Aiwa CSD-TD29 User manual
SERVICE MANUAL
DATA
CSD-TD29
K(S),EZ(S),
COMPACT DISC STEREO RADIO
CASSETTE RECEIVER BASIC CD MECHANISM : KSM-213 RDM
BASIC TRAPE MECHANISM : AZM-6 YR3NC
S/M Code No. 09-027-457-9T2
SIMPLE
Replace this Service Manual with "Revision Publishing" when it is issued.
K(S),EZ(S)
CSD-TD69
EZ(L)
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-2-
ACCESSORIES PARTS LIST -1/1
CSD-TD29 CSD-TD29 CSD-TD29 CSD-TD69 CSD-TD69
KSC EZSC EZLC KSC EZSC
O AS1001 87-099-726-010 PLUG,ADPTR CONV(K) X a . . d .
O AS1002 87-A80-081-010 AC CORD SET ASSY,EZ BLK X a b c d e
O AS1003 8C-CHE-951-010 RC UNIT,RC-CAT1 . . . d e
X AS1004 8C-CHA-971-010 LBL,POP U a b c . .
X AS1005 8C-CHL-972-010 LBL,POP EZ . . . d e
X AS1006 87-056-600-010 LBL,L K a . . d .
X AS1007 87-056-926-010 LBL,COLOR L BLU . . c . .
X AS1008 8C-CHA-851-010 CUSHION,ASSY CCHA a b c d e
X AS1009 8C-CHA-857-010 CTN,PRINTED EZSC a b c . .
X AS1010 8C-CHA-858-010 CTN,OUTER KSC a . . . .
X AS1011 8C-CHA-859-010 CTN,OUTER EZSC . b . . .
X AS1012 8C-CHA-866-010 CTN,OUTER EZLC . . c . .
X AS1013 8C-CHL-856-010 CTN,PRINTED EZSC . . . d e
X AS1014 8C-CHL-857-010 CTN,OUTER KSC . . . d .
X AS1015 8C-CHL-858-010 CTN,OUTER EZSC . . . . e
X AS1016 87-056-168-010 SH,CAUTION INF-WARR(EC) a b c d e
X AS1017 87-B40-085-010 BAG,PV 0.04-200-350 PL a b c d e
X AS1018 87-B50-079-010 LIST,FACILITY(B)-0007 a b c d e
O AS1019 8C-CHA-905-010 IB,K(E)FM TD29/69 a . . d .
O AS1020 8C-CHA-906-010 IB,EZ(9L)FM TD29/69 . b c . e
