Akai LCT2765TD User manual

1
1. Safety Guidelines
Caution: Always use a power cable is properly grounded. Please use the AC cords
listed below for each area:
USA ...................... UL
Canada ................ CSA/cUL
FCC Information
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy, and if not installed
and used in accordance with the instructions, may cause harmful interference will not
occur in a particular installation. If this equipment does cause by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio / TV technician for help.
FCC Warning
To assure continued FCC compliance, the user must the provided grounded power
supply cord and the provided shielded video interface cables to connect to this
equipment. Also, any unauthorized changes or modifications to this equipment would
void the user’s authority to operate this device.
Labels
A. CLASSIFICATION LABEL B. WARNING LABEL
1. CLASS 1 LASER PRODUCT
2. CAUTION: Invisible laser radiation when open and interlock failed or defeated.
Avoid direct exposure to beam.
3. CAUTION: Do not open the top cover or remove screws. There are no user serviceable
parts inside the Unit; leave all servicing to qualified service personnel. Do not
insert any metallic object into the System.

2
Important Safeguards
Before using your TV, please read these instructions completely, and keep this manual
for future reference.
Carefully observe and comply with all warnings, cautions and instructions placed on the
unit or described in the operating instructions or service manual.
The User Manual uses the following symbols to ensure a safe operation and prevent
any damage to operators or properties:
WARNING----- Ignorance or inappropriate use may cause
damage to the product.
ATTENTION---Ignorance or inappropriate use may cause injury
to the user.
Prohibition
Warning (Attention) symbol (indicating “Electric Shock”).
Never place TV on an unstable cart, stand, or table. The TV may
fall, causing serious personal injury, death, or serious damage to
the TV.
Never overload wall outlets and extension cords.
Never allow anything to rest on or roll over the power cord, and never
place the TV where the power cord is subject to wear or abuse.
Keep the product away from moisture:
- Do not expose this appliance to rain or moisture.
- If water penetrates into the product, stop the operation; unplug
the connector and contact with your dealer. Continuous use in
this case may result in fire or electric shock.
Examples:
WARNING
Never place item such as vases, aquariums, or candles on top of
the TV.
WARNING

3
WARNING
Avoid using dropped or damaged appliances:
If the product is dropped and the housing is damaged, the internal
components may function abnormally. Unplug the connector
immediately and contact the manufacturer for repair. Continuous use
of the product may cause fire or electric shock.
WARNING
While it is thundering, do not touch the connecting cables or
apparatus.
Never block or cover the slots or openings in the TV cabinet back,
bottom, and sides. Never place the TV:
- on a bed, sofa, rug, or similar surface;
- too close to drapes, curtains, or walls; or
- in a confined space such as bookcase, built-in cabinet, or any
other place with poor ventilation.
The slots and openings are provided to protect the TV from
overheating and to help maintain reliable operation of the TV.
Do not use the product if any abnormality occurs:
If any smoke or odor becomes apparent, unplug the connector
and contact the manufacturer immediately. Do not try to repair
the product by yourself.
Never use a damaged power cord:
Heavy objects, heat or tensile force may damage the power cord and
cause fire or electric shock.
Do not install the product close to smoke or moisture:
Fire or electric shock may be caused when the product is installed
close to smoke or moisture.
Do not installed the product in an area with heavy dust or high
humidity:
Fire or electric shock may be caused when the product is installed in
a place with heavy dust or high humidity.
ATTENTION
Instructions for moving the product:
Ensure that the power connector and any other leads are unplugged
before moving the product.

4
Insert batteries in accordance with instructions:
Insert the batteries with correct polarities (positive  and negative ).
Incorrect polarities may cause breakage and leakage of the
batteries, hurt operators and contaminate the remote controller.
Do not block or cover the vents:
Blocking the vents may cause overheating and fire. Do not install the
product in a place with little or no ventilation. Never cover the vents
with towels, blankets or dusters.
Unplug the connector:
Unplug the power connector when the product will not be used
for a long time.
ATTENTION
Unplug the connector
Hold the power connector when removing the power cable:
Pulling the power cable itself may damage the wires inside the cable
and cause fire or electric shock.
Do not touch the connector with wet hands:
To avoid risk of electric shock.
Unplug the connector
The power cable should be kept away from heat sources:
The heat produced by any heat source may melt the covering of the
power cable.
Always make sure the antenna system is properly grounded to provide adequate
protection against voltage surges and built-up static charges.(see Section 810 of the
National Electric Code.)
Antenna lead-in wire
Antenna discharge unit
(NEC Section 810-20)
Grounding conductors
(NEC Section 810-21)
Power service grounding
electrode system (NEC Art 250 Part H)
Ground clamp
Electric service equipment
Ground clamp
Use extreme care to make sure you are never in a position where your body (or any
item you are in contact with, such as a ladder or screwdriver) can accidentally touch
overhead power lines. Never locate the antenna near overhead power lines or other
electrical circuits. Never attempt to install any of the following during lightning activity:
a). an antenna system; or b).cables, wires, or any home theater component connected
to an antenna or phone system.

5
Others:
1). The LCD panel on this TV is manufactured using an extremely high level of
precision technology; however, an occasional pixel (dot of light) may display
constantly on the screen.
This is a structural property of LCD technology and is not a sign of
malfunction.
Such pixels are not visible when the picture is viewed from a normal viewing
distance.
2). LCD (Liquid Crystal Display) may cause interference in image, sound, etc. of
the other electronic equipment that is easy to receive electromagnetic waves
(i.e. AM radios and video equipment) under certain installed condition. In
particular, it may affect electronic equipment beyond the residential until where
a LCD TV is used.
3). The screen on this TV is manufactured from glass. To prevent damage, never
strike the glass with a sharp or heavy object.
4). Your LCD television contains a small amount of Mercury. When the television
is no longer useful, please follow local electronic waste guidelines for proper
disposal.
5). If you have the LCD screen facing to the sun, the LCD screen will be damaged.
Locate the TV in the place such away from windows side or out side of the rooms
with windows.
6). This product is designed for indoor use only.
The operation temperature are 5°C ~ 30°C.

6
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that product heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized
plug has two blades wider than the other. A grounding type plug has two blades and
a third grounding prong. The wide blade or the third prong are provided for your
safety. If the provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer,
or sold with the apparatus. When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of
time.
14. Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped.
15. The apparatus shall not be exposed to dripping or splashing and that no objected
filled with liquids, such as vase, shall be placed on the apparatus.

7
1. Before use .......................................... 8
1.1 Open the Package ..............................8
1.2 Installation ..........................................8
2. Product Features ................................ 9
3. Accessories ........................................ 9
4. Names and Functions of Parts ........... 10
4.1 Side View ...........................................10
4.2 Front View ..........................................10
4.3 Rear View ...........................................11
4.4 Remote Control ..................................12
5. Connect Accessory Devices ............... 16
6. Basic Operation .................................. 19
6.1 Power ON/OFF ...................................19
6.2 Selection of Input Mode ......................19
6.3 Other Function ....................................19
6.4 Using the POP double-window
feature ................................................20
6.5 OSD Option Adjustment .....................21
6.6 OSD Functions of TV System ............22
1 Using the Video Menu ......................22
Adjustment of “Contrast” ..................23
Adjustment of “Brightness” ...............23
Adjustment of “Back Light” ...............24
Adjustment of “Saturation” ...............24
Adjustment of “Hue” .........................25
Adjustment of “Sharpness” ...............25
Selection of “Phase” setting ............26
Selection of “Color Temperature” ..... 26
Selection of “Advance Picture
Adjust” ..............................................27
2 Using the Audio Menu ...................... 28
Adjustment of “Bass” ........................28
Adjustment of “Treble” ...................... 28
Adjustment of “Balance” ...................29
Selection of “Surround” ....................29
3 Using the Miscellaneous Menu ........30
Selection of “Language” ................... 30
Selection of “Closed Caption” .........30
Setting of “V-Chip” ...........................32
Contents
Setting of “Parental” .........................36
Selection of “Blue Mute” ...................38
Using “Default” .................................38
4 Using the TV Menu ...........................39
Using the “Auto Search” ...................39
Using the “Tuner Mode” ...................39
Using the “Channel Skip” .................40
Using the “Channel Name” ...............40
5 Using the Geometric Menu ..............41
Using “Contrast” ...............................41
Using “Brightness” ............................41
Using “Back Light” ............................42
Using “Auto Setting” .........................42
Using “Phase” ..................................43
Using “Manual Clock” .......................43
Using “Display Adjustment” ..............44
Selecting Channel ............................44
Channel Preview ..............................44
6.7 Operation of DVD System .................. 45
1 Suit Table Disc Types .......................45
2 Play a Disc .......................................45
3 Function Buttons ..............................46
4 Program Setting ...............................48
5 Setup of DVD ...................................49
GENERAL SETUP PAGE ................49
SPEAKER SETUP PAGE .................51
DOLBY DIGITAL PAGE ....................51
PREFERENCE PAGE ......................52
7. Technical Specification ....................... 55
8. Support the Signal Mode .................... 56
9. Cleaning and Simple
Troubleshooting ................................. 56

8
1. Before use
The product is a 27” WXGA (WXGA resolution) LCD TV/DVD Player Combo. It has
passed the UL and cUL safety certifications, and is an ideal product for personal and
commercial use. The product is a precise electronic product. Users should read the
following instructions carefully to maximize the performance and life span of the product:
1.1 Open the Package
- The product is packaged in a carton together with other standard accessories. Any
optional accessories shall be packed separately in another carton.
- Due to the size & weight of the product, it is recommended that it should be moved
by a minimum of two people.
- The protective glass and the glass substrate are installed on the front of the product.
Since both glasses can be broken and scraped easily, move the product gently.
Never place the unit with the glass facing downwards unless it is protected with soft
pads.
- When opening the carton, check that the product is in good condition and that all
standard accessories and items are included.
- Whenever possible, use the handles on the back of the Display for transport.
1.2 Installation
- Please use caution if wall mounting this product. Follow all directions from the
manufacturer of the wall mount and be sure to securely fasten the product to the
mount. While the TV can be wall mounted, improper wall installation may void the
warranty.
- Due to the higher power consumption, always use the jack exclusively designed for
this product. If an extended line is required, please consult with your service agent.
- The product should be installed on a flat surface to avoid tipping. The distance
between the back of the product and the wall should be maintained for proper
ventilation.
- Avoid installing the product in the kitchen, bathroom or any other places with higher
humidity so as not to shorten the service life of the electronic components.
- Please ensure the product be installed horizontally, any 90 degree clockwise or
counterclockwise installation may induce poor ventilation and subsequent component
damage.
- To protect the screen and avoid screen burn, do not hold on a static picture for a
long time.

9
2. Product Features
The 27˝ LCD TV/DVD Player Combo provides quality image displays and is suitable for a
variety of multi media applications:
1. Available input signals
- The standard PC module provides VGA (D-SUB 15 PIN), and a RS-232 (D-SUB 9
PIN MALE) communication connector.
The product supports PC mode image resolutions up to (1024 x 768@60Hz) with a
vertical frequency of 60 Hz. (The VGA input may not be supported some of the PC
Display Card.)
- The Video module provides composite video (RCA), S-video (DIN 4 PIN) and
component video (RCA) input connectors. It supports the quality input images of
DVD and HDTV (480P/720P/1080i). The Video module also provides one set of
Stereo Audio output.
- The TUNER Module
The RF input terminal is for ANTENNA and CABLE TV channels.
2. Power Management Function
The machine provides an automatic power control function.
3. WXGA LCD TV Panel
The WXGA LCD TV panel provides high resolution and high contrast image. The
number of pixels is 1366 (H) x 768 (V). The contrast is 1000:1.
4. Build in slot-in DVD player
This LCD TV build in a slot-in DVD player, and compatible for DVD/CD/CD-R/ CD-RW
format disc. (The DVD player may not be supported some of the disk.)
5. Others
- PIP/POP Function: The user may watch image from two source at same time.
(The PIP/POP function may not supported all of the difference signal format.)
- The LCD TV unit provides cool, middle, warm and user color temperature options.
The user may customize their favorite color temperature.
3. Accessories
1 User Manual x 1
2 AC Cable x 1
3 Remote Control x 1
4 Battery(UM-3/R6P/AA) x 2
5 Warranty Card x 1
6 Insertion Card x 1

10
4. Names and Functions of Parts
4.1 Side View
4.2 Front View
(IR) Infrared Receiver: Receives IR signals from the remote control.
(Power on / Standby) LED: Press (Power) to turn on and off.
Indicator on (Red) Standby mode
Indicator on (Green) Power on mode
Sketch map
Disc Slot:
Place a disc in the
disc slot.
Note: Insert a disc
with the logo-printed
side facing the front.
STANDBY: Press (Standby) to turn on and turn off.
VOL.+/-
A. They are used as ＜ / ＞ buttons in the OSD Menu
screen.
B. Press to adjust the volume.
CH.+/-
A. They are used as ∧ / ∨ buttons in the OSD Menu
screen.
B. Press to scan through channels. To scan quickly
through channels, press and hold down either
channels.
MENU: Press to display the menu. Press again to exit the menu.
SOURCE: Press to cycle display TV, AV, S-Video,
Component, DVD, and VGA source menu.
When display the OSD-menu, press it to confirm.
(OPEN/CLOSE): Press to open or close the disc tray.
(STOP): Press to stop playing the disc.
(PLAY/PAUSE): Press to play or pause the disc.
The functions of the buttons are described as follows:
Sketch map

11
4.3 Rear View
󱰻 Push the power switch (O: Off, I: On). The power indicator on the front of the panel
should now display red, indicating that the LCD TV is in standby mode.
󱰼 Use the included power cord and connect to an earthed 100-240V, 50/60Hz AC outlet.
Note: Shut down the power switch, turn on it again after the power indicator is extinguished
entirely.
󱰽 Signal input and other terminals:
A. COAXIAL OUT: This terminal is used as a digital audio output to audio amplifier.
B. RS-232: The D-SUB 9 pins terminal is used as a control port for serial communication
between PC and Panel. (For after sales service use only.)
C. D-SUB(VGA) INPUT: For PC display purpose. Connects to the Mini D-Sub 15 pins
analog output connector of the PC display card.
D-SUB(VGA) AUDIO INPUT: Connect the audio terminal to the audio output terminal
of the PC.
D. YPbPr INPUT: Connect the separate component video cables to the device having
component video outputs (YPbPr) to the YPbPr terminal of the TV.
YPbPr AUDIO INPUT: Connect the audio cable to device’s audio L and R terminal
and to the L and R audio terminal of the TV.
E. VIDEO INPUT: Connect the video input terminal to the output terminal of the video
output device.
F. S-VIDEO INPUT: Connects to the S-Video output terminal of your video equipment
that has S-Video.
G. AUDIO INPUT: Connect the audio input terminal to the audio output terminal of
the video output equipment. With S-VIDEO audio input signals share this terminal.
H. RF IN: Connect the antenna or cable set-top box with 75 Ohm F type connector into the
RF IN terminal.
I. AUDIO OUTPUT: Connect to the audio amplifier that with audio input.
Sketch map
󱰻
󱰼
󱰽

12
4.4 Remote Control
󱯎 Power ( ): Press to turn on and off.
󱯐 Mute ( ): Press to mute the sound.
Press again or press ＜ , ＞ to restore
the sound.
󱯒 CCD: Press to select the Closed
Caption mode.
󱯔 V-CHIP: Press to select the child
protect mode.
󱯖 MTS: Press repeatedly to cycle through
the Multi-channel TV sound (MTS)
options: Mono, Stereo and SAP
(Second Audio Program).
󱯘 Favorite: Press repeatedly to cycle
through the favorite channel list.
󱯚 PIP. Pos: Press to change the PIP
window position under PIP mode.
󱯜 PIP. Size: Press to cycle through the
PIP size, such as Large, Medium,
Small.
󱯞 Add/Erase: Press to add or delete
favorite channel.
󱯠 PIP: Press to cycles through the
different POP or PIP modes, such as
Basic PIP, LR POP, and exit.
󱯡 0~9 Number Buttons: In TV mode,
press 0~9 to select a channel; the
channel changes after 2 seconds.
In DVD mode, press 0~9 to input the
items.
󱯢 Zoom: Press to zoom the image max
from 8 times to minimally 1/8 times.
󱯣 Recall: Press to return to previous
channel.
󱯤 P.Mode: Press repeatedly to cycle
(Continued on next page)
through the picture mode: Hi-Bright, User, Dark, Normal and Vivid.
󱯥 P.Size: Press repeatedly to cycle through the picture size that best corresponds your
viewing requirements: Normal, Full, Wide1, Wide2, Wide3, 4:3, No scale, Panoramic
and Normal.
When in POP mode, it can select picture size is: Full, 4:3 and Normal.
󱯦 Vol ∧ / ∨ : Press to adjust the volume.
󱯧 Ch ≪ / ≫ : Press to scan through channels. To scan quickly through channels, press
and hold down either channels.
󱯢
󱯩
󱯫
󱯮
󱯯
󱯴
󱯐
󱯖
󱯻
󱯺
󱯒
󱯚
󱯜
󱯡
󱯦
󱯤
󱯬
󱯷
󱯶
󱯰
󱯣
󱯪
󱯭
󱯲
󱯎
󱯧
󱯼
󱯽
󱯔
󱯘
󱯞
󱯠
󱯥
󱯸
󱯹
󱯵
󱯳
󱯱
󱯨

13
󱯨 Freeze: Press to freeze the picture,
press again to restore the picture.
󱯩 Menu: Press to enter into the on-screen
setup menu, press again to exit.
󱯪 S.Mode: Press repeatedly to cycle
through the sound mode: Normal,
News, Cinema, Flat and User.
󱯫 ＜ , ∧ , ∨ , ＞ , Enter: Press ＜ , ∧ , ∨ ,
＞ to move the on-screen cursor. To
select an item, press ENTER to
confirm.
󱯬 System: Press repeatedly to cycle
through the system options: AUTO
and NTSC3.58.
(This button is activate for AV, S-Video
input source.)
󱯭 Source: Press to select the signal
source, such as TV, AV, S-Video,
Component, DVD or VGA.
󱯮 Sleep: Press repeatedly until it
displays the time in minutes (5 Min,
10 Min, 15 Min, 30 Min, 60 Min, 90
Min, 120 Min and, OFF) that you
want the TV to remain on before
shutting off. To cancel sleep time,
press Sleep button repeatedly
until sleep OFF appears.
󱯯 Display: Press to display the channel
information and it disappear after 3
seconds.
󱯰 Play/Pause: Press to play or pause
the DVD disc.
󱯱 Stop: Press to stop playing the disc.
󱯲 Angle: Press to select desired viewing
angle of the Video (disc feature).
(Continued on next page)
󱯳 Open/Close: Press to open or close the disc tray.
󱯴 Skip+/-: Press to skip the forward or backward.
󱯵 Search+/- : Press to search the forward or backward.
󱯶 DVD Menu: Press to return DVD disc menu.
󱯢
󱯩
󱯫
󱯮
󱯯
󱯴
󱯐
󱯖
󱯻
󱯺
󱯒
󱯚
󱯜
󱯡
󱯦
󱯤
󱯬
󱯷
󱯶
󱯰
󱯣
󱯪
󱯭
󱯲
󱯎
󱯧
󱯼
󱯽
󱯔
󱯘
󱯞
󱯠
󱯥
󱯸
󱯹
󱯵
󱯳
󱯱
󱯨

14
󱯷 DVD Info: Press to display DVD
information.
󱯸 Setup: Press to display a menu.
Press it again to exit menu.
󱯹 Repeat: Press repeatedly to cycle
through the options: CHAPTER,
TITLE, ALL and nothing.
󱯺 Audio: Press to select desired audio
track.
󱯻 Prog: Press to display the program
menu. Press it again to exit.
 󱯼 Sub. title: Press to select desired
DVD subtitle.
 󱯽 Title: Press to display to DVD disc
title.
Note: Press Ch ≪ / ≫ on the remote
control can turn on TV set from
last preview mode.
Insertion of Batteries:
- Turn the remote control upside down, press and slide off the battery cover.
- Insert two 1.5V (AA) batteries into the compartment, take care to observe the  and 
markings indicated inside.
- Replace the cover and slide in reverse until the lock snaps.
󱯢
󱯩
󱯫
󱯮
󱯯
󱯴
󱯐
󱯖
󱯻
󱯺
󱯒
󱯚
󱯜
󱯡
󱯦
󱯤
󱯬
󱯷
󱯶
󱯰
󱯣
󱯪
󱯭
󱯲
󱯎
󱯧
󱯼
󱯽
󱯔
󱯘
󱯞
󱯠
󱯥
󱯸
󱯹
󱯵
󱯳
󱯱
󱯨

15
Range of Remote Control
Sketch map
30°
20°
20°
30°
-
Ensure the remote control is pointed towards the remote control window on the display
unit.
-
No obstacles should be placed between the remote control and the remote control
window.
-
The effective receiving range for the signal is within 5-8 meters from the front of the
remote control window, and 30° to the left or right side and 20° above or below the
control window.
Care For Remote Control
-
Avoid spilling liquids on the remote.
- Avoid dropping or otherwise jarring the remote.
-
Always store the remote control at dry and normal room temperature place.
- If the remote is nor performing satisfactorily, replace the batteries. The batteries should
be replaced after one year.
- If the remote control will be idled for a long time (above 1 month) take out the batteries
to avoid leakage from the batteries.
- Clean up the entire remote control especially the battery compartment if any leakage
found.
- Do not mix using different kind of new and used batteries together to avoid leakage.

16
5. Connect Accessory Devices
Connecting a DVD player or other
equipment
Switch off LCD TV and external equipment
before connecting cables.
1. Connect a DVD player or other
equipment’s Component Video Out
(Y,Pb,Pr) to the LCD TV’s corresponding
Component In (Y,Pb,Pr) terminal.
2. Connect a DVD player’s Audio Out to the
TV Component L/R terminal.
3. Press Power to turn on the LCD TV.
Turn on external equipment also.
4. Press Source to select COMPONENT
signal source.
DVD or other equipment
Red White
Red
Green
Connecting the Computer
Switch off LCD TV and external equipment
before connecting cables.
1. Connect a computer’s VGA Out to the
LCD TV’s VGA In terminal.
2. Connect a computer’s Audio Out to the
LCD TV’s Audio In terminal.
3. Press Power to turn on the LCD TV.
Turn on external equipment also.
4. Press Source to select VGA signal
source.
Blue

17
Connecting the DVD or VCR player devices
Switch off LCD TV and external equipment before connecting cables.
1. Connect a DVD or VCR player’s Video Out to the LCD TV’s Video In terminal by a
Video cable.
2. Connect a DVD or VCR player’s S-VIDEO Out to the LCD TV’s S-VIDEO In terminal by a
S-VIDEO cable.
3. Connect a DVD or VCR player’s Audio Out to the LCD TV’s L/R terminal by a Audio
cable, in this stage, the S-VIDEO and VIDEO is sharing this L/R Audio in channels.
4. Press Power to turn on the LCD TV. Turn on external equipment also.
5. Press Source to select AV or S-VIDEO signal source.
Connect audio amplifier or other TV set
Switch off LCD TV and external equipment
before connecting cables.
1. Connect the LCD TV Audio Out (R/L) to
the audio amplifier In (R/L).
2. Press Power button to turn on the LCD
TV. Turn on external equipment also.
Red
White
DVD or VCR player
DVD or VCR player
White
Yellow Red
Audio Amplifier
Red White

18
Connecting directly to cable or an antenna
When using 75Ω coaxial Aerial: Connect directly to the RF terminal of the tuner.
Connect audio amplifier
Switch off LCD TV and external equipment before
connecting cables.
1. Connect the LCD TV-combo’s COAXIAL OUT
to the Audio Amplifier COAXIAL Input terminal by
a coaxial cable.
2. Press Power to turn on the LCD TV-combo.
Turn on external equipment also.
3. Press Source to select DVD signal source, and
set the Audio Amplifier to coaxial input mode.
4. When DVD is playing, you can enjoy coaxial
digital audio by Audio Amplifier.
Mixer
VHF Antenna
1m above
Special Antenna
UHF Antenna
75Ω Coaxial Aerial
RF(VHF/UHF) terminal
Insert the Disc to slot-in DVD Player
1. Press Source button to select DVD signal source.
2. Insert a disc into the slot-in DVD Player’s disc
tray, please confirm the disc’s screen is face to us.
3. The DVD Play will auto slot in the disc, and the
LCD TV will display “Loading”, if the disc type is
fit the spec, you can enjoy the playing.
Note: Please be noted that the disc’s contents must be
in front, if you put it in reverse, the LCD TV screen
will display “No Disc”.
Disc’s
screen
side

19
6. Basic Operation
6.1 Power ON/OFF: The Display is in
Standby mode
- Press the Power on the remote control or
on the control panel to turn on the unit. The
power indicator changes from red to green.
- Press the Power on the remote control
or on the control panel again to return the
display to standby mode.
The power indicator changes from green to
red.
Note: For protecting your LCD TV product, the
interval time between turn on the LCD TV
product and shut down it should be kept at
least one minute.
6.2 Selection of Input Mode
- Press SOURCE on the remote control or
on the LCD TV control panel to select the
signal source you desired.
When no input from the selected signal
source, “Main no signal” will appear, press
Source on the remote control or on the
control panel again to search the next
source.
Note:
󱯎 The LCD-TV will automatically turn itself off after approximately 15 minutes if no signal input. When no signal
is inputted for about 14 minutes. A “No signal and going to power down” wording will appear.
󱯐In DVD mode, if no disc playing for about 5 minutes, there is a screensaver as big DVD logo run and
change color continuously.
6.3 Other Function
Freeze:
- Press it to hold the current video and press
again to cancel and return to normal
viewing.
Zoom :
- Press it repeatedly the size of image will
change cycling in following sequence: 2
times → 4 times → 8 times → 1/8 times
→ 1/4 times → 1/2 times → normal.
Display:
- Press once to display the information as
following, and disappear after 3 second;
68
When in TV mode
When in VGA mode
VGA
1280 x 1024 60Hz
Power
Source
Favorite
, Enter
Freeze
Zoom
Display
Sleep:
- Press repeatedly until it displays the time in minutes that you want the TV to remain
on before shutting off.
Note: When “Turn off by Timer setting?” wording will appear remain one minute on before shutting off, you can
press “<” or “>” button to selected, press “Enter” to confirm. If select “Cancel” or no operation, the LCD-TV will
automatically turn off after one minutes, if select “OK”, it will turn off immediately.
Sleep
