Alarm Lock Trilogy Networx Double-Sided PDL6300 Installation manual

1
Double-Sided PDL Trilogy Series Stand-Alone Access
Control Systems with Proximity Credential Access
WI2265LF 1/18
PDL6300 PRIMARY SIDE
(CONTAINS ANTENNA AND METAL KEY CYLINDER) PDL6300 SECONDARY SIDE
(CONTAINS BATTERIES AND MOUNTING SCREWS)
345 Bayview Avenue, Amityville, New York 11701
For Sales and Repairs 1-800-ALA-LOCK
For Technical Service 1-800-645-9440
or visit us at http://tech.napcosecurity.com/
(Note: Technical Service is for security professionals only)
Publicly traded on NASDAQ Symbol: NSSC
© ALARM LOCK 2018
Wireless Trilogy®
Double-Sided PDL6300
Supports Version 2 Gateways and Expanders
Programming Instructions
PROXIMITY
CREDENTIAL
DL-WINDOWS PROGRAMMING
SOFTWARE
AL-IM2 SERIES
"VERSION 2"
GATEWAY MODULES
AL-IM2-80211
AL-IME2
AL-IME2POE
AL-IM2-PIE PLUG-IN
EXPANDER MODULE
AL-IME-USB
GATEWAY MODULE
PROXIMITY KEYFOB

2
Table of Contents
Lock Features ...........................................................3
Supported Products and Applications.................4
Lock Design Overview.............................................6
Terminology Used in this Manual..........................7
Programming Levels ...............................................9
Conventions Used in this Manual..........................10
LED and Sounder Indicators..................................10
Emergency Commands...........................................11
Wireless Remote Releases.....................................13
Wiring and Power Up...............................................14
Erase All Programming...........................................14
Battery Replacement ...............................................14
Quick Start.................................................................15
Testing the Codes Entered.....................................17
Programming Functions Overview .......................18
Programming Functions .........................................19-31
Groups and Scheduled Group 1 Examples .........32
Programming Record Sheet...................................34
User Code Record Sheet.........................................35
Schedule Record Sheet...........................................37
Glossary.....................................................................38-39
Warranty.....................................................................40
THE ALARM LOCK TRILOGY PDL-SERIES STAND-ALONE ACCESS CONTROL SYSTEM IS ASERIES OF STATE-OF-
THE-ART MICROPROCESSOR-BASED PROGRAMMABLE KEYPAD-ENTRY AND PROXIMITY SECURITY LOCKS.
PDL6300
PDL6300
This double-sided stand-alone door lock provides controlled entry and exit at certain
locations such as airport security areas and police stations. Features an HID com-
patible Proximity credential reader, and a real-time clock/calendar that automatically
adjusts for Daylight Saving Time and allows for automated programming of events.
Up to 5000 unique User Codes can be added to the lock, from 3-6 digits in length.
The Trilogy Networx™ PDL6300 is designed to allow all features to be programmed
either at the keypad or through its radio link to a DL-Windows equipped computer.
For example, Audit Log Data may be transmitted through the radio link back to the
DL-Windows computer.
Wireless Network, DL-Windows and Keypad Programming
If your Networx wireless network is not yet set up, you can add Users and program
other features using the PDL6300 keypad as a temporary convenience to allow the
lock to be put into use before installing the wireless network. Be aware that all pro-
gramming added using the keypad cannot be retrieved into DL-Windows, so if you
decide to start programming using the lock keypad, we recommend you keep hard-
copy records (in a secure location) of all Users, User Codes, and any proximity cre-
dentials that may have been programmed. Keeping these hardcopy records will save
time because after the wireless network is set up, all programming added via the lock
keypad can easily be re-added to DL-Windows and downloaded back to the lock(s).
These instructions include manual keypad programming. For DL-Windows user in-
structions, see the DL-Windows User's Guide (OI382); for configuring your wireless
system, see the DL-Windows for Networx User's Guide (OI383).
DOUBLE-SIDED PDL SERIES LOCKS
The word "credential" used throughout this manual is a generic word intended to describe a User Code, a proximity card, proximity keyfob (such as a
ProxKey®keyfob), a hardwired Remote Input momentary contact, a Wireless Remote Release, or any future device or design that allows the lock to
unlock, allowing passage through the door. Trilogy®is a registered trademark of Alarm Lock. ProxCard®and ProxKey® are trademarks of the HID©
Corporation. Microsoft®and Windows®are trademarks of the Microsoft Corporation.

3
Audit Trail
 40,000 Event Capacity**
 Entries Logged with Time and Date
 Critical Programming Events Logged
 Uploadable using Alarm Lock's DL-Windows software (see page
4)
Lock Features
 Metal Key Override*.
 Keypad Lockout (see page 26, Functions 60-61)
 Non-Volatile (Fixed) Memory
 Real-Time Clock (within one second accuracy) (see page 24,
Functions 43-44)
 Visual and Audible Keypad Feedback (see page 10)
 Battery Status Monitor (see page 14)
Scheduling
 500 Scheduled Events (see pages 29-31)
 Automated Unlock/Lock
 Enable/Disable Users (see page 20, Function 3)
 Enable/Disable Groups (see page 21)
 Four "Quick Schedules" (4 most common schedules, page 30)
 Real-time clock and calendar (see page 24)
 Group Enable/Disable with Timeout Functions (see page 22,
Functions 25-34)
User Access Methods
 Keypad Entered User Codes (see pages 15-16, 19)
 Proximity Credential (Card or ProxKey®keyfob) (see page 16)
 User Code and ProxCard®(For highest security) (see page 16)
 Batch Enroll - Quickly and easily enroll multiple Proximity Cre-
dentials without the use of a PC. (see page 16)
Note: ProxCards®and ProxKey®Keyfobs both function identi-
cally. Keyfob credentials can be substituted for all references to
ProxCards®in this manual.
User Features
 5000 Users (see pages 15-16, 19)
 6 Pre-defined Administration User Levels including Master,
Installer, Manager, Supervisor and Basic User Codes (see page
9)
 User Code Lengths from 3-6 digits
 Service Code ("One-Time-Only" Code) (see page 8)
 User Lockout Mode (see page 20, Function 6)
 Users Assignable to a Group or Groups (see page 32)
 Guard Tour Code (see "User 299: Guard Tour Code" page 8)
 Global Lock-Down / Unlock in emergency; activated from Wire-
less Remote Release Transmitters, DL-Windows or initiated
from another Networx lock in the system (see "How do the
Emergency Commands work?" on page 8)
Keypad and Computer Programming
 Full Administrative programming from a PC using Alarm Lock's
DL-Windows Software. See the DL-Windows User's Guide
(OI382) and the DL-Windows for Networx User's Guide (OI383)
 Networked mode: PC running DL-Windows is connected to
(wirelessly or wired) a network, either using an Ethernet or
802.11 connection. Communications are accomplished through
networked Gateway module(s). See pages 4-5 for supported
products.
 Non-networked mode: PC running DL-Windows does not re-
quire a network. Communications are accomplished using an
AL-IME-USB Gateway inserted into a USB port on your Win-
dows laptop or PC. Note: Only "Local" Emergency Commands
are supported when using an AL-IME-USB Gateway. See pag-
es 4-5 for supported products.
 Wireless programming range: Up to 200 feet, depending on
building construction materials
Lock Features
PDL6300 PRIMARY SIDE PDL6300 SECONDARY SIDE
This key cylinder ONLY
used to securely remove
this handle (does not
unlock the lock--use when
changing batteries)*
Battery Pack inside
This key cylinder
unlocks the lock*
(No communication
port Interface)
Proximity
Credential
Readers
* Note: Only the Primary side key cylinder allows
non-logged access; the Secondary side key
cylinder is only used to secure the housing to the
door. Therefore a person in possession of only
the metal key who is located on the Secondary
side of the door has no means of unlocking the
PDL6300.
Red LED
Green LED
Red LED
Green LED

4
DL-Windows Software Application
Alarm Lock Trilogy Microsoft Windows-based software application, v4.0 or higher, supports
Trilogy Networx and Trilogy stand alone locks, with single database (PDL6300 series door
locks require v5.2.3 or higher). For use with Free of charge and downloadable online at
www.alarmlock.com. DL-Windows software is the basis for the wireless lock program-
ming interface. For those unfamiliar with using DL-Windows software, stop here and re-
view the DL-Windows User's Guide (OI382) and the DL-Windows for Networx User's Guide
(OI383).
RR-4BKEYFOBRR-1BUTTON
RR-1BUTTON and RR-4BKEYFOB
The PDL6300 series door locks are compatible with the RR-1BUTTON Wireless Remote
Release Button (see WI1999) and RR-4BKEYFOB Wireless Remote Release Keyfob (see
WI2004). The PDL6300 can wirelessly unlock all Networx™ series door locks. The RR-
4BKEYFOB is a portable pocket-size remote release, and the 1-button RR-1BUTTON is
intended for fixed mounting at a hidden location. Each requires one battery (service life of up to
12,000 openings). During normal operation, the lock typically opens within 2 seconds of the
button press.
AL-IM2 SERIES WI-FI Gateway Modules
A Networx series door lock contains a radio that transmits and receives data--via a private
wireless signal--to an intermediate device called a Gateway module. In turn, this Gateway
module is connected (either wirelessly or wired) to a computer network such as a LAN or
corporate Intranet. A Windows PC connected to this network can control and program all
Networx series door locks by the use of the DL-Windows software (see OI382 and OI383).
With access rights to the software, one computer--or several--can control the software and
consequently can control the devices in the system. Note: See below for an explanation of
"VERSION 2". Several Gateway device models are available:
 "Wireless / Wired" AL-IM2-80211 Hardwired / Wireless Gateway Interface Module.
Supplied with its own class 2 transformer to supply power and supports connection to a
network either using 802.11 or a standard Ethernet cable. This "Wireless / Wired"
Gateway module has two antennas, one for the proprietary radio connection to the
Networx series door lock and the other for 802.11 network transmissions. Ensure
adequate 802.11 coverage in the area where the "Wireless / Wired" Gateway is mounted.
Supports up to 63 Networx locks. Ceiling- or wall-mountable.
 "Wired" AL-IME2 Hardwired Gateway Interface Module, supports up to 63 Networx
Locks, connects directly to a network using a standard RJ-45 Ethernet cable. This model
has one antenna used to transmit to the Networx series door lock via an Alarm Lock
proprietary radio connection. Ceiling- or wall-mountable. Powered with Class 2, 6VAC
transformer (supplied).
 "Power over Ethernet" AL-IME2POE Hardwired Gateway Interface Module + POE
(Power Over Ethernet), supports up to 63 Networx Locks, connects directly to a network
using a standard RJ-45 Ethernet cable and POE. This model has one antenna used to
transmit to the Networx series door lock via an Alarm Lock proprietary radio connection.
Ceiling- or wall-mountable.
 AL-IME-USB - USB Portable Gateway Interface Module, virtually the same functionality of
the Gateways listed above, however this highly portable and compact module connects to
a standard USB 2.0 socket or greater in your Windows laptop or PC, quickly and
effortlessly creating a wireless connection to your Networx series door locks. Requires DL
-Windows v5.2.3 or higher. Note: Only "Local" Emergency Commands are supported
when using an AL-IME-USB Gateway.
AL-IME-USB
AL-IM2-80211
AL-IME2
AL-IME2POE
Supported Products and Applications

5
"VERSION 2" CONSIDERATIONS
 Before adding any of the current wireless Expander models (AL-IME2-EXP and AL-IME2-PIE) at least one
version 2 Gateway (AL-IM2-80211, AL-IME2 and AL-IME2POE) must be installed and operational in your
system. The new wireless Expanders cannot communicate with any of the older Gateways (AL-IME, AL-
IM80211, AL-IMEPOEP and AL-IME-USB).
 Version 2 Gateways and Expanders require DL-Windows version 5.4.2 or later.
 Mixing older Gateways with Version 2 Gateways is supported by DL-Windows 5.4.2 or later.
 Compared with the original "version 1" Gateways, the "Version 2" Gateways have a different enclosure design,
the operation and colors of the LEDs are different, and the location of the hidden Ethernet socket is through the
rear mounting plate.
Note: The AL-IME2-POE Gateway is compatible with Alarm Lock and Continental Access products.
Refer to the documentation supplied with your software for integration details.
AL-NSM
Signal Meter
AL-NSG Signal Generator
SITE SURVEY TOOLS
The AL-NSM Networx Signal Meter and the AL-NSG Networx Signal Generator greatly
assist with identifying optimal Gateway locations for the anticipated installation doors. See
WI2092 for complete information, but a general description follows:
AL-NSM Networx Signal Meter
Performs a site survey test of the premises to:
 find the optimum location for Gateways relative to locks
 find the optimum location for locks relative to Gateways
 determine the optimum number of Gateways required to cover the signal area of the locks
you plan to install
 perform diagnostic testing of existing Gateway radio signals within your installation
environment
Using the various available Modes, the AL-NSM can measure radio noise levels, calculate
overall signal quality, discover Networx locks not yet assigned to Gateways, and even send a
"locate" signal (causing all unassigned locks to "beep").
The AL-NSM can be used with an existing Gateway and the "Gateway Signal Test Mode"
feature in DL-Windows, or with the AL-NSG Networx Signal Generator explained below.
Note: See the "Gateway Signal Test Mode" feature in the DL-WINDOWS for Networx V5
User's Guide (OI383).
AL-NSG Networx Signal Generator
As mentioned above, the AL-NSM Signal Meter may be used with either an existing
operational Gateway or the portable AL-NSG Networx Signal Generator. The AL-NSG is a
portable battery-powered Gateway simulation device that generates continuous Gateway radio
signals to an AL-NSM.
Depending on how you use the AL-NSG, the AL-NSG can be placed in the proposed
location for a Gateway or in the proposed location of a lock, to determine the acceptability and
the dependability of the radio signal coverage. The AL-NSG can be mounted using the inert
nylon lanyard or reusable adhesive mounting putty (supplied with the AL-NSG).
Supported Products and Applications (cont'd)
The Networx™AL-IME2-EXP Expanders extend the coverage area of AL-IME2 series Gate-
ways, allowing control of up to its rated maximum of 63 Networx locks per Gateway. Installation
is simple, as Expanders only require a connection to 12VDC power supply. AL-IME2-EXP Ex-
panders are cost-effective, easier to wire than conventional Gateways, and feature a simplified
'Plug and Play' setup where the Networx system automatically identifies all newly powered Ex-
panders and quickly determines the best wireless signal pathways. Up to 7 Expanders can be
added to one AL-IME2 series Gateway. The easy to install AL-IME2-PIE Plug-In Expander
can simply be powered by any ordinary 120VAC wall outlet. See OI391 for more information.
AL-IME2-PIE
AL-IM2-EXP

6
Lock Design Overview
Why Use Software inside a Lock?
With ordinary door locks, the need to make physical copies of metal keys and distributing them can be a
huge organizational and financial task -- and what will you do if someone causes a security breach by los-
ing their key?
The answer lies in the advantage of SOFTWARE. Software (also called "firmware") is not "hard" or "fixed"
like hardware is. Software is "soft" -- flexible and changeable to your needs. Software exists inside your
Alarm Lock™ series lock, and can be programmed (and re-programmed again and again) to suit your
changing requirements. No more metal keys to distribute...instead, distribute User Codes -- and delete
them from the lock software when needed. (A User Code is the software equivalent of a metal key--it is a
series of numbers the User enters into the door lock keypad to unlock the lock).
Preparing to Program your Lock
The keypad contains 12 buttons, numbers 1 through 9 plus zero, a star button (:) and a special "AL"
button (;). These 12 buttons are all you need to program your lock. In addition to using the keypad to
manually program your lock, you can also program your lock using a computer program named DL-
Windows. Using DL-Windows is not required--although it does make programming faster and easier. This
manual will show you how to program your lock manually, without DL-Windows. (For more information
about DL-Windows, see User Guide OI237).
Programming your lock begins after you unpack it from the box -- there is a specific procedure outlined in
the "Quick Start" (page 15) in which you "wake up" the lock to prepare it for programming. This "Quick
Start" procedure shows you all the steps required to get your lock to start working. To begin programming,
you must first enter something called "Program Mode".
What is Program Mode?
Most technical people find working with "hardware" easy--they use tools to make fixes or changes to hard-
ware. But with the software inside the lock, you enact changes (you "interface") using the keypad. The
software has only two "modes"--"Normal Mode" and "Program Mode". When you want to make changes to
the lock program (such as adding User Codes), you enter "Program Mode". When you finish programming
and wish to put the lock into use, you exit Program Mode to enter "Normal Mode".
You enter Program Mode using the keypad by pressing the Master Code of the lock that was set at the
factory. This Master Code is basically a secret passcode that allows you to enter Program Mode. But
since all locks are identical and leave the factory with the same Master Code, the factory Master Code is
therefore not very secret--and should be changed to your own personal Master Code. This way, only YOU
can enter Program Mode and make changes to your lock's programming.
Once the new Master Code is set , then you can continue with the Quick Start procedure and set the
weekday, date and time. After this, you can start entering User Codes for people to use. All changes to
the lock are organized by their Function Number. Want to change the date? Use Function Number 38.
Want to add a User Code? Use Function Number 2. There are 99 Functions in total, some that you will
use often, and others that you may never need.
Notice that when you program your lock, programming tends to follow a consistent 5-step pattern:
(1) Enter Program Mode (2) Press ;followed by the Function # (3) Press ;and enter data (4)
Press :to end your programming (5) Exit Program Mode.
Turn the page and learn about the special terminology used with your lock. Once that is clear, use the
Quick Start procedure on page 15 to help you get up and running.

7
Terminology Used in this Manual
What is a Lock Program?
A Lock Program contains the instructions that a lock uses to per-
form its various functions. You can use the keypad to create a
Lock Program that is stored within the lock. You can also use DL-
Windows (defined below) to create a Lock Program on your com-
puter, and then transfer and store the Program in the circuitry
contained inside the lock itself. The Lock Program is essentially a
computer database file that maintains feature settings, schedules,
audit trails, etc. Using DL Windows, Lock Programs can be creat-
ed with default information, edited on your PC, and then sent to
(and even received from) locks.
The Lock Program consists of 4 areas: User Codes, Features,
Time Zones, and Schedules, all defined below:
What are User Codes?
Also called User Access Codes or PIN No. Codes, User Codes
are numbers the User presses into the lock keypad to unlock the
lock. The User Codes are part of the Lock Program, and the Lock
Program is stored in the lock circuitry awaiting the Users to "key-
in" their User Codes.
What are Features?
Your lock is designed to support several options and functions.
Using the keypad or DL-Windows software (the Programmable
Features window), you can select the features you wish to
activate, such as if the lock will automatically adjust for Daylight
Saving Time in the spring and autumn, or if the lock sounder
should be disabled or enabled.
What is a TimeZone?
Events (recorded lock activities) can be programmed to occur at
certain times. It is these times (for example, "every Tuesday at
5pm") that are referred to as TimeZones. TimeZones can be
created manually through the keypad. In DL-Windows, you can
use the Schedule-TimeZone screen to create these Time-
Zones, and once created, you can link events to these Time-
Zones.
What is a Schedule?
Your lock can be programmed to maintain a schedule in which
certain events can occur automatically. For example, you can
program the lock to allow Groups of Users (with their User Codes)
access ONLY during specific business hours. With another ex-
ample, you can program another lock to UNLOCK at 9am, LOCK
at noon for lunch, UNLOCK at 1pm, and LOCK again at 5pm--
every weekday. As you can see, many different combinations of
Schedules can be created to suit the needs of the Users. First
you create TimeZones (see above). Next you create events and
link them to your TimeZones (also using the Schedule-TimeZone
screen in DL-Windows). When finished, you can view (in DL-
Windows) your schedule in the Schedule View screen.
What is a User?
A User is a person who is authorized to unlock, use or make pro-
gramming changes to the lock. This User can be anyone--from a
one-time visitor (who will almost certainly have no authority to
make programming changes) to the owner of the building in which
the lock is installed (who may wish to have total authority to make
changes to the lock programming). The PDL6300 lock can hold
up to 5000 Users in its programming memory, and each User
possesses a pre-defined level of authority--a Programming Level-
-as to their ability to use or make changes to the lock.
What is a Programming Level?
The Programming Level defines the range of programming tasks
a User is allowed to perform. The higher the Level, the more pro-
gramming tasks the User is allowed (with Master allowing ALL
tasks).
For example, PDL6300 Series locks can hold up to 5000 Users in
its programming memory, and each User is associated with a
User Number (see definition of "User Number" below) and there-
fore a specific Programming Level, as follows:
Master: Always associated with User Number 1. Is always
enabled and can program all functions. (Abbreviated as
Programming Level = M).
Installer: Always associated with User Numbers 2 and 3.
Can program all functions except changing the Master Code.
(Abbreviated as Programming Level = 4).
Manager: Always associated with User Numbers 4, 5, and 6.
Can program all functions except functions relating to lock
configuration. (Abbreviated as Programming Level = 3).
Supervisor: Always associated with User Numbers 7, 8 and
9. Can only program functions relating to day to day
operation. (Abbreviated as Programming Level = 2).
Print Only Users: In previous versions of the ALARM LOCK
Trilogy series locks, Print Only Users were always associated
with User Numbers 10 & 11 and were restricted to printing
event logs only, using a special AL-IR1 handheld printer. With
the PDL6300 series wireless lock no longer requiring (or
allowing) the use of this AL-IR1 printer, Print Only Users are
also no longer required. Although the attributes of User
Numbers 10 and 11 have been changed to replicate those of
"Basic Users", to ensure compatibility with previous lock
model versions, the use of User Numbers 10 and 11 with the
PDL6300 lock is not recommended.
Basic Users: Always associated with User Number 12 and
higher (except 297-300). No programming ability allowed.
Most Users are Basic Users, who are given their own personal
User Codes (and / or proximity credentials) and are only
allowed to simply unlock the lock.
Programming Levels are hierarchical--higher levels are allowed to
do anything the levels below them can do. For example, if you
are a Manager, you are allowed to do anything that Supervisors,
Print-Only Users and Basic Users can do in addition to those
tasks allowed for Managers (Level 3).
What is the Minimum Required Program Level?
This Programming Level abbreviation is the minimum program-
ming level required to access the particular Function. (The higher
the level number, the more programming tasks the User is al-
lowed, with Master allowing all tasks).
In this manual, Programming Levels for the PDL6300 series are
abbreviated as follows: M = Master, 4= Installer, 3= Manager, 2
= Supervisor, 1= Print Only Users
For the PDL6300 series, the Master is abbreviated with an "M",
and all other Levels are hierarchical, with higher levels being al-
lowed to do anything the levels below them can do. Therefore
Level 4 is "higher" than level 3. See page 9 for more information.
What is a User Number?
User Numbers are used and are significant within each individual
lock only. The User Number determines the Programming Level
for each User. For example, the PDL6300 series lock can hold
up to 5000 Users in its programming memory. This memory can
be thought of as simply a numbered list from 1 through 5000.

8
Each entry in the list is represented by a User Number. There-
fore, where a User is located in this list will determine their Pro-
gramming Level. Because of their similarities, the terms User
Number, User Location and Location Number can be used inter-
changeably. In some DL-Windows screens, the word "Slot" is
also used. They all mean the same thing.
Since User Numbers are fixed, knowing a User Number will
specify the associated Programming Level, and will in turn deter-
mine a User's programming abilities. For example, User Number
1 is always the Master, who can perform all programming tasks.
Programming Levels are hierarchical--higher levels are allowed
to do anything the levels below them can do. For example, if you
are User 2, you are allowed to do anything that Users 3 through
11 can do.
What is a Group?
With many lock applications, it is convenient for large numbers of
similar Users to be grouped together. Placing Users into Groups
(by assigning them specific User Numbers) allows large num-
bers of Users to be controlled all at once rather than individually--
saving time and effort. Groups are controlled via schedules, and
a typical example involves enabling or disabling a Group at a
certain time. Default Group associations are specified in the
tables on page 9. For example, if you wish to add a User to
Group 1, assign this User a User Number between 51 and 100.
These default Group associations can be changed if needed to
allow Groups larger than the default number of 50 (by using key-
pad Function 35). (See page 21 for Group function examples).
How do the Emergency Commands work?
For use with all 6300 series locks enrolled into the Trilogy Net-
worx™radio network, these wireless commands can be sent to
all locks in an Account during a crisis or other urgent situation.
By default, Administrative Users (Users 1-11) can send an
Emergency command. In addition, any User Code can be pro-
grammed to allow the use of these Emergency Commands by
simply adding that User Code to an "Emergency Users" list
within DL-Windows. When an enabled User Code is pressed at
any 6300 series lock keypad, first the 6300 series lock unlocks,
then the lock permits the use of these emergency commands to
be sent to all locks in the network, as follows:
 ...press 911 to issue "Emergency Lock
Down",to indefinitely lock all doors;
 ...press 000 to issue "Emergency Passage",
to indefinitely unlock all doors;
 ...press 123 to issue "Return to Normal" re-
turning all doors to "normal" (non-emergency) operation.
In addition, emergency commands may be sent via an RR-
4BKEYFOB. Note: 3 chirps sound after each emergency com-
mand entry. See page 11 and the DL-Windows User Guide
OI383, "Emergency Commands" for more information. Note:
DL-Windows does not need to be running to allow these
"Emergency" commands to be initiated; any 6300 series lock
keypad can be used to disseminate these commands through-
out the system.
Who are Users 297-300?
Users assigned to User Numbers 297, 298, 299 and 300 have
special abilities, as follows:
User 297: Quick Enable User 300
User 297 possesses the unique ability to enable the User
Code associated with User 300. User 297 does this by first
entering their own User 297 User Code into the lock keypad.
When User 300 subsequently enters their User 300 User
Code, the lock allows access (for one time) and then the Us-
er 300 User Code becomes disabled.
For example, you wish to allow one-time access to a tempo-
rary worker. Simply enter the User 297 User Code into the
lock keypad. Later, when the temporary worker enters the
User 300 User Code into the lock keypad, the User 300 User
Code allows access (for one time only) and then becomes
disabled. Later, if you wish to grant the temporary worker re-
access, simply re-enter the User 297 User Code and the
User 300 User Code will be re-enabled (again for one time
only). Note: From the factory, the User 300 User Code is
blank; when the User 300 User Code is added, it is automati-
cally enabled by default. In addition, each time Features or
Users are uploaded to the lock, the User 300 User Code is re
-enabled in ALL the locks in the Account.
User 298: Reserved
In previous versions of the ALARM LOCK Trilogy series
locks, User Number 298 initiated the sending of data to or
from the lock, and a special "AL-PCI" cable was used to
physically connect the lock to a PC running DL-Windows.
With the PDL6300 series wireless lock no longer requiring a
wired connection, User Number 298 is also no longer re-
quired and has been removed as an active code. Note that
the User 298 code does provide a "Guard Tour" type function
(logging the code entry with a time and date stamp in the
Event Log / Audit Trail), but to ensure compatibility with previ-
ous lock model versions, the use of User 298 with the
PDL6300 lock is not recommended. Note: User 298 is not
an access code (it is a "non-pass" code) and therefore does
not allow passage through the door. See "User 299: Guard
Tour Code" below.
User 299: Guard Tour Code
A Guard Tour Code is used to log the movement of a security
guard as he or she makes rounds from one assigned guard
tour station to the next. Entering the User 299 code provides
precise verification and accountability of a guard's movement
by logging the location with a time and date stamp in the
Event Log (Audit Trail).
Note: User 299 is not an access code (it is a "non-pass"
code) and therefore does not allow the security guard to pass
through the door.
User 300: One-Time Only Service Code
This is a One-Time Only Service User Code enabled by User
297. For example, User Code 300 is sometimes used for
guard tour duties. See User 297: Quick Enable User 300
above.
What is DL-Windows?
DL-Windows is a computer program that allows you to program
your ALARM LOCK T3 Security Lock. DL-Windows is not re-
quired to program your lock, but it makes programming much
faster and easier. With DL-Windows, you can quickly create
Lock Programs (programs that make the lock perform its many
functions) add multiple Users (who have access), add proximity
credentials, retrieve event logs, and create Schedules. The ben-
efit of DL-Windows is that it allows you to set up all lock program-
ming in advance (on your computer), and then later send the
information to the locks at your convenience.
Terminology Used in this Manual (cont'd)

9
The Programming Level defines the range of programming
tasks a User is allowed to perform. The higher the Level, the
more programming tasks the User is allowed (with Master
allowing ALL tasks).
For example, the PDL6300 series lock can hold up to 5000
User Codes in its programming memory, and each User Code
is associated with a User Number (see definition of "User
Number" in the previous "Terminology" section) and therefore
a specific Programming Level, as follows:
Master: Always associated with User number 1. Is al-
ways enabled and can program all functions. (Abbreviated
as Programming Level = M).
Installer: Always associated with Users 2 and 3. Can pro-
gram all functions except changing the Master Code.
(Abbreviated as Programming Level = 4).
Manager: Always associated with Users 4, 5, and 6. Can
program all functions except functions relating to lock
configuration. (Abbreviated as Programming Level = 3).
Supervisor: Always associated with Users 7, 8 and 9.
Can only program functions relating to day to day
operation. (Abbreviated as Programming Level = 2).
Print Only Users: In previous versions of the ALARM
LOCK Trilogy series locks, Print Only Users were always
associated with User Numbers 10 & 11 and were restricted
to printing event logs only, using a special AL-IR1
handheld printer. With the PDL6300 series wireless lock
no longer requiring (or allowing) the use of this AL-IR1
printer, Print Only Users are also no longer required.
Although the attributes of User Numbers 10 and 11 have
been changed to replicate those of "Basic Users", to
ensure compatibility with previous lock model versions, the
use of User Numbers 10 and 11 with the PDL6300 lock is
not recommended.
Basic Users: Always associated with User number 12 and
higher (except 297-300). No programming ability allowed.
Programming Levels are hierarchical--higher levels are al-
lowed to do anything the levels below them can do. For exam-
ple, if you are a Manager, you are allowed to do anything that
Supervisors, Print-Only Users and Basic Users can do in addi-
tion to those tasks allowed for Managers (Level 3).
Programming Levels
Lock Defaults for PDL6300
Users added will default to a Group Association and a Programming Level ability as follows:
USER TYPE USER NUMBER GROUP DEFAULT MINIMUM PROGRAM
Master Code 1 - M
Installer Codes 2 & 3 none 4
Manager Codes 4 - 6 none 3
Supervisor Codes 7 - 9 none 2
(Reserved--see "Print Only Users" above) 10 - 11 none --
Basic User Codes 12 - 50 none none
Basic User Codes Group 1 51 - 100 1 none
Basic User Codes Group 2 101 - 150 2 none
Basic User Codes Group 3 151 - 200 3 none
Basic User Codes Group 4 201 - 250 4 none
Basic User Codes 251 - 296 none none
Quick Enable User 300 Code 297 none none
(Reserved--see page 8) 298 none none
Guard Tour Code* 299 none none
Service Code 300 none none
Basic User Codes 301-5000 none none
*This code is a Non-Pass code and therefore does not allow passage through the door.

10
Programming Key Sequence.
Programming
Information
General Program Mode Information
If a wrong key is pressed during code entry, hold any key continuously until the error sound is heard (7 short beeps), this will clear the entry. Re-enter the key
sequence again.
All program sequences are followed by the :key; 2 short beeps indicate a successful program sequence.
Enabling/Disabling Users (By User Number)
3. Disable User ;3;[ _ _ _ ] :
4. Enable User ;4;[ _ _ _ ] :
User Number must be between 2 and 5000.
NOTE: Will Enable/Disable users even if the user is associated with an enabled Group.
2
Conventions Used in this Manual
LED and Sounder Indicators
Minimum Required Program Level
Program Levels are abbreviated as follows:
M= Master
4= Installer
3= Manager
2= Supervisor
1= Print Only Users
This Program Level abbreviation is the
minimum program level required to
access the particular Function. (The
higher the level, the more programming
tasks the User is allowed, with Master
allowing all tasks).
Function
Description
Function
Number Function Name
ACTIVITY LED SOUNDER COMMENTS
Keypress 1 RED Flash 1 Beep Normal Operation
Access Granted or Remote Release 2 GREEN Flashes 2 Beeps Valid credential (proximity credential, User
Code, Remote Input or Wireless Remote
Release)
Invalid Credential 7 RED Flashes 7 Beeps
Successful Program Entry 2 GREEN Flashes 2 Beeps When in Program Mode
Unsuccessful Program Entry 7 RED Flashes 7 Beeps When in Program Mode
Exit Program Mode 1 RED, 2 GREEN Flashes 10 Beeps
Valid but Disabled Credential 1 GREEN, 4 RED Flashes 1 long, 5 short beeps Credential exists in memory, but disabled
Low Battery See page 14 before changing batteries;
see Functions 52-54 for the definition of
"Pass Time"
Emergency Commands are in effect 1 Red Flash every
two seconds
Optional: Pulsing beep
(once per second) for
30 seconds
See page 11; also see OI382 and OI383
for more information.
RED LED and Sounder turn on steady for the duration
of the Pass Time
The PDL6300 series lock provides visual and audible keypad feedback. Note: Both the Primary and Secondary sides of the
PDL6300 each have red and green LEDs (the LEDs only flash on the side being used, except when Emergency Commands
are activated). With a fully charged battery, the LED and sounder feedback is as follows:

11
Emergency Commands
The PDL6300 series locks can be programmed to send and/or respond to Emergency Commands ("Emergency Lock
Down", "Emergency Passage" and "Return to Normal"). Emergency Commands can be initiated directly from the
lock's keypad, initiated from an RR-4BKEYFOB Wireless Remote Release or initiated from the Networx server running DL-
Windows. (Note: "Emergency Passage" is not available with the Wireless Remote Release). Emergency Com-
mands are available in two types: "Global" or "Local".
 With "Global Emergency Commands", activating the Emergency Command changes the state of all locks in the entire
system.
 With "Local Emergency Commands", only the lock that initiates the Emergency Command will change state; activating
the Emergency Command does NOT change the state of all locks in the entire system.
For more information about how Emergency Commands work with your ENTIRE system, see the DL-Windows for Networx
User's Guide (OI383).
Understanding "Global" vs. "Local"
The following features should be understood before using Emergency Commands with your PDL6300. Below describes
the various features available for Global Emergency Commands or Local Emergency
Commands, or combinations of both.
TIP: If using an RR-4BKEYFOB Wireless Remote Release, before reading this page,
we recommend that you read the documentation that came with it, and also the "Wireless
Remote Releases" section on page 13.
Receiving Emergency Commands
Lock Responds to Global Emergency Commands
 When enabled: The lock WILL accept and adhere to Emergency Commands
that disseminate from another lock or from DL-Windows. Note: This feature does
not need to be enabled (checked) for the lock to accept commands from an RR-
4BKEYFOB Wireless Remote Release.
 When disabled: The lock WILL NOT accept nor adhere to Emergency Com-
mands that disseminate from another lock or from DL-Windows. CAUTION: Dis-
abling (un-checking) this feature could be of great consequence for the safe ad-
ministration of your Networx system.
Activating Global Emergency Commands
Keypad initiates Global Emergency Commands: When enabled (checked),if an Emergency Command is initi-
ated from the keypad, the lock will first inform the Gateway to broadcast the Emergency Command to all locks as-
signed to the same "Gateway Group", then the lock will respond to that Emergency Command accordingly (if
the above "Lock Responds to Global Emergency Commands" is enabled).
Keyfob initiates Global Emergency Commands: When enabled (checked), if an Emergency Command is initi-
ated from an RR-4BKEYFOB Wireless Remote Release, the "paired" lock will first inform the Gateway to broadcast
the Emergency Command to all locks assigned to the same "Gateway Group", then the paired lock will respond
to that Emergency Command accordingly (if the above "Lock Responds to Global Emergency Commands" is ena-
bled).
Note: See OI383 for more information about Gateway Emergency Groups.
Activating Local Emergency Commands
Keypad initiates Local Emergency Commands: When enabled (checked), if an Emergency Command is initi-
ated from the keypad, the lock will immediately change state accordingly. The Emergency Command will NOT be
sent to the Gateway and therefore will NOT be sent to other locks in the system.
Keyfob initiates Local Emergency Commands: When enabled (checked), if an Emergency Command is initi-
ated from an RR-4BKEYFOB Wireless Remote Release, the paired lock will immediately change state accordingly.
The Emergency Command will NOT be sent to the Gateway and therefore will NOT be sent to other locks in the
system.
TIP: Combining Global and Local Features: You can combine the various Global and Local Emergency fea-
Emergency Commands

12
tures to customize your system.
Example #1: DL-Windows by default enables (checks) all of the features, as shown above in the Features dialog.
What will happen when all features are enabled and an "Emergency Lock Down" command is initiated at the keypad?
Because the Activate Local Emergency commands are enabled, the lock that initiates the Emergency Command will
lock down, then the lock will inform the Gateway to broadcast the Emergency Command to all locks assigned to the
same "Gateway Group".
Example #2: This example is known as the "pull station option", where one of the Activate Global Emergen-
cy commands is checked, none of the Activating Local Emergency commands are checked, and the "Lock
Responds to Global Emergency Commands" is unchecked. If an "Emergency Lock Down" command is initi-
ated at a lock keypad, the lock will first inform the Gateway to broadcast the Emergency Command to all locks as-
signed to the same "Gateway Group", then the lock will ignore the broadcast when received.
Emergency Users
Activating Emergency Commands
By default, Administrative Users (Users 1 through 11) automatically have the ability to initiate Emergency Commands
from the keypad. In addition, "Basic Users" (Users 12+) may be granted the ability to initiate Emergency Commands
from the keypad by adding them as Emergency Users in DL-Windows (for more information about adding Emergency
Users in DL-Windows, see OI383). Note: All paired Wireless Remote Releases have the ability to initiate Emergen-
cy Commands (see page 13 for more information).
Access During an Emergency
 When enabled: If the feature Users are Disabled During Lockdown is enabled (checked) for a specific
lock, and when the Networx system is in an Emergency Lock Down state, "Basic Users" (Users 12+) are de-
nied the ability to unlock the physical lock (User Codes / proximity credentials for these Basic Users are ig-
nored). The User Codes / proximity credentials added to Administrative Users (Users 1 through 11) as well as
all "Emergency Users" remain enabled, retaining the ability to unlock a secured lock.
 When disabled: If the feature Users are Disabled During Lockdown is disabled (unchecked)for aspe-
cific lock, and when the Networx system is in an Emergency Lock Down state, ANY valid User Code or proxim-
ity credential that exists in the lock's internal memory will be allowed to unlock the secured lock, regardless of
User Number.
Emergency Alert Options
Sounder
If Enable Sounder on Emergency is enabled (checked), upon receiving an Emergency Command, the integral sound-
er will beep once per second for 30 seconds.
Tip: Only "Local" Emergency Commands are supported when using an AL-IME-USB Gateway . See page 4
for Gateway model descriptions.
Emergency Commands (cont'd)
When a User Code from an Administrative or Emergency User is pressed at any 6300 series lock keypad,
first the 6300 series lock unlocks, then the lock permits the use of the following Emergency Commands:
...press 911 to issue "Emergency Lock Down"
...press 000 to issue "Emergency Passage"
...press 123 to issue "Return to Normal"
[ _ _ _ _ ]
Administrative
or
Emergency User
Code

13
Overview
Two types of "Wireless Remote Release" devices are compatible with the PDL6300 series door lock:
The RR-1BUTTON Wireless Remote Release Button (see WI1999) and RR-4BKEYFOB Wireless Re-
mote Release Keyfob (see WI2004). Whether the Wireless Remote Release contains a single button
(RR-1BUTTON) or four buttons (RR-4BKEYFOB), each button can be "paired" (connected) with one
PDL6300 series lock. This means, for example, the four buttons on the RR-4BKEYFOB can each
be paired with four separate PDL6300 series locks. In addition, each individual PDL6300 series lock con-
tains ten (10) "slots" ("User Numbers"), and each "slot" is available to accommodate one paired Wireless
Remote Release button. Therefore, each individual PDL6300 series lock can ultimately be paired with up
to ten Wireless Remote Release buttons on multiple Wireless Remote Release devices.
Note: Since each button can ONLY be paired with one specific PDL6300 lock at a time, when a
previously paired button is later paired with a second locking device, the first pairing is erased.
Before you "pair" (connect) your Wireless Remote Release buttons, be sure to consider the following:
 Wireless Remote Releases can be paired before a lock is enrolled into a Networx system. However, to allow for
lock discovery, the lock must be defaulted and re-initialized (see ERASE ALL PROGRAMMING on page 14),
clearing all previously programmed Users and/or paired Wireless Remote Releases.
Pairing Wireless Remote Release Buttons
Refer to the programming instructions included with the model RR-1BUTTON Wireless Remote Release Button (see
WI1999) and/or the model RR-4BKEYFOB Wireless Remote Release Keyfob (see WI2004).
Emergency Lock Down (via Wireless Remote Release)
The PDL6300 series lock has the added ability to accept Emergency Lock Down commands from a Wireless Remote
Release (model RR-4BKEYFOB only). Using the RR-4BKEYFOB, when buttons 3 and 4 are pressed simultaneously,
within seconds an Emergency Lock Down command is sent to all locks to which the RR-4BKEYFOB is currently
paired (up to 4). Conversely, pressing buttons 1 and 2 simultaneously will send a Re-
turn to Normal command, returning the paired locks back to the state they were in prior
to receiving the Emergency Lock Down command.
See page 11 for the two different modes (see the section "Global" vs. "Local") to which
the PDL6300 series lock will respond when an Emergency Command when sent from a
Wireless Remote Release.
Wireless Remote Releases
RR-4BKEYFOB
RR-1BUTTON
RR-4BKEYFOB

14
WIRING
See the Installation Manual for more information.
Batteries:
 Use four 1.5V size-AA alkaline batteries
-- or --
 For longer life and better performance in sub-freezing tem-
peratures, use four 1.5V size-AA Eveready lithium batteries
POWER UP
 When applying power to the lock for the first time, stop
and follow the procedure outlined in "Quick Start, First time
Power Up" on page 15.
 When power is re-applied to a lock that was already op-
erational, proceed as follows:
1. Disconnect battery pack connector.
2. With battery power disconnected, press and hold
down ;for 10 seconds to insure discharge of all ca-
pacitors.
3. Re-connect battery pack (lock will sound 3 short beeps). If
beeps are not heard, then begin again at step 1.
4. Do not press any keys for 15 seconds.
5. After 15 seconds, the LED will flash red 6 times and 6
beeps will sound.
The lock is now ready for use. The pre-existing program is
loaded from fixed memory. Set the clock using functions 38,
39 and 40.
ERASE ALL PROGRAMMING
RESTORE FACTORY DEFAULT (original "out of box" set-
tings that were set at the factory will be loaded).
1. Enter the current Master Code (if not known, proceed
directly to ALTERNATIVE METHOD, below). Wait for the
green light and press ;until multiple beeps are heard.
You are now in Program Mode.
2. Press ;99 ;000 :.
3. Listen for 6 beeps. The lock will re-lock. All settings
and programming have been erased. Proceed directly to
page 15, Quick Start, and follow the procedure "Enter
Program Mode and Change Factory Master Code".
ALTERNATIVE METHOD (Master Code not known)
1. Remove the Secondary side handle.
2. Disconnect the battery pack.
3. Remove the screws from the Secondary side mount-
ing plate and screws from Secondary side rose plate.
4. Remove the Primary side body from the door to allow
access to the electronics. Remove the Primary side back
plate by unscrewing the four flat head Phillips screws.
5. Locate the Reset Cable (2 yellow wires with a black
connector, soldered into the Primary side PC board). In
the hardware package, locate the Reset Shunt Cable
(single yellow wire loop with a black connector).
Plug the Reset Shunt Cable into the Reset Cable.
Wiring and Power Up
6. Press and hold down ;for 10 seconds (to ensure all
power is drained from the lock) and release.
7. Connect the batteries and listen for 3 beeps. After
hearing the 3 beeps, you have 3 seconds to press and
hold ;. After hearing 6 additional beeps, re-
lease ;. Note: If you do not hear the 3 beeps after
connecting the batteries, you must start over at step 2.
Always be sure to follow this exact procedure.
8. Test by pressing the default Master Code of 123456 (a
beep will sound and the lock will unlock). Note: We rec-
ommend leaving the shunt wire off for security. With the
wire on, the lock can be reset.
9. Reinstall the Primary mounting plate with 4 flat head
Phillips screws. Run the main cable harness and motor
wires through the door.
Install the Secondary rose plate and the Secondary mount-
ing plate. Carefully route the motor wire through the slot in
the rose plate and into the motor cable notch without
pinching or cutting the wire. Reinstall the Secondary hous-
ing and handle.
See installation instructions for more details.
All settings and programming have been erased. Proceed
directly to page 15, Quick Start, and follow the procedure
"Enter Program Mode and Change Factory Master
Code".
BATTERY REPLACEMENT
When a key is pressed (or a proximity credential is present-
ed) and the batteries are weak, the red LED will light and a
steady tone will sound for the duration of the Pass Time
("Pass Time" is the duration the lock remains unlocked after a
valid credential allows access to be granted).
Use four (4) AA-size 1.5 volt alkaline batteries. Always re-
place weak batteries as soon as possible.
CAUTION: Do not press any keys while batteries are
disconnected or you may erase the real-time clock set-
tings.
1. Loosen battery door screw by turning counterclockwise 2
turns only (turning more will unscrew the screw from the
battery door).
2. Pull out the battery pack and quickly replace batteries -
within 1 minute.
3. If you do not hear the 3 beeps when power is re-applied,
all programming and settings have been retained, and the
lock is ready for use. Go to step 5.
4. If you do hear 3 beeps when power is re-applied, do not
press any keys for 15 seconds. After the 15 second
period, the LED will flash red 6 times and 6 beeps will
sound. Reset the clock using DL-Windows or functions
38, 39 and 40.
5. Replace the cover and gently tighten the screw.

15
Quick Start
First Time Start Up
1. Unpack the lock.
2. With the batteries disconnected, hold down the ;key for 10 seconds and release.
3. Connect the batteries and listen for 3 beeps. Within 5 seconds of hearing the 3 beeps, press and hold ;until beeping
starts. This will clear the lock of all programmed data. Important: If you do not hear these 3 beeps, you must start over at
step 2.
4. Listen for another series of beeps and LED flashes followed by 10 seconds of silence. The lock is now ready to program.
Failure to follow this exact procedure can result in erratic lock behavior. Important Note: When entering any key sequence
below, do not pause more than 25 seconds between any key presses--otherwise you must start again.
Enter Program Mode and Change Factory Master Code
Keypad programming may be performed on either side of the lock (on either keypad).
1. Press the default Master Code: 123456.
2. Wait for the green light and press ;until multiple beeps are heard. You are now in Program Mode.
Note: The lock will beep every 6 seconds as a reminder that you are in Program Mode.
3. Enter a new personal 6-digit Master Code number by pressing the following keys:
;1;[new Master Code] ;[new Master Code] :(the second set of digits must be exactly the same).
(For example, if you want your new Master Code to be "664433". Press:
;1;664433 ;664433 :).
Now that the Master Code has been changed, there is no need to change it again (unless you want to). Since you are
still in Program Mode, you can now proceed directly below and program various functions. Note: Programming any
Function, such as setting the clock, follows a consistent 5-step pattern: (1) Enter Program Mode (2) Press ;
[Function #] (3) Press ;and enter data (4) Press :to end (5) Exit Program Mode.
Note: There is a 3minute Program Mode timeout if no keys are pressed when in Program Mode. A steady tone will
sound for the final 15 seconds of the 3 minute timeout period as a warning. To remain in Program Mode, press any key.
Set the Weekday
1. Enter Program Mode (if not in already).
2. Press ;40 ;[number of weekday] :. (Use 1= Sunday, 7 = Saturday).
(For example - Friday - press ;40 ;6:).
Set the Date
1. Enter Program Mode (if not in already).
2. Press ;38 ;[MMDDYY] :.
(For example - May 10, 2002 - press ;38 ;051002 :).
Set the Time
1. Enter Program Mode (if not in already. If you just finished the above procedure, you are still in Program Mode).
2. Press ;39 ;[HHMM]:. (Use 24-hour military format, where PM adds 12 hours).
(For example - 2:30pm - press ;39 ;1430 :).
Enter User Codes
1. Enter Program Mode (if not in already).
2. Press ;2;[User Number] ;[new User Code] :.
(For example, John Smith is designated as User 21. You want him to use the code of "232323" to unlock the door.
Program the lock by pressing: ;2;21 ;232323 :).
3. Repeat step 2 for each new user.
Delete a User Code
1. Enter Program Mode (if not in already).

16
Quick Start (cont'd)
2. Press ;2;[User Number]:.
The lock will flash a green LED and beep continuously for 6 seconds. When the red LED flashes, the User Code is deleted.
3. Repeat step 2 for each new User.
User Code Conflicts
Care should be taken not to program a new User Code which matches the first digits of any other User Code (only the User
Code with the least number of digits will be recognized). Example: If User Codes 123 and 123456 are both entered in the
system, only code 123 would be recognized, unless the ENTER Key has been enabled (see Function 69, see page 29). In
addition, an error will sound if you try to program a new User Code that matches the first digits of the Master Code.
WARNING: When attempting to change an existing Master Code, it is HIGHLY recommended that you enable all
Groups (see Function 23 on page 21), exit Program Mode, and enter the new anticipated Master Code to verify that the
anticipated sequence does not currently open the lock. If the lock does not open, the anticipated Master Code can be
used as the new Master Code; if the lock opens, the anticipated Master Code already exists in the lock (as a User
Code), and the anticipated Mater Code should NOT be used. Always repeat this procedure with any new anticipated
Master Codes.
Enroll Proximity Credentials at the Lock -- ("Single Enrolling" or "Batch Enrolling")
If you wish to enroll only one proximity credential ("Single Enrolling") or many ("Batch Enrolling"), the process is basically
the same. Keypad programming may be performed on either side of the lock (on either keypad or proximity reader).
1. Enter Program Mode (if not in already).
2. Press ;2;[User Number] :. (Enter the User Number you wish to match with the proximity credential).
3. Lock will beep continuously. Place a new proximity credential in front of the Prox reader (under the lock keypad).
When the lock beeps three times, the proximity credential has been enrolled.
4. Press ;to end the process. To return to normal operation, exit Program Mode (see below).
(For example, you wish to enroll two proximity credentials for User 14 and User 15 respectively. Press ;
2;14:. and place the first proximity credential in front of the reader (hear 3 beeps) and then
within 10 seconds, place the second proximity credential in front of the reader (hear 3 beeps)).
You can continue entering proximity credentials in this way, automatically incrementing the User number with each
presentation of a proximity credential. When finished, press ;.
Note: Batch Enrolling will not program Users 297 through 300, as these are Special Function User Codes. After
a proximity credential for User 296 has been Batch Enrolled, the next proximity credential presented will enroll as
User 301.
High Security Access (Proximity Credential & User Code Access)
Program the lock for High Security Access for User Number 15, with a proximity credential and a User Code of 7452 required
for access:
1. Enter Program Mode (if not in already).
2. Press ;2;15:.
3. Lock will beep continuously. Place a new proximity credential in front of the Prox reader (under the lock keypad). When
the lock beeps three times, the proximity credential has been enrolled.
4. Press ;2;15;7452:.
In order for User 15 to open the Lock, a User Code must be entered and a proximity credential must be presented to the
PDL6300 Lock. User may enter code or present the proximity credential in either order to open the lock. The sounder will beep
for up to 10 seconds, waiting for the User to enter their User Code and present their proximity credential.
Delete a High Security Access Code
Note: Deleting a proximity credential associated with a User number will also delete the User Code programmed for that
User Number. Delete the proximity credential by not presenting any proximity credential for enrollment, as follows:
1. Enter Program Mode (if not in already).
2. Press ;2;[User Number] :(enter the User Number matched to the proximity credential you want to de-
lete).
3. Lock will beep continuously. Do not present ANY proximity credential during this step. Wait until lock stops beeping,
about 10 seconds.
4. Press ;to end

17
Verifying Basic Keypad User Codes
Test a valid User Code as follows:
 VALID CODE - The green LED will flash momentarily and the sounder will beep a few times after a valid code is
entered.
 INVALID CODE - The red LED will flash several times and the sounder will beep several times after an invalid code is
entered. Use Function 2 to re-program the code.
Verifying Proximity Credential (or Keyfob) Access
Test a programmed proximity credential (ProxCard®or ProxKey®Keyfob) as follows:
Simply present the programmed proximity credential to the proximity reader in the front of the lock.
 VALID PROXIMITY CREDENTIAL - The green LED will flash momentarily and the sounder will beep a few times after a
valid proximity credential has been presented to the lock.
 INVALID PROXIMITY CREDENTIAL - The red LED will flash several times and the sounder will beep several times after an
invalid proximity credential has been presented to the lock. Use Function 2 to re-program the credential.
Verifying High Security Access (Proximity Credential + User Code)
Test proximity credential programmed for High Security Access. A proximity credential and User Code are both required for
access.
1. Enter the User Code for the User Number programmed for High Security Access. The sounder will beep slowly for up to
10 seconds.
2. Present the
proximity credential programmed for the same User Number.
User may enter the User Code or present the proximity credential in either order to open the lock. The sounder will beep for up
to 10 seconds, waiting for the User to enter User Code or to present the proximity credential. Note: Do not present the prox-
imity credential and enter the User Code simultaneously.
Exit Program Mode
Hold Down any key for 3 seconds. Program Mode exit is confirmed by several beeps. You are now in normal operation.
Re-enter Program Mode
If you wish to re-enter Program Mode, key-in your new 6-digit Master Code, and press ;.
You are now ready to mount and install your PDL series lock and give out your User Codes. Before installation, it is suggested
you test and verify that all User Codes entered are active (see below).
Testing the Codes Entered

18
Function 1 Change Master Code See page 19
Function 2 Add/Delete/Change User Codes See page 19
Function 3 User Disable (By User Number) See page 20
Function 4 User Enable (By User Number) See page 20
Function 5 User Enable with Timeout See page 20
Function 6 Enable Total User Lockout See page 20
Function 7 Disable Total User Lockout See page 20
Function 8 Exit Program Mode See page 20
Function 9 Enable User 300 (Service Code) See page 20
Function 10 Erase All Users Except the
Master Code See page 20
Function 11 Reserved --
Function 12 Clear All Schedules and Timeout
Functions See page 21
Function 13 Clear All Timeout Functions See page 21
Function 14 - 17 Group 1-4 Disable See page 21
Function 18 Disable All Groups See page 21
Function 19 - 22 Group 1-4 Enable See page 21
Function 23 Enable All Groups See page 21
Function 24 Reserved --
Function 25 - 28 Group Disable with Timeout See page 22
Function 29 Disable All Groups with Timeout See page 22
Function 30 - 33 Group Enable with Timeout See page 22
Function 34 Disable All Groups with Timeout See page 22
Function 35 Group Add/Delete Association See page 22
Function 36 - 37 Reserved --
Function 38 Set Date See page 23
Function 39 Set Time See page 23
Function 40 Set Weekday See page 23
Function 41 Daylight Saving Time Start Date See page 23
Function 42 Daylight Saving Time End Date See page 23
Function 43 Speed Up Clock See page 24
Function 44 Slow Down Clock See page 24
Function 45 - 46 Passage Mode Enable/Disable See page 24
Function 47 Timed Passage Mode See page 24
Programming Functions--Overview
Function 48 Enable Passage Mode See page 25
Function 49 Disable Passage Mode See page 25
Function 50 Return Lock to Normal Passage
Mode Schedule See page 25
Function 51 Passage Mode Configuration See page 25
Function 52 - 54 Pass Time See page 25
Function 55 Reserved -
Function 56 Reserved -
Function 57 Reserved -
Function 58 Reserved -
Function 59 Reserved -
Function 60 Number of Attempt Before
Lockout See page 27
Function 61 Set the Attempts Lockout Time See page 27
Function 62 Add/Delete/Change User Codes
(for Primary Side code entry) See page 27
Function 64 - 65 Disable/Enable Remote Input See page 27
Function 66 Reserved -
Function 67 Add System Features See page 28
Function 68 Delete All Features added by
Function 67 See page 28
Function 69 - 70 Enable/Disable Enter Key See page 29
Function 71 Reserved --
Function 72 - 73 Scheduled Enable/Disable
Passage Mode See page 29
Function 74 - 77 Schedule Enable Group 1 - 4 See page 29
Function 78 Schedule Enable All Groups See page 29
Function 79 - 82 Schedule Disable Group 1 - 4 See page 29
Function 83 Schedule Disable All Groups See page 29
Function 84 - 87 Quick Schedules - Enable Group See page 30
Function 88 Passage Mode
(Open Time Window) See page 30
Function 89 Passage Mode
(Close Time Window) See page 30
Function 90 Reserved --
Function 91 Reserved --
Function 92 Enable Group 4
(Open Time Window) See page 31
Function 93 Enable Group 4
(Close Time Window) See page 31
Function 94 - 98 Reserved --
Function 99 Clear All Lock Programming See page 31
Function 63 Add/Delete/Change User Codes
(for Secondary Side code entry) See page 27

19
1. New Master Code (User Number 1) ; 1 ; [ _ _ _ _ _ _ ] ; [ _ _ _ _ _ _ ] :
(New Master Code) (Confirm New Master Code)
 Master Code must be 6 digits only (cannot be a proximity credential).
 Factory Default = 123456 (see page 6 for more information)
 User Number must be between 2 and 5000.
 User Codes added with this feature are enabled to pass from either side of the lock. To add User Codes for use with only the Primary
side or only the Secondary side, see Functions 62 and/or 63.
 To delete a User Code or proximity credential, leave the User Code blank and wait for the rapid beeping to stop, then to avoid erroneously
enrolling proximity credentials, press and hold any keypad key for 3 seconds to exit Program Mode (exit is confirmed by several beeps). If
more programming is desired, re-enter Program Mode.
 User Code must be 3-6 digits.
 Each User Code can be thought of as a person. As long as each person possesses their own unique User Code, you can control access to
the lock by adding or deleting User Codes. See "Terminology Used in this Manual" on page 7 for more information.
3
M
Programming Functions
Lock Defaults for PDL6300
Users added will default to a Group Association and a Programming Level ability as follows:
USER TYPE USER NUMBER GROUP DEFAULT
ASSOCIATION MINIMUM PROGRAM LEVEL (See page 7)
Master Code 1 - M
Installer Codes 2 & 3 none 4
Manager Codes 4 - 6 none 3
Supervisor Codes 7 - 9 none 2
(Reserved--see "Print Only Users", page 9) 10 - 11 none --
Basic User Codes 12 - 50 none none
Basic User Codes Group 1 51 - 100 1 none
Basic User Codes Group 2 101 - 150 2 none
Basic User Codes Group 3 151 - 200 3 none
Basic User Codes Group 4 201 - 250 4 none
Basic User Codes 251 - 296 none none
Quick Enable User 300 Code 297 none none
(Reserved--see page 8) 298 none none
Guard Tour Code* 299 none none
Service Code 300 none none
Basic User Codes 301-5000 none none
*This code is a Non-Pass code and therefore does not allow passage through the door.
2. Adding and Deleting User Codes and/or Proximity
Cards (for User Numbers 2-5000)
; 2 ; [ _ _ _ _ ] ; [ _ _ _ _ _ _ ] :
(User Number) (User Code)
(Deleting Entire User) ; 2 ; [ _ _ _ _ ] :[Beep Beep Beep]
(Wait 10 seconds for
beeping to end)
(User Number)
(Entering a Proximity Card) ; 2 ; [ _ _ _ _ ] :[Beep Beep Beep]
(Present card to reader
within 10 seconds)
(User Number)
(Entering a "User Code" / "PIN No. Code" into the lock programming)

20
USERS (Continued)
; 6 :
6. Enable Total User Lockout Mode
(This Function enabled through keypad only)
7. Disable Total User Lockout Mode
(This Function enabled through keypad only) ; 7 :
User Lockout Mode
Prevents all User Codes (Except User 1 Code) from operating the lock. Note: No other programming
functions or schedules will re-enable Users. Users must be re-enabled with Function 7.
Note: Does not change the User enable/disable status. Note: If the lock is currently in Passage
Mode (door "unlocked") and Function 6 is programmed, the lock will remain in Passage Mode.
M
5. User Enable with Timeout
(Enter Timeout, XXX Hours)
(This Function enabled through keypad only)
; 5 ; [ _ _ _ _ ] ; [ _ _ _ _ ] :
(User Number) (XXX Hours)
 With Function 5, User Numbers must be between 2-5000; hours must be between 1-999.
 Function 5 can temporarily override a disabled User (disabled using Function 3 above).
 Since this is a temporary feature, Function 5 can only be enabled using the keypad.
 Example: Brian, User Number 1157, rarely works at the office, but when he does, enable him for his 8 hour work day by
entering Program Mode and pressing: ;5;1157 ;008 :.
 NOTE: Up to 4 Timeout Functions may be pending at any one time. An error beep will sound when attempting to program more
than 4 Timeout Functions.
2
Service Code is a One-Time-Only Code. Once it is used, it is disabled until enabled again.
NOTE: User Number 297 is used to reset Service Code Use. See "Terminology Used in
this Manual" on page 8 for more information and examples regarding special Users 297-300.
; 9 :
9. Enable User 300 (Service Code)
2
; 1 0 ; 0 0 0 :
10. Erase All Users Except the Master Code (User 1)
(This Function enabled through keypad only)
Erases all User Codes except the Master Code (User 1).
 Function 10 can only be performed using the keypad. M
11. Reserved
3. Disable User ; 3 ; [ _ _ _ _ ] :
(User Number)
4. Enable User ; 4 ; [ _ _ _ _ ] :
(User Number)
User Enable/Disable (By User Number)
 User Number must be between 2 and 5000.
NOTE: Will Enable/Disable Users even if the User is associated with an enabled Group. Use Feature 3 to disable a specific User
Number and their associated User Code. If the disabled User Code is entered, the lock will flash 1 Green and 4 Red Flashes (with
1 long and 5 short beeps) indicating that the User Code exists in memory, but is disabled. Function 4 will "undo" Function 3.
Programming Functions (cont'd)
Allows Program Mode exit for keypads without hold-down functionality, such as some Wiegand readers with integral keypads. 3
; 8 :
8. Exit Program Mode
2
