Allen-Bradley ArmorBlock 1732E-8IOLM12R User manual

Installation Instructions
ArmorBlock I/O 8 Channel IO-Link
Master Module
Catalog number 1732E-8IOLM12R
Table of Contents
Topic Page
Important User Information 2
Environment and Enclosure 3
Preventing Electrostatic Discharge 3
Additional Resources 4
About the Module 4
Install the Module 6
Mount the Module 7
Connect the I/O, Network and Auxiliary Cables to the Module 9
Configure the Module 11
Interpret LED Indicators 13
Specifications 15

2ArmorBlock I/O 8 Channel IO-Link Master Module
Publication 1732E-IN001A-EN-E - July 2016
Important User Information
Solid-state equipment has operational characteristics differing from those of electromechanical
equipment. Safety Guidelines for the Application, Installation and Maintenance of Solid State Controls
(Publication SGI-1.1 available from your local Rockwell Automation sales office or online at
http://www.rockwellautomation.com/literature/) describes some important differences between
solid-state equipment and hard-wired electromechanical devices. Because of this difference, and also
because of the wide variety of uses for solid-state equipment, all persons responsible for applying this
equipment must satisfy themselves that each intended application of this equipment is acceptable.
In no event will Rockwell Automation, Inc. be responsible or liable for indirect or consequential damages
resulting from the use or application of this equipment.
The examples and diagrams in this manual are included solely for illustrative purposes. Because of the
many variables and requirements associated with any particular installation, Rockwell Automation, Inc.
cannot assume responsibility or liability for actual use based on the examples and diagrams.
No patent liability is assumed by Rockwell Automation, Inc. with respect to use of information, circuits,
equipment, or software described in this manual.
Reproduction of the contents of this manual, in whole or in part, without written permission of Rockwell
Automation, Inc., is prohibited.
Throughout this manual, when necessary, we use notes to make you aware of safety considerations.
WARNING: Identifies information about practices or circumstances that can cause an
explosion in a hazardous environment, which may lead to personal injury or death,
property damage, or economic loss.
ATTENTION: Identifies information about practices or circumstances that can lead to
personal injury or death, property damage, or economic loss. Attentions help you
identify a hazard, avoid a hazard and recognize the consequences.
SHOCK HAZARD: Labels may be on or inside the equipment (for example, drive or
motor) to alert people that dangerous voltage may be present.
BURN HAZARD: Labels may be on or inside the equipment (for example, drive or
motor) to alert people that surfaces may reach dangerous temperatures.
IMPORTANT Identifies information that is critical for successful application and understanding of
the product.

ArmorBlock I/O 8 Channel IO-Link Master Module 3
Publication 1732E-IN001A-EN-E - July 2016
Environment and Enclosure
Preventing Electrostatic Discharge
ATTENTION: This equipment is intended for use in overvoltage Category II
applications (as defined in IEC 60664-1), at altitudes up to 2000 m (6562 ft)
without derating.
This equipment is considered Group 1, Class A industrial equipment according to
IEC/CISPR 11. Without appropriate precautions, there may be difficulties with
electromagnetic compatibility in residential and other environments due to
conducted and radiated disturbances.
This equipment is supplied as enclosed equipment. It should not require
additional system enclosure when used in locations consistent with the
equipment Enclosure Type Ratings. Subsequent sections of this publication may
contain more information regarding specific enclosure type ratings, beyond what
this product provides, that are required to comply with certain product safety
certifications.
In addition to this publication, see:
• Industrial Automation Wiring and Grounding Guidelines, Rockwell
Automation publication 1770-4.1, for additional install requirements.
• NEMA Standard 250 and IEC 60529, as applicable, for explanations of the
degrees of protection provided by different types of enclosure.
ATTENTION: This equipment is sensitive to electrostatic discharge, which can
cause internal damage and affect normal operation. Follow these guidelines
when you handle this equipment:
• Touch a grounded object to discharge potential static.
• Wear an approved grounding wriststrap.
• Do not touch connectors or pins on component boards.
• Do not touch circuit components inside the equipment.
• Use a static-safe workstation, if available.
• Store the equipment in appropriate static-safe packaging when not in use.
ATTENTION: To comply with UL restrictions, this equipment and all connected
I/O must be powered from a source compliant with the following:
Safety Extra Low Voltage (SELV)
ATTENTION: To comply with CE Low Voltage Directive (LVD), this equipment
and all connected I/O must be powered from a source compliant with the
following: Safety Extra Low Voltage (SELV)

4ArmorBlock I/O 8 Channel IO-Link Master Module
Publication 1732E-IN001A-EN-E - July 2016
Additional Resources
If you would like a manual, you can:
• download a free electronic version from the internet:
http://literature.rockwellautomation.com
• purchase a printed manual by contacting your local Allen-Bradley distributor or
Rockwell Automation representative
About the Module
The ArmorBlock I/O 8 Channel IO-Link Master Module provides eight channels that
can be individually configured as IO-Link master or as a standard digital I/O module. The
IO-Link channel master module can be configured to fit any IO-Link and/or discrete
application.
In IO-Link mode, the module supports eight channels for IO-Link master
communication with IO-Link compatible devices. In standard digital I/O mode, the
module supports eight channels of digital input or output. Standard digital input channels
support IEC61131-2 type 1 input. Channels can also be disabled if not in use.
You must use this module with RSLogix™ 5000/Studio 5000® software, version 20 or later.
Use this diagram to identify the external features of the module.
Resource Description
ArmorBlock IO-Link Master Module Wiring
Diagrams 1732E-WD008 Pinout guide wiring diagram for the ArmorBlock IO-Link Master module.
ArmorBlock 8 Channel IO-Link Master Module
User Manual 1732E-UM007 A detailed description of module functionality,
configuration, installation procedure and
information on how to use the ArmorBlock I/O
8 Channel IO-Link Master Module.
Industrial Automation Wiring and Grounding
Guidelines, publication 1770-4.1.More information on proper wiring and grounding
techniques.

ArmorBlock I/O 8 Channel IO-Link Master Module 5
Publication 1732E-IN001A-EN-E - July 2016
Module Identification
Description Description
1 EtherNet/IP D-code M12 connector 8 Auxiliary power indicator
2 Function earth(1)
(1) Functional Earth grounds the I/O block’s EtherNet/IP communication circuitry which is designed to mitigate the effect of
noise on the network. The device requires a solid earth ground connection, either through a metal screw to a grounded
metal panel or through a wire. refer to EtherNet/IP Connector on page 10 for connections.
9 Micro-style power out
3 EtherNet/IP D-code M12 connector 10 Micro-style power in
4 Link 2 status indicator 11 Channel I/O or digital I/O status indicators
5 Network status indicator 12 Module status indicator
6 Node address switches 13 Link 1 status indicator
7 Micro-style I/O connectors
45871
7
9
1
4
5
3
6
13
12
10
11
2
8

6ArmorBlock I/O 8 Channel IO-Link Master Module
Publication 1732E-IN001A-EN-E - July 2016
Install the Module
To install the module:
• Set the network address.
•Mountthemodule.
• Connect the I/O, Network and Auxiliary cables to the module.
Set the Network Address
The I/O block ships with the rotary switches set to 999 and DHCP enabled.
To change the network address, you can do one of the following:
• adjust the switch on the front of the module.
• use a Dynamic Host Configuration Protocol (DHCP) server, such as Rockwell
Automation BootP/DHCP.
• retrieve the IP address from nonvolatile memory.
The I/O block reads the switches first to determine if the switches are set to a valid
number. To set the network address:
1. Remove power.
2. Remove the switch dust caps.
3. Rotate the three (3) switches on the front of the module using a small blade
screwdriver.
4. Line up the small notch on the switch with the number setting you wish to use.
Valid settings range from 001…254.
5. Replace switch dust caps. Make sure not to over tighten.
6. Reapply power.

ArmorBlock I/O 8 Channel IO-Link Master Module 7
Publication 1732E-IN001A-EN-E - July 2016
Set Network Address
When the switches are set to a valid number, the I/O block’s IP address is 192.168.1.xxx
(where xxx represents the number set on the switches). The I/O block’s subnet mask is
255.255.255.0 and the gateway address is set to 0.0.0.0. When the I/O block uses the
network address set on the switches, the I/O block does not have a host name assigned to it
or use any Domain Name Server.
If the switches are set to an invalid number (for example, 000 or a value greater than 254
excluding 888), the I/O block checks to see if DHCP is enabled. If DHCP is enabled, the
I/O block asks for an address from a DHCP server. The DHCP server also assigns other
Transport Control Protocol (TCP) parameters.
If DHCP is not enabled, the I/O block uses the IP address (along with other TCP
configurable parameters) stored in nonvolatile memory.
Mount the Module
Two sets of mounting holes are used to mount the module directly to a panel or machine.
Mounting holes accommodate #8 (M4) pan head screws. The torque specification is 0.68
Nm (6 lb-in.).
0
2
4
6
8
0
2
4
6
8
0
2
4
6
8
Example shows default
node address set at 163.
44233
Note: You need to remove the
protective switch dust caps before
you can adjust the address settings.

8ArmorBlock I/O 8 Channel IO-Link Master Module
Publication 1732E-IN001A-EN-E - July 2016
Product Dimensions
Refer to the mounting dimensions illustration to help you mount the module.
Module Dimensions
25.6
(1.01)
166.5 (6.56)
32 (1.26)
Side Mounting
32 (1.26 )
43.3 (1.70)
Front Mounting
18 (0.71)
37 (1.46)
16.2 (0.64)
166.5 (6.56)
179 (7.05)
Measurements are in millimeters (inches)
45765

ArmorBlock I/O 8 Channel IO-Link Master Module 9
Publication 1732E-IN001A-EN-E - July 2016
Mount the Module in High Vibration Areas
If you mount the module in an area that is subject to shock or vibration, we recommend
you use a flat and a lock washer to mount the module. Mount the flat and the lock washer
as shown in the mounting illustration. Torque the mounting screws to 0.68 Nm (6 lb-in.).
High Vibration Area Mounting
Connect the I/O, Network and Auxiliary Cables to the Module
The 1732E-8IOLM12R ArmorBlock EtherNet/IP module has a 5-pin micro-style I/O
connectors. We provide caps to cover the unused connectors on your module. Connect the
quick-disconnect cord sets you selected for your module to the appropriate ports.
I/O Connectors
Micro-style 5-Pin I/O Female Connector
45768
Lock washer
Flat washer
3
4
1
2
5
43853
(View into connector)
Pin 1 Sensor source voltage
Pin 2 IO-Link, Input/output B
Pin 3 Return
Pin 4 IO-Link, Input/output A
Pin 5 PE

10 ArmorBlock I/O 8 Channel IO-Link Master Module
Publication 1732E-IN001A-EN-E - July 2016
EtherNet/IP Connector
D-Code Micro Network Female Connector
IMPORTANT
Use the 1585D–M4DC–H: Polyamide small body unshielded mating
connectors for the D-Code M12 female network connector.
Note that the distance between the center of each Ethernet connector is
16.2 mm (refer to Module Dimensions on page 8). Rockwell Automation
recommends the use of suitable cable based on this measurement. Some of
the recommended cables are 1585D-M4TBJM-x and 1585D-M4TBDM-x
for daisychains.
IMPORTANT
Use two twisted pair CAT5E UTP or STP cables
(View into connector 1)
Pin 1 M12_Tx+
Pin 2 M12_Rx+
Pin 3 M12_Tx-
Pin 4 M12_Rx-
Pin 5 Connector shell shield GND
4
2
31
5
44808
4
2
31
5
44808
(View into connector 2)
Pin 1 M12_Rx+
Pin 2 M12_Tx+
Pin 3 M12_Rx-
Pin 4 M12_Tx-
Pin 5 Connector shell shield GND
D-Code
M12 Pin
Wire Color Signal 8-wayModular
RJ45 Pin
1 White-orange TX+ 1
2 White-green RX+ 3
3 Orange TX- 2
4GreenRX- 6

ArmorBlock I/O 8 Channel IO-Link Master Module 11
Publication 1732E-IN001A-EN-E - July 2016
Configure the Module
Refer to the illustration for configuration operations.
Configure Operations
Refer to On-Machine Connectivity Catalog, publication M117-CA001, for Rockwell
Automation cable and cord set offerings or use the configuration tools available at
www.ab.com/e-tools/.
45871
EtherNet/IP D-code
M12 connector
EtherNet/IP D-code
M12 connector
Networkaddress
switches
Power connector Power connector
M12 style
I/O connectors

12 ArmorBlock I/O 8 Channel IO-Link Master Module
Publication 1732E-IN001A-EN-E - July 2016
Auxiliary Power Connectors
Attach the micro-style 4-pin connector to the micro-style 4-pin receptacle as shown below.
Auxiliary Power Micro-style 4-Pin Receptacles
The power required by the module is based on a 4-pin micro-style connector system. The
module receives its required power through the male connector on the left. A female
connector on the right is also provided so that power can be daisy-chained from module to
module.
The module requires two 24V DC (nominal) supplies. These supplies are called the
Module Power and the Auxiliary Power. The Module power powers the microprocessor
and Ethernet portions of the module. The Auxiliary Power provides power for the Digital
Outputs, the Digital Inputs, and the Sensor Voltage.
Internally, the Module Power and Auxiliary Power are isolated from each other.
IMPORTANT
The maximum current that any pin on the power connectors can carry is 4 A.
1
4
3
2
Male Input Female Output
(View into receptacle)
Pin 1 Auxiliary power+
Pin 2 Module/sensor power+
Pin 3 Module/sensor power-
Pin 4 Auxiliary power-
45764
3
4
1
2
45763

ArmorBlock I/O 8 Channel IO-Link Master Module 13
Publication 1732E-IN001A-EN-E - July 2016
Interpret LED Indicators
This module has the following indicators:
• Module, Network, and Link status indicators for EtherNet/IP
•Powerstatusindicator
• Individual channel status indicators for inputs and outputs
Status Indicators
Indicator Status for Module
Indicator Status Description
Module status Off No power applied to the device.
Flashing green The device has not been configured.
If Master Sync Enable bit is set, and the device is not
synchronized to a PTP master, the device is not configured.
Green Device operating normally.
Red Unrecoverable fault – may require device replacement.
Link 2 status indicator
Network status indicator
45871
Module status indicator
I/O status indicators
Auxiliary Power status indicator
Link 1 status indicator

14 ArmorBlock I/O 8 Channel IO-Link Master Module
Publication 1732E-IN001A-EN-E - July 2016
Module status Flashing red One or more recoverable minor faults detected. Possible
minor faults indicated are:
•The device is performing a firmware flash update.
•The IO-Link stack is faulted.
•IP Address switches do not match configuration in use
•The device has completed a reset to factory default
request due to the switches being set to 888 at power
up, and a power cycle is required.
Flashing red/green The module is performing POST (Power-On Self Test), which
completes within 30 s.
Network status Off The device is not initialized or the module does not have an
IP address.
Flashing green The device has an IP address, but no connections are
established.
Green The device is online, has an IP address, and at least one
connection is established.
Flashing red One or more connections have timed out.
Red The module has detected that its IP address is already in
use.
Link status Off No link established.
Green Link established on indicated port at 100 Mbps.
Flashing green Link activity present on indicated port at 100 Mbps.
Yellow Link established on indicated port at 10 Mbps.
Flashing yellow Link activity present on indicated port at 10 Mbps.
Auxiliary power
status Off No power to device or input not valid.
Green Power applied to device.
Channel LED Indicator Status for Module
Indicator Status Mode Description
Channel LED
status Off Both Output/input is in off state, is in IO-Link mode but is not energized.
Yellow Standard I/O Output/input is in on state.
Flashing green IO-Link Port startup or IO-Link device not found.
Green IO-Link IO-Link enabled.
Flashing red IO-Link IO-Link device connected to channel does not match
configured electronic key.
Red Both Output is shorted or over-current condition exists.
IMPORTANT
The Module Status LED indicator will flash red and green for a maximum
30 s while the module completes its POST (Power-On Self Test).
Indicator Status for Module
Indicator Status Description

ArmorBlock I/O 8 Channel IO-Link Master Module 15
Publication 1732E-IN001A-EN-E - July 2016
Specifications
General Specifications
Attribute Value
Number of inputs/outputs 8 Type 1 defined, sinking
Communication rate, Ethernet 10/100 Mbps, Full or half-duplex
100 meter per segment
Communication rate, IO-Link 4.8 kB; 38.4 kB; 230.4 kB
Voltage, power, max 28.8V DC
Voltage, power, min 20V DC
Current, Module Power, max per module 100 mA @ 24V DC
Current, Auxiliary Power, module only (no
Digital Output loads, no Sensor Voltage
Loads, and no power daisy-chain loads)
30 mA @ 24V DC
Current, Auxiliary Power, max per module
(module plus Digital Output Loads, plus
Sensor Voltage Loads, plus power
daisy-chain loads)
4 A
Isolation voltage 50V (continuous), Basic Insulation Type, outputs and output
power to Network. 50V Basic Insulation Type between the
field network connections. 50V Basic Insulation Type between
module power and output power.
No isolation between individual I/Os or between I/Os and
output power. No isolation between both network channels at
the CPU/DLR power side.
Status indicators Module status – red/green
Network status – red/green
Link status – green/yellow
Power status – green
I/O LED – yellow/red
IO-Link LED – green/red
Dimensions, approx., HxWxD 179 x 37 x 27 mm (7.05 x 1.46 x 1.06 in.)
Pilot Duty Rating DC-14
Weight, approx. 0.34 kg (0.75 lb)
Wiring category(1)
(1) Use this Conductor Category information for planning conductor routing. Refer to publication 1770-4.1, Industrial
Automation Wiring and Grounding Guidelines.
1 – on signal ports
1 – on power ports
1 – on communication ports
Enclosure type rating Meets IP65/66/67/69K

16 ArmorBlock I/O 8 Channel IO-Link Master Module
Publication 1732E-IN001A-EN-E - July 2016
ArmorBlock I/O 8 Channel IO-Link Master Module – Standard Digital Input
Attribute Value
On-state voltage, min 15V DC
On-state current, min 2.0 mA
Off-state voltage, max 5V DC
Off-state current, max 1.5 mA
Input delay time Software configurable
Sensor Source Voltage (SSV) voltage,
min 1V
Sensor Source Voltage (SSV)
available current, per channel, max 500 mA
Sensor Source Voltage (SSV)
available current, per connector, max 1 A
Short circuit detection Per I/O connector (two shared channels per I/O connector)
ArmorBlock I/O 8 Channel IO-Link Master Module – Standard Digital Output
Attribute Value
On-state voltage, min 15V DC
On-state voltage, max 28.8V DC
On-state voltage, nom 24V DC
On-state current, per output, max 250 mA
On-state current, total for all
channels combined, max 2 A (250 mA X 8 outputs)
Off-state current leakage, per
output, max 500 A
Surge current, per output, max 0.3 A for 10 ms, repeatable every 3 seconds.
Short circuit detection Per channel

ArmorBlock I/O 8 Channel IO-Link Master Module 17
Publication 1732E-IN001A-EN-E - July 2016
Environmental Specifications
Attribute Value
Temperature, operating IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
-20…60 °C (-4…140 °F)
Temperature, ambient
rating (UL) 60 °C (140 °F)
Temperature, nonoperating IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating Cold),
IEC 60068-2-2 (Test Bb, Unpackaged Nonoperating Dry Heat),
IEC 60068-2-14 (Test Na, Unpackaged Nonoperating Thermal Shock):
-40…85 °C (-40…185 °F)
Relative humidity IEC 60068-2-30 (Test Db, Unpackaged Damp Heat):
5…95% noncondensing
Vibration IEC 60068-2-6 (Test Fc, Operating):
5 g @ 10…500 Hz
Shock, operating IEC 60068-2-27 (Test Ea, Unpackaged Shock):
30 g
Shock, nonoperating IEC 60068-2-27 (Test Ea, Unpackaged Shock):
50 g
Emissions CISPR 11 (IEC 61000-6-4):
Class A
ESD immunity IEC 61000-4-2:
6 kV contact discharges
8 kV air discharges
Radiated RF immunity IEC 61000-4-3:
10V/m with 1 kHz sine-wave 80% AM from 80...1000 MHz
10V/m with 1 kHz sine-wave 80% AM from 1000...2000 MHz
10V/m with 200 Hz SQ-wave 100% Pulse modulated at 50% duty cycle
@ 900 MHz Pulse
10V/m with 200 Hz 50% Pulse 100% AM @ 1890 MHz Pulse
10V/m with 1 kHz sine-wave 80% AM from 2000…2700 MHz
EFT/B immunity IEC 61000-4-4:
±3 kV at 5 kHz on power ports
±3 kV at 5 kHz on signal ports
Surge transient immunity IEC 61000-4-5:
±1 kV line-line(DM) and ±2 kV line-earth(CM) on power ports
±1 kV line-earth(CM) on signal ports
±2 kV line-earth(CM) on communication ports
Conducted RF immunity IEC 61000-4-6:
10V rms with 1 kHz sine-wave 80% AM from 150 kHz…80 MHz

18 ArmorBlock I/O 8 Channel IO-Link Master Module
Publication 1732E-IN001A-EN-E - July 2016
Certifications
Certification (when
product is marked)(1) Value
c-UR-us UL Recognized Component, certified for US and Canada. See UL File
E322657.
CE EMC Directive 2014/30/EU Directive, compliant with:
EN 61326-1; Meas./Control/Lab., Industrial Requirements
EN 61000-6-2; Industrial Immunity
EN 61000-6-4; Industrial Emissions
EN 61131-2; Programmable Controllers (Clause 8, Zone A & B)
RCM Australian Radiocommunications Act, compliant with:
AS/NZS CISPR11; Industrial Emissions.
KC Korean Registration of Broadcasting and Communications Equipment,
compliant with:
Article 58-2 of Radio Waves Act, Clause 3
EtherNet/IP ODVA conformance tested to EtherNet/IP specifications.
(1) See the Product Certification link at http://www.rockwellautomation.com/products/certification/ for Declaration of
Conformity, Certificates, and other certification details.

ArmorBlock I/O 8 Channel IO-Link Master Module 19
Publication 1732E-IN001A-EN-E - July 2016
Notes:

Rockwell Automation Support
Rockwell Automation provides technical information on the Web to assist you in using its products. At
http://www.rockwellautomation.com/support/, you can find technical manuals, a knowledge base of FAQs,
technical and application notes, sample code and links to software service packs, and a MySupport feature
that you can customize to make the best use of these tools.
For an additional level of technical phone support for installation, configuration and troubleshooting, we
offer TechConnect support programs. For more information, contact your local distributor or Rockwell
Automation representative, or visit http://www.rockwellautomation.com/support/.
Installation Assistance
If you experience a problem within the first 24 hours of installation, please review the information that's
contained in this manual. You can also contact a special Customer Support number for initial help in getting
your product up and running.
New Product Satisfaction Return
Rockwell Automation tests all of its products to ensure that they are fully operational when shipped from
the manufacturing facility. However, if your product is not functioning and needs to be returned, follow
these procedures.
Documentation Feedback
Your comments will help us serve your documentation needs better. If you have any suggestions on how to
improve this document, complete this form, publication RA-DU002, available at
http://www.rockwellautomation.com/literature/.
Rockwell Automation maintains current product environmental information on its website at
http://www.rockwellautomation.com/rockwellautomation/about-us/sustainability-ethics/product-environmental-compliance.page.
United States or Canada 1.440.646.3434
Outside United States or
Canada Use the Worldwide Locator at
http://www.rockwellautomation.com/support/americas/phone_en.html, or
contact your local Rockwell Automation representative.
United States Contact your distributor. You must provide a Customer Support case number
(call the phone number above to obtain one) to your distributor to complete
the return process.
Outside United States Please contact your local Rockwell Automation representative for the return
procedure.
Publication 1732E-IN001A-EN-E - July 2016
Copyright © 2016 Rockwell Automation, Inc. All rights reserved.
Allen-Bradley, Rockwell Automation, and ArmorBlock I/O are trademarks of Rockwell Automation, Inc.
Trademarks not belonging to Rockwell Automation are property of their respective companies.
