S E R V I C E M A N U A L

SIMPLE MANUAL

• Replace this Service Manual with ”Revision Publishing” when it is issued.

XR-M77

• TYPE:

S/M Code No. 09–995–331–7T1

COMPACT DISC STEREO

SYSTEM

HJB,HJW(207)

• BASIC CD MECHANISM:KSM-213CDM

ELECTRICAL MAIN PARTS LIST - 1

NOTE: The characters in the suffix column indicate the part usage.

US .....................XX..................................A...................

KANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

C 201 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 203 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 207 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 202 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 209 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 208 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 206 87-010-408-080 CAP, ELECT 47-50V A...................

C 205 87-015-698-080 CAP,E 4.7-50 7L A...................

C 204 87-015-698-080 CAP,E 4.7-50 7L A...................

C 214 87-010-178-080 CHIP CAP 1000P A...................

C 212 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 217 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 219 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 211 87-010-198-080 CAP, CHIP 0.022 A...................

C 218 87-010-248-080 CAP, ELECT 220-10V A...................

C 210 87-010-312-080 C-CAP,S 15P-50 CH A...................

C 213 87-012-145-080 CAP, CHIP S 270P CH A...................

C 215 87-015-681-080 CAP,E 10-16 7L A...................

C 216 87-015-694-080 CAP,E 0.47-50 7L A...................

C 225 87-010-194-080 CAP, CHIP 0.047 A...................

C 223 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 221 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 220 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 222 87-010-248-080 CAP, ELECT 220-10V A...................

C 227 87-010-263-080 CAP, ELECT 100-10V A...................

C 224 87-015-681-080 CAP,E 10-16 7L A...................

CN 201 87-A60-778-010 CONN,18P B TMC-D(P) A...................

CN 203 8Z-CL5-618-010 CONN,7P H WHT 528070710 A...................

CN 2203 8Z-CL5-617-010 CONN,7P V WHT 528060710 A...................

CN 4401 87-A60-424-010 CONN,16P V TOC-B A...................

D 201 87-A40-337-080 ZENER,MTZJ 6.8B A...................

D 201 8Z-CL5-613-010 LED,SE6201AT RED W/REFCT A...................

D 208 8Z-CL5-614-010 LED,W03304GSC-SC GR A...................

D 207 8Z-CL5-614-010 LED,W03304GSC-SC GR A...................

D 206 8Z-CL5-614-010 LED,W03304GSC-SC GR A...................

D 205 8Z-CL5-615-010 LED,W03327GRHW GR/RED DUAL COL A...................

D 204 8Z-CL5-615-010 LED,W03327GRHW GR/RED DUAL COL A...................

D 202 8Z-CL5-615-010 LED,W03327GRHW GR/RED DUAL COL A...................

D 203 8Z-CL5-615-010 LED,W03327GRHW GR/RED DUAL COL A...................

D 218 87-020-331-080 CHIP-DIODE,DAN202K A...................

D 219 87-020-331-080 CHIP-DIODE,DAN202K A...................

D 217 87-020-331-080 CHIP-DIODE,DAN202K A...................

D 213 87-070-345-080 DIODE,IN4148 A...................

D 214 87-070-345-080 DIODE,IN4148 A...................

D 212 87-070-345-080 DIODE,IN4148 A...................

D 216 87-070-345-080 DIODE,IN4148 A...................

D 215 87-070-345-080 DIODE,IN4148 A...................

D 210 87-070-345-080 DIODE,IN4148 A...................

D 211 87-070-345-080 DIODE,IN4148 A...................

D 222 87-020-330-080 DIODE,DAP202K A...................

D 221 87-020-331-080 CHIP-DIODE,DAN202K A...................

D 220 87-020-331-080 CHIP-DIODE,DAN202K A...................

D 225 87-070-345-080 DIODE,IN4148 A...................

D 223 87-070-345-080 DIODE,IN4148 A...................

F 881 87-A91-276-080 FUSE,125MA 125V F 251 A...................

FL 201 8Z-CL1-630-010 FL,13-ST-36GNAK A...................

IC 202 87-070-282-010 IC,BU2092 A...................

IC 214 8Z-CL5-616-010 IC,RPM638CBRL676/6938-V4 A...................

ELECTRICAL MAIN PARTS LIST - 2

L 201 87-A50-052-010 COIL,CLOCK 5.76MHZ T1 A...................

Q 209 87-026-230-080 CHIP-TR,DTA114YK A...................

Q 208 87-A30-087-080 C-FET,2SK2158 A...................

Q 201 89-327-125-080 CHIP TR,2SC2712GR A...................

Q 210 87-026-230-080 CHIP-TR,DTA114YK A...................

Q 211 87-026-230-080 CHIP-TR,DTA114YK A...................

Q 212 87-026-230-080 CHIP-TR,DTA114YK A...................

Q 216 87-026-235-080 CHIP-TR,DTC114EK A...................

Q 215 87-A30-087-080 C-FET,2SK2158 A...................

Q 213 89-111-625-080 TR,2SA1162 (0.15W) A...................

Q 217 89-327-125-080 CHIP TR,2SC2712GR A...................

Q 218 89-406-556-080 TR,2SD65F A...................

S 206 87-036-073-010 TACT SWITCH A...................

S 203 87-036-073-010 TACT SWITCH A...................

S 201 87-036-073-010 TACT SWITCH A...................

S 208 87-036-073-010 TACT SWITCH A...................

S 207 87-036-073-010 TACT SWITCH A...................

S 205 87-036-073-010 TACT SWITCH A...................

S 202 87-036-073-010 TACT SWITCH A...................

S 209 87-036-073-010 TACT SWITCH A...................

S 204 87-036-073-010 TACT SWITCH A...................

S 201 87-A90-646-010 SW,RTRY 3-2-1 RE0131 A...................

S 211 87-036-073-010 TACT SWITCH A...................

S 218 87-036-073-010 TACT SWITCH A...................

S 212 87-036-073-010 TACT SWITCH A...................

S 210 87-036-073-010 TACT SWITCH A...................

S 219 87-036-073-010 TACT SWITCH A...................

S 220 87-036-073-010 TACT SWITCH A...................

S 221 87-036-073-010 TACT SWITCH A...................

W 203 8Z-CL5-603-010 FF-CABLE, 7P 1.0 150MM UL2896 A...................

IC 201 8Z-CL5-601-010 C-IC,LC876564-XXXX A...................

87-A90-140-010 HLDR,51052-0510 V0 A...................

C 534 87-010-195-080 C-CAP,S 0.068-25 F A...................

C 531 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 532 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 530 87-015-684-080 CAP,E 47-16 7L A...................

C 545 87-015-696-080 CAP,E 2.2-50 7L A...................

C 546 87-015-696-080 CAP,E 2.2-50 7L A...................

C 552 87-010-213-080 C-CAP,S 0.015-50 B A...................

C 551 87-010-213-080 C-CAP,S 0.015-50 B A...................

C 554 87-015-688-080 CAP,E 4.7-35 7L A...................

C 553 87-015-688-080 CAP,E 4.7-35 7L A...................

C 555 87-015-694-080 CAP,E 0.47-50 7L A...................

C 556 87-015-694-080 CAP,E 0.47-50 7L A...................

C 557 87-015-694-080 CAP,E 0.47-50 7L A...................

C 558 87-015-694-080 CAP,E 0.47-50 7L A...................

C 559 87-015-695-080 CAP,E 1-50 7L A...................

C 563 87-010-154-080 CAP CHIP 10P A...................

C 568 87-015-679-080 33U 10V SRA A...................

C 567 87-015-679-080 33U 10V SRA A...................

C 561 87-015-680-080 CAP,E 47-10 7L A...................

C 562 87-015-680-080 CAP,E 47-10 7L A...................

C 566 87-015-688-080 CAP,E 4.7-35 7L A...................

C 565 87-015-688-080 CAP,E 4.7-35 7L A...................

C 560 87-015-695-080 CAP,E 1-50 7L A...................

C 804 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 805 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 806 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 807 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 808 87-010-389-090 CAP, E 2200-25 SME A...................

C 811 87-010-060-080 ELECTROLYTIC 100-16V A...................

C 812 87-010-060-080 ELECTROLYTIC 100-16V A...................

C 819 87-010-194-080 CAP, CHIP 0.047 A...................

C 813 87-010-235-080 CAP,E 470-16 SME A...................

ELECTRICAL MAIN PARTS LIST - 3

C 820 87-010-194-080 CAP, CHIP 0.047 A...................

C 822 87-010-387-080 CAP,E 470-25 SME A...................

C 821 87-010-453-090 CAP ELECT 4700-25V SME A...................

C 829 87-015-681-080 CAP,E 10-16 7L A...................

C 833 87-010-188-080 CAP,CHIP 6800P A...................

C 834 87-010-188-080 CAP,CHIP 6800P A...................

C 830 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 837 87-010-260-080 CAP, ELECT 47-25V A...................

C 835 87-015-688-080 CAP,E 4.7-35 7L A...................

C 836 87-015-688-080 CAP,E 4.7-35 7L A...................

C 849 87-010-182-080 C-CAP,S 2200P-50 B A...................

C 848 87-015-691-080 CAP,E 0.1-50 7L A...................

C 847 87-015-691-080 CAP,E 0.1-50 7L A...................

C 850 87-010-182-080 C-CAP,S 2200P-50 B A...................

CN 201 87-A60-770-010 CONN,18P B TMC-D(X) A...................

CN 405 87-009-036-010 CONNECTOR, 8P PH V WHT A...................

CN 804 87-009-034-010 CONN,6P PH V A...................

D 503 87-070-345-080 DIODE,IN4148 A...................

D 502 87-070-345-080 DIODE,IN4148 A...................

D 501 87-070-345-080 DIODE,IN4148 A...................

D 804 87-002-743-080 ZENER,MTZJ 33B A...................

D 803 87-070-345-080 DIODE,IN4148 A...................

D 804 87-070-345-080 DIODE,IN4148 A...................

D 801 87-A40-466-080 ZENER,MTZJ2.7A A...................

D 802 88-CD9-651-090 DIODE,J05 A...................

D 801 88-CD9-651-090 DIODE,J05 A...................

D 807 8Z-CL5-626-010 DIODE,6A1 A...................

D 806 8Z-CL5-626-010 DIODE,6A1 A...................

D 809 8Z-CL5-626-010 DIODE,6A1 A...................

D 808 8Z-CL5-626-010 DIODE,6A1 A...................

D 818 87-070-345-080 DIODE,IN4148 A...................

D 819 87-070-345-080 DIODE,IN4148 A...................

D 820 87-070-345-080 DIODE,IN4148 A...................

IC 504 87-017-915-080 IC,BU4094BCF A...................

IC 501 87-A21-111-040 C-IC,M62495FP A...................

IC 801 87-A20-909-010 IC,LA4663 A...................

J 801 87-009-216-010 JACK, DIA 3.5 A...................

J 802 87-A60-238-010 TERMINAL,SP 4P (MSC) A...................

Q 501 87-026-213-080 CHIP-TR,DTC114YK A...................

Q 502 87-026-213-080 CHIP-TR,DTC114YK A...................

Q 503 89-111-625-080 TR,2SA1162 (0.15W) A...................

Q 504 89-327-125-080 CHIP TR,2SC2712GR A...................

Q 801 89-213-702-010 TR,2SB1370 (1.8W) A...................

Q 804 89-327-125-080 CHIP TR,2SC2712GR A...................

Q 803 89-327-125-080 CHIP TR,2SC2712GR A...................

Q 806 89-406-556-080 TR,2SD65F A...................

Q 807 89-406-556-080 TR,2SD65F A...................

Q 811 87-026-211-080 TR,DTA144EK A...................

Q 812 89-111-625-080 TR,2SA1162 (0.15W) A...................

Q 814 89-327-125-080 CHIP TR,2SC2712GR A...................

Q 813 89-327-125-080 CHIP TR,2SC2712GR A...................

W 804 8Z-CL5-627-010 F-CABLE,5P 2.5 250MM UL2468 AW A...................

* 8Z-CL5-625-010 HLDR,51052- 0910V0 A...................

C 884 87-010-387-080 CAP,E 470-25 SME A...................

C 883 87-015-697-080 CAP,E 3.3-50 7L A...................

C 881 87-A10-479-080 CAP,CER 2200P-250 M E KH A...................

CN 102 87-099-570-010 CONN,13P TUC-P13P-B1 A...................

CN 101 8Z-CL5-624-010 CONN,13P H WHT 528071310 A...................

CN 803 87-009-031-010 CONNECTOR, 3P A...................

CN 1101 8Z-CL5-623-010 CONN,13P V WHT 528061310 A...................

D 207 87-070-345-080 DIODE,IN4148 A...................

D 882 87-070-345-080 DIODE,IN4148 A...................

D 881 87-070-345-080 DIODE,IN4148 A...................

D 884 87-070-345-080 DIODE,IN4148 A...................

ELECTRICAL MAIN PARTS LIST - 4

D 887 87-070-345-080 DIODE,IN4148 A...................

D 886 87-070-345-080 DIODE,IN4148 A...................

D 885 87-070-345-080 DIODE,IN4148 A...................

D 883 87-070-345-080 DIODE,IN4148 A...................

F 801 87-A91-266-010 FUSE,2.5A 125V F 51NM A...................

F 803 87-A91-266-010 FUSE,2.5A 125V F 51NM A...................

F 802 87-A91-266-010 FUSE,2.5A 125V F 51NM A...................

F 805 87-A91-270-010 FUSE,5A 125V F 51NM A...................

F 804 87-A91-270-010 FUSE,5A 125V F 51NM A...................

F 881 87-A91-276-080 FUSE,125MA 125V F 251 A...................

P 1 87-A60-317-010 TERMINAL, 1P MSC A...................

P 2 87-A60-317-010 TERMINAL, 1P MSC A...................

PT 882 8Z-NF8-661-010 PT,SUB ZNF-8(U) A...................

Q 881 87-026-230-080 CHIP-TR,DTA114YK A...................

RY 881 87-A90-976-010 RELAY,AC12V SDT-S-112LMR A...................

W 101 8Z-CL5-621-010 FF-CABLE, 13P 1.0 220MM A...................

W 801 8Z-CL5-622-010 F-CABLE,9P 2.5 250MM UL2468 AW A...................

C 403 87-010-060-080 ELECTROLYTIC 100-16V A...................

C 407 87-010-178-080 CHIP CAP 1000P A...................

C 402 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 405 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 408 87-010-198-080 CAP, CHIP 0.022 A...................

C 404 87-010-754-080 CAP,E220-10 SRA 7L A...................

C 409 87-010-754-080 CAP,E220-10 SRA 7L A...................

C 406 87-015-680-080 CAP,E 47-10 7L A...................

C 401 87-015-697-080 CAP,E 3.3-50 7L A...................

C 410 87-010-060-080 ELECTROLYTIC 100-16V A...................

C 413 87-010-193-080 CHIP CAPACITOR,0.033 A...................

C 418 87-010-213-080 C-CAP,S 0.015-50 B A...................

C 417 87-012-157-080 C-CAP,S 330P-50 CH A...................

C 414 87-015-681-080 CAP,E 10-16 7L A...................

C 412 87-015-691-080 CAP,E 0.1-50 7L A...................

C 416 87-015-692-080 CAP,E 0.22-50 7L A...................

C 425 87-010-176-080 C-CAP,S 680P-50 SL A...................

C 422 87-010-183-080 C-CAP,S 2700P-50 B A...................

C 429 87-010-186-080 CAP,CHIP 4700P A...................

C 420 87-010-193-080 CHIP CAPACITOR,0.033 A...................

C 423 87-010-195-080 C-CAP,S 0.068-25 F A...................

C 434 87-010-184-080 CHIP CAPACITOR 3300P(K) A...................

C 438 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 435 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 430 87-012-156-080 C-CAP,S 220P-50 CH A...................

C 436 87-015-680-080 CAP,E 47-10 7L A...................

C 432 87-015-680-080 CAP,E 47-10 7L A...................

C 437 87-015-688-080 CAP,E 4.7-35 7L A...................

C 431 87-015-692-080 CAP,E 0.22-50 7L A...................

C 433 87-015-695-080 CAP,E 1-50 7L A...................

C 447 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 446 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 445 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 442 87-010-314-080 C-CAP,S 22P-50V A...................

C 448 87-010-315-080 C-CAP,S 27P-50 CH A...................

C 445 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 455 87-010-060-080 ELECTROLYTIC 100-16V A...................

C 459 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 458 87-010-316-080 C-CAP,S 33P-50 CH A...................

C 457 87-010-316-080 C-CAP,S 33P-50 CH A...................

C 453 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 450 87-012-140-080 CAP 470P A...................

C 452 87-012-140-080 CAP 470P A...................

C 454 87-012-153-080 C-CAP,S 120P-50 CH A...................

C 451 87-012-156-080 C-CAP,S 220P-50 CH A...................

C 460 87-010-060-080 ELECTROLYTIC 100-16V A...................

C 467 87-010-060-080 ELECTROLYTIC 100-16V A...................

ELECTRICAL MAIN PARTS LIST - 5

C 461 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 466 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 468 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 469 87-012-154-080 C-CAP,S 150P-50 CH A...................

C 465 87-015-688-080 CAP,E 4.7-35 7L A...................

C 462 87-A10-505-080 CAP,E 220-6.3 SF A...................

C 479 87-010-060-080 ELECTROLYTIC 100-16V A...................

C 475 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 477 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 478 87-010-221-080 CAP, ELECT 470-10V A...................

C 476 87-010-236-080 CAP,E 1000-10 SME A...................

C 483 87-010-181-080 CAP,CHIP S 1800P A...................

C 484 87-010-181-080 CAP,CHIP S 1800P A...................

C 480 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 482 87-015-681-080 CAP,E 10-16 7L A...................

C 481 87-015-681-080 CAP,E 10-16 7L A...................

C 490 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 495 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 494 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 493 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 492 87-015-682-080 CAP,E 22-16 7L A...................

C 491 87-015-684-080 CAP,E 47-16 7L A...................

C 827 87-010-247-080 CAP, ELECT 100-50V A...................

C 828 87-010-247-080 CAP, ELECT 100-50V A...................

C 823 87-010-260-080 CAP, ELECT 47-25V A...................

C 825 87-010-260-080 CAP, ELECT 47-25V A...................

C 824 87-010-260-080 CAP, ELECT 47-25V A...................

C 826 87-010-260-080 CAP, ELECT 47-25V A...................

C 851 87-015-697-080 CAP,E 3.3-50 7L A...................

C 4404 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 4402 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 4403 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 4401 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 4410 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 4411 87-015-681-080 CAP,E 10-16 7L A...................

CN 408 87-009-863-010 CONN,2P ZH WHT A...................

CN 407 87-009-865-010 CONN,2P ZH BLU A...................

CN 402 8Z-CL5-610-010 CONN,16P H WHT 528071610 A...................

CN 401 8Z-CL5-610-010 CONN,16P H WHT 528071610 A...................

CNA 407 8Z-CL5-611-010 CONN ASSY,2P RED ZHRAWG28 UL15 A...................

CNA 408 8Z-CL5-612-010 CONN ASSY,2P BLU ZHRAWG28 UL15 A...................

D 403 87-070-345-080 DIODE,IN4148 A...................

D 407 87-070-345-080 DIODE,IN4148 A...................

D 401 87-070-345-080 DIODE,IN4148 A...................

D 402 87-070-345-080 DIODE,IN4148 A...................

D 810 88-CD9-651-090 DIODE,J05 A...................

D 811 88-CD9-651-090 DIODE,J05 A...................

D 813 88-CD9-651-090 DIODE,J05 A...................

D 812 88-CD9-651-090 DIODE,J05 A...................

D 824 87-070-345-080 DIODE,IN4148 A...................

D 823 87-070-345-080 DIODE,IN4148 A...................

D 821 87-070-345-080 DIODE,IN4148 A...................

D 822 87-070-345-080 DIODE,IN4148 A...................

IC 404 87-A20-445-010 IC,BA5936 A...................

IC 401 87-A20-446-010 C-IC,LA9241ML A...................

IC 402 87-A20-459-010 C-IC,LC78622ED A...................

L 401 87-005-730-080 COIL,10UH J SP02 A...................

L 405 87-005-742-080 COIL,100UH J SP02 A...................

L 404 87-005-742-080 COIL,100UH J SP02 A...................

M 401 87-A91-069-010 MOT,RF-370CA15370 A...................

Q 403 87-026-239-080 TR,DTC114TK (0.2W) A...................

Q 401 87-026-463-080 TR,2SA933S (0.3W) A...................

Q 471 89-406-556-080 TR,2SD65F A...................

Q 498 89-327-125-080 CHIP TR,2SC2712GR A...................

ELECTRICAL MAIN PARTS LIST - 6

Q 497 89-327-125-080 CHIP TR,2SC2712GR A...................

Q 493 89-406-556-080 TR,2SD65F A...................

Q 496 89-406-556-080 TR,2SD65F A...................

Q 492 89-406-556-080 TR,2SD65F A...................

Q 494 89-406-556-080 TR,2SD65F A...................

Q 491 89-406-556-080 TR,2SD65F A...................

Q 809 87-026-463-080 TR,2SA933S (0.3W) A...................

Q 810 87-026-463-080 TR,2SA933S (0.3W) A...................

Q 817 89-111-625-080 TR,2SA1162 (0.15W) A...................

Q 815 89-327-125-080 CHIP TR,2SC2712GR A...................

Q 816 89-327-125-080 CHIP TR,2SC2712GR A...................

S 402 8Z-CL5-609-010 SW,PUSH 1-1-1 MQS2 A...................

S 401 8Z-CL5-609-010 SW,PUSH 1-1-1 MQS2 A...................

SFR 401 87-024-437-080 SFR100K,RH063EC A...................

W 402 8Z-CL5-604-010 FF-CABLE, 16P 1.0 100MM A...................

W 401 8Z-CL5-604-010 FF-CABLE, 16P 1.0 100MM A...................

X 401 81-592-641-010 VIB,CER 16.93MHZ A...................

C 571 87-010-060-080 ELECTROLYTIC 100-16V A...................

C 572 87-010-060-080 ELECTROLYTIC 100-16V A...................

C 578 87-010-176-080 C-CAP,S 680P-50 SL A...................

C 577 87-010-176-080 C-CAP,S 680P-50 SL A...................

C 579 87-010-318-080 C-CAP,S 47P-50 CH A...................

C 575 87-015-688-080 CAP,E 4.7-35 7L A...................

C 573 87-015-688-080 CAP,E 4.7-35 7L A...................

C 574 87-015-688-080 CAP,E 4.7-35 7L A...................

C 576 87-015-688-080 CAP,E 4.7-35 7L A...................

C 580 87-010-318-080 C-CAP,S 47P-50 CH A...................

C 582 87-012-154-080 C-CAP,S 150P-50 CH A...................

C 581 87-012-154-080 C-CAP,S 150P-50 CH A...................

C 583 87-015-695-080 CAP,E 1-50 7L A...................

C 584 87-015-695-080 CAP,E 1-50 7L A...................

IC 505 87-070-391-040 IC,BA4558F A...................

J 501 8Z-CL5-608-010 JACK,PIN 6P VERTICAL A...................

C 518 87-010-188-080 CAP,CHIP 6800P A...................

C 516 87-010-188-080 CAP,CHIP 6800P A...................

C 512 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 519 87-012-140-080 CAP 470P A...................

C 517 87-012-140-080 CAP 470P A...................

C 515 87-015-684-080 CAP,E 47-16 7L A...................

C 511 87-015-688-080 CAP,E 4.7-35 7L A...................

C 513 87-015-688-080 CAP,E 4.7-35 7L A...................

C 514 87-015-688-080 CAP,E 4.7-35 7L A...................

C 510 87-015-688-080 CAP,E 4.7-35 7L A...................

C 525 87-010-178-080 CHIP CAP 1000P A...................

C 520 87-010-178-080 CHIP CAP 1000P A...................

C 523 87-010-195-080 C-CAP,S 0.068-25 F A...................

C 527 87-010-195-080 C-CAP,S 0.068-25 F A...................

C 521 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 526 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 524 87-015-684-080 CAP,E 47-16 7L A...................

C 528 87-015-695-080 CAP,E 1-50 7L A...................

C 522 87-015-695-080 CAP,E 1-50 7L A...................

IC 503 87-A21-022-040 C-IC,BA3880FS A...................

C 907 87-010-060-080 ELECTROLYTIC 100-16V A...................

C 906 87-010-197-080 CAP, CHIP 0.01 DM A...................

CN 404 87-A60-116-010 CONN,6P H S2M-6WR A...................

CNA 404 8Z-CL5-619-010 CONN ASSY,6P PHR06-170MM JST A...................

D 201 87-070-345-080 DIODE,IN4148 A...................

D 901 87-A40-558-010 LED,SLZ-8128A-01-A A...................

Q 904 89-327-125-080 CHIP TR,2SC2712GR A...................

Q 903 89-327-125-080 CHIP TR,2SC2712GR A...................

NOTE: The characters in the suffix column indicate the part usage.

US .....................XX..................................A...................

KANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

8Z-CL5-003-010 CABI,SIDE R A...................

8Z-CL5-004-010 CABI,SIDE L A...................

8Z-CL5-005-010 LID,CD A...................

8Z-CL5-008-010 WINDOW,CD A...................

8Z-CL5-009-010 WINDOW,FL SUH A...................

8Z-CLF-001-010 PANEL,CONT S FA A...................

8Z-CLF-002-010 PANEL,FRONT S FA A...................

8Z-CLF-003-010 PLATE,DECO SUH A...................

8Z-CLF-006-010 CABI,FRONY UH A...................

8Z-CLF-008-010 CABI,REAR SU A...................

8Z-CL5-012-010 BTN,SET REC A...................

8Z-CL5-013-010 BTN,SET CD A...................

8Z-CL5-014-010 BTN,SET POWER A...................

8Z-CL5-015-010 BTN,SET FUNC A...................

8Z-CL5-016-010 BTN,POWER A...................

8Z-CL5-018-010 BTN,CD OPEN A...................

8Z-CL5-019-010 BTN,JOG A...................

8Z-CL5-020-010 BTN,CRYSTAL TU A...................

8Z-CL5-021-010 BTN,CRYSTAL AX A...................

8Z-CL5-022-010 BTN,CRYSTAL CD A...................

8Z-CL5-023-010 BTN,CRYSTAL MD A...................

88-CD9-210-010 BASE,CHUCK A...................

88-CD9-211-010 RING,CHUCK A...................

88-CH6-220-010 CUSHION,CD A A...................

8Z-CL5-205-010 PULLEY,GEAR CD A...................

8Z-CL5-206-010 GEAR,MID CD A...................

8Z-CL5-207-010 GEAR,CD A...................

8Z-CL5-208-010 PULLEY,MOTOR A...................

8Z-CL5-210-010 CHAS,CD A...................

8Z-CL5-211-010 PANEL,CD A...................

8Z-CL5-216-010 FOOT,CABI A...................

8Z-CL5-217-010 BELT,PULLEY A...................

8Z-CL5-220-010 BUSHING,U A...................

8Z-NB8-240-010 COVER, PL A...................

* 8Z-CL5-201-010 GUIDE,LED A...................

* 8Z-CL5-203-010 HLDR,GEAR CD A...................

* 8Z-CL5-204-010 HLDR,CD CHUCK A...................

* 8Z-CL5-209-010 HLDR,FL A...................

* 8Z-CL5-213-010 HLDR,(A) PWB TU A...................

* 8Z-CL5-214-010 HLDR,(B) PWB TU A...................

* 8Z-CL5-215-010 PLATE,MTG TX A...................

* 8Z-CL5-221-010 HLDR,BKT MOUNT A...................

87-067-975-010 S-SCREW,IT+4-8 A...................

87-231-096-410 Q+3-10 A...................

87-261-071-410 V+2.6-4 A...................

87-261-092-410 V+3-4 GLD A...................

87-351-535-310 VT2+1.7-8 BLK A...................

87-571-094-410 TAPPING SCREW, VIT+3-6 (GLD) A...................

87-571-095-410 VIT+3-8 A...................

87-581-095-410 UIT+3-8 A...................

87-651-074-410 VT1+2.6-8 A...................

87-723-074-410 QT2+2.6-8 W/O SLOT BLK A...................

87-723-096-410 QT2+3-10W/O SLOT BL A...................

87-724-096-410 QT2+3-10 W/O SLOT CR A...................

87-741-095-410 UT2+3-8 GLD A...................

87-761-074-410 VFT2+2.6-8 A...................

* 87-571-033-410 TAPPING SCREW, VIT+2-4 A...................

* 87-751-076-410 SCREW 2.6-12 A...................

MECHANICAL PARTS LIST - 1

NOTE: The characters in the suffix column indicate the part usage.

SC2 ....................OO..................................A...................

LH2C ...................XX...................................B..................

USC2 ...................XX....................................C.................

KANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

84-CD8-083-010 0E BADGE,AIWA 30.5-5.2 2.5LEAD ABC.................

88-CH6-019-010 PANEL,CD ABC.................

8Z-CDB-001-010 CABI,FRONT ABC.................

8Z-CDB-002-010 CABI,REAR A...................

8Z-CDB-003-010 PANEL,FRONT A...................

8Z-CDB-004-010 WINDOW,LED(EX) .B..................

8Z-CDB-005-010 LID,CD A...................

8Z-CDB-006-010 LID,CASS A...................

8Z-CDB-007-010 LID,BATT ABC.................

8Z-CDB-008-010 WINDOW,CASS ABC.................

8Z-CDB-009-010 WINDOW,CD ABC.................

8Z-CDB-010-010 WINDOW,TU A...................

8Z-CDB-011-010 WINDOW,LED A...................

8Z-CDB-012-010 GRILLE,SPKR L ABC.................

8Z-CDB-013-010 GRILLE,SPKR R ABC.................

8Z-CDB-014-010 ARM,MAIN HANDL ABC.................

8Z-CDB-015-010 COVER, HANDLE ABC.................

8Z-CDB-035-010 POINTER,TUNNING ABC.................

8Z-CDB-037-010 LENS,LED ABC.................

8Z-CDB-040-010 CHAS,CD A...................

8Z-CDB-041-010 CABI,REAR(U) .BC.................

8Z-CDB-042-010 PANEL,FRONT(U) ..C.................

8Z-CDB-043-010 LID,CD(U) .BC.................

8Z-CDB-044-010 LID,CASS(U) .BC.................

8Z-CDB-045-010 WINDOW,TU(U) ..C.................

8Z-CDB-046-010 WINDOW,LED(U) ..C.................

8Z-CDB-047-010 CHAS,CD(U) .BC.................

8Z-CDB-048-010 KEY,FUNCT(U) .BC.................

8Z-CDB-049-010 CHAS,CD(EZ) ....................

8Z-CDB-050-010 WINDOW,TU(EZ) ....................

8Z-CDB-067-010 CABI,REAR EZ ....................

8Z-CDB-016-010 KEY,VOL ABC.................

8Z-CDB-017-010 KEY,FUNCTION A...................

8Z-CDB-018-010 KEY,CASS REC ABC.................

8Z-CDB-019-010 KEY,CASS PAUSE ABC.................

8Z-CDB-020-010 KEY,CASS PLAY ABC.................

8Z-CDB-021-010 KEY,CASS STOP ABC.................

8Z-CDB-022-010 KEY,CASS FF ABC.................

8Z-CDB-023-010 KEY,CASS REW ABC.................

8Z-CDB-024-010 KEY,Q-SOUND ABC.................

8Z-CDB-025-010 KEY,EQ ABC.................

8Z-CDB-026-010 KEY,CD A ABC.................

8Z-CDB-027-010 KEY,CD B ABC.................

8Z-CDB-028-010 KNOB,SL BAND ABC.................

8Z-CDB-029-010 KNOB,SL ST/MN ABC.................

8Z-CDB-030-010 KNOB,RTRY TU ABC.................

82-CD8-212-010 0E SPR-T,CAM CD ABC.................

84-CD5-215-010 0E GEAR ABC.................

84-CD5-216-010 0E BRACKET ABC.................

84-CT5-209-010 PLATE,MAGNET ABC.................

87-036-368-010 0E MAGNET ABC.................

87-A90-147-010 COVER,AC SEL SW .B..................

87-CD7-206-010 DOOR,CD LOCKER ABC.................

87-CD7-207-010 HLDR,LOCKER ABC.................

88-CD8-209-010 SPR-C,BATT ABC.................

88-CD8-222-010 SPR-P,DAMP CD ABC.................

MECHANICAL PARTS LIST - 2

MECHANICAL PARTS LIST - 3

88-CD9-207-010 COVER, AC SOCKET ABC.................

88-CD9-210-010 1A BASE,CHUCK ABC.................

88-CD9-211-010 RING,CHUCK ABC.................

8Z-CD8-215-010 HLDR,BAR ANT ABC.................

8Z-CDB-204-010 HLDR,KEY FUNC ABC.................

8Z-CDB-205-010 GEAR,PVC ABC.................

8Z-CDB-206-010 HLDR,PVC ABC.................

8Z-CDB-207-010 HLDR,LED ABC.................

8Z-CDB-208-010 HLDR,SPKR ABC.................

8Z-CDB-209-010 HLDR,BAND ABC.................

8Z-CDB-210-010 SPR-T,LID CASS ABC.................

8Z-CDB-211-010 SPR-T,LID CD ABC.................

8Z-CDB-212-010 HLDR,PWB ABC.................

8Z-CDB-215-010 HLDR,LID CD ABC.................

8Z-CDB-218-010 W, TUNING ABC.................

8Z-CDB-220-010 GEAR,TUNING ABC.................

8Z-CDB-222-010 1F PLATE,FM ABC.................

87-251-091-410 0E U+3-3 ABC.................

87-261-032-410 0E V+2-3 GLD ABC.................

87-261-096-410 0E SCREW,V+3-10 GLD ABC.................

87-651-035-410 0E VT1 2-6 GLD ABC.................

87-661-096-410 0E SCREW,VFT1+3-10 ABC.................

87-741-074-410 0E UT2+2.6-8 ABC.................

87-741-096-410 0E UT2+3-10 ABC.................

87-741-102-410 0E UT2+3-20 ABC.................

87-745-094-410 0E UT2+3-6 ABC.................

87-751-034-410 0E SCREW VT2+2-5 ABC.................

87-B10-102-010 0E UT2+3-15 W/O ABC.................

81-590-677-010 1A SWITCH LEAF ABC.................

87-043-116-010 1C ANT,WHIP ABC.................

87-A60-177-010 1A JACK,AC U W/SW ..C.................

87-A60-178-010 JACK,AC E W/SW .B..................

87-A60-179-010 1A JACK,AC D W/SW A...................

87-A90-146-010 0E SW,SL 1-1-2 .B..................

8Z-CDB-619-010 1F PT,D A...................

8Z-CDB-620-010 1F PT,U ..C.................

8Z-CDB-621-010 1F PT,E ....................

8Z-CDB-622-010 PT,H .B..................

8Z-CDB-623-010 FF-CABLE, 16P 1.0 140MM CD-RF ABC.................

8Z-CDB-625-010 FF-CABLE, 16P 1.25 240MM FRONT ABC.................

8Z-CDB-632-010 WIRE ASSY,210 26 FM-ANT ABC.................

SP 2 88-CD8-622-010 1F SPKR,F 77 7OHM 3W ABC.................

SP 1 88-CD8-622-010 1F SPKR,F 77 7OHM 3W ABC.................

87-A80-110-010 AC CORD ASSY,U SPT-2W A...................

PT 881 8Z-CL5-681-010 PT,U L6636EI-66/36 A...................

W 203 8Z-CL5-603-010 FF-CABLE, 7P 1.0 150MM UL2896 A...................

87-A90-140-010 HLDR,51052-0510 V0 A...................

W 804 8Z-CL5-627-010 F-CABLE,5P 2.5 250MM UL2468 AW A...................

W 101 8Z-CL5-621-010 FF-CABLE, 13P 1.0 220MM A...................

W 801 8Z-CL5-622-010 F-CABLE,9P 2.5 250MM UL2468 AW A...................

W 401 8Z-CL5-604-010 FF-CABLE, 16P 1.0 100MM A...................

W 402 8Z-CL5-604-010 FF-CABLE, 16P 1.0 100MM A...................

Other manuals for XR-M77

Table of contents

Popular Stereo System manuals by other brands

Sony

Sony HCD-VX88 Service manual

Philips

Philips MCM398D/12 user manual

Sony

Sony CMT-SPZ90DB operating instructions

LG OM4560 owner's manual

JVC

JVC UX-G3 instructions

Odys

Odys ODYS - LOOP instruction manual

Panasonic

Panasonic SC-AK100 operating instructions

Sharp

Sharp CD-G10000V Operation manual

Bogen

Bogen NEARSCAPES 4.1 manual

Panasonic

Panasonic SCPM29 - MINI HES W/CD PLAYER operating instructions

Meyer

Meyer LD-3 operating instructions

THOMSON

THOMSON MIC302U manual

Philips

Philips MCM530 Service manual

Sony

Sony SS-CEP50 Service manual

Cetacea Sound

Cetacea Sound CVS-II user guide

Sony

Sony MHC-V21D Service manual

Denon

Denon UCD-250 Service manual

Exibel

Exibel BDX600-UK user manual

Aiwa XR-M77 User manual

Popular Stereo System manuals by other brands
