ALC AWSC35 User manual

Front cover INTERIOR
FO LD
FO LD
11.69”
PRINTED ON A4 SIZE SHEET (8.25X11.69”) folded in half
Model AWSC35
Wireless Video Surveillance System
BACK cover
Wireless Made Simple.
QUICK START GUIDE
ACCESSORY
Compatible with ALC AWS3155 and AWS3266
Video Surveillance Systems
CAMERA MOUNTING
NOTE: Cameras are IP66 rated for indoor/outdoor use. For outdoor use it is
recommended to install camera under shelter to protect from direct exposure to
sunlight and other environmental elements. Avoid pointing a camera directly at
any bushes or tree branches or objects that may naturally move due to winds.
CAMERA INSTALLATION + SETUP
1 2 43
Tip: Plan the location of your camera for optimal viewing and proximity to AC Power outlets, (1) power extension
cable is included.
NOTE: Avoid installing in a location which requires the Wireless signal to pass through cement, concrete and metal
structures. This will reduce the transmission range.
Secure the multi-position
camera stand to a stable
surface, ceiling or wall.
Loosen the T-Bolt on the camera
stand and adjust viewing angle using
the Thumb Screw to rotate position.
Align hole on bottom of camera
with T-Bolt to install camera.
Screw antenna into rear of camera.
Attach power cable to power
extension cord AC Adapter.
Plug into electric outlet.
Indoor/Outdoor Camera
Outdoor camera with
multi-position stand
AC power adapter
Power extension cable
Camera Installation
Screw Pack
Quick Start Guide
IN THE BOX
Let’s Get Started
Model AWSC35
REQUIRES ALC AWS2155 WIRELESS SURVEILLANCE SYSTEM TO WORK.
For detailed installation and setup, please refer to the Model AWSC35
extended User’s Guide available on our website:
www.atomslabs.com/support
SCAN
TO VIEW COMPLETE USER’S GUIDE
Wireless Outdoor
Security Camera
Antenna
Multi-position
Camera Bracket
Thumb screw
Camera
Bracket T-Bolt
AC Power cord
In-line Pairing
Button
Infrared
LED sensors
1
2
3
PAIRING ADDITIONAL
CAMERAS TO MONITOR
The Wireless Surveillance System supports up to four (4)
wireless surveillance cameras. Use the following steps to pair
each additional camera.
From the Main Menu on the Monitor, select the
CAMERA SET UP icon
Select camera
station to
be paired
Tap the CAMERA STATION you want to pair;
a 60-second timer will start.
Within 60 seconds, press the PAIRING KEY once on the camera’s
power cord or in the back of the camera. The timer will stop when
the camera is paired.
Go to Home Screen to view live cameras on the Monitor.
AC power cable
Camera In-line
Pairing Button
9:00 am - 6:00 pm (Central Time)
Monday - Friday
ATOMS LABS, LLC
2670 Firewheel Drive, Suite D
Flower Mound, TX 7502
CUSTOMER SUPPORT
1.844.767.8544
