Aiwa CA-DW235 User manual
S E R V I C E M A N U A L
SIMPLE MANUAL
•Replace this Service Manual with ”Revision Publishing” when it is issued.
CA-DW235
CA-DW245
• TYPE: U,LH
COMPACT DISC STEREO SYSTEM
• BASIC TAPE MECHANISM:TN-21ZSW-1694
S/M Code No. 09–993–410–3T1
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
ELECTRICALPARTSLIST-1/5
NOTE: The characters in the suffix column indicate the part usage.
245LH ..................XX..................................A...................
235U ...................XX...................................B..................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
C 217 87-010-400-080 CAP, ELECT 0.47-50V AB..................
C 218 87-010-400-080 CAP, ELECT 0.47-50V AB..................
C 229 87-010-401-080 CAP, ELECT 1-50V AB..................
C 228 87-010-401-080 CAP, ELECT 1-50V AB..................
C 238 87-010-263-080 CAP, ELECT 100-10V AB..................
C 237 87-010-380-080 CAP, ELECT 47-16V AB..................
C 235 87-010-544-080 CAP, ELECT 0.1-50V AB..................
C 236 87-010-544-080 CAP, ELECT 0.1-50V AB..................
C 234 87-010-546-080 CAP, ELECT 0.33-50V AB..................
C 233 87-010-546-080 CAP, ELECT 0.33-50V AB..................
C 248 87-010-404-080 CAP, ELECT 4.7-50V AB..................
C 247 87-010-404-080 CAP, ELECT 4.7-50V AB..................
C 246 87-010-405-080 CAP, ELECT 10-50V AB..................
C 244 87-010-405-080 CAP, ELECT 10-50V AB..................
C 241 87-010-405-080 CAP, ELECT 10-50V AB..................
C 243 87-010-405-080 CAP, ELECT 10-50V AB..................
C 245 87-010-405-080 CAP, ELECT 10-50V AB..................
C 242 87-010-405-080 CAP, ELECT 10-50V AB..................
C 261 87-010-402-080 CAP, ELECT 2.2-50V AB..................
C 262 87-010-402-080 CAP, ELECT 2.2-50V AB..................
C 293 87-010-404-080 CAP, ELECT 4.7-50V AB..................
C 291 87-010-404-080 CAP, ELECT 4.7-50V AB..................
D 281 87-A40-466-080 ZENER,MTZJ2.7A AB..................
IC 203 87-A21-111-040 C-IC,M62495FP AB..................
C 208 87-010-402-080 CAP, ELECT 2.2-50V AB..................
C 207 87-010-408-080 CAP, ELECT 47-50V AB..................
C 209 87-018-134-080 CAPACITOR,TC-U 0.01-16 AB..................
C 211 87-010-401-080 CAP, ELECT 1-50V AB..................
C 212 87-010-401-080 CAP, ELECT 1-50V AB..................
C 210 87-018-134-080 CAPACITOR,TC-U 0.01-16 AB..................
C 220 87-010-405-080 CAP, ELECT 10-50V AB..................
C 222 87-018-134-080 CAPACITOR,TC-U 0.01-16 AB..................
C 226 87-018-134-080 CAPACITOR,TC-U 0.01-16 AB..................
C 223 87-018-134-080 CAPACITOR,TC-U 0.01-16 AB..................
IC 201 87-A20-946-040 C-IC,MM1434XF AB..................
C 251 87-010-401-080 CAP, ELECT 1-50V AB..................
C 267 87-010-380-080 CAP, ELECT 47-16V AB..................
C 268 87-010-380-080 CAP, ELECT 47-16V AB..................
C 265 87-010-383-080 CAP, ELECT 33-25V AB..................
C 266 87-010-383-080 CAP, ELECT 33-25V AB..................
C 263 87-018-131-080 CAP, CER 1000P-50V AB..................
C 264 87-018-131-080 CAP, CER 1000P-50V AB..................
C 279 87-010-112-080 CAP, ELECT 100-16V AB..................
C 271 87-010-221-080 CAP, ELECT 470-10V AB..................
C 272 87-010-221-080 CAP, ELECT 470-10V AB..................
C 277 87-010-260-080 CAP, ELECT 47-25V AB..................
C 278 87-010-384-080 CAP, ELECT 100-25V AB..................
C 280 87-010-401-080 CAP, ELECT 1-50V AB..................
C 281 87-010-401-080 CAP, ELECT 1-50V AB..................
IC 202 87-A20-591-010 IC,BA5417 AB..................
J 251 87-009-216-010 JACK, DIA 3.5 AB..................
PN 201 88-CT6-621-010 SP TERMINAL 4P LEVER AB..................
Q 243 89-320-011-010 TR,2SC2001 (0.6W) AB..................
Q 244 89-320-011-010 TR,2SC2001 (0.6W) AB..................
C 508 87-010-221-080 CAP, ELECT 470-10V AB..................
C 509 87-010-263-080 CAP, ELECT 100-10V AB..................
C 507 87-010-401-080 CAP, ELECT 1-50V AB..................
C 506 87-010-404-080 CAP, ELECT 4.7-50V AB..................
C 501 87-010-453-010 CAP, ELECT 4700-25V AB..................
C 510 87-010-248-080 CAP, ELECT 220-10V AB..................
C 514 87-010-248-080 CAP, ELECT 220-10V AB..................
C 511 87-010-384-080 CAP, ELECT 100-25V AB..................
C 512 87-010-385-080 CAP, ELECT 220-25V AB..................
C 533 87-010-221-080 CAP, ELECT 470-10V AB..................
C 531 87-010-263-080 CAP, ELECT 100-10V AB..................
C 543 87-010-221-080 CAP, ELECT 470-10V AB..................
C 541 87-010-374-080 CAP, ELECT 47-10V AB..................
C 544 87-010-405-080 CAP, ELECT 10-50V AB..................
D 506 84-RM1-695-010 DIODE,1N4148 AB..................
D 505 84-RM1-695-010 DIODE,1N4148 AB..................
D 503 84-RM1-695-010 DIODE,1N4148 AB..................
D 509 84-RM1-695-010 DIODE,1N4148 AB..................
D 508 84-RM1-695-010 DIODE,1N4148 AB..................
D 507 87-017-148-080 ZENER,HZS6A1L AB..................
D 504 87-017-161-080 ZENER,HZS7C2L AB..................
D 511 87-017-139-010 ZENER,HZS15-2 AB..................
IC 510 87-070-416-010 IC,NJU7201 L55 AB..................
PN 501 87-049-919-010 CONN,3P EH V WHT AB..................
Q 503 87-026-291-010 TR,DTC124XS AB..................
Q 507 87-026-462-010 TR,2SC1740S AB..................
Q 505 87-026-462-010 TR,2SC1740S AB..................
Q 502 87-026-463-010 TR,2SA933S,RS AB..................
Q 506 88-NF9-637-010 TR,2SA1318T/U AB..................
Q 501 89-112-965-010 TR,2SA1296GR AB..................
Q 504 89-213-702-010 TR,2SB1370 (1.8W) AB..................
Q 510 87-026-462-010 TR,2SC1740S AB..................
Q 532 87-026-291-010 TR,DTC124XS AB..................
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
ELECTRICALPARTSLIST-2/5
Q 531 87-026-463-010 TR,2SA933S,RS AB..................
Q 542 87-026-291-010 TR,DTC124XS AB..................
Q 541 89-112-965-010 TR,2SA1296GR AB..................
88-CT6-632-010 TERMINAL,ASSY MECHA 1P AB..................
C 305 87-010-374-080 CAP, ELECT 47-10V AB..................
C 306 87-010-374-080 CAP, ELECT 47-10V AB..................
C 307 87-010-382-080 CAP, ELECT 22-25V AB..................
C 308 87-010-405-080 CAP, ELECT 10-50V AB..................
C 309 87-010-545-080 CAP, ELECT 0.22-50V AB..................
C 304 87-018-131-080 CAP, CER 1000P-50V AB..................
C 302 87-018-131-080 CAP, CER 1000P-50V AB..................
C 303 87-018-131-080 CAP, CER 1000P-50V AB..................
C 301 87-018-131-080 CAP, CER 1000P-50V AB..................
C 311 87-010-248-080 CAP, ELECT 220-10V AB..................
C 312 87-010-374-080 CAP, ELECT 47-10V AB..................
C 318 87-010-382-080 CAP, ELECT 22-25V AB..................
C 317 87-010-382-080 CAP, ELECT 22-25V AB..................
C 315 87-010-401-080 CAP, ELECT 1-50V AB..................
C 316 87-010-401-080 CAP, ELECT 1-50V AB..................
C 319 87-010-405-080 CAP, ELECT 10-50V AB..................
C 310 87-010-545-080 CAP, ELECT 0.22-50V AB..................
C 327 87-010-404-080 CAP, ELECT 4.7-50V AB..................
C 320 87-010-405-080 CAP, ELECT 10-50V AB..................
C 321 87-018-125-080 CAP, CER 330P-50V AB..................
C 322 87-018-125-080 CAP, CER 330P-50V AB..................
C 328 87-018-131-080 CAP, CER 1000P-50V AB..................
C 329 87-018-132-080 CAP, CER 2200P-16V AB..................
C 326 87-018-196-080 CAP, CER 1500P-16V AB..................
C 325 87-018-196-080 CAP, CER 1500P-16V AB..................
C 331 87-010-374-080 CAP, ELECT 47-10V AB..................
C 334 87-018-122-080 CAP 180P-50 B AB..................
C 343 87-018-125-080 CAP, CER 330P-50V AB..................
C 341 87-018-125-080 CAP, CER 330P-50V AB..................
C 342 87-018-125-080 CAP, CER 330P-50V AB..................
C 344 87-018-125-080 CAP, CER 330P-50V AB..................
C 765 87-018-209-080 CAP, CER 0.1-50V AB..................
D 761 84-RM1-695-010 DIODE,1N4148 AB..................
D 762 84-RM1-695-010 DIODE,1N4148 AB..................
IC 302 87-001-440-010 IC,BA15218N AB..................
IC 301 87-020-828-010 IC,BA3416BL * AB..................
L 330 88-CT6-620-010 REC OSC AB..................
PN 301 87-A60-110-010 CONN,4P V S2M-4W AB..................
PN 302 87-A60-111-010 CONN,5P V S2M 5W AB..................
PN 751 87-099-832-010 CONN,8P S2M-8W AB..................
Q 308 87-026-462-080 TR,2SC1740 S(RS 0.3W) AB..................
Q 306 89-320-011-080 TR,2SC2001 (15W) AB..................
Q 311 87-026-291-080 TR,DTC124XS AB..................
Q 762 87-026-291-080 TR,DTC124XS AB..................
Q 761 87-026-463-080 TR,2SA933S (0.3W) AB..................
Q 771 87-026-291-080 TR,DTC124XS AB..................
Q 770 89-112-965-080 TR,2SA1296 (0.75W) AB..................
R 761 87-029-019-010 RES, FUSEIBLE 1/2W-2.2 AB..................
SFR 761 87-024-239-010 SFR,2.2K V RH0632C AB..................
SW 301 88-CT6-619-010 BACK SLIDE SW 6P2T SHORTIN AB..................
8Z-CT9-202-010 HLDR,LCD AB..................
8Z-CT9-203-010 HLDR,LED A AB..................
8Z-CT9-204-010 HLDR,LED B AB..................
8Z-CT9-205-010 HLDR,LED C AB..................
C 607 87-018-134-080 CAPACITOR,TC-U 0.01-16 AB..................
C 606 87-018-134-080 CAPACITOR,TC-U 0.01-16 AB..................
C 609 87-018-209-080 CAP, CER 0.1-50V AB..................
C 608 87-018-209-080 CAP, CER 0.1-50V AB..................
C 601 89-654-185-080 CAP,TC 18P-50 J CH UP125 AB..................
C 604 89-654-215-080 CAP,TC 22P-50 J CH UP125 AB..................
C 602 89-654-235-080 CAP TC 27P-50J CH AB..................
C 605 89-654-275-080 CAP,TC 39P-50 J CH UP125 AB..................
C 603 89-654-275-080 CAP,TC 39P-50 J CH UP125 AB..................
C 612 87-010-248-080 CAP, ELECT 220-10V AB..................
C 610 87-010-263-080 CAP, ELECT 100-10V AB..................
C 615 87-010-400-080 CAP, ELECT 0.47-50V AB..................
C 616 87-010-401-080 CAP, ELECT 1-50V AB..................
C 613 87-010-402-080 CAP, ELECT 2.2-50V AB..................
C 611 87-018-209-080 CAP, CER 0.1-50V AB..................
C 614 87-018-209-080 CAP, CER 0.1-50V AB..................
C 621 87-010-263-080 CAP, ELECT 100-10V AB..................
C 622 87-010-378-080 CAP, ELECT 10-16V AB..................
C 620 87-018-134-080 CAPACITOR,TC-U 0.01-16 AB..................
D 601 84-RM1-695-010 DIODE,1N4148 AB..................
D 602 84-RM1-695-010 DIODE,1N4148 AB..................
D 617 84-RM1-695-010 DIODE,1N4148 AB..................
D 611 84-RM1-695-010 DIODE,1N4148 AB..................
D 615 84-RM1-695-010 DIODE,1N4148 A...................
D 616 84-RM1-695-010 DIODE,1N4148 A...................
D 612 84-RM1-695-010 DIODE,1N4148 AB..................
D 614 87-027-607-080 ZENER,HZ7B3L AB..................
IC 601 8Z-CH4-636-010 IC,LC867132V-**** AB..................
L 601 87-003-171-010 COIL,15UH TROIDAL AB..................
LCD 601 8Z-CT9-630-010 LCD,HLC7107 ZCT-9 AB..................
LED 603 8Z-CT6-632-010 LED,L-934LID AB..................
LED 605 8Z-CT6-632-010 LED,L-934LID AB..................
LED 608 8Z-CT6-632-010 LED,L-934LID AB..................
LED 604 8Z-CT6-632-010 LED,L-934LID AB..................
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
ELECTRICALPARTSLIST-3/5
LED 607 8Z-CT6-632-010 LED,L-934LID AB..................
LED 609 8Z-CT6-632-010 LED,L-934LID AB..................
LED 606 8Z-CT6-632-010 LED,L-934LID AB..................
LED 602 8Z-CT6-632-010 LED,L-934LID AB..................
LED 610 8Z-CT6-632-010 LED,L-934LID AB..................
PN 601 87-A60-109-010 CONN,2P V S2M-2W AB..................
Q 603 87-026-291-010 TR,DTC124XS AB..................
Q 601 87-026-291-010 TR,DTC124XS AB..................
Q 602 87-026-463-010 TR,2SA933S,RS AB..................
Q 607 87-026-464-010 TR,DTC114TS AB..................
Q 609 87-026-464-010 TR,DTC114TS AB..................
Q 605 87-026-464-010 TR,DTC114TS AB..................
Q 608 87-026-464-010 TR,DTC114TS AB..................
Q 606 87-026-464-010 TR,DTC114TS AB..................
Q 615 87-026-291-010 TR,DTC124XS A...................
Q 614 87-026-463-010 TR,2SA933S,RS A...................
Q 610 87-026-464-010 TR,DTC114TS AB..................
Q 611 87-026-464-010 TR,DTC114TS AB..................
Q 617 87-026-464-010 TR,DTC114TS AB..................
Q 612 87-026-464-010 TR,DTC114TS AB..................
Q 618 87-026-464-010 TR,DTC114TS AB..................
Q 613 89-318-155-080 TR,2SC1815 (0.4W) AB..................
S 603 8Z-CT6-636-010 SW,TACT EVQJAC04M AB..................
S 606 8Z-CT6-636-010 SW,TACT EVQJAC04M AB..................
S 602 8Z-CT6-636-010 SW,TACT EVQJAC04M AB..................
S 607 8Z-CT6-636-010 SW,TACT EVQJAC04M AB..................
S 604 8Z-CT6-636-010 SW,TACT EVQJAC04M AB..................
S 609 8Z-CT6-636-010 SW,TACT EVQJAC04M AB..................
S 605 8Z-CT6-636-010 SW,TACT EVQJAC04M AB..................
S 608 8Z-CT6-636-010 SW,TACT EVQJAC04M AB..................
S 610 8Z-CT6-636-010 SW,TACT EVQJAC04M AB..................
S 613 8Z-CT6-636-010 SW,TACT EVQJAC04M AB..................
S 615 8Z-CT6-636-010 SW,TACT EVQJAC04M AB..................
S 611 8Z-CT6-636-010 SW,TACT EVQJAC04M AB..................
S 616 8Z-CT6-636-010 SW,TACT EVQJAC04M AB..................
S 612 8Z-CT6-636-010 SW,TACT EVQJAC04M AB..................
S 614 8Z-CT6-636-010 SW,TACT EVQJAC04M AB..................
X 601 87-030-273-010 VIB,XTAL 32.768K5PPM AB..................
X 602 87-A70-070-080 VIB,CER 5.76MHZ CRHF AB..................
C 839 87-010-401-080 CAP, ELECT 1-50V AB..................
C 838 87-010-401-080 CAP, ELECT 1-50V AB..................
C 834 87-010-404-080 CAP, ELECT 4.7-50V AB..................
C 835 87-010-544-080 CAP, ELECT 0.1-50V AB..................
C 840 87-010-221-080 CAP, ELECT 470-10V AB..................
C 844 87-010-401-080 CAP, ELECT 1-50V AB..................
C 841 87-010-401-080 CAP, ELECT 1-50V AB..................
C 842 87-018-127-080 CAP, CER 470P-50V AB..................
D 820 84-RM1-695-010 DIODE,1N4148 AB..................
D 821 84-RM1-695-010 DIODE,1N4148 AB..................
D 822 84-RM1-695-010 DIODE,1N4148 AB..................
J 801 88-CT6-625-010 JACK,MIC AB..................
Q 823 87-026-291-080 TR,DTC124XS AB..................
Q 824 87-026-462-080 TR,2SC1740 S(RS 0.3W) AB..................
Q 820 87-026-610-080 TR,KTC3198GR AB..................
Q 822 87-026-610-080 TR,KTC3198GR AB..................
Q 821 89-322-405-080 TR,2SC2240GR AB..................
VR 801 87-A90-768-010 VR,RTRY 10KAX1 1 H AB..................
C 409 87-010-248-080 CAP, ELECT 220-10V AB..................
C 404 87-010-248-080 CAP, ELECT 220-10V AB..................
C 403 87-010-263-080 CAP, ELECT 100-10V AB..................
C 406 87-010-374-080 CAP, ELECT 47-10V AB..................
C 401 87-010-403-080 CAP, ELECT 3.3-50V AB..................
C 405 87-018-134-080 CAPACITOR,TC-U 0.01-16 AB..................
C 402 87-018-134-080 CAPACITOR,TC-U 0.01-16 AB..................
C 410 87-010-263-080 CAP, ELECT 100-10V AB..................
C 414 87-010-405-080 CAP, ELECT 10-50V AB..................
C 412 87-010-544-080 CAP, ELECT 0.1-50V AB..................
C 416 87-010-545-080 CAP, ELECT 0.22-50V AB..................
C 417 87-018-125-080 CAP, CER 330P-50V AB..................
C 425 87-018-129-080 CAP, CER 680P-50V AB..................
C 436 87-010-374-080 CAP, ELECT 47-10V AB..................
C 432 87-010-374-080 CAP, ELECT 47-10V AB..................
C 431 87-010-400-080 CAP, ELECT 0.47-50V AB..................
C 433 87-010-401-080 CAP, ELECT 1-50V AB..................
C 437 87-010-404-080 CAP, ELECT 4.7-50V AB..................
C 430 87-018-123-080 CAP, CER 220P-50V AB..................
C 435 87-018-134-080 CAPACITOR,TC-U 0.01-16 AB..................
C 438 87-018-209-080 CAP, CER 0.1-50V AB..................
C 442 87-018-059-080 CAP TC-S 22P-50CH AB..................
C 448 87-018-111-080 CAP, CERA-SOL SS 27P AB..................
C 447 87-018-209-080 CAP, CER 0.1-50V AB..................
C 446 87-018-209-080 CAP, CER 0.1-50V AB..................
C 445 87-018-209-080 CAP, CER 0.1-50V AB..................
C 459 87-010-263-080 CAP, ELECT 100-10V AB..................
C 455 87-010-263-080 CAP, ELECT 100-10V AB..................
C 457 87-018-106-080 CAP,TC-U 15P-50 SL AB..................
C 458 87-018-106-080 CAP,TC-U 15P-50 SL AB..................
C 453 87-018-119-080 CAP, CER 100P-50V AB..................
C 454 87-018-120-080 CAP, CERA-SOL SS 120P AB..................
C 451 87-018-123-080 CAP, CER 220P-50V AB..................
C 450 87-018-127-080 CAP, CER 470P-50V AB..................
C 452 87-018-127-080 CAP, CER 470P-50V AB..................
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
ELECTRICALPARTSLIST-4/5
C 462 87-010-248-080 CAP, ELECT 220-10V AB..................
C 467 87-010-263-080 CAP, ELECT 100-10V AB..................
C 465 87-010-404-080 CAP, ELECT 4.7-50V AB..................
C 469 87-018-121-080 CAP, CER 150P-50V AB..................
C 461 87-018-209-080 CAP, CER 0.1-50V AB..................
C 466 87-018-209-080 CAP, CER 0.1-50V AB..................
C 460 87-018-209-080 CAP, CER 0.1-50V AB..................
C 476 87-010-236-080 CAP,E 1000-10 SME AB..................
C 478 87-010-263-080 CAP, ELECT 100-10V AB..................
C 470 87-010-544-080 CAP, ELECT 0.1-50V AB..................
C 477 87-018-134-080 CAPACITOR,TC-U 0.01-16 AB..................
C 479 87-018-134-080 CAPACITOR,TC-U 0.01-16 AB..................
C 475 87-018-134-080 CAPACITOR,TC-U 0.01-16 AB..................
C 480 87-010-221-080 CAP, ELECT 470-10V AB..................
C 481 87-010-405-080 CAP, ELECT 10-50V AB..................
C 482 87-010-405-080 CAP, ELECT 10-50V AB..................
C 483 87-018-123-080 CAP, CER 220P-50V AB..................
C 484 87-018-123-080 CAP, CER 220P-50V AB..................
C 489 87-018-209-080 CAP, CER 0.1-50V AB..................
C 497 87-018-119-080 CAP, CER 100P-50V AB..................
C 496 87-018-119-080 CAP, CER 100P-50V AB..................
C 494 87-018-119-080 CAP, CER 100P-50V AB..................
C 498 87-018-119-080 CAP, CER 100P-50V AB..................
C 495 87-018-119-080 CAP, CER 100P-50V AB..................
C 492 87-018-134-080 CAPACITOR,TC-U 0.01-16 AB..................
C 493 87-018-134-080 CAPACITOR,TC-U 0.01-16 AB..................
C 491 87-018-209-080 CAP, CER 0.1-50V AB..................
C 490 87-018-209-080 CAP, CER 0.1-50V AB..................
C 499 87-018-209-080 CAP, CER 0.1-50V AB..................
D 402 84-RM1-695-010 DIODE,1N4148 AB..................
D 403 84-RM1-695-010 DIODE,1N4148 AB..................
D 401 84-RM1-695-010 DIODE,1N4148 AB..................
IC 401 87-A20-446-010 C-IC,LA9241ML AB..................
IC 402 87-A20-459-010 C-IC,LC78622ED AB..................
IC 404 87-A21-093-010 IC,LA6541D AB..................
L 401 87-003-102-080 COIL, 10UH AB..................
L 403 87-003-102-080 COIL, 10UH AB..................
L 405 87-003-152-080 COIL, 100UH AB..................
L 404 87-003-152-080 COIL, 100UH AB..................
L 412 81-NWB-655-010 COIL,10UH TROIDAL AB..................
PN 402 87-A60-061-010 CONN,06P V 9604S-06C AB..................
PN 401 87-A60-424-010 CONN,16P V TOC-B AB..................
Q 401 87-026-463-080 TR,2SA933S (0.3W) AB..................
Q 402 89-113-184-080 TR,2SA1318T AB..................
SFR 430 87-024-176-010 SFR,100K DIA6 V AB..................
X 401 81-592-641-010 VIB,CER 16.93MHZ AB..................
88-CT6-624-010 SPR,BATT AB..................
C 904 87-A10-577-080 CAP,CER 0.022-50 Z YF AB..................
C 903 87-A10-577-080 CAP,CER 0.022-50 Z YF AB..................
C 901 87-A10-577-080 CAP,CER 0.022-50 Z YF AB..................
C 902 87-A10-577-080 CAP,CER 0.022-50 Z YF AB..................
D 902 87-A40-465-010 DIODE,FR202 AB..................
D 904 87-A40-465-010 DIODE,FR202 AB..................
D 903 87-A40-465-010 DIODE,FR202 AB..................
D 901 87-A40-465-010 DIODE,FR202 AB..................
D 905 87-A40-465-010 DIODE,FR202 AB..................
FC 902 87-A90-160-080 FUSE CLAMP,FC 51F AB..................
FC 901 87-A90-160-080 FUSE CLAMP,FC 51F AB..................
8Z-CT9-651-010 PIN,RT-01T-1.0B AB..................
C 6 87-010-378-080 CAP, ELECT 10-16V AB..................
C 1 87-018-059-080 CAP TC-S 22P-50CH AB..................
C 3 87-018-059-080 CAP TC-S 22P-50CH AB..................
C 2 87-018-062-080 CAP,TC-S 33P-50 CH AB..................
C 9 87-018-147-080 CAP,TC-U 10P-50 CH AB..................
C 9 87-018-148-080 CAP,TC-U 12P-50 CH ....................
C 7 87-018-208-080 CAP 0.047-50F AB..................
C 8 87-A11-227-080 CAP,TC U 2200P-50 K B UP050 AB..................
C 14 87-010-400-080 CAP, ELECT 0.47-50V AB..................
C 18 87-010-544-080 CAP, ELECT 0.1-50V AB..................
C 19 87-010-544-080 CAP, ELECT 0.1-50V AB..................
C 12 87-018-059-080 CAP TC-S 22P-50CH AB..................
C 16 87-018-131-080 CAP, CER 1000P-50V AB..................
C 15 87-018-134-080 CAPACITOR,TC-U 0.01-16 AB..................
C 10 87-018-134-080 CAPACITOR,TC-U 0.01-16 AB..................
C 13 87-018-142-080 CAP,TC-U 3.9P-50 CH AB..................
C 11 87-018-147-080 CAP,TC-U 10P-50 CH ....................
C 17 87-018-205-080 CAP, CERA-SOL 0.022 AB..................
C 20 87-010-400-080 CAP, ELECT 0.47-50V AB..................
C 21 87-010-403-080 CAP, ELECT 3.3-50V AB..................
C 27 87-010-545-080 CAP, ELECT 0.22-50V AB..................
C 26 87-010-545-080 CAP, ELECT 0.22-50V AB..................
C 22 87-018-134-080 CAPACITOR,TC-U 0.01-16 AB..................
C 28 87-018-208-080 CAP 0.047-50F AB..................
C 29 87-018-208-080 CAP 0.047-50F AB..................
C 30 87-010-248-080 CAP, ELECT 220-10V AB..................
C 31 87-010-379-080 CAP, ELECT 22-16V AB..................
C 35 87-018-059-080 CAP TC-S 22P-50CH ....................
C 34 87-018-134-080 CAPACITOR,TC-U 0.01-16 AB..................
C 32 87-018-134-080 CAPACITOR,TC-U 0.01-16 AB..................
C 33 87-018-134-080 CAPACITOR,TC-U 0.01-16 AB..................
C 38 87-A11-224-080 CAP,TC 47P-50 J CH UP125 AB..................
C 38 87-A11-225-080 CAP,TC 82P-50 J CH UP125 ....................
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
ELECTRICALPARTSLIST-5/5
C 37 87-A11-226-080 CAP,TC 180P-50 K CH UP125 AB..................
C 41 87-018-090-080 CAP,TC-S 18P-50 UJ ....................
C 44 87-018-122-080 CAP 180P-50 B ....................
C 44 87-018-123-080 CAP, CER 220P-50V ....................
C 46 87-018-130-080 CAP,TC-U 820P-50 B ....................
C 45 87-018-197-080 CAP, CER 1800P-16V ....................
CF 2 87-008-261-010 FILTER, SFE10.7MA5-A AB..................
CF 3 87-008-261-010 FILTER, SFE10.7MA5-A AB..................
CF 1 87-A91-150-010 FLTR, CFAL-455(TOKO) AB..................
D 1 84-RM1-695-010 DIODE,1N4148 AB..................
D 2 84-RM1-695-010 DIODE,1N4148 AB..................
D 4 84-RM1-695-010 DIODE,1N4148 AB..................
D 3 87-A40-226-080 VARI-CAP,SVC251SPA AB..................
IC 1 87-A20-955-010 IC,LA1828 AB..................
L 9 87-A50-334-010 COIL,FM DET (TOKO) AB..................
L 8 87-A50-335-010 COIL,FM IFT (TOKO) AB..................
L 7 87-A50-336-010 COIL,AM IFT (TOKO) AB..................
L 6 87-A50-337-010 COIL,AM OSC (TOKO) AB..................
L 5 87-A50-342-010 COIL,FM OSC D ....................
L 5 87-A50-343-010 COIL,FM OSC EX A...................
L 4 87-A50-345-010 COIL,FM RF EX AB..................
L 2 87-A50-346-010 COIL,FM BPF D ....................
L 2 87-A50-347-010 COIL,FM BPF EX AB..................
L 3 87-A50-348-010 COIL,BAR ANT LW/MW (COI) ....................
L 3 87-A50-349-010 COIL,BAR ANT AMW (COI) ....................
L 3 87-A50-350-010 COIL,BAR ANT AMN (COI) AB..................
L 5 87-A50-449-010 COIL,FM OSC U .B..................
L 10 87-003-102-080 COIL, 10UH AB..................
L 16 87-A50-337-010 COIL,AM OSC (TOKO) ....................
L 17 87-A50-337-010 COIL,AM OSC (TOKO) ....................
L 16 87-A50-339-010 COIL,LW OSC (TOKO) ....................
L 17 87-A50-340-010 COIL,SW OSC (TOKO) ....................
L 11 87-A50-341-010 COIL,SW ANT (TOKO) ....................
L 41 87-003-143-080 COIL 4.7 UH ....................
Q 3 87-026-215-080 TR,DTC114YS AB..................
Q 5 87-026-291-080 TR,DTC124XS AB..................
Q 2 87-026-572-080 TR,DTA114TS AB..................
Q 4 89-109-521-080 TR,2SA952 (0.6W) ....................
Q 1 89-319-233-080 TR,2SC1923 (0.1W) AB..................
SW 1 88-CT6-618-010 SLIDE SW 4P3T ....................
SW 1 88-CT7-602-010 SLIDE SW 2P2T AB..................
TC 6 87-011-220-080 TRIMMER CAP 20P VTC ....................
TC 5 87-011-221-080 CAP, TRIMMER 30P ....................
TC 6 87-011-221-080 CAP, TRIMMER 30P ....................
VC 1 87-A91-167-010 TUN-CAP,20P-160P FA-22125 N000 AB..................
VC 1 87-A91-168-010 TUN-CAP,20P-140P FA-22124 N000 ....................
VC 1 87-A91-169-010 TUN-CAP,40P-140P FA-22124 AN00 ....................
VC 1 87-A91-170-010 TUN-CAP,20P-335P FA-2217 N000- ....................
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
MECHANICAL PARTS LIST-1/2
NOTE: The characters in the suffix column indicate the part usage.
245LH ..................XX..................................A...................
235U ...................XX...................................B..................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
86-CT6-035-010 LID,BATT RF AB..................
86-CT6-036-010 HANDL,RF AB..................
86-CT9-039-010 BADGE,AIWA 30N AB..................
88-CT6-022-010 COVER, HNDL AB..................
8Z-CT9-001-010 CABI,FRONT .B..................
8Z-CT9-002-010 WINDOW,DISPLAY .B..................
8Z-CT9-003-010 BOX,CASS (L) AB..................
8Z-CT9-004-010 BOX,CASS (R) AB..................
8Z-CT9-005-010 WINDOW,CASS (L) AB..................
8Z-CT9-006-010 WINDOW,CASS (R) AB..................
8Z-CT9-007-010 BOX,CD AB..................
8Z-CT9-017-010 POINTER,TUN AB..................
8Z-CT9-021-010 LENS,FUNC AB..................
8Z-CT9-022-010 LENS,OPE AB..................
8Z-CT9-023-010 LENS,GEQ AB..................
8Z-CT9-024-010 LENS,Q-SOUND AB..................
8Z-CT9-025-010 RING,GEQ AB..................
8Z-CT9-027-010 WINDOW,DISPLAY D ....................
8Z-CT9-028-010 WINDOW,DISPLAY HR ....................
8Z-CT9-030-010 CABI,FRONT D ....................
8Z-CT9-031-010 CABI,FRONT HR ....................
8Z-CT9-044-010 CABI,REAR AB..................
8Z-CT9-045-010 CABI,FR LH A...................
8Z-CT9-009-010 KEY,CASS (A) AB..................
8Z-CT9-010-010 KEY,CASS (B) AB..................
8Z-CT9-011-010 KNOB,RTRY TU AB..................
8Z-CT9-012-010 KNOB,RTRY BAND(3B) ....................
8Z-CT9-013-010 BTN,CD A AB..................
8Z-CT9-014-010 BTN,CD B AB..................
8Z-CT9-015-010 KNOB,RTRY MIC AB..................
8Z-CT9-016-010 BTN,FUNCTION AB..................
8Z-CT9-018-010 BTN,VOL AB..................
8Z-CT9-019-010 BTN,Q-SOUND AB..................
8Z-CT9-020-010 BTN,GEQ AB..................
8Z-CT9-026-010 KNOB,RTRY BAND(2B) AB..................
8Z-CT9-046-010 BTN,RTRY BAND D ....................
8Z-CT9-047-010 BTN,FUNC D ....................
8Z-CT9-048-010 BTN,QSOUND D ....................
8Z-CT9-050-010 BTN,GEQ D ....................
86-CT9-026-010 PLATE,AC AB..................
88-CT6-046-010 PANEL,CD AB..................
8Z-CT9-008-010 WINDOW,CD AB..................
S 0 87-036-389-010 SW,PUSH LOCK AB..................
86-CD4-225-010 CHUCK(A) AB..................
86-CT9-202-010 DRUM,TU AB..................
86-CT9-205-110 HLDR,REC AB..................
86-CT9-207-010 HLDR,ANT AB..................
86-CT9-210-010 SPR-T,CASS AB..................
86-CT9-211-010 SPR-T,CD AB..................
86-CT9-212-010 SPR-C,BATT LINK AB..................
86-CT9-213-010 SPR-C,BATT(-) AB..................
86-CT9-219-110 OIL-DMPR,GEAR AB..................
86-CT9-220-110 OIL-DMPR,BRACKET AB..................
86-CT9-222-010 PLATE,MAGNET AB..................
86-CT9-223-010 CUSH,FOOT AB..................
87-036-368-010 MAGNET AB..................
87-CT7-207-010 SPR-P,REC AB..................
88-CD6-661-010 HLDR,BAR ANT. AB..................
8Z-CT6-213-010 BASE,CHUCK AB..................
8Z-CT6-214-010 RING,CHUCK AB..................
8Z-CT9-201-010 HLDR,POINTER AB..................
8Z-CT9-206-010 CAP,SW AB..................
8Z-CT9-207-010 GEAR,BAND AB..................
8Z-CT9-208-010 BASE,GEQ AB..................
8Z-CT9-209-010 CHAS,CD AB..................
8Z-CT9-210-010 SPR-P,PLT AB..................
8Z-CT9-211-010 SPR-P,BAND(3B) ....................
8Z-CT9-212-010 SPR-P,BAND(2B) AB..................
81-CD5-204-010 SCREW CD AB..................
87-261-072-410 V+2.6-5 AB..................
87-571-095-410 VIT+3-8 .B..................
87-651-075-210 VT1+2.6-10 AB..................
87-651-100-410 VT1+3-16 AB..................
87-651-104-410 VT1+3-30 AB..................
87-721-095-410 QT2+3-8GLD W/O SLOT AB..................
87-751-094-410 VT2+3-6 W10SL0T AB..................
87-751-095-410 VT2+3-8 W/O AB..................
87-751-095-410 VT2+3-8 W/O AB..................
87-751-097-410 SCREW 3X12 AB..................
* 87-571-033-410 TAPPING SCREW, VIT+2-4 AB..................
87-A90-086-010 COVER,AC-SOCKET AB..................
88-CT6-606-010 FFC WIRE 16P(1.0 ) AB..................
ANT 1 88-CT6-633-010 ANT,ROD AB..................
CN 302 88-CT6-605-010 CONN ASSY,5P RPH AB..................
CN 402 8Z-CT6-631-010 CONN ASSY,6P CD MO AB..................
CN 751 88-CT6-608-010 CONN ASSY,8P MO AB..................
F 901 87-035-191-010 FUSE, 3.15AT A...................
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
MECHANICAL PARTS LIST-2/2
F 901 87-035-486-010 FUSE,2.5A 125V D UL .B..................
J 901 87-A60-177-010 JACK,AC U W/SW .B..................
J 901 87-A60-178-010 JACK,AC E W/SW A...................
J 901 87-A60-179-010 JACK,AC D W/SW ....................
PT 901 88-CT6-629-010 PT,D ....................
PT 901 88-CT6-630-010 PT,EZ/K ....................
PT 901 88-CT6-631-010 POWER TRANS,EI-57/25 A...................
PT 901 88-CT7-629-010 PT,U .B..................
S 901 87-A91-302-010 SW,AC SL 2 2 2 SDKGA40100 A...................
86-CT9-039-010 BADGE,AIWA 30N AB..................
86-CT9-117-010 CABI,SPKR-REAR L RF AB..................
86-CT9-118-010 CABI,SPKR-REAR R RF AB..................
8Z-CT9-041-010 CABI,SPKR FR A AB..................
8Z-CT9-042-010 CABI,SPKR FR B AB..................
8Z-CT9-043-010 GRILLE,SPKR AB..................
87-651-100-410 VT1+3-16 AB..................
87-751-096-410 VT2+3-10 GLD AB..................
8Z-CT6-646-010 CORD ASSY,SPEAKER AB..................
8Z-CT6-647-010 SPKR,12 3.2OHM A...................
8Z-CT9-631-010 SPKR,12 7.0OHM .B..................
88-CT6-632-010 TERMINAL,ASSY MECHA 1P AB..................
8Z-CT9-202-010 HLDR,LCD AB..................
8Z-CT9-203-010 HLDR,LED A AB..................
8Z-CT9-204-010 HLDR,LED B AB..................
8Z-CT9-205-010 HLDR,LED C AB..................
88-CT6-624-010 SPR,BATT AB..................
8Z-CT9-651-010 PIN,RT-01T-1.0B AB..................
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
ACCESSORIES / PACKAGE LIST-1/1
NOTE: The characters in the suffix column indicate the part usage.
245LH ..................XX..................................A...................
235U ...................XX...................................B..................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
87-036-389-010 SW,PUSH LOCK AB..................
IC 201 87-A20-946-040 C-IC,MM1434XF AB..................
IC 203 87-A21-111-040 C-IC,M62495FP AB..................
IC 401 87-A20-446-010 C-IC,LA9241ML AB..................
IC 402 87-A20-459-010 C-IC,LC78622ED AB..................
IC 404 87-A21-093-010 IC,LA6541D AB..................
IC 601 8Z-CH4-636-010 IC,LC867132V-**** AB..................
Q 504 89-213-702-010 TR,2SB1370 (1.8W) AB..................
8Z-CT9-901-010 IB,D(J)FM ....................
8Z-CT9-905-010 IB,U(ESF)FM .B..................
8Z-CT9-906-010 IB,LH(ESP)FM A...................
8Z-CT9-907-010 IB,H(ECA)FM ....................
8Z-CT9-909-010 IB,K(E) ....................
87-050-076-010 AC CORD SET ASSY,E A...................
87-050-099-010 AC CORD SET ASSY K3P ....................
87-A80-033-010 AC CORD SET,D BLK ....................
87-A80-109-010 AC CORD,HK7281 BLK U .B..................
87-A80-119-010 AC CORD SET ASSY,AZ ....................
87-A90-312-010 PLUG,CONVERSION WTN-1157R1 A...................
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
Other manuals for CA-DW235
2
This manual suits for next models
1
Other Aiwa Stereo System manuals
