Aiwa LCX-155 User manual

S E R V I C E M A N U A L
SIMPLE MANUAL
•Replace this Service Manual with ”Revision Publishing” when it is issued.
LCX-155
• TYPE: U
S/M Code No. 09–98B–310–70A
COMPACTDISCSTEREOSYSTEM

ELECTRICAL MAIN PARTS LIST-1
NOTE: The characters in the suffix column indicate the part usage.
USC ....................XX..................................A...................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
JW 378 87-A90-896-080 F-BEAD, 035600STY7 A...................
JW 504 87-A90-896-080 F-BEAD, 035600STY7 A...................
C 161 87-010-178-080 CHIP CAP 1000P A...................
C 209 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 203 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 201 87-010-375-080 CAP,E 330-10 SME A...................
C 202 87-012-350-080 C-CAP,1-25 F A...................
C 208 87-015-819-080 CAPACITOR,0.01 A...................
C 213 87-010-154-080 CAP CHIP 10P A...................
C 217 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 210 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 212 87-010-318-080 C-CAP,S 47P-50 CH A...................
C 216 87-010-400-080 CAP, ELECT 0.47-50V A...................
C 214 87-012-149-080 C-CAP,S 30P-50 CH A...................
CN 201 87-099-720-010 CONN,30P TYK-B(P) A...................
CN 202 87-A60-404-010 CONN,3P TKX-P03P-F1 A...................
D 3 87-A40-291-080 DIODE,1N4148 (CPT) A...................
D 205 87-020-027-080 CHIP-DIODE 1SS184 A...................
D 202 87-A40-291-080 DIODE,1N4148 (CPT) A...................
D 201 87-A40-291-080 DIODE,1N4148 (CPT) A...................
D 209 87-A40-291-080 DIODE,1N4148 (CPT) A...................
D 212 87-027-825-080 ZENER,HZ9A3L A...................
D 211 87-A40-291-080 DIODE,1N4148 (CPT) A...................
D 942 87-A40-365-080 LED,L-1154 SGD A...................
D 945 87-A40-365-080 LED,L-1154 SGD A...................
D 946 87-A40-365-080 LED,L-1154 SGD A...................
D 944 87-A40-365-080 LED,L-1154 SGD A...................
D 948 87-A40-365-080 LED,L-1154 SGD A...................
D 949 87-A40-365-080 LED,L-1154 SGD A...................
D 947 87-A40-365-080 LED,L-1154 SGD A...................
D 943 87-A40-365-080 LED,L-1154 SGD A...................
D 941 87-A40-365-080 LED,L-1154 SGD A...................
IC 202 87-A20-914-010 IC,SPS-442-1-F A...................
IC 201 8Z-CL8-661-010 IC,LC867240A A...................
L 206 87-003-098-080 COIL,2.2UH A...................
LCD 201 8Z-CL8-665-010 LCD,ZCL-8 A...................
Q 202 87-026-223-080 TR,DTC143TK A...................
Q 201 87-026-237-080 CHIP-TR,DTC124XK A...................
Q 203 89-320-011-080 TR,2SC2001 (15W) A...................
S 201 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 207 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 205 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 206 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 208 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 204 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 209 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 203 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 215 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 212 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 211 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 214 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 213 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 210 87-A90-095-080 SW,TACT EVQ11G04M A...................
X 202 87-A70-070-080 VIB,CER 5.76MHZ CRHF A...................
8Z-CL8-682-010 FF-CABLE, 16P 1.0 180MM A...................
C 5 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 8 87-010-198-080 CAP, CHIP 0.022 A...................
C 4 87-010-248-080 CAP, ELECT 220-10V A...................
C 9 87-010-263-080 CAP, ELECT 100-10V A...................
C 6 87-010-374-080 CAP, ELECT 47-10V A...................
C 1 87-010-406-080 CAP, ELECT 22-50 A...................
C 17 87-010-178-080 CHIP CAP 1000P A...................
C 15 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 13 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 18 87-010-213-080 C-CAP,S 0.015-50 B A...................
C 10 87-010-263-080 CAP, ELECT 100-10V A...................
C 12 87-010-401-080 CAP, ELECT 1-50V A...................
C 14 87-010-405-080 CAP, ELECT 10-50V A...................
C 16 87-010-546-080 CAP, ELECT 0.33-50V A...................
C 29 87-010-178-080 CHIP CAP 1000P A...................
C 24 87-010-180-080 C-CER 1500P A...................
C 39 87-010-178-080 CHIP CAP 1000P A...................
C 34 87-010-186-080 CAP,CHIP 4700P A...................
C 38 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 35 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 36 87-010-374-080 CAP, ELECT 47-10V A...................
C 33 87-010-403-080 CAP, ELECT 3.3-50V A...................
C 37 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 32 87-010-406-080 CAP, ELECT 22-50 A...................
C 31 87-010-545-080 CAP, ELECT 0.22-50V A...................
C 30 87-012-140-080 CAP 470P A...................
C 40 87-010-147-080 C-CAP,S 3P-50 CH A...................
C 44 87-010-176-080 C-CAP,S 680P-50 SL A...................
C 46 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 45 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 42 87-010-313-080 CAP, CHIP 18P A...................

ELECTRICAL MAIN PARTS LIST-2
C 48 87-010-315-080 C-CAP,S 27P-50 CH A...................
C 59 87-010-263-080 CAP, ELECT 100-10V A...................
C 58 87-010-314-080 C-CAP,S 22P-50V A...................
C 57 87-010-314-080 C-CAP,S 22P-50V A...................
C 60 87-010-178-080 CHIP CAP 1000P A...................
C 61 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 62 87-010-248-080 CAP, ELECT 220-10V A...................
C 65 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 77 87-010-112-080 CAP, ELECT 100-16V A...................
C 74 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 72 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 73 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 78 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 71 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 83 87-010-178-080 CHIP CAP 1000P A...................
C 84 87-010-178-080 CHIP CAP 1000P A...................
C 86 87-010-183-080 C-CAP,S 2700P-50 B A...................
C 87 87-010-183-080 C-CAP,S 2700P-50 B A...................
C 82 87-010-405-080 CAP, ELECT 10-50V A...................
C 81 87-010-405-080 CAP, ELECT 10-50V A...................
C 95 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 93 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 94 87-010-263-080 CAP, ELECT 100-10V A...................
C 91 87-010-380-080 CAP, ELECT 47-16V A...................
C 98 87-012-154-080 C-CAP,S 150P-50 CH A...................
C 96 87-016-459-040 CAP,E 470-10 SMG A...................
C 103 87-010-297-080 CAP CHIO 100P A...................
C 105 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 106 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 102 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 101 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 112 87-010-235-080 CAP,E 470-16 SME A...................
C 111 87-010-235-080 CAP,E 470-16 SME A...................
C 133 87-012-365-080 C-CAP,S 0.027-25VBK A...................
C 154 87-010-178-080 CHIP CAP 1000P A...................
C 157 87-010-178-080 CHIP CAP 1000P A...................
C 151 87-010-194-080 CAP, CHIP 0.047 A...................
C 153 87-010-194-080 CAP, CHIP 0.047 A...................
C 156 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 150 87-010-452-080 CAPACITOR,1-16 A...................
C 152 87-012-359-080 C-CAP,S 0.68-10 FZ A...................
C 155 87-012-359-080 C-CAP,S 0.68-10 FZ A...................
C 158 87-012-359-080 C-CAP,S 0.68-10 FZ A...................
C 159 87-015-835-080 C-CAP,0.047 D A...................
C 160 87-010-178-080 CHIP CAP 1000P A...................
CN 4 87-A60-248-010 CONN,16P H CFF1416 A...................
CN 3 8Z-CL8-681-010 CONN ASSY,6P CD MOTOR A...................
D 2 87-A40-291-080 DIODE,1N4148 (CPT) A...................
D 11 87-070-274-080 DIODE,1N4003 SEM A...................
D 12 87-A40-291-080 DIODE,1N4148 (CPT) A...................
FB 1 83-XM1-617-080 C-COIL,BK2125HM601 A...................
IC 1 87-A20-446-010 C-IC,LA9241ML A...................
IC 2 87-A20-459-010 C-IC,LC78622ED A...................
IC 3 87-A20-856-010 IC,BA6898S A...................
Q 1 87-026-463-080 TR,2SA933S (0.3W) A...................
Q 91 87-026-210-080 CHIP-TR,DTC144EK A...................
Q 90 87-026-211-080 TR,DTA144EK A...................
Q 93 87-026-610-080 TR,KTC3198GR A...................
Q 92 87-A30-226-010 TR,2SB1655E A...................
Q 94 89-112-965-080 TR,2SA1296 (0.75W) A...................
X 1 87-A70-046-010 VIB,XTAL 16.934MHZ A...................
T 2 87-A60-317-010 TERMINAL, 1P MSC A...................
T 1 87-A60-317-010 TERMINAL, 1P MSC A...................
C 209 87-010-220-080 C-CAP,S 0.018-25 B A...................
C 208 87-010-220-080 C-CAP,S 0.018-25 B A...................
C 205 87-010-401-080 CAP, ELECT 1-50V A...................
C 204 87-010-401-080 CAP, ELECT 1-50V A...................
C 207 87-010-402-080 CAP, ELECT 2.2-50V A...................
C 206 87-010-402-080 CAP, ELECT 2.2-50V A...................
C 203 87-010-405-080 CAP, ELECT 10-50V A...................
C 219 87-010-248-080 CAP, ELECT 220-10V A...................
C 213 87-010-248-080 CAP, ELECT 220-10V A...................
C 217 87-010-382-080 CAP, ELECT 22-25V A...................
C 215 87-010-384-080 CAP, ELECT 100-25V A...................
C 216 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 220 87-010-237-080 CAP, ELECT 1000-16V A...................
C 222 87-010-237-080 CAP, ELECT 1000-16V A...................
C 221 87-010-248-080 CAP, ELECT 220-10V A...................
C 241 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 242 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 243 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 245 87-010-197-080 CAP, CHIP 0.01 DM A...................
D 201 87-A40-291-080 DIODE,1N4148 (CPT) A...................
IC 201 87-A20-734-010 IC,TDA2007A A...................
J 201 87-A60-420-010 JACK,3.5 ST (MSC) A...................
J 202 87-A60-754-010 TERMINAL,SPK 4P MSP-154V-05 A...................
L 202 87-005-366-010 COIL, 1UH A...................
L 201 87-005-366-010 COIL, 1UH A...................
Q 204 87-026-218-080 TR,DTC144ES (0.2W) A...................
Q 201 87-026-313-080 TR,DTC343TS A...................
Q 202 87-026-313-080 TR,DTC343TS A...................
Q 205 87-026-609-080 TR,KTA1266GR A...................

ELECTRICAL MAIN PARTS LIST-3
Q 203 89-213-702-010 TR,2SB1370 (1.8W) A...................
C 109 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 126 87-010-190-080 S CHIP F 0.01 A...................
C 128 87-010-192-080 C-CAP,S 0.022-50 F A...................
C 129 87-010-192-080 C-CAP,S 0.022-50 F A...................
C 127 87-010-403-080 CAP, ELECT 3.3-50V A...................
C 125 87-016-658-090 CAP,E 4700-35 SMG A...................
C 135 87-010-101-080 CAP, ELECT 220-16 A...................
C 136 87-010-112-080 CAP, ELECT 100-16V A...................
C 131 87-010-192-080 C-CAP,S 0.022-50 F A...................
C 130 87-010-192-080 C-CAP,S 0.022-50 F A...................
C 132 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 138 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 133 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 137 87-010-260-080 CAP, ELECT 47-25V A...................
C 144 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 143 87-010-263-080 CAP, ELECT 100-10V A...................
C 141 87-012-140-080 CAP 470P A...................
CF 101 87-033-213-080 CLAMP, FUSE A...................
CF 102 87-033-213-080 CLAMP, FUSE A...................
D 105 87-070-022-010 DIODE,IN5402 (RECT) A...................
D 104 87-070-022-010 DIODE,IN5402 (RECT) A...................
D 103 87-070-022-010 DIODE,IN5402 (RECT) A...................
D 106 87-070-022-010 DIODE,IN5402 (RECT) A...................
D 102 87-A40-291-080 DIODE,1N4148 (CPT) A...................
D 109 87-A40-291-080 DIODE,1N4148 (CPT) A...................
D 101 87-A40-291-080 DIODE,1N4148 (CPT) A...................
D 100 87-A40-291-080 DIODE,1N4148 (CPT) A...................
D 114 87-017-932-080 ZENER,MTJ6.2B A...................
D 115 87-070-334-080 ZENER,MTZJ10B A...................
D 113 87-A40-291-080 DIODE,1N4148 (CPT) A...................
D 116 87-A40-291-080 DIODE,1N4148 (CPT) A...................
F 101 87-035-457-010 FUSE,3.15A 250V TW/C A...................
PR 100 87-A90-093-080 PROTECTOR,3A 491SERIES 60V A...................
Q 106 87-026-610-080 TR,KTC3198GR A...................
Q 107 87-026-610-080 TR,KTC3198GR A...................
Q 104 87-026-610-080 TR,KTC3198GR A...................
Q 103 87-026-610-080 TR,KTC3198GR A...................
Q 108 87-026-610-080 TR,KTC3198GR A...................
Q 111 87-026-610-080 TR,KTC3198GR A...................
Q 110 89-213-702-010 TR,2SB1370 (1.8W) A...................
W 2 8Z-CL8-691-010 F-CABLE,3P 2.5 180MM A...................
WH 101 87-A90-458-010 HLDR,WIRE 2.5-3P A...................
8Z-CL8-686-010 CONN ASSY,8P RPH A...................
C 408 87-010-248-080 CAP, ELECT 220-10V A...................
C 401 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 402 87-010-401-080 CAP, ELECT 1-50V A...................
C 409 87-010-405-080 CAP, ELECT 10-50V A...................
C 407 87-010-405-080 CAP, ELECT 10-50V A...................
C 405 87-010-406-080 CAP, ELECT 22-50 A...................
C 410 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 413 87-010-401-080 CAP, ELECT 1-50V A...................
C 412 87-010-406-080 CAP, ELECT 22-50 A...................
C 415 87-010-426-080 C-CAP,S 0.012-25 B A...................
C 418 87-010-426-080 C-CAP,S 0.012-25 B A...................
C 422 87-010-112-080 CAP, ELECT 100-16V A...................
C 429 87-010-178-080 CHIP CAP 1000P A...................
C 431 87-010-178-080 CHIP CAP 1000P A...................
C 430 87-010-178-080 CHIP CAP 1000P A...................
C 432 87-010-263-080 CAP, ELECT 100-10V A...................
C 434 87-010-401-080 CAP, ELECT 1-50V A...................
CN 401 87-099-408-010 CONN,8P EH V WHT A...................
D 405 87-A40-291-080 DIODE,1N4148 (CPT) A...................
D 403 87-A40-291-080 DIODE,1N4148 (CPT) A...................
D 404 87-A40-291-080 DIODE,1N4148 (CPT) A...................
IC 401 87-001-596-010 IC,NJM4580L A...................
L 401 88-CL6-609-010 COIL,BIAS 8CL6 A...................
Q 403 87-CD7-603-080 TR,SS8050 A...................
SW 401 88-CL6-608-010 SW,RP 8CL6 A...................
C 306 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 301 87-010-401-080 CAP, ELECT 1-50V A...................
C 302 87-010-401-080 CAP, ELECT 1-50V A...................
C 308 87-010-545-080 CAP, ELECT 0.22-50V A...................
C 309 87-010-545-080 CAP, ELECT 0.22-50V A...................
C 305 87-010-545-080 CAP, ELECT 0.22-50V A...................
C 304 87-010-545-080 CAP, ELECT 0.22-50V A...................
C 311 87-010-182-080 C-CAP,S 2200P-50 B A...................
C 310 87-010-263-080 CAP, ELECT 100-10V A...................
C 312 87-010-263-080 CAP, ELECT 100-10V A...................
C 315 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 319 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 316 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 318 87-010-405-080 CAP, ELECT 10-50V A...................
C 317 87-010-405-080 CAP, ELECT 10-50V A...................
C 314 87-010-405-080 CAP, ELECT 10-50V A...................
C 313 87-010-405-080 CAP, ELECT 10-50V A...................
C 320 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 333 87-010-178-080 CHIP CAP 1000P A...................
C 332 87-010-178-080 CHIP CAP 1000P A...................
C 331 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 330 87-010-197-080 CAP, CHIP 0.01 DM A...................
CN 301 87-099-719-010 CONN,30P TYK-B(X) A...................

ELECTRICAL MAIN PARTS LIST-4
D 302 87-070-136-080 ZENER,MTZJ5.1B A...................
D 301 87-A40-347-080 ZENER,MTZJ2.2B A...................
IC 301 87-A20-715-010 IC,M62439SP A...................
J 301 87-A60-354-010 JACK,PIN 2P MSP -242V-05 A...................
Q 300 87-026-610-080 TR,KTC3198GR A...................
C 819 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 813 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 814 87-012-286-080 CAP, U 0.01-25 A...................
C 812 87-012-286-080 CAP, U 0.01-25 A...................
C 829 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 828 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 820 87-010-260-080 CAP, ELECT 47-25V A...................
C 823 87-012-286-080 CAP, U 0.01-25 A...................
C 821 87-012-286-080 CAP, U 0.01-25 A...................
C 822 87-012-286-080 CAP, U 0.01-25 A...................
C 959 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 960 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 963 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 961 87-012-170-080 C-CAP,U 8P-50 CH A...................
CF 801 87-008-261-010 FILTER, SFE10.7MA5-A A...................
CF 802 87-008-261-010 FILTER, SFE10.7MA5-A A...................
FFE 801 A8-8ZA-193-070 8ZA-1 YFEUNC A...................
J 801 87-A60-202-010 TERMINAL,ANT 4P MSP-154V-02 A...................
L 981 87-NF4-650-010 COIL,AM PACK 4N(TOK) A...................
Q 806 87-A30-072-080 C-TR,RT1P 144C A...................
Q 805 89-327-143-080 TR,2SC2714 (0.1W) A...................
C 731 87-012-286-080 CAP, U 0.01-25 A...................
C 758 87-012-167-080 C-CAP,U 5P-50 CH A...................
C 757 87-012-188-080 C-CAP,U 47P-50 CH A...................
C 756 87-012-286-080 CAP, U 0.01-25 A...................
C 769 87-010-260-080 CAP, ELECT 47-25V A...................
C 763 87-010-829-080 CAP, U 0.047-16 A...................
C 765 87-012-286-080 CAP, U 0.01-25 A...................
C 768 87-012-286-080 CAP, U 0.01-25 A...................
C 764 87-012-337-080 C-CAP,U 56P-50 CH A...................
C 773 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 774 87-010-263-080 CAP, ELECT 100-10V A...................
C 771 87-010-383-080 CAP, ELECT 33-25V A...................
C 777 87-010-400-080 CAP, ELECT 0.47-50V A...................
C 779 87-010-401-080 CAP, ELECT 1-50V A...................
C 778 87-010-401-080 CAP, ELECT 1-50V A...................
C 775 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 772 87-010-829-080 CAP, U 0.047-16 A...................
C 770 87-010-829-080 CAP, U 0.047-16 A...................
C 776 87-012-286-080 CAP, U 0.01-25 A...................
C 780 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 786 87-010-401-080 CAP, ELECT 1-50V A...................
C 785 87-010-401-080 CAP, ELECT 1-50V A...................
C 781 87-010-405-080 CAP, ELECT 10-50V A...................
C 782 87-010-405-080 CAP, ELECT 10-50V A...................
C 789 87-012-275-080 C-CAP,U 1200P-50 B A...................
C 783 87-012-286-080 CAP, U 0.01-25 A...................
C 784 87-012-286-080 CAP, U 0.01-25 A...................
C 796 87-010-403-080 CAP, ELECT 3.3-50V A...................
C 791 87-010-405-080 CAP, ELECT 10-50V A...................
C 794 87-010-406-080 CAP, ELECT 22-50 A...................
C 795 87-010-596-080 CAP, S 0.047-16 A...................
C 799 87-010-829-080 CAP, U 0.047-16 A...................
C 793 87-012-273-080 C-CAP,U 820P-50 B A...................
C 790 87-012-275-080 C-CAP,U 1200P-50 B A...................
C 798 87-012-278-080 C-CAP,U 2200P-50 B A...................
C 797 87-012-278-080 C-CAP,U 2200P-50 B A...................
D 773 87-A40-470-080 DIODE,1SS254 A...................
IC 771 87-A20-913-010 IC,LA1837NL A...................
L 771 87-A50-266-010 COIL,FM DET-2N(TOK) A...................
L 772 87-A90-733-010 FLTR,PCFAZH-450 (TOK) A...................
C 701 87-010-260-080 CAP, ELECT 47-25V A...................
C 702 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 709 87-012-195-080 C-CAP,U 100P-50CH A...................
C 704 87-012-286-080 CAP, U 0.01-25 A...................
C 703 87-012-286-080 CAP, U 0.01-25 A...................
C 711 87-010-263-080 CAP, ELECT 100-10V A...................
C 712 87-010-831-080 C-CAP,U,0.1-16F A...................
C 717 87-012-286-080 CAP, U 0.01-25 A...................
C 719 87-012-286-080 CAP, U 0.01-25 A...................
C 714 87-012-286-080 CAP, U 0.01-25 A...................
C 727 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 728 87-010-248-080 CAP, ELECT 220-10V A...................
C 722 87-012-176-080 CAP 15P A...................
C 721 87-012-176-080 CAP 15P A...................
C 720 87-012-195-080 C-CAP,U 100P-50CH A...................
C 729 87-012-274-080 CHIP CAP,U 1000P-50B A...................
C 723 87-012-274-080 CHIP CAP,U 1000P-50B A...................
C 725 87-012-274-080 CHIP CAP,U 1000P-50B A...................
IC 721 87-070-127-110 IC,LC72131 D A...................
Q 711 87-A30-196-080 TR,2SC4115SRS A...................
X 721 87-A70-061-010 VIB,XTAL 4.500MHZ CSA-309 A...................
87-A80-110-010 AC CORD ASSY,U SPT-2W A...................
PT 101 8Z-CL8-652-010 PT,U HI A...................
WH 2 87-A90-458-010 HLDR,WIRE 2.5-3P A...................

MECHANICAL PARTS LIST-1
NOTE: The characters in the suffix column indicate the part usage.
USC ....................XX..................................A...................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
8Z-CL8-001-010 CABI,FR U A...................
8Z-CL8-007-010 BOX,CASS A...................
8Z-CL8-008-010 PANEL,CASS A...................
8Z-CL8-020-010 LID,CD A...................
8Z-CL8-021-010 CHAS,CD A...................
8Z-CL8-025-010 KEY,CONT A...................
8Z-CL8-027-010 KEY,POWER A...................
8Z-CL8-028-010 KEY,GEQ A...................
8Z-CL8-029-010 KEY,VOL A...................
8Z-CL8-030-010 KEY,CASS A...................
87-B00-002-010 BADGE,AIWA 30 ABS SIL A...................
8Z-CL8-022-010 WINDOW,DISP A...................
8Z-CL8-023-010 WINDOW,CASS A...................
8Z-CL8-024-010 WINDOW,TOP A...................
86-CD0-223-010 COVER, CHUCK A...................
86-NFZ-231-010 DMPR,70 A...................
87-036-368-010 MAGNET A...................
87-064-108-010 NC LATCH A...................
87-NF8-220-010 DMPR,150 A...................
88-CD9-210-110 BASE,CHUCK A...................
88-CD9-211-110 RING,CHUCK A...................
88-CH6-019-010 PANEL,CD A...................
8Z-CL8-204-010 CUSH,FOOT A...................
8Z-CL8-205-010 SPR-T,CD A...................
8Z-CL8-206-010 SPR-P,REC A...................
8Z-CL8-209-010 SPR-T,CASS A...................
* 8Z-CL8-201-010 GUIDE,LCD A...................
87-067-703-010 TAPPING SCREW, BVT2+3-10 A...................
87-342-074-010 UT2+2.6-8 A...................
87-571-032-410 VIT+2-3 A...................
87-741-170-410 UT2+4-8 A...................
87-761-096-410 VFT2+3-10 GLD A...................
* 87-571-033-410 TAPPING SCREW, VIT+2-4 A...................
* 87-B10-230-010 BVT2+3-10 W/O SLOT SILVER CR A...................
* 87-B10-231-010 QT1+3-12 SILVER CR A...................
81-590-677-010 SWITCH LEAF A...................
87-A90-896-080 F-BEAD, 035600STY7 A...................
8Z-CL8-682-010 FF-CABLE, 16P 1.0 180MM A...................
W 2 8Z-CL8-691-010 F-CABLE,3P 2.5 180MM A...................
WH 101 87-A90-458-010 HLDR,WIRE 2.5-3P A...................
8Z-CL8-686-010 CONN ASSY,8P RPH A...................
87-A80-110-010 AC CORD ASSY,U SPT-2W A...................
WH 2 87-A90-458-010 HLDR,WIRE 2.5-3P A...................

ACCESSORIES/PACKAGELIST
NOTE: The characters in the suffix column indicate the part usage.
USC ....................XX..................................A...................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
8Z-CL8-901-010 IB,U (ESF)C A...................
8Z-CL8-671-010 SPKR,WOOFER 4OHM 8W A...................
8Z-CL8-694-010 CORD,SPKR GRY A...................
87-067-758-010 BVT2+3-12 W/O SLOT A...................
87-761-097-410 VFT2+3-10 GLD A...................
87-B00-002-010 BADGE,AIWA 30 ABS SIL A...................
87-CL4-099-010 SPKR,CORD BUSH A...................
8Z-CL8-101-010 CABI,FR SPKR A...................
8Z-CL8-103-010 FRAME,SPKR A...................
8Z-CL8-204-010 CUSH,FOOT A...................
87-043-115-010 ANT,FEEDER FM A...................
87-A90-030-010 ANT,LOOP AM-NC C A...................
8Z-CK4-952-010 RC UNIT,RC-ZAT04 A...................
