Alarm Lock Sirenlock 710 User manual

Sirenlock: 250/260 & 700/710
• Deadbolt and deadlatch meet relatching
requirements
• Blaring 95db dual tone Piezo alarm
• Selectable 2-minute alarm or constant alarm
• 9V battery powered and audible low battery warning
• Meets or exceeds UL, CFM, ADA, NYC housing
requirements
• 250/700 Models have changeable 2 minute alarm
cutoff or manual reset
• 260/710 Models have changeable 2 minute auto
reset or manual reset
• 700/710 Models available in 33” and 48” versions
and are MEA approved
• Model 700 available in red, duronodic or aluminum
nishes. Models 250, 260 and 710 available in
aluminum nishes only
• Non-handled surface installations on single or
double doors
Clapper plate & full
door exit style alarms
Sirenlock™
Model 250/260
Sirenlock™ Model 700/710

345 Bayview Ave., Amityville, New York 11701
1-800-ALA-LOCK •Fax [phone]
www.alarmlock.com
NAPCO 7/2007 ALA108C
Sirenlock 700/710
Delayed Egress Exit Alarms
DIMENSIONS:
(WxHxD): 33” x 8 1/2” x 3 1/4”
(48” bar available; use for glass doors)
WEIGHT: 11lbs
SHIPPING WEIGHT: 12lbs
MOUNTING HEIGHT: Center of unit should be approximately
38” from floor
OPERATING TEMPERATURE: 20˚F to 135˚F (-7˚C to 57˚C)
SPECIAL FEATURES:
700 Models have changeable 2-minute alarm cutoff or manual
reset. 710 Models have changeable 2-minute auto reset or
manual reset
STANDARD FEATURES:
• Non-handled surface installations on single or double doors.
• Audible low battery warning and cam for exterior key control.
• Low activation pressure. Includes door warning sign.
POWER: 9VDC Alkaline Battery (use optional “AC9” or “PP100”
for AC power with battery backup). Current (Standby) - 7 Micro
Amps typical.
BATTERY LIFE: One year standby typical; 200 Alarm sequences
typical; constant alarm 7 hours typical
LOCK BOLT: 1” throw - Heavy die cast zinc alloy with reinforced
steel inserts
DIE-CAST COVER FINISHES: US28 Aluminum or US312
Duronodic; AL Red (700 only)
PUSH BAR: Extruded Aluminum Channel with Push Bar
SOUND PRESSURE: 95dB Dual Piezo Horn (measured at 10’)
Sirenlock 250/260
Clapper Plate Style Exit Alarms
DIMENSIONS:
(WxHxD): 18” x 8 1/2” x 3 1/4” (24”W when using extended
clapper plate)
WEIGHT:9lbs SHIPPING WEIGHT: 10lbs
MOUNTING HEIGHT: Center of unit should be approximately
38” from floor
OPERATING TEMPERATURE: 20˚F to 135˚F (-7˚C to 57˚C)
SPECIAL FEATURES:
250 Models have changeable 2-minute alarm cutoff or manual
reset. 260 Models have changeable 2-minute auto reset or
manual reset
STANDARD FEATURES:
• Non-handled surface installations on single or double doors.
• Audible low battery warning and cam for exterior key control.
• Low activation pressure. Includes door warning sign.
POWER: 9VDC Alkaline Battery (use optional AC9 or PP100
for AC power with battery backup). Current (Standby) - 7 Micro
Amps typical.
BATTERY LIFE: One year standby typical; 200 Alarm sequences
typical; constant alarm 7 hours typical
LOCK BOLT: 1” throw - Heavy die cast zinc alloy with reinforced
steel inserts
DIE-CAST COVER FINISHES: US28 Aluminum
SOUND PRESSURE: 95dB Dual Piezo Horn (measured at 10’)
