Allen-Bradley CENTERLINE 1500 User manual

CENTERLINE 600 A One-High Cabinet, Standard and
Arc-Resistant Enclosure
Bulletin Numbers 1512A, 1512AT, 1512DM, 1512DO, 1512M, 1562E, 1912B, 1912L
User Manual
Original Instructions

Important User Information
Read this document and the documents listed in the additional resources section about installation, configuration, and
operation of this equipment before you install, configure, operate, or maintain this product. Users are required to
familiarize themselves with installation and wiring instructions in addition to requirements of all applicable codes, laws,
and standards.
Activities including installation, adjustments, putting into service, use, assembly, disassembly, and maintenance are
required to be carried out by suitably trained personnel in accordance with applicable code of practice.
If this equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment may
be impaired.
In no event will Rockwell Automation, Inc. be responsible or liable for indirect or consequential damages resulting from
the use or application of this equipment.
The examples and diagrams in this manual are included solely for illustrative purposes. Because of the many variables and
requirements associated with any particular installation, Rockwell Automation, Inc. cannot assume responsibility or
liability for actual use based on the examples and diagrams.
No patent liability is assumed by Rockwell Automation, Inc. with respect to use of information, circuits, equipment, or
software described in this manual.
Reproduction of the contents of this manual, in whole or in part, without written permission of Rockwell Automation,
Inc., is prohibited.
Throughout this manual, when necessary, we use notes to make you aware of safety considerations.
Labels may also be on or inside the equipment to provide specific precautions.
WARNING: Identifies information aboutpractices or circumstances that can cause an explosion in a hazardous
environment, which may lead to personal injury or death, property damage, or economic loss.
ATTENTION: Identifies information about practices or circumstances that can lead to personal injury or death, property
damage, or economic loss. Attentions help you identify a hazard, avoid a hazard, and recognize the consequence.
IMPORTANT Identifies information that iscritical for successful application and understanding of the product.
SHOCK HAZARD: Labels may be on or inside the equipment, for example, a drive or motor, to alert people that dangerous
voltage may be present.
BURNHAZARD:Labels may be onor inside theequipment, for example, adriveormotor,toalert peoplethatsurfacesmay
reach dangerous temperatures.
ARC FLASH HAZARD: Labels may be on or inside the equipment, for example, a motor control center, to alert people to
potentialArcFlash.ArcFlashwillcausesevereinjury or death. WearproperPersonalProtectiveEquipment(PPE).FollowALL
Regulatory requirements for safe work practices and for Personal Protective Equipment (PPE).

Rockwell Automation Publication 1512A-UM101A-EN-P - October 2018 3
TableofContents
Preface
About This Publication. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
What This Manual Contains. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Additional Resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Chapter 1
General Information Starter Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Recommended Torque Values. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Recommended Line and Load Cable Sizes. . . . . . . . . . . . . . . . . . . . . . . 11
Environmental Conditions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
High Altitude Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Chapter 2
Installation – Standard Enclosure Door Opening Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Opening the Low Voltage Doors. . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Opening the Medium Voltage Doors. . . . . . . . . . . . . . . . . . . . . . . . 14
Anchoring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Joining Sections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Access to the Power Bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Rear Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Side Access. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Front Access – Top Incoming Line Cables and Power Bus . . . . 20
Front Access – Bottom Incoming Line Cables . . . . . . . . . . . . . . . 23
Load Cable Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Chapter 3
Installation – Arc-Resistant
(ArcShield) Door Opening Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Opening the Low Voltage Doors. . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Opening the Medium Voltage Door. . . . . . . . . . . . . . . . . . . . . . . . . 28
Anchoring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Joining Sections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Access to the Power Bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Rear Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Side Access. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Front Access to Power Bus (Bottom Entry/Exit) . . . . . . . . . . . . . 34
Front Access – Top Incoming Line Cables (Top Entry/Exit). . 35
Load Cable Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Chapter 4
Common Installation Bus Splicing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Power Bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Insulated Power Bus Splicing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Ground Bus. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Incoming Line Cable Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

4Rockwell Automation Publication 1512A-UM101A-EN-P - October 2018
Table of Contents
Hi-Pot and Insulation Resistance Test . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Start-up Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Contactor Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Preliminary Checks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Testing Contactor Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Chapter 5
Maintenance Recommended Maintenance Schedule . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Tool Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Door Interlock Circumvention. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Power Lock-out Procedure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Fuse Removal and Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Bolt-on Fuse Removal/Installation. . . . . . . . . . . . . . . . . . . . . . . . . . 53
Clip-on Fuse Removal/Installation. . . . . . . . . . . . . . . . . . . . . . . . . . 54
Contactor Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Remove the Contactor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Contactor Interlock Rod Adjustment. . . . . . . . . . . . . . . . . . . . . . . . . . . 58
To Reduce the Gap Distance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
To Increase the Gap Distance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Isolation Switch Mechanism Inspection and Lubrication . . . . . . . . . 60
Isolation Blade Switch Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Isolation Switch Mechanism Grounding Adjustment. . . . . . . . . . . . . 64
Auxiliary Contacts Inspection and Replacement . . . . . . . . . . . . . . . . . 65
Auxiliary Contacts Adjustment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Adjusting the Normally Open (ISa) Contacts. . . . . . . . . . . . . . . . 66
Adjusting the Normally Closed (ISb) Contacts . . . . . . . . . . . . . . 67
Adjusting the Change-of-State Point . . . . . . . . . . . . . . . . . . . . . . . . 68
Emergency Circumvention Procedure for Power Cell Entry. . . . . . . 68
Installing Z-clip with Isolation Switch Handle in the
OFF Position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Installing Z-clip with Isolation Switch Handle in the
ON Position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Chapter 6
Spare Parts Spare Parts List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Appendix A
ArcShield Unit Information Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
ArcShield Design. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Exhaust Systems: Chimney or Plenum Option. . . . . . . . . . . . . . . . . . . 74
Plenum Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Plenum Exhaust Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Additional Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Chimney Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Chimney Exhaust Considerations. . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Rockwell Automation Publication 1512A-UM101A-EN-P - October 2018 5
Table of Contents
Appendix B
ArcShield Plenum Installation
Instructions Recommended Torque Values. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Plenum Bracing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
General Plenum Layout for ArcShield Line-up. . . . . . . . . . . . . . . . . . . 81
STEP 1 – Mounting a Single Plenum . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Cabinet Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Plenum Placement on Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
STEP 2 – Alignment of Side by Side Plenums. . . . . . . . . . . . . . . . . . . . 84
STEP 3 – Sequence of Final Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . 85
STEP 4 – Closing the Front of the Plenum Sections. . . . . . . . . . . . . . 86
STEP 5 – Extension and Elbow Assembly . . . . . . . . . . . . . . . . . . . . . . . 86
STEP 6 – Mounting Extension/Elbow to Plenum Line-up. . . . . . . . 87
STEP 7 – Additional Mounting Support. . . . . . . . . . . . . . . . . . . . . . . . 89
Appendix C
ArcShield Chimney Installation
Instructions Recommended Torque Values. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
General Plenum Layout for ArcShield Line-up. . . . . . . . . . . . . . . . . . . 92
Cabinet Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Chimney Placement on Structure. . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

6Rockwell Automation Publication 1512A-UM101A-EN-P - October 2018
Table of Contents
Notes:

Rockwell Automation Publication 1512A-UM101A-EN-P - October 2018 7
Preface
About This Publication This manual provides detailed installation instructions for installing, using the
operator handle, energizing, and maintaining your CENTERLINE® 1500
motor control center (MCC).
This manual is intended for engineers or technicians that are directly involved
in the installation, connection, energizing, and maintenance of the
CENTERLINE 1500 motor control center.
If you do not have a basic understanding of the CENTERLINE 1500 motor
control center, contact your local Allen-Bradley distributor or Rockwell
Automation sales representative for information on available training courses
What This Manual Contains This user manual contains the following sections:
• MCC anchoring, joining cabinets, and power bus access
• Information on components such as contactors, fuses, isolation switch,
and auxiliary contacts
• Required tools, recommended torque values, and how to perform
routine maintenance tasks
• ArcShield specific content, including installation, plenum and chimney
layout, and mounting information
• Spare Parts list
Additional Resources These documents contain additional information concerning related products
from Rockwell Automation.
You can view or download publications at
http://www.rockwellautomation.com/global/literature-library/overview.page.
To order paper copies of technical documentation, contact your local
Allen-Bradley distributor or Rockwell Automation sales representative.
Resource Description
Medium Voltage Motor Controllers Specification Guide,
publication 1500-SR020 Provides specifications for all medium voltage motor
control centers
General Handling Procedures for Medium Voltage
Controllers, publication MV-QS050 Providesinformationonlifting,moving,receiving,and leveling a medium voltage motor control center
MediumVoltageContactor800 A,2400…7200V(SeriesF)
User Manual, publication 1502-UM054 Provides information for handling, installing, maintaining and troubleshooting the 800 A contactor
Industrial AutomationWiring andGrounding Guidelines,
publication 1770-4.1 Provides general guidelines for installing a Rockwell
Automation industrial system.
Product Certifications website, http://
www.rockwellautomation.com/global/certification/
overview.page
Provides declarations of conformity, certificates, and
other certification details.

8Rockwell Automation Publication 1512A-UM101A-EN-P - October 2018
Preface
Notes:

Rockwell Automation Publication 1512A-UM101A-EN-P - October 2018 9
Chapter 1
General Information
This manual pertains to the CENTERLINE® 1500, 600 A medium voltage
motor control center. This MCC structure provides one complete medium
voltage controller unit.
The installation section provides instructions for both the standard enclosure
type and the arc resistant structure type (ArcShield™).
The product Bulletin numbers that are primarily covered by this document are:
• 1512A 600 A FVNR controller
• 1512AT 600 A Transformer Feeder
This document can be used as a reference guide for the following Bulletin
numbers:
• 1512DM 600 A VFD Input Contactor Units
• 1512DO 600 A VFD Output Contactor Units
• 1512M 600 A VFD Output Bypass Starter
• 1562E 600 A MV SMC Flex Solid-State
Reduced Voltage Starter Input Section
• 1912B 600 A Synchronous Controller (Stator)
• 1912L 600 A Brushless Synchronous Controller (Stator)
Starter Identification A nameplate is attached to the right-side flange of the structure (see Figure 1).
See the nameplate for information such as series number, section number,
NEMA enclosure type, unit ratings, and bus ratings.
IMPORTANT This document is to be used for all Bulletin 1512 and Bulletin 1912 unit
types, including arc resistant (ArcShield) units. See Appendix A, Appendix B,
and Appendix C for specific ArcShield information.
ATTENTION: Refer to the information in Appendix A, Appendix B, and
Appendix C to correctly install and maintain ArcShield arc resistant units.
Failure to do so may negate the arc resistant benefits that are provided by
ArcShield,exposing personnel to risk of serious injury or death.

10 Rockwell Automation Publication 1512A-UM101A-EN-P - October 2018
Chapter 1 General Information
Figure 1 - Typical Structure Nameplate
A nameplate is also found in the low voltage compartment (see Figure 2) with
specific unit motor application information.
Figure 2 - Typical Unit Nameplate
See these nameplates whenever you contact Rockwell Automation for
assistance. Be prepared to provide such information as series number, structure
series, unit series, diagram schematic, and catalog number.

Rockwell Automation Publication 1512A-UM101A-EN-P - October 2018 11
General Information Chapter 1
Recommended Torque
Values
When reinstalling components, or when reassembling the cabinet, tighten the
following bolt sizes to the specified torque values:
Table 1 - Torque Values for Hardware
RecommendedLineandLoad
Cable Sizes
Environmental Conditions The controller must accept nominal plant power of 2400V, 3300V, 4200V,
4800V, 5500V, 6600V, 6900V (+5/-15%), or 7200V (+0/-15%), 3 PH,
50/60 Hz (± 3%).
The standard controller must operate in an ambient temperature range of
0…40 °C (32…104 °F) with a relative humidity of up to 95% (noncondensing).
Higher ambient temperature conditions are supported with factory assistance.
Store the equipment in an environment with an ambient temperature range of
-40…+85 °C (-40…+185 °F).
If storage temperature fluctuates or if humidity exceeds 85%, space heaters
must be used to prevent condensation. The equipment must be stored in a
heated building which has adequate air circulation.
Rockwell Automation products are built using materials that comply with
Class 1: Industrial Clean Air sulfur environments as defined in IEC Standard
60654-4 (Operating Conditions for Industrial-Process Measurement and
Control Equipment), and G1 as defined in ISO-S71.04-1985 (Environmental
Conditions for Process Measurement and Control Systems: Airborne
Contaminants).
1/4 in. hardware 8 N•m (6 lb•ft)
5/16 in. hardware 15 N•m (12 lb•ft)
3/8 in. hardware 27 N•m (20 lb•ft)
1/2 in. hardware 65 N•m (48 lb•ft)
Table 2 - Recommended Maximum Line and Load Cable Sizes
Standard Cabinet Arc Resistant Cabinet
Line cables (2) 500 MCM or (1) 750 MCM per phase (1) 500 MCM or (2) 4/0 per phase
Load cables (1) 500 MCM or (2) 250 MCM per phase (1) 500 MCM or (2) 250 MCM per phase
WARNING: Do not store the equipment outside.

12 Rockwell Automation Publication 1512A-UM101A-EN-P - October 2018
Chapter 1 General Information
High Altitude Application
The equipment operates at altitudes from 0…1000 m (0…3300 ft) above sea
level, without derating. For applications above 1000 m (3300 ft), the
maximum current and basic impulse levels (BIL) of the controllers shall be
derated, and vacuum contactors may be compensated for operation at the
specified altitude (see publication 1500-SR020).

Rockwell Automation Publication 1512A-UM101A-EN-P - October 2018 13
Chapter 2
Installation – Standard Enclosure
Door Opening Procedure Opening the Low Voltage Doors
Low voltage doors are identified as LV in Figure 3.
1. To access the low voltage compartment, use a screwdriver and turn both
of the 1/4-turn fasteners, which are located on the low voltage door, 90°
in a counterclockwise direction.
2. The door is now released and will swing open.
3. Reverse the procedure to secure the doors.
Figure 3 - Standard Cabinet
IMPORTANT For information on the installation site preparation, seepublication
MV-QS050.
ATTENTION: Use suitable personal protective equipment (PPE) per local
codes or regulations. Failure to do so may result in severe burns, injury, or
death. Refer to the standards such as NFPA 70E, Standard for Electrical Safety
in the Workplace and CSA Z462, Workplace Electrical Safety Standard for
safety guidance when working in and around electrical equipment.
1/4 Turn Fasteners for Upper Low Voltage Door
1/4 Turn Fasteners for Lower Low Voltage Door

14 Rockwell Automation Publication 1512A-UM101A-EN-P - October 2018
Chapter 2 Installation – Standard Enclosure
Refer to Access to the Power Bus on page 18 for the procedure to open the
swing-out low voltage panel behind the low voltage door.
Opening the Medium Voltage Doors
The medium voltage doors are identified as MV in Figure 4.
Figure 4 - MV Door Locking Bolt and Isolation Switch Location
Refer to Access to the Power Bus on page 18 for the procedure to open the
swing-out low voltage panel behind the low voltage door (for standard cabinet
only).
1. Electrically open the contactor by pressing the STOP button on the
starter or at the remote control location.
2. Move the isolation switch handle to the OFF position.
3. Unscrew the door locking bolts for both medium voltage doors.
ATTENTION: Medium voltage components may be located behind the
swing-out low voltage panel (standard cabinets only). Complete the power
lockout procedure (See Power Lock-out Procedure on page 49) before
attempting to open the swing-out low voltage panel. Failure to do so may
result in severe burns, injury, or death.
ATTENTION: Complete the Power Lockout procedure (See Power Lock-out
Procedure on page 49) before beginning anyservice procedures to the unit.
Failure to do so may result in severe burns, injury, or death.
IMPORTANT The medium voltage doors have their own isolation switch handle and
interlocking safeguards. The top MV door must be opened before the lower
MV door can be opened.
Isolation Switch
Door Locking Bolts for Upper
Medium Voltage Door
Door Locking Bolts for Lower
Medium Voltage Door

Rockwell Automation Publication 1512A-UM101A-EN-P - October 2018 15
Installation – Standard Enclosure Chapter 2
4. The doors are now released and will swing open to the left.
5. Reverse the procedure to close the door
Anchoring Place the controller in the desired installation location. The floor must be flat
and level. The mounting surface for the equipment must be flat and within
±1 mm per meter. Installing metal shims is an acceptable method of
compensating for mounting surfaces that are out of tolerance. Mounting
surfaces that are not flat may inhibit proper set-up and operation of the latches
and interlocks. Use four M12 (1/2 in.) floor mounting bolts to securely fasten
the controller to the mounting surface. See Figure 6 as an example of the
location of the mounting holes in the cabinet.
IMPORTANT Verify that the swing-out low voltage panel is in its original position
before attempting to close the MV door. When closing the medium
voltage door, confirm all doorlocking bolts on the right side of the
MV door are in place and tightened until the door isflush with the
flange. Donotovertightenthebolts.Ifthe door is not securely
fastened,itisnotbepossibletomovetheisolationswitchhandletothe
ONposition.
ATTENTION: Complete the Power Lock-out procedure (See Power
Lock-out Procedure on page 49) before beginning anyservice
procedures to the unit. Failure to do so may result in severe burns,
injury or death.
TIP Refer to Dimension Drawing provided with order documentation for
additional details that are related to cabinet floor plan.
IMPORTANT Pre-determined cabinets have been designed for Uniform Building Code
(UBC) seismic zone 1, 2A, 2B, 3 and 4, and IBC (International Building Code)
seismic activity without overturning or lateral movement, provided they are
securely mounted according to UBC, IBC, and local building codes. Thiscan
include concrete paddesign, steel floor design, and thesizing of cabinet
anchors. Concrete floor cutouts must not be next to floor anchor bolts and
must be sized to seismic load. Consult the factory if floor mounting must be
reviewed by an accredited engineer. Many jurisdictions require an engineer
from the local area to review the design. Seismic qualification does not
indicate that the equipment will function properly after a seismic event.

16 Rockwell Automation Publication 1512A-UM101A-EN-P - October 2018
Chapter 2 Installation – Standard Enclosure
Figure 5 - Standard Top Entry/Exit Locations
Figure 6 - Standard Bottom Entry/Exit Locations and Mounting Locations
SeismicApplications
•For installation on concrete – the minimum depth and radius of the
concrete which support the cabinet anchors is dependent on seismic
loads. See important information above.
•For installation on a metal structure – the metal plate depth and
cabinet anchoring method is dependent on seismic loads.
• A - Line Cable Conduit Opening
5.68 x 9.00 [144 x 229]
• B - Load Cable Conduit Opening
9.00 x 10.00 [229 x 242]
• C - Control Wire Conduit Opening
3.00 x 3.00 [76 x 76]
0 [0]
4.65 [118]
16.04 [407]
30.00 [762]
36.00 [914]
0 [0]
3.62 [92]
5.41 [137]
6.62 [168]
36.00 [914]
A
B
C
A
B
C
D
E
• A - Line Cable Conduit Opening
5.68 x 9.00 [144 x 229]
• B - Load Cable Conduit Opening
9.00 x 10.00 [229 x 242]
• C - Control Wire Conduit Opening
3.00 x 5.00 [76 x 127]
• D - Non-removable Sill Channels
1.00 x 3.00 [25 x 76]
• E - Mounting Holes for 0.5 in. [12mm]
Diameter Anchor Bolts
0 [0]
4.70 [119]
9.32 [237]
21.15 [537]
30.00 [762]
33.00 [838]
36.00 [914]
0 [0]
2.31 [59]
4.62 [117]
6.38 [162]
7.68 [170]
33.69 [856]
36.00 [914]

Rockwell Automation Publication 1512A-UM101A-EN-P - October 2018 17
Installation – Standard Enclosure Chapter 2
Joining Sections
1. Position the left side section on a level surface and secure the section in
place with M12 (1/2 in.) floor mounting bolts (refer to Anchoring on
page 15).
2. When joining NEMA/EEMAC Type 12 sections, apply a continuous
3 mm (1/8 in.) wide bead of silicon sealer around the perimeter of one
section.
3. Remove the side bus access covers if applicable.
4. Position the right section against the left section. Verify that the surface
is level.
5. Secure the sections together using the 1/4-20 self-tapping screws.
Thread the screw through the 7 mm (0.281 in.) clearance hole to the
corresponding 6 mm (0.219 in.) pilot hole. To access the front clearance
holes of the left-side cabinet, open the medium voltage doors. To access
the rear clearance holes, remove the rear covers of the starter. If rear
access is not available, refer to Front Access – Top Incoming Line Cables
and Power Bus on page 20 or Front Access – Bottom Incoming Line
Cables on page 23.
6. Secure the right section to the floor using M12 (1/2 in.) floor mounting
bolts (refer to Anchoring on page 15).
TIP Joining hardware can be found in a package that ismounted to the front of
the shipping skid. See publication MV-QS050 for level floor surface
requirements.
IMPORTANT For arc resistant cabinets, see Chapter 3 for special instructions.
ATTENTION: The mounting surface for the equipment must be flat and
within ±1 mm per meter. Installing metal shims is an acceptable method of
compensating for mounting surfaces that are out oftolerance. Mounting
surfaces that are not flat may inhibit proper set-up and operation of the
latches and interlocks.

18 Rockwell Automation Publication 1512A-UM101A-EN-P - October 2018
Chapter 2 Installation – Standard Enclosure
Figure 7 - Joining Sections
Access to the Power Bus
Rear access is the preferred access method for attaching line cables and for
making bus splice connections. However, these procedures can be done with
front-only access. Front access requires more time and disassembly of the
equipment to complete this procedure.
Rear Access
1. Remove the hardware securing the center rear bus access cover
(Figure 8).
2. Remove the center rear bus access cover.
3. Once the rear bus cover is removed, you will see the three busbars
(Figure 9).
Front
Front
Side Bus
Access Cover
0.219Pilot
Holes (5x)
0.281 Pilot
Holes (5x)
0.281 Pilot
Holes (5x)
0.219Pilot
Holes (3x)
ATTENTION: This procedure requirescontact with medium voltage
components. To avoid shock hazards, lock out incoming power before
working on the equipment (See Power Lock-out Procedure on page 49).
Verify with a hotstick or appropriate voltage measuring device that all
circuits are voltage free. Failure to do so may result in severe burns, injury, or
death.

Rockwell Automation Publication 1512A-UM101A-EN-P - October 2018 19
Installation – Standard Enclosure Chapter 2
Figure 8 - Access to Power Bus from Side and Rear of Cabinet
Figure 9 - Rear Power Bus Access, Rear Panel Removed
Side Access
A side bus access cover is on each side of the controller.
1. Remove the hardware from the appropriate side bus access cover.
2. Remove the side bus access cover.
3. Once the side bus access cover is removed, you will see the three busbars.
(Figure 10).
Side Bus
Access Cover
Center Rear Bus
Access Cover

20 Rockwell Automation Publication 1512A-UM101A-EN-P - October 2018
Chapter 2 Installation – Standard Enclosure
Figure 10 - Side Power Bus Access, Right Side Access Panel Removed
Front Access – Top Incoming Line Cables and Power Bus
Complete the Power Lockout Procedure (See Power Lock-out Procedure on
page 49) for both medium voltage power cells and the power bus.
1. Open the low voltage cell door (refer to Opening the Low Voltage
Doors on page 13).
2. Open the medium voltage cell doors (refer to Opening the Medium
Voltage Doors on page 14).
3. Remove the three door hinge pins on each medium voltage
compartment door.
4. With two people, carefully set the doors carefully aside.
5. Remove two self-tapping screws from the upper low voltage panel
upright supports (Figure 11).
