Akai AMD20 User manual
Microset: Radio / DVD-player
with USB-port and Cardreader
GB 2
NL 29
FR 57
ES 85
DE 113
EL 144
User manual
Gebruiksaanwijzing
Manuel de l’utilisateur
Manual de instrucciones
Gebrauchsanleitung
Οδηγίες χρήσεως
AMD20
3
AMD20
Table of contents
Copyright notice
Design and specications are subject to change without notice.
1. Safety........................................................................... 3
1.1 Intended use ....................................................................3
1.2 Labels in this manual .......................................................3
1.3 General safety instructions ..............................................4
2. Preparations for use................................................... 4
2.1 Unpacking ........................................................................4
2.2 Package contents ............................................................5
3. Installation................................................................... 5
3.1 Installing the speakers .....................................................6
3.2 Connecting random equipment ........................................7
3.3 Remote control.................................................................9
4. Functions................................................................... 10
4.1 DVD Micro System.........................................................10
4.2 Remote control...............................................................11
5. Operation................................................................... 13
5.1 Master power switch ......................................................13
5.2 Quick start ......................................................................13
5.3 DVD/CD functions ..........................................................15
5.4 Radio functions ..............................................................18
5.5 USB functions ................................................................18
5.6 SD/MMC functions .........................................................19
5.7 General setup menu operation ......................................19
6. Cleaning and maintenance ...................................... 23
6.1 Handle and care of a disc ..............................................23
7. Troubleshooting........................................................ 24
8. Technical data........................................................... 26
9. Disposal of used electrical and electronic
equipment.................................................................. 28
Safety1.
Intended use1.1
The DVD Micro System plays music from CDs and music, videos and photos
from DVDs and USB. The appliance also plays photos from Kodak picture
CDs. Read the manual carefully before the rst use.
i Due to the great variety of products with external memory
connection (USB, SD/MMC, etc.) and their sometimes quite
manufacturer-specic functions we can neither guarantee that all
devices will be recognised, nor that all operating options that are
possible in theory will actually work.
2 DVDs and DVD appliances are manufactured under the worldwide
agreed DVD regional code system that the appliance will operate
only with corresponding disc of the same regional code. If the code
number on the label of a DVD does not match that on the label
alongside, the DVD will not play on this appliance.
i The appliance has built in copyright protection technology that
prevents copying from a disc to any media. If a video recorder is
connected to the appliance, the video output image will be distorted
during recording.
D Manufactured under license from Dolby Laboratories. "Dolby" and
the double-D symbol are trademarks of Dolby Laboratories.
Condential unpublished works. Copyright 1992-1997 Dolby
Laboratories. All rights reserved.
Labels in this manual1.2
! WARNING
A warning means that injury or death is possible if the instructions
are not obeyed.
! CAUTION
A caution means that damage to the equipment is possible.
3
AMD20
Table of contents
Copyright notice
Design and specications are subject to change without notice.
1. Safety........................................................................... 3
1.1 Intended use ....................................................................3
1.2 Labels in this manual .......................................................3
1.3 General safety instructions ..............................................4
2. Preparations for use................................................... 4
2.1 Unpacking ........................................................................4
2.2 Package contents ............................................................5
3. Installation................................................................... 5
3.1 Installing the speakers .....................................................6
3.2 Connecting random equipment ........................................7
3.3 Remote control.................................................................9
4. Functions................................................................... 10
4.1 DVD Micro System.........................................................10
4.2 Remote control...............................................................11
5. Operation................................................................... 13
5.1 Master power switch ......................................................13
5.2 Quick start ......................................................................13
5.3 DVD/CD functions ..........................................................15
5.4 Radio functions ..............................................................18
5.5 USB functions ................................................................18
5.6 SD/MMC functions .........................................................19
5.7 General setup menu operation ......................................19
6. Cleaning and maintenance ...................................... 23
6.1 Handle and care of a disc ..............................................23
7. Troubleshooting........................................................ 24
8. Technical data........................................................... 26
9. Disposal of used electrical and electronic
equipment.................................................................. 28
Safety1.
Intended use1.1
The DVD Micro System plays music from CDs and music, videos and photos
from DVDs and USB. The appliance also plays photos from Kodak picture
CDs. Read the manual carefully before the rst use.
i Due to the great variety of products with external memory
connection (USB, SD/MMC, etc.) and their sometimes quite
manufacturer-specic functions we can neither guarantee that all
devices will be recognised, nor that all operating options that are
possible in theory will actually work.
2 DVDs and DVD appliances are manufactured under the worldwide
agreed DVD regional code system that the appliance will operate
only with corresponding disc of the same regional code. If the code
number on the label of a DVD does not match that on the label
alongside, the DVD will not play on this appliance.
i The appliance has built in copyright protection technology that
prevents copying from a disc to any media. If a video recorder is
connected to the appliance, the video output image will be distorted
during recording.
D Manufactured under license from Dolby Laboratories. "Dolby" and
the double-D symbol are trademarks of Dolby Laboratories.
Condential unpublished works. Copyright 1992-1997 Dolby
Laboratories. All rights reserved.
Labels in this manual1.2
! WARNING
A warning means that injury or death is possible if the instructions
are not obeyed.
! CAUTION
A caution means that damage to the equipment is possible.
4
5
AMD20
i A note gives additional information, e.g. for a procedure.
General safety instructions1.3
! WARNING
Do not put force on the appliance. The appliance can fall and can
cause serious injury.
! CAUTION
Do not spill any liquid on the appliance.
! WARNING
Do not insert any objects in the ventilation holes.
! CAUTION
Do not block the ventilation holes.
i This appliance is double insulated; therefore no earth wire is
required. Always check that the mains voltage corresponds to the
voltage on the rating plate.
L This appliance employs a laser system. To prevent direct exposure
to the laser beam, do not open the appliance. Visible laser
radiation when open and interlock defeated.
Preparations for use2.
Unpacking2.1
● Unpack the appliance carefully.
● Check the package contents as described below. If any item is missing,
please contact your reseller.
● Remove the labels from the front panel carefully if present.
i We recommend that you retain the original carton and packing
materials in case it ever becomes necessary to return your product
for service. This is the only way to safely protect the product
against damage in transit. If you do dispose of the carton and the
packing materials, please remember to recycle with due care to the
environment.
Package contents2.2
The following items are included in the received package:
1 DVD Micro System
2 Speakers
2 Pair of speaker wire
1 Remote control
2 Batteries (AAA)
1 RCA cable
1 Operator manual
i If any item is missing, please contact your reseller.
Installation3.
● Put the appliance on a horizontal at surface.
● Connect the speakers to the appliance. Read the paragraph
"Installing the speakers".
● Connect the random equipment to the appliance. Read the paragraph
"Connecting random equipment".
● Connect the appliance to the mains.
● Install the batteries in the remote control. Read the paragraph
"Remote control".
!
CAUTION
● Do not put the appliance near a heat source.
● Do not expose the appliance to direct sunlight.
4
5
AMD20
i A note gives additional information, e.g. for a procedure.
General safety instructions1.3
! WARNING
Do not put force on the appliance. The appliance can fall and can
cause serious injury.
! CAUTION
Do not spill any liquid on the appliance.
! WARNING
Do not insert any objects in the ventilation holes.
! CAUTION
Do not block the ventilation holes.
i This appliance is double insulated; therefore no earth wire is
required. Always check that the mains voltage corresponds to the
voltage on the rating plate.
L This appliance employs a laser system. To prevent direct exposure
to the laser beam, do not open the appliance. Visible laser
radiation when open and interlock defeated.
Preparations for use2.
Unpacking2.1
● Unpack the appliance carefully.
● Check the package contents as described below. If any item is missing,
please contact your reseller.
● Remove the labels from the front panel carefully if present.
i We recommend that you retain the original carton and packing
materials in case it ever becomes necessary to return your product
for service. This is the only way to safely protect the product
against damage in transit. If you do dispose of the carton and the
packing materials, please remember to recycle with due care to the
environment.
Package contents2.2
The following items are included in the received package:
1 DVD Micro System
2 Speakers
2 Pair of speaker wire
1 Remote control
2 Batteries (AAA)
1 RCA cable
1 Operator manual
i If any item is missing, please contact your reseller.
Installation3.
● Put the appliance on a horizontal at surface.
● Connect the speakers to the appliance. Read the paragraph
"Installing the speakers".
● Connect the random equipment to the appliance. Read the paragraph
"Connecting random equipment".
● Connect the appliance to the mains.
● Install the batteries in the remote control. Read the paragraph
"Remote control".
!
CAUTION
● Do not put the appliance near a heat source.
● Do not expose the appliance to direct sunlight.
6
7
AMD20
i This appliance is equipped with rubber feet to prevent it from
moving. The feet are made from non-migrating material specially
formulated to avoid leaving any marks or stains on furniture.
However, certain types of furniture polishes, wood preservatives or
cleaning sprays cause the rubber to soften and leave marks or a
residue on the furniture, and potentially risk the surface to become
damaged. To prevent damage to wooden surfaces, we recommend
that you apply self-adhesive pads to the bottom of the rubber feet
before installation.
Installing the speakers3.1
6~16 ohm
LINE INPUT
The cables and terminals are colour-coded:
- Red wires connect to red terminals (+).
- Black wires connect to black terminals (-).
● Place the speakers on a horizontal at surface. Place the speakers close
enough to the appliance to be able to connect the wires.
● Connect the wires as described below.
Connection to speakers
● Press the latches to open the terminals. Keep the latches depressed.
● Connect the wire ends to the speakers matching the (+) and (-) polarity
markings.
● Release the latches to lock the wire ends.
Connection to the appliance
● Press the latches to open the terminals.
● Connect the wire ends of the speakers to the appliance matching the (+)
and (-) polarity markings.
● Lift the latches to lock the wire ends.
Connecting random equipment3.2
6~16 ohm
LINE INPUT
The appliance includes various options for permanent connection of random
equipment. Suitable cables can be purchased at your reseller.
6
7
AMD20
i This appliance is equipped with rubber feet to prevent it from
moving. The feet are made from non-migrating material specially
formulated to avoid leaving any marks or stains on furniture.
However, certain types of furniture polishes, wood preservatives or
cleaning sprays cause the rubber to soften and leave marks or a
residue on the furniture, and potentially risk the surface to become
damaged. To prevent damage to wooden surfaces, we recommend
that you apply self-adhesive pads to the bottom of the rubber feet
before installation.
Installing the speakers3.1
6~16 ohm
LINE INPUT
The cables and terminals are colour-coded:
- Red wires connect to red terminals (+).
- Black wires connect to black terminals (-).
● Place the speakers on a horizontal at surface. Place the speakers close
enough to the appliance to be able to connect the wires.
● Connect the wires as described below.
Connection to speakers
● Press the latches to open the terminals. Keep the latches depressed.
● Connect the wire ends to the speakers matching the (+) and (-) polarity
markings.
● Release the latches to lock the wire ends.
Connection to the appliance
● Press the latches to open the terminals.
● Connect the wire ends of the speakers to the appliance matching the (+)
and (-) polarity markings.
● Lift the latches to lock the wire ends.
Connecting random equipment3.2
6~16 ohm
LINE INPUT
The appliance includes various options for permanent connection of random
equipment. Suitable cables can be purchased at your reseller.
8
9
AMD20
Audio connections (input)
● Stereo audio: Connect a suitable cable to the R/L channels of the LINE IN
connection.
Audio connections (output)
The appliance has the following audio outputs:
● Stereo audio: Connect a suitable cable to the R/L channels of the AUDIO
OUT connection.
● Coaxial digital audio: Insert a suitable cable into the COAXIAL AUDIO
OUT connection.
Video connections
The video connections allow you to send to video signal (still images or
movies) to a connected TV.
The appliance has the following video outputs (in order of preference):
● Component: Connect a suitable cable to the Pr/Y/Pb channels of the
COMPONENT VIDEO OUT connection.
● SCART: Insert a suitable cable into the SCART OUT connection.
● S-Video: Insert a suitable cable into the S-VIDEO OUTPUT connection.
● Composite video: Insert a suitable cable into the VIDEO OUTPUT
connection.
i Do not make all connections simultaneously as this will affect the
output quality.
Cable connection
● Insert an FM aerial or a suitable cable into the RADIO ANTENNA
connection.
Remote control3.3
Install batteries
● Remove the battery cover.
● Insert the batteries matching the (+) and (-)
polarity markings.
● Re-install the battery cover.
! CAUTION Incorrect installation
can cause battery leakage and
corrosion which will damage the
appliance. Corrosion, oxidation,
battery leakage and any other
gradually acidic defect of this nature
will invalidate the guarantee.
8
9
AMD20
Audio connections (input)
● Stereo audio: Connect a suitable cable to the R/L channels of the LINE IN
connection.
Audio connections (output)
The appliance has the following audio outputs:
● Stereo audio: Connect a suitable cable to the R/L channels of the AUDIO
OUT connection.
● Coaxial digital audio: Insert a suitable cable into the COAXIAL AUDIO
OUT connection.
Video connections
The video connections allow you to send to video signal (still images or
movies) to a connected TV.
The appliance has the following video outputs (in order of preference):
● Component: Connect a suitable cable to the Pr/Y/Pb channels of the
COMPONENT VIDEO OUT connection.
● SCART: Insert a suitable cable into the SCART OUT connection.
● S-Video: Insert a suitable cable into the S-VIDEO OUTPUT connection.
● Composite video: Insert a suitable cable into the VIDEO OUTPUT
connection.
i Do not make all connections simultaneously as this will affect the
output quality.
Cable connection
● Insert an FM aerial or a suitable cable into the RADIO ANTENNA
connection.
Remote control3.3
Install batteries
● Remove the battery cover.
● Insert the batteries matching the (+) and (-)
polarity markings.
● Re-install the battery cover.
! CAUTION Incorrect installation
can cause battery leakage and
corrosion which will damage the
appliance. Corrosion, oxidation,
battery leakage and any other
gradually acidic defect of this nature
will invalidate the guarantee.
10 11
AMD20
11
AMD20
Functions4.
DVD Micro System4.1
12
9
13
11
10
8
1 2 3 5 6 74
Front panel
1 Standby button
2 Display
3 Disc tray
4 Remote sensor
5 Headphone jack
6 USB slot
7 Memory card slot
8 Cover for connection of external devices
9 Previous track/chapter button
10 Next track/chapter button
11 Volume dial
12 Play/Pause button
13 Open/close button
Back panel
14 Master power switch
Remote control4.2
General functions
15 Standby button
16 Digit buttons (0-10+)
17 SETUP button
18 VOLUME +/- button
19 Arrow buttons
20 SOUND EFFECT button (S.EFFECT)
21 USB button
22 TONE button
23 CHANNEL LEVEL button (CH-LEVEL)
24 ENTER button
25 SOURCE SELECT button
26 VIDEO OUTPUT MODE button
(V-MODE)
27 MUTE button
6~16 ohm
LINE INPUT
14
16
23
18
27
26
25
24
22
15
17
20
21
19
10 11
AMD20
11
AMD20
Functions4.
DVD Micro System4.1
12
9
13
11
10
8
1 2 3 5 6 74
Front panel
1 Standby button
2 Display
3 Disc tray
4 Remote sensor
5 Headphone jack
6 USB slot
7 Memory card slot
8 Cover for connection of external devices
9 Previous track/chapter button
10 Next track/chapter button
11 Volume dial
12 Play/Pause button
13 Open/close button
Back panel
14 Master power switch
Remote control4.2
General functions
15 Standby button
16 Digit buttons (0-10+)
17 SETUP button
18 VOLUME +/- button
19 Arrow buttons
20 SOUND EFFECT button (S.EFFECT)
21 USB button
22 TONE button
23 CHANNEL LEVEL button (CH-LEVEL)
24 ENTER button
25 SOURCE SELECT button
26 VIDEO OUTPUT MODE button
(V-MODE)
27 MUTE button
6~16 ohm
LINE INPUT
14
16
23
18
27
26
25
24
22
15
17
20
21
19
12
13
AMD20
DVD functions
28 GO TO button
29 PLAYBACK CONTROL button (PBC)
30 PROGRAM button (PROG)
31 FWD button
32 REV button
33 TITLE button
34 AUDIO button
35 STEP button
36 A-B REPEAT button
37 REPEAT button
38 STOP button
39 ZOOM button
40 MENU button
41 SUBTITLE/AUTO button
42 PREV button
43 NEXT button
44 On Screen Display button (OSD)
45 ANGLE button
46 PLAY/PAUSE button
47 OPEN/CLOSE button
Tuner functions
48 SEARCH + button
49 SEARCH - button
50 MEMORY button
51 STOP button
52 MO/ST button
53 AUTO button
54 RADIO + button
55 RADIO - button
36
35
46
47
45
44
41
42
43
38
39
40
28
29
30
31
32
33
37
34
48
49
52
53
54
55
51
50
Operation5.
All functions of the appliance are accessible using the remote control.
All instructions refer to operation with the remote control, unless indicated
otherwise.
Master power switch5.1
The appliance is equipped with a master power switch (14) located at the
back panel.
● Set the switch into the ON position prior to taking the appliance into
operation.
● Set the switch into the OFF position prior to disconnecting from the mains.
i
● The appliance is designed to be operated using the remote control.
For regular use you may nd it convenient to switch the appliance to
standby mode after use. However, if you wish to care for the environment
and not waste energy by leaving the appliance in standby mode, you can
also switch off at the master power switch.
● When the appliance is not in use for longer period, we recommend to
switch the appliance off at the master power switch.
Quick start5.2
General functions
● Check that the master power (14) switch is in the ON position.
● To switch on the appliance, press the STANDBY button (15). To switch off
the appliance, press the STANDBY button (15) again.
● To select the source mode (DVD/TUNER/LINE), press the SOURCE
SELECT button (25).
● To select an extra signal source (USB/MEMORY CARD), press the USB
button (21). Press the button once again to exit this function.
● To adjust the volume, press the VOL + button or the VOL - button (18).
● To adjust the volume of each speaker separately, press the CH-LEVEL
button (23). Then press the VOL + button or the VOL - button (18).
12
13
AMD20
DVD functions
28 GO TO button
29 PLAYBACK CONTROL button (PBC)
30 PROGRAM button (PROG)
31 FWD button
32 REV button
33 TITLE button
34 AUDIO button
35 STEP button
36 A-B REPEAT button
37 REPEAT button
38 STOP button
39 ZOOM button
40 MENU button
41 SUBTITLE/AUTO button
42 PREV button
43 NEXT button
44 On Screen Display button (OSD)
45 ANGLE button
46 PLAY/PAUSE button
47 OPEN/CLOSE button
Tuner functions
48 SEARCH + button
49 SEARCH - button
50 MEMORY button
51 STOP button
52 MO/ST button
53 AUTO button
54 RADIO + button
55 RADIO - button
36
35
46
47
45
44
41
42
43
38
39
40
28
29
30
31
32
33
37
34
48
49
52
53
54
55
51
50
Operation5.
All functions of the appliance are accessible using the remote control.
All instructions refer to operation with the remote control, unless indicated
otherwise.
Master power switch5.1
The appliance is equipped with a master power switch (14) located at the
back panel.
● Set the switch into the ON position prior to taking the appliance into
operation.
● Set the switch into the OFF position prior to disconnecting from the mains.
i
● The appliance is designed to be operated using the remote control.
For regular use you may nd it convenient to switch the appliance to
standby mode after use. However, if you wish to care for the environment
and not waste energy by leaving the appliance in standby mode, you can
also switch off at the master power switch.
● When the appliance is not in use for longer period, we recommend to
switch the appliance off at the master power switch.
Quick start5.2
General functions
● Check that the master power (14) switch is in the ON position.
● To switch on the appliance, press the STANDBY button (15). To switch off
the appliance, press the STANDBY button (15) again.
● To select the source mode (DVD/TUNER/LINE), press the SOURCE
SELECT button (25).
● To select an extra signal source (USB/MEMORY CARD), press the USB
button (21). Press the button once again to exit this function.
● To adjust the volume, press the VOL + button or the VOL - button (18).
● To adjust the volume of each speaker separately, press the CH-LEVEL
button (23). Then press the VOL + button or the VOL - button (18).
14
15
AMD20
● To select the tone (bass/treble), press the TONE button (22). To adjust the
tone, press the VOL + button or the VOL - button (18).
● To switch between sound effects (concert/living/hall/bath/cave/arena/
church), press the S.EFFECT button (20). Press the button once again to
exit this function.
● To mute or restore sound, press the MUTE button (27).
● To connect a headphone, insert the cable plug in the headphone jack (5).
To prevent hearing damage, remember to adjust the volume to a
comfortable level.
DVD/CD functions
● Switch on the appliance. Select the DVD mode.
● Place a disc in the disc tray. To open or close the disc tray, press the
OPEN/CLOSE button (47).
The display shows the total number of tracks on the CD.
● To start playback, press the PLAY/PAUSE button (46) once.
● For extended instructions, read the paragraph "DVD/CD functions" further
on in this manual.
Radio functions
● Switch on the appliance. Select the tuner mode.
● To tune to the station of your choice, press the SEARCH + button (48) or
the SEARCH - button (49) repeatedly until the frequency is found.
● For extended instructions, read the paragraph "Radio functions" further on
in this manual.
USB functions
● Switch on the appliance.
● Insert the USB device in the slot (6). The device can only be connected
one way.
● Select the DVD mode. Then select the correct function with the USB
button (21).
● To start playback, press the PLAY/PAUSE button (46) once.
● For extended instructions, read the paragraph "USB functions" further on
in this manual.
SD/MMC functions
● Switch on the appliance.
● Insert the SD/MMC device in the slot (7). The device can only be
connected one way.
● Select the DVD mode. Then select the correct function with the
USB button (21).
● To start playback, press the PLAY/PAUSE button (46) once.
● For extended instructions, read the paragraph "SD/MMC functions" further
on in this manual.
DVD/CD functions5.3
After the disc has been loaded, a content menu will display on the TV screen.
● Press the arrow buttons (19) to select a menu item.
● Press ENTER to enter the selected menu item.
During playback, the following functions are available:
● To select a chapter (DVD) or track (CD), press the digit buttons (16).
● To select the next or previous chapter (DVD) or track (CD), press the
PREV button (42) or the NEXT button (43).
● To forward or rewind the DVD, press the FWD button (31) or the REV
button (32). The available speed rates are: 2x, 4x, 8x, 16x, 32x.
● To pause playback, press the PLAY/PAUSE button (46) once; to resume
playback, press the button again.
● To stop playback temporarily, press the STOP button (38) once. Press the
button again to stop playback permanently, or press the PLAY/PAUSE
button (46) to resume playback.
● To repeat a chapter (DVD) or one or all tracks (CD):
Press the REPEAT button (37) once to repeat the current chapter or -
track.
Press the button once again (2x) to repeat the current title. -
Press the button once again (3x) to repeat all chapters or tracks. -
Press the button once again (4x) to cancel the function. -
● To play the DVD frame by frame, press the STEP button (35).
Press the PLAY/PAUSE button (46) to resume normal playback.
● To view a specic title of a DVD, press the TITLE button (33).
Use the arrow buttons to select the title.
● To select the audio language of a DVD, press the AUDIO button (34)
repeatedly until the desired language is set.
● To switch on the subtitles of a DVD, press the SUBTITLE button (41).
Press the button again to switch off the subtitles.
● To select extra information of a DVD or CD (remaining time/passed
playtime/track number/chapter number), press the OSD button (44).
● To select the camera angle, press the ANGLE button (45).
14
15
AMD20
● To select the tone (bass/treble), press the TONE button (22). To adjust the
tone, press the VOL + button or the VOL - button (18).
● To switch between sound effects (concert/living/hall/bath/cave/arena/
church), press the S.EFFECT button (20). Press the button once again to
exit this function.
● To mute or restore sound, press the MUTE button (27).
● To connect a headphone, insert the cable plug in the headphone jack (5).
To prevent hearing damage, remember to adjust the volume to a
comfortable level.
DVD/CD functions
● Switch on the appliance. Select the DVD mode.
● Place a disc in the disc tray. To open or close the disc tray, press the
OPEN/CLOSE button (47).
The display shows the total number of tracks on the CD.
● To start playback, press the PLAY/PAUSE button (46) once.
● For extended instructions, read the paragraph "DVD/CD functions" further
on in this manual.
Radio functions
● Switch on the appliance. Select the tuner mode.
● To tune to the station of your choice, press the SEARCH + button (48) or
the SEARCH - button (49) repeatedly until the frequency is found.
● For extended instructions, read the paragraph "Radio functions" further on
in this manual.
USB functions
● Switch on the appliance.
● Insert the USB device in the slot (6). The device can only be connected
one way.
● Select the DVD mode. Then select the correct function with the USB
button (21).
● To start playback, press the PLAY/PAUSE button (46) once.
● For extended instructions, read the paragraph "USB functions" further on
in this manual.
SD/MMC functions
● Switch on the appliance.
● Insert the SD/MMC device in the slot (7). The device can only be
connected one way.
● Select the DVD mode. Then select the correct function with the
USB button (21).
● To start playback, press the PLAY/PAUSE button (46) once.
● For extended instructions, read the paragraph "SD/MMC functions" further
on in this manual.
DVD/CD functions5.3
After the disc has been loaded, a content menu will display on the TV screen.
● Press the arrow buttons (19) to select a menu item.
● Press ENTER to enter the selected menu item.
During playback, the following functions are available:
● To select a chapter (DVD) or track (CD), press the digit buttons (16).
● To select the next or previous chapter (DVD) or track (CD), press the
PREV button (42) or the NEXT button (43).
● To forward or rewind the DVD, press the FWD button (31) or the REV
button (32). The available speed rates are: 2x, 4x, 8x, 16x, 32x.
● To pause playback, press the PLAY/PAUSE button (46) once; to resume
playback, press the button again.
● To stop playback temporarily, press the STOP button (38) once. Press the
button again to stop playback permanently, or press the PLAY/PAUSE
button (46) to resume playback.
● To repeat a chapter (DVD) or one or all tracks (CD):
Press the REPEAT button (37) once to repeat the current chapter or -
track.
Press the button once again (2x) to repeat the current title. -
Press the button once again (3x) to repeat all chapters or tracks. -
Press the button once again (4x) to cancel the function. -
● To play the DVD frame by frame, press the STEP button (35).
Press the PLAY/PAUSE button (46) to resume normal playback.
● To view a specic title of a DVD, press the TITLE button (33).
Use the arrow buttons to select the title.
● To select the audio language of a DVD, press the AUDIO button (34)
repeatedly until the desired language is set.
● To switch on the subtitles of a DVD, press the SUBTITLE button (41).
Press the button again to switch off the subtitles.
● To select extra information of a DVD or CD (remaining time/passed
playtime/track number/chapter number), press the OSD button (44).
● To select the camera angle, press the ANGLE button (45).
16
17
AMD20
i
● Normally, if an MP3 disc is loaded, the unit will take longer time to read
the initial data.
● A DVD that does not match the region code cannot be read by this
appliance.
● If a disc contains mixed content (e.g. MP3 and video les), the appliance
will only recognise, list and play one content type.
● The screen saver becomes active if no disc has been loaded for
3 minutes, or if the appliance has been in STOP mode for 3 minutes.
Using the GO TO function
The GO TO function can be used to select a specic starting point on a DVD
or CD.
● Press the GO TO button (28).
● Press the arrow buttons to select an entry.
The possible entries for DVD are:
- Disc time
- Chapter
- Title
- Chapter time
- Title time
The possible entries for CD are:
- Track time
- Specic track
● Press the digit buttons to set a selection.
Using the PROGRAM function
● Press the PROG button (30) to enter the PROGRAM function.
● Press the digit buttons to select a desired track, and use the arrow button
down to highlight the next entry.
● To conrm the selection and start the program, move the highlight to
"START" and press the ENTER button.
● To stop the progam, press the PROG button (30) and press ENTER.
Using the A-B REPEAT function
The A-B REPEAT function can be used to repeat a specic section of a DVD.
● Press the A-B REPEAT button (36) once to select the starting point (A).
● Press the A-B REPEAT button again to select the ending point (B).
The appliance plays the section repeatedly.
● To cancel the A-B REPEAT function, press the A-B REPEAT button again.
The appliance will resume the normal playback.
Using the ZOOM function
This function can be used for zooming in and out on photos and DVDs.
The available zoom ratios are: 2x, 3x, 4x, 1/2, 1/3, 1/4.
● Press the ZOOM button (39).
● Press the ZOOM button again to set the correct size.
● Press the arrow buttons to move through the picture.
Using the MP3/MPEG4 playback function
● Insert an MP3/MPEG4 disc. A content menu will display on the TV screen.
● Press the up/down arrow buttons (19) to select a folder or a le.
● Press the ENTER button (24) to enter the selected folder or le.
● Press the PROG button (30) to switch between folders and les.
Press ENTER to conrm.
Using the Kodak picture CD playback function
● Insert a Kodak picture CD.
● Press the STOP (38) button to enter the thumbnail mode. Choose an
option (Slide show/Menu/prev-next) and press ENTER (24).
● Press the PROG button (30) to change the mode. Press ENTER (24) to
conrm.
● Press the PLAY/PAUSE button (46) to hold the slide show at the current
picture.
● Press the PREV button (42) or the NEXT button (43) to select the
previous or next picture.
● Press the PLAY/PAUSE button (46) to resume the slide show.
● To magnify the picture, press the ZOOM button (39). To zoom in or out on
the picture, press the FastForward button (31) or FastRewind button (32).
To move the picture, press the arrow buttons (19).
● To ip the image vertical or horizontal, press the up/down arrow buttons (19).
● To rotate the image left or right, press the left/right arrow buttons (19).
i The slide show is paused in the zoom mode. The image rotation
and wipe effect functions are not available in the zoom mode.
16
17
AMD20
i
● Normally, if an MP3 disc is loaded, the unit will take longer time to read
the initial data.
● A DVD that does not match the region code cannot be read by this
appliance.
● If a disc contains mixed content (e.g. MP3 and video les), the appliance
will only recognise, list and play one content type.
● The screen saver becomes active if no disc has been loaded for
3 minutes, or if the appliance has been in STOP mode for 3 minutes.
Using the GO TO function
The GO TO function can be used to select a specic starting point on a DVD
or CD.
● Press the GO TO button (28).
● Press the arrow buttons to select an entry.
The possible entries for DVD are:
- Disc time
- Chapter
- Title
- Chapter time
- Title time
The possible entries for CD are:
- Track time
- Specic track
● Press the digit buttons to set a selection.
Using the PROGRAM function
● Press the PROG button (30) to enter the PROGRAM function.
● Press the digit buttons to select a desired track, and use the arrow button
down to highlight the next entry.
● To conrm the selection and start the program, move the highlight to
"START" and press the ENTER button.
● To stop the progam, press the PROG button (30) and press ENTER.
Using the A-B REPEAT function
The A-B REPEAT function can be used to repeat a specic section of a DVD.
● Press the A-B REPEAT button (36) once to select the starting point (A).
● Press the A-B REPEAT button again to select the ending point (B).
The appliance plays the section repeatedly.
● To cancel the A-B REPEAT function, press the A-B REPEAT button again.
The appliance will resume the normal playback.
Using the ZOOM function
This function can be used for zooming in and out on photos and DVDs.
The available zoom ratios are: 2x, 3x, 4x, 1/2, 1/3, 1/4.
● Press the ZOOM button (39).
● Press the ZOOM button again to set the correct size.
● Press the arrow buttons to move through the picture.
Using the MP3/MPEG4 playback function
● Insert an MP3/MPEG4 disc. A content menu will display on the TV screen.
● Press the up/down arrow buttons (19) to select a folder or a le.
● Press the ENTER button (24) to enter the selected folder or le.
● Press the PROG button (30) to switch between folders and les.
Press ENTER to conrm.
Using the Kodak picture CD playback function
● Insert a Kodak picture CD.
● Press the STOP (38) button to enter the thumbnail mode. Choose an
option (Slide show/Menu/prev-next) and press ENTER (24).
● Press the PROG button (30) to change the mode. Press ENTER (24) to
conrm.
● Press the PLAY/PAUSE button (46) to hold the slide show at the current
picture.
● Press the PREV button (42) or the NEXT button (43) to select the
previous or next picture.
● Press the PLAY/PAUSE button (46) to resume the slide show.
● To magnify the picture, press the ZOOM button (39). To zoom in or out on
the picture, press the FastForward button (31) or FastRewind button (32).
To move the picture, press the arrow buttons (19).
● To ip the image vertical or horizontal, press the up/down arrow buttons (19).
● To rotate the image left or right, press the left/right arrow buttons (19).
i The slide show is paused in the zoom mode. The image rotation
and wipe effect functions are not available in the zoom mode.
18
19
AMD20
Using the Video CD playback function
● Press the PBC button (29) to switch on the playback function.
● Insert a Video CD.
● To start playback, press the PLAY/PAUSE button (46) once.
● Press the PBC button (29) to quit the playback and return to the main
menu.
Radio functions5.4
● To search for frequencies automatically, press the AUTO button (53).
● To ne tune the frequency, press the SEARCH + button (48) or the
SEARCH - button (49).
● To select a preset station, press the digit buttons (16).
● To skip to the next preset station, press the RADIO - button (54) or the
RADIO + button (55).
● To stop the automatic search for frequencies, press the STOP button (51).
● To switch between Mono and Stereo reception, press the MO/ST button (52).
Using the MEMORY function
This function is used to set a frequency as a preferred station.
● Press the MEMORY button (50).
● Search for the desired frequency with the SEARCH + button (48) or the
SEARCH - button (49).
● Press the MEMORY button when the desired frequency is found.
● Select the desired preset number (1-40) with the digit buttons to save the
frequency as a preset station.
● Press MEMORY again to conrm the selection.
USB functions5.5
After the device has been connected, a content menu will display on the TV
screen.
● Press the up/down arrow buttons (19) to select a folder or a le.
● Press the ENTER button (24) to enter the selected folder or le. You can
also use the digit buttons (16) to select a folder or to play the le.
● Press the PROG button (30) to switch between folders and les.
Press ENTER (24) to conrm.
● Press the MENU button (40) to return to the content menu during playback.
During playback, the following functions are available:
● To select a track, press the PREV button (42) or the NEXT button (43)
until the desired track is set.
● To pause playback, press the PLAY/PAUSE button (46) once; to resume
playback, press the button again.
● To stop playback, press the STOP button (38).
● To remove the device, gently pull it out of the slot.
i Due to the great variety of products with USB ports and their
sometimes quite manufacturer-specic functions we can neither
guarantee that all devices will be recognised, nor that all operating
options that are possible in theory will actually work.
SD/MMC functions5.6
After the device has been connected, a content menu will display on the
TV screen.
● Press the up/down arrow buttons (19) to select a folder or a le.
● Press the ENTER button (24) to enter the selected folder or le.
You can also use the digit buttons (16) to select a folder or to play the le.
● Press the PROG button (30) to switch between folders and les.
Press ENTER (24) to conrm.
● Press the MENU button (40) to return to the content menu during playback.
During playback, the following functions are available:
● To select a track, press the PREV button (42) or the NEXT button (43)
until the desired track is set.
● To pause playback, press the PLAY/PAUSE button (46) once;
to resume playback, press the button again.
● To stop playback, press the STOP button (38).
● To remove the device, gently pull it out of the slot.
General setup menu operation5.7
This chapter explains a complete setup of the appliance: settings of screen
display, audio setup and video setup.
To change the initial settings
The following actions have to be carried out with the remote control.
18
19
AMD20
Using the Video CD playback function
● Press the PBC button (29) to switch on the playback function.
● Insert a Video CD.
● To start playback, press the PLAY/PAUSE button (46) once.
● Press the PBC button (29) to quit the playback and return to the main
menu.
Radio functions5.4
● To search for frequencies automatically, press the AUTO button (53).
● To ne tune the frequency, press the SEARCH + button (48) or the
SEARCH - button (49).
● To select a preset station, press the digit buttons (16).
● To skip to the next preset station, press the RADIO - button (54) or the
RADIO + button (55).
● To stop the automatic search for frequencies, press the STOP button (51).
● To switch between Mono and Stereo reception, press the MO/ST button (52).
Using the MEMORY function
This function is used to set a frequency as a preferred station.
● Press the MEMORY button (50).
● Search for the desired frequency with the SEARCH + button (48) or the
SEARCH - button (49).
● Press the MEMORY button when the desired frequency is found.
● Select the desired preset number (1-40) with the digit buttons to save the
frequency as a preset station.
● Press MEMORY again to conrm the selection.
USB functions5.5
After the device has been connected, a content menu will display on the TV
screen.
● Press the up/down arrow buttons (19) to select a folder or a le.
● Press the ENTER button (24) to enter the selected folder or le. You can
also use the digit buttons (16) to select a folder or to play the le.
● Press the PROG button (30) to switch between folders and les.
Press ENTER (24) to conrm.
● Press the MENU button (40) to return to the content menu during playback.
During playback, the following functions are available:
● To select a track, press the PREV button (42) or the NEXT button (43)
until the desired track is set.
● To pause playback, press the PLAY/PAUSE button (46) once; to resume
playback, press the button again.
● To stop playback, press the STOP button (38).
● To remove the device, gently pull it out of the slot.
i Due to the great variety of products with USB ports and their
sometimes quite manufacturer-specic functions we can neither
guarantee that all devices will be recognised, nor that all operating
options that are possible in theory will actually work.
SD/MMC functions5.6
After the device has been connected, a content menu will display on the
TV screen.
● Press the up/down arrow buttons (19) to select a folder or a le.
● Press the ENTER button (24) to enter the selected folder or le.
You can also use the digit buttons (16) to select a folder or to play the le.
● Press the PROG button (30) to switch between folders and les.
Press ENTER (24) to conrm.
● Press the MENU button (40) to return to the content menu during playback.
During playback, the following functions are available:
● To select a track, press the PREV button (42) or the NEXT button (43)
until the desired track is set.
● To pause playback, press the PLAY/PAUSE button (46) once;
to resume playback, press the button again.
● To stop playback, press the STOP button (38).
● To remove the device, gently pull it out of the slot.
General setup menu operation5.7
This chapter explains a complete setup of the appliance: settings of screen
display, audio setup and video setup.
To change the initial settings
The following actions have to be carried out with the remote control.
20
21
AMD20
● Press the SETUP button (17).
● Press the arrow buttons (left and right) (19) to select a menu.
The submenu is displayed directly.
● Press the arrow buttons (up and down) to enter the submenu.
● Press the ENTER button (24) to select a setting, or the left arrow button to
cancel the selection.
● Press the SETUP button to store the settings and exit.
General setup page
● In the TV DISPLAY section, press the arrow buttons to select 4:3
PANSCAN or 4:3 LETTERBOX for a conventional TV set. Select 16:9 or
WIDE SQUEEZE for a wide screen TV set.
● In the ANGLE MARK section, press the arrow buttons to switch this
function ON or OFF. When switched ON, the appliance shows the angle
mark when multi-camera angles are available.
● In the OSD LANG section, press the arrow buttons to choose the
language.
● In the CLOSED CAPTIONS section, press the arrow buttons to switch this
function ON or OFF. When switched ON, the appliance shows hidden text
when it is available.
● In the SCREEN SAVER section, press the arrow buttons to switch the
screen ON or OFF.
● In the LAST MEMORY section press the arrow buttons to switch this
function ON or OFF. When switched ON, the appliance remembers the
disc's last playback time.
Audio setup page
Analog audio setup
● DOWNMIX: Select LT/RT to mix 5.1-channel audio into left channel and
right channel. Select STEREO to mix 5.1 channel audio into signal stereo.
i This function is only available for Dolby AC-3 encoded 5.1-channel
discs.
Digital audio setup
DIGITAL OUTPUT
● Select SPDIF OFF to switch off the digital audio signal output.
● Select SPDIF RAW to set the digital audio signal output to its raw format
(DTS/Dolby Digital 5.1).
● Select SPDIF PCM to set the digital audio signal output to PCM format.
i When SPDIF PCM is set, the LPCM OUT feature sample rating for
the analog audio input (48 kHz or 96 kHz).
Dolby digital audio setup
DUAL MONO
● Stereo: both channels as is. STEREO is the default setting.
● L-Mono: left channel only.
● R-Mono: right channel only.
● Mix-Mono: the average of both the left and right channel.
i This function is only available for Dolby AC-3 encoded 2-channel
discs.
DYNAMIC
● Select the value for the dynamic range compression to avoid losing sound
details resulting from a low volume.
High Denition Compatible Digital (HDCD)
● Select the value (2x, 1x or OFF) for full sound richness of HDCD-encoded
CDs.
Video setup page
VIDEO OUTPUT
● OFF: Select S-Video mode of the S-Video connection.
● YUV: Set the video output in analog component video format.
● P_YUV: Set the video output in progressive YUV signals.
● RGB: Set the video output in RGB format when SCART output is used.
Other manuals for AMD20
1
Table of contents
Other Akai Stereo System manuals
