Alcatel SPEED TOUCH 570 Instruction Manual

3EC 16982 ADAA TCZZA Ed. 01
SPEED TOUCH 570
CLI Reference Guide
Wireless ADSL Router

3EC 16982 ADAA TCZZA Ed. 01
2/ 268
Status Released
Change Note BD F aa 39813
Short Title CD-RG AST570 CLI
All rights reserved. Passing on and copying of this
document, use and communication of its contents
not permitted without written authorization from Alcatel.

Contents
3EC 16982 ADAA TCZZA Ed. 01 3/ 268
Contents
Preface 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1 ADSL Commands 21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 Bridge Commands 23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3 CIP Commands 39. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4 Config Commands 49. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5 DHCP Commands 55. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6 DNS Commands 93. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7 Firewall Commands 115. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8 IP Commands 141. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9 MER Commands 163. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
10 NAT Commands 173. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
11 Phonebook Commands 189. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
12 PPP Commands 199. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
13 PPTP Commands 217. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
14 Software Commands 225. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
15 System Commands 231. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
16 TD Commands 239. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
17 Wireless Commands 241. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Index 265. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Contents
3EC 16982 ADAA TCZZA Ed. 01
4/ 268

Preface
5/ 268
3EC 16982 ADAA TCZZA Ed. 01
Preface
Welcome to the Alcatel SpeedTouch570 Command Line Interface Reference Guide !
This Reference Guide aims to give the fastidious user a concise, practical and easy to use
document for configuring the SpeedTouch570 via its character based Command Line Interface.
Although the SpeedTouch570 Web interface is adequate enough for most users, access via the
CLI may be still important for advanced and detailed configuration and troubleshooting.
This CLI Reference Guide covers the CLI commands of the following Alcatel DSL SpeedTouch
products:
Alcatel SpeedTouch570
The Reference Guide consists of three main parts:
Part 1 : CLI Navigation
This part is meant to make the user familiar with the use and operation of the
SpeedTouch570 CLI. Next to describing the various access methods to the CLI, this part will
describe in brief some general manipulations to navigate through and to perform some
operations on the CLI.
Part 2 : CLI Command Description
This part forms the main part of this Reference Guide. Here all available CLI commands of the
SpeedTouch570 products are alphabetically described per group selection.
Each command is described in a systematic manner:
The full name of the CLI command (including the group selection)
A short description of the CLI command, if needed completed by a description of the
possible impact on the user and/or the SpeedTouch570
The syntax of the command with a description of each parameter
An example to demonstrate the use of the CLI command
A list of related CLI commands.
Part 3 : CLI Command Index
This part allows the user to look up a command alphabetically in its incomplete form.

Preface
6/ 268 3EC 16982 ADAA TCZZA Ed. 01
Trademarks
The following trademarks are used in this document:
Speed Touchis a trademark of the Alcatel Company
Netscapeand Netscape Navigatorare registered trademarks of Netscape
Communications Corporation
Windowsand Internet Explorerare trademarks of Microsoft Corporation
Appleand MacOS are registered trademarks of Apple Computer Inc.
UNIXis a registered trademark of UNIX System Laboratories, Inc.
Ethernetis a trademark of Xerox Corporation.
Other products may be trademarks or registered trademarks of their respective manufacturers.
Updates
Due to the continuous evolution of the Alcatel DSL technology, existing products are regularly
upgraded. Alcatel documentation changes accordingly.
For more information on the newest technological changes and documents, please consult the
Alcatel web site at following URL:
http://www.alcatel.com
http://www.alcateldsl.com
Directive
Unless expressly and unambiguously approved by Alcatel, you may not:
disassemble, decompile, reverse engineer, trace or otherwise analyze the equipment, its
content, operation, or functionality, or otherwise attempt to derive source code (or the
underlying ideas, algorithms, structure or organization) from the equipment or from any
other information provided by Alcatel, except to the extent that this restriction is expressly
prohibited by local law;
copy, rent, loan, resell, sublicense, or otherwise transfer or distribute the equipment to
others;
modify, adapt or create a derivative work of the equipment;
remove from any copies of the equipment any product identification, copyright or other
notices;
disseminate performance information or analysis (including, without limitation,
benchmarks) from any source relating to the equipment.
Such acts not expressly approved by Alcatel will result in the loss of product warranty and will
invalidate the user's authority to operate this equipment.

7/ 268
3EC 16982 ADAA TCZZA Ed. 01
Alcatel
SpeedTouch570
CLI Navigation

8/ 268 3EC 16982 ADAA TCZZA Ed. 01

9/ 268
3EC 16982 ADAA TCZZA Ed. 01
Accessing the Command Line Interface
Users can access the Command Line Interface via:
The SpeedTouch570 CLI web pages
This requires that TCP/IP connectivity exists between the host from which the web browser is
opened and the SpeedTouch570
A Telnet session
This requires that TCP/IP connectivity exists between the host from which the Telnet session is
opened and the SpeedTouch570.
Access via the Web Pages
The SpeedTouch570 CLI is accessible via its web interface. Browse to the SpeedTouch570
web pages and click in the left frame. As a result the CLI web menu is opened in a new
browser window:
You can open the CLI web pages directly by pointing the browser to the following URL:
http://10.0.0.138/cli.htm (in which the 10.0.0.138 IP address should be replaced by the
actual SpeedTouch570 IP address if needed).
All CLI groups and commands are placed in a menu. You can open a group by clicking the mark
next to a group name, or clicking the group name.
Clicking on a command name will execute it. Commands without parameters are indicated with
and are executed immediately.
Commands which require additional parameters are indicated with . After you configured all
parameters you must click to execute the command.

10 / 268 3EC 16982 ADAA TCZZA Ed. 01
Access via a Telnet Session
As soon a session to the CLI is opened, the SpeedTouch570 banner pops up, followed by the CLI
prompt.
In case the SpeedTouch570 is protected by a System password authentication will be required
before access is granted.
The following figure shows an example of the SpeedTouch570 banner after opening a Telnet
session and authentication.
EXAMPLE:
/home/doejohn{1}$ telnet 10.0.0.138
Trying 10.0.0.138...
Connected to 10.0.0.138.
Escape character is ’^]’.
User :
SpeedTouch (00–90–D0–00–01–23–45)
Password : ######
–––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
*
* ______
* ___/_____/\
* / /\\ Alcatel Speed Touch 570
* _____/__ / \\ Wireless ADSL Router
* _/ /\_____/___ \ Version R1.0
* // / \ /\ \
* _______//_______/ \ / _\/____ Copyright (c) 1999–2001 Alcatel
* / / \ \ / / / /\
* __/ / \ \ / / / / _\__
* / / / \_______\/ / / / / /\
* /_/______/___________________/ /________/ /___/ \
* \ \ \ ___________ \ \ \ \ \ /
* \_\ \ / /\ \ \ \ \___\/
* \ \/ / \ \ \ \ /
* \_____/ / \ \ \________\/
* /__________/ \ \ /
* \ _____ \ /_____\/
* \ / /\ \ /___\/
* /____/ \ \ /
* \ \ /___\/
* \____\/
*
–––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
=>

11 / 268
3EC 16982 ADAA TCZZA Ed. 01
Navigation and Manipulation
Manipulation commands are commands that manipulate operations on the command line, for
example changing the command group, go to the beginning of the command line, go to the end of
the command line, etc.
Command group Navigation
From top level, you can change to a command group by executing the name of the desired
command group.
To obtain a list of all available command groups, execute help from the top level.
EXAMPLE:
=>help
Following commands are available :
help : Displays this help information
? : Displays this help information
exit : Exits this shell.
.. : Exits group selection.
Following command groups are available :
wireless dhcp dns td mer
bridge pptp ppp cip nat
adsl qosbook phonebook ip software
system config firewall
=>
To return to top level, or to descend one level (in case of nested command groups) execute .. .
EXAMPLE:
=>phonebook
[phonebook]=>
[phonebook]=>..
=>

12 / 268 3EC 16982 ADAA TCZZA Ed. 01
The Help Command
Execute help from top level to list all available command groups for the SpeedTouch570.
EXAMPLE:
=>help
Following commands are available :
help : Displays this help information
? : Displays this help information
exit : Exits this shell.
.. : Exits group selection.
Following command groups are available :
wireless dhcp dns td mer
bridge pptp ppp cip nat
adsl qosbook phonebook ip software
system config firewall
=>
You can execute the help command from each command group selection. This results in a list of
the available commands (and nested command groups, if available) in this particular command
group.
EXAMPLE:
=>firewall
[firewall]=>
[firewall]=>help
Following commands are available :
tron : Enables verbose console messaging.
troff : Disables verbose console messaging.
match : Defines an ip packet match.
assign : Assign a chain to an entry point.
list : Shows a list of all the hooks with the chain attached.
flush : Clears all hooks. If a hook is provided, that hook is cleared.
Following command groups are available :
chain rule
[firewall]=>

13 / 268
3EC 16982 ADAA TCZZA Ed. 01
Executing e.g. help firewall from top level gives the same result as executing help from the firewall
command group selection.
EXAMPLE:
=>firewall help
Following commands are available :
tron : Enables verbose console messaging.
troff : Disables verbose console messaging.
match : Defines an ip packet match.
assign : Assign a chain to an entry point.
list : Shows a list of all the hooks with the chain attached.
flush : Clears all hooks. If a hook is provided, that hook is cleared.
Following command groups are available :
chain rule
=>
Entering help followed by a specific command, e.g. help firewall assign (starting from top level)
or help assign (e.g. on the firewall command group selection) results in a description of the syntax
for the command.
EXAMPLE:
=>help firewall assign
Assign a chain to an entry point.
Syntax : assign hook = <{input|sink|forward|source|output}> chain = <string>
parameters :
hook = <{input|sink|forward|source|output}>
Name of hook to assign chain to.
chain = <string>
Name of chain to use.
=>

14 / 268 3EC 16982 ADAA TCZZA Ed. 01
Command Completion
The CLI features command completion, which means that when starting to enter a command it can
be completed by pressing the Tab" key.
For example, entering aat the firewall command group selection, followed by a Tab" stroke
results in the full assign command being completed. Entering firewall a from top level gives the
same result.
For the completion to be successful, the part to be added must be unique. Completion works for the
command groups, for the commands, for the options, but not for values.
EXAMPLE:
=>firewall
[firewall]=>a “Tab“
[firewall]=>assign
Going to the beginning or end of the Command Line
Go to the beginning of the Command Line by pressing "Ctrl+A"; to go to the end of the
Command Line press "Ctrl+E".
In the following example, the first  indicates the position of the cursor after pressing "Ctrl+A", the
second the position of the cursor after pressing "Ctrl+E".
EXAMPLE:
=>list
Breaking off Commands
You can break off a command by pressing Ctrl+G". This can be useful in a situation where a user
is prompted to enter a value which it does not know and wants to abort the command. Instead of
being prompted over and over again for the same value, this allows to break of the command.
In the example below Ctrl+G" is pressed after the third prompt `vpi =`. The command is broken
of and the user returns to the command line.
EXAMPLE:
[firewall]=>match
chain =
chain =
chain = Ctrl+G"
[firewall]=>

15 / 268
3EC 16982 ADAA TCZZA Ed. 01
History of Commands
To retake previous commands press the up arrow   and come back to more recent commands
with the down arrow  . Press Enter (↵)" to select and execute the retaken command.
EXAMPLE:
=>firewall
[firewall]=>list
assign hook=input chain=input
assign hook=sink chain=sink
assign hook=forward chain=forward
assign hook=source chain=source
[firewall]=>  
[firewall]=>:firewall list

16 / 268 3EC 16982 ADAA TCZZA Ed. 01
Command Line Interface Top Level Structure
The following command groups are available:
adsl
bridge
cip
config
dhcp
dns
firewall
ip
mer
nat
phonebook
ppp
pptp
software
system
td
wireless

17 / 268
3EC 16982 ADAA TCZZA Ed. 01
Command Line Interface Commands
All CLI commands are commands that operate on, or configure, the SpeedTouch570.
You can execute these commands from top level, preceded by the name of the command group
from which the command should be executed (e. g. firewall list).
You can also execute the commands from the command group itself, using the reduced form of the
command (e.g. list at the firewall command group selection).
`!` in a command means `NOT`, e.g. the `[!]syn`parameter in the firewall rule create command.
EXAMPLE:
=>firewall list
assign hook=input chain=input
assign hook=sink chain=sink
assign hook=forward chain=forward
assign hook=source chain=source
=>firewall
[firewall]=>list
assign hook=input chain=input
assign hook=sink chain=sink
assign hook=forward chain=forward
assign hook=source chain=source
[firewall]=>
Instead of entering a completely builtup command with all its parameters, you can also enter just
the command itself, without its parameters. After this you are prompted to complete the command
with the required and the optional parameters. For the optional parameters you can simply press
enter without giving a value.
The example below is the equivalent of `firewall assign hook=input chain=input`. To break of
such incomplete command press Ctrl+G".
EXAMPLE:
=>firewall assign
hook = input
chain= input
=>

18 / 268 3EC 16982 ADAA TCZZA Ed. 01

19 / 268
3EC 16982 ADAA TCZZA Ed. 01
Alcatel
SpeedTouch570
CLI Command Description

20 / 268 3EC 16982 ADAA TCZZA Ed. 01
