Alcatel ONE TOUCH X600 User manual

Quick Start Guide
CJB26Q0ALAAB

Welcome! This manual brief is the profile of your USB-Modem, about the details of
how to set the management parameters, see help information on the web
management page.
www.sar-tick.com
This product meets applicable national SAR limits of
2.0W/kg.
The specific maximum SAR values can be found in the
following section of this user guide.
When carrying the product or using it while worn on your
body, either use an approved accessory such as a holster
or otherwise maintain a distance of 5 mm from the body
to ensure compliance with RF exposure requirements.
Note that the product may be transmitting even if you are
not making a phone call.

Getting to Know Your Modem
1. USB Interface
2. Cap
3. Strap Hole
4. Indicator LED
5. SIM/USIM Card Slot

Note:
You can tie the cap and modem by threading a strap through the strap hole to avoid cap
missing.
How to start your modem
1. Remove the cap from the USB modem.
2. Insert the SIM/UMSIM card into card slot on back of modem.
3. Insert the USB modem into computer’s USB port.
4. When the installation is complete, the modem’s web management page is

displayed, the modem connects to the network automatically. The modem’s web
management page will be displayed every time automatically when the modem is
inserted into the computer.
5. After the program is installed, a shortcut icon for the management program
appears on the desktop. You can also double-click the shortcut icon on the desktop
to start the management program.
Note:
Do not remove the SIM/USIM card when the card is in use.
If the modem does not be installed automatically, find the AutoRun.exe file in
modem’s root and double-click it to run.
If the connection failed, access http://192.168.1.1 to check the status.
If you cannot access http://192.168.1.1, disconnect other network connections,
such as an Ethernet or Wi-Fi connection, remove the modem and re-insert it, or
restart your computer.

LED Indicates
(Following table are listed the LED Indicates for each status.)
LED Indicator
Description
Flashing Red
Searching network
Solid Red
No Service, No SIM or SIM error
Flashing Green
Registering into 2G network
Solid Green
Connected to 2G network
Flashing Blue
Registering into 3G network
Solid Blue
Connected to 3G network
Flashing Cyan
Registering into 3G+ network
Solid Cyan
Connected to 3G+ network
Off
The device is removed

Safety and Use
We recommend that you read this chapter carefully before using the USB-Modem. The
manufacturer disclaims any liability for damage, which may result as a consequence of
improper use of the USB-Modem or of use contrary to the instructions contained herein.
Traffic Safety
When driving, do not use the USB-Modem
When switched on, the USB-Modem emits electromagnetic waves that can interfere
with the vehicle’s electronic systems such as ABS anti-lock brakes or airbags. To ensure
that there is no problem, do not place the USB-Modem on top of the dashboard or
within an airbag deployment area.
Check with your car dealer or the car manufacturer to make sure that the dashboard
is adequately shielded from modem RF energy.

Conditions of Use
Switch the USB-Modem off before boarding an aircraft.
Switch the USB-Modem off when you are in health care facilities, except in designated
areas. As with many other types of equipment now in regular use, the USB-Modem can
interfere with other electrical or electronic devices, or equipment-using radio
frequencies.
Switch the USB-Modem off when you are near gas or flammable liquids. Strictly obey
all signs and instructions posted in a fuel depot, petrol station, chemical plant, or in any
potentially explosive atmosphere.
When the USB-Modem is switched on, it should be kept at least 15 cm from any
medical device such as a pacemaker, a hearing aid or insulin pump, etc.
Do not let children use the USB-Modem without supervision.
When replacing the cover, please note that the USB-Modem may contain substances
that could create an allergic reaction.
Always handle the USB-Modem with care and keep it in a clean and dust-free place.
Do not allow the USB-Modem to be exposed to adverse weather or environmental

conditions (moisture, humidity, rain, infiltration of liquids, dust, sea air, etc). The
manufacturer’s recommended operating temperature range is -10°C to +50°C.
Do not open, dismantle or attempt to repair the USB-Modem yourself.
Do not drop, throw or bend the USB-Modem.
Do not paint it.
WEEE Approval
The USB-Modem is in compliance with the essential requirements and other relevant
provisions of the Waste Electrical and Electronic Equipment Directive 2002/96/EC (WEEE
Directive).
RoHs Approval
The USB-Modem is in compliance with the restriction of the use of certain hazardous
substances in electrical and electronic equipment Directive 2002/95/EC (RoHs Directive).

Radio Waves
Proof of compliance with international standards (ICNIRP) or with European Directive
1999/5/EC (R&TTE) is required of all modem models before they can be put on the market.
The protection of the health and safety for the user and any other person is an essential
requirement of these standards or this directive.
THIS DEVICE MEETS INTERNATIONAL GUIDELINES FOR EXPOSURE TO RADIO WAVES.
The USB-Modem is a radio transmitter and receiver. It is designed not to exceed the limits for
exposure to radio waves (radio frequency electromagnetic fields) recommended by
international guidelines. The guidelines were developed by an independent scientific
organization (ICNIRP) and include a substantial safety margin designed to assure the safety of
all persons, regardless of age and health.
The radio wave exposure guidelines use a unit of measurement known as the Specific
Absorption Rate, or SAR. The SAR limit for mobile devices is 2 W/kg.
Tests for SAR are conducted using standard operating positions with the device transmitting
at its highest certified power level in all tested frequency bands. The highest SAR values
under the ICNIRP guidelines for this device model are:

Maximum SAR for this model and conditions under which it was recorded.
Body-worn SAR
WCDMA2100
0.629
During use, the actual SAR values for this device are usually well below the values stated
above. This is because, for purposes of system efficiency and to minimize interference on the
network, the operating power of your mobile device is automatically decreased when full
power is not needed for the call. The lower the power output of the device, the lower its SAR
value.
Body-worn SAR testing has been carried out at a separation distance of 5mm. To meet RF
exposure guidelines during body-worn operation, the device should be positioned at least
this distance away from the body. If you are not using an approved accessory ensure that
whatever product is used is free of any metal and that it positions the phone the indicated
distance away from the body.
The World Health Organization has stated that present scientific information does not
indicate the need for any special precautions for the use of mobile devices. They recommend

that if you are interested in further reducing your exposure then you can easily do so by
limiting your usage or keep the device away from the head and body.
For more information you can go to www.alcatelonetouch.com
Additional information about electromagnetic fields and public health are available on the
following site: http://www.who.int/peh-emf
The USB-Modem is equipped with a built-in antenna. For optimal operation, you should avoid
touching it or degrading it.
This equipment is in compliance with the essential requirements and other relevant
provisions of Directive 1999/5/EC. The entire copy of the Declaration of Conformity for your
telephone can be obtained through our Website: www.alcatelonetouch.com
Address: Room 1910-12A, Tower 3, China HK City, 33 Canton Road, Tsimshatsui, Kowloon,
Hong Kong
