Button User Manual
Updated October 18, 2019
Button is a wireless panic button with protection against accidental activation. It can
operate for up to 5 years on the bundled battery. It is connected to the Ajax security
system via the Jeweller security protocol, with a transmission distance of up to 1300
m without obstacles.
Button only connects to . No provision is made for connection to the and
integration modules!
The button is linked to the security system and congured via for
Windows, macOS, iPhone and Android smartphones. The users are alerted about all
alarms and events via push notications, SMS, and phone calls (if enabled).
Ajax hubs ocBridge Plus
uartBridge
Ajax applications
Devices Controls
18/10/2019 Button User Manual - Ajax Support
https://support.ajax.systems/en/manuals/button/?_ga=2.98140895.1985800128.1571327333-1921628607.1570693416 2/12
The Ajax security system can be used for independent monitoring of the site and can
be connected to the security company’s Central Monitoring Station.
Button is supported by the hubs with OS Malevich 2.7.102orhigher. All hubs will
be updated until the end of August 2019. To request an early-access rmware
update, please .
Functional elements
Operating principle
Button is a wireless panic button that, when pressed, transmits an alarm to users, as
well as to the security company’s CMS.
Buy panic button Button
ll out the form
Alarm button1.
Indicator lights2.
Button mounting hole3.
18/10/2019 Button User Manual - Ajax Support
https://support.ajax.systems/en/manuals/button/?_ga=2.98140895.1985800128.1571327333-1921628607.1570693416 3/12
The button is equipped with protection against accidental activation and transmits
alarms at a distance of up to 1,300 m from the hub. Please be aware that the
presence of any obstructions that impede the signal (for example, walls or oors) will
reduce this distance.
Button is easy to carry around. You can always keep it on a wrist or a neckless. The
device is resistant to dust and splashes.
Connecting the button to the Ajax security system
Prior to initiating connection
Only users with administrative rights can add a device to the hub
In order to connect a Button
Follow the hub instructions to install the . Create an account, add a
hub to the app, and create at least one room.
1. Ajax application
Enter the Ajax app.2.
Activate the hub and check your internet connection.3.
Ensure that the hub is not in armed mode and is not being updated by checking its
status in the app.
4.
Click on Add Device in the Ajax app.1.
Name the device, scan its QR code (located on the package) or enter it manually,
select a room and a group (if group mode is enabled).
2.
Click Add and the countdown will begin.3.
Hold the button for 7 seconds. When the Button is added, the LEDs will ash
green once.
4.
18/10/2019 Button User Manual - Ajax Support
https://support.ajax.systems/en/manuals/button/?_ga=2.98140895.1985800128.1571327333-1921628607.1570693416 4/12
For detection and pairing, the Button must be located within the hub radio
communication zone (on the single protected object).
The connected button will appear in the list of hub devices in the application.
Updating the statuses of the device in the list does not depend on the polling time
value in the hub settings. Data is updated only by pressing the Button.
The Button only works with one hub. When connected to a new hub, the button Button
stops transmitting commands to the old hub. Note that after being added to the new
hub, the Button is not automatically removed from the device list of the old hub. This
must be done manually through the Ajax application.
States
Button statuses can be viewed in the device menu:
Ajax app Devices Button1.
18/10/2019 Button User Manual - Ajax Support
https://support.ajax.systems/en/manuals/button/?_ga=2.98140895.1985800128.1571327333-1921628607.1570693416 5/12
Parameter Value
Battery charge
Button battery charge level. There are two statuses:
Button operating mode
This displays the operating mode of the button.
There are two modes:
Battery OK
Battery low
Panic button
SmartButton (in development)
18/10/2019 Button User Manual - Ajax Support
https://support.ajax.systems/en/manuals/button/?_ga=2.98140895.1985800128.1571327333-1921628607.1570693416 6/12
Indicator light brightness Displays current brightness level of indicator light:
Protection against accidental activation
Displays the selected type of protection against
accidental activation:
Firmware Button rmware version
ID Device ID
Settings
You can adjust the device parameters in the settings section:
SmartButton (in development)
Disabled (no display)
Minimum
Maximum
Off — protection disabled.
Delay when pressing — in order to send alarm
you should hold the button down for more
than 1.5 seconds.
Double-pressing — in order to send alarm you
should double-press on the button with a
pause of no more than 0.5 seconds.
Ajax app Devices Button Settings 1.
18/10/2019 Button User Manual - Ajax Support
https://support.ajax.systems/en/manuals/button/?_ga=2.98140895.1985800128.1571327333-1921628607.1570693416 7/12
Parameter Value
First eld Name of the device, can be changed
Room The choice of the virtual room that the device is
assigned to
Button operating mode
This displays the operating mode of the button.
There are two modes:
Panic Button — sends an alarm when pressed
SmartButton (in development)
18/10/2019 Button User Manual - Ajax Support
https://support.ajax.systems/en/manuals/button/?_ga=2.98140895.1985800128.1571327333-1921628607.1570693416 8/12
Device user
Assigns a panic button user. After assignment,
button presses will be displayed as events of the
selected user
Brightness of indicator lights This displays the current brightness of the indicator
lights:
Protection against accidental activation
Displays the selected type of protection against
accidental activation:
Firmware Button rmware version
ID Device ID
Note that any changes to the settings will be applied on the second click!
Operating indication
Button status is indicated with red or green LED indicators.
Category Indication Event
Linking to security system
Green LEDs ash 6 times The button is not registered in
any security system
Lights up green for a few
seconds
Adding a button to the security
system
Li ht b i Command is delivered to security
Disabled (no display)
Minimum
Maximum
Off — protection disabled.
Delay when pressing — in order to send alarm
you should hold the button down for more
than 1.5 seconds.
Double-pressing — in order to send alarm you
should double-press on the button with a
pause of no more than 0.5 seconds.
18/10/2019 Button User Manual - Ajax Support
https://support.ajax.systems/en/manuals/button/?_ga=2.98140895.1985800128.1571327333-1921628607.1570693416 9/12
Command delivery indication
Lights up green briey y
system
Lights up red briey Command is not delivered to
security system
Feedback Indication
(follows the Command Delivery
Indication)
Lights up green for about half a
second after the command
delivery indication
The security system has received
and performed the command
Briey lights up red after the
command delivery indication
The security system did not
perform the command
Battery status
(follows Feedback Indication)
After the main indication it lights
up red and goes out smoothly
Button battery needs to be
replaced. At the same time,
button commands are delivered
to the security system.
Use cases
Button can be installed on a at surface or carried around.
To install on a at surface (for example, under the table), secure the Button with
double-sided adhesive tape.
To carry the Button on the strap: attach the strap to the Button using the mounting
hole in the main body of the Button.
Maintenance
When cleaning the key fob body, use cleaners that are suitable for technical
maintenance.
Never use substances containing alcohol, acetone, gasoline and other active solvents
to clean the Button.
The pre-installed battery provides up to 5 years of key fob operation in normal use
(one press per day). More frequent use may reduce battery life. You can check battery
l l t ti i th Aj
18/10/2019 Button User Manual - Ajax Support
https://support.ajax.systems/en/manuals/button/?_ga=2.98140895.1985800128.1571327333-1921628607.1570693416 10/12
level at any time in the Ajax app.
The pre-installed battery is sensitive to low temperatures and if the key fob is cooled
signicantly, the battery level indicator in the app may show incorrect values until the
key fob becomes warmer.
The battery level value is not updated on a regular basis, but only updates after
pressing the button.
When the battery has run down, the user will receive a notication in the Ajax app, and
the LED will steadily light up red and go out each time the button is pressed.
Technical Specications
Number of buttons 1
LED backlight indicating command delivery Available
Protection against accidental activation Available
Frequency band 868.0 – 868.6 MHz or 868.7 – 869.2 MHz,
depending on the sales region
Compatibility Operates with , , ,
featuring OS Malevich 2.7.102 and later
Maximum radio signal power Up to 20 mW
Radio signal modulation GFSK
Radio signal range Up to 1,300 m (without obstacles)
Power supply 1 CR2032 battery, 3 V
Battery life Up to 5 years (depending on frequency of use)
Protection class IP54
Operating temperature range From -10°С to +40°С
Operating humidity Up to 75%
Dimensions 47 х 35 х 13 mm
Battery Replacement
Hub Hub Plus Hub 2 ReX
18/10/2019 Button User Manual - Ajax Support
https://support.ajax.systems/en/manuals/button/?_ga=2.98140895.1985800128.1571327333-1921628607.1570693416 11/12
e s o s 35 3
Weight 16 g
Complete Set
Warranty
The warranty for the products manufactured by the AJAX SYSTEMS
MANUFACTURING limited liability company is valid for 2 years after purchase and
does not extend to the bundled battery.
If the device does not function properly, we recommend that you rst contact the
support service as technical issues can be resolved remotely in half of the cases!
Technical support:
Button1.
Pre-installed CR2032 battery2.
Double-sided tape3.
Quick Start Guide4.
