ALcom CL-3350 INF User manual

CL-3350 INF
USER' S MANUAL
DIGITAL ENHANCED CORDLESS TELEPHONE
with Caller ID Function

Congratulations
on purchasing our high quality product.
Please read the manual carefully to find out all features and how your telephone
works, so you can get the best out of your new phone.
Safety precautions
To reduce the risk of electrical shock and injury, please follow these basic safety
precautions before using the phone.
1. Carefully read and observe the instructions in this manual.
2. Follow all warnings marked on the unit.
3. When cleaning, unplug the phone first, then use a damp cloth to wipe. Do not
use liquid or aerosol cleaners.
4. Do not place objects on the line cord that may cause damage.
5. Do not use this phone in wet surroundings or environments where there is a
risk of explosion.
6. Avoid spilling of any liquid on the phone.
7. Unplug this phone from the wall outlet and refer servicing to qualified service
personnel only.
8. Pay attention to the polarity of the batteries, insert the rechargeable batteries
in accordance with polarity symbols ( this instruction is found in the installing
batteries section.)
9. Use only . Never use other
ordinary batteries or conventional alkaline batteries. Otherwise this may not
only cause personal injuries but also damage to the unit.
10. Do not mix exhausted batteries with full batteries. Exhausted batteries shall
not be disposed of with the usual household waste or in a fire.
11. If you are sure you will not be going to use the handset over a month, please
take out the batteries from the battery compartment.
12. Use only .
13. Keep the phone out of the reach of children.
14. Use the phone only in the described manner.
15. Stop using the phone if it becomes damaged.
16. The phone is designed to work with in a temperature range from 5 to 45 .
the batteries indicated in the User's Manual
the power supply indicated in the User's Manual

Table of Contents
Before Using
Basic Function
Package Contents
Location and Function of Controls
LCD Window Icon Descriptions
Connecting Lines
Installing Batteries
Charging Handset
Using Handset Carrying Clip
Using Earmic (optional)
Turning Handset On/Off
Choosing Dial Mode
Setting Time
Making a Call
Receiving a Call
Switching the Microphone off (Mute)
Adjusting Voice Volume
Adjusting Ring Volume
Last Number Redial
Caller ID
Battery Level Indicator
Key Lock
Smart Dialing
Out of Range Indication
Registered Recall
Tone Dialing Switchover
Paging
1
3
4
4
5
7
8
8
1
9
10
10
11
11
12
13
14
14
15
15
16
30
Symptom
Check that the power adapter is properly connected.
Check that the telephone line cord is properly connected.
Check that the handset is fully charged.
Check that the handset batteries are installed properly.
Check that the telephone line cord is properly connected.
Check that the power adapter is properly connected.
Check that the handset batteries are not in low status.
Clean the charge contacts.
Consistently short battery life may indicate that
replacement of the batteries is necessary.
Check & Remedy
No operation
No dial tone
Warning beep occurs
when making a call
The Handset seems to
have very short
battery life.
Appendix
Troubleshooting
Appendix
6
6
16
16

Advanced Menu Functions
Using Multi System
Appendix
Menu Navigation
Menu Map
Phonebook
Call by Call
Key Beep
Selecting Ring Type
Setting VIP Ring
Changing PIN
Setting Access Code
Registering a New Handset
Resetting Handset
Selecting Base
Call Barring
Releasing Handset
Caller ID Type
Intercom Between Handsets
Call Transfer Between Handsets
Troubleshooting
Feature List
29
17
17
18
19
20
21
21
22
22
23
24
24
25
26
26
27
28
29
30
Caller ID type selection ( FSK or DTMF )
Stores up to 10 incoming calls number, up to 20 digits for each number
Stores up to 10 outgoing calls number, up to 24 digits for each number
Stores up to 10 numbers in phonebook memory, up to 24 digits for each
number
LCD displays calling and dialing number
Key lock setting
Call transfer of external calls (when using two or more handsets)
Internal calls
Ringer type selection
Setting VIP numbers with matching ringer
Ringer volume adjusting
Earpiece volume adjusting
New call indicator
Battery level indicator
In use indicator
Microphone mute function
Dialing mode selection
Real time clock (set time)
Redialing and preparation dialing functions
Smart dialing feature
Page on base unit to look for the handset easily
Call by call function
Key tone selection
Barring number setting
Access code setting
Tone dialing switchover
Out of range indication
Registered recall
Supports GAP function
Feature List
Feature List

Package Contents
*The shape of the plugs vary according to each country's specification.
Before Using
1
28
Using Multi System
User's manual
User's manual Line cord*
Adapters* Carrying clip
Three AAA batteries
(Rechargeable
Ni-MH batteries)
HandsetBase
Location and Function of Controls
Base
Charge pins
In use indicator
lights steadily when
a call is in progress.
Page button
Pages the handsets.
Also used to register
a new handset
Charge indicator
lights steadily
while the handset
is charging
Power Jack
Phone
Line Jack
Rear and bottom View
INT
C/R
OK
1
0
2ABC
3
DEF
4
GHI
5JKL
6
MNO
7
PQRS
8TUV
9
WXYZ
M
E
N
U
You can transfer a call from one handset to
another.
1. During a telephone conversation, press
the button. Your caller will be put on
hold.
2. Enter the handset number (1~6) you
want to transfer to.
3. The paged handset will ring. To answer
the call from you, the paged handset
should press any button.
4. You can speak to the handset (Intercom).
5. To transfer the external call to the paged
handset, press the button.
Call Transfer Between Handsets
Result: The paged handset is connected to
the outside party.
: When you transfer a call, you may hang
up before the transferred station
answers your paging. The connection
between the caller and the station is
completed when you hang up. If the
transferred station does not answer the
call within a predetermined time, the
call is transferred back to your station.
Or, to cancel the call transfer and talk
with the outside party again, press the
button.
Note
INT
INT
Once you have unpacked your phone, check to make sure that all the parts shown below are
available. If any piece is missing or broken, please promptly call your dealer.
Before Using

Handset
Location and Function of Controls(continued)
227
Charge pins
Carrying clip
Battery cover
Rear View
If you have several handsets registered to the
base, two handsets can talk to each other on
an internal communication call.
:
If you enter a handset number that does not
exist, the handset sounds an error tone.
1. Press the button on your handset.
2. Enter the handset number (1~6) you
want to page.
3. The paged handset rings. The LCD
window on the paged handset displays
your handset number (the paging
handset).
Notes
To cancel the intercom call, press either the
button or the button.
Using Multi System
Up to 6 handsets can be used with a base. You can make an intercom call and transfer an external
call between the handsets.
Intercom Between Handsets
4. To answer the call from you, the paged
handset's user should press any button.
5. To end the call, press either the INT
button or the button.
Notes: If an external call comes in during an
intercom conversation, you will hear
beeps. When you hear the low beeps,
finish the intercom call by pressing the
button.
Then the external line rings. Press the
button to answer the call.
INT
INT
Earpiece
LCD window
Microphone
Scrolls through menu
options. Also adjusts
volume. In Standby mode,
scrolls through the
phonebook entries.
Allows you to access menu
options. Also used to return
to Standby mode from any
menu.
When navigating menu
options, confirms the
menu or the option
selected.
Activates intercom
communications. During a
call, transfers a call to
another handset.
In Standby mode, press
to lock keys on the phone.
Squeeze to turn the
phone on or off.
Redials the last number
you dialed. When entering
a number, inserts a pause
between numbers.
Clears characters from
the display. Also used to
go back to the previous
menu.
Makes, answers, or ends a
call.
INT
C/R
OK
1
0
2ABC
3
DEF
4
GHI
5JKL
6
MNO
7
PQRS
8TUV
9
WXYZ
M
E
N
U
Using Multi System
Before Using

3
26
Menu
Signal strength icon
Line icon
Key lock icon
New call icon
Mute icon
Battery status icon
This icon is always displayed when your phone is on, and shows the
current signal strength. More bars indicate more signal strength.
This icon indicates that the line is engaged.
This icon indicates the keys are locked.
This icon indicates that there is a new call. To view the caller, access
the Call Log menu. See page 13.
This icon indicates that your phone's microphone is off
temporarily.
This icon is displayed at all times when your phone is on, and shows
the level of your battery charge. The more bars, the greater the
capacity.
LCD Window Icon Descriptions
This area displays in-use
information such as the other
party's number, call duration,
menus, etc. In Standby mode, it
displays the handset number, and
the current time.
You can remove the registered handset from
the base if necessary.
The LCD window displays all handsets
currently registered to the base.
1. Press the button.
to choose
, then press the button.
3. Enter the PIN, then press the button.
4. Press the button to choose
, then press the button.
2. Press the or button
or
Result:
Releasing Handset
5. If you want to select the handset to
release individually, enter the number(s)
of the handset(s).
When the selected handset number(s)
disappears in the LCD window, press
the button.
Result: The selected handset(s) will be
removed from the base. The LCD
window displays .
If the removed handset is currently
registered to another base unit and is
within the range of the base unit, you
can use the handset with the base.
There are two different Caller ID types which are
DTMF and FSK. This feature allows you to
change the Caller ID type.
1. Press the button.
3. Enter the PIN, then press the button.
Then the LCD window displays
2. Press the or button to choose
, then press the button.
Caller ID Type
4. Press and hold the button for
about 3 seconds, then the current
setting is displayed (FSK or DTMF).
5. If you want to change the Caller ID type,
press the button once. Then the
phone exit to standby mode.
6. If not, press the button to exit.
MENU
OK
OK
OK
OK
MENU
OK
OK
MENU
.
Before Using

Connecting Lines
Connect one end of the phone line cord to
the phone line jack on the rear of the base,
and the other end to a standard phone wall
jack.
Connect the modular end of the power
adapter to the power jack of the base, and
plug the other end into a standard AC wall
outlet.
Installing Batteries
Slide the battery cover in the direction of
the arrow and pull it out.
The rechargeable Ni-MH batteries (AAA size )
come with your phone. Install the battery before
using your phone.
2. Insert new batteries as indicated,
matching correct polarity (+, ).
Note: Reversing the orientation may
damage the handset.
1.
2.
1.
-
425
To AC wall outlet
To phone wall jack
It is possible to set the phone to restrict
numbers that can be dialed. Calls beginning
with numbers you specified can not be dialed
in this feature.
You can set up to 4 different restricted
numbers containing up to 4 digits each.
If the feature is on, the message
displays when the restricted number is dialed.
To activate a call barring number:
1. Press the button.
3. Enter the PIN, then press the button.
4. Press the button to access
.
5. Enter the number you want to restrict, up
to 4 digits.
2. Press the or button to choose
, then press the button.
Call Barring
6. Press the button to save the
number.
To deactivate a call barring number:
1. Press the button.
2. Press th or button to choose
, then press the
button.
3. Enter the PIN, then press the
button.
4. Press the button to access
.
5. Press the or button to choose
the cell number you want to deactivate,
and clear the number.
6. Press the button to save the
selection.
MENU
OK
OK
OK
OK
OK
OK
OK
OK
MENU
Before Using Menu

3. To replace the battery cover, slide the
cover up until it snaps shut.
Charging Handset
Important Not : YOU
SHOULD FULLY CHARGE THE HANDSET
14-16
To charge the handset, you should place it on
the base.
Before initial operation,
for
about hours.
e
Result: When charging, the handset automatically
turns on and the charging lamp on the base
lights up.
Installing Battery(continued)
5
24
The batteries need to be replaced if they
do not recover their full storage capacities
after recharging.
When replacing the batteries, always use
good quality Ni-MH re-chargeable
batteries. Never use other batteries or
conventional alkaline batteries.
Notes:
INT
C/R
OK
1
0
2
ABC
3
DEF
4
GHI
5
JKL
6
MNO
7
PQRS
8
TUV
9
WXYZ
M
E
N
U
If you reset the handset, all the user-selectable
features including Phonebook, incoming and
outgoing call numbers and other settings
return to the initial setting at the time of
purchase.
To reset your handset:
1. Press the button.
Resetting Handset
2. Press the or button to choose
, then press the button.
3. Enter the PIN, then press the button.
4. Press button to confirm the reset.
Your handset can be used with up to 4 base
units. This menu option allows you to select
the base you want to use.
To use the handset with more than one
base unit, you must register the
handset to each base unit. See page
23.
To select a base unit:
Note:
1. Press the button.
2. Press the or button to choose
, then press the
button.
Selecting Base
3. Press the or button to scroll
through the available bases.
4. Press the button to save the
selection.
Result: If you select , the handset
will automatically find the first
available base unit when you lose
contact while moving around.
MENU
OK
OK
OK
MENU
OK
OK
Menu Before Using

623
Using Handset Carrying Clip
The supplied handset carrying clip allows you
to conveniently carry the handset with you. It
clips easily to your belt, waist band, or shirt
pocket.
If you want to remove the carrying clip:
Insert a screw driver along the edge of one
of its arms and release the clip. Then lift it
off.
If you want to attach the carrying clip:
Attach the carrying clip to the back of the
handset. Make sure that the carrying clip
locks into place.
Using Earmic (optional)
The earmic jack is located in the middle
right side of the handset and is
standard plug. Simply plug the
into the jack and the will be
activated.
2.5mm
earmic
earmic
Note:
Earphone
Microphone
Clip
Earmic plug
When the earmic is plugged into the
earmic jack, the microphone on the
handset will be deactivated.
Earmic jack
Registering a New Handset
5. Press and hold the button on the
base for more than 5 seconds, then the
IN USE indicator starts to blinks. Then
release the button.
6. Press the button.
7. Enter your phone's AC (Authentication
Code), and press the button. The
AC is "0000".
Note:
Result:
Result:
The LCD window prompts you to
enter AC.
AC remains the same even if you want
to register other handsets from different
manufacturers to this base.
When the registration is properly
completed, the LCD window displays
the handset number, and returns to
Standby mode.
OK
OK
Press
this button.
Before Using Menu
The handset which comes with the base unit
was already registered as handset 1. Each
additional handset you purchase must be
registered to the base unit.
A handset can be registered to up to 4
different base units. And a base can be
used with up to 6 handsets.
To register a handset:
The PIN is preset to "0000" at the
factory. You can change the PIN. For
details, see page 22. If you want to
register other handsets from different
manufacturers to this base, you must
enter their PIN codes in this step.
Note:
1. Press the button.
button.
3. Enter the PIN, then press the
button.
Note:
4. Press the or button to choose
the base number you want, then press
the button.
2. Press the or button to choose
, then press the
MENU
OK
OK
OK
