8
X DOLBY DIGITAL W 0403 87-A60-884-010 0E PIN,DIA1 COATING-SHS USM CX-NDS8
X DOLBY DIGITAL W 0405 87-A60-884-010 0E PIN,DIA1 COATING-SHS USM CX-NDS8
O DOLBY DIGITAL X 0101 87-A70-116-010 1B VIB,XTAL 10.00MHZ USM CX-NDS8
O DOLBY DIGITAL X 0102 87-A70-115-010 1B VIB,XTAL 12.288MHZ USM CX-NDS8
O DSP/ECHO(MIC MIX) C 0531 87-010-405-080 0E CAP,E 10-50 M 11L SME USM CX-NDS8
O DSP/ECHO(MIC MIX) C 0532 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DSP/ECHO(MIC MIX) C 0533 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DSP/ECHO(MIC MIX) C 0534 87-012-156-080 0E C-CAP,S 220P-50 J CH GRM USM CX-NDS8
O DSP/ECHO(MIC MIX) C 0535 87-010-178-080 0E C-CAP,S 1000P-50 K B C2012 USM CX-NDS8
O DSP/ECHO(MIC MIX) C 0536 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O DSP/ECHO(MIC MIX) C 0541 87-010-178-080 0E C-CAP,S 1000P-50 K B C2012 USM CX-NDS8
X DSP/ECHO(MIC MIX) CLP0501 87-A60-884-010 0E PIN,DIA1 COATING-SHS USM CX-NDS8
S DSP/ECHO(MIC MIX) Q 0531 87-A30-076-080 0E C-TR,2SC3052F USM CX-NDS8
S DSP/ECHO(MIC MIX) Q 0532 87-A30-075-080 0E C-TR,2SA1235F USM CX-NDS8
X DSP/ECHO(MIC MIX) R 0531 88-128-101-080 0E C-RES, 100-1/8W J USM CX-NDS8
X DSP/ECHO(MIC MIX) R 0532 88-118-822-080 0E C-RES,S 8.2K-1/10W J USM CX-NDS8
X DSP/ECHO(MIC MIX) R 0533 88-118-101-080 0E C-RES,S 100-1/10W J USM CX-NDS8
X DSP/ECHO(MIC MIX) R 0534 88-118-392-080 0E C-RES,S 3.9K-1/10W J USM CX-NDS8
X DSP/ECHO(MIC MIX) R 0535 88-118-472-080 0E C-RES,S 4.7K-1/10W J USM CX-NDS8
X DSP/ECHO(MIC MIX) R 0536 88-118-104-080 0E C-RES,S 100K-1/10W J USM CX-NDS8
X DSP/ECHO(MIC MIX) R 0537 88-118-123-080 0E C-RES,S 12K-1/10W J USM CX-NDS8
O E-GEQ C 0202 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O E-GEQ C 0203 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O E-GEQ C 0205 87-010-314-080 0E C-CAP,S 22P-50 J CH GRM USM CX-NDS8
O E-GEQ C 0206 87-010-182-080 0E C-CAP,S 2200P-50 K B C2012 USM CX-NDS8
O E-GEQ CN 0201 87-A60-623-010 0E CONN,6P V 2MM JMT USM CX-NDS8
! S E-GEQ IC 0201 87-A20-870-010 1F IC,GP1F37R USM CX-NDS8
! O E-GEQ J 0201 87-A60-573-010 1A JACK,PIN 1P ORN USM CX-NDS8
X E-GEQ JR 0205 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
O E-GEQ L 0201 87-005-274-080 0E COIL,68UH K LAL03 USM CX-NDS8
O E-GEQ L 0202 87-008-501-080 0E FLTR, DSS306-55 USM CX-NDS8
X E-GEQ R 0201 88-118-820-080 0E C-RES,S 82-1/10W J USM CX-NDS8
X E-GEQ R 0202 88-118-105-080 0E C-RES,S 1M-1/10W J USM CX-NDS8
X E-GEQ R 0204 88-118-101-080 0E C-RES,S 100-1/10W J USM CX-NDS8
X ELECTRICAL 80-XV1-218-010 0E CUSH-S,PWB USM CX-NDS8
! X ELECTRICAL 87-069-033-010 0E CABLE,TIE USM CX-NDS8
! O ELECTRICAL 87-085-189-010 0E BUSHING,AC CORD(U) CM-22C USM CX-NDS8
X ELECTRICAL 87-098-335-010 0E LBL,REPLACEMENT USM CX-NDS8
! X ELECTRICAL 87-098-374-010 0E LBL,FUSE 10A 125V USM CX-NDS8
O ELECTRICAL 87-A91-832-010 — FAN,DSB0812H(DELTA) -400MM USM CX-NDS8
O ELECTRICAL 88-904-281-110 0E FF-CABLE,4P 1.25 280MM USM CX-NDS8
O ELECTRICAL 88-906-621-110 1A FF-CABLE,6P 1.25 620MM USM CX-NDS8
O ELECTRICAL 88-907-421-110 0E FF-CABLE,7P 1.25 420MM USM CX-NDS8
O ELECTRICAL 88-910-151-110 0E FF-CABLE, 10P 1.25 150MM USM CX-NDS8
O ELECTRICAL 88-911-291-110 0E FF-CABLE,11P 1.25 290MM USM CX-NDS8
O ELECTRICAL 88-913-521-110 1A FF-CABLE,13P 1.25 520MM USM CX-NDS8
O ELECTRICAL 88-915-111-110 0E FF-CABLE,15P 1.25 USM CX-NDS8
X ELECTRICAL 8Z-NF5-613-010 0E WIRE ASSY,150 BLACK 24 USM CX-NDS8
X ELECTRICAL * 8Z-NB6-230-010 0E PLATE,SHLD RF S USM CX-NDS8
! O ELECTRICAL PT 0001 8A-NFG-621-010 — PT,U EI96-75 ANF-G USM CX-NDS8
! O ELECTRICAL W 0001 87-A80-110-010 1B AC CORD ASSY,U SPT-2W USM CX-NDS8
O FLTR C 0104 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8

PARTS LIST
-15-
! =! SAFTY PARTS
C=Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
K NO. =Only use japanese.
C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX
O FLTR C 0105 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O FLTR C 0111 87-010-545-080 0E CAP,E 0.22-50 M 11L SME USM CX-NDS8
O FLTR C 0112 87-010-545-080 0E CAP,E 0.22-50 M 11L SME USM CX-NDS8
O FLTR C 0113 87-010-545-080 0E CAP,E 0.22-50 M 11L SME USM CX-NDS8
O FLTR C 0114 87-010-545-080 0E CAP,E 0.22-50 M 11L SME USM CX-NDS8
O FLTR C 0115 87-010-546-080 0E CAP,E 0.33-50 M 11L SME USM CX-NDS8
O FLTR C 0116 87-010-546-080 0E CAP,E 0.33-50 M 11L SME USM CX-NDS8
O FLTR C 0121 87-010-546-080 0E CAP,E 0.33-50 M 11L SME USM CX-NDS8
O FLTR C 0122 87-010-546-080 0E CAP,E 0.33-50 M 11L SME USM CX-NDS8
O FLTR C 0152 87-010-260-080 0E CAP,E 47-25 M 11L SME USM CX-NDS8
O FLTR C 0171 87-012-368-080 0E C-CAP,S 0.1-50 Z F USM CX-NDS8
O FLTR C 0172 87-012-368-080 0E C-CAP,S 0.1-50 Z F USM CX-NDS8
O FLTR C 0173 87-012-368-080 0E C-CAP,S 0.1-50 Z F USM CX-NDS8
O FLTR C 0174 87-012-368-080 0E C-CAP,S 0.1-50 Z F USM CX-NDS8
! O FLTR CN 0101 87-A60-996-010 0E CONN,13P V BLK TAC-L13X-A3 USM CX-NDS8
! O FLTR J 0102 87-A60-238-010 1A TERMINAL,SP 4P (MSC) USM CX-NDS8
O FLTR J 0103 87-A61-481-010 — JACK,DIA6.3 BLK ST W/SW MSC16B USM CX-NDS8
X FLTR JR 0101 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X FLTR JR 0102 88-129-000-080 0E C-JUMPER,3216 USM CX-NDS8
X FLTR JR 0106 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X FLTR JR 0107 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X FLTR JR 0109 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X FLTR JR 0110 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
O FLTR L 0101 87-A50-610-010 0E COIL,1UH K(MDEC) USM CX-NDS8
O FLTR L 0102 87-A50-610-010 0E COIL,1UH K(MDEC) USM CX-NDS8
S FLTR Q 0101 87-A30-076-080 0E C-TR,2SC3052F USM CX-NDS8
S FLTR Q 0102 87-A30-076-080 0E C-TR,2SC3052F USM CX-NDS8
S FLTR Q 0103 87-A30-076-080 0E C-TR,2SC3052F USM CX-NDS8
S FLTR Q 0104 87-A30-076-080 0E C-TR,2SC3052F USM CX-NDS8
S FLTR Q 0105 87-A30-269-040 0E C-FET,2SJ461-T1 USM CX-NDS8
S FLTR Q 0106 87-A30-269-040 0E C-FET,2SJ461-T1 USM CX-NDS8
S FLTR Q 0107 87-A30-076-080 0E C-TR,2SC3052F USM CX-NDS8
S FLTR Q 0108 87-A30-076-080 0E C-TR,2SC3052F USM CX-NDS8
S FLTR Q 0109 87-A30-076-080 0E C-TR,2SC3052F USM CX-NDS8
S FLTR Q 0110 87-A30-076-080 0E C-TR,2SC3052F USM CX-NDS8
S FLTR Q 0111 87-A30-086-040 0E C-TR,CSD1306E USM CX-NDS8
S FLTR Q 0112 87-A30-086-040 0E C-TR,CSD1306E USM CX-NDS8
S FLTR Q 0113 87-A30-075-080 0E C-TR,2SA1235F USM CX-NDS8
S FLTR Q 0114 87-A30-221-040 0E C-TR,DTA114WK USM CX-NDS8
S FLTR Q 0115 87-A30-076-080 0E C-TR,2SC3052F USM CX-NDS8
X FLTR R 0101 88-118-472-080 0E C-RES,S 4.7K-1/10W J USM CX-NDS8
X FLTR R 0102 88-118-472-080 0E C-RES,S 4.7K-1/10W J USM CX-NDS8
X FLTR R 0105 88-118-224-080 0E C-RES,S 220K-1/10W J USM CX-NDS8
X FLTR R 0106 88-118-103-080 0E C-RES,S 10K-1/10W J USM CX-NDS8
X FLTR R 0107 88-118-103-080 0E C-RES,S 10K-1/10W J USM CX-NDS8
X FLTR R 0108 88-118-104-080 0E C-RES,S 100K-1/10W J USM CX-NDS8
X FLTR R 0109 88-118-224-080 0E C-RES,S 220K-1/10W J USM CX-NDS8
X FLTR R 0110 88-118-224-080 0E C-RES,S 220K-1/10W J USM CX-NDS8
X FLTR R 0111 88-118-104-080 0E C-RES,S 100K-1/10W J USM CX-NDS8
X FLTR R 0112 88-118-103-080 0E C-RES,S 10K-1/10W J USM CX-NDS8
X FLTR R 0115 88-118-562-080 0E C-RES,S 5.6K-1/10W J USM CX-NDS8
X FLTR R 0116 88-118-562-080 0E C-RES,S 5.6K-1/10W J USM CX-NDS8
X FLTR R 0117 88-118-471-080 0E C-RES,S 470-1/10W J USM CX-NDS8
X FLTR R 0118 88-118-471-080 0E C-RES,S 470-1/10W J USM CX-NDS8
X FLTR R 0121 88-118-223-080 0E C-RES,S 22K-1/10W J USM CX-NDS8
X FLTR R 0122 88-118-223-080 0E C-RES,S 22K-1/10W J USM CX-NDS8
X FLTR R 0123 88-118-562-080 0E C-RES,S 5.6K-1/10W J USM CX-NDS8
X FLTR R 0124 88-118-562-080 0E C-RES,S 5.6K-1/10W J USM CX-NDS8
X FLTR R 0125 88-118-222-080 0E C-RES,S 2.2K-1/10W J USM CX-NDS8
X FLTR R 0126 88-118-222-080 0E C-RES,S 2.2K-1/10W J USM CX-NDS8
X FLTR R 0127 88-118-103-080 0E C-RES,S 10K-1/10W J USM CX-NDS8
X FLTR R 0128 88-121-103-080 0E RES,10K-1/8W J USM CX-NDS8
X FLTR R 0129 88-121-562-080 0E RES,5.6K-1/8W J USM CX-NDS8
X FLTR R 0130 88-118-562-080 0E C-RES,S 5.6K-1/10W J USM CX-NDS8
X FLTR R 0131 88-118-474-080 0E C-RES,S 470K-1/10W J USM CX-NDS8
X FLTR R 0132 88-118-474-080 0E C-RES,S 470K-1/10W J USM CX-NDS8
X FLTR R 0133 88-118-103-080 0E C-RES,S 10K-1/10W J USM CX-NDS8
X FLTR R 0134 88-118-103-080 0E C-RES,S 10K-1/10W J USM CX-NDS8
X FLTR R 0135 88-118-392-080 0E C-RES,S 3.9K-1/10W J USM CX-NDS8
X FLTR R 0136 88-118-392-080 0E C-RES,S 3.9K-1/10W J USM CX-NDS8

PARTS LIST
-16-
! =! SAFTY PARTS
C=Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
K NO. =Only use japanese.
C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX
X FLTR R 0137 88-118-472-080 0E C-RES,S 4.7K-1/10W J USM CX-NDS8
X FLTR R 0138 88-118-472-080 0E C-RES,S 4.7K-1/10W J USM CX-NDS8
X FLTR R 0139 88-121-223-080 0E RES,22K-1/8W J USM CX-NDS8
X FLTR R 0140 88-121-223-080 0E RES,22K-1/8W J USM CX-NDS8
X FLTR R 0151 88-100-000-010 0E PLATING-JW, 0.58 SN95 USM CX-NDS8
X FLTR R 0152 88-118-103-080 0E C-RES,S 10K-1/10W J USM CX-NDS8
X FLTR R 0153 88-118-683-080 0E C-RES,S 68K-1/10W J USM CX-NDS8
X FLTR R 0154 88-118-105-080 0E C-RES,S 1M-1/10W J USM CX-NDS8
X FLTR R 0157 88-118-103-080 0E C-RES,S 10K-1/10W J USM CX-NDS8
X FLTR R 0158 88-118-104-080 0E C-RES,S 100K-1/10W J USM CX-NDS8
O FLTR R 0161 87-A00-441-050 0E RES,270-1/2W J RP USM CX-NDS8
O FLTR R 0162 87-A00-441-050 0E RES,270-1/2W J RP USM CX-NDS8
O FLTR R 0163 87-A00-441-050 0E RES,270-1/2W J RP USM CX-NDS8
O FLTR R 0164 87-A00-441-050 0E RES,270-1/2W J RP USM CX-NDS8
X FLTR R 0165 88-128-102-080 0E C-RES, 1K-1/8W J USM CX-NDS8
X FLTR R 0170 88-118-122-080 0E C-RES,S 1.2K-1/10W J USM CX-NDS8
X FLTR R 0171 88-118-223-080 0E C-RES,S 22K-1/10W J USM CX-NDS8
X FLTR R 0172 88-118-223-080 0E C-RES,S 22K-1/10W J USM CX-NDS8
X FLTR R 0173 88-130-100-080 0E RES,10-1/4W J USM CX-NDS8
X FLTR R 0174 88-130-100-080 0E RES,10-1/4W J USM CX-NDS8
X FLTR R 0175 88-128-100-080 0E C-RES, 10-1/8W J USM CX-NDS8
X FLTR R 0176 88-128-100-080 0E C-RES, 10-1/8W J USM CX-NDS8
X FLTR R 0177 88-121-222-080 0E RES,2.2K-1/8W J USM CX-NDS8
X FLTR R 0178 88-121-222-080 0E RES,2.2K-1/8W J USM CX-NDS8
O FRCB MECHA 8A-NF6-201-010 0E GUIDE,FL USM CX-NDS8
O FRCB MECHA 8A-NF6-203-010 0E GUIDE,OPE USM CX-NDS8
O FRCB MECHA 8A-NF6-204-010 0E GUIDE,DECK USM CX-NDS8
O FUNC/E.VR C 0609 87-010-181-080 0E C-CAP,S 1800P-50 K B GRM USM CX-NDS8
O FUNC/E.VR C 0610 87-010-181-080 0E C-CAP,S 1800P-50 K B GRM USM CX-NDS8
O FUNC/E.VR C 0611 87-010-956-080 0E C-CAP,S 0.068-25 K B GRM USM CX-NDS8
O FUNC/E.VR C 0612 87-016-369-080 0E C-CAP,S 0.033-25 K B GRM USM CX-NDS8
O FUNC/E.VR C 0613 87-A11-567-080 0E C-CAP,S 0.01-50 K B USM CX-NDS8
O FUNC/E.VR C 0614 87-016-669-080 0E C-CAP,S 0.1-25 K B USM CX-NDS8
O FUNC/E.VR C 0616 87-010-184-080 0E C-CAP,S 3300P-50 K B C2012 USM CX-NDS8
O FUNC/E.VR C 0617 87-012-369-080 0E C-CAP,S 0.047-50 Z F USM CX-NDS8
O FUNC/E.VR C 0618 87-010-401-080 0E CAP,E 1-50 M 11L SME USM CX-NDS8
O FUNC/E.VR C 0619 87-010-263-080 0E CAP,E 100-10 M 11L SME USM CX-NDS8
O FUNC/E.VR C 0620 87-016-669-080 0E C-CAP,S 0.1-25 K B USM CX-NDS8
O FUNC/E.VR C 0621 87-A11-567-080 0E C-CAP,S 0.01-50 K B USM CX-NDS8
O FUNC/E.VR C 0623 87-010-401-080 0E CAP,E 1-50 M 11L SME USM CX-NDS8
O FUNC/E.VR C 0624 87-010-401-080 0E CAP,E 1-50 M 11L SME USM CX-NDS8
O FUNC/E.VR C 0626 87-A11-590-080 0E C-CAP,S 0.047-16 K B USM CX-NDS8
O FUNC/E.VR C 0627 87-010-400-080 0E CAP,E 0.47-50 M 11L SME USM CX-NDS8
O FUNC/E.VR C 0628 87-010-400-080 0E CAP,E 0.47-50 M 11L SME USM CX-NDS8
O FUNC/E.VR C 0629 87-A11-590-080 0E C-CAP,S 0.047-16 K B USM CX-NDS8
O FUNC/E.VR C 0630 87-010-383-080 0E CAP,E 33-25 M 11L SME USM CX-NDS8
O FUNC/E.VR C 0631 87-010-185-080 0E C-CAP,S 3900P-50 K B USM CX-NDS8
O FUNC/E.VR C 0632 87-010-185-080 0E C-CAP,S 3900P-50 K B USM CX-NDS8
O FUNC/E.VR C 0633 87-010-178-080 0E C-CAP,S 1000P-50 K B C2012 USM CX-NDS8
O FUNC/E.VR C 0634 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O FUNC/E.VR C 0635 87-A12-376-080 0E CAP,M 0.1-100 J CP USM CX-NDS8
O FUNC/E.VR C 0636 87-A12-376-080 0E CAP,M 0.1-100 J CP USM CX-NDS8
O FUNC/E.VR C 0637 87-A12-376-080 0E CAP,M 0.1-100 J CP USM CX-NDS8
O FUNC/E.VR C 0638 87-A12-376-080 0E CAP,M 0.1-100 J CP USM CX-NDS8
O FUNC/E.VR C 0639 87-010-405-080 0E CAP,E 10-50 M 11L SME USM CX-NDS8
O FUNC/E.VR C 0641 87-010-401-080 0E CAP,E 1-50 M 11L SME USM CX-NDS8
O FUNC/E.VR C 0642 87-010-401-080 0E CAP,E 1-50 M 11L SME USM CX-NDS8
O FUNC/E.VR C 0643 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O FUNC/E.VR C 0644 87-010-401-080 0E CAP,E 1-50 M 11L SME USM CX-NDS8
O FUNC/E.VR C 0645 87-012-156-080 0E C-CAP,S 220P-50 J CH GRM USM CX-NDS8
X FUNC/E.VR C 0661 88-118-472-080 0E C-RES,S 4.7K-1/10W J USM CX-NDS8
X FUNC/E.VR C 0662 88-118-472-080 0E C-RES,S 4.7K-1/10W J USM CX-NDS8
X FUNC/E.VR C 0663 88-118-472-080 0E C-RES,S 4.7K-1/10W J USM CX-NDS8
X FUNC/E.VR C 0664 88-118-472-080 0E C-RES,S 4.7K-1/10W J USM CX-NDS8
O FUNC/E.VR C 0671 87-010-322-080 0E C-CAP,S 100P-50 J CH GRM USM CX-NDS8
O FUNC/E.VR C 0672 87-010-322-080 0E C-CAP,S 100P-50 J CH GRM USM CX-NDS8
O FUNC/E.VR C 0673 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USM CX-NDS8
O FUNC/E.VR C 0679 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O FUNC/E.VR C 0680 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USM CX-NDS8
O FUNC/E.VR C 0682 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8

PARTS LIST
-17-
! =! SAFTY PARTS
C=Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
K NO. =Only use japanese.
C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX
! O FUNC/E.VR CN 0601 87-099-719-010 1B CONN,30P H BLK TYK-B(X) USM CX-NDS8
! O FUNC/E.VR CN 0602 87-099-194-010 0E CONN,6P V BLK 6216 USM CX-NDS8
S FUNC/E.VR D 0602 87-A40-745-080 0E ZENER,UZ4.7BSA USM CX-NDS8
S FUNC/E.VR D 0603 87-020-465-080 0E DIODE,1SS133 USM CX-NDS8
X FUNC/E.VR FB 0601 88-100-000-010 0E PLATING-JW, 0.58 SN95 USM CX-NDS8
S FUNC/E.VR IC 0601 87-A21-452-130 1H C-IC,BD3876AKS2 USM CX-NDS8
O FUNC/E.VR J 0601 87-A60-885-010 1A JACK,PIN 6P R/W MSC USM CX-NDS8
X FUNC/E.VR JR 0601 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X FUNC/E.VR JR 0602 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X FUNC/E.VR JR 0611 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X FUNC/E.VR JR 0612 88-129-000-080 0E C-JUMPER,3216 USM CX-NDS8
X FUNC/E.VR JR 0614 88-118-123-080 0E C-RES,S 12K-1/10W J USM CX-NDS8
X FUNC/E.VR JR 0617 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X FUNC/E.VR JR 0618 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X FUNC/E.VR JR 0619 88-129-000-080 0E C-JUMPER,3216 USM CX-NDS8
X FUNC/E.VR JR 0620 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X FUNC/E.VR JR 0622 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X FUNC/E.VR JR 0625 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X FUNC/E.VR JR 0627 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X FUNC/E.VR JR 0661 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
S FUNC/E.VR Q 0601 87-026-610-080 0E TR,KTC3198GR USM CX-NDS8
S FUNC/E.VR Q 0605 87-A30-086-040 0E C-TR,CSD1306E USM CX-NDS8
S FUNC/E.VR Q 0606 87-A30-086-040 0E C-TR,CSD1306E USM CX-NDS8
S FUNC/E.VR Q 0607 87-A30-075-080 0E C-TR,2SA1235F USM CX-NDS8
S FUNC/E.VR Q 0608 87-A30-075-080 0E C-TR,2SA1235F USM CX-NDS8
S FUNC/E.VR Q 0609 87-A30-075-080 0E C-TR,2SA1235F USM CX-NDS8
X FUNC/E.VR R 0601 88-118-153-080 0E C-RES,S 15K-1/10W J USM CX-NDS8
X FUNC/E.VR R 0602 88-118-153-080 0E C-RES,S 15K-1/10W J USM CX-NDS8
X FUNC/E.VR R 0603 88-118-333-080 0E C-RES,S 33K-1/10W J USM CX-NDS8
X FUNC/E.VR R 0604 88-118-333-080 0E C-RES,S 33K-1/10W J USM CX-NDS8
X FUNC/E.VR R 0605 88-121-333-080 0E RES,33K-1/8W J USM CX-NDS8
X FUNC/E.VR R 0606 88-121-333-080 0E RES,33K-1/8W J USM CX-NDS8
X FUNC/E.VR R 0607 88-121-472-080 0E RES,4.7K-1/8W J USM CX-NDS8
X FUNC/E.VR R 0608 88-121-472-080 0E RES,4.7K-1/8W J USM CX-NDS8
X FUNC/E.VR R 0609 88-121-392-080 0E RES,3.9K-1/8W J USM CX-NDS8
X FUNC/E.VR R 0610 88-121-392-080 0E RES,3.9K-1/8W J USM CX-NDS8
X FUNC/E.VR R 0611 88-118-153-080 0E C-RES,S 15K-1/10W J USM CX-NDS8
X FUNC/E.VR R 0612 88-118-153-080 0E C-RES,S 15K-1/10W J USM CX-NDS8
X FUNC/E.VR R 0613 88-118-392-080 0E C-RES,S 3.9K-1/10W J USM CX-NDS8
X FUNC/E.VR R 0614 88-118-392-080 0E C-RES,S 3.9K-1/10W J USM CX-NDS8
X FUNC/E.VR R 0615 88-118-392-080 0E C-RES,S 3.9K-1/10W J USM CX-NDS8
X FUNC/E.VR R 0616 88-118-392-080 0E C-RES,S 3.9K-1/10W J USM CX-NDS8
X FUNC/E.VR R 0617 88-118-392-080 0E C-RES,S 3.9K-1/10W J USM CX-NDS8
X FUNC/E.VR R 0618 88-118-392-080 0E C-RES,S 3.9K-1/10W J USM CX-NDS8
X FUNC/E.VR R 0619 88-118-682-080 0E C-RES,S 6.8K-1/10W J USM CX-NDS8
X FUNC/E.VR R 0620 88-118-682-080 0E C-RES,S 6.8K-1/10W J USM CX-NDS8
X FUNC/E.VR R 0621 88-118-104-080 0E C-RES,S 100K-1/10W J USM CX-NDS8
X FUNC/E.VR R 0622 88-118-103-080 0E C-RES,S 10K-1/10W J USM CX-NDS8
X FUNC/E.VR R 0623 88-118-183-080 0E C-RES,S 18K-1/10W J USM CX-NDS8
X FUNC/E.VR R 0624 88-118-103-080 0E C-RES,S 10K-1/10W J USM CX-NDS8
X FUNC/E.VR R 0625 88-118-105-080 0E C-RES,S 1M-1/10W J USM CX-NDS8
X FUNC/E.VR R 0626 88-130-330-080 0E RES,33-1/4W J USM CX-NDS8
X FUNC/E.VR R 0627 88-128-390-080 0E C-RES, 39-1/8W J USM CX-NDS8
X FUNC/E.VR R 0628 88-128-390-080 0E C-RES, 39-1/8W J USM CX-NDS8
X FUNC/E.VR R 0629 88-128-330-080 0E C-RES, 33-1/8W J USM CX-NDS8
X FUNC/E.VR R 0630 88-118-223-080 0E C-RES,S 22K-1/10W J USM CX-NDS8
X FUNC/E.VR R 0631 88-130-101-080 0E RES,100-1/4W J USM CX-NDS8
X FUNC/E.VR R 0632 88-128-470-080 0E C-RES, 47-1/8W J USM CX-NDS8
X FUNC/E.VR R 0633 88-128-470-080 0E C-RES, 47-1/8W J USM CX-NDS8
X FUNC/E.VR R 0634 88-128-390-080 0E C-RES, 39-1/8W J USM CX-NDS8
X FUNC/E.VR R 0635 88-118-103-080 0E C-RES,S 10K-1/10W J USM CX-NDS8
X FUNC/E.VR R 0636 88-118-103-080 0E C-RES,S 10K-1/10W J USM CX-NDS8
X FUNC/E.VR R 0637 88-130-101-080 0E RES,100-1/4W J USM CX-NDS8
X FUNC/E.VR R 0638 88-128-390-080 0E C-RES, 39-1/8W J USM CX-NDS8
X FUNC/E.VR R 0639 88-118-682-080 0E C-RES,S 6.8K-1/10W J USM CX-NDS8
X FUNC/E.VR R 0640 88-118-682-080 0E C-RES,S 6.8K-1/10W J USM CX-NDS8
X FUNC/E.VR R 0641 88-118-124-080 0E C-RES,S 120K-1/10W J USM CX-NDS8
X FUNC/E.VR R 0642 88-118-124-080 0E C-RES,S 120K-1/10W J USM CX-NDS8
X FUNC/E.VR R 0645 88-118-104-080 0E C-RES,S 100K-1/10W J USM CX-NDS8
X FUNC/E.VR R 0646 88-118-103-080 0E C-RES,S 10K-1/10W J USM CX-NDS8

PARTS LIST
-18-
! =! SAFTY PARTS
C=Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
K NO. =Only use japanese.
C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX
X FUNC/E.VR R 0647 88-118-103-080 0E C-RES,S 10K-1/10W J USM CX-NDS8
X FUNC/E.VR R 0648 88-118-103-080 0E C-RES,S 10K-1/10W J USM CX-NDS8
X FUNC/E.VR R 0651 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X FUNC/E.VR R 0652 88-121-562-080 0E RES,5.6K-1/8W J USM CX-NDS8
X FUNC/E.VR R 0657 88-118-103-080 0E C-RES,S 10K-1/10W J USM CX-NDS8
X FUNC/E.VR R 0659 88-118-105-080 0E C-RES,S 1M-1/10W J USM CX-NDS8
X FUNC/E.VR R 0660 88-118-105-080 0E C-RES,S 1M-1/10W J USM CX-NDS8
X FUNC/E.VR R 0661 88-118-102-080 0E C-RES,S 1K-1/10W J USM CX-NDS8
X FUNC/E.VR R 0662 88-118-102-080 0E C-RES,S 1K-1/10W J USM CX-NDS8
X FUNC/E.VR R 0663 88-118-102-080 0E C-RES,S 1K-1/10W J USM CX-NDS8
X FUNC/E.VR R 0664 88-118-102-080 0E C-RES,S 1K-1/10W J USM CX-NDS8
X FUNC/E.VR R 0665 88-118-472-080 0E C-RES,S 4.7K-1/10W J USM CX-NDS8
X FUNC/E.VR R 0666 88-118-472-080 0E C-RES,S 4.7K-1/10W J USM CX-NDS8
X FUNC/E.VR R 0671 88-118-101-080 0E C-RES,S 100-1/10W J USM CX-NDS8
X FUNC/E.VR R 0672 88-118-101-080 0E C-RES,S 100-1/10W J USM CX-NDS8
X FUNC/E.VR R 0673 88-100-000-010 0E PLATING-JW, 0.58 SN95 USM CX-NDS8
X FUNC/E.VR R 0677 88-118-103-080 0E C-RES,S 10K-1/10W J USM CX-NDS8
X FUNC/E.VR R 0678 88-118-103-080 0E C-RES,S 10K-1/10W J USM CX-NDS8
X FUNC/E.VR R 0683 88-118-152-080 0E C-RES,S 1.5K-1/10W J USM CX-NDS8
X FUNC/E.VR R 0684 88-118-152-080 0E C-RES,S 1.5K-1/10W J USM CX-NDS8
X KNOB 8A-NF6-021-010 — KEY,POWER USM CX-NDS8
O KNOB 8A-NF6-022-010 0E KEY,ECHO USM CX-NDS8
X KNOB 8A-NF6-025-010 0E REFLECTOR,FUN USM CX-NDS8
O KNOB 8A-NF6-026-010 1B KEY,ASSY OPE USM CX-NDS8
X KNOB 8A-NF6-027-010 0E KEY,OPE USM CX-NDS8
X KNOB 8A-NF6-028-010 0E REFLECTOR,OPE USM CX-NDS8
O KNOB 8A-NF6-030-010 0E KNOB,RTRY JOG USM CX-NDS8
O KNOB 8A-NF6-036-010 0E KEY,CD EDIT USM CX-NDS8
O KNOB 8A-NF6-037-110 1A KEY,CD OPEN USM CX-NDS8
O KNOB 8A-NF6-045-010 1A KEY,ASSY POWER USM CX-NDS8
O KNOB 8A-NF6-104-010 — KEY,CD DIRECT 2 USM CX-NDS8
O KNOB 8A-NF6-105-010 — KEY,T-BASS U 2 USM CX-NDS8
X KNOB 8A-NF6-202-010 — GUIDE,FUN USM CX-NDS8
O KNOB 8A-NFG-003-010 0E KEY,DSP SURROUND USM CX-NDS8
O KNOB 8A-NFG-004-010 0E KEY,ASSY PRO ANF-16 USM CX-NDS8
X KNOB 8A-NFG-005-010 — BTN,PRO ANF-16 USM CX-NDS8
O KNOB 8A-NFG-006-010 — KEY,ASSY FUN ANF-16 USM CX-NDS8
X KNOB 8A-NFG-007-010 — KEY,FUN ANF-16 USM CX-NDS8
X KNOB 8A-NFT-201-010 — GUIDE,PRO USM CX-NDS8
X LBL,POP 87-B40-034-010 1B LBL,USA 1-800 USM CX-NDS8
X LBL,POP 8A-NF8-972-010 0E LBL,POP ENG USM CX-NDS8
X LBL,POP 8A-NFG-971-010 0E LBL,POP UR USM CX-NDS8
X LBL,POP 8A-NFT-970-010 1A LBL,POP UL USM CX-NDS8
O MACB MECHA * 87-067-001-010 0E S-SCREW,BVWWST2+3-12 W/O SLOT USM CX-NDS8
X MACB MECHA * 8A-NF6-227-010 1B HT-SINK,VM 2 USM CX-NDS8
X MECHANICAL 8A-NF6-211-210 1F CHAS,MAIN USM CX-NDS8
O MIC C 0601 87-010-186-080 0E C-CAP,S 4700P-50 K B C2012 USM CX-NDS8
O MIC C 0602 87-010-405-040 0E CAP,E 10-50 M 11L SME USM CX-NDS8
O MIC C 0603 87-010-320-080 0E C-CAP,S 68P-50 J CH GRM USM CX-NDS8
O MIC C 0604 87-010-546-040 0E CAP,E 0.33-50 M 11L SME USM CX-NDS8
O MIC C 0605 87-012-368-080 0E C-CAP,S 0.1-50 Z F USM CX-NDS8
O MIC C 0606 87-010-112-040 0E CAP,E 100-16 M 11L SME USM CX-NDS8
O MIC C 0607 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O MIC C 0608 87-010-178-080 0E C-CAP,S 1000P-50 K B C2012 USM CX-NDS8
O MIC C 0621 87-010-178-080 0E C-CAP,S 1000P-50 K B C2012 USM CX-NDS8
O MIC CN 0601 87-099-211-010 0E CONN,4P V BLK 6216 USM CX-NDS8
O MIC FB 0601 87-008-372-080 0E FLTR,EMI BL01 RN1 USM CX-NDS8
O MIC J 0601 87-A61-242-010 1A JACK,6.3 BLK MONO W/SW V KM USM CX-NDS8
O MIC J 0602 87-A61-242-010 1A JACK,6.3 BLK MONO W/SW V KM USM CX-NDS8
S MIC Q 0601 87-A30-087-080 0E C-FET,2SK2158 USM CX-NDS8
S MIC Q 0602 87-A30-076-080 0E C-TR,2SC3052F USM CX-NDS8
S MIC Q 0603 87-A30-076-080 0E C-TR,2SC3052F USM CX-NDS8
S MIC Q 0604 87-A30-075-080 0E C-TR,2SA1235F USM CX-NDS8
X MIC R 0601 88-118-104-080 0E C-RES,S 100K-1/10W J USM CX-NDS8
X MIC R 0602 88-118-334-080 0E C-RES,S 330K-1/10W J USM CX-NDS8
X MIC R 0603 88-118-154-080 0E C-RES,S 150K-1/10W J USM CX-NDS8
X MIC R 0604 88-118-224-080 0E C-RES,S 220K-1/10W J USM CX-NDS8
X MIC R 0605 88-118-562-080 0E C-RES,S 5.6K-1/10W J USM CX-NDS8
X MIC R 0606 88-118-334-080 0E C-RES,S 330K-1/10W J USM CX-NDS8
X MIC R 0607 88-118-472-080 0E C-RES,S 4.7K-1/10W J USM CX-NDS8

PARTS LIST
-19-
! =! SAFTY PARTS
C=Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
K NO. =Only use japanese.
C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX
X MIC R 0608 88-118-472-080 0E C-RES,S 4.7K-1/10W J USM CX-NDS8
X MIC R 0609 88-118-333-080 0E C-RES,S 33K-1/10W J USM CX-NDS8
X MIC R 0610 88-118-222-080 0E C-RES,S 2.2K-1/10W J USM CX-NDS8
X MIC R 0611 88-128-101-080 0E C-RES, 100-1/8W J USM CX-NDS8
X MIC R 0612 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
X MIC R 0613 88-118-102-080 0E C-RES,S 1K-1/10W J USM CX-NDS8
X MICON * 8A-NFG-615-010 1D PWB,COMB FRONT ANF-G USM CX-NDS8
X MICON * 8A-NFG-616-010 — PWB,FRONT ANF-G USM CX-NDS8
X MICON * 8A-NFG-617-010 — PWB,CD KEY ANF-G USM CX-NDS8
X MICON * 8A-NFG-618-010 — PWB,MIC ANF-G USM CX-NDS8
O MICON C 0101 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USM CX-NDS8
O MICON C 0102 87-010-322-080 0E C-CAP,S 100P-50 J CH GRM USM CX-NDS8
O MICON C 0103 87-010-312-080 0E C-CAP,S 15P-50 J CH GRM USM CX-NDS8
O MICON C 0104 87-012-157-080 0E C-CAP,S 330P-50 J CH GRM USM CX-NDS8
O MICON C 0105 87-010-415-040 0E CAP,E 10-50 M 5L SRE USM CX-NDS8
O MICON C 0106 87-010-493-040 0E CAP,E 0.47-50 M 5L SRE USM CX-NDS8
O MICON C 0107 87-A10-189-040 0E CAP,E 220-10 M 5L USM CX-NDS8
O MICON C 0108 87-A10-189-040 0E CAP,E 220-10 M 5L USM CX-NDS8
O MICON C 0109 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O MICON C 0110 87-010-178-080 0E C-CAP,S 1000P-50 K B C2012 USM CX-NDS8
O MICON C 0112 87-012-368-080 0E C-CAP,S 0.1-50 Z F USM CX-NDS8
O MICON C 0113 87-010-596-080 0E C-CAP,S 0.047-16 K R C2012 USM CX-NDS8
O MICON C 0114 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O MICON C 0115 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O MICON C 0116 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O MICON C 0118 87-012-145-080 0E C-CAP,S 270P-50 J CH GRM USM CX-NDS8
O MICON C 0180 87-010-178-080 0E C-CAP,S 1000P-50 K B C2012 USM CX-NDS8
O MICON C 0181 87-010-178-080 0E C-CAP,S 1000P-50 K B C2012 USM CX-NDS8
O MICON C 0202 87-012-156-080 0E C-CAP,S 220P-50 J CH GRM USM CX-NDS8
O MICON C 0203 87-010-322-080 0E C-CAP,S 100P-50 J CH GRM USM CX-NDS8
O MICON C 0204 87-012-157-080 0E C-CAP,S 330P-50 J CH GRM USM CX-NDS8
O MICON C 0205 87-012-156-080 0E C-CAP,S 220P-50 J CH GRM USM CX-NDS8
O MICON C 0214 87-010-322-080 0E C-CAP,S 100P-50 J CH GRM USM CX-NDS8
O MICON C 0215 87-010-322-080 0E C-CAP,S 100P-50 J CH GRM USM CX-NDS8
O MICON C 0216 87-010-177-080 0E C-CAP,S 820P-50 J SL C2012 USM CX-NDS8
O MICON C 0221 87-010-421-040 0E CAP,E 4.7-50 M 5L SRE USM CX-NDS8
O MICON C 0222 87-010-421-040 0E CAP,E 4.7-50 M 5L SRE USM CX-NDS8
O MICON C 0223 87-010-408-040 0E CAP,E 47-50 M 11L SME USM CX-NDS8
O MICON C 0224 87-012-369-080 0E C-CAP,S 0.047-50 Z F USM CX-NDS8
O MICON C 0312 87-010-498-040 0E CAP,E 10-16 M 5L SRE USM CX-NDS8
O MICON C 0314 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O MICON C 0315 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O MICON C 0316 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O MICON C 0321 87-012-393-080 0E C-CAP,S 0.22-16 K W5R CM/CB USM CX-NDS8
O MICON C 0382 87-010-320-080 0E C-CAP,S 68P-50 J CH GRM USM CX-NDS8
O MICON C 0383 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O MICON C 0384 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O MICON C 0385 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O MICON C 0386 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O MICON C 0387 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O MICON C 0392 87-010-320-080 0E C-CAP,S 68P-50 J CH GRM USM CX-NDS8
O MICON C 0401 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O MICON C 0402 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O MICON C 0403 87-010-322-080 0E C-CAP,S 100P-50 J CH GRM USM CX-NDS8
O MICON C 0404 87-010-322-080 0E C-CAP,S 100P-50 J CH GRM USM CX-NDS8
O MICON C 0405 87-010-322-080 0E C-CAP,S 100P-50 J CH GRM USM CX-NDS8
O MICON C 0406 87-010-322-080 0E C-CAP,S 100P-50 J CH GRM USM CX-NDS8
O MICON C 0407 87-010-322-080 0E C-CAP,S 100P-50 J CH GRM USM CX-NDS8
O MICON C 0408 87-010-322-080 0E C-CAP,S 100P-50 J CH GRM USM CX-NDS8
O MICON C 0461 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O MICON C 0462 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O MICON C 0463 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O MICON C 0464 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
O MICON C 0465 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-NDS8
X MICON C 0651 88-118-000-080 0E C-JUMPER,S USM CX-NDS8
O MICON C 0652 87-010-183-080 0E C-CAP,S 2700P-50 K B GRM USM CX-NDS8
O MICON C 0653 87-010-213-080 0E C-CAP,S 0.015-25 K B GRM USM CX-NDS8
O MICON C 0701 87-010-406-040 0E CAP,E 22-50 M 11L SME USM CX-NDS8
! O MICON CN 0101 87-099-720-010 1B CONN,30P BLK TYK-B(P) USM CX-NDS8
! O MICON CN 0103 87-099-013-010 0E CONN,11P V BLK 6216 USM CX-NDS8
