S E R V I C E M A N U A L
SIMPLE MANUAL
•Replace this Service Manual with ”Revision Publishing” when it is issued.
NSX-K580
• TYPE: HR
COMPACT DISC STEREO SYSTEM
• BASIC TAPE MECHANISM:2ZM-3MK2 PR4NM
• BASIC CD MECHANISM:4ZG-1 VOS1RDSHM
S/M Code No. 09–98C–406–6T1
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
ELECTRICALPARTSLIST-1/7
HRJ8STM ................XX..................................A...................
HRJSTM .................XX...................................B..................
HRJ7STM ................XX....................................C.................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
C 503 87-010-112-040 CAP,E 100-16 ABC.................
C 502 87-010-186-080 CAP,CHIP 4700P ABC.................
C 506 87-010-320-080 CHIP CAP 68P ABC.................
C 504 87-010-405-040 CAP,E 10-50 ABC.................
C 505 87-010-546-040 CAP,E 0.33-50 ABC.................
J 501 87-A60-651-010 JACK,3.5MONO ABC.................
Q 504 87-A30-075-080 C-TR,2SA1235F ABC.................
Q 503 87-A30-076-080 C-TR,2SC3052F ABC.................
Q 502 87-A30-076-080 C-TR,2SC3052F ABC.................
Q 501 87-A30-087-080 C-FET,2SK2158 ABC.................
C 1 87-010-387-080 CAP,E 470-25 SME ABC.................
C 8 87-A10-520-090 CAP,E 3300-35 M SMG ABC.................
C 9 87-A10-520-090 CAP,E 3300-35 M SMG ABC.................
C 6 87-A11-148-080 CAP,TC U 0.1-50 Z F ABC.................
C 4 87-A11-148-080 CAP,TC U 0.1-50 Z F ABC.................
C 5 87-A11-148-080 CAP,TC U 0.1-50 Z F ABC.................
C 3 87-A11-148-080 CAP,TC U 0.1-50 Z F ABC.................
C 31 87-010-403-080 CAP, ELECT 3.3-50V ABC.................
CN 1 87-A60-851-010 CONN,9P V VH ABC.................
D 6 87-017-447-010 DIODE,GBU4DL ABC.................
D 3 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 2 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 4 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 5 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 1 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 31 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 32 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
PT 2 8Z-NF8-663-010 PT,SUB ZNF-8(H) ABC.................
Q 31 87-026-245-080 TR,DTC114ES ABC.................
Q 32 87-A30-198-080 TR,KTC3199GR ABC.................
RY 1 87-A91-281-010 RELAY,AC DC12V OSA-SS-212DM5 ABC.................
S 1 87-A90-165-010 SW,SL 1-2-3 SWS2301 ABC.................
T 2 87-A60-317-010 TERMINAL, 1P MSC ABC.................
T 1 87-A60-317-010 TERMINAL, 1P MSC ABC.................
8Z-NF8-201-010 GUIDE,OPE ABC.................
8Z-NF8-202-010 GUIDE,FUN ABC.................
C 205 87-010-322-080 C-CAP,S 100P-50 CH ABC.................
C 202 87-010-322-080 C-CAP,S 100P-50 CH ABC.................
C 203 87-010-322-080 C-CAP,S 100P-50 CH ABC.................
C 207 87-010-322-080 C-CAP,S 100P-50 CH ABC.................
C 208 87-010-322-080 C-CAP,S 100P-50 CH ABC.................
C 204 87-010-322-080 C-CAP,S 100P-50 CH ABC.................
C 209 87-010-322-080 C-CAP,S 100P-50 CH ABC.................
C 206 87-010-322-080 C-CAP,S 100P-50 CH ABC.................
C 201 87-012-156-080 C-CAP,S 220P-50 CH ABC.................
C 211 87-010-322-080 C-CAP,S 100P-50 CH ABC.................
C 210 87-010-322-080 C-CAP,S 100P-50 CH ABC.................
C 254 87-010-194-080 CAP, CHIP 0.047 ABC.................
C 252 87-010-198-080 CAP, CHIP 0.022 ABC.................
C 259 87-015-699-040 CAP,E 10-50 7L ABC.................
C 256 87-015-699-040 CAP,E 10-50 7L ABC.................
C 251 87-015-699-040 CAP,E 10-50 7L ABC.................
C 255 87-A10-797-040 CAP,E 47-35 M 5L SRM ABC.................
C 262 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................
C 260 87-010-198-080 CAP, CHIP 0.022 ABC.................
C 301 87-010-182-080 C-CAP,S 2200P-50 B ABC.................
C 302 87-010-182-080 C-CAP,S 2200P-50 B ABC.................
C 311 87-010-194-080 CAP, CHIP 0.047 ABC.................
C 314 87-010-194-080 CAP, CHIP 0.047 ABC.................
C 313 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................
C 312 87-010-405-040 CAP,E 10-50 ABC.................
C 324 87-010-194-080 CAP, CHIP 0.047 ABC.................
C 321 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................
C 325 87-010-263-040 CAP,E 100-10 ABC.................
C 322 87-015-694-040 E/CAP 0.47-50 ABC.................
C 323 87-016-459-040 CAP,E 470-10 SMG ABC.................
C 332 87-010-178-080 CHIP CAP 1000P ABC.................
C 336 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................
C 337 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................
C 331 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................
C 334 87-010-312-080 C-CAP,S 15P-50 CH ABC.................
C 335 87-012-140-080 CAP 470P ABC.................
C 333 87-012-140-080 CAP 470P ABC.................
C 338 87-012-155-080 C-CAP 180P-50CH ABC.................
C 339 87-012-156-080 C-CAP,S 220P-50 CH ABC.................
C 341 87-010-194-080 CAP, CHIP 0.047 ABC.................
C 340 87-010-197-080 CAP, CHIP 0.01 DM ABC.................
C 351 87-010-382-040 CAP,E 22-25 SME ABC.................
C 401 87-010-197-080 CAP, CHIP 0.01 DM ABC.................
C 457 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................
C 453 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................
C 451 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................
C 455 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................
C 452 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................
C 454 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................
NOTE: The characters in the suffix column indicate the part usage.
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
ELECTRICALPARTSLIST-2/7
C 456 87-012-158-080 C-CAP,S 390P-50 CH ABC.................
C 601 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................
C 602 87-010-322-080 C-CAP,S 100P-50 CH ABC.................
C 603 87-010-322-080 C-CAP,S 100P-50 CH ABC.................
C 604 87-010-322-080 C-CAP,S 100P-50 CH ABC.................
C 701 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................
CON 102 87-099-015-010 CONN,13P 6216V ABC.................
CON 101 88-NF9-658-010 CONN,30P BLK TYK-B(P) ABC.................
CON 301 87-099-017-010 CONN, 15P 6216 V ABC.................
D 203 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 207 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 209 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 208 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 214 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 213 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 215 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 212 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 216 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 218 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 217 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 219 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 220 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 227 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 226 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 224 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 225 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 222 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 221 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 223 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 253 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 252 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 251 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 311 87-A40-509-080 ZENER,MTZJ6.8C ABC.................
D 324 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 321 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 323 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 332 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 335 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 334 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 331 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 333 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 336 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 351 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 352 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 452 87-017-932-080 ZENER,MTJ6.2B ABC.................
D 451 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
EMI 201 87-008-372-080 FILTER, EMI BL OIRNI ABC.................
EMI 202 87-A50-322-080 C-COIL,S BK2125 LM252 ABC.................
EMI 701 87-A50-322-080 C-COIL,S BK2125 LM252 ABC.................
FL 401 8Z-NH8-603-010 FL,BJ674GNK ABC.................
IC 201 8Z-NH8-602-010 C-IC,UPD780228GF-XXX ABC.................
IC 251 87-A20-914-010 IC,SPS-442-1-F ABC.................
IC 451 87-A21-023-040 C-IC,BA3835F ABC.................
IC 601 87-A21-021-040 C-IC,BU2099FV ABC.................
L 331 87-A50-434-010 COIL,CLK 4.19M(TOKO) ABC.................
LED 311 87-A40-317-080 LED,SLR-342VCT31 RED ABC.................
LED 602 87-A40-619-040 LED,SLR-56PT-T31-W GRN ABC.................
LED 604 87-A40-619-040 LED,SLR-56PT-T31-W GRN ABC.................
LED 605 87-A40-619-040 LED,SLR-56PT-T31-W GRN ABC.................
LED 606 87-A40-619-040 LED,SLR-56PT-T31-W GRN ABC.................
LED 601 87-A40-619-040 LED,SLR-56PT-T31-W GRN ABC.................
LED 608 87-A40-619-040 LED,SLR-56PT-T31-W GRN ABC.................
LED 603 87-A40-619-040 LED,SLR-56PT-T31-W GRN ABC.................
LED 607 87-A40-619-040 LED,SLR-56PT-T31-W GRN ABC.................
LED 609 87-A40-619-080 LED,SLR-56PT-TE7-W GRN ABC.................
LED 614 87-A40-619-080 LED,SLR-56PT-TE7-W GRN ABC.................
LED 610 87-A40-619-080 LED,SLR-56PT-TE7-W GRN ABC.................
LED 612 87-A40-619-080 LED,SLR-56PT-TE7-W GRN ABC.................
LED 611 87-A40-619-080 LED,SLR-56PT-TE7-W GRN ABC.................
LED 613 87-A40-619-080 LED,SLR-56PT-TE7-W GRN ABC.................
LED 634 87-A40-619-040 LED,SLR-56PT-T31-W GRN ABC.................
LED 632 87-A40-619-040 LED,SLR-56PT-T31-W GRN ABC.................
LED 631 87-A40-619-040 LED,SLR-56PT-T31-W GRN ABC.................
LED 633 87-A40-619-040 LED,SLR-56PT-T31-W GRN ABC.................
Q 207 87-A30-087-080 C-FET,2SK2158 ABC.................
Q 251 87-A30-074-080 C-TR,RT1P 141C ABC.................
Q 302 87-A30-067-080 C-TR,2SA 1298Y ABC.................
Q 301 87-A30-067-080 C-TR,2SA 1298Y ABC.................
Q 303 87-A30-240-080 TR,CSA1585BC ABC.................
Q 311 87-026-610-080 TR,KTC3198GR ABC.................
Q 312 87-A30-087-080 C-FET,2SK2158 ABC.................
Q 322 87-A30-073-080 C-TR,RT1N 141C ABC.................
Q 323 87-A30-087-080 C-FET,2SK2158 ABC.................
S 401 87-A91-024-080 SW,TACT KSH0611BT ABC.................
S 408 87-A91-024-080 SW,TACT KSH0611BT ABC.................
S 409 87-A91-024-080 SW,TACT KSH0611BT ABC.................
S 405 87-A91-024-080 SW,TACT KSH0611BT ABC.................
S 406 87-A91-024-080 SW,TACT KSH0611BT ABC.................
S 403 87-A91-024-080 SW,TACT KSH0611BT ABC.................
S 407 87-A91-024-080 SW,TACT KSH0611BT ABC.................
S 404 87-A91-024-080 SW,TACT KSH0611BT ABC.................
S 402 87-A91-024-080 SW,TACT KSH0611BT ABC.................
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
ELECTRICALPARTSLIST-3/7
S 419 87-A91-024-080 SW,TACT KSH0611BT ABC.................
S 413 87-A91-024-080 SW,TACT KSH0611BT ABC.................
S 415 87-A91-024-080 SW,TACT KSH0611BT ABC.................
S 414 87-A91-024-080 SW,TACT KSH0611BT ABC.................
S 410 87-A91-024-080 SW,TACT KSH0611BT ABC.................
S 417 87-A91-024-080 SW,TACT KSH0611BT ABC.................
S 412 87-A91-024-080 SW,TACT KSH0611BT ABC.................
S 411 87-A91-024-080 SW,TACT KSH0611BT ABC.................
S 418 87-A91-024-080 SW,TACT KSH0611BT ABC.................
S 416 87-A91-024-080 SW,TACT KSH0611BT ABC.................
S 423 87-A91-024-080 SW,TACT KSH0611BT ABC.................
S 429 87-A91-024-080 SW,TACT KSH0611BT ABC.................
S 427 87-A91-024-080 SW,TACT KSH0611BT ABC.................
S 420 87-A91-024-080 SW,TACT KSH0611BT ABC.................
S 425 87-A91-024-080 SW,TACT KSH0611BT ABC.................
S 428 87-A91-024-080 SW,TACT KSH0611BT ABC.................
S 426 87-A91-024-080 SW,TACT KSH0611BT ABC.................
S 421 87-A91-024-080 SW,TACT KSH0611BT ABC.................
S 422 87-A91-024-080 SW,TACT KSH0611BT ABC.................
S 424 87-A91-024-080 SW,TACT KSH0611BT ABC.................
S 430 87-A91-024-080 SW,TACT KSH0611BT ABC.................
S 433 87-A91-024-080 SW,TACT KSH0611BT ABC.................
S 431 87-A91-024-080 SW,TACT KSH0611BT ABC.................
S 432 87-A91-024-080 SW,TACT KSH0611BT ABC.................
S 434 87-A91-024-080 SW,TACT KSH0611BT ABC.................
SW 252 87-A90-535-010 SW,RTRY EC16B24304 ABC.................
SW 253 87-A90-950-010 SW,RTRY EC12E12504 ENCORDER ABC.................
C 307 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................
C 309 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................
C 301 87-010-318-080 C-CAP,S 47P-50 CH ABC.................
C 302 87-010-318-080 C-CAP,S 47P-50 CH ABC.................
C 306 87-012-145-080 CAP, CHIP S 270P CH ABC.................
C 305 87-012-145-080 CAP, CHIP S 270P CH ABC.................
C 304 87-012-157-080 C-CAP,S 330P-50 CH ABC.................
C 303 87-012-157-080 C-CAP,S 330P-50 CH ABC.................
C 314 87-010-178-080 CHIP CAP 1000P ABC.................
C 315 87-010-178-080 CHIP CAP 1000P ABC.................
C 316 87-010-178-080 CHIP CAP 1000P ABC.................
C 313 87-010-178-080 CHIP CAP 1000P ABC.................
C 310 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................
C 311 87-010-198-080 CAP, CHIP 0.022 ABC.................
C 312 87-010-198-080 CAP, CHIP 0.022 ABC.................
C 324 87-010-260-080 CAP, ELECT 47-25V ABC.................
C 325 87-010-370-080 CAP,E 330-6.3 SME ABC.................
C 327 87-010-404-080 CAP, ELECT 4.7-50V ABC.................
C 328 87-010-404-080 CAP, ELECT 4.7-50V ABC.................
C 321 87-016-492-080 C-CAP,S 0.33-16 FZ ABC.................
C 322 87-016-492-080 C-CAP,S 0.33-16 FZ ABC.................
C 337 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................
C 332 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................
C 339 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................
C 335 87-010-401-080 CAP, ELECT 1-50V ABC.................
C 336 87-010-401-080 CAP, ELECT 1-50V ABC.................
C 340 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................
C 354 87-010-175-080 CAP 560P ABC.................
C 358 87-010-183-080 C-CAP,S 2700P-50 B ABC.................
C 359 87-010-183-080 C-CAP,S 2700P-50 B ABC.................
C 357 87-010-197-080 CAP, CHIP 0.01 DM ABC.................
C 356 87-010-260-080 CAP, ELECT 47-25V ABC.................
C 351 87-012-140-080 CAP 470P ABC.................
C 352 87-012-140-080 CAP 470P ABC.................
C 355 87-012-349-080 C-CAP,S 1000P-50 CH ABC.................
C 360 87-010-183-080 C-CAP,S 2700P-50 B ABC.................
C 363 87-A10-772-080 CAP,M 5600P-50 J ABC.................
C 378 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................
C 370 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................
C 379 87-010-382-080 CAP, ELECT 22-25V ABC.................
C 374 87-016-083-080 C-CAP,S 0.15-16 RK ABC.................
C 373 87-016-083-080 C-CAP,S 0.15-16 RK ABC.................
C 386 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................
C 380 87-010-382-080 CAP, ELECT 22-25V ABC.................
C 388 87-012-156-080 C-CAP,S 220P-50 CH ABC.................
C 391 87-010-319-080 C-CAP,S 56P-50 CH ABC.................
C 392 87-010-319-080 C-CAP,S 56P-50 CH ABC.................
C 394 87-010-319-080 C-CAP,S 56P-50 CH ABC.................
C 393 87-010-319-080 C-CAP,S 56P-50 CH ABC.................
CN 301 87-099-827-010 CONN,3P S2M-3W ABC.................
CN 351 87-099-832-010 CONN,8P S2M-8W ABC.................
D 352 87-A40-269-080 C-DIODE,MC2836 ABC.................
IC 303 87-A20-783-040 C-IC,BA7762AFS ABC.................
L 302 87-A50-049-010 COIL,TRAP 85K(COI) ABC.................
L 301 87-A50-049-010 COIL,TRAP 85K(COI) ABC.................
L 351 87-007-342-010 COIL,OSC 85K BIAS ABC.................
Q 357 87-026-610-080 TR,KTC3198GR ABC.................
Q 358 87-026-610-080 TR,KTC3198GR ABC.................
Q 359 87-026-610-080 TR,KTC3198GR ABC.................
Q 354 87-A30-087-080 C-FET,2SK2158 ABC.................
Q 351 87-A30-087-080 C-FET,2SK2158 ABC.................
Q 353 87-A30-087-080 C-FET,2SK2158 ABC.................
Q 355 87-A30-105-080 C-TR,RT1P 441C ABC.................
SFR 352 87-A90-433-080 SFR,50K H NVZ6TLTA ABC.................
SFR 351 87-A90-433-080 SFR,50K H NVZ6TLTA ABC.................
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
ELECTRICALPARTSLIST-4/7
C 507 87-010-183-080 C-CAP,S 2700P-50 B ABC.................
C 509 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................
C 505 87-012-145-080 CAP, CHIP S 270P CH ABC.................
C 506 87-012-145-080 CAP, CHIP S 270P CH ABC.................
C 504 87-012-154-080 C-CAP,S 150P-50 CH ABC.................
C 503 87-012-154-080 C-CAP,S 150P-50 CH ABC.................
C 501 87-A10-060-080 C-CAP,S 0.18-16 K B ABC.................
C 502 87-A10-060-080 C-CAP,S 0.18-16 K B ABC.................
C 511 87-010-177-080 C-CAP,S 820P-50 SL ABC.................
C 510 87-010-177-080 C-CAP,S 820P-50 SL ABC.................
C 517 87-010-183-080 C-CAP,S 2700P-50 B ABC.................
C 512 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................
C 514 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................
C 515 87-010-263-080 CAP, ELECT 100-10V ABC.................
C 513 87-010-374-080 CAP, ELECT 47-10V ABC.................
C 527 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................
C 523 87-016-460-080 C-CAP,S 0.22-16 B ABC.................
C 521 87-016-460-080 C-CAP,S 0.22-16 B ABC.................
C 522 87-016-460-080 C-CAP,S 0.22-16 B ABC.................
CN 502 87-099-566-010 CONN,7P TUC-P7P-B1 ABC.................
CN 501 87-A60-689-010 CONN,7P H GRY TUC-P07X-C1 ABC.................
D 501 87-070-136-080 ZENER,MTZJ5.1B ABC.................
IC 501 87-A20-561-040 C-IC,M65847AFP ABC.................
C 4 87-012-368-080 C-CAP,S 0.1-50 F ABC.................
C 5 87-012-368-080 C-CAP,S 0.1-50 F ABC.................
C 6 87-012-368-080 C-CAP,S 0.1-50 F ABC.................
C 3 87-012-368-080 C-CAP,S 0.1-50 F ABC.................
C 1 87-012-369-080 C-CAP,S 0.047-50F ABC.................
C 2 87-012-369-080 C-CAP,S 0.047-50F ABC.................
C 9 87-A10-520-090 CAP,E 3300-35 M SMG ABC.................
C 10 87-A10-520-090 CAP,E 3300-35 M SMG ABC.................
C 29 87-010-247-080 CAP, ELECT 100-50V ABC.................
C 26 87-010-263-080 CAP, ELECT 100-10V ABC.................
C 21 87-010-406-080 CAP, ELECT 22-50 ABC.................
C 22 87-010-406-080 CAP, ELECT 22-50 ABC.................
C 24 87-010-406-080 CAP, ELECT 22-50 ABC.................
C 23 87-010-406-080 CAP, ELECT 22-50 ABC.................
C 25 87-010-430-080 CAP, ELECT 100-63 ABC.................
C 27 87-012-140-080 CAP 470P ABC.................
C 30 87-010-112-080 CAP, ELECT 100-16V ABC.................
C 31 87-010-235-080 CAP,E 470-16 SME ABC.................
C 33 87-010-405-080 CAP, ELECT 10-50V ABC.................
C 34 87-010-405-080 CAP, ELECT 10-50V ABC.................
C 61 87-010-260-080 CAP, ELECT 47-25V ABC.................
C 62 87-010-403-080 CAP, ELECT 3.3-50V ABC.................
C 93 87-010-380-080 CAP, ELECT 47-16V ABC.................
CN 91 87-A60-109-010 CONN,2P V S2M-2W ABC.................
CNA 1 8Z-NF8-669-010 CONN ASSY,9P VH ABC.................
D 1 87-017-447-010 DIODE,GBU4DL ABC.................
D 9 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 8 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 5 87-070-274-080 DIODE,1N4003 SEM ABC.................
D 3 87-070-274-080 DIODE,1N4003 SEM ABC.................
D 6 87-070-274-080 DIODE,1N4003 SEM ABC.................
D 4 87-070-274-080 DIODE,1N4003 SEM ABC.................
D 7 87-A40-383-080 ZENER,MTZJ30A ABC.................
D 10 87-A40-345-080 ZENER,MTZJ10C ABC.................
D 64 87-070-274-080 DIODE,1N4003 SEM ABC.................
D 62 87-A40-269-080 C-DIODE,MC2836 ABC.................
D 61 87-A40-270-080 C-DIODE,MC2838 ABC.................
D 91 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 92 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
Q 1 87-026-609-080 TR,KTA1266GR ABC.................
Q 2 87-026-609-080 TR,KTA1266GR ABC.................
Q 5 87-026-610-080 TR,KTC3198GR ABC.................
Q 8 87-A30-075-080 C-TR,2SA1235F ABC.................
Q 6 87-A30-076-080 C-TR,2SC3052F ABC.................
Q 9 87-A30-196-080 TR,2SC4115SRS ABC.................
Q 4 89-213-702-010 TR,2SB1370 (1.8W) ABC.................
Q 61 87-A30-074-080 C-TR,RT1P 141C ABC.................
Q 66 87-A30-075-080 C-TR,2SA1235F ABC.................
Q 64 87-A30-075-080 C-TR,2SA1235F ABC.................
Q 62 87-A30-075-080 C-TR,2SA1235F ABC.................
Q 67 87-A30-076-080 C-TR,2SC3052F ABC.................
Q 65 87-A30-076-080 C-TR,2SC3052F ABC.................
Q 63 87-A30-076-080 C-TR,2SC3052F ABC.................
Q 92 87-026-609-080 TR,KTA1266GR ABC.................
Q 91 87-A30-076-080 C-TR,2SC3052F ABC.................
WH 1 87-A90-510-010 HLDR,WIRE 2.5-9P ABC.................
87-067-703-010 TAPPING SCREW, BVT2+3-10 ABC.................
C 101 87-010-178-080 CHIP CAP 1000P ABC.................
C 102 87-010-178-080 CHIP CAP 1000P ABC.................
C 103 87-010-401-080 CAP, ELECT 1-50V ABC.................
C 104 87-010-401-080 CAP, ELECT 1-50V ABC.................
C 107 87-010-405-080 CAP, ELECT 10-50V ABC.................
C 108 87-010-405-080 CAP, ELECT 10-50V ABC.................
C 111 87-010-260-080 CAP, ELECT 47-25V ABC.................
C 112 87-010-260-080 CAP, ELECT 47-25V ABC.................
C 117 87-016-247-080 C-CAP,0.1-50 F ABC.................
C 118 87-016-247-080 C-CAP,0.1-50 F ABC.................
C 113 87-A10-685-080 C-CAP,S 470P-100 J CH ABC.................
C 114 87-A10-685-080 C-CAP,S 470P-100 J CH ABC.................
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
C 124 87-010-176-080 C-CAP,S 680P-50 SL ABC.................
C 123 87-010-176-080 C-CAP,S 680P-50 SL ABC.................
C 121 87-010-178-080 CHIP CAP 1000P ABC.................
C 122 87-010-178-080 CHIP CAP 1000P ABC.................
C 129 87-010-191-080 C-CAP,S 0.015-50 F ABC.................
C 128 87-012-368-080 C-CAP,S 0.1-50 F ABC.................
C 126 87-012-368-080 C-CAP,S 0.1-50 F ABC.................
C 127 87-012-368-080 C-CAP,S 0.1-50 F ABC.................
C 125 87-012-368-080 C-CAP,S 0.1-50 F ABC.................
C 130 87-010-191-080 C-CAP,S 0.015-50 F ABC.................
C 133 87-010-197-080 CAP, CHIP 0.01 DM ABC.................
C 131 87-010-197-080 CAP, CHIP 0.01 DM ABC.................
C 132 87-010-197-080 CAP, CHIP 0.01 DM ABC.................
D 101 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 103 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 109 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 104 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 102 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 108 87-A40-488-080 DIODE,1SS244 ABC.................
D 107 87-A40-488-080 DIODE,1SS244 ABC.................
D 110 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 114 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 112 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 115 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 113 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 111 87-A40-270-080 C-DIODE,MC2838 ABC.................
J 203 87-A60-238-010 TERMINAL,SP 4P (MSC) ABC.................
J 201 87-A60-483-010 JACK,DIA6.3 BLK ST W/S KM ABC.................
L 101 87-003-383-010 COIL,1UH-S ABC.................
L 102 87-003-383-010 COIL,1UH-S ABC.................
Q 104 87-A30-075-080 C-TR,2SA1235F ABC.................
Q 106 87-A30-075-080 C-TR,2SA1235F ABC.................
Q 105 87-A30-075-080 C-TR,2SA1235F ABC.................
Q 103 87-A30-075-080 C-TR,2SA1235F ABC.................
Q 107 87-A30-076-080 C-TR,2SC3052F ABC.................
Q 108 87-A30-076-080 C-TR,2SC3052F ABC.................
Q 109 87-A30-076-080 C-TR,2SC3052F ABC.................
Q 102 87-A30-257-080 C-TR,2SD1306E ABC.................
Q 101 87-A30-257-080 C-TR,2SD1306E ABC.................
Q 110 87-A30-076-080 C-TR,2SC3052F ABC.................
Q 116 87-A30-097-010 TR,FN 1016 ABC.................
Q 115 87-A30-097-010 TR,FN 1016 ABC.................
Q 117 87-A30-098-010 TR,FP 1016 ABC.................
Q 118 87-A30-098-010 TR,FP 1016 ABC.................
Q 111 87-A30-190-080 TR,CC5551 ABC.................
Q 112 87-A30-190-080 TR,CC5551 ABC.................
Q 127 87-A30-075-080 C-TR,2SA1235F ABC.................
Q 126 87-A30-075-080 C-TR,2SA1235F ABC.................
Q 128 87-A30-076-080 C-TR,2SC3052F ABC.................
Q 129 87-A30-076-080 C-TR,2SC3052F ABC.................
Q 124 87-A30-106-070 C-TR,CMBT5551 ABC.................
Q 123 87-A30-106-070 C-TR,CMBT5551 ABC.................
Q 131 87-A30-076-080 C-TR,2SC3052F ABC.................
Q 130 87-A30-076-080 C-TR,2SC3052F ABC.................
R 129 87-A00-257-080 RES,M/F 0.15-1W J ABC.................
R 130 87-A00-257-080 RES,M/F 0.15-1W J ABC.................
R 131 87-A00-257-080 RES,M/F 0.15-1W J ABC.................
R 132 87-A00-257-080 RES,M/F 0.15-1W J ABC.................
R 143 87-A00-440-050 RES,220-1/2W J RP ABC.................
R 144 87-A00-440-050 RES,220-1/2W J RP ABC.................
R 145 87-A00-440-050 RES,220-1/2W J RP ABC.................
R 146 87-A00-440-050 RES,220-1/2W J RP ABC.................
R 166 87-A00-257-080 RES,M/F 0.15-1W J ABC.................
R 165 87-A00-257-080 RES,M/F 0.15-1W J ABC.................
TH 101 87-A91-042-080 C-THMS,100K 55001 ABC.................
TH 102 87-A91-042-080 C-THMS,100K 55001 ABC.................
C 204 87-010-178-080 CHIP CAP 1000P ABC.................
C 203 87-010-178-080 CHIP CAP 1000P ABC.................
C 209 87-010-403-080 CAP, ELECT 3.3-50V ABC.................
C 212 87-010-182-080 C-CAP,S 2200P-50 B ABC.................
C 211 87-010-182-080 C-CAP,S 2200P-50 B ABC.................
C 218 87-010-260-080 CAP, ELECT 47-25V ABC.................
C 217 87-010-260-080 CAP, ELECT 47-25V ABC.................
C 215 87-010-322-080 C-CAP,S 100P-50 CH ABC.................
C 216 87-010-322-080 C-CAP,S 100P-50 CH ABC.................
C 213 87-010-403-080 CAP, ELECT 3.3-50V ABC.................
C 214 87-010-403-080 CAP, ELECT 3.3-50V ABC.................
C 210 87-010-403-080 CAP, ELECT 3.3-50V ABC.................
C 219 87-A10-946-080 C-CAP,S 220P-100 J CH ABC.................
C 227 87-010-186-080 CAP,CHIP 4700P ABC.................
C 228 87-010-186-080 CAP,CHIP 4700P ABC.................
C 223 87-010-190-080 S CHIP F 0.01 ABC.................
C 224 87-010-190-080 S CHIP F 0.01 ABC.................
C 226 87-010-544-080 CAP, ELECT 0.1-50V ABC.................
C 225 87-010-544-080 CAP, ELECT 0.1-50V ABC.................
C 229 87-010-993-080 C-CAP,S 0.056-25 B ABC.................
C 220 87-A10-946-080 C-CAP,S 220P-100 J CH ABC.................
C 234 87-010-190-080 S CHIP F 0.01 ABC.................
C 233 87-010-190-080 S CHIP F 0.01 ABC.................
C 239 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................
C 231 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................
C 232 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................
ELECTRICALPARTSLIST-5/7
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
C 230 87-010-993-080 C-CAP,S 0.056-25 B ABC.................
C 236 87-016-285-080 CAP,E 47-100SME ABC.................
C 235 87-016-285-080 CAP,E 47-100SME ABC.................
C 240 87-010-408-080 CAP, ELECT 47-50V ABC.................
D 204 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 202 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 203 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 201 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 207 87-A40-488-080 DIODE,1SS244 ABC.................
D 208 87-A40-488-080 DIODE,1SS244 ABC.................
D 214 87-020-465-080 DIODE,1SS133 (110MA) ABC.................
D 211 87-A40-270-080 C-DIODE,MC2838 ABC.................
J 204 87-A60-750-010 JACK,PIN 4P R/W BLUE ABC.................
L 202 87-003-383-010 COIL,1UH-S ABC.................
L 201 87-003-383-010 COIL,1UH-S ABC.................
Q 204 87-A30-075-080 C-TR,2SA1235F ABC.................
Q 205 87-A30-075-080 C-TR,2SA1235F ABC.................
Q 206 87-A30-075-080 C-TR,2SA1235F ABC.................
Q 203 87-A30-075-080 C-TR,2SA1235F ABC.................
Q 208 87-A30-076-080 C-TR,2SC3052F ABC.................
Q 209 87-A30-076-080 C-TR,2SC3052F ABC.................
Q 207 87-A30-076-080 C-TR,2SC3052F ABC.................
Q 202 87-A30-257-080 C-TR,2SD1306E ABC.................
Q 201 87-A30-257-080 C-TR,2SD1306E ABC.................
Q 210 87-A30-076-080 C-TR,2SC3052F ABC.................
Q 219 87-A30-119-040 C-TR,2SC3906K R ABC.................
Q 212 87-A30-190-080 TR,CC5551 ABC.................
Q 211 87-A30-190-080 TR,CC5551 ABC.................
Q 217 87-A30-255-010 TR,2SB1342 ABC.................
Q 218 87-A30-255-010 TR,2SB1342 ABC.................
Q 215 87-A30-256-010 TR,2SD1933 ABC.................
Q 216 87-A30-256-010 TR,2SD1933 ABC.................
Q 226 87-A30-076-080 C-TR,2SC3052F ABC.................
Q 227 87-A30-076-080 C-TR,2SC3052F ABC.................
Q 225 87-A30-076-080 C-TR,2SC3052F ABC.................
Q 224 87-A30-076-080 C-TR,2SC3052F ABC.................
Q 220 87-A30-119-040 C-TR,2SC3906K R ABC.................
R 234 87-A00-258-080 RES,M/F 0.22-1W J ABC.................
R 233 87-A00-258-080 RES,M/F 0.22-1W J ABC.................
R 232 87-A00-258-080 RES,M/F 0.22-1W J ABC.................
R 231 87-A00-258-080 RES,M/F 0.22-1W J ABC.................
R 266 87-A00-258-080 RES,M/F 0.22-1W J ABC.................
R 265 87-A00-258-080 RES,M/F 0.22-1W J ABC.................
C 601 87-010-180-080 C-CER 1500P ABC.................
C 602 87-010-180-080 C-CER 1500P ABC.................
C 605 87-010-318-080 C-CAP,S 47P-50 CH ABC.................
C 606 87-010-318-080 C-CAP,S 47P-50 CH ABC.................
C 619 87-010-185-080 C-CAP,S 3900P-50 B ABC.................
C 613 87-016-081-080 C-CAP,S 0.1-16 RK ABC.................
C 614 87-016-081-080 C-CAP,S 0.1-16 RK ABC.................
C 618 87-A11-008-080 CAP,M 0.056-50 J DE ABC.................
C 617 87-A11-008-080 CAP,M 0.056-50 J DE ABC.................
C 616 87-A11-011-080 CAP,M 0.12-50 J DE ABC.................
C 615 87-A11-011-080 CAP,M 0.12-50 J DE ABC.................
C 620 87-010-185-080 C-CAP,S 3900P-50 B ABC.................
C 622 87-010-401-080 CAP, ELECT 1-50V ABC.................
C 621 87-010-401-080 CAP, ELECT 1-50V ABC.................
C 626 87-010-405-080 CAP, ELECT 10-50V ABC.................
C 625 87-010-405-080 CAP, ELECT 10-50V ABC.................
C 629 87-010-405-080 CAP, ELECT 10-50V ABC.................
C 624 87-A10-773-080 CAP,M 0.10-50 J ABC.................
C 623 87-A10-773-080 CAP,M 0.10-50 J ABC.................
C 637 87-010-183-080 C-CAP,S 2700P-50 B ABC.................
C 636 87-010-194-080 CAP, CHIP 0.047 ABC.................
C 635 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................
C 634 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................
C 630 87-010-213-080 C-CAP,S 0.015-50 B ABC.................
C 633 87-010-263-080 CAP, ELECT 100-10V ABC.................
C 632 87-010-263-080 CAP, ELECT 100-10V ABC.................
C 638 87-010-314-080 C-CAP,S 22P-50V ABC.................
C 639 87-010-314-080 C-CAP,S 22P-50V ABC.................
C 631 87-010-992-080 C-CAP,S 0.047-25 B ABC.................
C 641 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................
CN 604 87-099-570-010 CONN,13P TUC-P13P-B1 ABC.................
CN 602 87-A60-131-010 CONN,6P V FE ABC.................
CN 601 88-NF9-657-010 CONN,30P H BLK TYK-B(X) ABC.................
D 601 87-A40-002-080 ZENER,MTZJ5.1C ABC.................
D 603 87-A40-234-080 ZENER,MTZJ5.6A ABC.................
D 602 87-A40-438-080 ZENER,MTZJ4.7A ABC.................
IC 601 87-A21-011-040 C-IC,M62445FP-600D ABC.................
J 602 87-A60-398-010 JACK,PIN 2P R/W HSP-242V24 ABC.................
Q 601 87-026-609-080 TR,KTA1266GR ABC.................
Q 604 87-A30-142-040 C-TR,DTA123EKA ABC.................
C 707 87-010-180-080 C-CER 1500P ABC.................
C 702 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................
C 706 87-010-197-080 CAP, CHIP 0.01 DM ABC.................
C 708 87-010-213-080 C-CAP,S 0.015-50 B ABC.................
C 709 87-010-213-080 C-CAP,S 0.015-50 B ABC.................
C 701 87-010-263-080 CAP, ELECT 100-10V ABC.................
C 704 87-010-319-080 C-CAP,S 56P-50 CH ABC.................
C 703 87-010-319-080 C-CAP,S 56P-50 CH ABC.................
C 705 87-012-393-080 C-CAP,S 0.22-16 R K ABC.................
ELECTRICALPARTSLIST-6/7
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
C 711 87-010-181-080 CAP,CHIP S 1800P ABC.................
C 712 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................
C 710 87-010-197-080 CAP, CHIP 0.01 DM ABC.................
C 714 87-010-374-080 CAP, ELECT 47-10V ABC.................
C 713 87-010-544-080 CAP, ELECT 0.1-50V ABC.................
C 719 87-012-141-080 CHIP-CAPACITOR,0.22-16F ABC.................
C 736 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................
C 733 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................
C 732 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................
C 738 87-010-318-080 C-CAP,S 47P-50 CH ABC.................
C 737 87-010-318-080 C-CAP,S 47P-50 CH ABC.................
C 739 87-010-318-080 C-CAP,S 47P-50 CH ABC.................
C 731 87-010-560-080 CAP,E 10-50 GAS ABC.................
C 734 87-012-157-080 C-CAP,S 330P-50 CH ABC.................
D 701 87-A40-234-080 ZENER,MTZJ5.6A ABC.................
IC 701 87-A20-613-040 C-IC,BU9262AFS ABC.................
L 701 87-005-448-080 COIL 220UH,K ABC.................
Q 732 87-A30-075-080 C-TR,2SA1235F ABC.................
Q 731 87-A30-076-080 C-TR,2SC3052F ABC.................
C 457 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................
C 458 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................
C 451 87-010-401-080 CAP, ELECT 1-50V ABC.................
C 452 87-010-401-080 CAP, ELECT 1-50V ABC.................
C 453 87-010-545-080 CAP, ELECT 0.22-50V ABC.................
C 454 87-010-545-080 CAP, ELECT 0.22-50V ABC.................
C 459 87-A11-004-080 CAP,M 0.022-50 J DE ABC.................
C 455 87-A11-010-080 CAP,M 0.082-50 J DE ABC.................
C 456 87-A11-010-080 CAP,M 0.082-50 J DE ABC.................
C 465 87-A11-004-080 CAP,M 0.022-50 J DE ABC.................
C 460 87-A11-004-080 CAP,M 0.022-50 J DE ABC.................
C 466 87-A11-004-080 CAP,M 0.022-50 J DE ABC.................
IC 451 87-A21-031-040 C-IC,BU4551BF ABC.................
ELECTRICALPARTSLIST-7/7
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
MECHANICAL PARTS LIST-1/1
NOTE: The characters in the suffix column indicate the part usage.
HRJ8STM ................XX..................................A...................
HRJSTM .................XX...................................B..................
HRJ7STM ................XX....................................C.................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
82-NE6-067-010 BADGE,AIWA 30N ABC.................
86-NF6-007-010 WINDOW,TOP ABC.................
8Z-NB8-011-010 PANEL,LEFT V-2 ABC.................
8Z-NB8-013-010 PANEL,TOP V-2 ABC.................
8Z-NF8-021-010 WINDOW,CASS 1 ABC.................
8Z-NF8-022-010 WINDOW,CASS 2 ABC.................
8Z-NF8-037-010 BOX,CASS 1H ABC.................
8Z-NF8-038-010 BOX,CASS 2H ABC.................
8Z-NF9-043-010 PANEL,RIGHT S V-2 ABC.................
8Z-NFV-012-010 WINDOW,CD ABC.................
8Z-NH8-001-010 WINDOW,DISP H ABC.................
8Z-NH8-002-010 PANEL,TRAY H ABC.................
8Z-NH8-003-010 CABI,FR H ABC.................
8Z-NH8-011-010 CABI,REAR HRJSTNM ABC.................
8Z-NF8-005-010 KEY,POWER ABC.................
8Z-NF8-006-010 KEY,CD ABC.................
8Z-NF8-007-010 REFLECTOR,ECO ..C.................
8Z-NF8-008-010 KEY,TIMER ABC.................
8Z-NF8-010-010 KEY,ASSY FUN ABC.................
8Z-NF8-019-010 KEY,ECHO ABC.................
8Z-NF8-020-010 KEY,RDS ABC.................
8Z-NF8-026-010 KNOB,RTRY JOG ABC.................
8Z-NF8-027-010 KNOB,RTRY VOL ABC.................
8Z-NF8-029-010 REFLECTOR,JOG ABC.................
8Z-NH8-006-010 KEY,EDIT ABC.................
8Z-NH8-007-010 KEY,ASSY PLAY ABC.................
8Z-NH8-009-010 KEY,ASSY PAUSE ABC.................
81-532-080-010 LABEL, CASS. COMPT ABC.................
CN 0 87-NF6-616-010 CONN ASSY,8P RPB ABC.................
84-ZG1-245-210 CAP,OPTICAL ABC.................
82-NF5-218-010 SPR-T,EJECT 1 (SIN) ABC.................
82-NF5-219-010 SPR-T,EJECT 2 (SIN) ABC.................
82-NF5-229-010 PLATE,LOCK ABC.................
86-NF9-224-010 SPR-C,LOCK ABC.................
87-NF4-216-010 HLDR,LOCK 1 ABC.................
87-NF4-217-010 HLDR,LOCK 2 ABC.................
87-NF4-221-010 HLDR,CABLE ABC.................
87-NF8-220-010 DMPR,150 ABC.................
88-NF5-208-010 HLDR,PWB-M N ABC.................
8Z-NB8-240-010 COVER, PL ABC.................
8Z-NF8-205-110 HLDR,HT-SINK ABC.................
* 8Z-NF9-204-010 PLATE,MIC ABC.................
87-067-581-010 TAPPING SCREW, BVT2+3-15 ABC.................
87-067-641-010 UTT2+3-8(W/O SLOT)BL ABC.................
87-067-688-010 BVTT+3-6 ABC.................
87-067-703-010 TAPPING SCREW, BVT2+3-10 ABC.................
87-067-758-010 BVT2+3-12 W/O SLOT ABC.................
87-078-191-010 S-SCREW,IT+4-10 ABC.................
87-721-096-410 QT2+3-10 GLD ABC.................
87-721-097-410 QT2+3-12 GLD ABC.................
87-NF4-224-010 S-SCREW,IT3B+3-8 CU ABC.................
87-050-079-010 AC-CORD ASSY,E ABC.................
87-085-185-010 BUSHING, AC CORD (E) ABC.................
87-A90-796-010 FAN,F614R-12MC-15-300MM ABC.................
88-906-241-110 FF-CABLE,6P 1.25 ABC.................
88-913-301-110 FF-CABLE,13P-1.25 ABC.................
88-915-101-110 FF-CABLE, 15P 1.25 100MM ABC.................
8Z-NF8-605-010 PT,ZNF-8HR ABC.................
8Z-NF8-201-010 GUIDE,OPE ABC.................
8Z-NF8-202-010 GUIDE,FUN ABC.................
WH 1 87-A90-510-010 HLDR,WIRE 2.5-9P ABC.................
87-067-703-010 TAPPING SCREW, BVT2+3-10 ABC.................
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
ACCESSORIES / PACKAGE LIST-1/1
NOTE: The characters in the suffix column indicate the part usage.
HRJ8STM ................XX..................................A...................
HRJSTM .................XX...................................B..................
HRJ7STM ................XX....................................C.................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
8Z-NH8-911-010 IB,H(EC-H)M ABC.................
87-006-269-010 AM LOOP ANT (UN) ABC.................
87-043-095-010 WIRE ANTENNA ABC.................
87-043-115-010 ANT,FEEDER FM ABC.................
87-050-103-010 CORD,PIN 1PY1.5M ABC.................
87-099-789-010 PLUG,ADPTR IR44 ABC.................
8Z-NH8-702-010 RC UNIT,RC-ZAS07 ABC.................
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
Other manuals for NSX-K580
1
Table of contents
Other Aiwa Stereo System manuals
