Aiwa NSX-SZ809 User manual

SERVICE MANUAL
DATA
NSX-SZ809 HA,LH
SIMPLE
S/M Code No. 09-013-443-5T2
• Replace this Service manual with “Revision Publishing” when it is issued.
COMPACT DISC STEREO SYSTEM BASIC CD MECHANISM : BZG-5 YZD3N1M BZG-5 YZD3N1CM
BASIC TAPE MECHANISM: 2ZM-3MK2 PR4NM

 2 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
O ACCESSORY 87-006-268-010 1C ANT,LOOP AM HASC1M CX-NSZ809
O ACCESSORY 87-006-268-010 1C ANT,LOOP AM LHSKM CX-SNSZ809
O ACCESSORY 87-043-115-010 1A FEEDER-ANT,FM HASC1M CX-NSZ809
O ACCESSORY 87-043-115-010 1A FEEDER-ANT,FM LHSKM CX-SNSZ809
O ACCESSORY 8 -NF7-701-010 1E RC UNIT,RC- AS01 HASC1M CX-NSZ809
O ACCESSORY 8 -NF7-701-010 1E RC UNIT,RC- AS01 LHSKM CX-SNSZ809
! O APPEARANCE 87-CE3-023-010 0E ADGE,AIWA 30N SILV HASC1M CX-NSZ809
! O APPEARANCE 87-CE3-023-010 0E ADGE,AIWA 30N SILV LHSKM CX-SNSZ809
! O APPEARANCE 8A-NF8-006-010 1 WINDOW,TOP HASC1M CX-NSZ809
! O APPEARANCE 8A-NF8-006-010 1 WINDOW,TOP LHSKM CX-SNSZ809
! O APPEARANCE 8A-NF8-007-010 1C PANEL,LEFT V-2 HASC1M CX-NSZ809
! O APPEARANCE 8A-NF8-007-010 1C PANEL,LEFT V-2 LHSKM CX-SNSZ809
! O APPEARANCE 8A-NF8-008-010 1C PANEL,RIGHT V-2 HASC1M CX-NSZ809
! O APPEARANCE 8A-NF8-008-010 1C PANEL,RIGHT V-2 LHSKM CX-SNSZ809
O APPEARANCE 8 -NF7-003-010 1 OX,CASS 1 REV HASC1M CX-NSZ809
O APPEARANCE 8 -NF7-003-010 1 OX,CASS 1 REV LHSKM CX-SNSZ809
O APPEARANCE 8 -NF7-004-010 1 OX,CASS 2 REV HASC1M CX-NSZ809
O APPEARANCE 8 -NF7-004-010 1 OX,CASS 2 REV LHSKM CX-SNSZ809
O APPEARANCE 8 -NF7-005-010 1A PANEL,TRAY HASC1M CX-NSZ809
O APPEARANCE 8 -NF7-005-010 1A PANEL,TRAY LHSKM CX-SNSZ809
O APPEARANCE 8 -NF7-007-010 0E WINDOW,CASS 1 HASC1M CX-NSZ809
O APPEARANCE 8 -NF7-007-010 0E WINDOW,CASS 1 LHSKM CX-SNSZ809
O APPEARANCE 8 -NF7-008-010 0E WINDOW,CASS 2 HASC1M CX-NSZ809
O APPEARANCE 8 -NF7-008-010 0E WINDOW,CASS 2 LHSKM CX-SNSZ809
O APPEARANCE 8 -NF7-035-010 1A WINDOW,TRAY HASC1M CX-NSZ809
O APPEARANCE 8 -NF7-035-010 1A WINDOW,TRAY LHSKM CX-SNSZ809
O APPEARANCE 8 -NF7-040-010 1C PANEL,TOP V-2 ANF8 HASC1M CX-NSZ809
O APPEARANCE 8 -NF7-040-010 1C PANEL,TOP V-2 ANF8 LHSKM CX-SNSZ809
O APPEARANCE 8 -NF7-045-010 1 PANEL,MOVE 1R H HASC1M CX-NSZ809
O APPEARANCE 8 -NF7-045-010 1 PANEL,MOVE 1R H LHSKM CX-SNSZ809
O APPEARANCE 8 -NF7-061-010 1H CA I,FR H HASC1M CX-NSZ809
O APPEARANCE 8 -NF7-061-010 1H CA I,FR H LHSKM CX-SNSZ809
O APPEARANCE 8 -NF7-068-010 -- WINDOW,DISP LH HASC1M CX-NSZ809
O APPEARANCE 8 -NF7-068-010 -- WINDOW,DISP LH LHSKM CX-SNSZ809
O APPEARANCE 8 -NF7-076-010 -- CA I,REAR LH W/O SPEC HASC1M CX-NSZ809
O APPEARANCE 8 -NF7-076-010 -- CA I,REAR LH W/O SPEC LHSKM CX-SNSZ809
O APPEARANCE 8 -NF7-081-010 -- PANEL,MOVE 1F HA HASC1M CX-NSZ809
O APPEARANCE 8 -NF7-082-010 -- PANEL,MOVE 1F LHK LHSKM CX-SNSZ809
O APPEARANCE 8 -NF7-086-010 -- PANEL,MOVE 2 LH HASC1M CX-NSZ809
O APPEARANCE 8 -NF7-086-010 -- PANEL,MOVE 2 LH LHSKM CX-SNSZ809
X CD M8- ZG-596-130 -- ZG-5 YZD3N1M LHSKM CX-SNSZ809
X CD M8- ZG-59R-130 -- ZG-5 YZD3N1CM HASC1M CX-NSZ809
X ELECTRICAL 80-XV1-218-010 0E CUSH-S,PW HASC1M CX-NSZ809
X ELECTRICAL 80-XV1-218-010 0E CUSH-S,PW LHSKM CX-SNSZ809
! X ELECTRICAL 87-069-033-010 0E CA LE,TIE HASC1M CX-NSZ809
! X ELECTRICAL 87-069-033-010 0E CA LE,TIE LHSKM CX-SNSZ809
! O ELECTRICAL 87-085-185-010 0E USHING,AC CORD(E) CM-22 HASC1M CX-NSZ809
! O ELECTRICAL 87-085-185-010 0E USHING,AC CORD(E) CM-22 LHSKM CX-SNSZ809
O ELECTRICAL 87-A91-751-010 1F FAN,DS 0812M-S382 -400MM HASC1M CX-NSZ809
O ELECTRICAL 87-A91-751-010 1F FAN,DS 0812M-S382 -400MM LHSKM CX-SNSZ809
X ELECTRICAL 88-100-000-090 0E PLATING-JW, HASC1M CX-NSZ809
X ELECTRICAL 88-100-000-090 0E PLATING-JW, LHSKM CX-SNSZ809
O ELECTRICAL 88-904-091-110 0E FF-CA LE,4P 1.25 90MM HASC1M CX-NSZ809
O ELECTRICAL 88-904-091-110 0E FF-CA LE,4P 1.25 90MM LHSKM CX-SNSZ809
O ELECTRICAL 88-905-151-110 0E FF-CA LE,5P 1.25 150MM HASC1M CX-NSZ809
O ELECTRICAL 88-905-151-110 0E FF-CA LE,5P 1.25 150MM LHSKM CX-SNSZ809
O ELECTRICAL 88-906-251-110 1A FF-CA LE,6P 1.25 HASC1M CX-NSZ809
O ELECTRICAL 88-906-251-110 1A FF-CA LE,6P 1.25 LHSKM CX-SNSZ809
O ELECTRICAL 88-908-301-110 1A FF-CA LE,8P 1.25 HASC1M CX-NSZ809
O ELECTRICAL 88-908-301-110 1A FF-CA LE,8P 1.25 LHSKM CX-SNSZ809
O ELECTRICAL 88-909-101-110 0E FF-CA LE, 9P 1.25 100MM HASC1M CX-NSZ809
O ELECTRICAL 88-909-101-110 0E FF-CA LE, 9P 1.25 100MM LHSKM CX-SNSZ809
O ELECTRICAL 88-915-101-110 0E FF-CA LE, 15P 1.25 100MM HASC1M CX-NSZ809
O ELECTRICAL 88-915-101-110 0E FF-CA LE, 15P 1.25 100MM LHSKM CX-SNSZ809
X ELECTRICAL A8- ZA-D90-030 -- ZA-D YNF7FRM LHSKM CX-SNSZ809
X ELECTRICAL A8- ZA-E90-030 -- ZA-E YNF7MAM LHSKM CX-SNSZ809
X ELECTRICAL A8- ZA-F90-030 -- ZA-F YNF7PTM LHSKM CX-SNSZ809
X ELECTRICAL A8- ZA-G90-030 -- ZA-G YNF7PAM LHSKM CX-SNSZ809
O ELECTRICAL M 0911 87-045-305-010 1F MOT,RF-500T HASC1M CX-NSZ809
O ELECTRICAL M 0911 87-045-305-010 1F MOT,RF-500T LHSKM CX-SNSZ809

 3 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
! O ELECTRICAL PT 0001 8 -NF7-612-010 -- PT, NF-7LH HASC1M CX-NSZ809
! O ELECTRICAL PT 0001 8 -NF7-612-010 -- PT, NF-7LH LHSKM CX-SNSZ809
! O ELECTRICAL W 0001 87-A80-105-010 1C AC CORD ASSY,AZ HASC1M CX-NSZ809
! O ELECTRICAL W 0001 87-A80-157-010 1 AC CORD ASSY,E LK CC LHSKM CX-SNSZ809
! O FRC MECHA 8A-NF6-201-010 0E GUIDE,FL HASC1M CX-NSZ809
O FUNC/E.VR C 0605 87-012-280-080 0E C-CAP,U 3300P-50 K HASC1M CX-NSZ809
O FUNC/E.VR C 0606 87-012-280-080 0E C-CAP,U 3300P-50 K HASC1M CX-NSZ809
O FUNC/E.VR C 0609 87-010-785-080 0E C-CAP,U 0.015-25 K GRM HASC1M CX-NSZ809
O FUNC/E.VR C 0610 87-010-785-080 0E C-CAP,U 0.015-25 K GRM HASC1M CX-NSZ809
O FUNC/E.VR C 0611 87-A12-084-080 0E CAP,E 0.22-50 SMG HASC1M CX-NSZ809
O FUNC/E.VR C 0612 87-A12-084-080 0E CAP,E 0.22-50 SMG HASC1M CX-NSZ809
O FUNC/E.VR C 0613 87-A12-084-080 0E CAP,E 0.22-50 SMG HASC1M CX-NSZ809
O FUNC/E.VR C 0614 87-A12-084-080 0E CAP,E 0.22-50 SMG HASC1M CX-NSZ809
O FUNC/E.VR C 0615 87-012-172-080 0E C-CAP,U 10P-50 D CH HASC1M CX-NSZ809
O FUNC/E.VR C 0616 87-016-455-080 0E CAP,E 470-10 M SMG HASC1M CX-NSZ809
O FUNC/E.VR C 0617 87-016-455-080 0E CAP,E 470-10 M SMG HASC1M CX-NSZ809
O FUNC/E.VR C 0618 87-A12-091-080 0E CAP,E 10-50 SMG HASC1M CX-NSZ809
O FUNC/E.VR C 0620 87-A12-062-080 0E CAP,E 100-10 SMG HASC1M CX-NSZ809
O FUNC/E.VR C 0623 87-A12-084-080 0E CAP,E 0.22-50 SMG HASC1M CX-NSZ809
O FUNC/E.VR C 0624 87-A12-084-080 0E CAP,E 0.22-50 SMG HASC1M CX-NSZ809
O FUNC/E.VR C 0630 87-A10-260-080 0E C-CAP,U 0.1-16 K HASC1M CX-NSZ809
O FUNC/E.VR C 0631 87-012-281-080 0E C-CAP,U 3900P-50 K GRM HASC1M CX-NSZ809
O FUNC/E.VR C 0632 87-012-281-080 0E C-CAP,U 3900P-50 K GRM HASC1M CX-NSZ809
O FUNC/E.VR C 0633 87-A11-070-080 0E C-CAP,U 0.033-16 K HASC1M CX-NSZ809
O FUNC/E.VR C 0634 87-A11-070-080 0E C-CAP,U 0.033-16 K HASC1M CX-NSZ809
O FUNC/E.VR C 0661 87-012-336-080 0E C-CAP,U 330P-50 J SL HASC1M CX-NSZ809
O FUNC/E.VR C 0662 87-012-336-080 0E C-CAP,U 330P-50 J SL HASC1M CX-NSZ809
O FUNC/E.VR C 0671 87-010-831-080 0E C-CAP,U 0.1-16 Z F HASC1M CX-NSZ809
O FUNC/E.VR C 0672 87-010-831-080 0E C-CAP,U 0.1-16 Z F HASC1M CX-NSZ809
O FUNC/E.VR C 0673 87-012-278-080 0E C-CAP,U 2200P-50 K HASC1M CX-NSZ809
O FUNC/E.VR C 0677 87-012-286-080 0E C-CAP,U 0.01-25 K HASC1M CX-NSZ809
X FUNC/E.VR C 0678 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
! O FUNC/E.VR CN 0601 87-099-719-010 1 CONN,30P H LK TYK- (X) HASC1M CX-NSZ809
! O FUNC/E.VR CN 0602 87-A60-131-010 0E CONN,6P V FE HASC1M CX-NSZ809
S FUNC/E.VR D 0601 87-A40-739-080 0E ZENER,UZ2.7 SA HASC1M CX-NSZ809
S FUNC/E.VR D 0602 87-A40-739-080 0E ZENER,UZ2.7 SA HASC1M CX-NSZ809
S FUNC/E.VR IC 0601 87-A21-401-040 1C C-IC,M61503FP HASC1M CX-NSZ809
O FUNC/E.VR J 0602 87-A60-881-010 0E JACK,PIN 2P MSP 242V05 P SN HASC1M CX-NSZ809
X FUNC/E.VR JR 0601 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X FUNC/E.VR JR 0602 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X FUNC/E.VR JR 0606 88-129-000-080 0E C-JUMPER,3216 HASC1M CX-NSZ809
X FUNC/E.VR JR 0607 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X FUNC/E.VR JR 0616 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
S FUNC/E.VR Q 0601 87-A30-087-080 0E C-FET,2SK2158 HASC1M CX-NSZ809
S FUNC/E.VR Q 0602 87-A30-087-080 0E C-FET,2SK2158 HASC1M CX-NSZ809
S FUNC/E.VR Q 0605 87-A30-090-080 0E FET,2SK2541 HASC1M CX-NSZ809
S FUNC/E.VR Q 0606 87-A30-090-080 0E FET,2SK2541 HASC1M CX-NSZ809
S FUNC/E.VR Q 0607 87-A30-076-080 0E C-TR,2SC3052F HASC1M CX-NSZ809
X FUNC/E.VR R 0601 88-108-102-080 0E C-RES,U 1K-1/16W J HASC1M CX-NSZ809
X FUNC/E.VR R 0602 88-108-102-080 0E C-RES,U 1K-1/16W J HASC1M CX-NSZ809
X FUNC/E.VR R 0603 88-108-682-080 0E C-RES,U 6.8K-1/16W J HASC1M CX-NSZ809
X FUNC/E.VR R 0604 88-108-682-080 0E C-RES,U 6.8K-1/16W J HASC1M CX-NSZ809
X FUNC/E.VR R 0605 88-108-103-080 0E C-RES,U 10K-1/16W J HASC1M CX-NSZ809
X FUNC/E.VR R 0606 88-108-103-080 0E C-RES,U 10K-1/16W J HASC1M CX-NSZ809
X FUNC/E.VR R 0607 88-108-103-080 0E C-RES,U 10K-1/16W J HASC1M CX-NSZ809
X FUNC/E.VR R 0608 88-108-103-080 0E C-RES,U 10K-1/16W J HASC1M CX-NSZ809
X FUNC/E.VR R 0609 88-108-562-080 0E C-RES,U 5.6K-1/16W J HASC1M CX-NSZ809
X FUNC/E.VR R 0610 88-121-562-080 0E RES,5.6K-1/8W J HASC1M CX-NSZ809
X FUNC/E.VR R 0611 88-108-183-080 0E C-RES,U 18K-1/16W J HASC1M CX-NSZ809
X FUNC/E.VR R 0612 88-108-183-080 0E C-RES,U 18K-1/16W J HASC1M CX-NSZ809
X FUNC/E.VR R 0613 88-121-472-080 0E RES,4.7K-1/8W J HASC1M CX-NSZ809
X FUNC/E.VR R 0614 88-121-472-080 0E RES,4.7K-1/8W J HASC1M CX-NSZ809
X FUNC/E.VR R 0615 88-108-183-080 0E C-RES,U 18K-1/16W J HASC1M CX-NSZ809
X FUNC/E.VR R 0616 88-108-183-080 0E C-RES,U 18K-1/16W J HASC1M CX-NSZ809
X FUNC/E.VR R 0618 88-108-332-080 0E C-RES,U 3.3K-1/16W J HASC1M CX-NSZ809
X FUNC/E.VR R 0621 88-108-824-080 0E C-RES,U 820K-1/16W J HASC1M CX-NSZ809
X FUNC/E.VR R 0622 88-108-824-080 0E C-RES,U 820K-1/16W J HASC1M CX-NSZ809
X FUNC/E.VR R 0625 88-121-472-080 0E RES,4.7K-1/8W J HASC1M CX-NSZ809
X FUNC/E.VR R 0626 88-121-103-080 0E RES,10K-1/8W J HASC1M CX-NSZ809
X FUNC/E.VR R 0627 88-108-123-080 0E C-RES,U 12K-1/16W J HASC1M CX-NSZ809

 4 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
X FUNC/E.VR R 0628 88-121-332-080 0E RES,3.3K-1/8W J HASC1M CX-NSZ809
X FUNC/E.VR R 0631 88-108-104-080 0E C-RES,U 100K-1/16W J HASC1M CX-NSZ809
X FUNC/E.VR R 0632 88-108-682-080 0E C-RES,U 6.8K-1/16W J HASC1M CX-NSZ809
X FUNC/E.VR R 0634 88-108-273-080 0E C-RES,U 27K-1/16W J HASC1M CX-NSZ809
X FUNC/E.VR R 0635 88-108-273-080 0E C-RES,U 27K-1/16W J HASC1M CX-NSZ809
X FUNC/E.VR R 0637 88-108-332-080 0E C-RES,U 3.3K-1/16W J HASC1M CX-NSZ809
X FUNC/E.VR R 0638 88-108-332-080 0E C-RES,U 3.3K-1/16W J HASC1M CX-NSZ809
X FUNC/E.VR R 0639 88-108-273-080 0E C-RES,U 27K-1/16W J HASC1M CX-NSZ809
X FUNC/E.VR R 0640 88-108-273-080 0E C-RES,U 27K-1/16W J HASC1M CX-NSZ809
X FUNC/E.VR R 0653 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X FUNC/E.VR R 0654 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X FUNC/E.VR R 0661 88-108-153-080 0E C-RES,U 15K-1/16W J HASC1M CX-NSZ809
X FUNC/E.VR R 0662 88-108-153-080 0E C-RES,U 15K-1/16W J HASC1M CX-NSZ809
X FUNC/E.VR R 0671 88-121-273-080 0E RES,27K-1/8W J HASC1M CX-NSZ809
X FUNC/E.VR R 0672 88-121-273-080 0E RES,27K-1/8W J HASC1M CX-NSZ809
X FUNC/E.VR.LOCAL F 0602 88-100-000-010 0E PLATING-JW, 0.58 SN95 HASC1M CX-NSZ809
O KNO 8 -NF7-012-010 1A KNO ,RTRY VOL HASC1M CX-NSZ809
O KNO 8 -NF7-012-010 1A KNO ,RTRY VOL LHSKM CX-SNSZ809
O KNO 8 -NF7-013-010 0E KNO ,RTRY JOG HASC1M CX-NSZ809
O KNO 8 -NF7-013-010 0E KNO ,RTRY JOG LHSKM CX-SNSZ809
O KNO 8 -NF7-014-010 0E KNO ,RTRY MIC HASC1M CX-NSZ809
O KNO 8 -NF7-014-010 0E KNO ,RTRY MIC LHSKM CX-SNSZ809
O KNO 8 -NF7-015-010 1A KEY,ASSY POWER HASC1M CX-NSZ809
O KNO 8 -NF7-015-010 1A KEY,ASSY POWER LHSKM CX-SNSZ809
X KNO 8 -NF7-016-010 -- KEY,POWER HASC1M CX-NSZ809
X KNO 8 -NF7-016-010 -- KEY,POWER LHSKM CX-SNSZ809
X KNO 8 -NF7-017-010 -- REFLECTOR,ECO HASC1M CX-NSZ809
X KNO 8 -NF7-017-010 -- REFLECTOR,ECO LHSKM CX-SNSZ809
X KNO 8 -NF7-020-010 -- TN,CD OPEN HASC1M CX-NSZ809
X KNO 8 -NF7-020-010 -- TN,CD OPEN LHSKM CX-SNSZ809
X KNO 8 -NF7-021-010 -- TN,PANEL OPEN HASC1M CX-NSZ809
X KNO 8 -NF7-021-010 -- TN,PANEL OPEN LHSKM CX-SNSZ809
O KNO 8 -NF7-022-010 1 KEY,ASSY OPE REV HASC1M CX-NSZ809
O KNO 8 -NF7-022-010 1 KEY,ASSY OPE REV LHSKM CX-SNSZ809
X KNO 8 -NF7-023-010 -- KEY,OPE HASC1M CX-NSZ809
X KNO 8 -NF7-023-010 -- KEY,OPE LHSKM CX-SNSZ809
X KNO 8 -NF7-024-010 -- CAP, OPE REV HASC1M CX-NSZ809
X KNO 8 -NF7-024-010 -- CAP, OPE REV LHSKM CX-SNSZ809
X KNO 8 -NF7-025-010 -- SH,OPE HASC1M CX-NSZ809
X KNO 8 -NF7-025-010 -- SH,OPE LHSKM CX-SNSZ809
O KNO 8 -NF7-026-010 1A KEY,ASSY PANORAMA HASC1M CX-NSZ809
O KNO 8 -NF7-026-010 1A KEY,ASSY PANORAMA LHSKM CX-SNSZ809
X KNO 8 -NF7-027-010 -- TN,PANORAMA HASC1M CX-NSZ809
X KNO 8 -NF7-027-010 -- TN,PANORAMA LHSKM CX-SNSZ809
X KNO 8 -NF7-028-010 -- SH,PANORAMA HASC1M CX-NSZ809
X KNO 8 -NF7-028-010 -- SH,PANORAMA LHSKM CX-SNSZ809
O KNO 8 -NF7-029-010 1A KEY, E HASC1M CX-NSZ809
O KNO 8 -NF7-029-010 1A KEY, E LHSKM CX-SNSZ809
O KNO 8 -NF7-030-010 0E KEY,CD HASC1M CX-NSZ809
O KNO 8 -NF7-030-010 0E KEY,CD LHSKM CX-SNSZ809
O KNO 8 -NF7-031-010 0E KEY,ENTER HASC1M CX-NSZ809
O KNO 8 -NF7-031-010 0E KEY,ENTER LHSKM CX-SNSZ809
O KNO 8 -NF7-037-010 0E KEY,PANEL HASC1M CX-NSZ809
O KNO 8 -NF7-037-010 0E KEY,PANEL LHSKM CX-SNSZ809
O KNO 8 -NF7-048-010 1 KEY,ASSY FUN 4 HASC1M CX-NSZ809
O KNO 8 -NF7-048-010 1 KEY,ASSY FUN 4 LHSKM CX-SNSZ809
X KNO 8 -NF7-049-010 -- KEY,FUN 4 HASC1M CX-NSZ809
X KNO 8 -NF7-049-010 -- KEY,FUN 4 LHSKM CX-SNSZ809
O KNO 8 -NF7-052-010 0E RING,FUN 4 HASC1M CX-NSZ809
O KNO 8 -NF7-052-010 0E RING,FUN 4 LHSKM CX-SNSZ809
O KNO 8 -NF7-055-010 1A KEY,TIMER H HASC1M CX-NSZ809
O KNO 8 -NF7-055-010 1A KEY,TIMER H LHSKM CX-SNSZ809
X KNO 8 -NF7-205-010 0E GUIDE,ECO HASC1M CX-NSZ809
X KNO 8 -NF7-205-010 0E GUIDE,ECO LHSKM CX-SNSZ809
X L L,POP 8 -NF7-970-010 0E L L,POP LHL HASC1M CX-NSZ809
X L L,POP 8 -NF7-971-010 0E L L,POP LHR HASC1M CX-NSZ809
X L L,POP 8 -NF7-974-010 -- L L,POP 809LHL LHSKM CX-SNSZ809
X L L,POP 8 -NF7-975-010 -- L L,POP 809LHR LHSKM CX-SNSZ809
X LOCAL MIC F 0502 88-100-000-010 0E PLATING-JW, 0.58 SN95 HASC1M CX-NSZ809
X LOCAL PACKING 87- 40-098-010 0E AG,PV 0.025-650-750 PL LHSKM CX-SNSZ809

 5 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
X LOCAL PACKING 8 -NF7-857-010 -- CUSHION,FRONT AR HASC1M CX-NSZ809
X LOCAL PACKING 8 -NF7-858-010 -- CUSHION,REAR AR HASC1M CX-NSZ809
X LOCAL PACKING 8 -NF7-859-010 -- CTN,PRINTED AR HASC1M CX-NSZ809
X LOCAL PACKING 8 -NF7-860-010 -- CUSHION,FRONT R LHSKM CX-SNSZ809
X LOCAL PACKING 8 -NF7-861-010 -- CUSHION,REAR R LHSKM CX-SNSZ809
X LOCAL PACKING 8 -NF7-862-010 -- CTN,PRINTED R LHSKM CX-SNSZ809
X LOCAL PACKING 93-704-337-010 1A SH,FOAMED-MAT 0.31-800-500 LHSKM CX-SNSZ809
X LOCAL PLATE 8 -NF7-057-010 -- L L,SPEC LHSK1M LHSKM CX-SNSZ809
X LOCAL PRINTED DU 87- 40-085-010 0E AG,PV 0.04-200-350 PL LHSKM CX-SNSZ809
O LOCAL PRINTED DU 8 -NF7-930-010 -- I ,HA(S)M-KIT HASC1M CX-NSZ809
O LOCAL PRINTED DU 8 -NF7-932-010 -- I ,LH(P)KIT - CCE LHSKM CX-SNSZ809
X LOCAL TUNER(IF) D 0801 88-100-000-010 0E PLATING-JW, 0.58 SN95 HASC1M CX-NSZ809
X LOCAL TUNER(RF) D 0944 88-100-000-010 0E PLATING-JW, 0.58 SN95 HASC1M CX-NSZ809
O MAC MECHA 87-067-579-010 0E VT2+3-8 W/0 SL0T HASC1M CX-NSZ809
X MAC MECHA 8 -NF7-243-010 0E HT-SINK,FET HASC1M CX-NSZ809
! O MECHANICAL 84-ZG1-267-010 0E PULLEY,LOAD MO 8 HASC1M CX-NSZ809
! O MECHANICAL 84-ZG1-267-010 0E PULLEY,LOAD MO 8 LHSKM CX-SNSZ809
O MECHANICAL 8 -NF7-210-010 0E HLDR,MECHA HASC1M CX-NSZ809
O MECHANICAL 8 -NF7-210-010 0E HLDR,MECHA LHSKM CX-SNSZ809
O MECHANICAL 8 -NF7-211-010 0E GEAR,PANEL HASC1M CX-NSZ809
O MECHANICAL 8 -NF7-211-010 0E GEAR,PANEL LHSKM CX-SNSZ809
O MECHANICAL 8 -NF7-212-010 0E GEAR,RELAY HASC1M CX-NSZ809
O MECHANICAL 8 -NF7-212-010 0E GEAR,RELAY LHSKM CX-SNSZ809
O MECHANICAL 8 -NF7-213-010 0E PULLEY,RELAY HASC1M CX-NSZ809
O MECHANICAL 8 -NF7-213-010 0E PULLEY,RELAY LHSKM CX-SNSZ809
O MECHANICAL 8 -NF7-214-010 0E ELT,SQ 1.8-113.5 HASC1M CX-NSZ809
O MECHANICAL 8 -NF7-214-010 0E ELT,SQ 1.8-113.5 LHSKM CX-SNSZ809
O MECHANICAL 8 -NF7-217-010 0E LEVER,SW HASC1M CX-NSZ809
O MECHANICAL 8 -NF7-217-010 0E LEVER,SW LHSKM CX-SNSZ809
O MECHANICAL 8 -NF7-220-010 0E SPR-T,OPEN HASC1M CX-NSZ809
O MECHANICAL 8 -NF7-220-010 0E SPR-T,OPEN LHSKM CX-SNSZ809
O MECHANICAL 8 -NF7-221-010 0E HLDR,PANEL HASC1M CX-NSZ809
O MECHANICAL 8 -NF7-221-010 0E HLDR,PANEL LHSKM CX-SNSZ809
O MECHANICAL 8 -NF7-222-010 0E HLDR,STOP HASC1M CX-NSZ809
O MECHANICAL 8 -NF7-222-010 0E HLDR,STOP LHSKM CX-SNSZ809
O MECHANICAL 8 -NF7-223-010 0E HLDR,PANEL 2 HASC1M CX-NSZ809
O MECHANICAL 8 -NF7-223-010 0E HLDR,PANEL 2 LHSKM CX-SNSZ809
X MECHANICAL 8 -NF7-224-010 1A PLATE,SHLD MOTOR HASC1M CX-NSZ809
X MECHANICAL 8 -NF7-224-010 1A PLATE,SHLD MOTOR LHSKM CX-SNSZ809
O MIC C 0502 87-012-282-080 0E C-CAP,U 4700P-50 K HASC1M CX-NSZ809
O MIC C 0503 87-010-112-040 0E CAP,E 100-16 M 11L SME HASC1M CX-NSZ809
O MIC C 0505 87-010-492-040 0E CAP,E 0.33-50 M 5L SRE HASC1M CX-NSZ809
O MIC C 0506 87-012-191-080 0E C-CAP,U 68P-50 J CH HASC1M CX-NSZ809
O MIC C 0507 87-010-545-040 0E CAP,E 0.22-50 M 11L SME HASC1M CX-NSZ809
O MIC C 0508 87-010-544-040 0E CAP,E 0.1-50 M 11L SME HASC1M CX-NSZ809
O MIC C 0510 87-012-195-080 0E C-CAP,U 100P-50 J CH HASC1M CX-NSZ809
O MIC C 0511 87-A12-065-040 0E CAP,E 33-16 SMG HASC1M CX-NSZ809
O MIC C 0512 87-012-274-080 0E C-CAP,U 1000P-50 K HASC1M CX-NSZ809
X MIC C 0513 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
O MIC C 0514 87-010-759-080 0E C-CAP,U 0.1-25 Z F HASC1M CX-NSZ809
O MIC C 0515 87-012-274-080 0E C-CAP,U 1000P-50 K HASC1M CX-NSZ809
O MIC C 0517 87-012-274-080 0E C-CAP,U 1000P-50 K HASC1M CX-NSZ809
O MIC C 0518 87-010-759-080 0E C-CAP,U 0.1-25 Z F HASC1M CX-NSZ809
O MIC C 0520 87-012-273-080 0E C-CAP,U 820P-50 K HASC1M CX-NSZ809
O MIC C 0531 87-010-805-080 0E C-CAP,S 1-16 Z F HASC1M CX-NSZ809
S MIC D 0531 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S MIC D 0532 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
O MIC F 0501 87-A90-896-080 0E F- EAD, 035600STY7 HASC1M CX-NSZ809
O MIC J 0502 87-A61-242-010 1A JACK,6.3 LK MONO W/SW V KM HASC1M CX-NSZ809
X MIC JR 0503 88-129-000-080 0E C-JUMPER,3216 HASC1M CX-NSZ809
S MIC Q 0503 87-A30-076-080 0E C-TR,2SC3052F HASC1M CX-NSZ809
S MIC Q 0504 87-A30-075-080 0E C-TR,2SA1235F HASC1M CX-NSZ809
S MIC Q 0505 87-A30-076-080 0E C-TR,2SC3052F HASC1M CX-NSZ809
S MIC Q 0506 87-A30-075-080 0E C-TR,2SA1235F HASC1M CX-NSZ809
S MIC Q 0531 87-A30-087-080 0E C-FET,2SK2158 HASC1M CX-NSZ809
X MIC R 0502 88-108-472-080 0E C-RES,U 4.7K-1/16W J HASC1M CX-NSZ809
X MIC R 0503 88-108-222-080 0E C-RES,U 2.2K-1/16W J HASC1M CX-NSZ809
X MIC R 0504 88-108-102-080 0E C-RES,U 1K-1/16W J HASC1M CX-NSZ809
X MIC R 0505 88-108-224-080 0E C-RES,U 220K-1/16W J HASC1M CX-NSZ809
X MIC R 0506 88-108-223-080 0E C-RES,U 22K-1/16W J HASC1M CX-NSZ809

 6 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
X MIC R 0508 88-108-332-080 0E C-RES,U 3.3K-1/16W J HASC1M CX-NSZ809
X MIC R 0511 88-108-273-080 0E C-RES,U 27K-1/16W J HASC1M CX-NSZ809
X MIC R 0512 88-108-103-080 0E C-RES,U 10K-1/16W J HASC1M CX-NSZ809
X MIC R 0513 88-108-394-080 0E C-RES,U 390K-1/16W J HASC1M CX-NSZ809
X MIC R 0514 88-108-561-080 0E C-RES,U 560-1/16W J HASC1M CX-NSZ809
X MIC R 0515 88-108-332-080 0E C-RES,U 3.3K-1/16W J HASC1M CX-NSZ809
X MIC R 0516 88-108-330-080 0E C-RES,U 33-1/16W J HASC1M CX-NSZ809
X MIC R 0517 88-128-101-080 0E C-RES, 100-1/8W J HASC1M CX-NSZ809
X MIC R 0518 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X MIC R 0520 88-108-472-080 0E C-RES,U 4.7K-1/16W J HASC1M CX-NSZ809
X MIC R 0531 88-108-562-080 0E C-RES,U 5.6K-1/16W J HASC1M CX-NSZ809
X MIC R 0532 88-108-104-080 0E C-RES,U 100K-1/16W J HASC1M CX-NSZ809
O MIC VR 0501 87-N 7-602-010 1A VR,RTRY 10KAX1 1 V HASC1M CX-NSZ809
X MICON * 8 -NF7-601-110 1E PW ,COM I FRONT HASC1M CX-NSZ809
X MICON * 8 -NF7-602-110 -- PW ,FRONT HASC1M CX-NSZ809
X MICON * 8 -NF7-603-110 -- PW ,M-OP-PANEL HASC1M CX-NSZ809
X MICON * 8 -NF7-604-110 -- PW ,S-OP-PANEL HASC1M CX-NSZ809
X MICON * 8 -NF7-605-110 -- PW ,MOTOR HASC1M CX-NSZ809
X MICON * 8 -NF7-606-110 -- PW , OX SW HASC1M CX-NSZ809
O MICON C 0039 87-A10-039-080 0E C-CAP,U 470P-50 J CH HASC1M CX-NSZ809
O MICON C 0040 87-012-195-080 0E C-CAP,U 100P-50 J CH HASC1M CX-NSZ809
O MICON C 0041 87-012-195-080 0E C-CAP,U 100P-50 J CH HASC1M CX-NSZ809
O MICON C 0042 87-012-195-080 0E C-CAP,U 100P-50 J CH HASC1M CX-NSZ809
O MICON C 0043 87-012-195-080 0E C-CAP,U 100P-50 J CH HASC1M CX-NSZ809
O MICON C 0044 87-012-195-080 0E C-CAP,U 100P-50 J CH HASC1M CX-NSZ809
O MICON C 0045 87-012-195-080 0E C-CAP,U 100P-50 J CH HASC1M CX-NSZ809
O MICON C 0046 87-012-195-080 0E C-CAP,U 100P-50 J CH HASC1M CX-NSZ809
O MICON C 0047 87-012-195-080 0E C-CAP,U 100P-50 J CH HASC1M CX-NSZ809
O MICON C 0048 87-012-199-080 0E C-CAP,U 220P-50 J CH HASC1M CX-NSZ809
O MICON C 0049 87-012-267-080 0E C-CAP,U 270P-50 K GRM HASC1M CX-NSZ809
O MICON C 0050 87-012-267-080 0E C-CAP,U 270P-50 K GRM HASC1M CX-NSZ809
O MICON C 0141 87-012-278-080 0E C-CAP,U 2200P-50 K HASC1M CX-NSZ809
O MICON C 0142 87-010-785-080 0E C-CAP,U 0.015-25 K GRM HASC1M CX-NSZ809
O MICON C 0153 87-A11-058-080 0E C-CAP,U 0.22-10 K HASC1M CX-NSZ809
O MICON C 0154 87-A10-189-040 0E CAP,E 220-10 M 5L HASC1M CX-NSZ809
O MICON C 0155 87-012-176-080 0E C-CAP,U 15P-50 J CH HASC1M CX-NSZ809
O MICON C 0156 87-012-198-080 0E C-CAP,U 180P-50 J CH HASC1M CX-NSZ809
O MICON C 0158 87-A10-039-080 0E C-CAP,U 470P-50 J CH HASC1M CX-NSZ809
O MICON C 0161 87-012-274-080 0E C-CAP,U 1000P-50 K HASC1M CX-NSZ809
O MICON C 0162 87-012-274-080 0E C-CAP,U 1000P-50 K HASC1M CX-NSZ809
O MICON C 0165 87-012-268-080 0E C-CAP,U 330P-50 K GRM HASC1M CX-NSZ809
O MICON C 0166 87-010-552-040 0E CAP,E 22-16 M 5L SRE HASC1M CX-NSZ809
O MICON C 0171 87-012-369-080 0E C-CAP,S 0.047-50 Z F HASC1M CX-NSZ809
O MICON C 0172 87-010-408-040 0E CAP,E 47-50 M 11L SME HASC1M CX-NSZ809
O MICON C 0173 87-010-421-040 0E CAP,E 4.7-50 M 5L SRE HASC1M CX-NSZ809
O MICON C 0174 87-010-421-040 0E CAP,E 4.7-50 M 5L SRE HASC1M CX-NSZ809
O MICON C 0180 87-010-759-080 0E C-CAP,U 0.1-25 Z F HASC1M CX-NSZ809
O MICON C 0185 87-010-759-080 0E C-CAP,U 0.1-25 Z F HASC1M CX-NSZ809
O MICON C 0186 87-012-274-080 0E C-CAP,U 1000P-50 K HASC1M CX-NSZ809
O MICON C 0188 87-012-369-080 0E C-CAP,S 0.047-50 Z F HASC1M CX-NSZ809
O MICON C 0191 87-012-286-080 0E C-CAP,U 0.01-25 K HASC1M CX-NSZ809
O MICON C 0192 87-010-759-080 0E C-CAP,U 0.1-25 Z F HASC1M CX-NSZ809
O MICON C 0251 87-010-260-040 0E CAP,E 47-25 M 11L SME HASC1M CX-NSZ809
O MICON C 0315 87-010-759-080 0E C-CAP,U 0.1-25 Z F HASC1M CX-NSZ809
O MICON C 0391 87-012-274-080 0E C-CAP,U 1000P-50 K HASC1M CX-NSZ809
O MICON C 0392 87-012-199-080 0E C-CAP,U 220P-50 J CH HASC1M CX-NSZ809
O MICON C 0451 87-010-759-080 0E C-CAP,U 0.1-25 Z F HASC1M CX-NSZ809
O MICON C 0452 87-010-759-080 0E C-CAP,U 0.1-25 Z F HASC1M CX-NSZ809
O MICON C 0453 87-010-759-080 0E C-CAP,U 0.1-25 Z F HASC1M CX-NSZ809
O MICON C 0454 87-010-759-080 0E C-CAP,U 0.1-25 Z F HASC1M CX-NSZ809
O MICON C 0455 87-010-759-080 0E C-CAP,U 0.1-25 Z F HASC1M CX-NSZ809
! O MICON CN 0101 87-099-720-010 1 CONN,30P LK TYK- (P) HASC1M CX-NSZ809
! O MICON CN 0103 87-099-196-010 0E CONN,8P V LK 6216 HASC1M CX-NSZ809
! O MICON CN 0201 87-099-017-010 0E CONN,15P V LK 6216 HASC1M CX-NSZ809
! O MICON CN 0301 87-099-209-010 0E CONN,4P H LK 6216 HASC1M CX-NSZ809
! O MICON CN 0302 87-A60-083-010 0E CONN,04P H 9604S-04F HASC1M CX-NSZ809
! O MICON CN 0303 87-099-209-010 0E CONN,4P H LK 6216 HASC1M CX-NSZ809
! O MICON CN 0304 87-099-209-010 0E CONN,4P H LK 6216 HASC1M CX-NSZ809
! O MICON CN 0911 87-099-212-010 0E CONN,5P V LK 6216 HASC1M CX-NSZ809
! O MICON CN 0912 87-099-210-010 0E CONN,5P H LK 6216 HASC1M CX-NSZ809

 7 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
O MICON CNA0901 8 -NF7-620-010 0E CONN ASSY,3P V 120MM HASC1M CX-NSZ809
S MICON D 0101 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S MICON D 0142 87-A40-748-080 0E ZENER,UZ5.6 SA HASC1M CX-NSZ809
S MICON D 0143 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S MICON D 0144 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S MICON D 0151 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S MICON D 0163 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S MICON D 0251 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S MICON D 0252 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S MICON D 0331 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S MICON D 0332 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S MICON D 0333 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S MICON D 0336 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S MICON D 0340 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S MICON D 0342 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S MICON D 0345 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S MICON D 0351 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S MICON D 0352 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S MICON D 0353 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S MICON D 0354 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S MICON D 0355 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S MICON D 0356 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S MICON D 0357 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S MICON D 0358 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S MICON D 0359 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S MICON D 0360 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S MICON D 0361 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S MICON D 0362 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S MICON D 0363 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S MICON D 0364 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S MICON D 0365 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S MICON D 0366 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S MICON D 0452 87-A40-802-080 0E ZENER,UZ5.1 SC HASC1M CX-NSZ809
S MICON D 0453 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S MICON D 0454 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S MICON D 0455 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S MICON D 0456 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
O MICON FL 0401 8 -NF7-621-010 2 FL, J815GNK HASC1M CX-NSZ809
S MICON IC 0101 8 -NF7-631-130 2A C-IC,LC866560W-5V19 HASC1M CX-NSZ809
S MICON IC 0161 87-A21-831-010 1 IC,SPS-442-1-F1 HASC1M CX-NSZ809
S MICON IC 0452 87-A21-023-040 1C C-IC, A3835F HASC1M CX-NSZ809
X MICON JR 0121 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X MICON JR 0123 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X MICON JR 0161 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X MICON JR 0162 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X MICON JR 0181 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X MICON JR 0183 88-129-000-080 0E C-JUMPER,3216 HASC1M CX-NSZ809
X MICON JR 0184 88-129-000-080 0E C-JUMPER,3216 HASC1M CX-NSZ809
X MICON JR 0185 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X MICON JR 0186 88-129-000-080 0E C-JUMPER,3216 HASC1M CX-NSZ809
X MICON JR 0187 88-129-000-080 0E C-JUMPER,3216 HASC1M CX-NSZ809
X MICON JR 0188 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X MICON JR 0189 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X MICON JR 0190 88-129-000-080 0E C-JUMPER,3216 HASC1M CX-NSZ809
X MICON JR 0191 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X MICON JR 0192 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X MICON JR 0193 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X MICON JR 0194 88-129-000-080 0E C-JUMPER,3216 HASC1M CX-NSZ809
X MICON JR 0195 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X MICON JR 0196 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X MICON JR 0197 88-129-000-080 0E C-JUMPER,3216 HASC1M CX-NSZ809
X MICON JR 0201 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X MICON JR 0202 88-129-000-080 0E C-JUMPER,3216 HASC1M CX-NSZ809
X MICON JR 0301 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X MICON JR 0302 88-129-000-080 0E C-JUMPER,3216 HASC1M CX-NSZ809
X MICON JR 0331 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X MICON JR 0350 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X MICON JR 0352 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X MICON JR 0354 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X MICON JR 0356 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809

 8 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
X MICON JR 0358 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X MICON JR 0360 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X MICON JR 0362 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X MICON JR 0364 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X MICON JR 0369 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X MICON JR 0401 88-129-000-080 0E C-JUMPER,3216 HASC1M CX-NSZ809
X MICON JR 0402 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X MICON JR 0403 88-129-000-080 0E C-JUMPER,3216 HASC1M CX-NSZ809
X MICON JR 0451 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X MICON JR 0902 88-129-000-080 0E C-JUMPER,3216 HASC1M CX-NSZ809
X MICON JR 0903 88-129-000-080 0E C-JUMPER,3216 HASC1M CX-NSZ809
X MICON JR 0904 88-129-000-080 0E C-JUMPER,3216 HASC1M CX-NSZ809
O MICON L 0151 87-A50-656-010 0E COIL,CLK 5.76MHZ (TOKO)7KLY HASC1M CX-NSZ809
O MICON LED0401 87-A40-791-040 0E LED,LTL-307E RED HASC1M CX-NSZ809
O MICON LED0402 87-017-756-040 0E LED,SLR-342DCT31 ORN HASC1M CX-NSZ809
S MICON Q 0141 87-026-609-080 0E TR,KTA1266GR HASC1M CX-NSZ809
S MICON Q 0151 87-A30-087-080 0E C-FET,2SK2158 HASC1M CX-NSZ809
S MICON Q 0153 87-A30-490-080 0E C-TR,KRC107S HASC1M CX-NSZ809
S MICON Q 0154 87-A30-076-080 0E C-TR,2SC3052F HASC1M CX-NSZ809
S MICON Q 0155 87-A30-076-080 0E C-TR,2SC3052F HASC1M CX-NSZ809
S MICON Q 0157 87-026-610-080 0E TR,KTC3198GR HASC1M CX-NSZ809
S MICON Q 0158 87-A30-484-080 0E C-TR,KRA102S HASC1M CX-NSZ809
S MICON Q 0171 87-A30-074-080 0E C-TR,RT1P 141C HASC1M CX-NSZ809
S MICON Q 0252 87-A30-582-080 0E TR,CDA1585 C HASC1M CX-NSZ809
S MICON Q 0253 87-A30-495-080 0E TR,2SA1981Y HASC1M CX-NSZ809
S MICON Q 0254 87-A30-495-080 0E TR,2SA1981Y HASC1M CX-NSZ809
S MICON Q 0901 87-A30-520-080 0E TR,2SC5342Y HASC1M CX-NSZ809
S MICON Q 0902 87-A30-520-080 0E TR,2SC5342Y HASC1M CX-NSZ809
S MICON Q 0903 87-A30-515-080 0E TR,2SA1979O/Y HASC1M CX-NSZ809
S MICON Q 0904 87-A30-515-080 0E TR,2SA1979O/Y HASC1M CX-NSZ809
X MICON R 0004 88-108-104-080 0E C-RES,U 100K-1/16W J HASC1M CX-NSZ809
X MICON R 0005 88-108-104-080 0E C-RES,U 100K-1/16W J HASC1M CX-NSZ809
X MICON R 0006 88-108-104-080 0E C-RES,U 100K-1/16W J HASC1M CX-NSZ809
X MICON R 0007 88-108-104-080 0E C-RES,U 100K-1/16W J HASC1M CX-NSZ809
X MICON R 0008 88-108-104-080 0E C-RES,U 100K-1/16W J HASC1M CX-NSZ809
X MICON R 0009 88-108-104-080 0E C-RES,U 100K-1/16W J HASC1M CX-NSZ809
X MICON R 0010 88-108-104-080 0E C-RES,U 100K-1/16W J HASC1M CX-NSZ809
X MICON R 0011 88-108-104-080 0E C-RES,U 100K-1/16W J HASC1M CX-NSZ809
X MICON R 0012 88-108-104-080 0E C-RES,U 100K-1/16W J HASC1M CX-NSZ809
X MICON R 0013 88-108-104-080 0E C-RES,U 100K-1/16W J HASC1M CX-NSZ809
X MICON R 0014 88-108-104-080 0E C-RES,U 100K-1/16W J HASC1M CX-NSZ809
X MICON R 0015 88-108-104-080 0E C-RES,U 100K-1/16W J HASC1M CX-NSZ809
X MICON R 0016 88-108-104-080 0E C-RES,U 100K-1/16W J HASC1M CX-NSZ809
X MICON R 0017 88-108-104-080 0E C-RES,U 100K-1/16W J HASC1M CX-NSZ809
X MICON R 0018 88-108-104-080 0E C-RES,U 100K-1/16W J HASC1M CX-NSZ809
X MICON R 0020 88-108-154-080 0E C-RES,U 150K-1/16W J HASC1M CX-NSZ809
X MICON R 0040 88-108-154-080 0E C-RES,U 150K-1/16W J HASC1M CX-NSZ809
X MICON R 0045 88-108-104-080 0E C-RES,U 100K-1/16W J HASC1M CX-NSZ809
X MICON R 0046 88-108-104-080 0E C-RES,U 100K-1/16W J HASC1M CX-NSZ809
X MICON R 0047 88-108-104-080 0E C-RES,U 100K-1/16W J HASC1M CX-NSZ809
X MICON R 0048 88-108-104-080 0E C-RES,U 100K-1/16W J HASC1M CX-NSZ809
X MICON R 0049 88-108-104-080 0E C-RES,U 100K-1/16W J HASC1M CX-NSZ809
X MICON R 0050 88-108-104-080 0E C-RES,U 100K-1/16W J HASC1M CX-NSZ809
X MICON R 0051 88-108-104-080 0E C-RES,U 100K-1/16W J HASC1M CX-NSZ809
X MICON R 0052 88-108-101-080 0E C-RES,U 100-1/16W J HASC1M CX-NSZ809
X MICON R 0053 88-108-101-080 0E C-RES,U 100-1/16W J HASC1M CX-NSZ809
X MICON R 0054 88-108-101-080 0E C-RES,U 100-1/16W J HASC1M CX-NSZ809
X MICON R 0055 88-108-101-080 0E C-RES,U 100-1/16W J HASC1M CX-NSZ809
X MICON R 0101 88-108-102-080 0E C-RES,U 1K-1/16W J HASC1M CX-NSZ809
X MICON R 0102 88-108-102-080 0E C-RES,U 1K-1/16W J HASC1M CX-NSZ809
X MICON R 0103 88-108-102-080 0E C-RES,U 1K-1/16W J HASC1M CX-NSZ809
X MICON R 0104 88-121-102-080 0E RES,1K-1/8W J HASC1M CX-NSZ809
X MICON R 0105 88-108-102-080 0E C-RES,U 1K-1/16W J HASC1M CX-NSZ809
X MICON R 0106 88-108-102-080 0E C-RES,U 1K-1/16W J HASC1M CX-NSZ809
X MICON R 0107 88-108-102-080 0E C-RES,U 1K-1/16W J HASC1M CX-NSZ809
X MICON R 0108 88-108-102-080 0E C-RES,U 1K-1/16W J HASC1M CX-NSZ809
X MICON R 0119 88-108-474-080 0E C-RES,U 470K-1/16W J HASC1M CX-NSZ809
X MICON R 0120 88-121-474-080 0E RES,470K-1/8W J HASC1M CX-NSZ809
X MICON R 0124 88-108-102-080 0E C-RES,U 1K-1/16W J HASC1M CX-NSZ809
X MICON R 0125 88-108-102-080 0E C-RES,U 1K-1/16W J HASC1M CX-NSZ809

 9 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
X MICON R 0126 88-108-102-080 0E C-RES,U 1K-1/16W J HASC1M CX-NSZ809
X MICON R 0127 88-108-102-080 0E C-RES,U 1K-1/16W J HASC1M CX-NSZ809
X MICON R 0128 88-108-223-080 0E C-RES,U 22K-1/16W J HASC1M CX-NSZ809
X MICON R 0129 88-108-101-080 0E C-RES,U 100-1/16W J HASC1M CX-NSZ809
X MICON R 0130 88-108-101-080 0E C-RES,U 100-1/16W J HASC1M CX-NSZ809
X MICON R 0131 88-108-102-080 0E C-RES,U 1K-1/16W J HASC1M CX-NSZ809
X MICON R 0133 88-108-101-080 0E C-RES,U 100-1/16W J HASC1M CX-NSZ809
X MICON R 0134 88-108-101-080 0E C-RES,U 100-1/16W J HASC1M CX-NSZ809
X MICON R 0135 88-108-101-080 0E C-RES,U 100-1/16W J HASC1M CX-NSZ809
X MICON R 0136 88-129-000-080 0E C-JUMPER,3216 HASC1M CX-NSZ809
X MICON R 0137 88-129-000-080 0E C-JUMPER,3216 HASC1M CX-NSZ809
X MICON R 0138 88-121-100-080 0E RES,10-1/8W J HASC1M CX-NSZ809
X MICON R 0139 88-108-472-080 0E C-RES,U 4.7K-1/16W J HASC1M CX-NSZ809
X MICON R 0141 88-108-103-080 0E C-RES,U 10K-1/16W J HASC1M CX-NSZ809
X MICON R 0142 88-108-104-080 0E C-RES,U 100K-1/16W J HASC1M CX-NSZ809
X MICON R 0143 88-108-472-080 0E C-RES,U 4.7K-1/16W J HASC1M CX-NSZ809
X MICON R 0144 88-108-102-080 0E C-RES,U 1K-1/16W J HASC1M CX-NSZ809
X MICON R 0145 88-128-471-080 0E C-RES, 470-1/8W J HASC1M CX-NSZ809
X MICON R 0146 88-108-153-080 0E C-RES,U 15K-1/16W J HASC1M CX-NSZ809
X MICON R 0152 88-108-153-080 0E C-RES,U 15K-1/16W J HASC1M CX-NSZ809
X MICON R 0153 88-108-333-080 0E C-RES,U 33K-1/16W J HASC1M CX-NSZ809
X MICON R 0154 88-108-103-080 0E C-RES,U 10K-1/16W J HASC1M CX-NSZ809
X MICON R 0155 88-108-224-080 0E C-RES,U 220K-1/16W J HASC1M CX-NSZ809
X MICON R 0156 88-108-101-080 0E C-RES,U 100-1/16W J HASC1M CX-NSZ809
X MICON R 0157 88-108-224-080 0E C-RES,U 220K-1/16W J HASC1M CX-NSZ809
X MICON R 0158 88-108-124-080 0E C-RES,U 120K-1/16W J HASC1M CX-NSZ809
X MICON R 0159 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X MICON R 0161 88-108-104-080 0E C-RES,U 100K-1/16W J HASC1M CX-NSZ809
X MICON R 0162 88-108-104-080 0E C-RES,U 100K-1/16W J HASC1M CX-NSZ809
X MICON R 0165 88-108-563-080 0E C-RES,U 56K-1/16W J HASC1M CX-NSZ809
X MICON R 0166 88-128-101-080 0E C-RES, 100-1/8W J HASC1M CX-NSZ809
X MICON R 0171 88-121-102-080 0E RES,1K-1/8W J HASC1M CX-NSZ809
X MICON R 0172 88-121-472-080 0E RES,4.7K-1/8W J HASC1M CX-NSZ809
X MICON R 0173 88-121-100-080 0E RES,10-1/8W J HASC1M CX-NSZ809
X MICON R 0174 88-121-472-080 0E RES,4.7K-1/8W J HASC1M CX-NSZ809
X MICON R 0175 88-128-102-080 0E C-RES, 1K-1/8W J HASC1M CX-NSZ809
X MICON R 0177 88-121-223-080 0E RES,22K-1/8W J HASC1M CX-NSZ809
X MICON R 0178 88-121-222-080 0E RES,2.2K-1/8W J HASC1M CX-NSZ809
X MICON R 0186 88-108-683-080 0E C-RES,U 68K-1/16W J HASC1M CX-NSZ809
X MICON R 0187 88-108-104-080 0E C-RES,U 100K-1/16W J HASC1M CX-NSZ809
X MICON R 0188 88-121-104-080 0E RES,100K-1/8W J HASC1M CX-NSZ809
X MICON R 0200 88-121-104-080 0E RES,100K-1/8W J HASC1M CX-NSZ809
X MICON R 0201 88-129-000-080 0E C-JUMPER,3216 HASC1M CX-NSZ809
X MICON R 0203 88-129-000-080 0E C-JUMPER,3216 HASC1M CX-NSZ809
X MICON R 0252 88-108-103-080 0E C-RES,U 10K-1/16W J HASC1M CX-NSZ809
X MICON R 0253 88-108-102-080 0E C-RES,U 1K-1/16W J HASC1M CX-NSZ809
X MICON R 0256 88-108-473-080 0E C-RES,U 47K-1/16W J HASC1M CX-NSZ809
X MICON R 0257 88-108-222-080 0E C-RES,U 2.2K-1/16W J HASC1M CX-NSZ809
X MICON R 0258 88-108-103-080 0E C-RES,U 10K-1/16W J HASC1M CX-NSZ809
X MICON R 0259 88-108-222-080 0E C-RES,U 2.2K-1/16W J HASC1M CX-NSZ809
X MICON R 0260 88-108-103-080 0E C-RES,U 10K-1/16W J HASC1M CX-NSZ809
X MICON R 0261 88-108-473-080 0E C-RES,U 47K-1/16W J HASC1M CX-NSZ809
X MICON R 0262 88-108-473-080 0E C-RES,U 47K-1/16W J HASC1M CX-NSZ809
X MICON R 0264 88-108-473-080 0E C-RES,U 47K-1/16W J HASC1M CX-NSZ809
X MICON R 0266 88-108-473-080 0E C-RES,U 47K-1/16W J HASC1M CX-NSZ809
X MICON R 0267 88-108-473-080 0E C-RES,U 47K-1/16W J HASC1M CX-NSZ809
X MICON R 0300 88-108-103-080 0E C-RES,U 10K-1/16W J HASC1M CX-NSZ809
X MICON R 0301 88-108-102-080 0E C-RES,U 1K-1/16W J HASC1M CX-NSZ809
X MICON R 0302 88-121-821-080 0E RES,820-1/8W J HASC1M CX-NSZ809
X MICON R 0303 88-108-102-080 0E C-RES,U 1K-1/16W J HASC1M CX-NSZ809
X MICON R 0304 88-108-122-080 0E C-RES,U 1.2K-1/16W J HASC1M CX-NSZ809
X MICON R 0305 88-108-122-080 0E C-RES,U 1.2K-1/16W J HASC1M CX-NSZ809
X MICON R 0306 88-108-182-080 0E C-RES,U 1.8K-1/16W J HASC1M CX-NSZ809
X MICON R 0307 88-108-182-080 0E C-RES,U 1.8K-1/16W J HASC1M CX-NSZ809
X MICON R 0315 88-108-104-080 0E C-RES,U 100K-1/16W J HASC1M CX-NSZ809
X MICON R 0320 88-108-103-080 0E C-RES,U 10K-1/16W J HASC1M CX-NSZ809
X MICON R 0321 88-108-102-080 0E C-RES,U 1K-1/16W J HASC1M CX-NSZ809
X MICON R 0322 88-108-821-080 0E C-RES,U 820-1/16W J HASC1M CX-NSZ809
X MICON R 0323 88-108-102-080 0E C-RES,U 1K-1/16W J HASC1M CX-NSZ809
X MICON R 0324 88-108-122-080 0E C-RES,U 1.2K-1/16W J HASC1M CX-NSZ809

 10 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
X MICON R 0325 88-108-122-080 0E C-RES,U 1.2K-1/16W J HASC1M CX-NSZ809
X MICON R 0326 88-108-182-080 0E C-RES,U 1.8K-1/16W J HASC1M CX-NSZ809
X MICON R 0327 88-108-182-080 0E C-RES,U 1.8K-1/16W J HASC1M CX-NSZ809
X MICON R 0328 88-121-332-080 0E RES,3.3K-1/8W J HASC1M CX-NSZ809
X MICON R 0329 88-108-472-080 0E C-RES,U 4.7K-1/16W J HASC1M CX-NSZ809
X MICON R 0330 88-108-682-080 0E C-RES,U 6.8K-1/16W J HASC1M CX-NSZ809
X MICON R 0331 88-108-103-080 0E C-RES,U 10K-1/16W J HASC1M CX-NSZ809
X MICON R 0332 88-108-183-080 0E C-RES,U 18K-1/16W J HASC1M CX-NSZ809
X MICON R 0335 88-108-272-080 0E C-RES,U 2.7K-1/16W J HASC1M CX-NSZ809
X MICON R 0340 88-108-103-080 0E C-RES,U 10K-1/16W J HASC1M CX-NSZ809
X MICON R 0341 88-108-102-080 0E C-RES,U 1K-1/16W J HASC1M CX-NSZ809
X MICON R 0342 88-108-821-080 0E C-RES,U 820-1/16W J HASC1M CX-NSZ809
X MICON R 0343 88-108-102-080 0E C-RES,U 1K-1/16W J HASC1M CX-NSZ809
X MICON R 0344 88-108-122-080 0E C-RES,U 1.2K-1/16W J HASC1M CX-NSZ809
X MICON R 0345 88-108-122-080 0E C-RES,U 1.2K-1/16W J HASC1M CX-NSZ809
X MICON R 0346 88-108-182-080 0E C-RES,U 1.8K-1/16W J HASC1M CX-NSZ809
X MICON R 0347 88-108-182-080 0E C-RES,U 1.8K-1/16W J HASC1M CX-NSZ809
X MICON R 0348 88-108-272-080 0E C-RES,U 2.7K-1/16W J HASC1M CX-NSZ809
X MICON R 0349 88-108-332-080 0E C-RES,U 3.3K-1/16W J HASC1M CX-NSZ809
X MICON R 0350 88-108-472-080 0E C-RES,U 4.7K-1/16W J HASC1M CX-NSZ809
X MICON R 0351 88-108-682-080 0E C-RES,U 6.8K-1/16W J HASC1M CX-NSZ809
X MICON R 0371 88-108-152-080 0E C-RES,U 1.5K-1/16W J HASC1M CX-NSZ809
X MICON R 0372 88-108-152-080 0E C-RES,U 1.5K-1/16W J HASC1M CX-NSZ809
X MICON R 0373 88-108-152-080 0E C-RES,U 1.5K-1/16W J HASC1M CX-NSZ809
X MICON R 0374 88-108-152-080 0E C-RES,U 1.5K-1/16W J HASC1M CX-NSZ809
X MICON R 0375 88-108-152-080 0E C-RES,U 1.5K-1/16W J HASC1M CX-NSZ809
X MICON R 0376 88-108-152-080 0E C-RES,U 1.5K-1/16W J HASC1M CX-NSZ809
X MICON R 0377 88-108-152-080 0E C-RES,U 1.5K-1/16W J HASC1M CX-NSZ809
X MICON R 0378 88-108-152-080 0E C-RES,U 1.5K-1/16W J HASC1M CX-NSZ809
X MICON R 0391 88-108-683-080 0E C-RES,U 68K-1/16W J HASC1M CX-NSZ809
X MICON R 0392 88-108-153-080 0E C-RES,U 15K-1/16W J HASC1M CX-NSZ809
X MICON R 0393 88-108-103-080 0E C-RES,U 10K-1/16W J HASC1M CX-NSZ809
X MICON R 0394 88-108-103-080 0E C-RES,U 10K-1/16W J HASC1M CX-NSZ809
X MICON R 0395 88-108-184-080 0E C-RES,U 180K-1/16W J HASC1M CX-NSZ809
X MICON R 0410 88-128-821-080 0E C-RES, 820-1/8W J HASC1M CX-NSZ809
X MICON R 0432 88-128-152-080 0E C-RES, 1.5K-1/8W J HASC1M CX-NSZ809
X MICON R 0452 88-108-273-080 0E C-RES,U 27K-1/16W J HASC1M CX-NSZ809
X MICON R 0453 88-108-273-080 0E C-RES,U 27K-1/16W J HASC1M CX-NSZ809
X MICON R 0454 88-108-273-080 0E C-RES,U 27K-1/16W J HASC1M CX-NSZ809
X MICON R 0455 88-108-273-080 0E C-RES,U 27K-1/16W J HASC1M CX-NSZ809
X MICON R 0456 88-108-472-080 0E C-RES,U 4.7K-1/16W J HASC1M CX-NSZ809
X MICON R 0457 88-108-104-080 0E C-RES,U 100K-1/16W J HASC1M CX-NSZ809
X MICON R 0458 88-108-563-080 0E C-RES,U 56K-1/16W J HASC1M CX-NSZ809
X MICON R 0459 88-121-683-080 0E RES,68K-1/8W J HASC1M CX-NSZ809
X MICON R 0461 88-121-101-080 0E RES,100-1/8W J HASC1M CX-NSZ809
X MICON R 0462 88-128-181-080 0E C-RES, 180-1/8W J HASC1M CX-NSZ809
X MICON R 0466 88-108-102-080 0E C-RES,U 1K-1/16W J HASC1M CX-NSZ809
X MICON R 0467 88-108-102-080 0E C-RES,U 1K-1/16W J HASC1M CX-NSZ809
X MICON R 0468 88-108-102-080 0E C-RES,U 1K-1/16W J HASC1M CX-NSZ809
X MICON R 0469 88-121-181-080 0E RES,180-1/8W J HASC1M CX-NSZ809
X MICON R 0901 88-108-123-080 0E C-RES,U 12K-1/16W J HASC1M CX-NSZ809
X MICON R 0902 88-108-123-080 0E C-RES,U 12K-1/16W J HASC1M CX-NSZ809
X MICON R 0903 88-108-822-080 0E C-RES,U 8.2K-1/16W J HASC1M CX-NSZ809
X MICON R 0904 88-108-822-080 0E C-RES,U 8.2K-1/16W J HASC1M CX-NSZ809
X MICON R 0905 88-128-120-080 0E C-RES, 12-1/8W J HASC1M CX-NSZ809
X MICON R 0906 88-128-120-080 0E C-RES, 12-1/8W J HASC1M CX-NSZ809
X MICON R 0907 88-128-120-080 0E C-RES, 12-1/8W J HASC1M CX-NSZ809
X MICON R 0908 88-128-120-080 0E C-RES, 12-1/8W J HASC1M CX-NSZ809
X MICON R 0909 88-128-120-080 0E C-RES, 12-1/8W J HASC1M CX-NSZ809
X MICON R 0911 88-128-120-080 0E C-RES, 12-1/8W J HASC1M CX-NSZ809
X MICON R 0912 88-128-120-080 0E C-RES, 12-1/8W J HASC1M CX-NSZ809
X MICON R 0913 88-128-120-080 0E C-RES, 12-1/8W J HASC1M CX-NSZ809
X MICON R 0914 88-128-120-080 0E C-RES, 12-1/8W J HASC1M CX-NSZ809
X MICON R 0915 88-128-120-080 0E C-RES, 12-1/8W J HASC1M CX-NSZ809
X MICON R 0921 88-108-222-080 0E C-RES,U 2.2K-1/16W J HASC1M CX-NSZ809
X MICON R 0922 88-108-222-080 0E C-RES,U 2.2K-1/16W J HASC1M CX-NSZ809
X MICON R 0923 88-108-182-080 0E C-RES,U 1.8K-1/16W J HASC1M CX-NSZ809
X MICON R 0924 88-108-182-080 0E C-RES,U 1.8K-1/16W J HASC1M CX-NSZ809
X MICON R 0925 88-108-221-080 0E C-RES,U 220-1/16W J HASC1M CX-NSZ809
X MICON R 0926 88-108-221-080 0E C-RES,U 220-1/16W J HASC1M CX-NSZ809

 11 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
X MICON R 0927 88-108-221-080 0E C-RES,U 220-1/16W J HASC1M CX-NSZ809
X MICON R 0928 88-108-221-080 0E C-RES,U 220-1/16W J HASC1M CX-NSZ809
X MICON R 0931 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X MICON R 0932 88-108-472-080 0E C-RES,U 4.7K-1/16W J HASC1M CX-NSZ809
X MICON R 0933 88-108-822-080 0E C-RES,U 8.2K-1/16W J HASC1M CX-NSZ809
X MICON R 0934 88-108-123-080 0E C-RES,U 12K-1/16W J HASC1M CX-NSZ809
O MICON S 0162 87-A91-645-010 1A SW,RTRY EC12E24304NON-CLICK HASC1M CX-NSZ809
O MICON S 0301 87-A90-095-080 0E SW,TACT EVQ11G04M HASC1M CX-NSZ809
O MICON S 0302 87-A90-095-080 0E SW,TACT EVQ11G04M HASC1M CX-NSZ809
O MICON S 0303 87-A90-095-080 0E SW,TACT EVQ11G04M HASC1M CX-NSZ809
O MICON S 0304 87-A90-095-080 0E SW,TACT EVQ11G04M HASC1M CX-NSZ809
O MICON S 0305 87-A90-095-080 0E SW,TACT EVQ11G04M HASC1M CX-NSZ809
O MICON S 0306 87-A90-095-080 0E SW,TACT EVQ11G04M HASC1M CX-NSZ809
O MICON S 0307 87-A90-095-080 0E SW,TACT EVQ11G04M HASC1M CX-NSZ809
O MICON S 0308 87-A90-095-080 0E SW,TACT EVQ11G04M HASC1M CX-NSZ809
O MICON S 0321 87-A90-095-080 0E SW,TACT EVQ11G04M HASC1M CX-NSZ809
O MICON S 0322 87-A90-095-080 0E SW,TACT EVQ11G04M HASC1M CX-NSZ809
O MICON S 0323 87-A90-095-080 0E SW,TACT EVQ11G04M HASC1M CX-NSZ809
O MICON S 0324 87-A90-095-080 0E SW,TACT EVQ11G04M HASC1M CX-NSZ809
O MICON S 0326 87-A90-095-080 0E SW,TACT EVQ11G04M HASC1M CX-NSZ809
O MICON S 0327 87-A90-095-080 0E SW,TACT EVQ11G04M HASC1M CX-NSZ809
O MICON S 0328 87-A90-095-080 0E SW,TACT EVQ11G04M HASC1M CX-NSZ809
O MICON S 0329 87-A90-095-080 0E SW,TACT EVQ11G04M HASC1M CX-NSZ809
O MICON S 0330 87-A90-095-080 0E SW,TACT EVQ11G04M HASC1M CX-NSZ809
O MICON S 0332 87-A90-095-080 0E SW,TACT EVQ11G04M HASC1M CX-NSZ809
O MICON S 0333 87-A90-095-080 0E SW,TACT EVQ11G04M HASC1M CX-NSZ809
O MICON S 0335 87-A90-095-080 0E SW,TACT EVQ11G04M HASC1M CX-NSZ809
O MICON S 0341 87-A90-095-080 0E SW,TACT EVQ11G04M HASC1M CX-NSZ809
O MICON S 0342 87-A90-095-080 0E SW,TACT EVQ11G04M HASC1M CX-NSZ809
O MICON S 0343 87-A90-095-080 0E SW,TACT EVQ11G04M HASC1M CX-NSZ809
O MICON S 0344 87-A90-095-080 0E SW,TACT EVQ11G04M HASC1M CX-NSZ809
O MICON S 0345 87-A90-095-080 0E SW,TACT EVQ11G04M HASC1M CX-NSZ809
O MICON S 0346 87-A90-095-080 0E SW,TACT EVQ11G04M HASC1M CX-NSZ809
O MICON S 0347 87-A90-095-080 0E SW,TACT EVQ11G04M HASC1M CX-NSZ809
O MICON S 0348 87-A90-095-080 0E SW,TACT EVQ11G04M HASC1M CX-NSZ809
O MICON S 0349 87-A90-095-080 0E SW,TACT EVQ11G04M HASC1M CX-NSZ809
O MICON S 0350 87-A90-095-080 0E SW,TACT EVQ11G04M HASC1M CX-NSZ809
O MICON S 0351 87-A90-095-080 0E SW,TACT EVQ11G04M HASC1M CX-NSZ809
O MICON S 0352 87-A90-095-080 0E SW,TACT EVQ11G04M HASC1M CX-NSZ809
O MICON S 0371 87-A91-991-010 1A SW,RTRY REO12303PV 8H HASC1M CX-NSZ809
O MICON S 0901 87-036-252-010 0E SW,MICRO SPP 51 HASC1M CX-NSZ809
O MICON S 0902 87-036-252-010 0E SW,MICRO SPP 51 HASC1M CX-NSZ809
O MICON S 0911 87-036-109-010 1A SW,MICRO SPP 61 HASC1M CX-NSZ809
O MICON S 0912 87-036-109-010 1A SW,MICRO SPP 61 HASC1M CX-NSZ809
X MICON LOCAL D 0102 88-100-000-010 0E PLATING-JW, 0.58 SN95 HASC1M CX-NSZ809
X MICON LOCAL D 0103 88-100-000-010 0E PLATING-JW, 0.58 SN95 HASC1M CX-NSZ809
X MICON LOCAL L 0171 88-100-000-010 0E PLATING-JW, 0.58 SN95 HASC1M CX-NSZ809
X MICON LOCAL L 0172 88-100-000-010 0E PLATING-JW, 0.58 SN95 HASC1M CX-NSZ809
! O OTHERS 82-NF5-229-010 0E PLATE,LOCK(*) HASC1M CX-NSZ809
! O OTHERS 82-NF5-229-010 0E PLATE,LOCK(*) LHSKM CX-SNSZ809
X OTHERS 83-CD7-594-010 0E SH,4-4-0.188 HASC1M CX-NSZ809
X OTHERS 83-CD7-594-010 0E SH,4-4-0.188 LHSKM CX-SNSZ809
X OTHERS 83-JT2-214-010 0E SH, 4-4-0.53 W/ADH HASC1M CX-NSZ809
X OTHERS 83-JT2-214-010 0E SH, 4-4-0.53 W/ADH LHSKM CX-SNSZ809
O OTHERS 86-NF9-224-010 0E SPR-C,LOCK HASC1M CX-NSZ809
O OTHERS 86-NF9-224-010 0E SPR-C,LOCK LHSKM CX-SNSZ809
X OTHERS 87-064-080-010 0E INDER,WIRE HASC1M CX-NSZ809
X OTHERS 87-064-080-010 0E INDER,WIRE LHSKM CX-SNSZ809
O OTHERS 87-064-185-010 0E HLDR,WIRE PVC 0.5 HASC1M CX-NSZ809
O OTHERS 87-064-185-010 0E HLDR,WIRE PVC 0.5 LHSKM CX-SNSZ809
! O OTHERS 87-NF4-216-010 0E HLDR,LOCK 1 HASC1M CX-NSZ809
! O OTHERS 87-NF4-216-010 0E HLDR,LOCK 1 LHSKM CX-SNSZ809
! O OTHERS 87-NF4-217-110 0E HLDR,LOCK 2 HASC1M CX-NSZ809
! O OTHERS 87-NF4-217-110 0E HLDR,LOCK 2 LHSKM CX-SNSZ809
X OTHERS 87-NF4-218-010 0E PLATE,EARTH MECHA HASC1M CX-NSZ809
X OTHERS 87-NF4-218-010 0E PLATE,EARTH MECHA LHSKM CX-SNSZ809
X OTHERS 88-NF5-207-010 0E PLATE,EARTH MIC HASC1M CX-NSZ809
X OTHERS 88-NF5-207-010 0E PLATE,EARTH MIC LHSKM CX-SNSZ809
! O OTHERS 8A-NF7-225-010 0E HLDR,PW PT 85S HASC1M CX-NSZ809
! O OTHERS 8A-NF7-225-010 0E HLDR,PW PT 85S LHSKM CX-SNSZ809

 12 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
! O OTHERS 8A-NF8-206-010 0E HLDR,PW M HASC1M CX-NSZ809
! O OTHERS 8A-NF8-206-010 0E HLDR,PW M LHSKM CX-SNSZ809
O OTHERS 8A-NF8-281-010 0E SPR-T,EJECT 1 HASC1M CX-NSZ809
O OTHERS 8A-NF8-281-010 0E SPR-T,EJECT 1 LHSKM CX-SNSZ809
O OTHERS 8A-NF8-282-010 0E SPR-T,EJECT 2 HASC1M CX-NSZ809
O OTHERS 8A-NF8-282-010 0E SPR-T,EJECT 2 LHSKM CX-SNSZ809
X OTHERS 8A-NF9-205-010 -- HT-SINK,FIN U HASC1M CX-NSZ809
X OTHERS 8A-NF9-205-010 -- HT-SINK,FIN U LHSKM CX-SNSZ809
O OTHERS 8 -NF7-225-010 0E HLDR,TR PNRM ST HASC1M CX-NSZ809
O OTHERS 8 -NF7-225-010 0E HLDR,TR PNRM ST LHSKM CX-SNSZ809
X OTHERS 8 -NF7-226-010 0E CUSH,PANEL MOVE HASC1M CX-NSZ809
X OTHERS 8 -NF7-226-010 0E CUSH,PANEL MOVE LHSKM CX-SNSZ809
X OTHERS 8 -NF7-227-010 1A PLATE,PT 85 HASC1M CX-NSZ809
X OTHERS 8 -NF7-227-010 1A PLATE,PT 85 LHSKM CX-SNSZ809
X OTHERS 8 -NF7-232-010 -- HT-SINK,U HASC1M CX-NSZ809
X OTHERS 8 -NF7-232-010 -- HT-SINK,U LHSKM CX-SNSZ809
O OTHERS 8 -NF7-235-010 0E HLDR,PW PNRM R HASC1M CX-NSZ809
O OTHERS 8 -NF7-235-010 0E HLDR,PW PNRM R LHSKM CX-SNSZ809
O OTHERS 8 -NF7-236-010 0E HLDR,PW PNRM F HASC1M CX-NSZ809
O OTHERS 8 -NF7-236-010 0E HLDR,PW PNRM F LHSKM CX-SNSZ809
O OTHERS 8 -NF7-237-010 1 HLDR,TR PNRM HASC1M CX-NSZ809
O OTHERS 8 -NF7-237-010 1 HLDR,TR PNRM LHSKM CX-SNSZ809
O OTHERS 8 -NF7-238-010 1A HLDR,FAN LOW HASC1M CX-NSZ809
O OTHERS 8 -NF7-238-010 1A HLDR,FAN LOW LHSKM CX-SNSZ809
O OTHERS 8 -NF7-239-010 1 HLDR,TR U HASC1M CX-NSZ809
O OTHERS 8 -NF7-239-010 1 HLDR,TR U LHSKM CX-SNSZ809
X OTHERS 8 -NF7-241-010 0E SH,TR VM HASC1M CX-NSZ809
X OTHERS 8 -NF7-241-010 0E SH,TR VM LHSKM CX-SNSZ809
X OTHERS 8 -NF7-244-010 1H HT-SINK,ASSY LH HASC1M CX-NSZ809
X OTHERS 8 -NF7-244-010 1H HT-SINK,ASSY LH LHSKM CX-SNSZ809
X OTHERS 8 -NF8-249-010 0E PLATE,SHLD DECK HASC1M CX-NSZ809
X OTHERS 8 -NF8-249-010 0E PLATE,SHLD DECK LHSKM CX-SNSZ809
X OTHERS 8 -NF9-204-010 0E CUSH, 11-8.5-2 HASC1M CX-NSZ809
X OTHERS 8 -NF9-204-010 0E CUSH, 11-8.5-2 LHSKM CX-SNSZ809
X OTHERS 8 -NFK-234-010 -- CHAS,MAIN S 85-65 FAN HASC1M CX-NSZ809
X OTHERS 8 -NFK-234-010 -- CHAS,MAIN S 85-65 FAN LHSKM CX-SNSZ809
! O OTHERS 8Z-NF6-210-010 0E DMPR,150 N HASC1M CX-NSZ809
! O OTHERS 8Z-NF6-210-010 0E DMPR,150 N LHSKM CX-SNSZ809
X P-SUPPLY/PW /FAN 8 -NFJ-630-010 1E PW ,COM MAIN NF-18 HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN 8 -NFJ-631-010 -- PW ,MAIN NF-18 HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN 8 -NFJ-633-010 -- PW ,FAN NF-18 HASC1M CX-NSZ809
O P-SUPPLY/PW /FAN C 0001 87-016-657-090 1F CAP,E 3300-71 M SMG HASC1M CX-NSZ809
O P-SUPPLY/PW /FAN C 0002 87-016-657-090 1F CAP,E 3300-71 M SMG HASC1M CX-NSZ809
O P-SUPPLY/PW /FAN C 0003 87-A12-317-080 0E C-CAP,U 0.1-50 Z F HASC1M CX-NSZ809
O P-SUPPLY/PW /FAN C 0004 87-A12-317-080 0E C-CAP,U 0.1-50 Z F HASC1M CX-NSZ809
O P-SUPPLY/PW /FAN C 0005 87-A12-317-080 0E C-CAP,U 0.1-50 Z F HASC1M CX-NSZ809
O P-SUPPLY/PW /FAN C 0006 87-A12-317-080 0E C-CAP,U 0.1-50 Z F HASC1M CX-NSZ809
O P-SUPPLY/PW /FAN C 0009 87-010-759-080 0E C-CAP,U 0.1-25 Z F HASC1M CX-NSZ809
O P-SUPPLY/PW /FAN C 0010 87-010-759-080 0E C-CAP,U 0.1-25 Z F HASC1M CX-NSZ809
O P-SUPPLY/PW /FAN C 0011 87-010-759-080 0E C-CAP,U 0.1-25 Z F HASC1M CX-NSZ809
O P-SUPPLY/PW /FAN C 0012 87-010-759-080 0E C-CAP,U 0.1-25 Z F HASC1M CX-NSZ809
O P-SUPPLY/PW /FAN C 0021 87-A12-780-090 1 CAP,E 4700-35 M 85 SKR HASC1M CX-NSZ809
O P-SUPPLY/PW /FAN C 0022 87-A12-780-090 1 CAP,E 4700-35 M 85 SKR HASC1M CX-NSZ809
O P-SUPPLY/PW /FAN C 0031 87-A12-091-080 0E CAP,E 10-50 SMG HASC1M CX-NSZ809
O P-SUPPLY/PW /FAN C 0032 87-012-286-080 0E C-CAP,U 0.01-25 K HASC1M CX-NSZ809
O P-SUPPLY/PW /FAN C 0034 87-A12-072-080 0E CAP,E 100-25 SMG HASC1M CX-NSZ809
O P-SUPPLY/PW /FAN C 0035 87-A12-071-080 0E CAP,E 47-25 SMG HASC1M CX-NSZ809
O P-SUPPLY/PW /FAN C 0036 87-010-381-080 0E CAP,E 330-16 M SME HASC1M CX-NSZ809
O P-SUPPLY/PW /FAN C 0038 87-012-286-080 0E C-CAP,U 0.01-25 K HASC1M CX-NSZ809
O P-SUPPLY/PW /FAN C 0060 87-A12-089-080 0E CAP,E 3.3-50 SMG HASC1M CX-NSZ809
O P-SUPPLY/PW /FAN C 0061 87-A12-071-080 0E CAP,E 47-25 SMG HASC1M CX-NSZ809
O P-SUPPLY/PW /FAN C 0083 87-A12-074-080 0E CAP,E 470-25 SMG HASC1M CX-NSZ809
O P-SUPPLY/PW /FAN C 0097 87-010-831-080 0E C-CAP,U 0.1-16 Z F HASC1M CX-NSZ809
O P-SUPPLY/PW /FAN C 0501 87-A12-087-080 0E CAP,E 1-50 SMG HASC1M CX-NSZ809
O P-SUPPLY/PW /FAN C 0502 87-A12-071-080 0E CAP,E 47-25 SMG HASC1M CX-NSZ809
O P-SUPPLY/PW /FAN C 0503 87-A12-071-080 0E CAP,E 47-25 SMG HASC1M CX-NSZ809
! O P-SUPPLY/PW /FAN CN 0501 87-099-564-010 0E CONN,4P V TUC-P4P- 1 HASC1M CX-NSZ809
O P-SUPPLY/PW /FAN CN 0502 87-A60-688-010 0E CONN,4P H GRY TUC-P04X-C1 HASC1M CX-NSZ809
O P-SUPPLY/PW /FAN CN 0503 87-A60-619-010 0E CONN,2P V 2MM JMT HASC1M CX-NSZ809
! O P-SUPPLY/PW /FAN CNA0001 8A-NF8-653-010 1 CONN ASSY,9P TID-A(480) HASC1M CX-NSZ809

 13 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
O P-SUPPLY/PW /FAN CNA0002 8 -NF7-618-010 0E CONN ASSY,3P V PANO HASC1M CX-NSZ809
S P-SUPPLY/PW /FAN D 0001 87-A40-393-090 0E DIODE,1N5402GW(F20) HASC1M CX-NSZ809
S P-SUPPLY/PW /FAN D 0002 87-A40-393-090 0E DIODE,1N5402GW(F20) HASC1M CX-NSZ809
S P-SUPPLY/PW /FAN D 0003 87-A40-393-090 0E DIODE,1N5402GW(F20) HASC1M CX-NSZ809
S P-SUPPLY/PW /FAN D 0004 87-A40-393-090 0E DIODE,1N5402GW(F20) HASC1M CX-NSZ809
S P-SUPPLY/PW /FAN D 0009 87-A40-839-090 1A DIODE,G5S A60L-6088 HASC1M CX-NSZ809
S P-SUPPLY/PW /FAN D 0029 87-A40-781-080 0E ZENER,UZ36 SA HASC1M CX-NSZ809
S P-SUPPLY/PW /FAN D 0030 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S P-SUPPLY/PW /FAN D 0031 87-A40-764-080 0E ZENER,UZ10 SC HASC1M CX-NSZ809
S P-SUPPLY/PW /FAN D 0033 87-A40-553-080 0E DIODE,1N4003 LES HASC1M CX-NSZ809
S P-SUPPLY/PW /FAN D 0034 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S P-SUPPLY/PW /FAN D 0035 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S P-SUPPLY/PW /FAN D 0041 87-A40-270-080 0E C-DIODE,MC2838 HASC1M CX-NSZ809
S P-SUPPLY/PW /FAN D 0042 87-A40-269-080 0E C-DIODE,MC2836 HASC1M CX-NSZ809
S P-SUPPLY/PW /FAN D 0060 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S P-SUPPLY/PW /FAN D 0062 87-A40-270-080 0E C-DIODE,MC2838 HASC1M CX-NSZ809
S P-SUPPLY/PW /FAN D 0063 87-A40-270-080 0E C-DIODE,MC2838 HASC1M CX-NSZ809
S P-SUPPLY/PW /FAN D 0064 87-A40-269-080 0E C-DIODE,MC2836 HASC1M CX-NSZ809
S P-SUPPLY/PW /FAN D 0065 87-A40-269-080 0E C-DIODE,MC2836 HASC1M CX-NSZ809
S P-SUPPLY/PW /FAN D 0071 87-A40-269-080 0E C-DIODE,MC2836 HASC1M CX-NSZ809
S P-SUPPLY/PW /FAN D 0072 87-A40-270-080 0E C-DIODE,MC2838 HASC1M CX-NSZ809
S P-SUPPLY/PW /FAN D 0076 87-A40-269-080 0E C-DIODE,MC2836 HASC1M CX-NSZ809
S P-SUPPLY/PW /FAN D 0077 87-A40-270-080 0E C-DIODE,MC2838 HASC1M CX-NSZ809
S P-SUPPLY/PW /FAN D 0501 87-A40-270-080 0E C-DIODE,MC2838 HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN JR 0001 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN JR 0003 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN JR 0004 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN JR 0005 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN JR 0006 88-129-000-080 0E C-JUMPER,3216 HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN JR 0023 88-128-820-080 0E C-RES, 82-1/8W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN JR 0024 88-128-820-080 0E C-RES, 82-1/8W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN JR 0502 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
S P-SUPPLY/PW /FAN Q 0001 87-A30-494-080 0E TR,2SA1980G HASC1M CX-NSZ809
S P-SUPPLY/PW /FAN Q 0002 87-A30-494-080 0E TR,2SA1980G HASC1M CX-NSZ809
S P-SUPPLY/PW /FAN Q 0003 87-A30-559-010 1A TR,CS 1370EF HASC1M CX-NSZ809
S P-SUPPLY/PW /FAN Q 0005 87-026-610-080 0E TR,KTC3198GR HASC1M CX-NSZ809
S P-SUPPLY/PW /FAN Q 0006 87-A30-076-080 0E C-TR,2SC3052F HASC1M CX-NSZ809
S P-SUPPLY/PW /FAN Q 0008 87-A30-075-080 0E C-TR,2SA1235F HASC1M CX-NSZ809
S P-SUPPLY/PW /FAN Q 0009 87-A30-494-080 0E TR,2SA1980G HASC1M CX-NSZ809
S P-SUPPLY/PW /FAN Q 0010 87-A30-076-080 0E C-TR,2SC3052F HASC1M CX-NSZ809
S P-SUPPLY/PW /FAN Q 0014 87-A30-075-080 0E C-TR,2SA1235F HASC1M CX-NSZ809
S P-SUPPLY/PW /FAN Q 0059 87-A30-107-070 0E C-TR,CM T5401 HASC1M CX-NSZ809
S P-SUPPLY/PW /FAN Q 0060 87-A30-076-080 0E C-TR,2SC3052F HASC1M CX-NSZ809
S P-SUPPLY/PW /FAN Q 0061 87-A30-075-080 0E C-TR,2SA1235F HASC1M CX-NSZ809
S P-SUPPLY/PW /FAN Q 0062 87-A30-076-080 0E C-TR,2SC3052F HASC1M CX-NSZ809
S P-SUPPLY/PW /FAN Q 0063 87-A30-075-080 0E C-TR,2SA1235F HASC1M CX-NSZ809
S P-SUPPLY/PW /FAN Q 0064 87-A30-076-080 0E C-TR,2SC3052F HASC1M CX-NSZ809
S P-SUPPLY/PW /FAN Q 0065 87-A30-484-080 0E C-TR,KRA102S HASC1M CX-NSZ809
S P-SUPPLY/PW /FAN Q 0501 87-A30-076-080 0E C-TR,2SC3052F HASC1M CX-NSZ809
S P-SUPPLY/PW /FAN Q 0502 87-A30-075-080 0E C-TR,2SA1235F HASC1M CX-NSZ809
S P-SUPPLY/PW /FAN Q 0503 87-A30-494-080 0E TR,2SA1980G HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0009 88-108-393-080 0E C-RES,U 39K-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0010 88-108-393-080 0E C-RES,U 39K-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0011 88-118-472-080 0E C-RES,S 4.7K-1/10W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0012 88-118-472-080 0E C-RES,S 4.7K-1/10W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0013 88-108-472-080 0E C-RES,U 4.7K-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0014 88-118-829-080 0E C-RES,S 8.2-1/10W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0016 88-108-333-080 0E C-RES,U 33K-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0018 88-118-221-080 0E C-RES,S 220-1/10W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0019 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0020 88-121-680-080 0E RES,68-1/8W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0021 88-108-472-080 0E C-RES,U 4.7K-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0022 88-108-221-080 0E C-RES,U 220-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0023 88-108-103-080 0E C-RES,U 10K-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0027 88-118-471-080 0E C-RES,S 470-1/10W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0028 88-108-103-080 0E C-RES,U 10K-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0029 88-108-222-080 0E C-RES,U 2.2K-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0030 88-108-333-080 0E C-RES,U 33K-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0031 88-108-473-080 0E C-RES,U 47K-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0032 88-121-102-080 0E RES,1K-1/8W J HASC1M CX-NSZ809

 14 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
X P-SUPPLY/PW /FAN R 0033 88-108-101-080 0E C-RES,U 100-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0034 88-108-394-080 0E C-RES,U 390K-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0037 88-128-820-080 0E C-RES, 82-1/8W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0038 88-130-181-080 0E RES,180-1/4W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0039 88-128-820-080 0E C-RES, 82-1/8W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0042 88-130-181-080 0E RES,180-1/4W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0043 88-130-181-080 0E RES,180-1/4W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0044 88-128-101-080 0E C-RES, 100-1/8W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0045 88-128-820-080 0E C-RES, 82-1/8W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0046 88-130-181-080 0E RES,180-1/4W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0048 88-130-103-080 0E RES,10K-1/4W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0050 88-128-101-080 0E C-RES, 100-1/8W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0051 88-128-101-080 0E C-RES, 100-1/8W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0052 88-108-333-080 0E C-RES,U 33K-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0054 88-118-473-080 0E C-RES,S 47K-1/10W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0055 88-118-473-080 0E C-RES,S 47K-1/10W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0056 88-108-332-080 0E C-RES,U 3.3K-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0057 88-108-222-080 0E C-RES,U 2.2K-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0058 88-108-332-080 0E C-RES,U 3.3K-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0059 88-118-103-080 0E C-RES,S 10K-1/10W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0060 88-118-473-080 0E C-RES,S 47K-1/10W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0061 88-108-333-080 0E C-RES,U 33K-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0062 88-108-273-080 0E C-RES,U 27K-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0063 88-108-273-080 0E C-RES,U 27K-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0064 88-108-102-080 0E C-RES,U 1K-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0065 88-108-123-080 0E C-RES,U 12K-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0066 88-108-104-080 0E C-RES,U 100K-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0067 88-108-103-080 0E C-RES,U 10K-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0068 88-108-224-080 0E C-RES,U 220K-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0069 88-108-224-080 0E C-RES,U 220K-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0070 88-108-102-080 0E C-RES,U 1K-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0071 88-108-473-080 0E C-RES,U 47K-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0072 88-108-473-080 0E C-RES,U 47K-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0073 88-128-820-080 0E C-RES, 82-1/8W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0074 88-128-820-080 0E C-RES, 82-1/8W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0076 88-108-562-080 0E C-RES,U 5.6K-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0077 88-108-102-080 0E C-RES,U 1K-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0078 88-108-393-080 0E C-RES,U 39K-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0079 88-108-183-080 0E C-RES,U 18K-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0080 88-121-153-080 0E RES,15K-1/8W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0081 88-108-101-080 0E C-RES,U 100-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0085 88-108-103-080 0E C-RES,U 10K-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0086 88-118-564-080 0E C-RES,S 560K-1/10W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0087 88-121-153-080 0E RES,15K-1/8W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0093 88-108-823-080 0E C-RES,U 82K-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0094 88-108-393-080 0E C-RES,U 39K-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0095 88-108-183-080 0E C-RES,U 18K-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0096 88-108-823-080 0E C-RES,U 82K-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0501 88-108-473-080 0E C-RES,U 47K-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0502 88-108-474-080 0E C-RES,U 470K-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0503 88-108-332-080 0E C-RES,U 3.3K-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0504 88-108-221-080 0E C-RES,U 220-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0505 88-118-103-080 0E C-RES,S 10K-1/10W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0506 88-108-103-080 0E C-RES,U 10K-1/16W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0507 88-118-399-080 0E C-RES,S 3.9-1/10W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0511 88-121-471-080 0E RES,470-1/8W J HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN R 0512 88-121-471-080 0E RES,470-1/8W J HASC1M CX-NSZ809
! O P-SUPPLY/PW /FAN WH 0001 87-A90-510-010 0E HLDR,WIRE 2.5-9P HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN,LOC R 0001 88-100-000-010 0E PLATING-JW, 0.58 SN95 HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN,LOC R 0005 88-100-000-010 0E PLATING-JW, 0.58 SN95 HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN,LOC R 0017 88-100-000-010 0E PLATING-JW, 0.58 SN95 HASC1M CX-NSZ809
X P-SUPPLY/PW /FAN,LOC R 0047 88-100-000-010 0E PLATING-JW, 0.58 SN95 HASC1M CX-NSZ809
X PACKING 87- 40-243-010 0E AG,PV 0.025-650-750 PL-SPA HASC1M CX-NSZ809
X PACKING 93-704-337-010 1A SH,FOAMED-MAT 0.31-800-500 HASC1M CX-NSZ809
X PANORAMA * 8 -NF7-616-010 0E PW ,AMP PANO 4M HASC1M CX-NSZ809
O PANORAMA C 0201 87-A12-088-080 0E CAP,E 2.2-50 SMG HASC1M CX-NSZ809
O PANORAMA C 0202 87-A12-088-080 0E CAP,E 2.2-50 SMG HASC1M CX-NSZ809
O PANORAMA C 0204 87-016-459-080 0E CAP,E 470-10 M SMG HASC1M CX-NSZ809
O PANORAMA C 0207 87-012-286-080 0E C-CAP,U 0.01-25 K HASC1M CX-NSZ809
O PANORAMA C 0208 87-012-286-080 0E C-CAP,U 0.01-25 K HASC1M CX-NSZ809

 15 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
O PANORAMA C 0213 87-012-172-080 0E C-CAP,U 10P-50 D CH HASC1M CX-NSZ809
O PANORAMA C 0215 87-010-831-080 0E C-CAP,U 0.1-16 Z F HASC1M CX-NSZ809
O PANORAMA C 0216 87-010-831-080 0E C-CAP,U 0.1-16 Z F HASC1M CX-NSZ809
O PANORAMA C 0301 87-012-274-080 0E C-CAP,U 1000P-50 K HASC1M CX-NSZ809
O PANORAMA C 0302 87-012-274-080 0E C-CAP,U 1000P-50 K HASC1M CX-NSZ809
O PANORAMA C 0303 87-A12-084-080 0E CAP,E 0.22-50 SMG HASC1M CX-NSZ809
O PANORAMA C 0304 87-A12-084-080 0E CAP,E 0.22-50 SMG HASC1M CX-NSZ809
O PANORAMA C 0309 87-A12-089-080 0E CAP,E 3.3-50 SMG HASC1M CX-NSZ809
O PANORAMA C 0310 87-A12-089-080 0E CAP,E 3.3-50 SMG HASC1M CX-NSZ809
O PANORAMA C 0311 87-A12-092-080 0E CAP,E 22-50 SMG HASC1M CX-NSZ809
O PANORAMA C 0312 87-A12-092-080 0E CAP,E 22-50 SMG HASC1M CX-NSZ809
O PANORAMA C 0315 87-012-199-080 0E C-CAP,U 220P-50 J CH HASC1M CX-NSZ809
O PANORAMA C 0316 87-012-199-080 0E C-CAP,U 220P-50 J CH HASC1M CX-NSZ809
O PANORAMA C 0317 87-012-286-080 0E C-CAP,U 0.01-25 K HASC1M CX-NSZ809
O PANORAMA C 0318 87-012-286-080 0E C-CAP,U 0.01-25 K HASC1M CX-NSZ809
O PANORAMA C 0401 87-010-831-080 0E C-CAP,U 0.1-16 Z F HASC1M CX-NSZ809
O PANORAMA C 0402 87-010-831-080 0E C-CAP,U 0.1-16 Z F HASC1M CX-NSZ809
O PANORAMA C 0403 87-A12-091-080 0E CAP,E 10-50 SMG HASC1M CX-NSZ809
O PANORAMA C 0404 87-A12-091-080 0E CAP,E 10-50 SMG HASC1M CX-NSZ809
X PANORAMA CLP0002 87-A60-884-010 0E PIN,DIA1 COATING-SHS HASC1M CX-NSZ809
X PANORAMA CLP0003 87-A60-884-010 0E PIN,DIA1 COATING-SHS HASC1M CX-NSZ809
O PANORAMA CN 0101 87-A60-134-010 0E CONN,9P V FE HASC1M CX-NSZ809
! O PANORAMA CN 0102 87-099-043-010 0E CONN,2P V WHT EH HASC1M CX-NSZ809
! O PANORAMA CN 0104 87-049-919-010 0E CONN,3P V WHT EH HASC1M CX-NSZ809
S PANORAMA D 0301 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S PANORAMA D 0302 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S PANORAMA D 0303 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S PANORAMA D 0304 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S PANORAMA D 0305 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S PANORAMA D 0306 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S PANORAMA D 0307 87-A40-768-080 0E ZENER,UZ16 SA HASC1M CX-NSZ809
S PANORAMA D 0308 87-A40-768-080 0E ZENER,UZ16 SA HASC1M CX-NSZ809
S PANORAMA D 0313 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S PANORAMA D 0314 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S PANORAMA D 0318 87-A40-270-080 0E C-DIODE,MC2838 HASC1M CX-NSZ809
S PANORAMA IC 0201 87-A21-911-040 1E C-IC,M61515FP HASC1M CX-NSZ809
X PANORAMA JR 0201 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X PANORAMA JR 0202 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X PANORAMA JR 0302 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X PANORAMA JR 0303 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X PANORAMA JR 0504 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
S PANORAMA Q 0303 87-A30-075-080 0E C-TR,2SA1235F HASC1M CX-NSZ809
S PANORAMA Q 0304 87-A30-075-080 0E C-TR,2SA1235F HASC1M CX-NSZ809
S PANORAMA Q 0305 87-A30-076-080 0E C-TR,2SC3052F HASC1M CX-NSZ809
S PANORAMA Q 0306 87-A30-076-080 0E C-TR,2SC3052F HASC1M CX-NSZ809
S PANORAMA Q 0307 87-A30-075-080 0E C-TR,2SA1235F HASC1M CX-NSZ809
S PANORAMA Q 0308 87-A30-075-080 0E C-TR,2SA1235F HASC1M CX-NSZ809
S PANORAMA Q 0309 87-A30-076-080 0E C-TR,2SC3052F HASC1M CX-NSZ809
S PANORAMA Q 0310 87-A30-076-080 0E C-TR,2SC3052F HASC1M CX-NSZ809
S PANORAMA Q 0311 87-A30-190-080 0E TR,CC5551 HASC1M CX-NSZ809
S PANORAMA Q 0312 87-A30-190-080 0E TR,CC5551 HASC1M CX-NSZ809
S PANORAMA Q 0313 87-A30-076-080 0E C-TR,2SC3052F HASC1M CX-NSZ809
S PANORAMA Q 0314 87-A30-076-080 0E C-TR,2SC3052F HASC1M CX-NSZ809
S PANORAMA Q 0315 87-A30-256-010 1A TR,2SD1933 HASC1M CX-NSZ809
S PANORAMA Q 0316 87-A30-256-010 1A TR,2SD1933 HASC1M CX-NSZ809
S PANORAMA Q 0317 87-A30-255-010 1A TR,2S 1342 HASC1M CX-NSZ809
S PANORAMA Q 0318 87-A30-255-010 1A TR,2S 1342 HASC1M CX-NSZ809
S PANORAMA Q 0319 87-A30-107-070 0E C-TR,CM T5401 HASC1M CX-NSZ809
S PANORAMA Q 0320 87-A30-107-070 0E C-TR,CM T5401 HASC1M CX-NSZ809
X PANORAMA R 0201 88-128-680-080 0E C-RES, 68-1/8W J HASC1M CX-NSZ809
X PANORAMA R 0202 88-128-680-080 0E C-RES, 68-1/8W J HASC1M CX-NSZ809
X PANORAMA R 0203 88-108-223-080 0E C-RES,U 22K-1/16W J HASC1M CX-NSZ809
X PANORAMA R 0204 88-108-223-080 0E C-RES,U 22K-1/16W J HASC1M CX-NSZ809
X PANORAMA R 0205 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X PANORAMA R 0211 88-108-123-080 0E C-RES,U 12K-1/16W J HASC1M CX-NSZ809
X PANORAMA R 0212 88-121-103-080 0E RES,10K-1/8W J HASC1M CX-NSZ809
X PANORAMA R 0213 88-108-472-080 0E C-RES,U 4.7K-1/16W J HASC1M CX-NSZ809
X PANORAMA R 0251 88-121-101-080 0E RES,100-1/8W J HASC1M CX-NSZ809
X PANORAMA R 0252 88-121-101-080 0E RES,100-1/8W J HASC1M CX-NSZ809
X PANORAMA R 0253 88-128-181-080 0E C-RES, 180-1/8W J HASC1M CX-NSZ809

 16 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
X PANORAMA R 0254 88-128-181-080 0E C-RES, 180-1/8W J HASC1M CX-NSZ809
X PANORAMA R 0255 88-128-181-080 0E C-RES, 180-1/8W J HASC1M CX-NSZ809
X PANORAMA R 0256 88-121-101-080 0E RES,100-1/8W J HASC1M CX-NSZ809
X PANORAMA R 0257 88-128-181-080 0E C-RES, 180-1/8W J HASC1M CX-NSZ809
X PANORAMA R 0261 88-121-151-080 0E RES,150-1/8W J HASC1M CX-NSZ809
X PANORAMA R 0262 88-128-181-080 0E C-RES, 180-1/8W J HASC1M CX-NSZ809
X PANORAMA R 0263 88-128-181-080 0E C-RES, 180-1/8W J HASC1M CX-NSZ809
X PANORAMA R 0264 88-128-181-080 0E C-RES, 180-1/8W J HASC1M CX-NSZ809
X PANORAMA R 0265 88-121-151-080 0E RES,150-1/8W J HASC1M CX-NSZ809
X PANORAMA R 0266 88-121-151-080 0E RES,150-1/8W J HASC1M CX-NSZ809
X PANORAMA R 0267 88-121-151-080 0E RES,150-1/8W J HASC1M CX-NSZ809
X PANORAMA R 0301 88-108-272-080 0E C-RES,U 2.7K-1/16W J HASC1M CX-NSZ809
X PANORAMA R 0302 88-108-272-080 0E C-RES,U 2.7K-1/16W J HASC1M CX-NSZ809
X PANORAMA R 0305 88-108-473-080 0E C-RES,U 47K-1/16W J HASC1M CX-NSZ809
X PANORAMA R 0306 88-108-473-080 0E C-RES,U 47K-1/16W J HASC1M CX-NSZ809
X PANORAMA R 0307 88-108-223-080 0E C-RES,U 22K-1/16W J HASC1M CX-NSZ809
X PANORAMA R 0308 88-108-223-080 0E C-RES,U 22K-1/16W J HASC1M CX-NSZ809
X PANORAMA R 0309 88-108-101-080 0E C-RES,U 100-1/16W J HASC1M CX-NSZ809
X PANORAMA R 0310 88-108-101-080 0E C-RES,U 100-1/16W J HASC1M CX-NSZ809
X PANORAMA R 0313 88-118-102-080 0E C-RES,S 1K-1/10W J HASC1M CX-NSZ809
X PANORAMA R 0314 88-118-102-080 0E C-RES,S 1K-1/10W J HASC1M CX-NSZ809
X PANORAMA R 0315 88-108-103-080 0E C-RES,U 10K-1/16W J HASC1M CX-NSZ809
X PANORAMA R 0316 88-108-103-080 0E C-RES,U 10K-1/16W J HASC1M CX-NSZ809
X PANORAMA R 0317 88-118-101-080 0E C-RES,S 100-1/10W J HASC1M CX-NSZ809
X PANORAMA R 0318 88-118-101-080 0E C-RES,S 100-1/10W J HASC1M CX-NSZ809
X PANORAMA R 0319 88-118-101-080 0E C-RES,S 100-1/10W J HASC1M CX-NSZ809
X PANORAMA R 0320 88-118-101-080 0E C-RES,S 100-1/10W J HASC1M CX-NSZ809
X PANORAMA R 0321 88-128-222-080 0E C-RES, 2.2K-1/8W J HASC1M CX-NSZ809
X PANORAMA R 0322 88-128-222-080 0E C-RES, 2.2K-1/8W J HASC1M CX-NSZ809
X PANORAMA R 0323 88-108-223-080 0E C-RES,U 22K-1/16W J HASC1M CX-NSZ809
X PANORAMA R 0324 88-108-223-080 0E C-RES,U 22K-1/16W J HASC1M CX-NSZ809
X PANORAMA R 0325 88-108-473-080 0E C-RES,U 47K-1/16W J HASC1M CX-NSZ809
X PANORAMA R 0326 88-108-473-080 0E C-RES,U 47K-1/16W J HASC1M CX-NSZ809
X PANORAMA R 0327 88-118-390-080 0E C-RES,S 39-1/10W J HASC1M CX-NSZ809
X PANORAMA R 0328 88-118-390-080 0E C-RES,S 39-1/10W J HASC1M CX-NSZ809
X PANORAMA R 0329 88-128-222-080 0E C-RES, 2.2K-1/8W J HASC1M CX-NSZ809
X PANORAMA R 0330 88-121-222-080 0E RES,2.2K-1/8W J HASC1M CX-NSZ809
X PANORAMA R 0331 88-121-331-080 0E RES,330-1/8W J HASC1M CX-NSZ809
X PANORAMA R 0332 88-121-331-080 0E RES,330-1/8W J HASC1M CX-NSZ809
O PANORAMA R 0333 87-A00-258-080 0E RES,M/F 0.22-1W J HASC1M CX-NSZ809
O PANORAMA R 0334 87-A00-258-080 0E RES,M/F 0.22-1W J HASC1M CX-NSZ809
X PANORAMA R 0337 88-108-101-080 0E C-RES,U 100-1/16W J HASC1M CX-NSZ809
X PANORAMA R 0338 88-108-101-080 0E C-RES,U 100-1/16W J HASC1M CX-NSZ809
X PANORAMA R 0339 88-108-392-080 0E C-RES,U 3.9K-1/16W J HASC1M CX-NSZ809
X PANORAMA R 0340 88-108-392-080 0E C-RES,U 3.9K-1/16W J HASC1M CX-NSZ809
X PANORAMA R 0341 88-108-122-080 0E C-RES,U 1.2K-1/16W J HASC1M CX-NSZ809
X PANORAMA R 0342 88-108-122-080 0E C-RES,U 1.2K-1/16W J HASC1M CX-NSZ809
X PANORAMA R 0343 88-118-102-080 0E C-RES,S 1K-1/10W J HASC1M CX-NSZ809
X PANORAMA R 0344 88-118-102-080 0E C-RES,S 1K-1/10W J HASC1M CX-NSZ809
X PANORAMA R 0345 88-108-103-080 0E C-RES,U 10K-1/16W J HASC1M CX-NSZ809
X PANORAMA R 0346 88-108-103-080 0E C-RES,U 10K-1/16W J HASC1M CX-NSZ809
X PANORAMA R 0351 88-118-222-080 0E C-RES,S 2.2K-1/10W J HASC1M CX-NSZ809
X PANORAMA R 0352 88-118-222-080 0E C-RES,S 2.2K-1/10W J HASC1M CX-NSZ809
X PANORAMA R 0353 88-118-122-080 0E C-RES,S 1.2K-1/10W J HASC1M CX-NSZ809
X PANORAMA R 0354 88-118-122-080 0E C-RES,S 1.2K-1/10W J HASC1M CX-NSZ809
X PANORAMA R 0360 88-108-472-080 0E C-RES,U 4.7K-1/16W J HASC1M CX-NSZ809
X PANORAMA R 0361 88-118-182-080 0E C-RES,S 1.8K-1/10W J HASC1M CX-NSZ809
X PANORAMA R 0362 88-118-182-080 0E C-RES,S 1.8K-1/10W J HASC1M CX-NSZ809
X PANORAMA R 0391 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
! X PLATE 87-057-961-010 0E L L,CAUTION TRIANGLE HASC1M CX-NSZ809
! X PLATE 87-057-995-010 0E L L,CAUTION EFSD HASC1M CX-NSZ809
X PLATE 8 -NF7-056-010 -- L L,SPEC HASC1M HASC1M CX-NSZ809
O POWER AMP C 0101 87-012-279-080 0E C-CAP,U 2700P-50 K GRM HASC1M CX-NSZ809
O POWER AMP C 0102 87-012-279-080 0E C-CAP,U 2700P-50 K GRM HASC1M CX-NSZ809
O POWER AMP C 0103 87-A12-084-080 0E CAP,E 0.22-50 SMG HASC1M CX-NSZ809
O POWER AMP C 0104 87-A12-084-080 0E CAP,E 0.22-50 SMG HASC1M CX-NSZ809
O POWER AMP C 0107 87-A12-089-080 0E CAP,E 3.3-50 SMG HASC1M CX-NSZ809
O POWER AMP C 0108 87-A12-089-080 0E CAP,E 3.3-50 SMG HASC1M CX-NSZ809
O POWER AMP C 0111 87-A12-077-080 0E CAP,E 33-35 SMG HASC1M CX-NSZ809
O POWER AMP C 0112 87-A12-077-080 0E CAP,E 33-35 SMG HASC1M CX-NSZ809

 17 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
O POWER AMP C 0113 87-A10-596-080 0E C-CAP,S 100P-100 J CH HASC1M CX-NSZ809
O POWER AMP C 0114 87-A10-596-080 0E C-CAP,S 100P-100 J CH HASC1M CX-NSZ809
O POWER AMP C 0117 87-A12-317-080 0E C-CAP,U 0.1-50 Z F HASC1M CX-NSZ809
O POWER AMP C 0118 87-A12-317-080 0E C-CAP,U 0.1-50 Z F HASC1M CX-NSZ809
O POWER AMP C 0119 87-012-286-080 0E C-CAP,U 0.01-25 K HASC1M CX-NSZ809
O POWER AMP C 0120 87-012-286-080 0E C-CAP,U 0.01-25 K HASC1M CX-NSZ809
O POWER AMP C 0123 87-010-177-080 0E C-CAP,S 820P-50 J SL C2012 HASC1M CX-NSZ809
O POWER AMP C 0124 87-010-177-080 0E C-CAP,S 820P-50 J SL C2012 HASC1M CX-NSZ809
O POWER AMP C 0133 87-012-282-080 0E C-CAP,U 4700P-50 K HASC1M CX-NSZ809
O POWER AMP C 0140 87-012-278-080 0E C-CAP,U 2200P-50 K HASC1M CX-NSZ809
O POWER AMP C 0186 87-010-759-080 0E C-CAP,U 0.1-25 Z F HASC1M CX-NSZ809
O POWER AMP C 0187 87-A12-180-080 0E CAP,E 10-63 M 105 KME HASC1M CX-NSZ809
O POWER AMP C 0188 87-A12-180-080 0E CAP,E 10-63 M 105 KME HASC1M CX-NSZ809
O POWER AMP C 0201 87-010-759-080 0E C-CAP,U 0.1-25 Z F HASC1M CX-NSZ809
O POWER AMP C 0202 87-010-759-080 0E C-CAP,U 0.1-25 Z F HASC1M CX-NSZ809
O POWER AMP C 0203 87-010-759-080 0E C-CAP,U 0.1-25 Z F HASC1M CX-NSZ809
O POWER AMP C 0204 87-010-759-080 0E C-CAP,U 0.1-25 Z F HASC1M CX-NSZ809
O POWER AMP C 0220 87-012-274-080 0E C-CAP,U 1000P-50 K HASC1M CX-NSZ809
O POWER AMP C 0225 87-A12-317-080 0E C-CAP,U 0.1-50 Z F HASC1M CX-NSZ809
O POWER AMP C 0226 87-A12-317-080 0E C-CAP,U 0.1-50 Z F HASC1M CX-NSZ809
O POWER AMP C 0227 87-A12-317-080 0E C-CAP,U 0.1-50 Z F HASC1M CX-NSZ809
O POWER AMP C 0228 87-A12-317-080 0E C-CAP,U 0.1-50 Z F HASC1M CX-NSZ809
O POWER AMP C 0241 87-010-831-080 0E C-CAP,U 0.1-16 Z F HASC1M CX-NSZ809
O POWER AMP CN 0003 8 -NF7-619-010 0E CONN ASSY,2P V PANO HASC1M CX-NSZ809
! O POWER AMP CN 0101 87-099-197-010 0E CONN,9P V LK 6216 HASC1M CX-NSZ809
S POWER AMP D 0101 87-A40-269-080 0E C-DIODE,MC2836 HASC1M CX-NSZ809
S POWER AMP D 0103 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S POWER AMP D 0104 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S POWER AMP D 0105 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S POWER AMP D 0106 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S POWER AMP D 0107 87-A40-488-080 0E DIODE,1SS244 HASC1M CX-NSZ809
S POWER AMP D 0108 87-A40-488-080 0E DIODE,1SS244 HASC1M CX-NSZ809
S POWER AMP D 0115 87-A40-270-080 0E C-DIODE,MC2838 HASC1M CX-NSZ809
S POWER AMP D 0117 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S POWER AMP D 0118 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S POWER AMP D 0150 87-A40-270-080 0E C-DIODE,MC2838 HASC1M CX-NSZ809
S POWER AMP D 0160 87-A40-270-080 0E C-DIODE,MC2838 HASC1M CX-NSZ809
S POWER AMP D 0185 87-A40-393-090 0E DIODE,1N5402GW(F20) HASC1M CX-NSZ809
S POWER AMP D 0186 87-A40-393-090 0E DIODE,1N5402GW(F20) HASC1M CX-NSZ809
S POWER AMP D 0187 87-A40-747-080 0E ZENER,UZ5.1 S HASC1M CX-NSZ809
S POWER AMP D 0188 87-A40-749-080 0E ZENER,UZ5.6 S HASC1M CX-NSZ809
S POWER AMP D 0189 87-A40-270-080 0E C-DIODE,MC2838 HASC1M CX-NSZ809
S POWER AMP D 0190 87-A40-269-080 0E C-DIODE,MC2836 HASC1M CX-NSZ809
S POWER AMP D 0191 87-A40-764-080 0E ZENER,UZ10 SC HASC1M CX-NSZ809
S POWER AMP D 0192 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S POWER AMP D 0193 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
O POWER AMP J 0201 87-A60-929-010 1A JACK,DIA6.3 LK ST W/S TAI HASC1M CX-NSZ809
! O POWER AMP J 0203 87-A60-238-010 1A TERMINAL,SP 4P (MSC) HASC1M CX-NSZ809
O POWER AMP J 0207 87-A60-881-010 0E JACK,PIN 2P MSP 242V05 P SN HASC1M CX-NSZ809
X POWER AMP JR 0101 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X POWER AMP JR 0102 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X POWER AMP JR 0103 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X POWER AMP JR 0104 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X POWER AMP JR 0105 88-128-223-080 0E C-RES, 22K-1/8W J HASC1M CX-NSZ809
X POWER AMP JR 0107 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X POWER AMP JR 0109 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X POWER AMP JR 0110 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X POWER AMP JR 0111 88-129-000-080 0E C-JUMPER,3216 HASC1M CX-NSZ809
X POWER AMP JR 0113 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X POWER AMP JR 0114 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
O POWER AMP JR 0123 87-A10-596-080 0E C-CAP,S 100P-100 J CH HASC1M CX-NSZ809
O POWER AMP JR 0124 87-A10-596-080 0E C-CAP,S 100P-100 J CH HASC1M CX-NSZ809
O POWER AMP L 0201 87-A50-610-010 0E COIL,1UH K(MDEC) HASC1M CX-NSZ809
O POWER AMP L 0202 87-A50-610-010 0E COIL,1UH K(MDEC) HASC1M CX-NSZ809
O POWER AMP L 0203 87-A50-610-010 0E COIL,1UH K(MDEC) HASC1M CX-NSZ809
O POWER AMP L 0204 87-A50-610-010 0E COIL,1UH K(MDEC) HASC1M CX-NSZ809
S POWER AMP Q 0103 87-A30-107-070 0E C-TR,CM T5401 HASC1M CX-NSZ809
S POWER AMP Q 0104 87-A30-107-070 0E C-TR,CM T5401 HASC1M CX-NSZ809
S POWER AMP Q 0105 87-A30-107-070 0E C-TR,CM T5401 HASC1M CX-NSZ809
S POWER AMP Q 0106 87-A30-107-070 0E C-TR,CM T5401 HASC1M CX-NSZ809

 18 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
S POWER AMP Q 0107 87-A30-076-080 0E C-TR,2SC3052F HASC1M CX-NSZ809
S POWER AMP Q 0108 87-A30-076-080 0E C-TR,2SC3052F HASC1M CX-NSZ809
S POWER AMP Q 0109 87-A30-076-080 0E C-TR,2SC3052F HASC1M CX-NSZ809
S POWER AMP Q 0110 87-A30-076-080 0E C-TR,2SC3052F HASC1M CX-NSZ809
S POWER AMP Q 0111 87-A30-190-080 0E TR,CC5551 HASC1M CX-NSZ809
S POWER AMP Q 0112 87-A30-190-080 0E TR,CC5551 HASC1M CX-NSZ809
S POWER AMP Q 0113 87-A30-076-080 0E C-TR,2SC3052F HASC1M CX-NSZ809
S POWER AMP Q 0114 87-A30-076-080 0E C-TR,2SC3052F HASC1M CX-NSZ809
S POWER AMP Q 0115 87-A30-106-040 0E C-TR,CM T5551 HASC1M CX-NSZ809
S POWER AMP Q 0116 87-A30-106-040 0E C-TR,CM T5551 HASC1M CX-NSZ809
S POWER AMP Q 0121 87-A30-190-080 0E TR,CC5551 HASC1M CX-NSZ809
S POWER AMP Q 0122 87-A30-190-080 0E TR,CC5551 HASC1M CX-NSZ809
S POWER AMP Q 0123 87-A30-107-070 0E C-TR,CM T5401 HASC1M CX-NSZ809
S POWER AMP Q 0124 87-A30-107-070 0E C-TR,CM T5401 HASC1M CX-NSZ809
S POWER AMP Q 0126 87-A30-107-070 0E C-TR,CM T5401 HASC1M CX-NSZ809
S POWER AMP Q 0127 87-A30-076-080 0E C-TR,2SC3052F HASC1M CX-NSZ809
S POWER AMP Q 0128 87-A30-076-080 0E C-TR,2SC3052F HASC1M CX-NSZ809
S POWER AMP Q 0130 87-A30-106-040 0E C-TR,CM T5551 HASC1M CX-NSZ809
S POWER AMP Q 0131 87-A30-098-010 1C TR,FP1016 HASC1M CX-NSZ809
S POWER AMP Q 0132 87-A30-098-010 1C TR,FP1016 HASC1M CX-NSZ809
S POWER AMP Q 0133 87-A30-097-010 1C TR,FN1016 HASC1M CX-NSZ809
S POWER AMP Q 0134 87-A30-097-010 1C TR,FN1016 HASC1M CX-NSZ809
S POWER AMP Q 0183 87-A30-162-010 1 FET,2SK2937 HASC1M CX-NSZ809
S POWER AMP Q 0184 87-A30-162-010 1 FET,2SK2937 HASC1M CX-NSZ809
S POWER AMP Q 0185 87-A30-076-080 0E C-TR,2SC3052F HASC1M CX-NSZ809
S POWER AMP Q 0186 87-A30-075-080 0E C-TR,2SA1235F HASC1M CX-NSZ809
S POWER AMP Q 0187 87-A30-075-080 0E C-TR,2SA1235F HASC1M CX-NSZ809
X POWER AMP R 0101 88-108-392-080 0E C-RES,U 3.9K-1/16W J HASC1M CX-NSZ809
X POWER AMP R 0102 88-108-392-080 0E C-RES,U 3.9K-1/16W J HASC1M CX-NSZ809
X POWER AMP R 0103 88-108-473-080 0E C-RES,U 47K-1/16W J HASC1M CX-NSZ809
X POWER AMP R 0104 88-108-473-080 0E C-RES,U 47K-1/16W J HASC1M CX-NSZ809
X POWER AMP R 0105 88-108-273-080 0E C-RES,U 27K-1/16W J HASC1M CX-NSZ809
X POWER AMP R 0106 88-108-273-080 0E C-RES,U 27K-1/16W J HASC1M CX-NSZ809
X POWER AMP R 0107 88-108-101-080 0E C-RES,U 100-1/16W J HASC1M CX-NSZ809
X POWER AMP R 0108 88-108-101-080 0E C-RES,U 100-1/16W J HASC1M CX-NSZ809
X POWER AMP R 0111 88-118-102-080 0E C-RES,S 1K-1/10W J HASC1M CX-NSZ809
X POWER AMP R 0112 88-118-102-080 0E C-RES,S 1K-1/10W J HASC1M CX-NSZ809
X POWER AMP R 0113 88-118-273-080 0E C-RES,S 27K-1/10W J HASC1M CX-NSZ809
X POWER AMP R 0114 88-118-273-080 0E C-RES,S 27K-1/10W J HASC1M CX-NSZ809
X POWER AMP R 0115 88-128-222-080 0E C-RES, 2.2K-1/8W J HASC1M CX-NSZ809
X POWER AMP R 0116 88-128-222-080 0E C-RES, 2.2K-1/8W J HASC1M CX-NSZ809
X POWER AMP R 0117 88-108-103-080 0E C-RES,U 10K-1/16W J HASC1M CX-NSZ809
X POWER AMP R 0118 88-108-103-080 0E C-RES,U 10K-1/16W J HASC1M CX-NSZ809
X POWER AMP R 0119 88-118-101-080 0E C-RES,S 100-1/10W J HASC1M CX-NSZ809
X POWER AMP R 0120 88-118-101-080 0E C-RES,S 100-1/10W J HASC1M CX-NSZ809
X POWER AMP R 0121 88-118-101-080 0E C-RES,S 100-1/10W J HASC1M CX-NSZ809
X POWER AMP R 0122 88-118-101-080 0E C-RES,S 100-1/10W J HASC1M CX-NSZ809
X POWER AMP R 0123 88-128-222-080 0E C-RES, 2.2K-1/8W J HASC1M CX-NSZ809
X POWER AMP R 0124 88-128-222-080 0E C-RES, 2.2K-1/8W J HASC1M CX-NSZ809
X POWER AMP R 0125 88-128-102-080 0E C-RES, 1K-1/8W J HASC1M CX-NSZ809
X POWER AMP R 0126 88-128-102-080 0E C-RES, 1K-1/8W J HASC1M CX-NSZ809
X POWER AMP R 0127 88-118-390-080 0E C-RES,S 39-1/10W J HASC1M CX-NSZ809
X POWER AMP R 0128 88-118-390-080 0E C-RES,S 39-1/10W J HASC1M CX-NSZ809
O POWER AMP R 0129 87-A00-262-080 0E RES,M/F 0.15-2W J HASC1M CX-NSZ809
O POWER AMP R 0130 87-A00-262-080 0E RES,M/F 0.15-2W J HASC1M CX-NSZ809
O POWER AMP R 0131 87-A00-262-080 0E RES,M/F 0.15-2W J HASC1M CX-NSZ809
O POWER AMP R 0132 87-A00-262-080 0E RES,M/F 0.15-2W J HASC1M CX-NSZ809
X POWER AMP R 0133 88-108-222-080 0E C-RES,U 2.2K-1/16W J HASC1M CX-NSZ809
X POWER AMP R 0134 88-108-222-080 0E C-RES,U 2.2K-1/16W J HASC1M CX-NSZ809
X POWER AMP R 0135 88-108-152-080 0E C-RES,U 1.5K-1/16W J HASC1M CX-NSZ809
X POWER AMP R 0136 88-108-152-080 0E C-RES,U 1.5K-1/16W J HASC1M CX-NSZ809
X POWER AMP R 0137 88-108-101-080 0E C-RES,U 100-1/16W J HASC1M CX-NSZ809
X POWER AMP R 0138 88-108-101-080 0E C-RES,U 100-1/16W J HASC1M CX-NSZ809
X POWER AMP R 0141 88-118-102-080 0E C-RES,S 1K-1/10W J HASC1M CX-NSZ809
X POWER AMP R 0142 88-118-102-080 0E C-RES,S 1K-1/10W J HASC1M CX-NSZ809
X POWER AMP R 0151 88-108-473-080 0E C-RES,U 47K-1/16W J HASC1M CX-NSZ809
X POWER AMP R 0152 88-108-473-080 0E C-RES,U 47K-1/16W J HASC1M CX-NSZ809
X POWER AMP R 0153 88-118-390-080 0E C-RES,S 39-1/10W J HASC1M CX-NSZ809
X POWER AMP R 0154 88-118-390-080 0E C-RES,S 39-1/10W J HASC1M CX-NSZ809
X POWER AMP R 0155 88-118-562-080 0E C-RES,S 5.6K-1/10W J HASC1M CX-NSZ809

 19 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
X POWER AMP R 0156 88-118-562-080 0E C-RES,S 5.6K-1/10W J HASC1M CX-NSZ809
X POWER AMP R 0157 88-108-472-080 0E C-RES,U 4.7K-1/16W J HASC1M CX-NSZ809
X POWER AMP R 0158 88-128-392-080 0E C-RES, 3.9K-1/8W J HASC1M CX-NSZ809
X POWER AMP R 0159 88-108-103-080 0E C-RES,U 10K-1/16W J HASC1M CX-NSZ809
X POWER AMP R 0160 88-121-103-080 0E RES,10K-1/8W J HASC1M CX-NSZ809
X POWER AMP R 0161 88-108-472-080 0E C-RES,U 4.7K-1/16W J HASC1M CX-NSZ809
X POWER AMP R 0162 88-108-472-080 0E C-RES,U 4.7K-1/16W J HASC1M CX-NSZ809
X POWER AMP R 0163 88-108-472-080 0E C-RES,U 4.7K-1/16W J HASC1M CX-NSZ809
X POWER AMP R 0164 88-108-472-080 0E C-RES,U 4.7K-1/16W J HASC1M CX-NSZ809
X POWER AMP R 0165 88-108-152-080 0E C-RES,U 1.5K-1/16W J HASC1M CX-NSZ809
X POWER AMP R 0166 88-108-152-080 0E C-RES,U 1.5K-1/16W J HASC1M CX-NSZ809
X POWER AMP R 0167 88-108-103-080 0E C-RES,U 10K-1/16W J HASC1M CX-NSZ809
X POWER AMP R 0168 88-118-473-080 0E C-RES,S 47K-1/10W J HASC1M CX-NSZ809
X POWER AMP R 0169 88-118-271-080 0E C-RES,S 270-1/10W J HASC1M CX-NSZ809
X POWER AMP R 0170 88-118-271-080 0E C-RES,S 270-1/10W J HASC1M CX-NSZ809
X POWER AMP R 0171 88-118-222-080 0E C-RES,S 2.2K-1/10W J HASC1M CX-NSZ809
X POWER AMP R 0172 88-118-222-080 0E C-RES,S 2.2K-1/10W J HASC1M CX-NSZ809
X POWER AMP R 0173 88-118-152-080 0E C-RES,S 1.5K-1/10W J HASC1M CX-NSZ809
X POWER AMP R 0174 88-118-152-080 0E C-RES,S 1.5K-1/10W J HASC1M CX-NSZ809
X POWER AMP R 0175 88-118-331-080 0E C-RES,S 330-1/10W J HASC1M CX-NSZ809
X POWER AMP R 0176 88-118-331-080 0E C-RES,S 330-1/10W J HASC1M CX-NSZ809
X POWER AMP R 0177 88-128-332-080 0E C-RES, 3.3K-1/8W J HASC1M CX-NSZ809
X POWER AMP R 0178 88-118-103-080 0E C-RES,S 10K-1/10W J HASC1M CX-NSZ809
X POWER AMP R 0179 88-118-103-080 0E C-RES,S 10K-1/10W J HASC1M CX-NSZ809
X POWER AMP R 0180 88-118-103-080 0E C-RES,S 10K-1/10W J HASC1M CX-NSZ809
X POWER AMP R 0184 88-118-102-080 0E C-RES,S 1K-1/10W J HASC1M CX-NSZ809
X POWER AMP R 0185 88-108-332-080 0E C-RES,U 3.3K-1/16W J HASC1M CX-NSZ809
X POWER AMP R 0186 88-118-102-080 0E C-RES,S 1K-1/10W J HASC1M CX-NSZ809
X POWER AMP R 0187 88-118-103-080 0E C-RES,S 10K-1/10W J HASC1M CX-NSZ809
X POWER AMP R 0188 88-118-222-080 0E C-RES,S 2.2K-1/10W J HASC1M CX-NSZ809
X POWER AMP R 0189 88-128-392-080 0E C-RES, 3.9K-1/8W J HASC1M CX-NSZ809
X POWER AMP R 0190 88-128-392-080 0E C-RES, 3.9K-1/8W J HASC1M CX-NSZ809
X POWER AMP R 0192 88-128-332-080 0E C-RES, 3.3K-1/8W J HASC1M CX-NSZ809
X POWER AMP R 0193 88-108-103-080 0E C-RES,U 10K-1/16W J HASC1M CX-NSZ809
X POWER AMP R 0194 88-108-103-080 0E C-RES,U 10K-1/16W J HASC1M CX-NSZ809
X POWER AMP R 0195 88-108-473-080 0E C-RES,U 47K-1/16W J HASC1M CX-NSZ809
X POWER AMP R 0196 88-108-473-080 0E C-RES,U 47K-1/16W J HASC1M CX-NSZ809
X POWER AMP R 0197 88-108-473-080 0E C-RES,U 47K-1/16W J HASC1M CX-NSZ809
X POWER AMP R 0198 88-108-473-080 0E C-RES,U 47K-1/16W J HASC1M CX-NSZ809
X POWER AMP R 0199 88-108-225-080 0E C-RES,U 2.2M-1/16W J HASC1M CX-NSZ809
X POWER AMP R 0201 88-108-223-080 0E C-RES,U 22K-1/16W J HASC1M CX-NSZ809
X POWER AMP R 0202 88-108-223-080 0E C-RES,U 22K-1/16W J HASC1M CX-NSZ809
X POWER AMP R 0203 88-108-000-080 0E C-JUMPER,U HASC1M CX-NSZ809
X POWER AMP R 0204 88-121-102-080 0E RES,1K-1/8W J HASC1M CX-NSZ809
X POWER AMP R 0205 88-121-102-080 0E RES,1K-1/8W J HASC1M CX-NSZ809
X POWER AMP R 0207 88-128-100-080 0E C-RES, 10-1/8W J HASC1M CX-NSZ809
X POWER AMP R 0208 88-128-100-080 0E C-RES, 10-1/8W J HASC1M CX-NSZ809
X POWER AMP R 0209 88-121-100-080 0E RES,10-1/8W J HASC1M CX-NSZ809
X POWER AMP R 0210 88-128-100-080 0E C-RES, 10-1/8W J HASC1M CX-NSZ809
X POWER AMP R 0231 88-108-473-080 0E C-RES,U 47K-1/16W J HASC1M CX-NSZ809
X POWER AMP R 0232 88-108-473-080 0E C-RES,U 47K-1/16W J HASC1M CX-NSZ809
O POWER AMP R 0243 87-A01-001-050 0E RES,220-1/2W J LT2J HASC1M CX-NSZ809
O POWER AMP R 0244 87-A01-001-050 0E RES,220-1/2W J LT2J HASC1M CX-NSZ809
O POWER AMP R 0245 87-A01-001-050 0E RES,220-1/2W J LT2J HASC1M CX-NSZ809
O POWER AMP R 0246 87-A01-001-050 0E RES,220-1/2W J LT2J HASC1M CX-NSZ809
X POWER AMP R 0247 88-130-100-080 0E RES,10-1/4W J HASC1M CX-NSZ809
X POWER AMP R 0248 88-130-100-080 0E RES,10-1/4W J HASC1M CX-NSZ809
X POWER AMP R 0249 88-128-100-080 0E C-RES, 10-1/8W J HASC1M CX-NSZ809
X POWER AMP R 0250 88-121-100-080 0E RES,10-1/8W J HASC1M CX-NSZ809
X POWER AMP R 0265 88-128-222-080 0E C-RES, 2.2K-1/8W J HASC1M CX-NSZ809
X POWER AMP R 0266 88-128-222-080 0E C-RES, 2.2K-1/8W J HASC1M CX-NSZ809
O POWER AMP TH 0101 87-A91-042-080 0E C-THMS,100K 55001 HASC1M CX-NSZ809
O POWER AMP TH 0102 87-A91-042-080 0E C-THMS,100K 55001 HASC1M CX-NSZ809
X PRINTED DU 87- 40-427-010 0E AG,PV 0.04-200-350 PL-SPA HASC1M CX-NSZ809
X PT * 8 -NF7-617-010 1 PW ,PT-85 H 2M HASC1M CX-NSZ809
! O PT CN 0001 87-A61-110-010 0E CONN,9P V TID-A HASC1M CX-NSZ809
S PT D 0002 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S PT D 0003 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S PT D 0004 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809
S PT D 0005 87-A40-291-080 0E DIODE,1N4148M (CPT) HASC1M CX-NSZ809

 20 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
! O PT PT 0002 8 -MA6-673-010 1 PT,SU MA H (VRK) HASC1M CX-NSZ809
! O PT RY 0001 87-A91-339-010 1 RELAY,AC DC12V G5PA-2 HASC1M CX-NSZ809
! O PT S 0001 87-A90-165-010 1A SW,SL 1-2-3 SWS2301 HASC1M CX-NSZ809
O PT T 0001 87-A60-317-010 0E TERMINAL, 1P MSC HASC1M CX-NSZ809
O PT T 0002 87-A60-317-010 0E TERMINAL, 1P MSC HASC1M CX-NSZ809
O SCREW 87-067-579-010 0E VT2+3-8 W/0 SL0T HASC1M CX-NSZ809
O SCREW 87-067-579-010 0E VT2+3-8 W/0 SL0T LHSKM CX-SNSZ809
O SCREW 87-067-641-010 0E UTT2+3-8 W/O SLOT LK HASC1M CX-NSZ809
O SCREW 87-067-641-010 0E UTT2+3-8 W/O SLOT LK LHSKM CX-SNSZ809
O SCREW 87-067-688-010 0E VTT+3-6 HASC1M CX-NSZ809
O SCREW 87-067-688-010 0E VTT+3-6 LHSKM CX-SNSZ809
O SCREW 87-067-703-010 0E VT2+3-10 W/0 SL0T HASC1M CX-NSZ809
O SCREW 87-067-703-010 0E VT2+3-10 W/0 SL0T LHSKM CX-SNSZ809
O SCREW 87-067-758-010 0E VT2+3-12 W/0 SL0T HASC1M CX-NSZ809
O SCREW 87-067-758-010 0E VT2+3-12 W/0 SL0T LHSKM CX-SNSZ809
O SCREW 87-078-199-010 0E S-SCREW,ITC+4-10 R HASC1M CX-NSZ809
O SCREW 87-078-199-010 0E S-SCREW,ITC+4-10 R LHSKM CX-SNSZ809
O SCREW 87-721-096-410 0E QT2+3-10 W/O SLOT HASC1M CX-NSZ809
O SCREW 87-721-096-410 0E QT2+3-10 W/O SLOT LHSKM CX-SNSZ809
O SCREW 87-721-097-410 0E QT2+3-12 W/O SLOT HASC1M CX-NSZ809
O SCREW 87-721-097-410 0E QT2+3-12 W/O SLOT LHSKM CX-SNSZ809
O SCREW 87- 10-315-010 0E VIT3 +3-8 R W/O HASC1M CX-NSZ809
O SCREW 87- 10-315-010 0E VIT3 +3-8 R W/O LHSKM CX-SNSZ809
O SCREW 87-NF4-224-010 0E S-SCREW,IT3 +3-8 CU HASC1M CX-NSZ809
O SCREW 87-NF4-224-010 0E S-SCREW,IT3 +3-8 CU LHSKM CX-SNSZ809
X TAPE 80-MQ1-209-010 0E CLOTH,20-7 HASC1M CX-NSZ809
X TAPE 80-MQ1-209-010 0E CLOTH,20-7 LHSKM CX-SNSZ809
! X TAPE 87-069-033-010 0E CA LE,TIE HASC1M CX-NSZ809
! X TAPE 87-069-033-010 0E CA LE,TIE LHSKM CX-SNSZ809
O TAPE 87-NF6-615-010 0E CONN ASSY,3P P HASC1M CX-NSZ809
O TAPE 87-NF6-615-010 0E CONN ASSY,3P P LHSKM CX-SNSZ809
O TAPE 87-NF6-616-010 1 CONN ASSY,8P RP HASC1M CX-NSZ809
O TAPE 87-NF6-616-010 1 CONN ASSY,8P RP LHSKM CX-SNSZ809
X TAPE M8-2ZM-381-130 2D 2ZM-3 MK2 YPR4NM HASC1M CX-NSZ809
X TAPE M8-2ZM-381-130 2D 2ZM-3 MK2 YPR4NM LHSKM CX-SNSZ809
O TAPE DECK C 0301 87-012-274-080 0E C-CAP,U 1000P-50 K HASC1M CX-NSZ809
O TAPE DECK C 0302 87-012-274-080 0E C-CAP,U 1000P-50 K HASC1M CX-NSZ809
O TAPE DECK C 0303 87-012-275-080 0E C-CAP,U 1200P-50 K GRM HASC1M CX-NSZ809
O TAPE DECK C 0304 87-012-275-080 0E C-CAP,U 1200P-50 K GRM HASC1M CX-NSZ809
O TAPE DECK C 0307 87-A12-062-080 0E CAP,E 100-10 SMG HASC1M CX-NSZ809
O TAPE DECK C 0308 87-A12-062-080 0E CAP,E 100-10 SMG HASC1M CX-NSZ809
O TAPE DECK C 0309 87-012-188-080 0E C-CAP,U 47P-50 J CH HASC1M CX-NSZ809
O TAPE DECK C 0310 87-012-188-080 0E C-CAP,U 47P-50 J CH HASC1M CX-NSZ809
O TAPE DECK C 0313 87-012-284-080 0E C-CAP,U 6800P-50 K GRM HASC1M CX-NSZ809
O TAPE DECK C 0314 87-012-284-080 0E C-CAP,U 6800P-50 K GRM HASC1M CX-NSZ809
O TAPE DECK C 0315 87-A12-062-080 0E CAP,E 100-10 SMG HASC1M CX-NSZ809
O TAPE DECK C 0317 87-A12-085-080 0E CAP,E 0.33-50 SMG HASC1M CX-NSZ809
O TAPE DECK C 0318 87-A12-085-080 0E CAP,E 0.33-50 SMG HASC1M CX-NSZ809
O TAPE DECK C 0326 87-010-787-080 0E C-CAP,U 0.022-25 K HASC1M CX-NSZ809
O TAPE DECK C 0327 87-010-831-080 0E C-CAP,U 0.1-16 Z F HASC1M CX-NSZ809
O TAPE DECK C 0360 87-A12-087-080 0E CAP,E 1-50 SMG HASC1M CX-NSZ809
O TAPE DECK C 0399 87-A10-039-080 0E C-CAP,U 470P-50 J CH HASC1M CX-NSZ809
O TAPE DECK C 0401 87-A12-083-080 0E CAP,E 0.1-50 SMG HASC1M CX-NSZ809
O TAPE DECK C 0402 87-A12-083-080 0E CAP,E 0.1-50 SMG HASC1M CX-NSZ809
O TAPE DECK C 0403 87-012-193-080 0E C-CAP,U 82P-50 J CH HASC1M CX-NSZ809
O TAPE DECK C 0404 87-012-193-080 0E C-CAP,U 82P-50 J CH HASC1M CX-NSZ809
O TAPE DECK C 0405 87-012-283-080 0E C-CAP,U 5600P-50 K HASC1M CX-NSZ809
O TAPE DECK C 0406 87-012-283-080 0E C-CAP,U 5600P-50 K HASC1M CX-NSZ809
O TAPE DECK C 0407 87-012-281-080 0E C-CAP,U 3900P-50 K GRM HASC1M CX-NSZ809
O TAPE DECK C 0408 87-012-281-080 0E C-CAP,U 3900P-50 K GRM HASC1M CX-NSZ809
O TAPE DECK C 0409 87-012-278-080 0E C-CAP,U 2200P-50 K HASC1M CX-NSZ809
O TAPE DECK C 0410 87-012-278-080 0E C-CAP,U 2200P-50 K HASC1M CX-NSZ809
O TAPE DECK C 0411 87-A12-091-080 0E CAP,E 10-50 SMG HASC1M CX-NSZ809
O TAPE DECK C 0412 87-A12-091-080 0E CAP,E 10-50 SMG HASC1M CX-NSZ809
O TAPE DECK C 0452 87-A12-069-080 0E CAP,E 22-25 SMG HASC1M CX-NSZ809
O TAPE DECK C 0453 87-012-279-080 0E C-CAP,U 2700P-50 K GRM HASC1M CX-NSZ809
O TAPE DECK C 0454 87-012-279-080 0E C-CAP,U 2700P-50 K GRM HASC1M CX-NSZ809
O TAPE DECK C 0455 87-012-279-080 0E C-CAP,U 2700P-50 K GRM HASC1M CX-NSZ809
O TAPE DECK C 0456 87-012-286-080 0E C-CAP,U 0.01-25 K HASC1M CX-NSZ809
O TAPE DECK C 0457 87-A12-361-080 0E CAP,M 5600P-100 J CP HASC1M CX-NSZ809
