Alarm Lock T3e Series Addendum Installation guide

NEW FEATURE
"ONE TIME ACCESS FOR
GROUP 3 USERS"
ADDENDUM
OVERVIEW
Your T3e Series lock now includes a new feature named "One Time Access for
Group 3 Users", allowing the creation of multiple 'one time only' User Codes.
When this feature is activated, an entry by a Group 3 User will allow entry only
once, then the user will become disabled. Note: When the User Code is entered
for the first time and access is granted, the Event Log will read "Entry" followed by
"User Disabled". If the User Code is entered a second time, access will be denied,
and the Event Log will read "User Denied Access".
TO ACTIVATE VIA THE KEYPAD
To use this new feature, proceed as follows:
1. Enable the Feature. Enter Program Mode and enter the key
sequence ;67;24:.
2. Assign the selected User Codes to Group 3. For example, to assign
User Number 15 to Group 3, press:
;35;15;3:
TO ACTIVATE VIA DL-WINDOWS (V3.03 or later)
DL-Windows provides a check box on the Features screen (click the Feat button,
click the Options tab, and check "One Time Only For Group 3 Users"). Note: If
this option is programmed via the keypad, downloading from versions of DL-
Windows prior to V3.03 will not alter the operation of this feature.
TO DEACTIVATE VIA THE KEYPAD
As with all ;67;commands, this feature can be disabled by
entering the following key sequence:
; 67;000:
345 Bayview Avenue
Amityville, New York 11701
For Sales and Repairs 1-800-ALA-LOCK
For Technical Service 1-800-645-9440
© ALARM LOCK 2004 WI1266 2/04
