Alcatel LINKZONE User manual

1
CJBXXXXALAAA
Quick Start Guide

2
www.sar-ck.com
This product meets applicable
naonal SAR limits of 1.6 W/kg.
The specic maximum SAR values
can be found in the Radio Waves
secon of this user guide.
When carrying the product or using
it while worn on your body, either
use an approved accessory such as
a holster or otherwise maintain a
distance of 10 mm from the body
to ensure compliance with RF
exposure requirements. Note that
the product may be transming
even if you are not surng the
Internet.
Safety and use
We recommend that you read this chapter carefully before
using this device. The manufacturer disclaims any liability
for damage, which may result as a consequence of improper
use of this device or of use contrary to the instrucons
contained herein.
Do not switch on your device when its use is
prohibited or when using the device may cause
interference or danger.
Follow rules or regulaons in hospitals and health
care facilies. Switch o your device near medical
apparatuses.

3
Switch o your device when on an aircra. The
device may cause interference to aircra control
signals.
Switch o your device near high-precision electronic
devices. The device may aect the performance of
these devices.
Do not aempt to disassemble your device or its
accessories. Only qualied personnel are allowed to
service or repair the device.
Do not place your device or its accessories in
containers with a strong electromagnec eld.
Do not place magnec storage media near your
device. Radiaon from the device may erase the
informaon stored on them.
Do not subject your device to high temperatures or
use it in a place with ammable gas such as a gas
staon.
Keep your device and its accessories away from
children. Do not allow children to use your device
without guidance.
Only use approved baeries and chargers to avoid
the risk of explosion.
Observe the laws or regulaons on device use.
Respect others’ privacy and legal rights when using
your device.
It is recommended that the equipment only be used in an
environment where the temperature is between 0°C and
45°C and humidity is between 10% to 90%.

4
CHARGERS
Main powered chargers will operate within the temperature
range of: 0°C to 40°C.
The chargers designed for your device meet with the
standard for safety of informaon technology equipment
and oce equipment use.
Due to dierent applicable electrical specicaons, a
charger you purchased in one jurisdicon may not work in
another jurisdicon. They should be used for this purpose
only.
Overview
LinkZone is a portable wireless router, providing a simple
way to share 4G with any Wi-Fi embedded device.
Package contents
LinkZone USB cable
Quick start guide Charger

5
Applicaon
LinkZone
PC
PAD
Smart phone
Geng to Know Your Device
Power key
LED indicator
WPS key
USB jack

6
LED Descripon
Part Descripon
Power key Hold the “Power” key for 3 seconds
to power the device on/ o.
WPS key Hold “WPS” key for 3 seconds to
acvate the WPS funcon. Once
acvated, the Wi-Fi LED indicator
will ash every two seconds. If the
network is not accessed within 2
minutes device will automacally exit
WPS mode.
LED indicators Displays signal, Wi-Fi, SMS, and
baery charge status.
Charging /
USB Port
Use the USB jack to charge your
device and connect your device to
the client via the USB cable.
Reset Hold both “Power” and “WPS” keys
simultaneously for 6 seconds. All
LED indicators will ash blue 4 mes
to indicate that the device has been
reset to factory mode.
Reboot Hold “Power” key for 10 seconds to
restart device.

7
Part Descripon
Power saving
mode
• If no buons are pressed for a
period of 30 seconds, all LED
lights will turn o automacally.
Press any buon, charge device, or
connect to a computer, to turn on
LED lights again.
• If no Wi-Fi is accessed for a period
of 10 minutes, network dialing
ceases automacally. Press any
buon, or access the device, to
turn on Wi-Fi again.
• If no Wi-Fi is accessed for a period
of 30 minutes, the Wi-Fi AP
funcon will turn o automacally.
Press any buon to turn on Wi-Fi
AP again.
Indicators
When the hotspot is powered on, the following icons will
illuminate. For a descripon of the icons, please refer to the
table below:

8
Network Indicator (Red or Blue LED)
Wi-Fi Indicator (Blue LED)
SMS Indicator (Blue LED)
Baery Indicator (Red or Blue LED)
LED Descripon
Network
Indicator
Solid Blue Registered and connected
to network.
Flashing Blue Network disconnected.
Solid Red No network, no SIM card
or SIM card error, limited
or no service.
Wi-Fi Solid Blue Wi-Fi is acve.
SMS Solid Blue New message
Flashing Blue Message inbox is full.
Baery Slow Flashing
Blue
Working
Quick Flashing
Blue
The baery is charging
and is plugged into a
power source.
Solid Blue The baery is fully
charged and is plugged
into a power source.
Flashing Red The baery level is less
than 10%.

9
Turning On Your Device
Step 1: Remove back cover:
Slot
Note: Find the slot on the front cover to open.
Step 2: Install Micro SIM Card and SD Card:
Micro SIM Card

10
Step 3: Install baery:
Step 4: Close back cover:
Posion the back cover so that locang nub is inserted
into corresponding indentaon (please refer to illustraon
below)
Step 5: Power device on:
Long Press the “Power” key unl all LED indicators
illuminate in blue.
Connecng in Wi-Fi mode
SSID: locate the SSID informaon on the scker on the Back
Cover.
Step 1: Use the Wi-Fi manager on the Wi-Fi embedded
device to select network name (SSID).
• From a Windows PC: Right-click Wireless network
connecon on the task bar, and select: View Available
Networks.

11
Choose SSID from the list of available networks.
• From a Mac computer: Select System Preferences ->
Network -> Airport. Click “Advanced” to choose SSID
from the list of available networks.
• From an iOS device: Sengs -> Wi-Fi. Choose SSID from
the available networks.
• From an android device: Sengs -> Wireless controls ->
Wi-Fi sengs. Choose SSID from the available networks.
Step 2: Enter the Wi-Fi key when prompted for a security
key.
Quick Setup Your Device
Website
Open your browser, and input the address hp://192.168.1.1
to access the login page.
Default login password: admin
Login and click “Seng” to congure the basic sengs.
Admin Password:
• Login Password: Set the password for login.
Wi-Fi Sengs:
• SSID: Set the network name of this device.
• Security: Congure the security mode for Wi-Fi
connecon.
LINK APP
Download the “LINK APP” by scanning the 2D code on App

12
Leaet.
Open LINK APP by entering the password.
Note: Default password is admin
Set the WiFi network name & WiFi password.
Save the sengs & restart network connecon.
Charging Your Device
You have two ways to charge your device.
Wall Charger:
Connect USB cable with Charger head and device, then
charging begin.
When the device is powered o, charging will take a
maximum of 3 hours.
USB Charger:
You can also charge the device by connecng it to a PC with
the USB cable.
When the device is powered o, charging will take a
maximum of 4 hours.
Note: In order to protect the baery, when low power LED
indicator ashes, please charge the device.
Radio Waves
THIS DEVICE MEETS GOVERNMENT REQUIREMENTS
FOR EXPOSURE TO RADIO WAVES.
Your router is a radio transmier and receiver. It is designed
and manufactured not to exceed the emission limits for
exposure to radio-frequency (RF) energy. These limits are

13
part of comprehensive guidelines and establish permied
levels of RF energy for the general populaon. The
guidelines are based on standards that were developed by
independent scienc organizaons through periodic and
thorough evaluaon of scienc studies. These guidelines
include a substanal safety margin designed to ensure the
safety of all persons, regardless of age and health.
The exposure standard for routers employs a unit of
measurement known as the Specic Absorpon Rate,
or SAR. The SAR limit set by public authories such as
the Federal Communicaons Commission of the US
Government (FCC), or by Industry Canada, is 1.6 W/kg
averaged over 1 gram of body ssue. Tests for SAR are
conducted using standard operang posions with the
router transming at its highest cered power level in all
tested frequency bands.
Although the SAR is determined at the highest cered
power level, the actual SAR level of the router while
operang can be well below the maximum value. This is
because the router is designed to operate at mulple power
levels so as to use only the power required to reach the
network. In general, the closer you are to a wireless base
staon antenna, the lower the power output of the router.
Before a router model is available for sale to the public,
compliance with naonal regulaons and standards must
be shown.
The highest SAR value for this model phone when tested is
1.26 W/Kg for use close to the body.
For body-worn operaon, the phone meets FCC RF
exposure guidelines provided that it is used with a non-
metallic accessory with the handset at least 10 mm from
the body.

14
Use of other accessories may not ensure compliance with
FCC RF exposure guidelines.
Addional informaon on SAR can be found on the Cellular
Telecommunicaons & Internet Associaon (CTIA) Web
site: hp://www.ca.org/
The World Health Organizaon (WHO) considers that
present scienc informaon does not indicate the need
for any special precauons for use of routers. If individuals
are concerned, they might choose to limit their own or their
children’s RF exposure by liming the length of calls, or using
“hands-free” devices to keep routers away from the head
and body. (fact sheet n°193). Addional WHO informaon
about electromagnec elds and public health are available
on the following website: hp://www.who.int/peh-emf.
Note: This equipment has been tested and found to comply
with the limits for a Class B digital device pursuant to part
15 of the FCC Rules. These limits are designed to provide
reasonable protecon against harmful interference in a
residenal installaon. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instrucons, may cause harmful
interference to radio communicaons. However, there is no
guarantee that interference to radio or television recepon,
which can be determined by turning the equipment o and
on. The user is encouraged to try to correct the interference
by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separaon between the equipment and
receiver.
- Connect the equipment into an outlet on a circuit dierent
from that to which the receiver is connected.

15
- Consult the dealer or an experienced radio/ TV technician
for help.
Changes or modicaons not expressly approved by the
party responsible for compliance could void the user’s
authority to operate the equipment.
For receiver devices associated with the operaon of a
licensed radio service (e.g. FM broadcast), they bear the
following statement:
This device complies with Part 15 of the FCC Rules.
Operaon is subject to the condion that this device does
not cause harmful interference.
For other devices, they bear the following statement:
This device complies with Part 15 of the FCC Rules.
Operaon is subject to the following two condions:
(1) this device may not cause harmful interference
(2) this device must accept any interference received,
including interference that may cause undesired operaon.
Your router is equipped with a built-in antenna. For opmal
operaon, you should avoid touching it or damaging it.
As routers oer a range of funcons, they can be used in
posions other than against your ear. In such circumstances
the device will be compliant with the guidelines when used
with headset or usb data cable. If you are using another
accessory ensure that whatever product is used is free of
any metal and that it posions the router at least 10 mm
away from the body.
Please note by using the device some of your personal
data may be shared with the main device. It is under your
own responsibility to protect your own personal data, not
to share with it with any unauthorized devices or third
party devices connected to yours. For products with Wi-

16
Fi features, only connect to trusted Wi-Fi networks. Also
when using your product as a hotspot (where available),
use network security. These precauons will help prevent
unauthorized access to your device. Your product can store
personal informaon in various locaons including a SIM
card, memory card, and built-in memory. Be sure to remove
or clear all personal informaon before you recycle, return,
or give away your product. Choose your apps and updates
carefully, and install from trusted sources only. Some apps
can impact your product’s performance and/or have access
to private informaon including account details, call data,
locaon details and network resources.
Note: any data shared with TCL Communicaon Ltd. is stored
in accordance with applicable data protecon legislaon.
For this reason, TCL Communicaon Ltd. implements
and maintains appropriate technical and organizaonal
measures to protect all personal data. Examples include:
protecon against unauthorized or unlawful processing,
accidental loss, destrucon of or damage to such personal
data. Measures shall provide a level of security that is
appropriate with regards to:
(1) the technical possibilies available,
(2) the costs for implemenng the measures,
(3) the risks involved with the processing of the personal
data, and
(4) the sensivity of the personal data processed.
You can access, review and edit your personal informaon
at any me by logging into your user account, vising your
user prole or by contacng us directly. Should you require
us to edit or delete your personal data, we may ask you to
provide us with evidence of your identy before we can act
on your request.

17
Licenses
The Wi-Fi Logo is a cercaon mark of the
Wi-Fi Alliance.
• FCC Compliance(FOR PART 15B/PART 15C)
FCC ID: 2ACCJB132
Warranty
The device is warranted against any deviaon from technical
specicaons for a period of twelve (12) (1) months from the
date specied on your original invoice.
Under the terms of this warranty, you must immediately
inform your vendor in case of a conformity defect on this
device, and present a proof of purchase.
The vendor or repair center will decide whether to replace or
repair this device, as appropriate.
Repaired or replaced this device is warranted ONE (1) month
unless there are statutory provisions to the contrary.
This warranty shall not apply to damage or defects to this
device due to:
1) Not following the instrucons for use or installaon,
2) Not being compliant with technical and safety standards
applicable in the geographical area where this device is used,
3) Improper maintenance of sources of energy, and of the
overall electric installaon,
4) Accidents or consequences of the of the vehicle in which
this device is transported, acts of vandalism, lightning, re,
(1) The warranty period may vary depending on your country.

18
humidity, inltraon of liquids, inclement weather,
5) Connecng to or integrang into this device any
equipment not supplied or not recommended by the
manufacturer,
6) Any servicing, modicaon or repair performed by
individuals not authorized by the manufacturer, the
vendor or the approved maintenance center,
7) Use of this device for a purpose other than that for which
it was designed,
8) Malfuncons caused by external causes (e.g., radio
interference from other equipment, power voltage
uctuaons),
9) Faulty connecons resulng from unsasfactory radio
transmission or caused by the absence of radio relay
coverage.
Warranty is also excluded for this device on which markings or
serial numbers have been removed or altered.
This device is also warranted against hidden defects (defects
inherent in the design, manufacture, etc.).
There are no other express warranes than this printed limited
warranty, expressed or implied, of any nature whatsoever.
In no event shall the manufacturer be liable for incidental or
consequenal damages of any nature whatsoever, including
but not limited to trading loss, commercial loss, to the full
extent those damages can be disclaimed by law. Some
countries/states do not allow the exclusion or limitaon of
incidental or consequenal damages, or limitaon of the
duraon of implied warranes, so the preceding limitaons or
exclusions may not apply to you.
