SERVICE MANUAL
DATA
CD STEREO SYSTEM
NSX-R20
S/M Code No. 09-023-454-0T2
SIMPLE
K(S)
BASIC TAPE MECHANISM : CMAT6Z2(1+1)ALPS
BASIC CD MECHANISM : BZG-2 ZD9GNC1
 This Service Manual is with Revision Publishing and when it is issued.
NSX-R21 EZ(S)

! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
 2 
ELECTRICAL PARTS LIST
CX-SNR20 CX-SNR21
KSC1 EZSC1
AC O C 0091 87-012-368-080 C-CAP,S 0.1-50 Z F a b
AC S D 0091 87-A40-269-080 C-DIODE,MC2836 a b
AC S D 0092 87-A40-270-080 C-DIODE,MC2838 a b
AC X W 0076 88-100-000-010 PLATING- W, 0.58 SN95 a b
AC X W 0092 88-100-000-010 PLATING- W, 0.58 SN95 a b
AC X W 0093 88-100-000-010 PLATING- W, 0.58 SN95 a b
AC X W 0094 88-100-000-010 PLATING- W, 0.58 SN95 a b
AC X PR 0003 88-100-000-010 PLATING- W, 0.58 SN95 a b
AC ! O PT 0002 8B-MA6-675-010 PT,SUB BMA E (VRK) a b
AC ! O RY 0001 87-A91-418-010 RELAY,AC12V G5PA-1-M a b
AC O T 0001 87-A60-317-010 TERMINAL, 1P MSC a b
AC O T 0002 87-A60-317-010 TERMINAL, 1P MSC a b
AC ! O WH 0002 87-A90-510-010 HLDR,WIRE 2.5-9P a b
FUNC/TAPE/E.VR O C 0301 87-012-275-080 C-CAP,U 1200P-50 K B GRM a b
FUNC/TAPE/E.VR O C 0302 87-012-275-080 C-CAP,U 1200P-50 K B GRM a b
FUNC/TAPE/E.VR O C 0303 87-012-275-080 C-CAP,U 1200P-50 K B GRM a b
FUNC/TAPE/E.VR O C 0304 87-012-275-080 C-CAP,U 1200P-50 K B GRM a b
FUNC/TAPE/E.VR O C 0305 87-A10-039-080 C-CAP,U 470P-50 CH a b
FUNC/TAPE/E.VR O C 0310 87-012-274-080 C-CAP,U 1000P-50 K B a b
FUNC/TAPE/E.VR O C 0363 87-010-759-080 C-CAP,U 0.1-25 Z F a b
CX-SNR20 CX-SNR21
KSC1 EZSC1
FUNC/TAPE/E.VR O C 0451 87-010-759-080 C-CAP,U 0.1-25 Z F a b
FUNC/TAPE/E.VR O C 0452 87-010-406-080 CAP,E 22-50 M 11L SME a b
FUNC/TAPE/E.VR O C 0453 87-012-279-080 C-CAP,U 2700P-50 K B GRM a b
FUNC/TAPE/E.VR O C 0454 87-012-279-080 C-CAP,U 2700P-50 K B GRM a b
FUNC/TAPE/E.VR O C 0455 87-012-279-080 C-CAP,U 2700P-50 K B GRM a b
FUNC/TAPE/E.VR O C 0456 87-012-286-080 C-CAP,U 0.01-25 K B a b
FUNC/TAPE/E.VR O C 0457 87-A12-361-080 CAP,M 5600P-100 CP a b
FUNC/TAPE/E.VR O C 0458 87-012-278-080 C-CAP,U 2200P-50 K B a b
FUNC/TAPE/E.VR O C 0459 87-012-271-080 C-CAP,U 560P-50 K B a b
FUNC/TAPE/E.VR O C 0460 87-012-368-080 C-CAP,S 0.1-50 Z F a b
FUNC/TAPE/E.VR O C 0461 87-012-158-080 C-CAP,S 390P-50 CH GRM a b
FUNC/TAPE/E.VR O C 0462 87-012-158-080 C-CAP,S 390P-50 CH GRM a b
FUNC/TAPE/E.VR O C 0463 87-010-759-080 C-CAP,U 0.1-25 Z F a b
FUNC/TAPE/E.VR O C 0464 87-012-278-080 C-CAP,U 2200P-50 K B a b
FUNC/TAPE/E.VR O C 0465 87-012-286-080 C-CAP,U 0.01-25 K B a b
FUNC/TAPE/E.VR O C 0601 87-012-188-080 C-CAP,U 47P-50 CH a b
FUNC/TAPE/E.VR O C 0602 87-012-188-080 C-CAP,U 47P-50 CH a b
FUNC/TAPE/E.VR O C 0603 87-010-263-080 CAP,E 100-10 M 11L SME a b
FUNC/TAPE/E.VR O C 0604 87-010-263-080 CAP,E 100-10 M 11L SME a b
FUNC/TAPE/E.VR O C 0605 87-A12-362-080 CAP,M 6800P-100 CP a b
CX-SNR20 CX-SNR21
KSC1 EZSC1
FUNC/TAPE/E.VR O C 0606 87-A12-362-080 CAP,M 6800P-100 CP a b
FUNC/TAPE/E.VR O C 0607 87-A10-039-080 C-CAP,U 470P-50 CH a b
FUNC/TAPE/E.VR O C 0608 87-A10-039-080 C-CAP,U 470P-50 CH a b
FUNC/TAPE/E.VR O C 0609 87-010-401-080 CAP,E 1-50 M 11L SME a b
FUNC/TAPE/E.VR O C 0610 87-010-401-080 CAP,E 1-50 M 11L SME a b
FUNC/TAPE/E.VR O C 0611 87-A12-348-080 C-CAP,U 560P-25 CH a b
FUNC/TAPE/E.VR O C 0612 87-A12-348-080 C-CAP,U 560P-25 CH a b
FUNC/TAPE/E.VR O C 0613 87-012-280-080 C-CAP,U 3300P-50 K B a b
FUNC/TAPE/E.VR O C 0614 87-012-280-080 C-CAP,U 3300P-50 K B a b
FUNC/TAPE/E.VR O C 0615 87-010-545-080 CAP,E 0.22-50 M 11L SME a b
FUNC/TAPE/E.VR O C 0616 87-010-545-080 CAP,E 0.22-50 M 11L SME a b
FUNC/TAPE/E.VR O C 0617 87-010-545-080 CAP,E 0.22-50 M 11L SME a b
FUNC/TAPE/E.VR O C 0618 87-010-545-080 CAP,E 0.22-50 M 11L SME a b
FUNC/TAPE/E.VR O C 0625 87-012-198-080 C-CAP,U 180P-50 CH a b
FUNC/TAPE/E.VR O C 0626 87-012-198-080 C-CAP,U 180P-50 CH a b
FUNC/TAPE/E.VR O C 0627 87-012-284-080 C-CAP,U 6800P-50 K B GRM a b
FUNC/TAPE/E.VR O C 0628 87-012-284-080 C-CAP,U 6800P-50 K B GRM a b
FUNC/TAPE/E.VR O C 0629 87-012-286-080 C-CAP,U 0.01-25 K B a b
FUNC/TAPE/E.VR O C 0630 87-012-286-080 C-CAP,U 0.01-25 K B a b
FUNC/TAPE/E.VR O C 0631 87-012-278-080 C-CAP,U 2200P-50 K B a b
CX-SNR20 CX-SNR21
KSC1 EZSC1
FUNC/TAPE/E.VR O C 0632 87-012-278-080 C-CAP,U 2200P-50 K B a b
FUNC/TAPE/E.VR O C 0641 87-010-401-080 CAP,E 1-50 M 11L SME a b
FUNC/TAPE/E.VR O C 0642 87-010-401-080 CAP,E 1-50 M 11L SME a b
FUNC/TAPE/E.VR O C 0651 87-010-248-080 CAP,E 220-10 M 11L SME a b
FUNC/TAPE/E.VR O C 0652 87-010-260-080 CAP,E 47-25 M 11L SME a b
FUNC/TAPE/E.VR O C 0655 87-010-404-080 CAP,E 4.7-50 M 11L SME a b
FUNC/TAPE/E.VR O C 0656 87-010-784-080 C-CAP,U 0.012-25 K B a b
FUNC/TAPE/E.VR O C 0663 87-010-759-080 C-CAP,U 0.1-25 Z F a b
FUNC/TAPE/E.VR O C 0664 87-010-759-080 C-CAP,U 0.1-25 Z F a b
FUNC/TAPE/E.VR O C 0665 87-A10-504-080 C-CAP,U 0.047-16 K B a b
FUNC/TAPE/E.VR O C 0666 87-A10-504-080 C-CAP,U 0.047-16 K B a b
FUNC/TAPE/E.VR O C 0669 87-012-274-080 C-CAP,U 1000P-50 K B a b
FUNC/TAPE/E.VR O C 0670 87-012-274-080 C-CAP,U 1000P-50 K B a b
FUNC/TAPE/E.VR O C 0677 87-012-286-080 C-CAP,U 0.01-25 K B a b
FUNC/TAPE/E.VR X CLP0303 87-A60-884-010 PIN,DIA1 COATING-SHS a b
FUNC/TAPE/E.VR X CLP0304 87-A60-884-010 PIN,DIA1 COATING-SHS a b
FUNC/TAPE/E.VR O CN 0301 87-A60-620-010 CONN,3P V 2MM MT a b
FUNC/TAPE/E.VR O CN 0302 87-A60-625-010 CONN,8P V 2MM MT a b
FUNC/TAPE/E.VR ! O CN 0601 87-099-719-010 CONN,30P H BLK TYK-B(X) a b
FUNC/TAPE/E.VR ! O CN 0602 87-099-194-010 CONN,6P V BLK 6216 a b

! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
 3 
CX-SNR20 CX-SNR21
KSC1 EZSC1
FUNC/TAPE/E.VR S D 0301 87-A40-269-080 C-DIODE,MC2836 a b
FUNC/TAPE/E.VR S D 0661 87-A40-438-080 ZENER,MTZ 4.7A a b
FUNC/TAPE/E.VR S D 0662 87-A40-438-080 ZENER,MTZ 4.7A a b
FUNC/TAPE/E.VR X FB 0601 88-118-000-080 C- UMPER,S a b
FUNC/TAPE/E.VR X FB 0602 88-118-000-080 C- UMPER,S a b
FUNC/TAPE/E.VR X FB 0603 88-100-000-010 PLATING- W, 0.58 SN95 a b
FUNC/TAPE/E.VR S IC 0601 87-A22-236-040 C-IC,BD3881FV a b
FUNC/TAPE/E.VR O 0602 87-A60-881-010 ACK,PIN 2P MSP 242V05 PBSN a b
FUNC/TAPE/E.VR X R 0301 88-108-000-080 C- UMPER,U a b
FUNC/TAPE/E.VR X R 0302 88-108-000-080 C- UMPER,U a b
FUNC/TAPE/E.VR X R 0303 88-108-000-080 C- UMPER,U a b
FUNC/TAPE/E.VR X R 0304 88-129-000-080 C- UMPER, 3216 a b
FUNC/TAPE/E.VR X R 0305 88-108-000-080 C- UMPER,U a b
FUNC/TAPE/E.VR X R 0306 88-129-000-080 C- UMPER, 3216 a b
FUNC/TAPE/E.VR X R 0401 88-129-000-080 C- UMPER, 3216 a b
FUNC/TAPE/E.VR X R 0402 88-129-000-080 C- UMPER, 3216 a b
FUNC/TAPE/E.VR X R 0403 88-108-000-080 C- UMPER,U a b
FUNC/TAPE/E.VR X R 0404 88-108-000-080 C- UMPER,U a b
FUNC/TAPE/E.VR X R 0603 88-108-000-080 C- UMPER,U a b
FUNC/TAPE/E.VR X R 0604 88-129-000-080 C- UMPER, 3216 a b
CX-SNR20 CX-SNR21
KSC1 EZSC1
FUNC/TAPE/E.VR X R 0605 88-108-000-080 C- UMPER,U a b
FUNC/TAPE/E.VR X R 0607 88-108-000-080 C- UMPER,U a b
FUNC/TAPE/E.VR X W 0401 88-100-000-010 PLATING- W, 0.58 SN95 a b
FUNC/TAPE/E.VR X W 0402 88-100-000-010 PLATING- W, 0.58 SN95 a b
FUNC/TAPE/E.VR X W 0403 88-100-000-010 PLATING- W, 0.58 SN95 a b
FUNC/TAPE/E.VR X W 0501 88-100-000-010 PLATING- W, 0.58 SN95 a b
FUNC/TAPE/E.VR X W 0601 88-100-000-010 PLATING- W, 0.58 SN95 a b
FUNC/TAPE/E.VR X W 0602 88-100-000-010 PLATING- W, 0.58 SN95 a b
FUNC/TAPE/E.VR X W 0604 88-100-000-010 PLATING- W, 0.58 SN95 a b
FUNC/TAPE/E.VR X W 0605 88-100-000-010 PLATING- W, 0.58 SN95 a b
FUNC/TAPE/E.VR X W 0606 88-100-000-010 PLATING- W, 0.58 SN95 a b
FUNC/TAPE/E.VR X W 0607 88-100-000-010 PLATING- W, 0.58 SN95 a b
FUNC/TAPE/E.VR X W 0608 88-100-000-010 PLATING- W, 0.58 SN95 a b
FUNC/TAPE/E.VR X W 0609 88-100-000-010 PLATING- W, 0.58 SN95 a b
FUNC/TAPE/E.VR X W 0610 88-100-000-010 PLATING- W, 0.58 SN95 a b
FUNC/TAPE/E.VR X W 0611 88-100-000-010 PLATING- W, 0.58 SN95 a b
FUNC/TAPE/E.VR X W 0612 88-100-000-010 PLATING- W, 0.58 SN95 a b
FUNC/TAPE/E.VR X W 0614 88-100-000-010 PLATING- W, 0.58 SN95 a b
FUNC/TAPE/E.VR X W 0615 88-100-000-010 PLATING- W, 0.58 SN95 a b
FUNC/TAPE/E.VR X W 0616 88-100-000-010 PLATING- W, 0.58 SN95 a b
CX-SNR20 CX-SNR21
KSC1 EZSC1
FUNC/TAPE/E.VR X W 0617 88-100-000-010 PLATING- W, 0.58 SN95 a b
FUNC/TAPE/E.VR X W 0618 88-100-000-010 PLATING- W, 0.58 SN95 a b
FUNC/TAPE/E.VR X W 0619 88-100-000-010 PLATING- W, 0.58 SN95 a b
FUNC/TAPE/E.VR X W 0620 88-100-000-010 PLATING- W, 0.58 SN95 a b
FUNC/TAPE/E.VR X W 0621 88-100-000-010 PLATING- W, 0.58 SN95 a b
FUNC/TAPE/E.VR X W 0622 88-100-000-010 PLATING- W, 0.58 SN95 a b
FUNC/TAPE/E.VR X W 0623 88-100-000-010 PLATING- W, 0.58 SN95 a b
FUNC/TAPE/E.VR X W 0624 88-100-000-010 PLATING- W, 0.58 SN95 a b
FUNC/TAPE/E.VR X W 0625 88-100-000-010 PLATING- W, 0.58 SN95 a b
FUNC/TAPE/E.VR X W 0626 88-100-000-010 PLATING- W, 0.58 SN95 a b
FUNC/TAPE/E.VR X W 0627 88-100-000-010 PLATING- W, 0.58 SN95 a b
FUNC/TAPE/E.VR X W 0641 88-100-000-010 PLATING- W, 0.58 SN95 a b
FUNC/TAPE/E.VR O L 0451 87-007-342-010 COIL,OSC 85KHZ BIAS a b
FUNC/TAPE/E.VR S Q 0301 87-A30-091-080 FET,2S 460 a b
FUNC/TAPE/E.VR S Q 0302 87-A30-091-080 FET,2S 460 a b
FUNC/TAPE/E.VR S Q 0303 87-A30-090-080 FET,2SK2541 a b
FUNC/TAPE/E.VR S Q 0304 87-A30-090-080 FET,2SK2541 a b
FUNC/TAPE/E.VR S Q 0305 87-A30-091-080 FET,2S 460 a b
FUNC/TAPE/E.VR S Q 0306 87-A30-091-080 FET,2S 460 a b
FUNC/TAPE/E.VR S Q 0307 87-A30-090-080 FET,2SK2541 a b
CX-SNR20 CX-SNR21
KSC1 EZSC1
FUNC/TAPE/E.VR S Q 0308 87-A30-090-080 FET,2SK2541 a b
FUNC/TAPE/E.VR S Q 0309 87-A30-090-080 FET,2SK2541 a b
FUNC/TAPE/E.VR S Q 0451 87-A30-630-080 TR,2SC5343GL a b
FUNC/TAPE/E.VR S Q 0452 87-A30-076-080 C-TR,2SC3052F a b
FUNC/TAPE/E.VR S Q 0453 89-333-317-880 TR,2SC3331(T/U) a b
FUNC/TAPE/E.VR S Q 0454 89-333-317-880 TR,2SC3331(T/U) a b
FUNC/TAPE/E.VR S Q 0455 87-A30-119-040 C-TR,2SC3906K R a b
FUNC/TAPE/E.VR S Q 0456 87-A30-076-080 C-TR,2SC3052F a b
FUNC/TAPE/E.VR S Q 0601 87-A30-538-040 C-TR,SRA2202S a b
FUNC/TAPE/E.VR S Q 0651 87-A30-087-080 C-FET,2SK2158 a b
FUNC/TAPE/E.VR S Q 0652 87-A30-087-080 C-FET,2SK2158 a b
FUNC/TAPE/E.VR S Q 0653 87-A30-076-080 C-TR,2SC3052F a b
FUNC/TAPE/E.VR X R 0301 88-108-393-080 C-RES,U 39K-1/16W a b
FUNC/TAPE/E.VR X R 0302 88-108-393-080 C-RES,U 39K-1/16W a b
FUNC/TAPE/E.VR X R 0303 88-108-823-080 C-RES,U 82K-1/16W a b
FUNC/TAPE/E.VR X R 0304 88-108-823-080 C-RES,U 82K-1/16W a b
FUNC/TAPE/E.VR X R 0305 88-108-224-080 C-RES,U 220K-1/16W a b
FUNC/TAPE/E.VR X R 0451 88-108-222-080 C-RES,U 2.2K-1/16W a b
FUNC/TAPE/E.VR X R 0453 88-108-472-080 C-RES,U 4.7K-1/16W a b
FUNC/TAPE/E.VR X R 0454 88-121-829-080 RES,8.2-1/8W a b

! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
 4 
CX-SNR20 CX-SNR21
KSC1 EZSC1
FUNC/TAPE/E.VR X R 0455 88-108-183-080 C-RES,U 18K-1/16W a b
FUNC/TAPE/E.VR X R 0456 88-108-183-080 C-RES,U 18K-1/16W a b
FUNC/TAPE/E.VR X R 0457 88-108-104-080 C-RES,U 100K-1/16W a b
FUNC/TAPE/E.VR X R 0458 88-108-563-080 C-RES,U 56K-1/16W a b
FUNC/TAPE/E.VR X R 0459 88-108-472-080 C-RES,U 4.7K-1/16W a b
FUNC/TAPE/E.VR X R 0461 88-108-472-080 C-RES,U 4.7K-1/16W a b
FUNC/TAPE/E.VR X R 0462 88-108-471-080 C-RES,U 470-1/16W a b
FUNC/TAPE/E.VR X R 0467 88-108-472-080 C-RES,U 4.7K-1/16W a b
FUNC/TAPE/E.VR X R 0468 88-108-272-080 C-RES,U 2.7K-1/16W a b
FUNC/TAPE/E.VR X R 0469 88-108-150-080 C-RES,U 15-1/16W a b
FUNC/TAPE/E.VR X R 0601 88-108-680-080 C-RES,U 68-1/16W a b
FUNC/TAPE/E.VR X R 0602 88-108-680-080 C-RES,U 68-1/16W a b
FUNC/TAPE/E.VR X R 0603 88-108-394-080 C-RES,U 390K-1/16W a b
FUNC/TAPE/E.VR X R 0604 88-108-394-080 C-RES,U 390K-1/16W a b
FUNC/TAPE/E.VR X R 0605 88-108-122-080 C-RES,U 1.2K-1/16W a b
FUNC/TAPE/E.VR X R 0606 88-108-122-080 C-RES,U 1.2K-1/16W a b
FUNC/TAPE/E.VR X R 0607 88-108-183-080 C-RES,U 18K-1/16W a b
FUNC/TAPE/E.VR X R 0608 88-108-183-080 C-RES,U 18K-1/16W a b
FUNC/TAPE/E.VR X R 0609 88-108-472-080 C-RES,U 4.7K-1/16W a b
FUNC/TAPE/E.VR X R 0610 88-108-472-080 C-RES,U 4.7K-1/16W a b
CX-SNR20 CX-SNR21
KSC1 EZSC1
FUNC/TAPE/E.VR X R 0611 88-108-223-080 C-RES,U 22K-1/16W a b
FUNC/TAPE/E.VR X R 0612 88-108-223-080 C-RES,U 22K-1/16W a b
FUNC/TAPE/E.VR X R 0613 88-108-273-080 C-RES,U 27K-1/16W a b
FUNC/TAPE/E.VR X R 0614 88-108-273-080 C-RES,U 27K-1/16W a b
FUNC/TAPE/E.VR X R 0615 88-108-153-080 C-RES,U 15K-1/16W a b
FUNC/TAPE/E.VR X R 0616 88-108-153-080 C-RES,U 15K-1/16W a b
FUNC/TAPE/E.VR X R 0617 88-108-153-080 C-RES,U 15K-1/16W a b
FUNC/TAPE/E.VR X R 0619 88-108-153-080 C-RES,U 15K-1/16W a b
FUNC/TAPE/E.VR X R 0621 88-108-332-080 C-RES,U 3.3K-1/16W a b
FUNC/TAPE/E.VR X R 0622 88-108-332-080 C-RES,U 3.3K-1/16W a b
FUNC/TAPE/E.VR X R 0623 88-108-182-080 C-RES,U 1.8K-1/16W a b
FUNC/TAPE/E.VR X R 0624 88-108-182-080 C-RES,U 1.8K-1/16W a b
FUNC/TAPE/E.VR X R 0625 88-108-103-080 C-RES,U 10K-1/16W a b
FUNC/TAPE/E.VR X R 0626 88-108-103-080 C-RES,U 10K-1/16W a b
FUNC/TAPE/E.VR X R 0627 88-108-222-080 C-RES,U 2.2K-1/16W a b
FUNC/TAPE/E.VR X R 0628 88-108-222-080 C-RES,U 2.2K-1/16W a b
FUNC/TAPE/E.VR X R 0629 88-108-103-080 C-RES,U 10K-1/16W a b
FUNC/TAPE/E.VR X R 0630 88-108-103-080 C-RES,U 10K-1/16W a b
FUNC/TAPE/E.VR X R 0631 88-108-222-080 C-RES,U 2.2K-1/16W a b
FUNC/TAPE/E.VR X R 0632 88-108-222-080 C-RES,U 2.2K-1/16W a b
CX-SNR20 CX-SNR21
KSC1 EZSC1
FUNC/TAPE/E.VR X R 0633 88-108-272-080 C-RES,U 2.7K-1/16W a b
FUNC/TAPE/E.VR X R 0634 88-108-272-080 C-RES,U 2.7K-1/16W a b
FUNC/TAPE/E.VR X R 0635 88-108-102-080 C-RES,U 1K-1/16W a b
FUNC/TAPE/E.VR X R 0636 88-108-102-080 C-RES,U 1K-1/16W a b
FUNC/TAPE/E.VR X R 0637 88-108-102-080 C-RES,U 1K-1/16W a b
FUNC/TAPE/E.VR X R 0638 88-108-102-080 C-RES,U 1K-1/16W a b
FUNC/TAPE/E.VR X R 0639 88-108-183-080 C-RES,U 18K-1/16W a b
FUNC/TAPE/E.VR X R 0640 88-108-183-080 C-RES,U 18K-1/16W a b
FUNC/TAPE/E.VR X R 0641 88-121-223-080 RES,22K-1/8W a b
FUNC/TAPE/E.VR X R 0642 88-108-222-080 C-RES,U 2.2K-1/16W a b
FUNC/TAPE/E.VR X R 0643 88-108-104-080 C-RES,U 100K-1/16W a b
FUNC/TAPE/E.VR X R 0644 88-108-104-080 C-RES,U 100K-1/16W a b
FUNC/TAPE/E.VR X R 0649 88-108-332-080 C-RES,U 3.3K-1/16W a b
FUNC/TAPE/E.VR X R 0650 88-108-332-080 C-RES,U 3.3K-1/16W a b
FUNC/TAPE/E.VR X R 0651 88-108-101-080 C-RES,U 100-1/16W a b
FUNC/TAPE/E.VR X R 0652 88-108-101-080 C-RES,U 100-1/16W a b
FUNC/TAPE/E.VR X R 0656 88-121-394-080 RES,390K-1/8W a b
FUNC/TAPE/E.VR X R 0657 88-108-274-080 C-RES,U 270K-1/16W a b
FUNC/TAPE/E.VR X R 0658 88-108-274-080 C-RES,U 270K-1/16W a b
FUNC/TAPE/E.VR X R 0659 88-108-394-080 C-RES,U 390K-1/16W a b
CX-SNR20 CX-SNR21
KSC1 EZSC1
FUNC/TAPE/E.VR X R 0660 88-108-274-080 C-RES,U 270K-1/16W a b
FUNC/TAPE/E.VR X R 0661 88-108-392-080 C-RES,U 3.9K-1/16W a b
FUNC/TAPE/E.VR X R 0662 88-108-392-080 C-RES,U 3.9K-1/16W a b
FUNC/TAPE/E.VR X R 0672 88-108-223-080 C-RES,U 22K-1/16W a b
FUNC/TAPE/E.VR X R 0673 88-108-392-080 C-RES,U 3.9K-1/16W a b
FUNC/TAPE/E.VR X R 0674 88-108-273-080 C-RES,U 27K-1/16W a b
FUNC/TAPE/E.VR X R 0677 88-108-223-080 C-RES,U 22K-1/16W a b
FUNC/TAPE/E.VR X R 0678 88-108-223-080 C-RES,U 22K-1/16W a b
FUNC/TAPE/E.VR O SFR0451 87-024-435-080 SFR,33K H RH063MC a b
FUNC/TAPE/E.VR O SFR0452 87-024-435-080 SFR,33K H RH063MC a b
MICON X * 8C-NF9-620-010 PWB,COMB FRONT CNF-9 a b
MICON X * 8C-NF9-621-010 PWB,FRONT CNF-9 a b
MICON X * 8C-NF9-623-010 PWB,HLDR WIRE CNF-9 a b
MICON O C 0108 87-010-785-080 C-CAP,U 0.015-25 K B GRM a b
MICON O C 0153 87-010-787-080 C-CAP,U 0.022-25 K B a b
MICON O C 0154 87-010-246-040 CAP,E 47-35 M 11L SME a b
MICON O C 0155 87-010-404-040 CAP,E 4.7-50 M 11L SME a b
MICON O C 0156 87-010-404-040 CAP,E 4.7-50 M 11L SME a b
MICON O C 0301 87-012-278-080 C-CAP,U 2200P-50 K B a b
MICON O C 0351 87-A10-353-080 C-CAP,U 0.22-10 K B a b

! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
 5 
CX-SNR20 CX-SNR21
KSC1 EZSC1
MICON O C 0361 87-012-274-080 C-CAP,U 1000P-50 K B a b
MICON O C 0362 87-012-274-080 C-CAP,U 1000P-50 K B a b
MICON O C 0371 87-012-274-080 C-CAP,U 1000P-50 K B a b
MICON O C 0372 87-012-274-080 C-CAP,U 1000P-50 K B a b
MICON O C 0601 87-010-382-040 CAP,E 22-25 M 11L SME a b
MICON O C 0801 87-A10-353-080 C-CAP,U 0.22-10 K B a b
MICON O C 0803 87-012-280-080 C-CAP,U 3300P-50 K B a b
MICON O C 0804 87-A10-592-080 C-CAP,S 0.015-50 B a b
MICON O C 0806 87-012-273-080 C-CAP,U 820P-50 K B a b
MICON O C 0808 87-010-544-040 CAP,E 0.1-50 M 11L SME a b
MICON O C 0809 87-010-404-040 CAP,E 4.7-50 M 11L SME a b
MICON O C 0810 87-010-759-080 C-CAP,U 0.1-25 Z F a b
MICON O C 0811 87-A12-052-080 C-CAP,S 0.033-25 B a b
MICON O C 0812 87-012-285-080 C-CAP,U 8200P-50 K B GRM a b
MICON O C 0901 87-012-195-080 C-CAP,U 100P-50 CH a b
MICON O C 0902 87-012-195-080 C-CAP,U 100P-50 CH a b
MICON O C 0903 87-012-195-080 C-CAP,U 100P-50 CH a b
MICON O C 0904 87-012-195-080 C-CAP,U 100P-50 CH a b
MICON O C 0905 87-012-195-080 C-CAP,U 100P-50 CH a b
MICON O C 0906 87-012-195-080 C-CAP,U 100P-50 CH a b
CX-SNR20 CX-SNR21
KSC1 EZSC1
MICON O C 0907 87-012-195-080 C-CAP,U 100P-50 CH a b
MICON O C 0908 87-012-195-080 C-CAP,U 100P-50 CH a b
MICON O C 0909 87-012-195-080 C-CAP,U 100P-50 CH a b
MICON O C 0910 87-012-195-080 C-CAP,U 100P-50 CH a b
MICON O C 0911 87-012-274-080 C-CAP,U 1000P-50 K B a b
MICON O C 0912 87-010-759-080 C-CAP,U 0.1-25 Z F a b
MICON O C 0913 87-A10-189-040 CAP,E 220-10 M 5L a b
MICON O C 0915 87-010-759-080 C-CAP,U 0.1-25 Z F a b
MICON O C 0916 87-010-759-080 C-CAP,U 0.1-25 Z F a b
MICON O C 0917 87-010-759-080 C-CAP,U 0.1-25 Z F a b
MICON O C 0919 87-012-286-080 C-CAP,U 0.01-25 K B a b
MICON O C 0920 87-010-829-080 C-CAP,U 0.047-16 Z F a b
MICON O C 0921 87-012-282-080 C-CAP,U 4700P-50 K B a b
MICON O C 0922 87-012-195-080 C-CAP,U 100P-50 CH a b
MICON O C 0923 87-016-116-080 C-CAP,U 0.015-25 B CB a b
MICON O C 0924 87-016-116-080 C-CAP,U 0.015-25 B CB a b
MICON O C 0925 87-016-116-080 C-CAP,U 0.015-25 B CB a b
MICON O C 0931 87-012-195-080 C-CAP,U 100P-50 CH a b
MICON O C 0932 87-012-195-080 C-CAP,U 100P-50 CH a b
MICON O C 0951 87-012-172-080 C-CAP,U 10P-50 D CH a b
CX-SNR20 CX-SNR21
KSC1 EZSC1
MICON O C 0952 87-010-854-080 C-CAP,S 560P-50 CH a b
MICON O C 0953 87-012-349-080 C-CAP,S 1000P-50 CH GRM a b
MICON O C 0961 87-010-391-040 CAP,E 10-35 M 11L SME a b
MICON O C 0962 87-012-336-080 C-CAP,U 330P-50 SL a b
MICON O C 0963 87-010-759-080 C-CAP,U 0.1-25 Z F a b
MICON ! O CN 0103 87-099-013-010 CONN,11P V BLK 6216 a b
MICON ! O CN 0701 87-099-720-010 CONN,30P BLK TYK-B(P) a b
MICON ! O CN 0731 87-099-196-010 CONN,8P V BLK 6216 a b
MICON S D 0103 87-020-465-080 DIODE,1SS133 a b
MICON S D 0104 87-020-465-080 DIODE,1SS133 a b
MICON S D 0301 87-A40-234-080 ZENER,MTZ 5.6A a b
MICON S D 0302 87-020-465-080 DIODE,1SS133 a b
MICON S D 0601 87-A40-269-080 C-DIODE,MC2836 a b
MICON S D 0801 87-020-465-080 DIODE,1SS133 a b
MICON S D 0983 87-020-465-080 DIODE,1SS133 a b
MICON O FL 0201 8C-NF9-615-010 FL,HUA-13SS09T a b
MICON S IC 0901 8C-NF9-610-030 C-IC,UPD780226GF-033-3BA a .
MICON S IC 0901 8C-NF9-611-030 C-IC,UPD780228GF-089-3BA . b
MICON S IC 0961 87-A21-831-010 IC,SPS-442-1-F1 a b
MICON X R 0101 88-108-000-080 C- UMPER,U a b
CX-SNR20 CX-SNR21
KSC1 EZSC1
MICON X R 0621 88-108-000-080 C- UMPER,U a b
MICON X R 0901 88-108-000-080 C- UMPER,U a b
MICON X R 0902 88-108-000-080 C- UMPER,U a b
MICON X R 0903 88-108-000-080 C- UMPER,U a b
MICON X R 0904 88-108-000-080 C- UMPER,U a b
MICON X R 0905 88-108-000-080 C- UMPER,U a b
MICON X R 0965 88-108-000-080 C- UMPER,U a b
MICON X W 0101 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0103 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0104 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0105 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0106 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0107 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0108 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0109 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0110 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0151 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0152 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0201 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0209 88-100-000-010 PLATING- W, 0.58 SN95 a b

! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
 6 
CX-SNR20 CX-SNR21
KSC1 EZSC1
MICON X W 0301 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0302 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0303 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0304 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0305 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0306 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0307 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0308 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0309 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0310 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0311 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0312 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0313 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0314 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0315 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0316 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0317 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0318 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0319 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0320 88-100-000-010 PLATING- W, 0.58 SN95 a b
CX-SNR20 CX-SNR21
KSC1 EZSC1
MICON X W 0321 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0322 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0323 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0324 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0325 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0326 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0327 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0328 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0329 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0330 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0331 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0601 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0602 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0603 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0606 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0607 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0608 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0609 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0610 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0611 88-100-000-010 PLATING- W, 0.58 SN95 a b
CX-SNR20 CX-SNR21
KSC1 EZSC1
MICON X W 0612 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0613 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0614 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0616 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0617 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0618 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0619 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0620 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0701 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0703 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0704 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0705 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0706 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0707 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0709 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0710 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0711 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0712 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0713 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0731 88-100-000-010 PLATING- W, 0.58 SN95 a b
CX-SNR20 CX-SNR21
KSC1 EZSC1
MICON X W 0732 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0801 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0803 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0804 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0805 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0806 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0807 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0808 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0809 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0901 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0902 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0903 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0904 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0905 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0906 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0907 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0908 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0909 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0910 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0912 88-100-000-010 PLATING- W, 0.58 SN95 a b

! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
 7 
CX-SNR20 CX-SNR21
KSC1 EZSC1
MICON X W 0913 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0914 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0915 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0916 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0917 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0918 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0919 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0920 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0921 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0922 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0923 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0925 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0926 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0927 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0928 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0929 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0930 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0931 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0932 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0933 88-100-000-010 PLATING- W, 0.58 SN95 a b
CX-SNR20 CX-SNR21
KSC1 EZSC1
MICON X W 0934 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0935 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0936 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0937 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0938 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0939 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0940 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0941 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0942 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0943 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0944 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0945 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0946 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0947 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0948 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0950 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0951 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0952 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0953 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0954 88-100-000-010 PLATING- W, 0.58 SN95 a b
CX-SNR20 CX-SNR21
KSC1 EZSC1
MICON X W 0956 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0957 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0958 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0959 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0960 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0961 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0962 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X W 0963 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON O L 0951 87-A50-655-010 COIL,CLK 4.19MHZ (TOKO)7KLY a b
MICON O LED0201 87-A41-062-040 LED,LTL-1CHEE-012A RED a b
MICON S Q 0102 87-A30-076-080 C-TR,2SC3052F a b
MICON S Q 0104 87-A30-538-040 C-TR,SRA2202S a b
MICON S Q 0301 87-A30-494-080 TR,2SA1980G a b
MICON S Q 0302 87-A30-076-080 C-TR,2SC3052F a b
MICON S Q 0303 87-A30-076-080 C-TR,2SC3052F a b
MICON S Q 0601 87-A30-495-080 TR,2SA1981Y a b
MICON S Q 0602 87-A30-495-080 TR,2SA1981Y a b
MICON S Q 0603 87-A30-200-080 TR,2SA1585SR a b
MICON S Q 0801 87-A30-076-080 C-TR,2SC3052F a b
MICON S Q 0802 87-A30-075-080 C-TR,2SA1235F a b
CX-SNR20 CX-SNR21
KSC1 EZSC1
MICON S Q 0803 87-A30-076-080 C-TR,2SC3052F a b
MICON S Q 0804 87-A30-076-080 C-TR,2SC3052F a b
MICON S Q 0805 87-A30-076-080 C-TR,2SC3052F a b
MICON S Q 0901 87-A30-538-040 C-TR,SRA2202S a b
MICON X R 0109 88-108-224-080 C-RES,U 220K-1/16W a b
MICON X R 0110 88-108-153-080 C-RES,U 15K-1/16W a b
MICON X R 0111 88-108-333-080 C-RES,U 33K-1/16W a b
MICON X R 0112 88-108-224-080 C-RES,U 220K-1/16W a b
MICON X R 0114 88-108-103-080 C-RES,U 10K-1/16W a b
MICON X R 0115 88-108-000-080 C- UMPER,U a b
MICON X R 0116 88-108-124-080 C-RES,U 120K-1/16W a b
MICON X R 0151 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X R 0152 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X R 0153 88-128-821-080 C-RES, 820-1/8W a b
MICON X R 0154 88-128-821-080 C-RES, 820-1/8W a b
MICON X R 0155 88-108-332-080 C-RES,U 3.3K-1/16W a b
MICON X R 0156 88-108-332-080 C-RES,U 3.3K-1/16W a b
MICON X R 0161 88-108-000-080 C- UMPER,U a b
MICON X R 0162 88-108-000-080 C- UMPER,U a b
MICON X R 0163 88-108-000-080 C- UMPER,U a b

! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
 8 
CX-SNR20 CX-SNR21
KSC1 EZSC1
MICON X R 0164 88-108-000-080 C- UMPER,U a b
MICON X R 0165 88-108-000-080 C- UMPER,U a b
MICON X R 0166 88-108-000-080 C- UMPER,U a b
MICON X R 0208 88-128-102-080 C-RES, 1K-1/8W a b
MICON X R 0301 88-108-104-080 C-RES,U 100K-1/16W a b
MICON X R 0302 88-108-472-080 C-RES,U 4.7K-1/16W a b
MICON X R 0303 88-108-153-080 C-RES,U 15K-1/16W a b
MICON X R 0304 88-108-102-080 C-RES,U 1K-1/16W a b
MICON X R 0306 88-108-471-080 C-RES,U 470-1/16W a b
MICON X R 0321 88-108-103-080 C-RES,U 10K-1/16W a b
MICON X R 0322 88-108-102-080 C-RES,U 1K-1/16W a b
MICON X R 0323 88-108-821-080 C-RES,U 820-1/16W a b
MICON X R 0324 88-108-102-080 C-RES,U 1K-1/16W a b
MICON X R 0325 88-108-122-080 C-RES,U 1.2K-1/16W a b
MICON X R 0326 88-121-122-080 RES,1.2K-1/8W a b
MICON X R 0327 88-108-182-080 C-RES,U 1.8K-1/16W a b
MICON X R 0328 88-121-182-080 RES,1.8K-1/8W a b
MICON X R 0329 88-108-272-080 C-RES,U 2.7K-1/16W a b
MICON X R 0330 88-108-332-080 C-RES,U 3.3K-1/16W a b
MICON X R 0331 88-121-472-080 RES,4.7K-1/8W a b
CX-SNR20 CX-SNR21
KSC1 EZSC1
MICON X R 0332 88-108-682-080 C-RES,U 6.8K-1/16W a b
MICON X R 0333 88-108-103-080 C-RES,U 10K-1/16W a b
MICON X R 0334 88-108-183-080 C-RES,U 18K-1/16W a b
MICON X R 0335 88-108-473-080 C-RES,U 47K-1/16W a b
MICON X R 0341 88-108-103-080 C-RES,U 10K-1/16W a b
MICON X R 0342 88-108-102-080 C-RES,U 1K-1/16W a b
MICON X R 0343 88-108-821-080 C-RES,U 820-1/16W a b
MICON X R 0344 88-108-102-080 C-RES,U 1K-1/16W a b
MICON X R 0345 88-108-122-080 C-RES,U 1.2K-1/16W a b
MICON X R 0346 88-108-122-080 C-RES,U 1.2K-1/16W a b
MICON X R 0347 88-108-182-080 C-RES,U 1.8K-1/16W a b
MICON X R 0348 88-108-182-080 C-RES,U 1.8K-1/16W a b
MICON X R 0349 88-108-272-080 C-RES,U 2.7K-1/16W . b
MICON X R 0350 88-108-332-080 C-RES,U 3.3K-1/16W . b
MICON X R 0351 88-108-472-080 C-RES,U 4.7K-1/16W . b
MICON X R 0361 88-108-103-080 C-RES,U 10K-1/16W a b
MICON X R 0362 88-108-103-080 C-RES,U 10K-1/16W a b
MICON X R 0363 88-108-100-080 C-RES,U 10-1/16W a b
MICON X R 0364 88-108-100-080 C-RES,U 10-1/16W a b
MICON X R 0371 88-108-103-080 C-RES,U 10K-1/16W a b
CX-SNR20 CX-SNR21
KSC1 EZSC1
MICON X R 0372 88-108-103-080 C-RES,U 10K-1/16W a b
MICON X R 0373 88-108-100-080 C-RES,U 10-1/16W a b
MICON X R 0374 88-108-100-080 C-RES,U 10-1/16W a b
MICON X R 0601 88-108-103-080 C-RES,U 10K-1/16W a b
MICON X R 0602 88-108-222-080 C-RES,U 2.2K-1/16W a b
MICON X R 0603 88-108-103-080 C-RES,U 10K-1/16W a b
MICON X R 0604 88-108-222-080 C-RES,U 2.2K-1/16W a b
MICON X R 0605 88-108-103-080 C-RES,U 10K-1/16W a b
MICON X R 0606 88-108-102-080 C-RES,U 1K-1/16W a b
MICON X R 0607 88-108-000-080 C- UMPER,U a b
MICON X R 0611 88-108-473-080 C-RES,U 47K-1/16W a b
MICON X R 0612 88-108-473-080 C-RES,U 47K-1/16W a b
MICON X R 0613 88-108-473-080 C-RES,U 47K-1/16W a b
MICON X R 0614 88-108-473-080 C-RES,U 47K-1/16W a b
MICON X R 0615 88-108-473-080 C-RES,U 47K-1/16W a b
MICON X R 0617 88-108-473-080 C-RES,U 47K-1/16W a b
MICON X R 0618 88-108-473-080 C-RES,U 47K-1/16W a b
MICON X R 0701 88-108-102-080 C-RES,U 1K-1/16W . b
MICON X R 0702 88-128-102-080 C-RES, 1K-1/8W . b
MICON X R 0703 88-108-102-080 C-RES,U 1K-1/16W . b
CX-SNR20 CX-SNR21
KSC1 EZSC1
MICON X R 0704 88-108-102-080 C-RES,U 1K-1/16W a b
MICON X R 0705 88-108-102-080 C-RES,U 1K-1/16W a b
MICON X R 0706 88-108-102-080 C-RES,U 1K-1/16W a b
MICON X R 0707 88-108-102-080 C-RES,U 1K-1/16W a b
MICON X R 0708 88-121-102-080 RES,1K-1/8W a b
MICON X R 0709 88-108-101-080 C-RES,U 100-1/16W a b
MICON X R 0710 88-128-101-080 C-RES, 100-1/8W a b
MICON X R 0711 88-108-101-080 C-RES,U 100-1/16W a b
MICON X R 0712 88-108-101-080 C-RES,U 100-1/16W a b
MICON X R 0719 88-108-100-080 C-RES,U 10-1/16W a b
MICON X R 0721 88-108-103-080 C-RES,U 10K-1/16W a b
MICON X R 0730 88-108-102-080 C-RES,U 1K-1/16W a b
MICON X R 0732 88-108-101-080 C-RES,U 100-1/16W a b
MICON X R 0733 88-108-101-080 C-RES,U 100-1/16W a b
MICON X R 0734 88-108-102-080 C-RES,U 1K-1/16W a b
MICON X R 0735 88-108-102-080 C-RES,U 1K-1/16W a b
MICON X R 0740 88-108-102-080 C-RES,U 1K-1/16W a b
MICON X R 0741 88-108-101-080 C-RES,U 100-1/16W a b
MICON X R 0742 88-108-102-080 C-RES,U 1K-1/16W a b
MICON X R 0743 88-108-474-080 C-RES,U 470K-1/16W a b

! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
 9 
CX-SNR20 CX-SNR21
KSC1 EZSC1
MICON X R 0744 88-108-823-080 C-RES,U 82K-1/16W a b
MICON X R 0745 88-108-104-080 C-RES,U 100K-1/16W a b
MICON X R 0749 88-108-474-080 C-RES,U 470K-1/16W a b
MICON X R 0803 88-108-102-080 C-RES,U 1K-1/16W a b
MICON X R 0804 88-108-224-080 C-RES,U 220K-1/16W a b
MICON X R 0805 88-108-273-080 C-RES,U 27K-1/16W a b
MICON X R 0806 88-108-562-080 C-RES,U 5.6K-1/16W a b
MICON X R 0807 88-108-000-080 C- UMPER,U a b
MICON X R 0808 88-121-101-080 RES,100-1/8W a b
MICON X R 0809 88-108-102-080 C-RES,U 1K-1/16W a b
MICON X R 0810 88-108-182-080 C-RES,U 1.8K-1/16W a b
MICON X R 0811 88-108-224-080 C-RES,U 220K-1/16W a b
MICON X R 0813 88-108-224-080 C-RES,U 220K-1/16W a b
MICON X R 0815 88-108-272-080 C-RES,U 2.7K-1/16W a b
MICON X R 0816 88-108-104-080 C-RES,U 100K-1/16W a b
MICON X R 0818 88-108-224-080 C-RES,U 220K-1/16W a b
MICON X R 0819 88-108-222-080 C-RES,U 2.2K-1/16W a b
MICON X R 0820 88-108-101-080 C-RES,U 100-1/16W a b
MICON X R 0821 88-108-104-080 C-RES,U 100K-1/16W a b
MICON X R 0822 88-108-224-080 C-RES,U 220K-1/16W a b
CX-SNR20 CX-SNR21
KSC1 EZSC1
MICON X R 0823 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X R 0824 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X R 0825 88-100-000-010 PLATING- W, 0.58 SN95 a b
MICON X R 0826 88-108-000-080 C- UMPER,U a b
MICON X R 0827 88-108-473-080 C-RES,U 47K-1/16W a b
MICON X R 0901 88-108-104-080 C-RES,U 100K-1/16W a b
MICON X R 0902 88-108-104-080 C-RES,U 100K-1/16W a b
MICON X R 0903 88-108-104-080 C-RES,U 100K-1/16W a b
MICON X R 0904 88-108-104-080 C-RES,U 100K-1/16W a b
MICON X R 0905 88-108-104-080 C-RES,U 100K-1/16W a b
MICON X R 0906 88-108-104-080 C-RES,U 100K-1/16W a b
MICON X R 0907 88-108-104-080 C-RES,U 100K-1/16W a b
MICON X R 0908 88-108-104-080 C-RES,U 100K-1/16W a b
MICON X R 0909 88-108-104-080 C-RES,U 100K-1/16W a b
MICON X R 0910 88-108-104-080 C-RES,U 100K-1/16W a b
MICON X R 0911 88-108-104-080 C-RES,U 100K-1/16W a b
MICON X R 0912 88-108-104-080 C-RES,U 100K-1/16W a b
MICON X R 0913 88-108-104-080 C-RES,U 100K-1/16W a b
MICON X R 0914 88-108-104-080 C-RES,U 100K-1/16W a b
MICON X R 0915 88-108-104-080 C-RES,U 100K-1/16W a b
CX-SNR20 CX-SNR21
KSC1 EZSC1
MICON X R 0916 88-108-104-080 C-RES,U 100K-1/16W a b
MICON X R 0917 88-108-104-080 C-RES,U 100K-1/16W a b
MICON X R 0918 88-108-104-080 C-RES,U 100K-1/16W a b
MICON X R 0919 88-108-104-080 C-RES,U 100K-1/16W a b
MICON X R 0920 88-108-104-080 C-RES,U 100K-1/16W a b
MICON X R 0921 88-108-104-080 C-RES,U 100K-1/16W a b
MICON X R 0922 88-108-104-080 C-RES,U 100K-1/16W a b
MICON X R 0923 88-108-104-080 C-RES,U 100K-1/16W a b
MICON X R 0924 88-108-104-080 C-RES,U 100K-1/16W a b
MICON X R 0925 88-108-104-080 C-RES,U 100K-1/16W a b
MICON X R 0926 88-108-104-080 C-RES,U 100K-1/16W a b
MICON X R 0927 88-108-104-080 C-RES,U 100K-1/16W a b
MICON X R 0928 88-108-104-080 C-RES,U 100K-1/16W a b
MICON X R 0929 88-108-104-080 C-RES,U 100K-1/16W a b
MICON X R 0930 88-108-104-080 C-RES,U 100K-1/16W a b
MICON X R 0931 88-108-104-080 C-RES,U 100K-1/16W a b
MICON X R 0932 88-108-104-080 C-RES,U 100K-1/16W a b
MICON X R 0933 88-121-104-080 RES,100K-1/8W a b
MICON X R 0934 88-108-683-080 C-RES,U 68K-1/16W a b
MICON X R 0935 88-108-683-080 C-RES,U 68K-1/16W a b
CX-SNR20 CX-SNR21
KSC1 EZSC1
MICON X R 0936 88-108-104-080 C-RES,U 100K-1/16W a b
MICON X R 0937 88-128-472-080 C-RES, 4.7K-1/8W a b
MICON X R 0938 88-108-472-080 C-RES,U 4.7K-1/16W a b
MICON X R 0939 88-108-472-080 C-RES,U 4.7K-1/16W a b
MICON X R 0940 88-108-104-080 C-RES,U 100K-1/16W a b
MICON X R 0941 88-108-104-080 C-RES,U 100K-1/16W a b
MICON X R 0942 88-108-103-080 C-RES,U 10K-1/16W a b
MICON X R 0943 88-121-472-080 RES,4.7K-1/8W a b
MICON X R 0946 88-108-000-080 C- UMPER,U a b
MICON X R 0947 88-108-104-080 C-RES,U 100K-1/16W a b
MICON X R 0948 88-121-104-080 RES,100K-1/8W a b
MICON X R 0951 88-108-102-080 C-RES,U 1K-1/16W a b
MICON X R 0955 88-108-104-080 C-RES,U 100K-1/16W a b
MICON X R 0956 88-108-104-080 C-RES,U 100K-1/16W a b
MICON X R 0957 88-108-104-080 C-RES,U 100K-1/16W a b
MICON X R 0958 88-108-103-080 C-RES,U 10K-1/16W a b
MICON X R 0959 88-108-103-080 C-RES,U 10K-1/16W a b
MICON X R 0961 88-121-181-080 RES,180-1/8W a b
MICON X R 0963 88-108-563-080 C-RES,U 56K-1/16W a b
MICON X R 0969 88-108-103-080 C-RES,U 10K-1/16W a b

! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
 10 
CX-SNR20 CX-SNR21
KSC1 EZSC1
MICON X R 0981 88-108-103-080 C-RES,U 10K-1/16W a b
MICON X R 0982 88-108-103-080 C-RES,U 10K-1/16W a b
MICON X R 0983 88-108-103-080 C-RES,U 10K-1/16W a b
MICON X R 0984 88-108-103-080 C-RES,U 10K-1/16W a b
MICON X R 0985 88-121-103-080 RES,10K-1/8W a b
MICON X R 0986 88-121-103-080 RES,10K-1/8W a b
MICON X R 0987 88-108-103-080 C-RES,U 10K-1/16W a b
MICON X R 0988 88-108-103-080 C-RES,U 10K-1/16W a b
MICON X R 0989 88-108-103-080 C-RES,U 10K-1/16W a b
MICON O S 0321 87-A90-164-080 SW,TACT SKQNAB(N) a b
MICON O S 0322 87-A90-164-080 SW,TACT SKQNAB(N) a b
MICON O S 0323 87-A90-164-080 SW,TACT SKQNAB(N) a b
MICON O S 0324 87-A90-164-080 SW,TACT SKQNAB(N) a b
MICON O S 0325 87-A90-164-080 SW,TACT SKQNAB(N) a b
MICON O S 0326 87-A90-164-080 SW,TACT SKQNAB(N) a b
MICON O S 0327 87-A90-164-080 SW,TACT SKQNAB(N) a b
MICON O S 0328 87-A90-164-080 SW,TACT SKQNAB(N) a b
MICON O S 0329 87-A90-164-080 SW,TACT SKQNAB(N) a b
MICON O S 0330 87-A90-164-080 SW,TACT SKQNAB(N) a b
MICON O S 0331 87-A90-164-080 SW,TACT SKQNAB(N) a b
CX-SNR20 CX-SNR21
KSC1 EZSC1
MICON O S 0332 87-A90-164-080 SW,TACT SKQNAB(N) a b
MICON O S 0333 87-A90-164-080 SW,TACT SKQNAB(N) a b
MICON O S 0334 87-A90-164-080 SW,TACT SKQNAB(N) a b
MICON O S 0335 87-A90-164-080 SW,TACT SKQNAB(N) a b
MICON O S 0341 87-A90-164-080 SW,TACT SKQNAB(N) a b
MICON O S 0342 87-A90-164-080 SW,TACT SKQNAB(N) a b
MICON O S 0343 87-A90-164-080 SW,TACT SKQNAB(N) a b
MICON O S 0344 87-A90-164-080 SW,TACT SKQNAB(N) a b
MICON O S 0345 87-A90-164-080 SW,TACT SKQNAB(N) a b
MICON O S 0346 87-A90-164-080 SW,TACT SKQNAB(N) a b
MICON O S 0347 87-A90-164-080 SW,TACT SKQNAB(N) a b
MICON O S 0348 87-A90-164-080 SW,TACT SKQNAB(N) a b
MICON O S 0350 87-A90-164-080 SW,TACT SKQNAB(N) . b
MICON O S 0351 87-A90-164-080 SW,TACT SKQNAB(N) . b
MICON O S 0361 87-A92-370-010 SW,RTRY RE012307PVB30F a b
MICON O S 0371 87-A92-371-010 SW,RTRY RE0123PVB30F a b
POWER AMP O C 0101 87-012-279-080 C-CAP,U 2700P-50 K B GRM a b
POWER AMP O C 0102 87-012-279-080 C-CAP,U 2700P-50 K B GRM a b
POWER AMP O C 0103 87-010-544-080 CAP,E 0.1-50 M 11L SME a b
POWER AMP O C 0104 87-010-544-080 CAP,E 0.1-50 M 11L SME a b
CX-SNR20 CX-SNR21
KSC1 EZSC1
POWER AMP O C 0107 87-010-404-080 CAP,E 4.7-50 M 11L SME a b
POWER AMP O C 0108 87-010-404-080 CAP,E 4.7-50 M 11L SME a b
POWER AMP O C 0109 87-012-195-080 C-CAP,U 100P-50 CH a b
POWER AMP O C 0110 87-012-195-080 C-CAP,U 100P-50 CH a b
POWER AMP O C 0111 87-010-407-080 CAP,E 33-50 M 11L SME a b
POWER AMP O C 0112 87-010-407-080 CAP,E 33-50 M 11L SME a b
POWER AMP O C 0113 87-012-195-080 C-CAP,U 100P-50 CH a b
POWER AMP O C 0114 87-012-195-080 C-CAP,U 100P-50 CH a b
POWER AMP O C 0117 87-012-368-080 C-CAP,S 0.1-50 Z F a b
POWER AMP O C 0118 87-012-368-080 C-CAP,S 0.1-50 Z F a b
POWER AMP O C 0119 87-012-286-080 C-CAP,U 0.01-25 K B a b
POWER AMP O C 0120 87-012-286-080 C-CAP,U 0.01-25 K B a b
POWER AMP O C 0121 87-010-401-080 CAP,E 1-50 M 11L SME a b
POWER AMP O C 0122 87-010-401-080 CAP,E 1-50 M 11L SME a b
POWER AMP O C 0123 87-010-177-080 C-CAP,S 820P-50 SL C2012 a b
POWER AMP O C 0124 87-010-177-080 C-CAP,S 820P-50 SL C2012 a b
POWER AMP O C 0125 87-012-195-080 C-CAP,U 100P-50 CH a b
POWER AMP O C 0126 87-012-195-080 C-CAP,U 100P-50 CH a b
POWER AMP O C 0133 87-012-282-080 C-CAP,U 4700P-50 K B a b
POWER AMP O C 0140 87-012-278-080 C-CAP,U 2200P-50 K B a b
CX-SNR20 CX-SNR21
KSC1 EZSC1
POWER AMP O C 0145 87-012-282-080 C-CAP,U 4700P-50 K B a b
POWER AMP O C 0146 87-012-282-080 C-CAP,U 4700P-50 K B a b
POWER AMP O C 0186 87-010-759-080 C-CAP,U 0.1-25 Z F a b
POWER AMP O C 0187 87-010-866-080 CAP,E 10-63 M VX a b
POWER AMP O C 0188 87-010-866-080 CAP,E 10-63 M VX a b
POWER AMP O C 0201 87-A10-260-080 C-CAP,U 0.1-16 K B a b
POWER AMP O C 0223 87-010-176-080 C-CAP,S 680P-50 SL a b
POWER AMP O C 0224 87-010-176-080 C-CAP,S 680P-50 SL a b
POWER AMP O C 0225 87-012-368-080 C-CAP,S 0.1-50 Z F a b
POWER AMP O C 0226 87-012-368-080 C-CAP,S 0.1-50 Z F a b
POWER AMP O C 0227 87-012-368-080 C-CAP,S 0.1-50 Z F a b
POWER AMP O C 0228 87-012-368-080 C-CAP,S 0.1-50 Z F a b
POWER AMP O C 0229 87-010-191-080 C-CAP,S 0.015-50 Z F GRM a b
POWER AMP O C 0230 87-010-191-080 C-CAP,S 0.015-50 Z F GRM a b
POWER AMP O C 0231 87-012-286-080 C-CAP,U 0.01-25 K B a b
POWER AMP O C 0232 87-012-286-080 C-CAP,U 0.01-25 K B a b
POWER AMP O C 0241 87-010-759-080 C-CAP,U 0.1-25 Z F a b
POWER AMP S D 0101 87-A40-269-080 C-DIODE,MC2836 a b
POWER AMP S D 0103 87-020-465-080 DIODE,1SS133 a b
POWER AMP S D 0104 87-020-465-080 DIODE,1SS133 a b
