SERVICE MANUAL
DATA
BASIC TAPE MECHANISM : TN-21ZSC-2003
BASIC CD MECHANISM : DA11T3C
COMPACT DISC STEREO
SYSTEM
LCX-257
S/M Code No. 09-006-346-6N1
HR(S,L,D)
EZ (S,L,D)
K(S,L,D)
HS(L) HC(L)
MODEL CODE : 86HR8-0117(B)

2
TABLE OF CONTENTS
SPECIFICATIONS .................................................................................................................................. 3
PROTECTION OF EYES FROM LASER BEAM DURING SERVICING/
Precaution to replace Optical block (SF-P101NR).................................................................................. 4
ELECTRICAL MAIN PARTS LIST ....................................................................................................... 5-8
WIRING-1 (MAIN: HC, HR)............................................................................................................... 9, 10
WIRING-2 (MAIN: HS, K, EZ ) ........................................................................................................ 11, 12
SCHEMATIC DIAGRAM-1 (MAIN 1/2)............................................................................................ 13, 14
WIRING-3 (PT)................................................................................................................................ 15, 16
SCHEMATIC DIAGRAM-2 (TUNER: HC, HR)................................................................................ 17, 18
SCHEMATIC DIAGRAM-3 (TUNER: HS, K, EZ,) ........................................................................... 19, 20
WIRING-4 (MICON/KEY/LED) ........................................................................................................ 21, 22
SCHEMATIC DIAGRAM-4 (MICON)............................................................................................... 23, 24
WIRING-5 (CD/MOTOR)................................................................................................................. 25, 26
SCHEMATIC DIAGRAM-5 (CD) ..................................................................................................... 27, 28
ELECTRICAL ADJUSTMENT-1 (HC, HR)...................................................................................... 29, 30
ELECTRICAL ADJUSTMENT-2 (HS, K, EZ) .................................................................................. 31, 32
VOLTAGE CHART........................................................................................................................... 33-35
FL (AIW4214-30PIN ACJ-11) GRID ASSIGNMENT/ANODE CONNECTION...................................... 36
TRANSISTOR ILLUSTRATION ............................................................................................................ 36
IC BLOCK DIAGRAM............................................................................................................................ 37
IC DESCRIPTION ............................................................................................................................ 38-43
MECHANICAL PARTS LIST 1/1 ........................................................................................................... 44
MECHANICAL EXPLODED VIEW 1/1............................................................................................ 45, 46
TAPE MECHANISM EXPLODED VIEW 1/1 ......................................................................................... 47
TAPE MECHANISM PARTS LIST 1/1 .................................................................................................. 48
CD MECHANISM EXPLODED VIEW 1/1 ............................................................................................. 49
CD MECHANISM PARTS LIST 1/1 ...................................................................................................... 49
SPEAKER PARTS LIST 1/1.................................................................................................................. 50
ACCESSORIES/PACKAGE LIST ......................................................................................................... 51

3
SPECIFICATIONS
HC, HR, MODELS HS, K, EZ MODELS
•
Design and specifications are subject to change without
notice.
•
Design and specifications are subject to change without
notice.

4
PROTECTION OF EYES FROM LASER BEAM DURING SERVICING
VAROITUS!
Laiteen Käyttäminen muulla kuin tässä käyttöohjeessa mainit-
ulla tavalla saattaa altistaa käyt-täjän turvallisuusluokan 1 ylit-
tävälle näkymättömälle lasersäteilylle.
VARNING!
Om apparaten används på annat sätt än vad som specificeras i
denna bruksanvising, kan användaren utsättas för osynling
laserstrålning, som överskrider gränsen för laserklass 1.
Caution: Invisible laser radiation when
open and interlocks defeated avoid expo-
sure to beam.
Advarsel:Usynling laserståling ved åbning,
når sikkerhedsafbrydere er ude af funktion.
Undgå udsættelse for stråling.
CAUTION
Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous
radiation exposure.
ATTENTION
L'utilisation de commandes, réglages ou procédures autres que
ceux spécifiés peut entraîner une dangereuse exposition aux
radiations.
ADVARSEL!
Usynlig laserståling ved åbning, når sikkerhedsafbrydereer ude
af funktion. Undgå udsættelse for stråling.
This Compact Disc player is classified as a CLASS 1 LASER
product.
The CLASS 1 LASER PRODUCT label is located on the rear
exterior.
This set employs laser. Therefore, be sure to follow carefully the
instructions below when servicing.
WARNING!
WHEN SERVICING, DO NOT APPROACH THE LASER EXIT
WITH THE EYE TOO CLOSELY. IN CASE IT IS NECESSARY TO
CONFIRM LASER BEAM EMISSION. BE SURE TO OBSERVE
FROM A DISTANCE OF MORE THAN 30cm FROM THE
SURFACE OF THE OBJECTIVE LENS ON THE OPTICAL
PICK-UP BLOCK.
CLASS 1
KLASSE 1
LUOKAN 1
KLASS 1
LASER PRODUCT
LASER PRODUKT
LASER LAITE
LASER APPARAT
Precaution to replace Optical block
(SF-P101NR)
1) After the connection, remove solder shown in
the right figure.
Body or clothes electrostatic potential could ruin
laser diode in the optical block. Be sure ground
body and workbench, and use care the clothes
do not touch the diode.
Solder
PICK-UP Assy P.C.B

5
REF. NO PART NO. KANRI DESCRIPTION
NO.
REF. NO PART NO. KANRI DESCRIPTION
NO.
ELECTRICAL MAIN PARTS LIST
IC
87-A21-368-010 IC,NJM7812FA(A)
87-A21-365-010 IC,NJM7808FA
87-002-849-080 IC,NJM78L06A
87-A21-443-040 C-IC,M62495AFP
87-A21-020-010 IC,TA8223K
87-A21-431-010 IC,BA4560N
87-A20-446-010 C-IC,LA9241ML
87-A20-459-010 C-IC,LC78622ED
87-A21-093-010 IC,LA6541D
8A-CLC-608-010 C-IC,LC877248A-5R02
87-070-127-110 IC,LC72131 D
87-A20-913-010 IC,LA1837NL
87-A21-482-010 IC,RPM6938-H4
TRANSISTOR
89-213-703-010 TR,2SB1370F
87-026-610-080 TR,KTC3198GR
89-406-555-080 TR,2SD655 (0.5W)
89-109-521-080 TR,2SA952 (0.6W)
89-109-332-380 TR,2SA933RS
89-113-187-080 TR,2SA1318TU
87-026-239-080 TR,DTC114TK (0.2W)
87-026-213-080 CHIP-TR,DTC114YK
89-112-965-080 TR,2SA1296 (0.75W)
87-026-291-080 TR,DTC124XS
87-026-263-080 C-TR,RN1410
87-026-237-080 CHIP-TR,DTC124XK
89-320-011-080 TR,2SC2001 (15W)
87-A30-072-080 C-TR,RT1P 144C
87-026-215-080 TR,DTC114YS
89-327-143-080 TR,2SC2714 (0.1W)
89-505-434-540 C-FET,2SK543(4/5)
<EXCEPT HRJS,HRD,HRL,HCL>
87-A30-086-070 C-TR,CSD1306E
<EXCEPT HRJS,HRD,HRL,HCL>
87-A30-074-080 C-TR,RT1P 141C
<EXCEPT HRJS,HRD,HRL,HCL>
DIODE
87-070-178-090 DIODE,1N5402-BD54
87-020-465-080 DIODE,1SS133 (110MA)
87-017-092-080 ZENER,HZS5C2
87-A40-189-080 DIODE,1SR139-400
87-070-345-080 DIODE,IN4148
87-017-149-080 ZENER,HZS6A2L
87-A40-270-080 C-DIODE,MC2838
<EXCEPT HRJS,HRD,HRL,HCL>
MAIN C.B
C109 87-016-440-090 CAP,E 4700-35V SME
C111 87-010-196-080 CHIP CAPACITOR,0.1-25
C112 87-010-401-080 CAP, ELECT 1-50V
C113 87-010-401-080 CAP, ELECT 1-50V
C114 87-010-101-080 CAP, ELECT 220-16
C115 87-010-101-080 CAP, ELECT 220-16
C117 87-010-403-080 CAP, ELECT 3.3-50V
C118 87-010-101-080 CAP, ELECT 220-16
C119 87-010-196-080 CHIP CAPACITOR,0.1-25
C120 87-010-263-080 CAP, ELECT 100-10V
C201 87-010-248-080 CAP, ELECT 220-10V
C203 87-010-248-080 CAP, ELECT 220-10V
C204 87-010-197-080 CAP, CHIP 0.01 DM
C207 87-010-196-080 C-CAP,S 0.1-25 F
<EXCEPT HRJS,HRD,HRL,HCL>
C208 87-010-196-080 C-CAP,S 0.1-25 F
<EXCEPT HRJS,HRD,HRL,HCL>
C213 87-010-196-080 CHIP CAPACITOR,0.1-25
C214 87-010-196-080 CHIP CAPACITOR,0.1-25
C223 87-A11-126-080 CAP,TC U 3300P-50 K B
<HRJS,HRD,HRL,HCL>
C224 87-A11-126-080 CAP,TC U 3300P-50 K B
<HRJS,HRD,HRL,HCL>
C225 87-010-401-080 CAP, ELECT 1-50V
C226 87-010-401-080 CAP, ELECT 1-50V
C227 87-018-208-080 CAP 0.047-50F
C228 87-018-208-080 CAP 0.047-50F
C229 87-018-132-080 CAP, CER 2200P-16V
C230 87-018-132-080 CAP, CER 2200P-16V
C231 87-010-406-080 CAP, ELECT 22-50
C232 87-010-406-080 CAP, ELECT 22-50
C233 87-010-260-080 CAP, ELECT 47-25V
C234 87-010-404-080 CAP, ELECT 4.7-50V
C235 87-010-112-080 CAP, ELECT 100-16V
C236 87-010-112-080 CAP, ELECT 100-16V
C237 87-010-237-080 CAP, ELECT 1000-16V
C238 87-010-237-080 CAP, ELECT 1000-16V
C241 87-018-209-080 CAP, CER 0.1-50V
C243 87-010-387-080 CAP,E 470-25 SME
C244 87-010-248-080 CAP, ELECT 220-10V
C247 87-010-318-080 C-CAP,S 47P-50 CH
<EXCEPT HRJS,HRD,HRL,HCL>
C248 87-010-318-080 C-CAP,S 47P-50 CH
<EXCEPT HRJS,HRD,HRL,HCL>
C250 87-010-401-080 CAP, ELECT 1-50V
C251 87-010-401-080 CAP, ELECT 1-50V
C255 87-010-401-080 CAP, ELECT 1-50V
C256 87-010-401-080 CAP, ELECT 1-50V
C257 87-010-401-080 CAP, ELECT 1-50V
C258 87-010-401-080 CAP, ELECT 1-50V
C259 87-010-401-080 CAP, ELECT 1-50V
C260 87-010-401-080 CAP, ELECT 1-50V
C270 87-010-322-080 C-CAP,S 100P-50 CH
C271 87-010-322-080 C-CAP,S 100P-50 CH
C301 87-010-322-080 C-CAP,S 100P-50 CH
C302 87-010-401-080 CAP, ELECT 1-50V
C305 87-010-374-080 CAP, ELECT 47-10V
C307 87-010-405-080 CAP, ELECT 10-50V
C308 87-010-248-080 CAP, ELECT 220-10V
C309 87-010-405-080 CAP, ELECT 10-50V
C310 87-010-322-080 C-CAP,S 100P-50 CH
C312 87-010-374-080 CAP, ELECT 47-10V
C313 87-010-401-080 CAP, ELECT 1-50V
C315 87-010-426-080 C-CAP,S 0.012-25 B
C318 87-010-426-080 C-CAP,S 0.012-25 B
C319 87-A11-098-080 CAP,270PF-50 CH
C320 87-010-197-080 CAP, CHIP 0.01 DM
C322 87-010-248-080 CAP, ELECT 220-10V
C324 87-010-186-080 CAP,CHIP 4700P
C327 87-010-405-080 CAP, ELECT 10-50V
C328 87-010-405-080 CAP, ELECT 10-50V
C329 87-010-178-080 CHIP CAP 1000P
C330 87-010-178-080 CHIP CAP 1000P
C331 87-010-178-080 CHIP CAP 1000P
C332 87-010-263-080 CAP, ELECT 100-10V
C334 87-010-401-080 CAP, ELECT 1-50V
C335 87-010-260-080 CAP, ELECT 47-25V
C341 87-010-197-080 CAP, CHIP 0.01 DM
C701 87-010-381-080 CAP, ELECT 330-16V
C702 87-010-404-080 CAP, ELECT 4.7-50V
C703 87-012-286-080 CAP, U 0.01-25
C704 87-012-286-080 CAP, U 0.01-25
C705 87-A10-592-080 C-CAP,S 0.015-50 J B
<HRJS,HRD,HRL,HCL>
C706 87-A10-592-080 C-CAP,S 0.015-50 J B
<HRJS,HRD,HRL,HCL>
C709 87-012-195-080 C-CAP,U 100P-50CH
C711 87-010-260-080 CAP, ELECT 47-25V

6
REF. NO PART NO. KANRI DESCRIPTION
NO.
REF. NO PART NO. KANRI DESCRIPTION
NO.
C712 87-010-831-080 C-CAP,U,0.1-16F
C714 87-012-286-080 CAP, U 0.01-25
C715 87-012-195-080 C-CAP,U 100P-50CH
<EXCEPT HRJS,HRD,HRL,HCL>
C717 87-012-286-080 CAP, U 0.01-25
C719 87-012-286-080 CAP, U 0.01-25
C720 87-012-195-080 C-CAP,U 100P-50CH
C721 87-012-176-080 CAP 15P
C722 87-012-176-080 CAP 15P
C723 87-018-131-080 CAP, CER 1000P-50V
C725 87-018-131-080 CAP, CER 1000P-50V
C727 87-010-196-080 CHIP CAPACITOR,0.1-25
C728 87-010-248-080 CAP, ELECT 220-10V
C729 87-012-274-080 CHIP CAP,U 1000P-50B
C731 87-012-286-080 CAP, U 0.01-25
C733 87-010-987-080 C-CAP,S 1500P-50 CH
<HRJS,HRD,HRL,HCL>
C733 87-012-280-080 CAP, U 3300P-50
<EXCEPT HRJS,HRD,HRL,HCL>
C734 87-010-987-080 C-CAP,S 1500P-50 CH
<HRJS,HRD,HRL,HCL>
C734 87-012-280-080 CAP, U 3300P-50
<EXCEPT HRJS,HRD,HRL,HCL>
C735 87-A10-592-080 C-CAP,S 0.015-50 J B
<HRJS,HRD,HRL,HCL>
C736 87-A10-592-080 C-CAP,S 0.015-50 J B
<HRJS,HRD,HRL,HCL>
C737 87-010-987-080 C-CAP,S 1500P-50 CH
<HRJS,HRD,HRL,HCL>
C738 87-010-987-080 C-CAP,S 1500P-50 CH
<HRJS,HRD,HRL,HCL>
C751 87-010-220-080 C-CAP,S 0.018-25 B
<HRJS,HRD,HRL,HCL>
C752 87-010-220-080 C-CAP,S 0.018-25 B
<HRJS,HRD,HRL,HCL>
C752 87-012-282-080 CAP, U 4700P-50
<EXCEPT HRJS,HRD,HRL,HCL>
C753 87-012-195-080 C-CAP,U 100P-50CH
<EXCEPT HRJS,HRD,HRL,HCL>
C755 87-012-286-080 CAP, U 0.01-25
<EXCEPT HRJS,HRD,HRL,HCL>
C756 87-012-286-080 CAP, U 0.01-25
C757 87-012-188-080 C-CAP,U 47P-50 CH
C758 87-012-167-080 C-CAP,U 5P-50 CH
C761 87-010-196-080 CHIP CAPACITOR,0.1-25
<EXCEPT HRJS,HRD,HRL,HCL>
C762 87-012-286-080 CAP, U 0.01-25
<EXCEPT HRJS,HRD,HRL,HCL>
C763 87-010-829-080 CAP, U 0.047-16
C764 87-012-337-080 C-CAP,U 56P-50 CH
<HRJS,HRD,HRL,HCL>
C765 87-012-286-080 CAP, U 0.01-25
C766 87-010-197-080 CAP, CHIP 0.01 DM
<EXCEPT HRJS,HRD,HRL,HCL>
C766 87-010-197-080 CAP, CHIP 0.01 DM
<EXCEPT HRJS,HRD,HRL,HCL>
C768 87-012-286-080 CAP, U 0.01-25
C769 87-010-260-080 CAP, ELECT 47-25V
C770 87-010-829-080 CAP, U 0.047-16
C771 87-010-383-080 CAP, ELECT 33-25V
C772 87-010-829-080 CAP, U 0.047-16
C773 87-010-196-080 CHIP CAPACITOR,0.1-25
C774 87-010-263-080 CAP, ELECT 100-10V
C775 87-010-404-080 CAP, ELECT 4.7-50V
C776 87-012-286-080 CAP, U 0.01-25
C777 87-010-400-080 CAP, ELECT 0.47-50V
<HRJS,HRD,HRL,HCL>
C777 87-010-493-080 CAP,E 0.47-50 GAS
<EXCEPT HRJS,HRD,HRL,HCL>
C778 87-010-401-080 CAP, ELECT 1-50V
C779 87-010-401-080 CAP, ELECT 1-50V
C779 87-010-829-080 CAP, U 0.047-16
C780 87-010-196-080 CHIP CAPACITOR,0.1-25
C781 87-010-405-080 CAP, ELECT 10-50V
C782 87-010-405-080 CAP, ELECT 10-50V
C783 87-012-286-080 CAP, U 0.01-25
C784 87-012-286-080 CAP, U 0.01-25
C785 87-010-402-080 CAP, ELECT 2.2-50V
<EXCEPT HRJS,HRD,HRL,HCL>
C785 87-016-279-080 CAP,E 1-50 BP<HRJS,HRD,HRL,HCL>
C786 87-010-402-080 CAP, ELECT 2.2-50V
<EXCEPT HRJS,HRD,HRL,HCL>
C786 87-016-279-080 CAP,E 1-50 BP<HRJS,HRD,HRL,HCL>
C787 87-012-275-080 C-CAP,U 1200P-50 B
<EXCEPT HRJS,HRD,HRL,HCL>
C788 87-012-275-080 C-CAP,U 1200P-50 B
<EXCEPT HRJS,HRD,HRL,HCL>
C789 87-012-275-080 C-CAP,U 1200P-50 B
C790 87-012-275-080 C-CAP,U 1200P-50 B
C791 87-010-405-080 CAP, ELECT 10-50V
C793 87-012-273-080 C-CAP,U 820P-50 B
C794 87-010-406-080 CAP, ELECT 22-50
C795 87-010-596-080 CAP, S 0.047-16
C796 87-010-403-080 CAP, ELECT 3.3-50V
C797 87-012-276-080 CAP, CHIP SS 1500 PBK
<EXCEPT HRJS,HRD,HRL,HCL>
C798 87-012-276-080 CAP, CHIP SS 1500 PBK
<EXCEPT HRJS,HRD,HRL,HCL>
C812 87-012-286-080 CAP, U 0.01-25
C814 87-012-286-080 CAP, U 0.01-25
<EXCEPT HRJS,HRD,HRL,HCL>
C820 87-010-260-080 CAP, ELECT 47-25V
C821 87-012-286-080 CAP, U 0.01-25
C822 87-012-286-080 CAP, U 0.01-25
C823 87-012-286-080 CAP, U 0.01-25
C828 87-010-196-080 CHIP CAPACITOR,0.1-25
C829 87-010-196-080 CHIP CAPACITOR,0.1-25
C830 87-010-406-080 CAP, ELECT 22-50
<EXCEPT HRJS,HRD,HRL,HCL>
C940 87-012-286-080 CAP, U 0.01-25
<EXCEPT HRJS,HRD,HRL,HCL>
C942 87-012-168-080 C-CAP,U 6P-50 CH
<EXCEPT HRJS,HRD,HRL,HCL>
C947 87-012-286-080 CAP, U 0.01-25
<EXCEPT HRJS,HRD,HRL,HCL>
C949 87-A10-039-080 C-CAP,U 470P-50 J CH
<EXCEPT HRJS,HRD,HRL,HCL>
C952 87-012-286-080 CAP, U 0.01-25
<EXCEPT HRJS,HRD,HRL,HCL>
C958 87-010-197-080 CAP, CHIP 0.01 DM
<EXCEPT HRJS,HRD,HRL,HCL>
C959 87-010-831-080 C-CAP,U,0.1-16F<HRJS,HRD,HRL,HCL>
C960 87-010-196-080 CHIP CAPACITOR,0.1-25
C961 87-012-174-080 C-CAP,U 12P-50 J CH
<HRJS,HRD,HRL,HCL>
C962 87-010-401-080 CAP, ELECT 1-50V
<EXCEPT HRJS,HRD,HRL,HCL>
C963 87-010-196-080 CHIP CAPACITOR,0.1-25
<HRJS,HRD,HRL,HCL>
CF801 87-008-423-010 CERAMIC FILTER, SFE10.7
<EXCEPT HRJS,HRD,HRL,HCL>
CF801 87-008-261-010 FILTER, SFE10.7MA5-A
<HRJS,HRD,HRL,HCL>
CF802 82-785-747-010 CF MS2 GHY R
<EXCEPT HRJS,HRD,HRL,HCL>
CF802 87-008-261-010 FILTER, SFE10.7MA5-A
<HRJS,HRD,HRL,HCL>
CN101 87-049-919-010 CONN,3P EH V WHT
CN201 87-099-719-010 CONN,30P TYK-B(X)
CN203 87-A60-060-010 CONN,07P V 9604S-07C
CN301 87-A60-627-010 CONN,10P V 2MM JMT
FB202 87-008-372-080 FILTER,EMI BL OIRNI
<EXCEPT HRJS,HRD,HRL,HCL>
FB203 87-008-372-080 FILTER,EMI BL OIRNI
<EXCEPT HRJS,HRD,HRL,HCL>
FB701 87-008-372-080 FILTER, EMI BL OIRNI

87
REF. NO PART NO. KANRI DESCRIPTION
NO.
REF. NO PART NO. KANRI DESCRIPTION
NO.
FFE801 A8-6ZA-19C-170 6ZA-1 YFEENC
<EXCEPT HRJS,HRD,HRL,HCL>
FFE801 A8-8ZA-193-070 8ZA-1 YFEUNC<HRJS,HRD,HRL,HCL>
! ICP203 87-001-132-080 ICP-N38
J201 87-A60-420-010 JACK,3.5 ST (MSC)
J202 87-A60-754-010 TERMINAL,SPK 4P MSP-154V-05
J203 87-A60-881-010 JACK,PIN 2P MSP 242V05 PBSN
J204 87-099-801-010 JACK,PIN 1P BLK
J801 87-A60-202-010 TERMINAL,ANT 4P MSP-154V-02
<HRJS,HRD,HRL,HCL>
J801 87-033-241-010 TERMINAL,ANT AJ-2039
<EXCEPT HRJS,HRD,HRL,HCL>
L204 87-005-239-080 COIL,100UH
L205 87-005-239-080 COIL,100UH
L301 87-007-342-010 COIL,OSC 85K BIAS
L771 87-A50-266-010 COIL,FM DET-2N(TOK)
L772 87-A91-110-010 FLTR,PCFJZH-450 (TOK)
L781 87-005-847-080 COIL,2.2UH(CECS)
<EXCEPT HRJS,HRD,HRL,HCL>
L832 87-005-847-080 COIL,2.2UH(CECS)
<EXCEPT HRJS,HRD,HRL,HCL>
L941 87-A50-020-010 COIL,ANT LW(COI)
<EXCEPT HRJS,HRD,HRL,HCL>
L942 87-A50-019-010 COIL,OSC LW(COI)
<EXCEPT HRJS,HRD,HRL,HCL>
L981 8Z-ZA1-665-010 COIL,AM PACK 2(TOK)
<EXCEPT HRJS,HRD,HRL,HCL>
L981 8Z-ZA1-667-010 COIL,AM PACK 4F(TOK)
<HRJS,HRD,HRL,HCL>
R251 87-029-124-010 RES,FUSE 2.2-1/4
R252 87-029-124-010 RES,FUSE 2.2-1/4
S301 8Z-CL8-668-010 SW,RP ZCL8
TC942 87-011-253-080 TRIMER,30P LAR
<EXCEPT HRJS,HRD,HRL,HCL>
X721 87-A70-061-010 VIB,XTAL 4.500MHZ CSA-309
MICON C.B
C601 87-010-196-080 CHIP CAPACITOR,0.1-25
C602 87-010-248-080 CAP, ELECT 220-10V
C606 87-010-178-080 CHIP CAP 1000P
C607 87-010-317-080 C-CAP,S 39P-50 CH
C608 87-010-312-080 C-CAP,S 15P-50 CH
C609 87-010-315-080 C-CAP,S 27P-50 CH
C610 87-010-452-080 CAPACITOR,1-16
C613 87-010-196-080 CHIP CAPACITOR,0.1-25
C614 87-010-196-080 CHIP CAPACITOR,0.1-25
C618 87-012-156-080 C-CAP,S 220P-50 CH
C619 87-010-196-080 CHIP CAPACITOR,0.1-25
C621 87-010-196-080 CHIP CAPACITOR,0.1-25
C622 87-010-401-080 CAP, ELECT 1-50V
C641 87-010-248-080 CAP, ELECT 220-10V
CN601 87-099-720-010 CONN,30P TYK-B(P)
CN602 87-A60-059-010 CONN,08P V 9604S-08C
CN604 87-A60-060-010 CONN,07P V 9604S-07C
L601 87-003-098-080 COIL,2.2UH
L603 87-003-098-080 COIL,2.2UH
LCD601 8A-CJB-630-010 LCD,AIW4214-30P1N ACJ-11
X601 87-030-376-080 VIB,CER CSA5.76MG200
CD C.B
C401 87-010-403-080 CAP, ELECT 3.3-50V
C402 87-010-197-080 CAP, CHIP 0.01 DM
C403 87-010-263-080 CAP, ELECT 100-10V
C404 87-010-248-080 CAP, ELECT 220-10V
C405 87-010-197-080 CAP, CHIP 0.01 DM
C406 87-010-374-080 CAP, ELECT 47-10V
C407 87-010-178-080 CHIP CAP 1000P
C408 87-010-198-080 CAP, CHIP 0.022
C409 87-010-248-080 CAP, ELECT 220-10V
C410 87-010-263-080 CAP, ELECT 100-10V
C411 87-A11-177-080 C-CAP,S 0.15-16 K B
C412 87-010-401-080 CAP, ELECT 1-50V
C413 87-016-369-080 C-CAP,S 0.033-25 B K
C414 87-010-405-080 CAP, ELECT 10-50V
C416 87-010-545-080 CAP, ELECT 0.22-50V
C417 87-012-157-080 C-CAP,S 330P-50 CH
C418 87-010-213-080 C-CAP,S 0.015-50 B
C419 87-A10-201-080 C-CAP,S0.33-16 KB
C420 87-016-369-080 C-CAP,S 0.033-25 B K
C421 87-A11-177-080 C-CAP,S 0.15-16 K B
C422 87-010-184-080 CHIP CAPACITOR 3300P(K)
C423 87-010-992-080 C-CAP,S 0.047-25 B
C424 87-016-460-080 C-CAP,S 0.22-16 B
C425 87-010-176-080 C-CAP,S 680P-50 SL
C426 87-A10-201-080 C-CAP,S0.33-16 KB
C428 87-010-197-080 CAP, CHIP 0.01 DM
C429 87-010-186-080 CAP,CHIP 4700P
C430 87-012-156-080 C-CAP,S 220P-50 CH
C431 87-010-545-080 CAP, ELECT 0.22-50V
C432 87-010-374-080 CAP, ELECT 47-10V
C433 87-010-401-080 CAP, ELECT 1-50V
C434 87-010-184-080 CHIP CAPACITOR 3300P(K)
C435 87-010-197-080 CAP, CHIP 0.01 DM
C436 87-010-374-080 CAP, ELECT 47-10V
C437 87-010-404-080 CAP, ELECT 4.7-50V
C438 87-016-669-080 C-CAP,S 0.1-25 K B
C439 87-010-178-080 CHIP CAP 1000P
C440 87-010-145-080 C-CAP,S 1P-50 CH
C441 87-010-197-080 CAP, CHIP 0.01 DM
C442 87-010-313-080 CAP, CHIP 18P
C445 87-010-196-080 CHIP CAPACITOR,0.1-25
C446 87-010-196-080 CHIP CAPACITOR,0.1-25
C447 87-010-196-080 CHIP CAPACITOR,0.1-25
C448 87-010-315-080 C-CAP,S 27P-50 CH
C450 87-012-140-080 CAP 470P
C451 87-012-156-080 C-CAP,S 220P-50 CH
C455 87-010-247-080 CAP, ELECT 100-50V
C457 87-010-316-080 C-CAP,S 33P-50 CH
C458 87-010-316-080 C-CAP,S 33P-50 CH
C459 87-010-263-080 CAP, ELECT 100-10V
C460 87-015-819-080 CAPACITOR,0.01
C461 87-010-197-080 CAP, CHIP 0.01 DM
C462 87-010-221-080 CAP, ELECT 470-10V
C463 87-A11-144-080 CAP,TC U 0.1-50 K B
C465 87-010-404-080 CAP, ELECT 4.7-50V
C466 87-010-196-080 CHIP CAPACITOR,0.1-25
C467 87-010-263-080 CAP, ELECT 100-10V
C469 87-012-154-080 C-CAP,S 150P-50 CH
C470 87-010-544-080 CAP, ELECT 0.1-50V
C471 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z
C472 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z
C473 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z
C474 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z
C475 87-010-197-080 CAP, CHIP 0.01 DM
C476 87-010-236-080 CAP,E 1000-10 SME
C477 87-010-197-080 CAP, CHIP 0.01 DM
C478 87-010-265-080 CAP, ELECT 33-16V
C479 87-010-197-080 CAP, CHIP 0.01 DM
C480 87-010-221-080 CAP, ELECT 470-10V
C481 87-010-405-080 CAP, ELECT 10-50V
C482 87-010-405-080 CAP, ELECT 10-50V
C489 87-010-196-080 CHIP CAPACITOR,0.1-25
C490 87-010-196-080 CHIP CAPACITOR,0.1-25
C491 87-010-197-080 CAP, CHIP 0.01 DM
C492 87-010-221-080 CAP, ELECT 470-10V
C494 87-A11-144-080 CAP,TC U 0.1-50 K B
C501 87-010-196-080 CHIP CAPACITOR,0.1-25
C502 87-010-322-080 C-CAP,S 100P-50 CH
C503 87-010-322-080 C-CAP,S 100P-50 CH
C504 87-010-322-080 C-CAP,S 100P-50 CH
REF. NO PART NO. KANRI DESCRIPTION
NO.
REF. NO PART NO. KANRI DESCRIPTION
NO.
C505 87-010-322-080 C-CAP,S 100P-50 CH
C506 87-010-322-080 C-CAP,S 100P-50 CH
C510 87-016-669-080 C-CAP,S 0.1-25 K B
CN401 87-A60-424-010 CONN,16P V TOC-B
CN403 87-A60-079-010 CONN,08P H 9604S-08F
CN405 87-A60-060-010 CONN,07P V 9604S-07C
CN406 87-A60-619-010 CONN,2P V 2MM JMT
CNA402 8A-CJB-623-010 CONN ASSY,6P CD MOTOR
L401 87-003-102-080 COIL, 10UH
L402 87-005-847-080 COIL,2.2UH(CECS)
L404 87-003-152-080 COIL, 100UH
L450 87-005-847-080 COIL,2.2UH(CECS)
SFR430 87-024-437-080 SFR100K,RH063EC
X401 87-A70-046-010 VIB,XTAL 16.934MHZ
KEY C.B
C901 87-010-196-080 CHIP CAPACITOR,0.1-25
C902 87-010-196-080 CHIP CAPACITOR,0.1-25
C903 87-010-197-080 CAP, CHIP 0.01 DM
C904 87-010-197-080 CAP, CHIP 0.01 DM
C905 87-010-405-080 CAP, ELECT 10-50V
C906 87-010-178-080 CHIP CAP 1000P
CN901 87-A60-080-010 CONN,07P H 9604S-07F
S901 87-A91-024-180 SW,TACT KSH0611BT
S902 87-A91-024-180 SW,TACT KSH0611BT
S904 87-A91-024-180 SW,TACT KSH0611BT
S905 87-A91-024-180 SW,TACT KSH0611BT
S906 87-A91-024-180 SW,TACT KSH0611BT
S907 87-A91-024-180 SW,TACT KSH0611BT
S908 87-A91-024-180 SW,TACT KSH0611BT
S909 87-A91-024-180 SW,TACT KSH0611BT
S910 87-A91-024-180 SW,TACT KSH0611BT
S911 87-A91-024-180 SW,TACT KSH0611BT
S913 87-A91-024-180 SW,TACT KSH0611BT
S915 87-A91-024-180 SW,TACT KSH0611BT
S916 87-A91-024-180 SW,TACT KSH0611BT
S917 87-A91-024-180 SW,TACT KSH0611BT
S920 87-A91-385-010 SW,RTRY EC12E12504-15MM
LED C.B
CN606 87-A61-297-010 CONN,5P TKX-P05P-A1
D621 87-A40-821-080 LED,SMLS1BE16C BLU/UMB
D622 87-A40-821-080 LED,SMLS1BE16C BLU/UMB
PT C.B
C100 87-010-398-010 CAP ELECT 2200
C101 87-010-198-080 CAP, CHIP 0.022
C102 87-010-198-080 CAP, CHIP 0.022
C103 87-010-198-080 CAP, CHIP 0.022
C104 87-010-198-080 CAP, CHIP 0.022
CNA101 8A-CLC-610-010 CONN ASSY,3P POWER
! F101 87-035-367-010 FUSE, 3.15A 250V
FC101 87-A90-505-080 FUSE CLAMP,TP00351-51
FC102 87-A90-505-080 FUSE CLAMP,TP00351-51
! PT101 8A-CLC-611-010 PT,ACL-12 E
<EXCEPT HRJS,HRD,HRL,HCL>
! PT101 8A-CLC-609-010 PT,ACL-12 H<HRJS,HRD,HRL,HCL>
S101 87-A90-234-010 SW,SL 1-2-2 SW2201
<HRJS,HRD,HRL,HCL>
! T1 87-A60-317-010 TERMINAL, 1P MSC
! T2 87-A60-317-010 TERMINAL, 1P MSC
MOTOR C.B
M2 9X-262-576-910 MOTOR GEAR ASSY
PIN3 91-564-722-110 CONNECTOR 6P
SW1 91-572-085-120 LEAF SW
• Regarding connectors, they are not stocked as they are not the initial order items.
The connectors are available after they are supplied from connector manufacturers upon the order is received.
88
A
Resistor Code
Chip Resistor Part Coding
Figure
Value of resistor
Chip resistor
Wattage Type Tolerance
1/16W
1/10W
1/8W
1608
2125
3216
5%
5%
5%
CJ
CJ
CJ
Form LW t
1.6 0.8 0.45
2 1.25 0.45
3.2 1.6
108
118
128
: A
: A
CHIP RESISTOR PART CODE
0.55
Resistor Code
Dimensions (mm)
Symbol
1/16W 1005 5% CJ 1.0 0.5 0.35 104
Lt
W

123456789
10 11 12 13 14
A
B
C
D
E
F
G
H
I
J
K
109
WIRING-1 (MAIN: HC, HR)

123456789
10 11 12 13 14
A
B
C
D
E
F
G
H
I
J
K
1211
WIRING-2 (MAIN: HS, K, EZ )

1413
SCHEMATIC DIAGRAM-1 (MAIN 1/2)
TAPE DECK
(TN-21ZSC-2003)
K,EZ
HS
K,EZ,HS
(HC, HR)
HC, HR
K, EZ, HS 3300p
nm
C223, 224
S101
AC VOLTAGE
230V
50Hz
(K,EZ)
220V
60Hz
(HS)
K, EZ, HS MODELS
HC, HR MODELS
L202
JW
J203
JW
